Cisco UCS C250 M1 Extended-Memory Rack-Mount Server

Hierarchical Navigation
NOTE: This product is no longer being sold and might not be supported. View the End-of-Life Notice to learn:
  • End-of-sale and end-of-life dates
  • What replacement products are available
  • Information about product support

High-Performance, Memory-intensive Server

Compare C-Series Rack Mount Server Models

View Video About Cisco Extended Memory Technology

UCS C250 M1 Rack Mount Server

Video Data Sheet

Learn more about Cisco extended memory rack server innovation within industry standards (4:15 min)

Viewing this embedded video requires the latest version of Adobe Flash Player with JavaScript enabled.
Get the Flash Player

View Interactive Model of Cisco UCS C250 M1

The Cisco UCS C250 M1 server is a high-performance, memory-intensive, two-socket, 2RU rack-mount server designed to increase performance and capacity for demanding virtualization and large-data-set workloads. It also can reduce the cost of smaller memory footprints.

The system is built for virtualized workloads in:

  • Enterprise data centers
  • Service provider environments
  • Virtual desktop hosting

The system can also help increase performance for large-data-set workloads, including database management systems and modeling and simulation applications.

  • Up to two Intel Xeon 5500 Series multicore processors
  • Up to 384 GB of industry-standard double-data-rate (DDR3) main memory (48 dual in-line memory modules [DIMMs])
  • Up to eight internal small form factor (SFF), (SAS), or (SATA) drives; up to 4 TB total
  • RAID 0 and 1 support for up to eight SAS or SATA drives through optional PCI Express (PCIe) controller; and RAID 0, 1, 5, 6, 10, 50, and 60 support for up to eight SAS or SATA drives with optional LSIMegaRAID adapter
  • Support for up to five PCIe cards in three low-profile, half-length x8 and two full-height, half-length x16 slots
  • Four integrated Gb Ethernet ports and two 10/100 Mbps Ethernet management ports for accessing the Cisco UCS Integrated Management Controller
  • Front-panel interface with video, two USB, and serial port connections. Back-panel video, two USB, and serial port connections
  • Increased reliability, availability, and serviceability through optional dual-redundant power supplies and front panel-accessible hot-swap cooling fans

Compare network adapter cards for the Cisco UCS C-Series Rack-Mount Servers

Featured Content

Cisco Extended Memory Technology Overview Video (3:29 min)
See how Cisco's patented technology increases performance and capacity for demanding virtualization and large-data-set workloads.

Cisco UCS C250 M1 At A Glance (PDF - 786 KB)
Learn how you can get extended memory for demanding workloads.

Managing Cisco UCS C-Series Servers (PDF - 337 KB)
Learn more about this comprehensive, flexible, and standards-based set of management capabilities.

A Short Primer on Cisco Extended Memory (PDF - 300 KB)
Cisco Extended Memory Technology provides more cost effective large memory footprints for virtualized as well as nonvirtualized workloads.
