The Cisco® 7304 1-Port OC-12c/STM-4c ATM Line Card delivers the versatility and high performance to benefit a variety of applications. These applications include high-speed WAN uplinks in customer premises equipment (CPE) deployments, high-speed enterprise backbone networks, and high-speed uplinks for the Cisco 7304 Router as a medium-density, medium-speed, edge-aggregation router in Tier 2 and 3 service provider points of presence (POPs). The line card uses Small Form-Factor Pluggable (SFP) optics to provide a range of options.
Cisco 7304 1-Port OC-12c/STM-4c ATM Line Card
Developed for customers that need a combination of performance and deployment flexibility, the Cisco 7304 meets current and future requirements for a midrange router. The Cisco 7304 delivers high-performance forwarding and hardware-accelerated services in a compact 4-rack-unit (4-RU), 4-interface-slot form factor.
Powerful and flexible, the Cisco 7304 provides multiprotocol support, interface granularity, and high-availability features in a platform that is ideal for deployment in various applications such as high-end enterprise routing, medium-speed and medium-density leased-line aggregation in service provider Tier 2 and 3 POPs, and service provider-managed CPE deployments (Table 1). Providing WAN connectivity at speeds ranging from DS-3 through OC-48/STM-16, and LAN connectivity at speeds up to Gigabit Ethernet (through two 1000 Ethernet ports built into the Cisco Network Services Engine NSE-100 route processor), the Cisco 7304 supports a wide range of concurrently running applications and lives up to the high standards of the Cisco 7000 Series of midrange routers.
Table 1. Cisco 7304 Router Features and Benefits
1 port of OC-12/STM-4 ATM
Offers connectivity options for both enterprise and service providers customers
Up to 622 Mbps
Provides high-performance routing and connectivity
Online insertion and removal (OIR)
Allows for insertion of the card without rebooting the router
Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5) and IP over ATM
Provides flexibility to choose the protocol that best suits the customers' needs
2048 virtual circuits
Delivers high scalability to meet the needs of service providers
Offers various optical choices for customers
The Cisco 7304 1-Port OC-12c/STM-4c ATM Line Card (Tables 2 and 3) includes the following components:
• Full-duplex ATM interface
• Unspecified bit rate (UBR) and variable bit rate (VBR) (not real-time) service classes
Cisco 7304 1-Port OC-12c/STM-4c ATM Line Card, spare
OC12/STM-4 SFP, Multimode Fiber
OC12/STM-4 SFP, Single Mode, Intermediate Reach
OC12/STM-4 SFP, Single Mode, Long Reach (40 km)
OC12/STM-4 SFP, Single Mode, Long Reach (80 km)
Service and Support
Cisco Systems® offers a wide range of services programs to accelerate customer success. These innovative services programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you protect your network investment, optimize network operations, and prepare your network for new applications to extend network intelligence and the power of your business. For more information about Cisco services, visit Cisco Technical Support Services or Cisco Advanced Services sections of the Cisco.com Website.
