The Cisco® Unified IP Phone 8961 is an advanced professional media endpoint that delivers an enhanced user experience with an easy-to-use and eco-friendly ergonomic design. Highlights of the portfolio include introduction of higher-resolution (VGA) color displays, a USB port, Gigabit Ethernet connectivity, and High-definition (HD) voice support, enabling a more productive user experience for multimedia application engagement. Application support includes XML and MIDlet-enabled applications. The Cisco Unified IP Phone 8961 is an ideal solution for knowledge professionals, administrative managers, and executives.
Features and Benefits
Table 1 lists the features and benefits of the Cisco Unified IP Phone 8961.
Table 1. Features and Benefits
Feature
Benefits
Hardware
Ergonomic Design
Highly usable and intuitive arrangement of lines, features and calls. Transfer, Conference and Hold appear on hard keys to reduce the number of presented softkeys to a maximum of 4 per call state.
Customization
This model can be ordered as Arctic White or Charcoal Gray. Handsets are available internationally as slimline (5oz, 140g) or standard (6oz, 170g) and can be mixed and matched between users within the same work environment to enable a feeling of customization and ownership among the users.
Display
VGA presentation for calling and applications. 5-inch (10 cm) graphical TFT color display, 24-bit color depth, 640 x 480 effective pixel resolution, with backlight. Display also supports localization requiring double-byte Unicode encoding for fonts.
Ethernet
Internal 2-port Cisco Ethernet switch allows for a direct connection to a 10/100/1000 BASE-T Ethernet network through an RJ-45 interface with single LAN connectivity for both the phone and a colocated PC. System administrator can designate separate VLANs (802.1Q) for the PC and phone, providing improved security and reliability of voice and data traffic.
USB
2 USB ports accelerate the usability of call handling and applications by enabling wired and wireless headsets.
5 lines expanding to 41 with 1 Key Expansion Module
The convenience of many speed dials or programmable features, or the necessity of following the activity of many lines. Up to 200 calls supported per device.
Buttons
5 feature buttons with state indicating LEDs.
5 call session buttons with state indicating LEDs.
Applications, Directories, Voicemail.
Conference, Transfer, Hold.
Volume Up/Down.
Back-lit Mute, Speakerphone, Headset.
Back, End Call, 5-Way Navigation Pad.
Arabic keypad (only available through unique SKUs. See table 4 for more details).
Accessories
Key Expansion Module
Available separately, enables advanced use of lines, speed dials and features.
Headset Support
Analog RJ-9 and USB wired and wireless headsets are supported.
Firmware
New user experience
Advanced organization of lines, speed dials and programmable features separate from call appearances. Great for those who make few calls per day, better for those who handle dozens of calls per hour.
SIP Signaling
SIP interoperation with the call control and partner applications enables a rich unified communications solution.
Application Support
XML and Java Midlet applications provided by Cisco's application development partners or customers' own development staff.
Unified Communications Manager Support
• Cisco Unified Communications Manager version 7.1(3a)SU1 or later.
• Survivable Remote Site Telephony (SRST) version 4.3 or later.
Licensing
Phone licensing is dependent on the call control platform and its policies. For the Cisco Unified Communications Manager, the 89611 requires 4 Device License Units (DLUs) or an Enhanced IP User Connect License for UCM release 7.1(5) or later. There are no special licence plus phone bundles for Tier II distributors. The 9951 is not support on non-Cisco third party call control systems.
Product Specifications
Table 2. Product Specifications
Protocols
SIP for signaling
H.264 for video
Connectivity
10/100/1000 wired Ethernet network port plus switched PC port
Options
Arctic White or Charcoal Gray color
Slimline (5oz, 140g) or Standard (6oz, 170g) handset
Language support
Arabic, Bulgarian, Catalan, Chinese (People's Republic of China), Chinese (Hong Kong), Chinese (Taiwan), Croatian, Czech, Danish, Dutch, English - plus localized prompts for the UK, Estonian, French, Finnish, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Latvian, Lithuanian, Norwegian, Polish, Portuguese (Portugal), Portuguese (Brazil), Romanian, Russian, Spanish (Spain), Slovak, Swedish, Serbian (Republic of Serbia), Serbian (Republic of Montenegro), Slovenian, Thai, Turkish
Physical dimensions (HxWxD)
9.2" (23.4 cm) x 10.33"(26.25 cm) x 1.56"(3.97 cm)
In slab mode with the footstand removed
Power
IEEE Power over Ethernet 802.3af and 802.3at supported, class 4. The 8961 is compatible with both class 3 and class 4 IEEE PoE switch blades and supports both Cisco Discovery Protocol (CDP) and Link Layer Discovery Protocol - Power over Ethernet (LLDP-PoE)
Temperature range
Enter specification description; include metric equivalents in parentheses
Operational Temperature
Temperature: 23°F (-5°C) ~ 131°F (55°C)
Non-Operational Temperature Shock
Temperature: -13°F (-25°C) ~ 158°F (70°C)
Temperature-Altitude (Operational)
Temperature: 140°F (40°C) Ambient condition to 9843 ft (3,000 m)
Temperature-Altitude (Non-Operational)
Ambient condition to 15,000 ft (4,572 m)
Temperature-Humidity (Non-Operational)
Humidity: 90% ± 5% Relative Humidity
Non-Operational Hot Temperature (Storage)
Temperature: 158° F (70°C) ± 2°C
Non-Operational Cold Temperature (Storage)
Temperature: -40°F (-40°C) ± 2°C
Quantity Shipped per Pallate
320 units
SKU
Description
Weight: Hardware
lb (kg)
Weight:
Single Carton
lb (kg)
Weight: Master Pack of 8 Cartons
lb (kg)
CP-8961-C-K9=
Cisco Unified IP Endpoint 8961, Charcoal, Standard Handset
3.43(1.558)
4.34(1.970)
36.46(16.540)
CP-8961-CL-K9=
Cisco Unified IP Endpoint 8961, Charcoal, Slimline Handset
3.37(1.527)
4.30(1.951)
36.13(16.389)
CP-8961-W-K9=
Cisco Unified IP Endpoint 8961, Arctic White, Standard Handset
3.57(1.620)
4.57(2.074)
38.29(17.370)
CP-8961-WL-K9=
Cisco Unified IP Endpoint 8961, Arctic White, Slimline Handset
• Dynamic Host Configuration Protocol (DHCP) client or static configuration
• Support for online firmware upgrades using Trivial File Transfer Protocol (TFTP)
• Domain Name System (DNS)
• HTTP Firmware Management
Network Features
• Cisco Discovery Protocol (CDP)
• Link Layer Discovery Protocol Power over Ethernet (LLDP-PoE)
• Transparent secure roaming
• Provisioning of network parameters through DHCP
• Switch Auto-Negotiation
• VPN Client
Security Features
• Certificates
• Image authentication
• Device authentication
• File authentication
• Signaling authentication
• Media encryption using Secure Real-Time Protocol (SRTP)
• Signaling encryption using Transport Layer Security (TLS) Protocol
• Certificate authority proxy function (CAPF)
• Secure profiles
• Encrypted configuration files
Provisioning and Manufacturing
• Cisco Unified Communications Manager Express Version Negotiation
• Web server for configuration and statistics
• QoS reporting: jitter, delay, dropped packets, and latency on a per-call basis
• Real Time Control Protocol (RTCP) support and monitoring
• Syslog
Ordering Information
Help customers understand all the components or parts they need to purchase in order to install and use the product. This section also provides a direct link to the Cisco Ordering Tool and lists part numbers for customer convenience.
To place an order, visit the Cisco Ordering Home Page. To download software, visit the Cisco Software Center.
Table 4. Ordering Information
Product Name
Part Number
Cisco Unified IP Phone 8961, Charcoal, Standard Handset, Spare
CP-8961-C-K9=
Cisco Unified IP Phone 8961, Charcoal, Slimline Handset, Spare
CP-8961-CL-K9=
Cisco Unified IP Phone 8961, White, Standard Handset, Spare
CP-8961-W-K9=
Cisco Unified IP Phone 8961, White, Slimline Handset, Spare
Cisco Unified IP Color Key Expansion Module, Charcoal
CP-CKEM-C=
Cisco Unified IP Color Key Expansion Module, White
CP-CKEM-W=
Locking Wallmount Kit for 8900 or 9900 Series, Charcoal
CP-89/9900-LWMK-C=
Locking Wallmount Kit for 8900 or 9900 Series, Arctic White
CP-89/9900-LWMK-W=
Locking Wallmount Kit for 8900 or 9900 Series and KEM, Charcoal
CP-89/9900-LK-K-C=
Locking Wallmount Kit for 8900 or 9900 Series and KEM, Arctic White
CP-89/9900-LK-K-W=
Table 7. Local Power Options: Cube and Regional Cords
The power cube is new for the 8900 and 9900 Series IP Phones, but the cords are the same cords as used with the 7900 series. Power Cube 4 supports up to 44W and is internationally rated for different power grids worldwide.
Product Name
Part Number
Cisco Unified IP Endpoint Power Cube 4: 48V; 0.917A; 47-63Hz; 100-240V~0.8A
CP-PWR-CUBE-4=
Asia Pacific
CP-PWR-CORD-AP=
Argentina
CP-PWR-CORD-AR=
Australia
CP-PWR-CORD-AU=
European Community
CP-PWR-CORD-CE=
China
CP-PWR-CORD-CN=
Japan
CP-PWR-CORD-JP=
North America
CP-PWR-CORD-NA=
Switzerland
CP-PWR-CORD-SW=
United Kingdom
CP-PWR-CORD-UK=
