Cisco Secure Firewall Management Center Device Configuration Guide, 10.x

About the dynamic attributes connector

The dynamic attributes connector enables your access control and DNS policy to adapt in real time to the changes in public and private cloud workloads and business-critical software-as-a-service (SaaS) applications. It simplifies policy management by keeping rules up to date without tedious manual updates and policy deployment. Customers require policy rules to be defined based on non-network constructs such as VM name or security group, so that firewall policy is persistent even when the IP address or VLAN changes.

How it works

This topic discusses the architecture of the dynamic attributes connector.

The following figure shows how the system functions at a high level.

The system supports certain public cloud providers.

This topic discusses supported connectors (which are the connections to those providers).
The dynamic attributes connector is provided with Secure Firewall Management Center.

Network download mode

The dynamic attributes connector always operated in network download mode. In this mode, the images required to make it work are downloaded from the internet. If your security requirements are strict, you can use air gapped mode.

Architectural overview:

Network download mode supports:

Table 1. List of supported connectors by dynamic attributes connector version
CSDAC version	AWS	AWS Security Groups	AWS Service Tags	Azure	Azure Service Tags	Cisco APIC	Cisco Cyber Vision	Cisco Multicl. Defense	Generic text	GitHub	Google Cloud	Microsoft Office 365	Tenable	vCenter	Webex	Zoom
Version 1.1 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	No	No	Yes	No	Yes	No	No
Version 2.0 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	No	Yes	Yes	No	Yes	No	No
Version 2.2 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	Yes	Yes	Yes	No	Yes	No	No
Version 2.3 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	Yes	Yes	Yes	No	Yes	Yes	Yes
Version 3.0 (on-premises)	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Version 3.1 (on-premises)	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes

Table 2. List of supported connectors by dynamic attributes connector platform
CSDAC version	AWS	AWS Security Groups	AWS Service Tags	Azure	Azure Service Tags	Cisco APIC	Cisco Cyber Vision	Cisco Multicl. Defense	Generic text	GitHub	Google Cloud	Microsoft Office 365	Tenable	vCenter	Webex	Zoom
Version 1.1 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	No	No	Yes	No	Yes	No	No
Cloud-delivered (Security Cloud Control)	Yes	No	No	Yes	Yes	No	No	Yes	No	Yes	Yes	Yes	Yes	No	No	No
Secure Firewall Management Center 7.4.1	Yes	No	No	Yes	Yes	No	No	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 7.6	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 7.7	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 10.0.0	Yes	Yes	Yes	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes

System requirements for the Dynamic Attributes Connector

The Dynamic Attributes Connector has the following memory requirements:


FMCv: Amount of RAM	Secure Firewall Management Center hardware model	Maximum number of (connectors + Azure AD realms)
At least 32 GB	Firepower 1000, Firepower 1600, vFMC	10
At least 64 GB	Firepower 2500, Firepower 2600,vFMC 300	20
At least 128 GB	Firepower 4500, Firepower 4600	30

The preceding limits apply to both virtual machines and physical machines.

The system prevents you from exceeding these limits to avoid deployment issues.

Enable the dynamic attributes connector

Enable the dynamic attributes connector to allow objects from cloud networking products to be used in Secure Firewall Management Center access controland DNS rules.

This task discusses how to enable the dynamic attributes connector in the Secure Firewall Management Center. The dynamic attributes connector is an integration that enables objects from cloud networking products to be used in Secure Firewall Management Center access controland DNS rules.

Procedure

Step 1	Log in to the Secure Firewall Management Center if you have not done so already.
Step 2	Click Integrations > Dynamic Attributes Connector.
Step 3	Slide to Enabled.
Step 4	Messages are displayed while the dynamic attributes connector is enabled. In the event of errors, try again. If errors persist, contact Cisco TAC.

What to do next

See Create a connector.

Configure networks and subnets for Docker containers

The Dynamic Attributes Connector uses Docker containers to retrieve connector data in the Secure Firewall Management Center. To avoid conflicts with the Secure Firewall Management Center management interface and other IP addresses used in your network, you can optionally use the command discussed in this section to change Docker IP addresses and ranges.

About Docker networks

The Docker daemon is used by the dynamic attributes connector requires the following networks:

docker0 which is used internally by the Docker daemon.
A series of IPv6 networks named vethnumber.

These are internal bridge networks used by the dynamic attributes connector.
Docker bridge networks used by dynamic attributes connector connectors named br-number.

Before you enable the dynamic attributes connector, there is only one Docker interface, named docker0, set to 172.18.0.1/16 (for a Secure Firewall Management Center Virtual; on-premises managers use different IP address ranges). The table in the Examples section provides details.

Change Docker networks and subnets

First enable the dynamic attributes connector as discussed in Enable the dynamic attributes connector.

To change Docker networks and subnets, run /usr/local/sf/bin/change_docker_subnet.sh -b CIDR-network -s address-pool-size as a user with root privileges where:

-b CIDR-network sets a network base address pool in CIDR notation.
-s address-pool-size sets a netmask for the network base address. You can use this option to limit the number of addresses in a base address range in the event the network range overlaps existing network ranges; in particular, we recommend certain -s values for Secure Firewall Management Center models to make sure you don't exceed the available RAM in the machine. (Docker containers are used by dynamic attributes connector connectors and those limits are shown in System requirements for the Dynamic Attributes Connector.)

Important

The networks you assign to Docker must be in an internal network range and must not conflict with networks used by the Secure Firewall Management Center or by other devices in your internal network.

Examples

The following table shows examples.


Secure Firewall Management Center model	Recommended -s value	Sample -b value	Dynamic Attributes Connector container addresses used
Firepower 1000, Firepower 1600, vFMC	27 (netmask 255.255.255.224)	172.19.0.0/16	30 IP addresses `docker0`: 172.19.0.1 Bridge networks `br-number` gateway `172.19.0.33` with subnet `172.19.0.32/27` Connectors created in networks like `172.19.0.38/27`, `172.19.0.39/27`, and so on
Firepower 2500, Firepower 2600, vFMC 300	26 (netmask 255.255.255.192)	192.168.0.0/16	62 IP addresses `docker0`: 192.168.1.1 Bridge networks `br-number` gateway `192.168.1.65`with subnet `192.168.1.64/26` Connectors created in networks like `192.168.1.71/26`, `192.168.1.72/26`, and so on
Firepower 4500, Firepower 4600	25 (netmask 255.255.255.128)	192.168.0.0/16	126 IP addresses `docker0`: 192.168.1.1 Bridge networks `br-number` gateway `192.168.1.129`with subnet `192.168.1.128/25` Connectors created in networks like `192.168.1.136/25`, `192.168.1.135/25`, and so on

For reference, the complete commands follow:

sudo /usr/local/sf/bin/change_docker_subnet.sh -b 172.19.0.0/16 -s 27

sudo /usr/local/sf/bin/change_docker_subnet.sh -b 192.168.0.0/16 -s 26

sudo /usr/local/sf/bin/change_docker_subnet.sh -b 192.168.0.0/16 -s 25

Verify the networks

To verify your network settings, enter sudo docker network inspect muster-net. The command results are displayed in JSON format.

Troubleshoot

Following are some solutions to common errors you might encounter using this command.

Error: Pull subnet value can not be greater than size

Solution: Change the value of -s so it is less than the CIDR network value.

For example,

INCORRECT: sudo /usr/local/sf/bin/change_docker_subnet.sh -b 172.19.0.0/16 -s 8

CORRECT: sudo /usr/local/sf/bin/change_docker_subnet.sh -b 172.19.0.0/16 -s 20

Error: After running the command, the Docker networks are wrong.

Solution: Restart the Docker daemon: sudo pmtool restartbyid docker

Error: Cannot connect to the Docker daemon at unix:///var/run/docker.sock. Is the docker daemon running?

Solution: Restart Docker: pmtool restartbyid docker

Error: Input can't be empty

The -s parameter is required.

Error: Pull size - 32 - can not be greater than 32 or less than 0

Solution: Change the value of -s so it is greater than 0 and less than 32.

About the dashboard

To access the dynamic attributes connector dashboard, log in to the Secure Firewall Manager and click Integrations > Dynamic Attributes Connector at the top of the page.

If the dynamic attributes connector is not enabled, move the slider to enable it. This process could take several minutes to complete.

The dynamic attributes connector Dashboard page displays the status of your connectors, adapters, and filters at a glance. Following is an example of the Dashboard of an unconfigured system:

The Cisco Secure Dynamic Attributes Connector dashboard displays at-a-glance information about configured connectors, filters, and adapters

Among the things you can do with the Dashboard are:

Add, edit, and delete connectors and dynamic attributes filters.
See how connectors and dynamic attributes filters are related to each other.
View warnings and errors.

Related Topics

Dashboard of an unconfigured system
Dashboard of a configured system
Add, edit, or delete connectors
Add, edit, or delete dynamic attributes filters

Dashboard of an unconfigured system

Sample dynamic attributes connector Dashboard page of an unconfigured system:

The Cisco Secure Dynamic Attributes Connector dashboard displays at-a-glance information about configured connectors, filters, and adapters

The Dashboard initially displays all the types of connectors you can configure for your system. You can do any of the following:

Hover the mouse pointer over a connector and click to create a new one.
Click Go to Connectors to add, edit, or delete connectors (good for creating, editing, or deleting multiple connectors at the same time).

For more information, see Create a connector.

Related Topics:

Dashboard of a configured system
Add, edit, or delete connectors
Add, edit, or delete dynamic attributes filters

Dashboard of a configured system

Sample dynamic attributes connector Dashboard page of a configured system:

Click an area in the figure to learn more about it or click one of the links following the figure.

The Cisco Dynamic Attributes Connector dashboard displays at-a-glance information about configured connectors and filters

The Dashboard shows the following (from left to right):


Connectors column	Filters column
List of connectors with a number indicating how many of each type are configured. Connectors collect dynamic attributes that could be sent to the Secure Firewall Manager. Dynamic attributes filters specify what data is sent. Click to view more information about all configured connectors. You can also click the name of a connector to add, edit, or delete connectors; or to view detailed information about them. For more information, see Add, edit, or delete connectors.	List of dynamic attributes filters associated with each connector with a number indicating how many of each filter are associated with a connector. Click to view more information about all configured filters. You can also click the name of a filter to add, edit, or delete filters; or to view detailed information about them. For more information, see Add, edit, or delete dynamic attributes filters.

Note

Some connectors, such as Outlook 365 and Azure Service tags, automatically pull available dynamic objects without the need for a dynamic attributes filters. Those connectors display Auto in the column.

The Dashboard indicates whether or not an object is available. The Dashboard page is refreshed every 15 seconds but you can click Refresh ( refresh icon ) at the top of the page at any time to refresh immediately. If issues persist, check your network connection.

Related Topics:

Add, edit, or delete connectors
Add, edit, or delete dynamic attributes filters

Add, edit, or delete connectors

The Dashboard enables you to view or edit connectors. You can click the name of a connector to view all instances of that connector or you can click for the following additional options:

Go to Connectors to view all connectors at the same time; you can add, edit, and delete connectors from there.
Add Connector > type to add a connector of the indicated type.

Click any connector in the connectors column () to display more information about it; an example follows:

Displaying more information about connectors from the dashboard

You have the following options:

Click the Edit icon () to edit this connector.
Click the More icon () for additional options.
Click to close the panel.
Click Version to display the version of the . You can optionally copy the version to the clipboard if necessary for Cisco TAC.

The table at the bottom of the panel enables you to add dynamic attributes filters; or to edit or dynamic attributes connector delete connectors. A sample follows:

At the bottom of the page you can add, edit, or delete dynamic attributes filters

Click the Add icon () to add a dynamic attributes filter for this connector. For more information, see Create dynamic attributes filters.

Hover the mouse pointer over the Actions column to either edit or delete the indicated connector.

View error information

To view error information for a connector:

On the Dashboard, click the name of the connector that is displaying the error.
In the right pane, click Information ().

An example follows.
To resolve this issue, edit the connector settings as discussed in Create an Office 365 connector.
If you cannot resolve the issue, click Version and copy the version to a text file.
Provide all of this information to Cisco TAC.

Add, edit, or delete dynamic attributes filters

The dashboard enables you to add, edit, or delete dynamic attributes filters. You can click the name of a filter to view all instances of that filter or you can click for the following additional options:

Go to Dynamic Attributes Filters to view all configured dynamic attributes filters. You can add, edit, or delete dynamic attributes filters from there.
Add Dynamic Attributes Filters to add a filter.

For more information about adding dynamic attributes filters, see Create dynamic attributes filters.

An example follows:

Displaying information about a dynamic attributes filter from the dashboard

Note

Some connectors, such as Outlook 365 and Azure Service tags, automatically pull available dynamic objects without the need for a dynamic attributes filters. Those connectors display Auto in the column.

You have the following options:

Click a filter instance to view summary information about dynamic attributes filters associated with a connector.
Click the Add icon () to add a new dynamic attributes filter.

For more information, see Create dynamic attributes filters.
Click in the filters column () indicates the indicated connector has no associated dynamic attributes filters. Without associated filters, the connector can send nothing to Firewall Management Center.

One way to resolve the issue is to click in the filters column and click Add Dynamic Attributes Filter. A sample follows.
Click to add, edit, or delete filters.
Click to close the panel.

Create a connector

A connector is an interface with a cloud service. The connector retrieves network information from the cloud service so the network information can be used in policies on the Secure Firewall Management Center.

We support the following:

Table 3. List of supported connectors by dynamic attributes connector version and platform
CSDAC version	AWS	AWS Security Groups	AWS Service Tags	Azure	Azure Service Tags	Cisco APIC	Cisco Cyber Vision	Cisco Multicl. Defense	Generic text	GitHub	Google Cloud	Microsoft Office 365	Tenable	vCenter	Webex	Zoom
Version 1.1 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	No	No	Yes	No	Yes	No	No
Version 2.0 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	No	Yes	Yes	No	Yes	No	No
Version 2.2 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	Yes	Yes	Yes	No	Yes	No	No
Version 2.3 (on-premises)	Yes	No	No	Yes	Yes	No	No	No	No	Yes	Yes	Yes	No	Yes	Yes	Yes
Version 3.0 (on-premises)	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Version 3.1 (on-premises)	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Cloud-delivered (Security Cloud Control)	Yes	No	No	Yes	Yes	No	No	Yes	No	Yes	Yes	Yes	Yes	No	No	No
Secure Firewall Management Center 7.4.1	Yes	No	No	Yes	Yes	No	No	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 7.6	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 7.7	Yes	Yes	Yes	Yes	Yes	No	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes
Secure Firewall Management Center 10.0.0	Yes	Yes	Yes	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes	Yes	No	Yes	Yes	Yes

Amazon Web Services connector—About user permissions and imported data

The dynamic attributes connector imports dynamic attributes from AWS to Secure Firewall Management Center for use in policies.

Dynamic attributes imported

We import the following dynamic attributes from AWS:

Tags, user-defined key-value pairs you can use to organize your AWS EC2 resources.

For more information, see Tag your EC2 Resources in the AWS documentation
IP addresses of virtual machines in AWS.

Minimum permissions required

The dynamic attributes connector requires a user at minimum with a policy that permits ec2:DescribeTags, ec2:DescribeVpcs, and ec2:DescribeInstances to be able to import dynamic attributes.

Create an AWS user with minimal permissions for the dynamic attributes connector

This task discusses how to set up a service account with minimum permissions to send dynamic attributes to Secure Firewall Management Center . For a list of these attributes, see Amazon Web Services connector—About user permissions and imported data.

Before you begin

You must already have set up your Amazon Web Services (AWS) account. For more information about doing that, see this article in the AWS documentation.

Procedure

Step 1

Log in to the AWS console as a user with the admin role.

Step 2

From the Dashboard, click Security, Identity & Compliance > IAM.

Step 3

Click Access Management > Users.

Step 4

Click Add Users.

Step 5

In the User Name field, enter a name to identify the user.

Step 6

Click Access Key - Programmatic Access.

Step 7

At the Set permissions page, click Next without granting the user access to anything. You can grant user access later.

Step 8

Add tags to the user if desired.

Step 9

Click Create User.

Step 10

Click Download .csv to download the user's key to your computer.

Note

This is the only opportunity you have to retrieve the user's key.

Step 11

Click Close.

Step 12

At the Identity and Access Management (IAM) page in the left column, click Access Management > Policies.

Step 13

Click Create Policy.

Step 14

On the Create Policy page, click JSON.

Create a JSON policy

Step 15

Enter the following policy in the field:

{
	"Version": "2012-10-17",
	"Statement": [
		{
			"Effect": "Allow",
			"Action": [
				"ec2:DescribeTags",
				"ec2:DescribeInstances",
				"ec2:DescribeVpcs"
			],
			"Resource": "*"
		}
	]
}

Step 16

Click Next.

Step 17

Click Review.

Step 18

On the Review Policy page, enter the requested information and click Create Policy.

Step 19

On the Policies page, enter all or part of the policy name in the search field and press Enter.

Step 20

Click the policy you just created.

Step 21

Click Actions > Attach.

Step 22

If necessary, enter all or part of the user name in the search field and press Enter.

Step 23

Click Attach Policy.

What to do next

Create an AWS connector.

Create an AWS connector

This task discusses how to configure a connector that sends data from AWS to the Secure Firewall Management Center for use in policies.

Before you begin

Create a user with at least the privileges discussed in Create an AWS user with minimal permissions for the dynamic attributes connector.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from AWS.
Region	(Required.) Enter your AWS region code.
Access Key	(Required.) Enter your access key.
Secret Key	(Required.) Enter your secret key.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Amazon Web Services Security Groups connector—About user permissions

The dynamic attributes connector imports dynamic attributes from AWS to Secure Firewall Management Center for use in policies.

Minimum permissions required

The dynamic attributes connector requires a user at minimum with a policy that permits ec2:DescribeTags, ec2:DescribeVpcs, and ec2:DescribeInstances to be able to import dynamic attributes.

Create an AWS user with minimal permissions for the dynamic attributes connector

This task discusses how to set up a service account with minimum permissions to send dynamic attributes to Secure Firewall Management Center . For a list of these attributes, see Amazon Web Services connector—About user permissions and imported data.

Before you begin

You must already have set up your Amazon Web Services (AWS) account. For more information about doing that, see this article in the AWS documentation.

Procedure

Step 1

Log in to the AWS console as a user with the admin role.

Step 2

From the Dashboard, click Security, Identity & Compliance > IAM.

Step 3

Click Access Management > Users.

Step 4

Click Add Users.

Step 5

In the User Name field, enter a name to identify the user.

Step 6

Click Access Key - Programmatic Access.

Step 7

At the Set permissions page, click Next without granting the user access to anything. You can grant user access later.

Step 8

Add tags to the user if desired.

Step 9

Click Create User.

Step 10

Click Download .csv to download the user's key to your computer.

Note

This is the only opportunity you have to retrieve the user's key.

Step 11

Click Close.

Step 12

At the Identity and Access Management (IAM) page in the left column, click Access Management > Policies.

Step 13

Click Create Policy.

Step 14

On the Create Policy page, click JSON.

Create a JSON policy

Step 15

Enter the following policy in the field:

{
	"Version": "2012-10-17",
	"Statement": [
		{
			"Effect": "Allow",
			"Action": [
				"ec2:DescribeTags",
				"ec2:DescribeInstances",
				"ec2:DescribeVpcs"
			],
			"Resource": "*"
		}
	]
}

Step 16

Click Next.

Step 17

Click Review.

Step 18

On the Review Policy page, enter the requested information and click Create Policy.

Step 19

On the Policies page, enter all or part of the policy name in the search field and press Enter.

Step 20

Click the policy you just created.

Step 21

Click Actions > Attach.

Step 22

If necessary, enter all or part of the user name in the search field and press Enter.

Step 23

Click Attach Policy.

What to do next

Create an AWS connector.

Create an AWS Security Groups connector

This task discusses how to configure a connector that sends AWS security groups data to the Secure Firewall Management Center for use in policies.

Before you begin

Do all of the following:

Create AWS security groups as discussed in Work with security groups on the AWS documentation site.
Create a user with at least the privileges discussed in Create an AWS user with minimal permissions for the dynamic attributes connector.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from AWS. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Region	(Required.) Enter your AWS region code.
AWS Access Key	(Required.) Enter your access key.
AWS Secret Key	(Required.) Enter your secret key.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Create an AWS service tags connector

This topic discusses how to create a connector for Amazon Web Services (AWS) service tags to the Secure Firewall Management Center for use in policies.

For more information, see resources like the following on the AWS documentation site:

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
URL	(Required.) Do not change the URL unless advised to do so.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Azure connector—About user permissions and imported data

The dynamic attributes connector imports dynamic attributes from Azure to Secure Firewall Management Center for use in policies.

Dynamic attributes imported

We import the following dynamic attributes from Azure:

Tags, key-value pairs associated with resources, resource groups, and subscriptions.

For more information, see this page in the Microsoft documentation.
IP addresses of virtual machines in Azure.

Minimum permissions required

The dynamic attributes connector requires a user at minimum with the Reader permission to be able to import dynamic attributes.

Create an Azure user with minimal permissions for the dynamic attributes connector

This task discusses how to set up a service account with minimum permissions to send dynamic attributes to Secure Firewall Management Center . For a list of these attributes, see Azure connector—About user permissions and imported data.

Before you begin

You must already have a Microsoft Azure account. To set one up, see this page on the Azure documentation site.

Procedure

Step 1	Log in to the Azure Portal as the owner of the subscription.
Step 2	Click Azure Active Directory.
Step 3	Find the instance of Azure Active Directory for the application you want to set up.
Step 4	Click Add > App registration.
Step 5	In the Name field, enter a name to identify this application.
Step 6	Enter other information on this page as required by your organization.
Step 7	Click Register.
Step 8	On the next page, write down or copy the Client ID (also referred to as application ID) and the tenant ID (also referred to as the directory ID). A sample follows.
Step 9	Next to Client Credentials, click Add a certificate or secret.
Step 10	Click New Client Secret.
Step 11	Enter the requested information and click Add.
Step 12	Copy the value of the Value field to the clipboard. This value, and not the Secret ID, is the client secret.
Step 13	Go back to the main Azure Portal page and click Subscriptions.
Step 14	Click the name of your subscription.
Step 15	Copy the subscription ID to the clipboard.
Step 16	Click Access Control (IAM).
Step 17	Click Add > Add role assignment.
Step 18	Click Reader and click Next.
Step 19	Click Select Members.
Step 20	On the right side of the page, click the name of the app you registered and click Select.
Step 21	Click Review + Assign and follow the prompts to complete the action.

What to do next

See Create an Azure connector.

Create an Azure connector

This task discusses how to create a connector to send data from Azure to Secure Firewall Management Center for use in policies.

Before you begin

Create an Azure user with at least the privileges discussed in Create an Azure user with minimal permissions for the dynamic attributes connector.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from Azure. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Subscription Id	(Required.) Enter your Azure subscription ID.
Tenant Id	(Required.) Enter your tenant ID.
Client Id	(Required.) Enter your client ID.
Client Secret	(Required.) Enter your client secret.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Create an Azure Service Tags connector

This topic discusses how to create a connector for Azure service tags to the Secure Firewall Management Center for use in policies. The IP addresses associated with these tags are updated every week by Microsoft.

For more information, see Virtual network service tags on Microsoft TechNet.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from Azure. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Subscription Id	(Required.) Enter your Azure subscription ID.
Tenant Id	(Required.) Enter your tenant ID.
Client Id	(Required.) Enter your client ID.
Client Secret	(Required.) Enter your client secret.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Cisco APIC connector

The following topics discuss how to configure the Cisco APIC Integration with the Secure Firewall Management Center.

How to use dynamic objects from Cisco APIC in Secure Firewall Management Center access control rules or DNS Rules

Summarizes how to use both Cisco APIC and the Secure Firewall Management Center to configure the integration.

Table 4. Configure Secure Firewall Management Center access control rules or DNS rules using network object groups
	Cisco APIC	A tenant allows a Cisco APIC administrator to set up domain-based access control. See Basic User Tenant Configuration
	Cisco APIC	An application profile is a container for other objects, such as an endpoint group (EPG). See Basic User Tenant Configuration
	Cisco APIC	An EPG is a container for network objects that serves as the way that devices connect to the network. An ESG is a logical entity that contains a collection of physical or virtual network endpoints. See EPGs and ESGs
	Secure Firewall Management Center	If you haven't done so already, Enable the dynamic attributes connector.
	Secure Firewall Management Center	Create the Cisco APIC connector which retrieves EPGs and ESGs from Cisco APIC and enables them to be used in Secure Firewall Management Center access control policies or DNS policies. See Create a Cisco APIC connector.
	Secure Firewall Management Center	(Optional.) View the dynamic objects fetched from Cisco APIC. See View dynamic objects in the Secure Firewall Management Center.
	Secure Firewall Management Center	To use dynamic objects in access control policies or DNS policies, you must add them as dynamic objects to those rules. See Create access control rules or DNS rules using dynamic attributes filters.

System requirements for the integration with Cisco APIC

Your system must meet the following requirements:

Secure Firewall Management Center version: 10.0.0 and later.

Essentials license or better required; high availability is supported.
Firewall Threat Defense version: 7.2 and later.
Cisco APIC version: 3.0(1k) or later.
If you use the ACI Endpoint Update App, it must be version 2.6.

Get required information for the integration

This section discusses:

Information required to configure the integration
Information used in dynamic object names

Cisco ACI Endpoint Update App site prefix and update interval

This information applies to you only if you're currently using the Cisco ACI Endpoint Update App; otherwise, you can skip it.

To find the Cisco ACI Endpoint Update App site prefix and update interval:

Log in to Cisco APIC as a user with admin privileges.

For more information, see APIC Roles and Privileges Matrix.
Click Apps.
Under ACI Endpoint Update app, click Open.
Click Edit ().
Write down the values of Update Interval (In seconds) and Site Prefix.

Required to configure the integration: Find a user with appropriate access

To find a user with at least the read-all role with readPriv access and the tenant-admin role with writePriv access for the security domain:

Log in to Cisco APIC.
Click Admin.
In the left pane, click Users.
In the right pane, double-click the name of a user.
Scroll to Security Domains.
For the relevant security domain, make sure the user has at least the read-all role with readPriv access and the tenant-admin role with writePriv access for the security domain, as the following figure shows.

Cisco APIC tenant name

The Cisco APIC tenant name is used in the names of dynamic objects created by this integration. To find it:

Log in to Cisco APIC.
Click Tenants.
Write down the name of the tenant that contains objects to send to .

Cisco APIC application profile name

The Cisco APIC application profile name is used in the names of dynamic objects created by this integration. To find it:

Log in to Cisco APIC.
Click Tenants.
Double-click the name of your tenant.
Expand your tenant.
Expand Application Profiles.
Write down the name of the application profile that contains EPGs and ESGs to integrate with ASA.

EPG name

The Cisco APIC EPG name is used in the names of dynamic objects created by this integration. To find it:

Log in to Cisco APIC.
Click Tenants.
Double-click the name of your tenant.
Expand your tenant.
Expand Application Profiles.
Expand the name of the application profile.
Expand Application EPGs.
Write down the name of the EPG or ESG that has network object groups to send to ASA.

The following figure shows an example.

Example

The following figure shows the values in Cisco APIC.

Create a Cisco APIC connector

This topic discusses creating a Cisco APIC connector that gets network object groups from a configured endpoint group (EPG) on Cisco APIC.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 60 seconds.) Interval at which IP mappings are retrieved from Cisco APIC. We recommend setting this to 15 seconds.
IP or Hostname	Enter the fully-qualified domain name or IP address of the Cisco APIC server from which to retrieve network object groups from EPGs and ESGs. Do not enter a scheme (such as `https://`) and do not include a trailing slash.
Add another cluster IP	(Optional.) Enter the IP address of other servers in the Cisco APIC cluster.
Username	Enter the name of a Cisco APIC user with at least at least the `read-all` role with `readPriv` access and the `tenant-admin` role with `writePriv` access for the security domain. Objects from all tenants the user has privileges to can be pushed to .
Password	Enter the user's password.
Server Certificate	(Recommended if using fully-qualified domain name.) You have the following options: Paste the certificate authority (CA) chain you got as discussed in Manually get a certificate authority (CA) chain. Click Get Certificate > Fetch to automatically fetch the certificate or, if that is not possible, get the certificate manually as discussed in Manually get a certificate authority (CA) chain. Click Get Certificate > Browse from file to upload a certificate chain you downloaded previously.

Step 5

Click Test and make sure the test succeeds before you save the connector.

Step 6

Click Save.

Step 7

Make sure Ok is displayed in the Status column.

Manually get a certificate authority (CA) chain

In the event you cannot automatically fetch the certificate authority chain, use one of the following browser-specific procedures to get a certificate chain used to connect securely to vCenter or Firewall Management Center.

The certificate chain is the root certificate and all subordinate certificates.

You can optionally use one of these procedures to connect to the following:

vCenter or NSX
Firewall Management Center
Cisco APIC

Get a Certificate Chain—Mac (Chrome and Firefox)

Use this procedure to get a certificate chain using the Chrome and Firefox browsers on Mac OS.

Open a Terminal window.
Enter the following command.
```
security verify-cert -P url[:port]
```
where url is the URL (including scheme) to vCenter or Firewall Management Center. For example:
```
security verify-cert -P https://myvcenter.example.com
```
If you access vCenter or Firewall Management Center using NAT or PAT, you can add a port as follows:
```
security verify-cert -P https://myvcenter.example.com:12345
```
Save the entire certificate chain to a plaintext file.
- Include all -----BEGIN CERTIFICATE----- and -----END CERTIFICATE----- delimiters.
- Exclude any extraneous text (for example, the name of the certificate and any text contained in angle brackets (< and >) as well as the angle brackets themselves.
Repeat these tasks for vCenter Firewall Management Center.

Get a Certificate Chain—Windows Chrome

Use this procedure to get a certificate chain using the Chrome browser on Windows.

Log in to vCenter or Firewall Management Center using Chrome.
In the browser address bar, click the lock to the left of the host name.
Click Certificate.
Click the Certification Path tab.
Click the top (that is, first) certificate in the chain.
Click View Certificate.
Click the Details tab.
Click Copy to File.
Follow the prompts to create a CER-formatted certificate file that includes the entire certificate chain.

When you're prompted to choose an export file format, click Base 64-Encoded X.509 (.CER) as the following figure shows.
Follow the prompts to complete the export.
Open the certificate in a text editor.
Repeat the process for all certificates in the chain.

You must paste each certificate in the text editor in order, first to last.
Repeat these tasks for vCenter or Firewall Management Center.

Get a Certificate Chain—Windows Firefox

Use the following procedure to get a certificate chain for the Firefox browser on either Windows or Mac OS.

Log in to vCenter or Firewall Management Center. using Firefox.
Click the lock to the left of the host name.
Click the right arrow (Show connection details). The following figure shows an example.
Click More Information.
Click View Certificate.
If the resulting dialog box has tab pages, click the tab page corresponding to the top-level CA.
Scroll to the Miscellaneous section.
Click PEM (chain) in the Download row. The following figure shows an example.
Save the file.
Repeat these tasks for vCenter or Firewall Management Center.

Create a Cisco Cyber Vision connector

This task discusses how to send data from Cisco Cyber Vision to the Secure Firewall Management Center .

Before you begin

Cisco Cyber Vision must be reachable from the machine on which the dynamic attributes connector is running. You must know its IP address, port, and API key.

To find the API key in the Cyber Vision management console, click Admin > API > Token, then click Show to display the token and to copy the token to the clipboard.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Cyber Vision Prefix	Enter an alphanumeric string to identify dynamic objects from this Cyber Vision's IP address when objects are sent to Secure Firewall Management Center . If you have one Cyber Vision IP address, you can enter any value such as 1 .
Pull Interval	(Default 60 seconds.) Interval at which data mappings are retrieved from Cyber Vision. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Host	(Required.) Enter the Cyber Vision fully qualified host name or IP address.
Port	(Required.) Enter the Cyber Vision listen port.
Token	(Required.) Enter the API token.

Step 5

Click Test and make sure the test succeeds before you save the connector.

Step 6

Click Save.

Step 7

Make sure Ok is displayed in the Status column.

Create a generic text connector

This task discusses how to create an ad hoc list of IP addresses you maintain manually and retrieve at an interval you select (30 seconds by default). You can update the list of addresses anytime you want.

Before you begin

Create text files with IP addresses and put it on a web server that is accessible from the Secure Firewall Management Center . IP addresses can include CIDR notation. The text file must have only one IP address per line.

For example, you might have a list of IP addresses for an "allow list" in access control rules and another list of IP addresses for a "block list" in access control rules.

You can specify up to 10,000 IP addresses per text file.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information:


Item	Description
Name	Enter a name to identify the connector.
Description	(Optional.) Enter a description
Pull Interval	Change the frequency, in seconds, at which the dynamic attributes connector retrieves IP addresses from the text file. The default is 30 seconds. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
URLs	Enter a URL from which to retrieve IP addresses.
Add another URL	(Optional.) Click the link to add more URLs to an existing list.
Username	(Optional.) If the server on which the text file is located uses authentication, enter the user's name in this field. We use Basic authentication.
Password	(Optional.) Enter the user's password.
Certificate	(Optional.) If a certificate chain is required for a secure connection to the web server, you have the following options: Click Get Certificate > Fetch to automatically fetch the certificate or, if that is not possible, get the certificate manually as discussed in Manually get a certificate authority (CA) chain. Click Get Certificate > Browse from file to upload a certificate chain you downloaded previously.

Step 5

Click Test and make sure the test succeeds before you save the connector.

Step 6

Click Save.

Step 7

Make sure Ok is displayed in the Status column.

Create a GitHub connector

This section discusses how to create a GitHub connector that sends data to the Secure Firewall Management Center for use in policies. The IP addresses associated with these tags are maintained by GitHub. You do not have to create a dynamic attributes filters.

For more information, see About GitHub's IP addresses.

Note

Do not change the URL because doing so will fail to retrieve any IP addresses.

Procedure

Step 1	Log in to the Secure Firewall Management Center.
Step 2	Click Integrations > Dynamic Attributes Connector > Connectors.
Step 3	Do any of the following: Add a new connector: click Add icon (), then click the name of the connector. Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.
Step 4	Enter a Name and an optional description.
Step 5	(Optional.) In the Pull Interval field, change the frequency, in seconds, at which the dynamic attributes connector retrieves IP addresses from GitHub. The default is 21,600 seconds (6 hours).
Step 6	Click Save.
Step 7	Make sure Ok is displayed in the Status column.

Google Cloud connector—About user permissions and imported data

The dynamic attributes connector imports dynamic attributes from Google Cloud to Secure Firewall Management Center for use in policies.

Dynamic attributes imported

We import the following dynamic attributes from Google Cloud:

Labels, key-value pairs you can use to organize your Google Cloud resources.

For more information, see Creating and Managing Labels in the Google Cloud documentation.
Network tags, key-value pairs associated with an organization, folder, or project.

For more information, see Creating and Managing Tags in the Google Cloud documentation.
IP addresses of virtual machines in Google Cloud.

Minimum permissions required

The dynamic attributes connector requires a user at minimum with the Basic > Viewer permission to be able to import dynamic attributes.

Create a Google Cloud user with minimal permissions for the dynamic attributes connector

This task discusses how to set up a service account with minimum permissions to send dynamic attributes to Secure Firewall Management Center . For a list of these attributes, see Google Cloud connector—About user permissions and imported data.

Before you begin

You must already have set up your Google Cloud account. For more information about doing that, see Setting Up Your Environment in the Google Cloud documentation.

Procedure

Step 1	Log in to your Google Cloud account as a user with the owner role.
Step 2	Click IAM & Admin > Service Accounts > Create Service Account.
Step 3	Enter the following information: Service account name: A name to identify this account; for example, `CSDAC`. Service account ID: Should be populated with a unique value after you enter the service account name. Service account description: Enter an optional description. For more information about service accounts, see Understanding Service Accounts in the Google Cloud documentation.
Step 4	Click Create and Continue.
Step 5	Follow the prompts on your screen until the Grant users access to this service account section is displayed.
Step 6	Grant the user the Basic > Viewer role.
Step 7	Click Done. A list of service accounts is displayed.
Step 8	Click More () at the end of the row of the service account you created.
Step 9	Click Manage Keys.
Step 10	Click Add Key > Create New Key.
Step 11	Click JSON.
Step 12	Click Create. The JSON key is downloaded to your computer.
Step 13	Keep the key handy when you configure the GCP connector.

What to do next

See Create a Google Cloud connector.

Create a Google Cloud connector

Before you begin

Have your Google Cloud JSON-formatted service account data ready; it's required to set up the connector.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from AWS. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
GCP region	(Required.) Enter the GCP region in which your Google Cloud is located. For more information, see Regions and Zones in the Google Cloud documentation.
Service account	Paste the JSON code for your Google Cloud service account.

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

Create an Office 365 connector

This task discusses how to create a connector for Office 365 tags to send data to the Secure Firewall Management Center for use in policies. The IP addresses associated with these tags are updated every week by Microsoft. You do not have to create a dynamic attributes filter to use the data.

For more information, see Office 365 URLs and IP address ranges on docs.microsoft.com.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from Azure. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Base API URL	(Required.) Enter the URL from which to retrieve Office 365 information, if it's different from the default. For more information, see Office 365 IP Address and URL web service on the Microsoft documentation site.
Instance name	(Required.) From the list, click an instance name. For more information, see Office 365 IP Address and URL web service on the Microsoft documentation site.
Disable optional IPs	(Required.) Enter true or false .

Step 5

Click Save.

Step 6

Make sure Ok is displayed in the Status column.

vCenter connector—About user permissions and imported data

The Dynamic Attributes Connector imports dynamic attributes from vCenter to Secure Firewall Management Center for use in policies.

Dynamic attributes imported

We import the following dynamic attributes from vCenter:

Operating system
MAC address
IP addresses
NSX tags

Minimum permissions required

The Dynamic Attributes Connector requires a user at minimum with the Read Only permission to be able to import dynamic attributes.

Create a vCenter user with minimal permissions for the dynamic attributes connector

This task discusses how to set up a service account with minimum permissions to send dynamic attributes to Secure Firewall Management Center . For a list of these attributes, see vCenter connector—About user permissions and imported data.

Before you begin

You must already have set up your vCenter Server account. For more information about doing that, see About vCenter Server Installation and Setup in the vCenter documentation.

Procedure

Step 1	Log into vCenter as an administrator.
Step 2	Click Menu > Administration.
Step 3	In the left pane, click Single Sign On > Users and Groups.
Step 4	From the Domain list, click the name of a domain to add the user.
Step 5	Click Add User.
Step 6	Enter the requested information and click Add.
Step 7	In the left pane, click Access Control > Global Permissions.
Step 8	Click Add().
Step 9	From the User field, click the name of the vCenter domain in which you created the user.
Step 10	In the search field, enter part of the user's name.
Step 11	From the Role list, click Read-only.
Step 12	Select the Propagate to children check box.
Step 13	Click OK.

What to do next

See Create a vCenter connector.

Create a vCenter connector

This task discusses how to create a connector for VMware vCenter to send data to the Secure Firewall Management Center for use in policies.

Before you begin

If you use non-trusted certificates to communicate with vCenter, see Manually get a certificate authority (CA) chain.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Enter an optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from vCenter. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Host	(Required.) Enter any of the following: vCenter's fully qualified host name vCenter's IP address (Optional.) A port Do not enter a scheme (such as `https://`) or trailing slash. For example, `myvcenter.example.com` or `192.0.2.100:9090`
User	(Required.) Enter the user name of a user with the Read-only role at minimum. User names are case-sensitive.
Password	(Required.) Enter the user's password.
NSX IP	If you use vCenter Network Security Visualization (NSX), enter its IP address.
NSX User	Enter the user name of an NSX user with the Auditor role at minimum.
NSX Type	Enter NSX-T.
NSX Password	Enter the NSX user's password.
vCenter Certificate	You have the following options: Paste the certificate authority (CA) chain you got as discussed in Manually get a certificate authority (CA) chain. Click Fetch to automatically fetch the certificate or, if that is not possible, get the certificate manually as discussed in Manually get a certificate authority (CA) chain. Click Get Certificate > Fetch to automatically fetch the certificate or, if that is not possible, get the certificate manually as discussed in Manually get a certificate authority (CA) chain. Click Get Certificate > Browse from file to upload a certificate chain you downloaded previously.

Following is an example of successfully fetching a certificate chain:

Sample of fetching a CA certificate for a vCenter connector

Expanding the certificate CA chain at the top of the dialog box displays the certificates similar to the following.

You can see the certificates in the chain if you expand the certificates

If it's not possible to fetch the certificate this way, you can get the certificate chain manually as discussed in Manually get a certificate authority (CA) chain.

Step 5

Click Save.

Create a Webex connector

This section discusses how to create a Webex connector that sends data to the Secure Firewall Management Center for use in policies. The IP addresses associated with these tags are maintained by Webex. You do not have to create a dynamic attributes filters.

For more information, see Port Reference for Webex Calling.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from Webex. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Provider Reserved IPs	(Required.) (Required.) Slide to enabled to retrieve any reserved IP addresses.

Step 5

Click Test and make sure the test succeeds before you save the connector.

Step 6

Click Save.

Step 7

Make sure Ok is displayed in the Status column.

Create a Zoom Connector

This section discusses how to create a Zoom connector that sends data to the Secure Firewall Management Center for use in policies. The IP addresses associated with these tags are maintained by Zoom. You do not have to create a dynamic attributes filters.

For more information, see Zoom network firewall or proxy server settings.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new connector: click Add icon (), then click the name of the connector.
Edit or delete a connector: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.


Value	Description
Name	(Required.) Enter a name to uniquely identify this connector.
Description	Optional description.
Pull Interval	(Default 30 seconds.) Interval at which IP mappings are retrieved from Zoom. The minimum value for Pull Interval is 1 second. You can set the maximum to any value you want. We recommend against setting the minimum to a low value because it can generate a lot of traffic, and, when applicable, can result in your being billed for the traffic.
Provider Reserved IPs	(Required.) Slide to enabled to retrieve any reserved IP addresses.

Step 5

Click Test and make sure the test succeeds before you save the connector.

Step 6

Click Save.

Step 7

Make sure Ok is displayed in the Status column.

Create dynamic attributes filters

Create dynamic attributes filters to expose them as dynamic objects in Secure Firewall Management Center for use in access control policies.

Dynamic attributes filters that you define using the Dynamic Attributes Connector are exposed in the Secure Firewall Management Center as dynamic objects that can be used in access control policies. For example, restrict access to an AWS server for the Finance Department to only members of the Finance group defined in Microsoft Active Directory.

Note

You cannot create dynamic attributes filters for Generic Text, Office 365, Azure Service Tags, Webex, or Zoom. These types of cloud objects provide their own IP addresses.

For more information about access control or DNS rules, see Create access control rules or DNS rules using dynamic attributes filters.

Before you begin

Create a connector

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Click Integrations > Dynamic Attributes Connector > Dynamic Attributes Filters.

Step 2

Do any of the following:

Add a new filter: click Add ().
Edit or delete a filter: Click More (), then click Edit or Delete at the end of the row.

Step 3

Enter the following information.


Item	Description
Name	Unique name to identify the dynamic filter (as a dynamic object) in a policy and in the Secure Firewall Management Center Object Manager (External Attributes > Dynamic Object).
Connector	From the list, click the name of a connector to use.
Query	Click Add .

Step 4

To add or edit a query, enter the following information.


Item	Description
Key	Click a key from the list. Keys are fetched from the connector.
Operation	Click one of the following: Equals to exactly match the key to the value. Contains to match the key to the value if any part of the value matches.
Values	Click either Any or All and click one or more values from the list. Click Add another value to add values to your query.

Step 5

Click Show Preview to display a list of networks or IP addresses returned by your query.

Step 6

When you're finished, click Save.

Step 7

(Optional.) Verify the dynamic object in the Secure Firewall Management Center.

Log in to the Secure Firewall Management Center as a user with the Network Admin role at minimum.
Click Objects > External Attributes > Dynamic Object.

The dynamic attribute query you created should be displayed as a dynamic object.

Dynamic attribute filter examples

This topic provides some examples of setting up dynamic attribute filters.

Examples: vCenter

The following example shows one criterion: a VLAN.

This sample shows a simple vCenter dynamic attributes filter that finds a VLAN

The following example shows three criteria that are joined with OR: the query matches any of three hosts.

Another sample vCenter dynamic attributes filter that finds any of three hosts; the query is joined by OR

Example: Azure

The following example shows one criterion: a server tagged as a Finance app.

Sample Azure dynamic attributes filter that finds the Finance app tag

Example: AWS

The following example shows one criterion: a FinanceApp with a value of 1.

Sample Amazon Web Services dynamic attributes filter that finds a tag FinanceApp with a value of 1

Example: pxGrid Cloud

The following example shows one criterion: PostureStatus is NonCompliant.

Manually get a certificate authority (CA) chain

In the event you cannot automatically fetch the certificate authority chain, use one of the following browser-specific procedures to get a certificate chain used to connect securely to vCenter or Firewall Management Center.

The certificate chain is the root certificate and all subordinate certificates.

You can optionally use one of these procedures to connect to the following:

vCenter or NSX
Firewall Management Center
Cisco APIC

Get a Certificate Chain—Mac (Chrome and Firefox)

Use this procedure to get a certificate chain using the Chrome and Firefox browsers on Mac OS.

Open a Terminal window.
Enter the following command.
```
security verify-cert -P url[:port]
```
where url is the URL (including scheme) to vCenter or Firewall Management Center. For example:
```
security verify-cert -P https://myvcenter.example.com
```
If you access vCenter or Firewall Management Center using NAT or PAT, you can add a port as follows:
```
security verify-cert -P https://myvcenter.example.com:12345
```
Save the entire certificate chain to a plaintext file.
- Include all -----BEGIN CERTIFICATE----- and -----END CERTIFICATE----- delimiters.
- Exclude any extraneous text (for example, the name of the certificate and any text contained in angle brackets (< and >) as well as the angle brackets themselves.
Repeat these tasks for vCenter Firewall Management Center.

Get a Certificate Chain—Windows Chrome

Use this procedure to get a certificate chain using the Chrome browser on Windows.

Log in to vCenter or Firewall Management Center using Chrome.
In the browser address bar, click the lock to the left of the host name.
Click Certificate.
Click the Certification Path tab.
Click the top (that is, first) certificate in the chain.
Click View Certificate.
Click the Details tab.
Click Copy to File.
Follow the prompts to create a CER-formatted certificate file that includes the entire certificate chain.

When you're prompted to choose an export file format, click Base 64-Encoded X.509 (.CER) as the following figure shows.
Follow the prompts to complete the export.
Open the certificate in a text editor.
Repeat the process for all certificates in the chain.

You must paste each certificate in the text editor in order, first to last.
Repeat these tasks for vCenter or Firewall Management Center.

Get a Certificate Chain—Windows Firefox

Use the following procedure to get a certificate chain for the Firefox browser on either Windows or Mac OS.

Log in to vCenter or Firewall Management Center. using Firefox.
Click the lock to the left of the host name.
Click the right arrow (Show connection details). The following figure shows an example.
Click More Information.
Click View Certificate.
If the resulting dialog box has tab pages, click the tab page corresponding to the top-level CA.
Scroll to the Miscellaneous section.
Click PEM (chain) in the Download row. The following figure shows an example.
Save the file.
Repeat these tasks for vCenter or Firewall Management Center.

About dynamic objects in access control rules or DNS rules

A dynamic object is automatically pushed from the dynamic attributes connector to the Secure Firewall Manager after you create connectors and save a dynamic attributes filter on the connector.

You can use these dynamic objects on the access control rule's or DNS rule's Dynamic Attributes tab page. You can add dynamic objects as source or destination attributes; for example, in an access control block rule, you can add a Finance dynamic object as a destination attribute to block access to Finance servers by whatever objects match the other criteria in the rule.

Note

You cannot create dynamic attributes filters for Generic Text, Office 365, Azure Service Tags, Webex, or Zoom. These types of cloud objects provide their own IP addresses.

Create dynamic attributes filters

Create dynamic attributes filters to expose them as dynamic objects in Secure Firewall Management Center for use in access control policies.

Dynamic attributes filters that you define using the Dynamic Attributes Connector are exposed in the Secure Firewall Management Center as dynamic objects that can be used in access control policies. For example, restrict access to an AWS server for the Finance Department to only members of the Finance group defined in Microsoft Active Directory.

Note

You cannot create dynamic attributes filters for Generic Text, Office 365, Azure Service Tags, Webex, or Zoom. These types of cloud objects provide their own IP addresses.

For more information about access control or DNS rules, see Create access control rules or DNS rules using dynamic attributes filters.

Before you begin

Create a connector

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Click Integrations > Dynamic Attributes Connector > Dynamic Attributes Filters.

Step 2

Do any of the following:

Add a new filter: click Add ().
Edit or delete a filter: Click More (), then click Edit or Delete at the end of the row.

Step 3

Enter the following information.


Item	Description
Name	Unique name to identify the dynamic filter (as a dynamic object) in a policy and in the Secure Firewall Management Center Object Manager (External Attributes > Dynamic Object).
Connector	From the list, click the name of a connector to use.
Query	Click Add .

Step 4

To add or edit a query, enter the following information.


Item	Description
Key	Click a key from the list. Keys are fetched from the connector.
Operation	Click one of the following: Equals to exactly match the key to the value. Contains to match the key to the value if any part of the value matches.
Values	Click either Any or All and click one or more values from the list. Click Add another value to add values to your query.

Step 5

Click Show Preview to display a list of networks or IP addresses returned by your query.

Step 6

When you're finished, click Save.

Step 7

(Optional.) Verify the dynamic object in the Secure Firewall Management Center.

Log in to the Secure Firewall Management Center as a user with the Network Admin role at minimum.
Click Objects > External Attributes > Dynamic Object.

The dynamic attribute query you created should be displayed as a dynamic object.

Dynamic attributes rule conditions

Dynamic attributes include:

(Source or destination.) Dynamic objects (such as from the dynamic attributes connector)

The dynamic attributes connector enables you to collect data (such as networks and IP addresses) from cloud providers and send it to the Secure Firewall Management Center so they can be used in access control rules.

For more information about the dynamic attributes connector, see About the dynamic attributes connector.
(Source only.) SGT objects contain tags either manually defined or defined in ISE. For more information, see Source and destination security group tag (SGT) matching and Security group tags.
(Source only.) Location IP objects, defined by Cisco ISE
(Source only.) Device type objects, defined by Cisco ISE (also referred to as endpoint profile objects)

Dynamic attributes can be used as source criteria and destination criteria in access control rules. Use the following guidelines:

Objects of different types are ANDd together
Objects of a similar type are ORd together

For example, if you choose source destination criteria SGT 1, SGT 2, and device type 1; the rule is matched if device type 1 is detected on either SGT 1 or SGT 2. As another example, if you select both a security group tag, and a dynamic object that lists IP addresses, the rule matches if traffic with the tag originates from (or is destined to) one of those IP addresses.

View dynamic objects in the Secure Firewall Management Center

(Optional.) The following task discusses how you can view Cisco APIC network objects in the Objects > External Attributes > Dynamic Object.

Before you begin

Complete all of the previous tasks related to integrating Cisco APIC with the Secure Firewall Management Center.

Procedure

Step 1

Log in to the Secure Firewall Management Center

Step 2

Expand Objects > External Attributes > Dynamic Object.

Dynamic objects have their own naming conventions; for example, AWS dynamic objects have names like aws_AMAZON.

Dynamic objects created by the integration with Cisco APIC have names matching the pattern:

APIC-site-name_tenant-name_application-profile-name_EPG-or-ESG-name

Example.

Step 3

To view IP addresses associated with each dynamic object, click (IPs) at the end of the row.

Example:

Find and optionally download IP addresses associated with a dynamic object

What to do next

See Create access control rules or DNS rules using dynamic attributes filters.

Create access control rules or DNS rules using dynamic attributes filters

Create access control rules using dynamic objects that are based on dynamic attributes filters you have previously configured.

This topic discusses how to create access control rules using dynamic objects (these dynamic objects are named after the dynamic attributes filters you created previously).

To add dynamic attributes filters to DNS policies, see Create basic DNS policies.

To add dynamic attributes filters to DNS policies, see Creating Basic DNS Policies.

Before you begin

Create dynamic attributes filters as discussed in Create dynamic attributes filters.

Note

You cannot create dynamic attributes filters for Generic Text, Office 365, Azure Service Tags, Webex, or Zoom. These types of cloud objects provide their own IP addresses.

Follow these steps to create access control rules or DNS rules using dynamic attributes filters:

Procedure

Step 1	Log in to the Secure Firewall Management Center Click Policies > Security policies > Access Control.
Step 2	Click Edit () next to an access control policy.
Step 3	Click Add Rule.
Step 4	Click the Dynamic Attributes tab.
Step 5	In the Available Attributes section, from the list, click Dynamic Objects. The following figure shows an example. This example shows a dynamic object named `APIC Dynamic Attribute` that corresponds to the dynamic attribute filter created in the dynamic attributes connector.
Step 6	Add the desired object to source or destination attributes.
Step 7	Add other conditions to the rule if desired.

What to do next

See Dynamic attributes rule conditions.

Use dynamic objects in DNS policies

The dynamic attributes connector enables you to configure dynamic filters, seen in the Secure Firewall Management Center as dynamic objects, in DNS rules. For information about DNS policies, see DNS Policies for Security Intelligence.

A dynamic object is automatically pushed from the dynamic attributes connector to the Secure Firewall Management Center after you create connectors and save a dynamic attributes filter on the connector.

You can use these dynamic objects on the DNS rule's Dynamic Attributes tab page, similarly to the way you use Security Group Tags (SGTs). You can add dynamic objects as source or destination attributes, except for endpoint device type objects, which are source only.

Procedure

Step 1	Click Policies > Security policies > DNS and create or edit a DNS policy.
Step 2	Add or edit a rule.
Step 3	Click the Dynamic Attributes tab.
Step 4	In the Dynamic Attributes list, select the objects you want to use, then add them to the source or destination lists as appropriate. Initially, all security group and dynamic objects are listed, by you can uncheck the Security Group option to see dynamic objects only.
Step 5	On the DNS tab, select the appropriate list or feed to match the DNS requests you are targeting.
Step 6	Add other conditions to the rule if desired and set the action.
Step 7	Click Save.

Dynamic firewall

These topics describe how to integrate user identity data (including Microsoft AD and ISE) with user trust data provided by Identity Intelligence to enhance your ability to detect identity-based exploits in your network.

About the dynamic firewall

Previously, the Secure Firewall Management Center collected information about users exclusively from the configured identity source, such as Microsoft Active Directory, the passive identity agent, Cisco Identity Services Engine (Cisco ISE), and so on. This information generally included user name, group, and IP address.

The dynamic firewall enables you to add user risk scores from Cisco Identity Intelligence to identity source-provided information so you can set policies based on always-current user posture and risk. We enable you to pair user identity with intelligence and use that information in reporting and access control policies.

To use the dynamic firewall, you must:

Have an Identity Intelligence tenant

See Duo Identity Security with Cisco Identity Intelligence.
Enable the Dynamic Attributes Connector
Set up an identity source:
- Cisco Identity Services Engine (Cisco ISE)
- pxGrid Cloud

  pxGrid Cloud combines identity and posture in the same feed

  More information: What is pxGrid?
In addition to providing authentication information, Cisco ISE and pxGrid Cloud can provide the following:
- SGT Exchange Protocol over TCP (SXP) binding and directory session information if desired. For more information, see the Cisco Identity Services Engine Administrator Guide
- Posture and mobile device management compliance. For more information, see Compliance.
Set up an identity realm:
- Create an LDAP realm or an Active Directory realm and realm directory
- Create a Microsoft Azure AD (SAML) realm for passive authentication

The identity source provides authentication information (login, logout) as well as posture. The identity source can also provide SXP binding and session directory information if desired.

The identity realm provides user, group, and IP address information.

How to configure the dynamic firewall

This topic helps you understand the concepts and options to configure the dynamic firewall discussed in About the dynamic firewall.

Summary

The dynamic firewall integrates an identity source (such as Cisco ISE) with Cisco Identity Intelligence, which provides user trust information to the Secure Firewall Management Center.

Configure Cisco Identity Intelligence to collect user trust information.
Configure a supported Secure Firewall Management Center identity source.
Configure a supported identity realm.
Enable the dynamic attributes connector.
Configure the dynamic firewall.

Workflow

The following procedure provides a high-level overview of how to configure the dynamic firewall.

As a Duo user with the Owner role, provision a Cisco Identity Intelligence tenant. You can provision a tenant from Duo Advantage as discussed in Provision Your Cisco Identity Intelligence Tenant.
In Cisco Identity Intelligence, create an API integration and use the information to set up the dynamic firewall. We use Cisco Identity Intelligence to find user and device risk information in your network. For more information about Cisco Identity Intelligence, see How-to Guides. For more information about this task, see Get required information for Identity Intelligence.
(Microsoft Azure AD realm only.) In Identity Intelligence, create a Microsoft Entra ID integration. For more information, see Microsoft Entra ID (Azure AD) Data Integration.
Create an identity source. (If you already have an identity source, continue with the next step.) You can do this in any of the following ways:
- The Configure Dynamic Firewall dialog box displays Configure links to start setting up your identity source.
- Click Integrations > Identity > Identity Sources.
For more information about creating identity sources, see:
Create an identity realm. We support the following realms:
- Create an LDAP realm or an Active Directory realm and realm directory Only Microsoft AD is supported; LDAP realms are not supported.
- Create a Microsoft Azure AD (SAML) realm for passive authentication
Enable the dynamic attributes connector. The dynamic attributes connector is required to use the dynamic firewall. It enables your identity source to integrate with Identity Intelligence to provide enhanced insights into user activity. See Enable the dynamic attributes connector.
Create the dynamic firewall instance. (If you already have a dynamic firewall instance, continue with the next step.) Click Integrations > Dynamic Attributes Connector and click Configure Dynamic Firewall. See Create a dynamic firewall instance.
Associate your identity source with Cisco Identity Intelligence. See Associate an identity source with Identity Intelligence.
View system-defined filters. We create dynamic attributes filters for the following:
- Untrusted device
- Trusted device
- Untrusted user
- Questionable user
You can edit or replace these dynamic attributes filters as discussed in Create dynamic attributes filters.
View system-defined access control rules. We create an access control policy named Dynamic Firewall Policy (or similar) with the following rules:
- Block an untrusted user from any source network to any destination network.
- Monitor a questionable user from any source network to any destination network.
- Block an untrusted device from any source network to any destination network.
You can edit or delete the access control policy and rules as discussed in View and edit the system-created access control policy.

Enable the dynamic attributes connector

Enable the dynamic attributes connector to allow objects from cloud networking products to be used in Secure Firewall Management Center access controland DNS rules.

This task discusses how to enable the dynamic attributes connector in the Secure Firewall Management Center. The dynamic attributes connector is an integration that enables objects from cloud networking products to be used in Secure Firewall Management Center access controland DNS rules.

Procedure

Step 1	Log in to the Secure Firewall Management Center if you have not done so already.
Step 2	Click Integrations > Dynamic Attributes Connector.
Step 3	Slide to Enabled.
Step 4	Messages are displayed while the dynamic attributes connector is enabled. In the event of errors, try again. If errors persist, contact Cisco TAC.

What to do next

See Create a connector.

Get required information for Identity Intelligence

This task discusses how to create an API client, which provides all the get required information to set up Identity Intelligence in the dynamic firewall.

If you already have an API client and you know the values of all the following, you can skip this procedure and continue with Create a dynamic firewall instance:

Client ID
API URL
Token URL
Client Secret

Before you begin

Integrating with the dynamic firewall requires you to create an API client integration in Identity Intelligence.

Among the values you must know about your API client integration is the client secret, which is displayed when you create the API client only. For that reason you might need to create the API integration first.

For more information about creating an API cilent integration, see Public API.

Procedure

Step 1	Log in to your Identity Intelligence tenant.
Step 2	Click (Integrations).
Step 3	Click Add Integration.
Step 4	On the next page, under API Clients, click Add API Client.
Step 5	Enter a Name and an optional Description.
Step 6	Click Save and Generate Credentials. The following figure shows an example.
Step 7	On the next page, click Copy all as the following figure shows.
Step 8	Save the credentials for later use.
Step 9	Click Finish.

What to do next

See Create a dynamic firewall instance.

Create an identity source and realm for the dynamic firewall

Before you configure the dynamic firewall, you must configure a supported identity realm and identity source.

Configure an identity realm

These identity realms are supported:

Create an LDAP realm or an Active Directory realm and realm directory

Only Microsoft AD is supported; LDAP realms are not supported.
Create a Microsoft Azure AD (SAML) realm for passive authentication

Configure an identity source

These identity sources are supported:

On-premises Cisco ISE: Ways to configure the Cisco Identity Services Engine (Cisco ISE) identity source
Single or multiple Cisco ISE clusters:
- Configuring a pxGrid Cloud identity source
- Configuring a pxGrid Cloud identity source (Cisco ISE 3.3 or earlier)

Create a dynamic firewall instance

This task discusses how to create a new instance of the dynamic firewall, which is an association between an identity source and Identity Intelligence.

Before you begin

Do all of the following:

Enable the dynamic attributes connector as discussed in Enable the dynamic attributes connector.
Create an identity source:
- Ways to configure the Cisco Identity Services Engine (Cisco ISE) identity source.
- Create a pxGrid Cloud identity source.

Procedure

Step 1

If you have not already done so, log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector.

Step 3

Click next to the name of the identity source with which to add the dynamic firewall.

The following figure shows an example.

Note

If you do not see an identity source, create one before continuing:

Step 4

Click Create Dynamic Firewall.

Step 5

Continue with Associate an identity source with Identity Intelligence.

Associate an identity source with Identity Intelligence

This task discusses how you associate an identity source with Identity Intelligence, which provides user and device trust ratings to the Secure Firewall Management Center.

For more information, see User Trust Level.

Before you begin

Before you begin, make sure you:

Understand how the identity realm, identity source, and Identity Intelligence work together as discussed in About the dynamic firewall.
Completed the tasks discussed in Create a dynamic firewall instance.

Procedure

Step 1	Start with Create a dynamic firewall instance.
Step 2	On the next page, from the left column, click your identity source. Then, in the right column, select the Cisco Identity Intelligence check box to add user intelligence, including user and device risk. The following figure shows an example.
Step 3	Click Next.
Step 4	Continue with Configure Identity Intelligence.

Configure Identity Intelligence

This task discusses how you associate an identity source with Identity Intelligence, which provides user and device risk ratings to the Secure Firewall Management Center.

Before you begin

Complete the tasks discussed in Associate an identity source with Identity Intelligence.

Procedure

Step 1	Complete the tasks discussed in Associate an identity source with Identity Intelligence.
Step 2	If you selected the Cisco Identity Intelligence check box, enter the information you found for Identity Intelligence as described in Get required information for Identity Intelligence. The following figure shows an example.
Step 3	(Optional.) For Identity Intelligence to consider a specific set of users as trusted, slide Exclusion List to Slider enabled (). Enter one user name per line in username@domain.com format. Users in this list are considered trusted by Identity Intelligence.
Step 4	Click Test. Only if the test succeeds, continue with the next step. If any errors are displayed, check all of your Identity Intelligence values and try again.
Step 5	Click Next.
Step 6	Continue with View system-defined filters.

View system-defined filters

This task discusses how you associate an identity source with Cisco Identity Intelligence, which provides user and device risk ratings to the Secure Firewall Management Center.

Before you begin

See Configure Identity Intelligence.

Procedure

Step 1	The system displays a set of system-defined dynamic attributes filters, as the following figure shows.
Step 2	View the system-created filters. Click on any row to expand the filter so you can view the filter and see its details.
Step 3	Click Next.
Step 4	Continue with View system-defined access control rules.

View system-defined access control rules

This task discusses access control rules created by the dynamic firewall.

Before you begin

See View system-defined filters.

Procedure

Step 1

View the system-created access control rules.

The following figure shows an example.

Step 2

Choose one of these options:

Click Skip to skip creating these access control rules. You can create your own anytime.
Click Next to create an access control policy named Dynamic Firewall Policy with the rules shown in the preceding figure.
Click Back to return to system-created filters.

Step 3

After you click Next, if you created access control rules successfully, the following page is displayed:

Edit the user exclusion list

(Optional.) You can instruct Identity Intelligence to treat specific users as trusted.

Before you begin

Configure the dynamic firewall as discussed in Create a dynamic firewall instance.

Procedure

Step 1	If you haven't already done so, log in to the Secure Firewall Management Center.
Step 2	Click Integrations > Dynamic Attributes Connector.
Step 3	Click next to the name of the identity source.
Step 4	Click Edit CII Exclusion List. The following dialog box is displayed.
Step 5	In the provided field, enter one user name in `username@domain.com` format on a line, press Enter, and enter another user name. Each user name is considered as trusted by Identity Intelligence.

View and edit the system-created access control policy

This topic discusses how you can edit the system-created access control rules and policy. Initially, the policy isn't associated with any devices but if you want to use it you can add devices, change rules, reorder rules, or delete rules.

Before you begin

Complete the tasks described in View system-defined access control rules.

Procedure

Step 1	If you haven't already done so, log in to the Secure Firewall Management Center.
Step 2	Click Policies > Security policies > Access Control.
Step 3	Click Edit () next to the policy named Dynamic Firewall Policy (or similar). The following figure shows a sample access control policy. Note that in this access control policy, only the rule set to monitor questionable users logs anything. To adjust the logging settings, see Logging settings for access control policies.
Step 4	Do any of the following: Target the access control policy at devices: Assign access control policy to devices. Edit the policy, including adding logging: Managing access control policies. Edit access control rules: Managing access control rules. Set advanced policy options: Configure advanced settings for the access control policy. Associate other policies with this access control policy: Associating other policies with access control.

Create dynamic attributes filters

Dynamic attributes filters that you define using the Dynamic Attributes Connector are exposed in the Secure Firewall Management Center as dynamic objects that can be used in access control policies. For example, you could restrict access to an AWS server for the Finance Department to only members of the Finance group defined in Microsoft Active Directory.

For more information about access control rules, see Create access control rules or DNS rules using dynamic attributes filters.

Procedure

Step 1

Log in to the Secure Firewall Management Center.

Step 2

Click Integrations > Dynamic Attributes Connector > Connectors.

Step 3

Do any of the following:

Add a new filter: click Add ().
Edit or delete a filter: Click More (), then click Edit or Delete at the end of the row.

Step 4

Enter the following information.

Item	Description
Name	Unique name to identify the dynamic filter (as a dynamic object) in access control policy and in the Secure Firewall Management Center Object Manager (External Attributes > Dynamic Object).
Connector	From the list, click the name of a connector to use.
Query	Click Add .

Step 5

To add a query, enter the following information.

Item	Description
Key	Click a key from the list. Keys are fetched from the connector.
Operation	Click one of the following: Equals to exactly match the key to the value. Contains to match the key to the value if any part of the value matches.
Values	Click either Any or All and click one or more values from the list. Click Add another value to add values to your query.

Step 6

Click Show Preview to display a list of networks or IP addresses returned by your query.

Step 7

When you're finished, click Save.

Step 8

(Optional.) Verify the dynamic object in the Secure Firewall Management Center .

Log in to the Secure Firewall Management Center as a user with the Network Admin role at minimum.
Click Objects > External Attributes > Dynamic Object.

The dynamic attribute query you created should be displayed as a dynamic object.

Disable the dynamic attributes connector

If you no longer wish to collect dynamic objects from cloud sources, you can disable the Dynamic Attributes Connector in the Secure Firewall Management Center as discussed in the following task.

Procedure

Step 1	Log in to the Secure Firewall Management Center if you have not done so already.
Step 2	Click Integrations > Dynamic Attributes Connector.
Step 3	Slide to Disabled.

Troubleshoot using the Secure Firewall Management Center

This task discusses how to generate troubleshoot files for the Secure Firewall Management Center.

Procedure

Step 1	Log in to the Secure Firewall Management Center.
Step 2	Click Troubleshooting > Health > Monitor.
Step 3	In the left pane, click Firewall Management Center.
Step 4	At the top, click System & Troubleshooting Details.
Step 5	Click Generate Troubleshooting Files.
Step 6	Provide the files to Cisco TAC or to your Beta coordinator.

Manually get a certificate authority (CA) chain

In the event you cannot automatically fetch the certificate authority chain, use one of the following browser-specific procedures to get a certificate chain used to connect securely to vCenter or Firewall Management Center.

The certificate chain is the root certificate and all subordinate certificates.

You can optionally use one of these procedures to connect to the following:

vCenter or NSX
Firewall Management Center
Cisco APIC

Get a Certificate Chain—Mac (Chrome and Firefox)

Use this procedure to get a certificate chain using the Chrome and Firefox browsers on Mac OS.

Open a Terminal window.
Enter the following command.
```
security verify-cert -P url[:port]
```
where url is the URL (including scheme) to vCenter or Firewall Management Center. For example:
```
security verify-cert -P https://myvcenter.example.com
```
If you access vCenter or Firewall Management Center using NAT or PAT, you can add a port as follows:
```
security verify-cert -P https://myvcenter.example.com:12345
```
Save the entire certificate chain to a plaintext file.
- Include all -----BEGIN CERTIFICATE----- and -----END CERTIFICATE----- delimiters.
- Exclude any extraneous text (for example, the name of the certificate and any text contained in angle brackets (< and >) as well as the angle brackets themselves.
Repeat these tasks for vCenter Firewall Management Center.

Get a Certificate Chain—Windows Chrome

Use this procedure to get a certificate chain using the Chrome browser on Windows.

Log in to vCenter or Firewall Management Center using Chrome.
In the browser address bar, click the lock to the left of the host name.
Click Certificate.
Click the Certification Path tab.
Click the top (that is, first) certificate in the chain.
Click View Certificate.
Click the Details tab.
Click Copy to File.
Follow the prompts to create a CER-formatted certificate file that includes the entire certificate chain.

When you're prompted to choose an export file format, click Base 64-Encoded X.509 (.CER) as the following figure shows.
Follow the prompts to complete the export.
Open the certificate in a text editor.
Repeat the process for all certificates in the chain.

You must paste each certificate in the text editor in order, first to last.
Repeat these tasks for vCenter or Firewall Management Center.

Get a Certificate Chain—Windows Firefox

Use the following procedure to get a certificate chain for the Firefox browser on either Windows or Mac OS.

Log in to vCenter or Firewall Management Center. using Firefox.
Click the lock to the left of the host name.
Click the right arrow (Show connection details). The following figure shows an example.
Click More Information.
Click View Certificate.
If the resulting dialog box has tab pages, click the tab page corresponding to the top-level CA.
Scroll to the Miscellaneous section.
Click PEM (chain) in the Download row. The following figure shows an example.
Save the file.
Repeat these tasks for vCenter or Firewall Management Center.

Security requirements

To safeguard the dynamic attributes connector, you should install it on a protected internal network. Although the dynamic attributes connector is configured to have only the necessary services and ports available, you must make sure that attacks cannot reach it.

If the dynamic attributes connector and the Secure Firewall Management Center reside on the same network, you can connect the Secure Firewall Management Center to the same protected internal network as the dynamic attributes connector.

Regardless of how you deploy your appliances, inter-system communication is encrypted. However, you must still take steps to ensure that communications between appliances cannot be interrupted, blocked, or tampered with; for example, with a distributed denial of service (DDoS) or adversary-in-the-middle attack.

Internet access requirements

By default, the dynamic attributes connector is configured to communicate with the Firepower System over the internet using HTTPS on port 443/tcp (HTTPS). If you do not want the dynamic attributes connector to have direct access to the internet, you can configure a proxy server.

The following information informs you of the URLs the dynamic attributes connector use to communicate with the Secure Firewall Management Center and with external servers.

Table 5. Dynamic Attributes Connector access requirements
URL	Reason
https://`fmc-ip`/api/fmc_platform/v1/ auth/generatetoken	Authentication
https://`fmc-ip`/api/fmc_config/ v1/domain/`domain-id`/object/dynamicobjects	GET and POST dynamic objects
https://`fmc-ip`/api/fmc_config/ v1/domain/ `domain-id`/object/dynamicobjects/ `object-id`/mappings?action=add	Add mappings
https://`fmc-ip`/api/fmc_config/ v1/domain/`domain-id` /object/dynamicobjects/ `object-id`/mappings?action=remove	Remove mappings

Table 6. Dynamic Attributes Connector vCenter access requirements
URL	Reason
https://`vcenter-ip`/rest/com/vmware/cis/session	Authentication
https://`vcenter-ip`/rest/vcenter/vm	Get VM information
https://`nsx-ip`/api/v1/fabric/virtual-machines/ `vm-id`	Get NSX-T tag associated with the virtual machine

Migration from DockerHub to Amazon ECR

Docker images for the Dynamic Attributes Connector are being migrated from Docker Hub to Amazon Elastic Container Registry (Amazon ECR).

To use the new field packages, you must allow access through your firewall or proxy to all of the following URLs:

https://public.ecr.aws
https://csdac-cosign.s3.us-west-1.amazonaws.com
https://d2glxqk2uabbnd.cloudfront.net
https://d5l0dvt14r5h8.cloudfront.net

For more information about Amazon Cloudfront URLs, see EKS Anywhere documentation.

Dynamic Attributes Connector Azure access requirements

The dynamic attributes connector calls built-in SDK methods to get instance information. These methods internally call https://login.microsoft.com (for authentication) and https://management.azure.com (to get instance information).

History for the dynamic attributes connector


Feature	Minimum Firewall Management Center	Minimum Firewall Threat Defense	Details
DNS rule support for dynamic objects and security group tags.	10.0.0	10.0.0	You can configure DNS rules in the DNS policy to use dynamic objects or security group tags (SGT). If you are using these types of objects in access control rules already, you can now extend their use to your DNS policy. We added the Dynamic Attributes tab to the add/edit DNS rule dialog box.
Dynamic firewall	10.0.0	10.0.0	Previously, the Secure Firewall Management CenterSecure Firewall Management Center collected information about users exclusively from the configured identity source, such as Microsoft Active Directory, the passive identity agent, Cisco Identity Services Engine (Cisco ISE), and so on. This information generally included user name, group, and IP address. The dynamic firewall enables you to add user risk scores from Cisco Identity Intelligence to identity source-provided information so you can set policies based on always-current user posture and risk. We enable you to pair user identity with intelligence and use that information in reporting and access control policies. New/modified screens: Click Integrations > Dynamic Attributes Connector. Then click next to the name of the identity source and click Create Dynamic Firewall.
Cisco APIC connector	10.0.0	10.0.0	The dynamic attributes connector enables you to send Cisco APIC dynamic endpoint group (EPG) and endpoint security group (ESG) data from Cisco APIC tenants to . New/updated screens: Integrations > Dynamic Attributes Connector > Connectors > New Connector
New connectors	7.6	20241127	AWS security groups, AWS service tags, and Cisco Cyber Vision These connectors can send an on-premises Secure Firewall Management Center dynamic objects as can Security Cloud Control. To receive dynamic objects from an on-premises dynamic attributes connector, version 3.0 of the on-premises dynamic attributes connector is required.
Dynamic Attributes Connector	7.4.0	7.4.0	This feature is introduced. The Dynamic Attributes Connector is now included in the Secure Firewall Management Center. You can use the dynamic attributes connector to get IP addresses from cloud-based platforms such as Microsoft Azure in access control rules without having to deploy to managed devices. More information: The dynamic attributes connector included with this product: About the dynamic attributes connector The standalone dynamic attributes connector: Cisco Secure Dynamic Attributes Connector Configuration Guide New/modified screen: Integrations > Dynamic Attributes Connector

Bias-Free Language

Results

Chapter: Dynamic Attributes Connector

Dynamic Attributes Connector

About the dynamic attributes connector

How it works

Related Topics

Network download mode

System requirements for the Dynamic Attributes Connector

Enable the dynamic attributes connector

Procedure

What to do next

Configure networks and subnets for Docker containers

About Docker networks

Change Docker networks and subnets

Examples

Verify the networks

Troubleshoot

About the dashboard

Dashboard of an unconfigured system

Dashboard of a configured system

Add, edit, or delete connectors

View error information

Add, edit, or delete dynamic attributes filters

Create a connector

Amazon Web Services connector—About user permissions and imported data

Dynamic attributes imported

Minimum permissions required

Create an AWS user with minimal permissions for the dynamic attributes connector

Before you begin

Procedure

What to do next

Create an AWS connector

Before you begin

Procedure

Amazon Web Services Security Groups connector—About user permissions

Minimum permissions required

Create an AWS user with minimal permissions for the dynamic attributes connector

Before you begin

Procedure

What to do next

Create an AWS Security Groups connector

Before you begin

Procedure

Create an AWS service tags connector

Procedure

Azure connector—About user permissions and imported data

Dynamic attributes imported

Minimum permissions required

Create an Azure user with minimal permissions for the dynamic attributes connector

Before you begin

Procedure

What to do next

Create an Azure connector

Before you begin

Procedure

Create an Azure Service Tags connector

Procedure

Cisco APIC connector

How to use dynamic objects from Cisco APIC in Secure Firewall Management Center access control rules or DNS Rules

System requirements for the integration with Cisco APIC

Get required information for the integration

Cisco ACI Endpoint Update App site prefix and update interval

Required to configure the integration: Find a user with appropriate access

Cisco APIC tenant name

Cisco APIC application profile name

EPG name

Example

Create a Cisco APIC connector

Procedure

Manually get a certificate authority (CA) chain

Get a Certificate Chain—Mac (Chrome and Firefox)

Get a Certificate Chain—Windows Chrome

Get a Certificate Chain—Windows Firefox

Create a Cisco Cyber Vision connector

Before you begin

Procedure

Create a generic text connector

Before you begin
