Cisco Catalyst 4506-E Switch Video Data Sheet
Video Data Sheet
The Catalyst 4506-E is ideal for wiring closet deployments and branch aggregation deployments. (2:48 min)
Viewing this embedded video requires the latest version of Adobe Flash Player with JavaScript enabled.
Get the Flash Player
| Cisco Catalyst 4506-E Chassis Features | |
|---|---|
Total Number of Slots |
6 |
Supervisor Engine Slots |
1¹ |
| Line Card Slot Speed | 24Gbps and 6Gbps |
Supervisor Engine Redundancy |
No |
Supervisor Engines Supported |
Supervisor Engine 6-E, 6L-E, V-10GE, V, IV, II-Plus-10GE, II-Plus) |
Line Card Slots |
5¹ |
Line Card Supports |
E-Series and Classic³ |
Number of Power Supply Bays |
2 |
AC/DC Input Power |
Yes |
Integrated PoE |
Yes |
Minimum Number of Power Supplies |
1 |
