Release Notes for NX-OS Live Protect Shield, Release 10.6(3)



CVE-2026-20212 - Cisco Nexus 9000 Series Switches Silicon One Remote Code Execution Vulnerability

Live Protect Shield

Cisco has released Live Protect shield for CVE-2026-20212 to temporarily mitigate this vulnerability in Cisco NX-OS Software.

For information about Live Protect for Cisco NX-OS Software, see Cisco Nexus 9000 Series NX-OS Security Configuration Guide.

Note: Live Protect shield is a temporary mitigation to bridge the gap until software updates can be scheduled. To fully remediate this vulnerability, upgrade to a fixed software release, which can be found using the Cisco Software Checker.

Overview

A vulnerability in the Silicon One integration for Cisco Nexus 9000 Series Switches could allow an unauthenticated, remote attacker to execute code with root privileges.

For additional information, refer to the security advisory at the following link:

https://sec.cloudapps.cisco.com/security/center/content/CiscoSecurityAdvisory/cisco-sa-n9k-s1-rce-EH8dEtr



Requirements

●      Affected switches

o   N9324C-SE1U

o   N9348Y2C6D-SE1U

o   N9364E-SG2-O

o   N9364E-SG2-Q

o   N9396T12C-SE1

o   N9348Y12C-SE1

o   N9396Y12C-SE1

o   N9336C-SE1

Note: The following switches are also affected but the Live Protect Shield is not supported on these platforms.

·       N9K-C9804

·       N9K-C9808

Any Cisco Nexus Switches other than the above mentioned ones are not affected.

●        Access: SSH, Telnet, or NXAPI access required for deployment.

Supported Releases

Cisco NX-OS Release 10.6(3)

Shield behavior during Upgrade and Downgrade

Upgrade: When upgrading to NX-OS 10.6(4) or higher, shield operational mode transitions to N/A.

Downgrade: When downgrading to NX-OS 10.6(2), the shield will not be removed. You must remove the shied prior to downgrade using nxsecure policy remove method. For information about Live Protect for Cisco NX-OS Software, see Cisco Nexus 9000 Series NX-OS Security Configuration Guide.

Verification & Deployment Flow

The following process map outlines the validation path after policy deployment:



Verification Details

Policy Status

Use the following command to confirm the shield is in enforce mode:

Shield Log Output

To inspect the hit events, use:

Shield Syslog

A syslog is received for every hit:

Reference

For detailed installation steps about Live Protect for Cisco NX-OS Software, see Cisco Nexus 9000 Series NX-OS Security Configuration Guide.
