The Cisco® Unified Communications system of voice and IP Communications products and applications helps organizations communicate more effectively-by helping them streamline business processes, reach the right resource the first time, and increase profitability. The Cisco Unified Communications portfolio is an important part of the Cisco Business Communications Solution-an integrated solution for organizations of all sizes that also includes network infrastructure, security, and network management products; wireless connectivity; and a lifecycle services approach-along with flexible deployment and outsourced management options, end-user and partner financing packages, and third-party communications applications.
The Cisco MCS 7845-H1 Unified CallManager Appliance is a high-availability server platform for Cisco Unified CallManager 5.0 and an integral part of a complete, scalable architecture for a new generation of high-quality IP Communications solutions for enterprise data networks. It delivers the high performance and availability that today's enterprise networks demand-and it is easy to deploy and highly cost-effective. The server appliance is preinstalled with an operating system and Cisco Unified CallManager 5.0. It is fully operational upon startup, requiring entry of just a few configuration items such as IP address and domain. At just 2 rack units (2RU) high, the Cisco MCS 7845-H1 offers tremendous power in a low-profile chassis that minimizes rack space. The appliance supports up to 7500 IP phones per appliance and 30,000 IP phones per cluster, and includes the following features and components:
• Two Intel Xeon 3.4-GHz or higher processors, an 800-MHz front side bus (FSB), and 2 MB of Layer 2 cache
• PC2-3200R 4-GB 400-MHz Double Data Rate 2 (DDR2) memory with online spare capabilities
• Integrated Ultra320 Smart Array 6i Redundant Array of Independent Disks (RAID) Controller with 64-MB read cache plus 128-MB battery-backed write cache
• Support for Integrated Lights Out (iLO) server management
• Support for up to six 1-inch Ultra320 Small Computer System Interface (SCSI) hot-plug hard drives
• Hot-plug redundant power supplies
• Hot-plug redundant fans
KEY FEATURES AND BENEFITS
The Cisco MCS 7845-H1 is a robust, highly available server platform designed to support today's IP Communications applications. It uses an Integrated Smart Array 6i Controller with a 64-MB cache to provide onboard RAID support without using one of the peripheral-component-interconnect (PCI)-X slots on the server. The appliance occupies only 2RU of space while providing the features most requested in a high-availability server platform. At product introduction, the Cisco MCS 7845-H1 includes two Intel Xeon 3.4-GHz processors, and the processor speed will be increased as Intel retires the 3.4-GHz processor and introduces new processors.
High availability on the Cisco MCS 7845-H1 is achieved through the following mechanisms:
• Redundant hot-swap 575W power supplies
• Redundant hot-swap fans
• Hot-swap SCSI hard drives configured using RAID 1
System Health LEDs
The Cisco MCS 7845-H1 provides system health LEDs and unit identification lights on the front and back of the server to ease identification of system problems. When an internal component fails, this indication is made on an internal component LED (amber) and on the front panel of the appliance. If the item can be serviced without removing the server hood, as in the case of a redundant power supply, the external health LED illuminates. If the item can be serviced by removing the hood, as in the case of a fan failure, the internal health LED illuminates. If no failures have occurred, the system health LEDs are green. If a failure has occurred but a redundant feature has enabled the system to continue running, the LED is amber. If the failure is critical and has caused the system to shut down, the LED is red.
Integrated Lights Out
The iLO standard is included on the motherboard. Combining essential management functions and diagnostics with basic lights-out functions as standard components of the server, iLO is available at no charge. It offers maximum security, availability, and control over business-critical servers without the need to visit the systems physically.
The iLO standard also provides fundamental server control and monitoring by integrating essential lights-out technology directly into the Cisco MCS 7845-H1 architecture.
Essential lights-out features include remote power control, text-based console, logs, status, and alert forwarding.
The easy-to-use, dedicated lights-out LAN port is accessible through a browser interface.
The iLO standard provides the following additional features:
• It saves a valuable PCI slot for additional functions and reduces installation and setup time.
• It eliminates the need for an external power adapter or any other internal or external cables.
• It provides a rich suite of security features, including Secure Sockets Layer (SSL).
• It provides a scalable solution by allowing group administration of iLO processors.
In the Cisco MCS 7845-H1, the ROM is divided into two logical sections. When the system boots, the primary ROM section is executed and used in server operation. During a ROM flash, the backup section is flashed. When the flash is fully completed, the backup section becomes the primary. If the flash does not complete safely, potentially because of power interruption, the backup is available to boot the system. In the situation in which both images are valid, the user can select which image to use at boot time.
Tape Drive Support
The Cisco MCS 7845-H1 can support an optional 36-/72-GB universal-serial-bus (USB) external Digital Audio Tape (DAT) drive (part number DAT-USB-EXT-72=) or an optional USB rack-mount DAT drive (part number DAT-USB-RM-72=). This tape drive connects through one of the 4 USB 2.0 ports provided by the Cisco MCS 7845-H1 server.
Table 1 lists product specifications for the Cisco MCS 7845-H1 Unified CallManager Appliance.
You may order the appliance in one of two ways. You can enter CALLMANAGER-5.0 into the Dynamic Configuration tool on Cisco.com and view a list of Cisco MCS Unified CallManager Appliances and their associated licenses. You can also order the components individually using the following product part numbers:
• KEY-CCM-ADMIN-K9= (order a minimum quantity of 2)
• DAT-USB-EXT-72= (optional external USB DAT tape drive)
• DAT-USB-RM-72= (optional rack-mount USB DAT tape drive)
• DAT-USB-ADPT= (required if DAT-USB-EXT-72= or DAT-USB-RM-72= are used)
• LIC-CCM5.X-2500= (optional-order if you want another 2500 users per appliance)
To order spare appliances, refer to Table 2.
Table 2. Ordering Information for Spare Appliances
Spare Part Number
Cisco Unified CallManager 5.0
To order spare parts for the appliance, refer to Table 3.
Table 3. Ordering Information for Appliance Spare Parts
Spare Part Number
Spare 72-GB Ultra320 hot-plug SCSI drive for Cisco MCS 7845-H1
Spare 575W power supply for Cisco MCS 7845-H1
Spare fan for Cisco MCS 7845-H1
Spare external USB 36-/72-GB DAT drive
Spare rack-mount USB 36-/73-GB DAT drive
PCI-to-USB DAT adapter
(required for DAT-USB-EXT-72= or DAT-USB-RM-72=)
IDENTIFYING CPU SPEED OF APPLIANCE
As the Cisco MCS 7845-H1 Unified CallManager Appliance matures, the processor speeds will be changed as Intel replaces slower processors. Table 4 provides the Cisco manufacturing part number shown on the chassis to help identify the processor speed of any individual appliance.
Table 4. Manufacturing Part Numbers by Processor Speed
Manufacturing Part Number Located on Server
Intel Xeon 3.4 GHz
Initial production of appliance
Intel Xeon 3.4 GHz
Revised server with CPU containing 2-MB Layer 2 cache
