Cisco Table Microphone Pro Data Sheet
Available Languages
Bias-Free Language
The documentation set for this product strives to use bias-free language. For the purposes of this documentation set, bias-free is defined as language that does not imply discrimination based on age, disability, gender, racial identity, ethnic identity, sexual orientation, socioeconomic status, and intersectionality. Exceptions may be present in the documentation due to language that is hardcoded in the user interfaces of the product software, language used based on RFP documentation, or language that is used by a referenced third-party product. Learn more about how Cisco is using Inclusive Language.
The Cisco Table Microphone Pro recessed into the table in a conference room.
Cisco Table Microphone Pro is a multi-directional audio peripheral designed to bring advanced voice capture and audio processing to your meeting rooms of all sizes and thus create an elevated, inclusive audio experience for people joining video meetings remotely.
It is a digital table microphone device that supports Audio over IP technology for supreme sound quality, seamless deployment and scalability, and unified device management while providing seamless plug-and-play connectivity with the latest generation of Cisco room kits and video conferencing endpoints.
The Cisco Table Microphone Pro used with the extended Cisco Room Kit EQ bundle to provide multi-directional speech pickup from a large meeting room.
The Table Microphone Pro uses multi-directional voice capture pattern that intelligently tracks and picks up speech only where the voice is coming from and minimizes signals from other parts of the room to enable an immersive and distraction-free audio experience for far end meeting participants. Recognized in the Red Dot Awards for outstanding product design, the Table Microphone Pro is powered and controlled via Power over Ethernet connectivity and augmented by Cisco’s proprietary end-to-end encryption when connected to a video endpoint to always keep your team’s communications safe and secure. Just like Cisco video collaboration endpoints, it can be centrally managed in Control Hub alongside your entire Cisco collaboration device deployment, providing seamless cloud admin, monitoring, and device analytics for IT administrators.
You can use the Cisco Table Microphone Pro as a single unit or connect multiple microphone devices with video conferencing endpoints through an external switch to solve voice pickup in the largest of workspaces. It works seamlessly with Cisco video bars, collaboration kits and integrated room devices without the need for an external Digital Signal Processor (DSP) unit. The table microphone stands out with its remarkably compact and aesthetic form factor, featuring a capacitive mute button and a tri-color LED light which shows mute status at a distance. To bring flexibility to any deployment, the Table Microphone Pro offers multiple mounting options: it can be placed on the table with the Ethernet cable remaining visible or completely hidden from view or can be recessed into the table for an even cleaner conference table setup and the best possible speech pickup quality.
Table 1. Features and benefits
| Feature |
Benefit |
| Multi-directional speech capture |
● Multi-directional, adaptive voice capture that only picks up speech from the active speaker(s) and filtering noise coming from other directions – resulting in a high signal-to-noise ratio and improved acoustic experience for remote participants.
● Each device contains 4 main microphone elements for voice pickup, enabling a directional capture of audio in the room. This gives remote participants a crisp, spatial sound experience of being in the same room with all participants during calls.
● It captures participant voices from different directions and delivers multiple streams of high-fidelity audio. The microphone recognizes which side of the table the speaker is on and enables a spatial audio experience for far-end participants (requires a video endpoint or speaker system that supports directional audio to be used on the far end) by emitting sound closer to the in-room participant’s live video feed.
● The microphone’s built-in noise cancellation architecture and audio processing is augmented by Machine Learning-based noise removal when connected to the video endpoint to block out unwanted noises.
● Applies intelligent levelling, equalization and mixing of voices captured to enable natural sound for participants on the far end
|
| Unified device management and robust security |
● Powered by Ethernet connectivity, the microphone is fully manageable via Control Hub alongside Cisco video endpoints and collaboration peripherals
● Eases the IT admin experience with a single dashboard for cloud device management, configurations, and device metrics
● The microphone is unique in supporting Cisco’s proprietary encryption to help ensure that conversations are captured and processed in a safe and secure way without exposing them to the network, helping organizations meet stringent data security requirements
|
| Flexible deployment |
● The microphone is simple to set up and configure and works seamlessly with Cisco video endpoints out of the box, without the need to deploy an external Digital Signal Processor.
● It supports Audio over IP (AoIP) technology to help organizations make their room deployment easier to install and scale, leverage better compatibility and manageability, and benefit from excellent, lossless audio quality
● Up to 8 microphones can be connected to optimize room coverage (consult with your sales representative about the number of microphones supported by the specific video endpoint).
● Each device can connect directly to the video endpoint or to a single switch in case of a series of microphones deployed, meaning only one Ethernet cable is needed between the table and the video system.
|
| Intuitive design |
● Clear status light: toggling from speech to mute mode is enabled via a concave capacitive touch button that enables silent handling while a discrete tri-color LED gives feedback around mute status.
● The design showcases simple and elegant aesthetics and is yet robust for everyday use. Its size is remarkably compact for its powerful capabilities.
● The magnetic attachment to the table adapters enables a simple and versatile mounting experience: the on-table configuration provides two optional cable outlets to streamline the cable presence or even hide the cabling completely, and when set up recessed into the table, the microphone blends in even more and hides the cable from view.
● The device has been recognized in the Red Dot Design Awards for outstanding product design
|
Mounting options of the Table Microphone Pro.
Table 2. Outlines the product specifications of the Cisco Table Microphone Pro
| Specification |
Description |
| Description |
Digital conferencing table microphone, supporting cardioid pickup pattern and 4 independent microphone channels |
| Product compatibility |
● Cisco Room Bar Pro•
● Cisco Room Kit EQ•
● Cisco Room Kit EQX•
● Cisco Room Kit Pro•
● Cisco Room Panorama•
● Cisco Room 70 Panorama and Room 70 Dual Panorama Upgrade•
● Cisco Board Pro 55 / 75
|
| Connector |
● Attached 11m cable (36ft) with RJ45 Ethernet connector
|
| Other ports |
● Micro USB service port
● Factory Reset pinhole
|
| Software features |
● Acoustic Echo Cancellation (AEC) – Microphone feature
● Automatic Handling Noise Attenuation – Microphone feature
● Cisco proprietary encryption
● AI-Powered Noise Removal
● Automatic Gain Control (AGC)
|
| Frequency range |
● 100 Hz to 16 kHz, +/- 6 dB (on axis)
|
| Free field sensitivity |
●
-22 dBFS +/- 3 dB rel 1V/Pa, 1kHz
|
| Signal-to-noise ratio |
● Minimum 70 dB
|
| User interface |
● Capacitive touch mute button in top of the microphone for easy accessibility
● Multi-color LED showing mute status
● Power light
|
| Mounting options |
The Table Microphone Pro can be integrated to the table in two different ways:
● Flush mounted and recessed into the table
● On top of the table (the cabling can be routed through a hole drilled into the table to remain hidden or, alternatively, routed along the top of the cable where the cable remains visible)
For more detailed guidance around the microphone placement and mounting options, please consult the Cisco Table Microphone Pro Installation Guide. |
| Device management |
Unified cloud device management, device controls, monitoring, and analytics in Control Hub alongside Cisco video endpoints and peripherals. |
| Physical dimensions |
● Diameter: 9,8 cm (3,85 inches)
● Height: 2,9 cm (1,15 inch)
● 9,8 x 9,8 x 2,9 cm (3.85 x 3.85 x 1.15 in)
● Attached cable length: 11 m (36 feet)
For more detailed dimensions for tabletop and in-table mounting, please consult the Table Microphone Pro CAD Drawings. |
| Weight |
0.29 lb / 0.3 kg |
| Power consumption |
5W - Power over Ethernet |
| Default components |
● Microphone unit
● Ethernet cable (11m)
● Mounting kit for on-table and in-table assembly
|
| Operating temperature and humidity |
● 0°C to 35°C (32°F to 95°F) Ambient Temperature
● 20% to 90% Relative Humidity (noncondensing)
|
| Storage and transport temperature and humidity |
● -20°C to 60°C (-4°F to 140°F) Ambient Temperature
● 10% to 90% Relative Humidity (noncondensing)
|
| Standards and regulatory compliance |
● FCC CFR 47 Part 15B (EMC)
● Directive 2014/30/EU (EMC Directive)
●
Directive 2014/35/EU (Low-Voltage Directive)
● Directive 2011/65/EU (RoHS)
● Directive 2002/96/EU (WEEE)
● NRTL approved (product safety)
Please check the Product Approval Status Database at www.ciscofax.com/ for approval documents per country. |
| Sustainability |
● Circular design principles applied for product architecture, materials, and packaging
● Foam-free, 100% recyclable packaging with a reduced amount of single-use plastics
● Post-Consumer Recycled (PCR) resin used in cosmetic parts originating from end-of-life Cisco devices and old electronics on cosmetic parts
● The microphone is designed for easy repair, refurbishing, and recycling to extend the lifecycle of the product and the materials used for manufacturing
● Power over Ethernet (PoE) connects and powers the microphone enabling smarter energy consumption.
● Cisco’s takeback and reuse program enables you to return your end-of-use devices for free, via a simple, secure, and sustainable process.
● Learn more about how Cisco supports the
Circular Economy.
|
Information about Cisco’s Environmental, Social and Governance (ESG) initiatives and performance is provided in Cisco’s CSR and sustainability reporting.
Table 3. Cisco environmental sustainability information
| Sustainability topic |
Reference |
|
| General |
Information on product-material-content laws and regulations |
|
| Information on electronic waste laws and regulations, including our products, batteries and packaging |
||
| Information on product takeback and reuse program |
||
| Sustainability Inquiries |
Contact: csr_inquiries@cisco.com |
|
| Material |
Product packaging weight and materials |
Contact: environment@cisco.com |
Warranty information is available on Cisco.com at the Product Warranties page.
Tables 4 gives ordering information for the Cisco Table Microphone Pro. To place an order, visit the Cisco® Ordering homepage. To download software, visit the Cisco Software Center.
Table 4. Ordering information
| Product name |
Part number |
Compliance model number |
| Cisco Table Microphone Pro |
CS-MIC-ARRAY-T |
TTC5-17 |
| Cisco Table Microphone Pro - Spare |
CS-MIC-ARRAY-T= |
TTC5-17 |
