System Security Configuration Guide for Cisco 8000 Series Routers, IOS XR Releases

OpenSSH certificate authentication

Updated: September 18, 2026

Want to summarize with AI?

Explains how an OpenSSH CA signs host and user certificates to establish mutual trust between a client and a Cisco IOS XR router.

OpenSSH certificate authentication is a two-way SSH trust model that

uses an SSH key as a CA to sign host and user certificates
authenticates the router to the client and the client user to the router, and
avoids first-connection trust establishment when both certificates chain to the trusted CA.

The certificate records the subject public key, signing CA, type, validity, key ID, and serial number. A user certificate also records principals that the router matches against the login username.

Supported key types

OpenSSH certificates support RSA, DSA, ECDSA, and Ed25519 keys. User certificates can also contain supported critical options and extensions created with ssh-keygen utility.

Table 1. Feature History Table
Feature Name	Release Information	Feature Description
OpenSSH Certificate based Authentication for Router	Release 25.4.1	Introduced in this release on: Fixed Systems (8010 [ASIC: A100]) (select variants only) This feature is supported on: 8011-32Y8L2H2FH 8011-12G12X4Y-A/D
OpenSSH Certificate based Authentication for Router	Release 25.1.1	Introduced in this release on: Fixed Systems (8700 [ASIC: K100], 8010 [ASIC: A100]) (select variants only) This feature is supported on: 8712-MOD-M 8011-4G24Y4H-I
OpenSSH Certificate based Authentication for Router	Release 24.4.1	Introduced in this release on: Fixed Systems (8200 [ASIC: P100], 8700 [ASIC: P100]) (select variants only); Modular Systems (8800 [LC ASIC: P100]) (select variants only) *This feature is supported on: 8212-48FH-M 8711-32FH-M 88-LC1-36EH 88-LC1-12TH24FH-E 88-LC1-52Y8H-EM
OpenSSH Certificate based Authentication for Router	Release 7.5.3	You can now use OpenSSH certificates to authenticate to the remote routers from a client machine. This feature uses the ssh-keygen utility, a standard SSH component to generate and manage authentication keys, available in OpenSSH to create a CA (Certificate Authority) like infrastructure for logging into the router. In this feature, the certificates that are used to authenticate router and client are both signed by the same CA. This automatically establishes trust between router and client, and eliminates the need to establish trust, while using the client for remote logging to router for the first time.

How OpenSSH certificate authentication works

A system with OpenSSH and ssh-keygen provides the certificate-signing infrastructure.

Summary

The router and client trust the same CA. The CA signs a router host certificate and a user certificate before the client opens the SSH connection.

Workflow

These stages describe OpenSSH certificate authentication:

An administrator creates an OpenSSH trustpoint on the router and assigns it to host and user authentication.
The CA system generates an SSH CA key pair. Its public key is installed in the router trustpoint.
The router generates a certificate-signing request. The CA signs it as a host certificate, and the signed certificate is imported into the router.
The client generates a user key pair. The CA signs the public key with the login username as a principal, and the signed user certificate is installed on the client.
The client trusts the CA for the router host and presents its user certificate during login. The router validates the certificate, matches its principal to the login username, and permits authorized access.

Result

The host and user certificates establish a mutually authenticated SSH channel.

Prerequisites for OpenSSH certificate authentication

Establish CA trust and valid identities before an OpenSSH certificate login.

Use a CA system that has OpenSSH and the ssh-keygen utility.
Install the CA public key in an OpenSSH trustpoint on the router.
Assign a trustpoint for host authentication and up to ten trustpoints for user authentication.
Import a valid CA-signed host certificate into the router.
Install the CA-signed user certificate and its matching private key on the client.
Set a user-certificate principal that matches the SSH login username.
Configure the username locally on the router unless TACACS+ certificate-user authorization is enabled.

The router and client can authenticate each other only when their certificates are valid, signed by a trusted CA, and associated with the requested identities.

Configure OpenSSH certificate authentication

Establish certificate-based authentication between an OpenSSH client and a Cisco IOS XR router.

Before you begin

Provide a CA system and client system with OpenSSH and ssh-keygen .
Provide secure methods to transfer the CA public key, certificate-signing request, signed host certificate, and signed user certificate.

Procedure

Establish the OpenSSH trustpoint on the router and generate its CA key pair on the CA host.

On the router, create an OpenSSH trustpoint and assign it to host and user authentication.

Example:

Router# configure
Router(config)# crypto ca openssh trustpoint sample-openssh-ca
Router(config)# ssh server openssh trustpoint host sample-openssh-ca
Router(config)# ssh server openssh trustpoint user sample-openssh-ca
Router(config)# commit

On the CA host, generate the CA key pair and display its public key.
Example:
```
ca-host$ ssh-keygen -t rsa -f sample-ca-key
ca-host$ cat sample-ca-key.pub
```
Leave the passphrase empty.

Create, install, and verify the CA-signed router host certificate.
1. On the router, install the CA public key in the trustpoint and verify it.
  Example:
```
Router# crypto ca openssh authenticate sample-openssh-ca
Enter the CA pubkey.
End with a blank line or the word "quit" on a line by itself
Do you accept this certificate? [yes/no]: yes
Router# show crypto ca openssh certificates
```
  Paste the complete CA public key at the prompt.
2. On the router, generate and display the host certificate-signing request.
  Example:
```
Router# crypto ca openssh enroll sample-openssh-ca
Display Certificate Request to terminal? [yes/no]: yes
```
  Copy only the host-key content between the host-key markers to a file named sample-host.pub on the CA host.
3. On the CA host, sign the router host key and display the signed certificate.
  Example:
```
ca-host$ ssh-keygen -h -s sample-ca-key -I "sample-router" -V +10w -z 10 sample-host.pub
ca-host$ cat sample-host-cert.pub
```
  The example creates a host certificate with identity sample-router, a 10-week validity period, and serial number 10.
4. On the router, import the signed host certificate and verify its properties.
  Example:
```
Router# crypto ca openssh import sample-openssh-ca certificate
Enter the OpenSSH certificate.
End with a blank line
Router# show crypto ca openssh certificates
```
  The output lists the CA certificate and router host certificate with the host certificate's key ID, serial number, and validity period.

Create and install the CA-signed user certificate and authorize its username on the router.

On the client host, generate the user key pair and display its public key.

Example:

client-host$ ssh-keygen -t rsa -f sample-user-key
client-host$ cat sample-user-key.pub

On the CA host, sign the user public key with a principal that matches the router username.

Example:

ca-host$ ssh-keygen -s sample-ca-key -I "sample-user-cert" -V +10w -n sample-user -z 20 sample-user-key.pub
ca-host$ ssh-keygen -Lf sample-user-key-cert.pub

The user-certificate signing command uses these parameters:

Table 2. User-certificate signing parameters
Parameter	Description	Example value
CACert	Specifies the filename of the CA private key that signs the user public key.	sample-ca-key
IdentityOfSysReqCert	Specifies the identity assigned to the user certificate.	`sample-user-cert`
CertValidity	Specifies the certificate validity period.	`+10w`
Username	Specifies the principals added to the certificate. During authentication, a principal must match the SSH login username. Separate multiple principals with commas.	`sample-user`
CertSerialNo	Specifies the certificate serial number.	`20`
CopiedUserCertName	Specifies the filename containing the user public key copied from the client host for signing.	sample-user-key.pub

Note

In addition to the mandatory user-certificate fields, you can configure supported critical options and extensions. See the ssh-keygen documentation for details.

On the client host, install the signed user certificate and trust the CA for the router host.

Place sample-user-key-cert.pub with its matching private key. Add an @cert-authority entry containing the router hostname and CA public key to the client's known_hosts file.

On the router, configure the username that matches the user-certificate principal.

Example:

Router# configure
Router(config)# username sample-user
Router(config-un)# group root-lr
Router(config-un)# commit

On the client host, connect to the router with the signed user certificate and matching private key.

Example:

client-host$ ssh -o CertificateFile=sample-user-key-cert.pub -i sample-user-key sample-user@192.0.2.2 -o StrictHostKeyChecking=yes

The client validates the router host certificate, and the router validates and authorizes the signed user certificate.
