Cisco WebEx Cloud Connected Audio

Cost-Effective Audio Conferencing

Cisco WebEx Cloud Connected Audio (CCA) is a cost-effective audio conferencing solution for Cisco WebEx meetings. It extends the functionality of Cisco Unified Communications Manager and incorporates on-premises equipment to connect your organization to a Cisco WebEx Cloud data center via dedicated peering connections. It is designed for enterprise customers using a minimum of 1.5 million audio conferencing minutes per month.

Customer Deployment Scenarios

Video Data Sheet

This video will provide an introduction and overview of Cisco WebEx Cloud Connected Audio, and show you how and where this solution can provide real benefits to your organization (4:58 min)

Features and Capabilities

With Cisco WebEx Cloud Connected Audio, call routing is performed on premises, call signaling and audio traffic occurs over redundant IP connections, and call mixing is done in the cloud.

Natively integrated to the Cisco WebEx meeting experience, this audio solution delivers an integrated attendee list, active speaker, video and audio switching, and hybrid audio support, in addition to all the dynamic tools of the market-leading conferencing solution.

  • Audio Cost Reduction: Reduces audio conferencing costs by eliminating public switched telephone network (PSTN) transport and termination charges for Internet calling
  • Feature Parity with WebEx: Fully integrated into WebEx conferencing
  • Investment Protection/Extension: Extends the investment benefits of Cisco Unified Communications Manager from IP telephony to conferencing
  • Ports-Based Pricing: Makes monthly audio costs predictable and easy to budget
  • Cloud-Based Solution: Removes the need to administer and maintain a complicated on-premises audio solution and makes all future enhancements and upgrades available without additional deployments

Specifications at a Glance

Media and Signaling

  • Supports audio compression codec G.711, SIP (Session Initiation Protocol) signaling, and RFC2833 for dual-tone multifrequency (DTMF).
  • Any non G.711 traffic will need to be transcoded at the customer premises.

Peering Connections

  • Circuit hand-offs must be optical Ethernet-based. Minimum Ethernet hand-off interface is Gigabit Ethernet; Link Aggregation Control Protocol (LACP) may be used to bundle multiple circuits.
  • Customer connects with Cisco WebEx at two or more WebEx locations. Connections can be configured in active/active mode.

Conferencing Telephone Numbers

  • Conference numbers belong to the customer. The customer will provide at least one toll and one toll-free number.
  • WebEx does not provide the WebEx PSTN numbers with Cisco WebEx CCA. The customer will also need to provide the international call-in numbers if applicable.
  • The customer must pass one Direct Inward Dialing (DID) Digital Number Identification Service (DNIS) to WebEx via the Cisco Unified Border Element for all conferencing numbers.

Hardware and Software Licenses

  • Supports both Cisco Integrated Services Routers (ISRs) and Aggregated Services Routers (ASRs). Hardware will depend upon Cisco WebEx CCA port requirements.
  • Supports redundant or active/active Cisco Unified Border Element licenses
