Release Notes for Cisco SIP IP Phone 7940/7960 Release 7.1
June 22, 2004
Contents
This document lists the known problems in Cisco Session Initiation Protocol (SIP) IP Phone 7940/7960 Release 7.1 and contains information about the Cisco SIP IP Phone 7940/7960 (hereafter referred to as the Cisco SIP IP phone) that is not included in the most recent release of the phone documentation.
This document includes the following sections:
•Obtaining Technical Assistance
New and Changed Information
New Software Features in Release 7.1
No new software features are supported in Cisco IP Phone 7940/7960 Release 7.1.
Installation Notes
For Cisco SIP IP phones, follow the instructions in the "Upgrading the Cisco SIP IP Phone Firmware" section at the following URL:
For these instructions, use P0S3-07-1-00.sbn as the image name for Release 7.1. You can find the current images at the following URL:
http://www.cisco.com/cgi-bin/tablebuild.pl/sip-ip-phone7960
Caveats
Open Caveats—Release 7.1
This section documents possible unexpected behavior by Cisco IP Phone 7940/7960 Release 7.1. This section lists only severity 1 and 2 caveats and select severity 3 caveats.
•CSCea49094: SIP: 79x0 phones are NOT escaping RESERVED characters in URI/URLs
•CSCec14587: SIP: Need to CACHE & cycle thru multiple DNS entries for FQDN Type A
•CSCec44511: SIP Phone are not sending ICMP port unreachable
•CSCec87021: SIP: Inconsistent Behavior of AutoComplete Feature on 79x0 phones
•CSCed73817: Anonymous Call Rejection returns wrong Response code
•CSCee17946: SIP: 79x0 ignores dst_start_time parameter when configured
•CSCee49363: SIP: Tx INVITEs to wrong port number after Rx 302 Moved Temporarily
•CSCee53134: SIP: CallerID Blocking needs to change more values to ANONYMOUS
Resolved Caveats—Release 7.1
All caveats listed in this section are resolved in Cisco IP Phone 7940/7960 Release 7.1. This section lists only severity 1 and 2 caveats and select severity 3 caveats.
•CSCec60588: 7960 SIP phone reboots if subjected to Protos SIP Cert Test
•CSCec77988: 7960s MD5-sess recalculates A1 on every request
•CSCed21171: SIP IP Phone resets rtp session when it receives sip re-invite
•CSCed37675: SIP phone reboots with false duplicate IP address message
•CSCed40049: SIPPhone: CANCEL message not formatted properly after 180 received
•CSCed40056: SIPPhone: DND config causes weird NTP behavior
•CSCed44124: HTTP requests fail, sysbufs get hung
•CSCed48311: Media takes 0.4 sec to be set up
•CSCed51891: SIPPhone: ACK to 407 sent to proxy1_address when outbound proxy cfgd
•CSCed53241: SIP: DSP handling of RTP streams has changed when call is MUTEd
•CSCed53258: SIP: DSP stops sending DTMF AVT packets when in CONFERENCE
•CSCed59936: Microphone sensitivity for 7940/7960
•CSCed59956: Some tone might not play properly
•CSCed68662: port 65535 reject calls
•CSCed69788: SIPPhone: INVITE w/o media line in SDP causes phone hang/reboot
•CSCed81406: SIPPhone: G729 calls send RFC2833 packets and voice packets at 10ms
•CSCed88935: SIP: Issues with IP UDP Fragmentation of Larger SIP Messages
•CSCed91569: SIP: Proxy-Authorization header missing in ACK request
•CSCee03194: 79x0: Phone uses cached A record instead A record from SRV lookup
•CSCee03195: SIPPhone: Phone Accepts packets from multicast/broadcast source
•CSCee06742: AdminVLAN Id will be lost after the second reboot.
•CSCee16710: 79x0: When VAD is enabled and mute is engaged, no comfort noise RTP
•CSCee20672: Phone does not drop to LA config hunt when Alternate TFTP is changed
•CSCee25060: Phone might not be able to preempt a tone with another one
•CSCee31047: Universal App Loader does not config file hunt on all TFTP errors
•CSCee42371: SIP: Issues with providing remote party ID headers in Re-INVITE
•CSCee49590: 79x0: Config File size limited to 5724 bytes instead of 8192 bytes
•CSCee57017: Called Cisco 7960 uses incorrect Nonce-Count value on re-INVITE
Related Documentation
•Cisco SIP IP Phone Administrator Guide, Release 7.1
•Cisco IP Phone 7960/7940 Series - Quick Reference
•Regulatory Compliance and Safety Information for the Cisco IP Phone 7960, 7940, and 7910 Series
•Installing the Wall Mount Kit for the Cisco IP Phone
