Automated deployment automates the day-zero experience of securely onboarding and deploying the NFVIS WAN Edge device, with default factory shipped settings, into the SD-WAN network.
Automated deployment discovers the vBond IP address dynamically using the PnP process for the ENCS physical platform.
The following are the primary requirements to use this onboarding option:
The NFVIS WAN Edge device must be connected to a WAN transport that can provide a dynamic IP address, default-gateway and DNS information.
If you have a static IP address, you must configure the IP address using the following configuration example:
configure terminal bridges bridge wan-br no dhcp bridges bridge wan-br no dhcp system settings wan ip address 188.8.131.52 255.255.255.0 system settings default-gw 184.108.40.206 system settings dns-server 220.127.116.11 pnp automatic dhcp disable pnp automatic dns disable pnp automatic cco enable commit
The NFVIS WAN Edge device can DNS resolve devicehelper.cisco.com for the Plug-and-Play Connect server.
In Cisco vManage, a device configuration must be built and attached to the WAN Edge device to successfully onboard the device.
Use the show pnp status command to view the progress of PnP redirection to Cisco vBond.
Device# show pnp status pnp status response PnP Agent is not running server-connection status: Success time: 22:22:20 Dec 09 device-info status: Success time: 22:09:19 Dec 09 capability status: Success time: 22:06:17 Dec 09 redirection status: Success time: 22:25:46 Dec 09 certificate-install status: Success time: 22:51:26 Dec 09 device-auth status: Success time: 22:01:29 Dec 09 pnp status ip-address "" pnp status ipv6-address "" pnp status port "" pnp status transport "" pnp status cafile "" pnp status created_by user pnp status dhcp_opt43 0 pnp status dns_discovery 0 pnp status cco_discovery 0 pnp status dhcp-ipv6 0 pnp status dns-ipv6 0 pnp status cco-ipv6 0 pnp status timeout 0
In case of any failure, you can use the pnp action command stop , pnp action command start or pnp action command restart command to start, stop or restart the process.
