The Cisco Webex® Room Kit Pro provides a powerful and flexible platform for creating the ultimate video collaboration experience – large, custom video rooms, including boardrooms, auditoriums, and purpose-built rooms for vertical applications. The Room Kit Pro is the most advanced product within the Room Kit Series, built with integrators in mind and enabling flexibility and creativity for customized video collaboration rooms that delight customers.

The Room Kit Pro acts as the audio and video engine for Ultra-High-Definition (UHD) video collaboration applications and AV integrations in which multiple screens, cameras, and content sources may be required – whether with the Cisco Webex Quad Camera, Precision 60 Camera, or SpeakerTrack 60 dual camera. The Room Kit Pro continues the same artificial intelligence capabilities already offered on the rest of the Cisco Webex Room Series: intelligent views, noise suppression, voice commands, and people count.

The Room Kit Pro delivers up to 2160p60 end-to-end UHD video. The codec’s rich set of video and audio inputs, flexible media engine, and support for up to three screens enable a variety of use cases, adaptable to your specific needs. The Room Kit Pro can register on premises or to Cisco Webex in the cloud.

The Room Kit Pro supports intelligent cameras and functionality to enable dynamic viewing capabilities in video meetings:

     Cisco Webex Quad Camera: Camera system with four embedded digital cameras that enable best overview and speaker tracking capabilities. With the Quad Camera, the Room Kit Pro can also deliver analytics such as people count.

     Cisco® SpeakerTrack 60 Camera: Dual camera system featuring a unique direct, fast-switching approach for speaker tracking with two Precision 60 cameras.

     Cisco PresenterTrack: Makes it easier for presenters to move around the front of the room, using the Precision 60 Camera to follow a presenter within a defined zone.

With its powerful media engine, the Room Kit Pro lets you build the video collaboration room of your dreams.


Figure 1.

Cisco Webex Codec Pro

Cisco offers three options to purchase the Cisco Webex Room Kit Pro:

     Room Kit Pro: Codec Pro, Quad Camera, and Touch 10

     Room Kit Pro Precision 60: Codec Pro, Precision 60 Camera, and Touch 10

     Codec Pro: Codec only


Figure 2.

Cisco Webex Room Kit Pro integrator package with Quad Camera and Touch 10

Bringing more intelligence to large and specialized rooms

The Cisco Webex Room Kit Pro is video innovation in box, bringing more intelligence and usability to your to your largest and specialized collaboration rooms and spaces. While others are still struggling to insert advanced features such as speaker tracking, wireless sharing, and 4K content into their high-end products, Cisco is already proliferating these innovations to meeting rooms of all sizes in a cost-effective and simple way. With the Room Kit Pro, Cisco is helping customers experience smarter meetings, enable smarter presentations, and create smarter room and device integrations. And when registered to the Cisco Webex in the cloud, additional cloud-based functionalities are enabled that enhance the user experience and team workflow as well as further simplifying deployment.

     Smart meetings: Powerful, integrated cameras deliver intelligent view capabilities, such as automatic framing and speaker tracking; automatic noise suppression reductions meeting disruptions

     Smart presentations: Supports up to three screens, dual content sources, wireless sharing, and 4K content make for great presentations

     Smart integrations: People count for usage metrics and resource allocation; tight integrations with screens to enhance user interactions; APIs and macros allow meeting personalization

     Registration flexibility: Built for both cloud and on-premises deployment, protecting your investment

Product features

Table 1 summarizes the key features of the Cisco Webex Room Kit Pro.

Table 1.          Feature summary

Feature Summary



Design features

  One of the most powerful and feature-rich codecs available, with the ultimate in video and audio quality
  UHD resolution to support large screen surfaces
  1.5 Rack Units (RU) high, rack mountable, with optional rack-mounting solution
  Professional-grade connectors using Euroblock / Phoenix
  Unmatched quality and flexibility
  Standards-compliant 1080p and 2160p solution, compatible with standards-based video without losing features

Application features

  Supports Cisco Intelligent Proximity for content sharing to mobile devices and wireless sharing from Macs and PCs
  Supports switched conferencing for enhanced layouts and enabling video on multiple screens
  Easy control of room peripherals such as lights, room dividers, and curtains directly from the Touch 10 through the API (requires external third-party control system processor)
  Limitless integration possibilities
  Participate in Cisco Webex Teams whiteboarding sessions from the Webex Teams app; receive on-screen notification of shared whiteboard content (supported on cloud-registered devices)
  Embedded MultiSite with up to 5 participants
  6 simultaneous video inputs that can be combined individually on all 3 outputs
  Calls with HD video and UHD content
  Simplified join-meeting experience with One Button to Push (OBTP)
  Ideal for team-based collaboration, boardrooms, meeting rooms, and industry applications

Performance features

  Optimal definition up to 1080p60
  Up to 15 Mbps total MultiSite bandwidth (6 Mbps in point-to-point calls)
  6 simultaneous video inputs - 3 4K and 3 Full HD
  Connect up to 8 microphones directly to the codec
  Full-duplex audio with high-quality stereo sound
  Full API
  Cisco Media Assure packet loss protection (Cisco ClearPath also supported)

Product capabilities

Table 2 lists the specifications for the Cisco Webex Room Kit Pro and select specifications for relevant cameras and peripherals where noted.

Table 2.             Product specifications

Specification

Description

Software compatibility

  Cisco Collaboration Endpoint (CE) Software Version 9.4 or later, or Cisco Webex Room OS

Default components in Room Kit Pro

  Cisco Webex Codec Pro
  Cisco Webex Quad Camera (a package is also available with the Precision 60 camera)
  Cisco Touch 10 control unit
  Wall mount for Quad Camera

Optional hardware components

  Cisco Table Microphone (with Euroblock plug), wall mount for Codec Pro, rack mount for Codec Pro, various cables

Bandwidth

  Up to 6 Mbps point-to-point

Minimum bandwidth for resolution/frame rate

  720p30 from 768 kbps
  720p60 from 1152 kbps
  1080p30 from 1472 kbps
  1080p60 from 2560 kbps

Firewall traversal

  Cisco Expressway technology H.460.18, H.460.19 firewall traversal

Video standards

  H.264, H.265, H.263 for TANDBERG MXP interop only (check Admin Guide)

Video inputs (6)

  2 HDMI inputs support formats up to maximum 1080p60
  3 HDMI inputs support formats up to maximum UHD (3840 x 2160) @ 30 fps including HD1080p60
  One 3G-SDI/HD-SDI input supports formats up to maximum 1080p60
  Extended Display Identification Data (EDID)
  Consumer Electronics Control (CEC) 2.0

Video outputs (3)

  2 HDMI outputs support formats up to 3840 x 2160@60 fps (4Kp60)
  1 HDMI output supports formats up to 3840 x 2160@30 fps (4Kp30)
  CEC 2.0

Encode and decode

  Video stream: Full HD 1080p60
  Content stream: 4K 2160p15

Audio standards

  G.711, G.722, G.722.1, G.729AB, 64 kbps and 128 kbps MPEG4 AAC-LD mono and stereo, OPUS

Audio features

  High quality 20-kHz audio
  8 separate acoustic echo cancellers
  8-port audio mixer
  8 assignable equalizers
  Automatic Gain Control (AGC)
  Automatic noise reduction
  Active lip synchronization

Audio inputs

  8 microphones, 48V phantom powered, Euroblock connector, each with separate echo cancellers and noise reduction; all microphones can be set for balanced line level
  3 HDMI, digital: stereo PC/DVD input

Audio outputs

  6 balanced line level outputs, Euroblock connector
  3 HDMI outputs
  HDMI input #1 supports Audio Return Channel (ARC) audio output to Quad Camera
  1 line out for subwoofer (Quad Camera)

Speakers (Quad Camera)

  High-quality speakers
  Frequency response 70 Hz to 20 kHz
  Max output level SPL 90 dB

Speaker tracking (Quad Camera, SpeakerTrack 60)

  6-element microphone array for accurate speaker tracking

Dual stream

  H.239 (H.323) dual stream
  BFCP Session Initiation Protocol (SIP) dual stream
  Supports resolutions up to 3840 x 2160p15 fps and 1080p60

Wireless sharing

  Cisco Webex clients (up to 3840 x 2160p5)
  Cisco Intelligent Proximity client (up to 1920 x 1080p5)

Multipoint support

  5-way embedded SIP/H.323 conferencing capability with MultiSite option

MultiSite features (embedded multipoint) (optional upgrade)

  Adaptive SIP/H.323 MultiSite:
   3-way resolution up to 1080p30 plus content up to 4Kp15
   4-way resolution up to 720p30 plus content up to 4Kp15
   5-way resolution up to 720p30 plus content up to 4Kp15
  Full individual audio and video transcoding
  H.323, SIP, and VoIP in the same conference
  Support for presentation (H.239, BFCP) from any participant at resolutions up to 3840 x 2160p5
  Best impression (automatic continuous presence layouts)
  Encryption and dual stream from any site

Protocols

  H.323
  SIP
  Cisco Webex

Embedded encryption

  H.323 and SIP point-to-point
  Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
  Automatic key generation and exchange

IP network features

  DNS lookup for service configuration
  Differentiated Services (DiffServ) (Quality of Service [QoS])
  IP-adaptive bandwidth management (including flow control)
  Automatic gatekeeper discovery
  Dynamic playout and lip-sync buffering
  H.245 dual-tone multifrequency (DTMF) tones in H.323
  DTMF tones in SIP, RFC 4733
  Date and time support using Network Time Protocol (NTP)
  Packet loss-based down speeding
  Uniform Resource Identifier (URI) dialing
  TCP/IP
  Dynamic Host Configuration Protocol (DHCP)
  802.1X network authentication
  802.1Q Virtual LAN
  802.1p QoS and class of service
  Cisco Media Assure and ClearPath

Call control

  Cisco Collaboration Cloud / Webex
  Cisco Unified Communications Manager (CUCM)
   Native registration CUCM
   Requires CUCM Version 10.5.2 or later with device pack for Room Kit Pro
  Cisco TelePresence Video Communication Server (VCS)
   Native registration with VCS
  Third-party H.323 gatekeepers and standards-based SIP proxies

IPv6 network support

  Single call stack support for both H323 and SIP
  Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
  Support for static IP address assignment, stateless auto-configuration, and DHCP v6

Security features

  Management using HTTPS and SSH
  IP administration password
  Password to access administration features on Touch controller
  Disable IP services
  Network settings protection

Certificate management

  Certificate Authority Proxy Function (CAPF) support for additional security
  Manufacturer-Installed Certificates (MIC)
  Locally Significant Certificates (LSC)
  X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported

Network interfaces Codec Pro

  1 Ethernet (RJ-45) 10/100/1000 for LAN
  2 Ethernet (RJ-45) 10/100/1000 for direct pairing with camera (camera control)
  2 Ethernet (RJ-45) 10/100/1000 with PoE, 1 dedicated for direct pairing with Touch 10
  Wi-Fi 802.11a/b/g/n/ac 2.4 GHz and 5 GHz for LAN
  2x2 multiple input and multiple output (MIMO)

Other interfaces

  2x USB A port, USB-B, uUSB, factory reset pinhole

Power supply (Quad Camera)

  100 to 240 VAC, 50/60 Hz, 12V DC input
  Standby 6W, average 20W, peak 70W

Operating temperature and humidity

  0° to 40°C (32° to 104°F) ambient temperature
  10% to 90% Relative Humidity (RH)

Storage and transport temperature

  -20° to 60°C (-4° to 140°F) at RH 10% to 90% (noncondensing)

Dimensions


Quad Camera:

  Width: 37.4 in. (95.0 cm)
  Height: 4.7 in. (12.0 cm)
  Depth: 4.0 in. (10.3 cm)
  Weight: 10.6 lb (4.8 kg)


Codec Pro:

  Width: 17.1 in. (43.6 cm)
  Height: 2.6 in. (6.6 cm)
  Depth: 9.1 in. (23.1 cm)
  Weight: 7.3 lb (3.3 kg)



Camera Overview

5K Ultra HD camera

Support up to 60 fps

15.1 MP image sensor

1/1.7 CMOS

5x digital zoom (3 tele-lenses each with 50° horizontal field of view)

f/2.0 aperture

83° horizontal field of view; 51.5° vertical field of view

Auto-framing (audio + face detect)

Regulatory compliance

     Directive 2014/30/EU (EMC Directive) and Directive 2014/35/EU (Low-Voltage Directive) for the non-radio versions

     Directive 2014/53/EU (Radio Equipment Directive) for the radio versions

     Directive 2011/65/EU (RoHS)

     Directive 2002/96/EU (WEEE)

     NRTL approved (Product Safety)

     FCC Listed (Radio Equipment)

Standards

     Radio: EN 300 328, EN 301 893, EN 300 440 (only for the radio versions)

     EMC: EN 301 489-1 & -17 (only for the radio versions), EN 55032 - Class A, EN 55024

     Safety: EN 60950-1 (for radio and non-radio), EN 62479, EN 62311 (for the radio versions)

     FCC CFR 47 Part 15B (EMC) – Class A

     FCC CFR 47 Part 15C (RF)

     FCC CFR 47 Part 15E (RF)

Please check the Product Approval Status Database https://www.ciscofax.com/ for approval documents per country.

Ordering information

To place an order, please contact your local Cisco representative and refer to Table 3.

Table 3.             Ordering information

Product Name

Part Number

Compliance Model Number

Cisco Room Kit Pro – GPL, including

Codec Pro

Quad Camera

Touch 10 control unit

CS-KITPRO-K9

CS-CODEC-PRO+

CS-QUADCAM+

CTS-TOUCH10+

NA

TTC6-13

TTC8-10

TTC5-09

Cisco Webex Room Kit Pro with Precision 60 – GPL, including

Codec Pro

Precision 60 Camera

Touch 10 control unit

CS-KITPRO-P60-K9

CS-CODEC-PRO+

CTS-CAM-P60

CS-TOUCH10+

TTC6-13

TTC8-07

TTC5-09

Cisco Webex Codec Pro – GPL, including

Codec Pro

CS-CODEC-PRO-K9

CS-CODEC-PRO+

TTC6-13

TTC6-13

Cisco Webex Codec Pro, No Radio – GPL

Codec Pro – No Radio

CS-CODEC-PRO-NR-K9

CS-CODEC-PRO-NR+

TTC6-13

TTC6-13

Cisco Webex Codec Pro – TAA compliant, including

Codec Pro – TAA, No Radio, or

Codec Pro – TAA

CS-CODEC-PRO-K9++

CS-CODEC-PRO-NR++

CS-CODEC-PRO++

TTC6-13

TTC6-13

TTC6-13

Cisco Webex Codec Pro, No Radio, nonencrypted – GPL

Codec Pro – No Radio

CS-CODEC-PRO-K7

CS-CODECPRO-NR-K7+

TTC6-13

TTC6-13

Options

Rack ears for Codec Pro

CS-CPRO-RACKEARS

Wall-mount kit for Codec Pro

CS-CPRO-WMK

Cisco Table Microphone with Euroblock connector

CS-MIC-TABLE-E

TTC5-14

Extension cable for Table Microphone

CAB-MIC-EXT-E

Cisco Ceiling Microphone

CTS-MIC-CLNG-G2

TTC5-13

Shielded cable for Ceiling Microphone (non-plenum rated)

CAB-ETHRSHLD-10M

8 m/26 ft HDMI 2.0 certified cable

CAB-PRES-2HDMI-GR

HDMI 2.0 cable 1.5 m/5 ft, gray

CAB-2HDMI-1.5M-GR

HDMI 2.0 cable 3 m/10 ft, gray

CAB-2HDMI-3M-GR

Ethernet cable 1.5 m/5 ft, gray

CAB-ETH-1.5M-GR

Ethernet cable 3 m/10 ft, gray

CAB-ETH-3M-GR

Ethernet cable 5 m/16.4 ft, gray

CAB-ETH-5M-GR

Software options – ordered separately

Remote Monitoring

L-KIT-RM (L-TP-RM)

-

MultiSite (embedded multipoint)

L-KITPRO-MS

-

Spares

Cisco Webex Codec Pro

CS-CODEC-PRO=

TTC6-13

Cisco Webex Codec Pro – No Radio No Crypto

CS-CODEC-PRO-NR-K7=

TTC6-13

Cisco Webex Quad Camera

CS-QUADCAM=

TTC8-10

Cisco Precision 60 Camera

CTS-CAM-P60=

TTC8-07

Cisco Service and Support

Cisco and our partners provide a broad portfolio of smart, personalized services and support that can help you realize the full business value of your Cisco investment by increasing business agility and network availability. This portfolio of services accelerates business innovation by harnessing the network as a powerful business platform.

Cisco environmental sustainability

Information about Cisco’s environmental sustainability policies and initiatives for our products, solutions, operations, and extended operations or supply chain is provided in the “Environment Sustainability” section of Cisco’s Corporate Social Responsibility (CSR) Report.

Reference links to information about key environmental sustainability topics (mentioned in the “Environment Sustainability” section of the CSR Report) are provided in the following table:

Sustainability topic

Reference

Information on product material content laws and regulations

Materials

Information on electronic waste laws and regulations, including products, batteries, and packaging

WEEE compliance

Cisco makes the packaging data available for informational purposes only. It may not reflect the most current legal developments, and Cisco does not represent, warrant, or guarantee that it is complete, accurate, or up to date. This information is subject to change without notice.

Cisco Capital

Flexible payment solutions to help you achieve your objectives

Cisco Capital makes it easier to get the right technology to achieve your objectives, enable business transformation and help you stay competitive. We can help you reduce the total cost of ownership, conserve capital, and accelerate growth. In more than 100 countries, our flexible payment solutions can help you acquire hardware, software, services and complementary third-party equipment in easy, predictable payments. Learn more.

For more information

     Learn more about the Cisco Webex Room Kit Pro.

     Download the Cisco Webex Teams app.

Learn more
