THIS PRODUCT IS NO LONGER BEING SOLD AND MIGHT NOT BE SUPPORTED. READ THE END-OF-LIFE NOTICE TO LEARN ABOUT POTENTIAL REPLACEMENT PRODUCTS AND INFORMATION ABOUT PRODUCT SUPPORT.
The Cisco® MCS 7835-H1 Media Convergence Server is a high-availability server platform for Cisco Unified Communications solutions. An integral part of a complete, scalable architecture for a new generation of high-quality IP voice solutions that run on enterprise data networks, the Cisco MCS 7835-H1 delivers the high performance and availability demanded by today's enterprise networks-and it is easy to deploy and highly cost-effective. At only 2 rack units (2RU) high, the Cisco MCS 7835-H1 offers tremendous power in a low-profile chassis that minimizes rack space. It runs a variety of Cisco IP Communications applications, such as Cisco CallManager; its features include:
• Intel Xeon 3.4-GHz (or higher) processors, an 800-MHz front side bus (FSB), and 2 MB of Layer 2 cache
• 2-GB PC2-3200R 400-MHz Double Data Rate 2 (DDR2) memory with online spare capabilities
• Integrated Ultra320 Smart Array 6i Redundant Array of Independent Disks (RAID) Controller with 64-MB read cache plus 128-MB battery-backed write cache
• Cisco Unified IP Interactive Voice Response (IP IVR)
• Cisco Unified MeetingPlace® conferencing solution-Supports Cisco MeetingPlace systems with up to 480 concurrent voice conferencing licenses running the following software: Cisco MeetingPlace for Outlook, Cisco MeetingPlace for Notes, Cisco MeetingPlace Instant Messaging (dedicated server), Cisco MeetingPlace Web Conferencing (up to 50 concurrent Web conferencing licenses per server; Cisco MCS 7845-H1 and MCS 7845-I1 for > 50 concurrent Web conferencing licenses), Cisco MeetingPlace Directory Integration Application (dedicated server for > 200 concurrent voice conferencing licenses), Cisco MeetingPlace Video Integration, Cisco MeetingPlace H.323/Session Initiation Protocol (SIP) Gateway Software, and Cisco MeetingPlace Simple Mail Transfer Protocol (SMTP) E-mail Gateway Software
• Cisco Unified MeetingPlace Express
• Cisco Personal Assistant-Up to 2500 users per server
• Cisco Unified IP Queue Manager
• Cisco Unity® Unified Messaging-Up to 48 ports and up to 2000 mailboxes
KEY FEATURES AND BENEFITS
The Cisco MCS 7835-H1is a robust, highly available server platform designed to support today's unified communications applications. It uses an Integrated Smart Array 6i Controller with a 64-MB cache to provide onboard RAID support without using one of the peripheral component-interface (PCI)-X slots on the server. The Cisco MCS 7835-H1 occupies only 2RU of space while providing the features most requested in a high-availability server platform. At product introduction the Cisco MCS 7835-H1 will ship with an Intel Xeon 3.4-GHz processor and over time the processor speed will be increased as Intel retires the 3.4-GHz processor and introduces new processors.
• High availability on the Cisco MCS 7835-H1 is achieved through the following mechanisms:
• Redundant hot-swap 575W power supplies
• Hot-swap SCSI hard drives configured using RAID 1
System Health LEDs
The Cisco MCS 7835-H1 provides system health LEDs and unit identification lights on the front and back of the server to make pinpointing system problems easier than ever. When an internal component fails, this indication is made on an internal component LED (amber) and on the front panel of the Cisco MCS 7835-H1. If the item is serviceable without removing the server hood, as in the case of a redundant power supply, the external health LED illuminates. If the item is serviceable by removing the hood, as in the case of a fan failure, the internal health LED illuminates. If no failures have occurred, the system health LEDs are green. If a failure has occurred but a redundant feature has enabled the system to continue running, the LED is amber. If the failure is critical and has caused the system to shut down, the LED is red.
Integrated Lights Out
The Integrated Lights Out (iLO) Standard is included on the motherboard. Combining essential management functions and diagnostics with basic lights-out functions as standard components of the server, iLO is available at no charge. iLO Standard offers maximum security, availability, and control over business-critical servers without the need to visit the systems physically.
• iLO Standard provides fundamental server control and monitoring by integrating essential lights-out technology directly into the Cisco MCS 7835-H1 server architecture.
• Essential lights-out features include remote power control, text-based console, logs, status, and alert forwarding.
• The easy-to-use, dedicated lights-out LAN port is accessible through a browser interface.
• iLO Standard saves a valuable PCI slot for additional functions and reduces installation and setup time.
• iLO Standard eliminates the need for an external power adapter or any other internal or external cables.
• iLO Standard provides a rich suite of security features, including Secure Sockets Layer (SSL).
• iLO Standard provides a scalable solution by allowing group administration of iLO processors.
In the Cisco MCS 7835-H1, the ROM is divided into two logical sections. When the system boots, the primary ROM section is executed and used in server operation. During a ROM flash, the backup section is flashed. When the flash is fully completed, the backup section becomes the primary. If under rare conditions the flash does not complete safely, potentially because of power interruption, the backup is available to boot the system. In the situation where both ROM images are valid, the user can select which image to use at boot time.
DAT Tape Support
The Cisco MCS 7835-H1 can support an optional 36-/72-GB universal-serial-bus (USB) external Digital Audio Tape (DAT) drive (part number DAT-USB-EXT-72=) or an optional USB rack-mount DAT drive (part number DAT-USB-RM-72=). This tape drive connects through one of the 4 USB 2.0 ports provided by the Cisco MCS 7835-H1 server.
To order spare parts for the servers refer to Table 4.
Table 4. Ordering Information for Server Spare Parts
Spare Part Number
Spare 1024-MB SDRAM DIMM for Cisco MCS 7835-H1
Spare 72-GB U320 hot-plug SCSI drive for Cisco MCS 7835-H1
Spare 575W power supply for Cisco MCS 7835-H1
Spare fan for Cisco MCS 7835-H1
IDENTIFYING CPU SPEED OF SERVER
As the Cisco MCS 7835-H1 matures and Intel replaces slower processors, the processor speeds will change. Table 5 provides the Cisco manufacturing part number that will be shown on the chassis to help identify any processor speed of any individual server.
Table 5. Manufacturing Part Numbers by Processor Speed
Manufacturing Part Number Located on Server
Intel Xeon 3.4-GHz 1MB Layer 2 cache
Initial production of server
Intel Xeon 3.4-GHz 2MB Layer 2 cache
Revised with new processor containing 2-MB of Layer 2 cache
