The Cisco® CRS-1 Carrier Routing System is the industry's first carrier router offering continuous system operation, unprecedented service flexibility, and system longevity. The Cisco CRS-1 is powered by Cisco IOS® XR Software - a unique self-healing, distributed operating system. As part of a video-enabled IP Next-Generation Network (NGN), the Cisco CRS-1 Series delivers continuous, always-on operation that easily scales to support the massive bandwidth requirements of visual networking experiences such as high-definition IPTV and Cisco TelePresence. These services demand a platform that delivers predictable forwarding performance and efficient, intelligent fabric-based multicast replication. The Cisco CRS-1 Series enables the Internet and NGNs to handle the approaching zettabyte era of carrier IP communications while protecting network investments for decades to come.
The Cisco CRS-1 Series 20-Port Gigabit Ethernet Flexible Interface Module (Figure 1) provides 20 ports of IEEE 802.3-compliant Gigabit Ethernet interfaces and two available Cisco I-Flex shared port adapter (SPA) slots. By providing service intelligence, modularity, and configuration flexibility with fully compatible SPAs, the Cisco I-Flex design offers carriers long-term savings and the ability to handle evolving service delivery requirements, such as SONET-to-Ethernet.
The SPAs can be a mix of Ethernet or Packet over SONET/SDH (POS), and are identical to the SPAs used in other Cisco platforms such as the Cisco XR 12000 Series and the Cisco CRS Carrier Routing System. Gigabit Ethernet physical interface characteristics can be selected using different modular Small Form-Factor Pluggable (SFP) optics - short, long, extra long, and copper interfaces are supported. Extensive per-port and per-VLAN counters simplify network performance monitoring and troubleshooting.
Short-term: 5% to 90% but not to exceed 0.024 kg water/kg of dry air
Short-term refers to a period of not more than 96 consecutive hours and a total of not more than 15 days in 1 year. (This refers to a total of 360 hours in any given year, but no more than 15 occurrences during that 1-year period.)
Approvals and Compliance
Table 2. Compliance and Agency Approvals
IEC/EN 60825 Laser Safety
FDA - Code of Federal Regulations Laser Safety
FCC Class A
ICES 003 Class A
AS/NZS 3548 Class A
CISPR 22 (EN55022) Class A
VCCI Class A
BSMI Class A
IEC/EN 61000-3-2: Power Line Harmonics
IEC/EN 61000-3-3: Voltage Fluctuations and Flicker
Cisco offers numerous innovative services programs to accelerate customer success. These programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you to protect your network investment, optimize network operations, and prepare the network for new applications to extend network intelligence and the power of your business. For more information about Cisco services, see Cisco Technical Support Services or Cisco Advanced Services.
For More Information
For more information about the Cisco CRS-1 Series 20-Port Gigabit Ethernet Flexible Interface Module, contact your local account representative or visit: www.cisco.com/go/crs
