Cisco 12012 Gigabit Switch Router Air Filter Assembly Replacement and Upgrade Instructions
Product Numbers: GSR12-FLT-UPG =, GSR12-FLTR-ENH =
Document Order Number: DOC-7811554=
This document provides information for removing the GSR air filter assembly, which consists of the air filter and air filter tray, and replacing the assembly with an upgraded air filter and air filter tray assembly. This document contains the following sections:
•
Installation Safety and ESD Precautions
•Required Tools and Parts
•Safety Guidelines
•Preventing Electrostatic Discharge Damage
•Attaching the ESD-Preventive Strap
•Safety Warnings
•Removing the Air Filter Assembly
•Removing the Air Filter
•Removing the Air Filter Tray
•Installing the Air Filter Assembly
•Installing the Air Filter Tray
•Installing the Air Filter in the Air Filter Tray
•Attaching the Air Filter Tray
•Cisco Connection Online
•Documentation CD-ROM
Use this document in conjunction with the "Cisco 12012 GSR Installation and Configuration Guide", (Document Number 78-4331-xx) that supports your Cisco 12012 Gigabit Switch Router and the "Cisco12012 Gigabit Switch Router Air Filter Upgrade Supplement" (Document Number 78-11633-xx) which is provided with this document.
Installation Safety and ESD Precautions
Before installing or removing an air filter assembly, review the safety guidelines in this section to prevent injury to yourself or damage to the equipment. This section also lists the tools and parts that you will need to perform the remove and install procedures.
Required Tools and Parts
You will need the following tools and parts to remove the existing air filter assembly and install the replacement air filter assembly:
•Number 1 Phillips screwdriver
•M3 Phillips, pan head screws
•3/16-inch flat-blade screwdriver
•ESD-preventive wrist strap
•Air Filter Assembly — GSR12-FLT-UPG =
•Air Filter — GSR12-FLTR-ENH =
Note Save the five screws when removing the installed air filter tray, they will be used to secure the replacement air filter tray to the chassis.
Safety Guidelines
Observe the following guidelines to ensure your safety and protect the equipment. This list does not identify all of the potentially hazardous situations that you may encounter in the workplace, so be alert and exercise care when you are working near or with the router's electrical and electronic components.
•Always disconnect all power cords and line card interface cables before working on the equipment.
•Keep tools and router components away from walkway areas.
•Do not work alone if potentially hazardous conditions exist in the work area.
•Do not take any action that poses a potential hazard to yourself, other personnel, or the equipment.
•Carefully examine your work area for potential hazards, such as damp floors, ungrounded power extension cables, and missing safety grounds.
Safety with Electricity
Although the air filter assembly upgrade does not require electrical power, it is safe to observe the following basic safety guidelines when working near or with the router's electrical and electronic equipment:
•Before beginning any procedure requiring access to the card cages or other interior router components, locate the emergency power-off switch for the room in which you will be working.
•Do not work alone if potentially hazardous conditions exist in your work area.
•Never assume that power has been disconnected from a circuit; always verify that power has been removed.
•Do not perform any action that poses a potential hazard to yourself, other personnel, or the equipment.
•Carefully examine your work area for possible hazards, such as damp floors, ungrounded power extension cables, and missing safety grounds.
In addition, observe the following guidelines when you are working with equipment connected to telephone wiring or other network cabling.
Warning Do not work on the system or connect or disconnect cables during lightning storms.
•Never install telephone jacks in wet or damp locations unless the jack is specifically designed for use in such areas.
•Never touch uninsulated telephone wires or terminals unless telephone lines are disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
Preventing Electrostatic Discharge Damage
Electrostatic discharge damage to circuit boards can occur if they are handled improperly. Such mishandling can result in intermittent or complete failures of the board.
When handling circuit boards, observe the following guidelines to prevent ESD damage:
•Always use an ESD-preventive wrist strap and ensure that the strap makes adequate contact with your skin. Insert the equipment end of the wrist strap (the banana jack) into the ESD socket on the upper left edge of the card cage. See Figure 1
•The wrist strap protects equipment from ESD voltages on the body only; ESD voltages on clothing can still cause damage to electronic components.
Caution For safety, periodically check the resistance value of the antistatic wrist strap. The resistance measurement should be between 1 and 10 megohms.
Attaching the ESD-Preventive Strap
Attach the electrostatic discharge (ESD) antistatic strap to your body and the Cisco 12012 Gigabit Switch Router (GSR) chassis. See Figure 1.
Figure 1 Connecting an ESD-Preventive strap to the GSR Chassis
Safety Warnings
Safety warnings appear throughout this publication in procedures that, if performed incorrectly, may harm you. A warning symbol precedes each warning statement. The following paragraph is an example of a safety warning. It identifies the warning symbol and associates it with a bodily injury hazard. The remaining paragraphs in this section are translations of the initial safety warning.
|
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. (To see translations of the warnings that appear in this publication, refer to the appendix "Translated Safety Warnings" in the installation guide that accompanied this device.)
|
Waarschuwing
|
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van standaard maatregelen om ongelukken te voorkomen. (Voor vertalingen van de waarschuwingen die in deze publicatie verschijnen, kunt u het aanhangsel "Translated Safety Warnings" (Vertalingen van veiligheidsvoorschriften) in de installatiegids die bij dit toestel is ingesloten, raadplegen.
|
Varoitus
|
Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan. Ennen kuin työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista. (Tässä julkaisussa esiintyvien varoitusten käännökset löydät tämän laitteen mukana olevan asennusoppaan liitteestä "Translated Safety Warnings" (käännetyt turvallisuutta koskevat varoitukset).)
|
Attention
|
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant entraîner des blessures. Avant d'accéder à cet équipement, soyez conscient des dangers posés par les circuits électriques et familiarisez-vous avec les procédures courantes de prévention des accidents. Pour obtenir les traductions des mises en garde figurant dans cette publication, veuillez consulter l'annexe intitulée « Translated Safety Warnings » (Traduction des avis de sécurité) dans le guide d'installation qui accompagne cet appareil.
|
Warnung
|
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur Vermeidung von Unfällen bewußt. (Übersetzungen der in dieser Veröffentlichung enthaltenen Warnhinweise finden Sie im Anhang mit dem Titel "Translated Safety Warnings" (Übersetzung der Warnhinweise) in der diesem Gerät beiliegenden Installationsanleitung.)
|
Avvertenza
|
Questo simbolo di avvertenza indica un pericolo. Si è in una situazione che può causare infortuni. Prima di lavorare su qualsiasi apparecchiatura, occorre conoscere i pericoli relativi ai circuiti elettrici ed essere al corrente delle pratiche standard per la prevenzione di incidenti. La traduzione delle avvertenze riportate in questa pubblicazione si trova nell'appendice, "Translated Safety Warnings" (Traduzione delle avvertenze di sicurezza), del manuale d'installazione che accompagna questo dispositivo.
|
Advarsel
|
Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan føre til personskade. Før du utfører arbeid på utstyr, må du være oppmerksom på de faremomentene som elektriske kretser innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å unngå ulykker. (Hvis du vil se oversettelser av de advarslene som finnes i denne publikasjonen, kan du se i vedlegget "Translated Safety Warnings" [Oversatte sikkerhetsadvarsler] i installasjonsveiledningen som ble levert med denne enheten.)
|
Aviso
|
Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos fisicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir possíveis acidentes. (Para ver as traduções dos avisos que constam desta publicação, consulte o apêndice "Translated Safety Warnings" - "Traduções dos Avisos de Segurança", no guia de instalação que acompanha este dispositivo).
|
¡Advertencia!
|
Este símbolo de aviso significa peligro. Existe riesgo para su integridad física. Antes de manipular cualquier equipo, considerar los riesgos que entraña la corriente eléctrica y familiarizarse con los procedimientos estándar de prevención de accidentes. (Para ver traducciones de las advertencias que aparecen en esta publicación, consultar el apéndice titulado "Translated Safety Warnings," en la guía de instalación que se acompaña con este dispositivo.)
|
Varning!
|
Denna varningssymbol signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanligt förfarande för att förebygga skador. (Se förklaringar av de varningar som förekommer i denna publikation i appendix "Translated Safety Warnings" [Översatta säkerhetsvarningar] i den installationshandbok som medföljer denna anordning.)
|
Removing the Air Filter Assembly
This procedure guides you through removing the air filter assembly.
•Removing the Air Filter
•Removing the Air Filter Tray
Removing the Air Filter
This procedure guides you through the removal of the air filter from the air filter tray.
Warning To prevent damage, do not place any tools on the air filter tray or inside the card cage. Laying tools inside either the card cage or on the air filter tray could restrict the air flow and cause an overtemperature condition in the Cisco 12012.
Step 1 Attach an antistatic wrist strap to yourself and to one of the two ESD connection sockets located on the front edges of the card cage or to bare metal on the card cage frame. See Figure 1
Step 2 Use the 3/16-inch flat-blade screwdriver to loosen the two captive screws on the air filter tray.
Figure 2 Removing the Air Filter from the Air Filter Tray
Step 3 Pivot the tray down, away from the card cage.
Step 4 An indentation on each side of the air filter tray holds the air filter inside the tray. Grasp the air filter with your fingers and gently pull it out of the air filter tray. See Figure 2.
Warning There might be exposed line or fabric cards. Extreme caution is advised when working around an open card cage.
Step 5 Set the air filter aside.
Step 6 Close the air filter tray and use finger pressure only to tighten the two captive screws to the chassis.
Removing the Air Filter Tray
This procedure guides you through removing the air filter tray.
Step 1 Use the number 1 Phillips screwdriver to remove the five screws used to attach the bottom hinge of the air filter tray to the chassis. See Figure 3.
Step 2 Put the screws in a safe place away from the card cage.
Figure 3 Removing the Screws from the Air Filter Tray
Note Hold the air filter tray firmly with one hand because it will be completely disconnected from the chassis.
Step 3 Loosen the two captive screws at the top of the air filter tray until it is no longer attached to the card cage and chassis.
Step 4 Move the air filter tray away from the front of the card cage and chassis so that any dislodged dust will not be drawn into the card cage.
Step 5 Set the air filter tray out of the way.
Installing the Air Filter Assembly
This procedure guides you through installing the air filter assembly for the Cisco 12012 Gigabit Switch Router.
•Installing the Air Filter Tray
•Installing the Air Filter in the Air Filter Tray
•Attaching the Air Filter Tray
•Cisco Connection Online
Note Your antistatic wrist strap should still be attached. If not, reattach the antistatic strap for ESD protection. See Figure 1
Installing the Air Filter Tray
This procedure guides you through attaching the air filter tray to the chassis. The air filter tray is open on all sides and the bottom to increase the cooling capacity of the Cisco 12012 Gigabit Switch Router.
Step 1 While holding the air filter tray firmly with one hand, ensure that the five holes in the hinge, located at the bottom of the air filter tray, align with the holes in the chassis; then use finger pressure only to tighten the two captive screws at the top of the air filter tray. See Figure 4.
Figure 4 Air Filter Hinge Holes and Chassis Holes Alignment
Step 2 Use the number 1 Phillips screwdriver and all five of the screws you saved earlier to fasten the bottom hinge of the air filter tray to the chassis.
Step 3 After tightening all five screws, give each screw an additional one quarter turn to ensure a tight seal between the air filter tray and the chassis.
Installing the Air Filter in the Air Filter Tray
This procedure guides you through installing the air filter into the air filter tray.
Step 1 Loosen the two captive screws at the top of the air filter tray. See Figure 4.
Step 2 Allow the bottom hinge to hold the air filter tray in the full open position.
Step 3 With the air filter tray in the full open position, gently slide the air filter into the air filter tray until it is firmly seated against the bottom of the air filter tray. See Figure 5.
Figure 5 Installing the Air Filter in the Air Filter Tray
Caution The air filter must be seated against the bottom of the air filter tray, with the filter fabric facing downward, toward the floor, and the open side of the filter facing upward. See
Figure 5.
Attaching the Air Filter Tray
This procedure guides you through attaching the air filter tray to the chassis.
Step 1 Raise the air filter tray until it touches the chassis.
Step 2 With one hand apply pressure to the top of the air filter tray. While holding the pressure, use the 3/16-inch flat-blade screwdriver to tighten the captive screws to ensure a good seal of the air filter tray against the chassis.
Step 3 After tightening both captive screws with the 3/16-inch flat-blade screwdriver, give each screws an additional one quarter turn to ensure a tight seal between the air filter tray and the chassis.
