Diagnostic Tests

Revised: July 22, 2009, OL-15636-07

Introduction

This chapter describes diagnostic tests that can be performed on media gateways, subscriber terminations, and trunk terminations. All media gateways and subscriber and trunk terminations must be in the maintenance state for testing. The following tests are described in this chapter:

•Media Gateway Tests

•Subscriber Termination Tests

•Signaling System 7 Trunk Termination Tests

•Integrated Services Digital Network Trunk Termination Tests

•Channel-Associated Signaling Trunk Termination Tests

•Announcement Trunk Termination Tests

•Troubleshooting Using Snoop

•Query Verification Tool and Translation Verification Tool

•Network Loopback Test for Network-Based Call Signaling/Media Gateway Control Protocol Endpoints

•Session Initiation Protocol Subscriber Registration Status Check

•System Health Report

•Fast Audit and Sync Tool

•ISDN Network Loopback Test

•Enhanced Traffic Measurement

•Cisco BTS 10200 Status

•Call Tracer (CTRAC)

•Tabular Display of Events and Alarms

•Prior to Manual Switchover Switch Integrity Diagnostic Utility

•PSTN Trunk Testing

Caution The use of the UNIX ifconfig down command on any signaling interface to test or troubleshoot network or interface failures of the Cisco BTS 10200 Softswitch Signaling Interface might lead to undesirable consequences or conditions.

Media Gateway Tests

This section describes the tests that can be performed on media gateways. A gateway must be in the maintenance state.

Step 1 Force the media gateway into maintenance state:
control mgw id=c2421.65; mode=forced; target-state=maint;
Reply Example:
Reply: Success: CLI change successful
MGW ID -> c2421.65
INITIAL STATE -> ADMIN_INS
REQUEST STATE -> ADMIN_MAINT
RESULT STATE -> ADMIN_MAINT
FAIL REASON -> ADM found no failure
REASON -> ADM executed successful
RESULT -> ADM configure result in success
Step 2 Display the Test Menu.
diag mgw
Reply Example:
Reply: Diagnostic MGW Menu.
===
(1) MGW Network Connectivity Test
(2) MGW MGCP Connectivity Test
(3) ALL
Note Test 1 tests if there is a path to the device (ping).

Test 2 tests if Media Gateway Control Protocol (MGCP) has access to the device.

Test 3 performs tests 1 and 2.

Step 3 To perform a specific test, use the following examples as a guide.
diag mgw id=ubr-03; test=1;
Reply Example:
MEDIA GATEWAY LINE DIAGNOSTIC TEST EXECUTED -> diag mgw
ID -> ubr-03
TEST-TYPE -> ADM-MGW-NETW-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED
Reply: Diagnostic command executed.
diag mgw id=ubr-03; test=2;
Reply Example:
MEDIA GATEWAY LINE DIAGNOSTIC TEST EXECUTED -> diag mgw
ID -> ubr-03
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED
Reply: Diagnostic command executed.
diag mgw id=ubr-03; test=3;
Reply Example:
MEDIA GATEWAY LINE DIAGNOSTIC TEST EXECUTED -> diag mgw
ID -> ubr-03
TEST-TYPE -> ADM-MGW-NETW-CONNECTIVITY-TEST
TEST-DURATION -> 11
RESULT -> TEST-SUCCESS
REASON -> PASSED
MEDIA GATEWAY LINE DIAGNOSTIC TEST EXECUTED -> diag mgw
ID -> ubr-03
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED
Reply: Diagnostic command executed.
Step 4 Force the media gateway into INS state:
control mgw id=c2421.65; mode=forced; target-state=ins;
Reply Example:
Reply: Success: CLI change successful
MGW ID -> c2421.65
INITIAL STATE -> ADMIN_MAINT
REQUEST STATE -> ADMIN_INS
RESULT STATE -> ADMIN_INS
FAIL REASON -> ADM found no failure
REASON -> ADM executed successful
RESULT -> ADM configure result in success
Subscriber Termination Tests

This section describes the tests that can be performed on subscriber terminations. All terminations must be in the maintenance state.

Step 1 Force the subscriber termination into maintenance state:
control subscriber-termination id=sub2-ctx2; mode=forced; target-state=maint;
Step 2 Display the Test Menu.
diag subscriber-termination;
Reply Example:
Reply: Diagnostic Subscriber Menu.
===
(1) Subscriber MGCP Connectivity Test
(2) Subscriber Termination Connection Test
(3) Subscriber Termination Ring Test
(4) ALL
Note Test 1 tests if MGCP has access to the termination.

Test 2 tests if there is a path to the device (ping).

Test 3 tests if the subscriber can be rung. The Ring parameter must be specified in seconds for this test. The default is 5 seconds.

Test 4 performs tests 1 through 3.

Step 3 To perform a specific test, use the following examples as a guide.
diag subscriber-termination id=sub2-ctx2; test=1;
Reply Example:
SUBSCRIBER LINE DIAGNOSTIC TEST EXECUTED -> diag subscriber-termination
ID -> sub2-ctx2
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 10
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
diag subscriber-termination id=sub-ubr3-1@cisco.com; test=2;
Reply Example:
SUBSCRIBER LINE DIAGNOSTIC TEST EXECUTED -> diag subscriber-termination
ID -> sub-ubr3-1@Cisco.com
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 55
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
diag subscriber-termination id=sub-ubr3-1@cisco.com; test=3; ring-duration=10;
Reply Example:
SUBSCRIBER LINE DIAGNOSTIC TEST EXECUTED -> diag subscriber-termination
ID -> sub-ubr3-1@Cisco.com
TEST-TYPE -> ADM-TERM-RING-TEST
TEST-DURATION -> 9989
RESULT -> TEST-SUCCESS
REASON -> PASSED
Reply: Diagnostic command executed.
Step 4 Force the subscriber termination into INS state:
control subscriber-termination id=sub2-ctx2; mode=forced; target-state=ins;
Note Ring-duration values are 0-999 (Default = 5). Maximum ring time is 30 seconds regardless of whether the duration is set higher than or equal to 31.

Signaling System 7 Trunk Termination Tests

This section describes the tests that can be performed on Signaling System 7 (SS7) trunk terminations. All terminations must be in the maintenance state for testing.

Step 1 Force the SS7 trunk termination into maintenance state:
control ss7-trunk-termination tgn-id=103; mode=forced; target-state=maint;
Note Set customer-originated trace (COT), circuit verification message (CVM), and circuit query message (CQM) on the terminating gateway or switch to perform these tests. Otherwise, the test or tests will fail.

Step 2 Display the Test Menu.
diag ss7-trunk-termination
Reply Example:
Reply: Diagnostic SS7 Trunk Group Menu.
===
Test 1: SS7 MGCP Connectivity Test
Test 2: SS7 Termination Connection Test
Test 3: SS7 COT Test
Test 4: SS7 CQM Test
Test 5: SS7 CVT Test
Test 6: SS7 CIC Audit
Test 0: ALL Tests
Note Test 1 tests if MGCP has access to the SS7 trunk termination.

Test 2 tests if there is a path to the device (ping).

Test 3 tests the integrity of the SS7 Bearer Path.

Test 4 queries the SS7 circuit (or group of circuits) status. A range of CICs can be specified (to a maximum of 24). Both remote and local trunk states are displayed in the results.

Test 5 tests to ensure that each end of the circuit has sufficient and consistent information for using the circuit in call connections. Common language location identifier (CLLI) names are included.

Test 6 tests to ensure the CIC connections.

Test 0 performs tests 1 through 6.

Step 3 To perform a specific test, use the following examples as a guide:
diag ss7-trunk-termination tgn-id=103; cic=13; test=1;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 103
CIC -> 13
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
diag ss7-trunk-termination tgn-id=103; cic=13; test=2;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 103
CIC -> 13
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 33
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
diag ss7-trunk-termination tgn-id=103; cic=14; test=3;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 103
CIC -> 14
TEST-TYPE -> ADM-SS7-COT-TEST
TEST-DURATION -> 0
RESULT -> TEST-FAILURE
REASON -> ADM-MAINT-STATE-REQUIRED
Reply: Diagnostic command executed.
diag ss7-trunk-termination tgn-id=2; cic=1-24; test=4
Reply Example:
Reply: Success:
TGN ID -> 2
START CIC -> 1
END CIC -> 24
TEST TYPE -> ADM running SS7 circuit query message test
TEST DURATION -> 0
RESULT -> ADM ran test successfully
REASON -> CQM test pass
CIC COUNT -> 24
CIC STATES ->
Remote State
Local State
CIC 1 -> CS_IDLE
ACTV
IDLE
CIC 2 -> CS_IDLE
ACTV
IDLE
CIC 3 -> CS_IDLE
ACTV
IDLE
CIC 4 -> CS_IDLE
ACTV
IDLE
CIC 5 -> CS_IDLE
ACTV
IDLE
CIC 6 -> CS_IDLE
ACTV
IDLE
CIC 7 -> CS_IDLE
ACTV
IDLE
CIC 8 -> CS_IDLE
ACTV
IDLE
CIC 9 -> CS_IDLE
ACTV
IDLE
CIC 10 -> CS_IDLE
ACTV
IDLE
CIC 11 -> CS_IDLE
ACTV
IDLE
CIC 12 -> CS_IDLE
ACTV
IDLE
CIC 13 -> CS_IDLE
ACTV
IDLE
CIC 14 -> CS_IDLE
ACTV
IDLE
CIC 15 -> CS_IDLE
ACTV
IDLE
CIC 16 -> CS_IDLE
ACTV
IDLE
CIC 17 -> CS_IDLE
ACTV
IDLE
CIC 18 -> CS_IDLE
ACTV
IDLE
CIC 19 -> CS_IDLE
ACTV
IDLE
CIC 20 -> CS_IDLE
ACTV
IDLE
CIC 21 -> CS_IDLE
ACTV
IDLE
CIC 22 -> CS_IDLE
ACTV
IDLE
CIC 23 -> CS_IDLE
ACTV
IDLE
CIC 24 -> CS_IDLE
ACTV
IDLE
Note Table 15-1 lists the responses that can be returned for the CQM test.
diag ss7-trunk-termination tgn-id=2; cic=1; test=5
Reply Example:
Reply: Success:
TGN ID -> 2
START CIC -> 1
END CIC -> 1
TEST TYPE -> ADM running SS7 circuit validation test
TEST DURATION -> 0
RESULT -> ADM ran test successfully
REASON -> CVT test pass
CLLI -> DALLTXRCDN5
Step 4 Force the SS7 trunk termination into INS state:
control ss7-trunk-termination tgn-id=103; mode=forced; target-state=ins;
Table 15-1 CQM Responses

Response

Description

CS_TRANSIENT

Transient

CS_UNEQUIPPED

Unequipped

CS_IC_BUSY

Incoming Busy

CS_IC_BUSY_LOCBLOC

Incoming Busy and Locally Maintenance Blocked

CS_IC_BUSY_REMBLOC

Incoming Busy and Remotely Maintenance Blocked

CS_IC_BUSY_BOTH_BLOC

Incoming Busy and Remotely and Locally Maintenance Blocked

CS_OG_BUSY

Outgoing Busy

CS_OG_BUSY_LOCBLOC

Outgoing Busy and Locally Maintenance Blocked

CS_OG_BUSY_REMBLOC

Outgoing Busy and Remotely Maintenance Blocked

CS_OG_BUSY_BOTH_BLOC

Outgoing Busy and Remotely and Locally Maintenance Blocked

CS_IDLE

Idle

CS_IDLE_LOCBLOC

Idle and Locally Maintenance Blocked

CS_IDLE_REMBLOC

Idle and remotely maintenance blocked

CS_IDLE_BOTH_BLOC

Idle and Remotely and Locally Maintenance Blocked

CS_HW_LOCBLOC

Locally Hardware Blocked

CS_HW_LOCBLOC_LOCBLOC

Locally Hardware and Locally Maintenance Blocked

CS_HW_LOCBLOC_REMBLOC

Locally Hardware and Remotely Maintenance Blocked

CS_HW_LOCBLOC_BOTHBLOC

Locally Hardware and Remotely and Locally Maintenance Blocked

CS_HW_REMBLOC

Remotely Hardware Blocked

CS_HW_REMBLOC_LOCBLOC

Remotely Hardware and Locally Maintenance Blocked

CS_HW_REMBLOC_REMBLOC

Remotely Hardware and Remotely Maintenance Blocked

CS_HW_REMBLOC_BOTHBLOC

Remotely Hardware and Remotely and Locally Maintenance Blocked

CS_HW_BOTHBLOC

Remotely and Locally Hardware Blocked

CS_HW_BOTHBLOC_LOCBLOC

Remotely and Locally Hardware and Locally Maintenance Blocked

CS_HW_BOTHBLOC_REMBLOC

Remotely and Locally Hardware and Remotely Maintenance Blocked

CS_HW_BOTHBLOC_BOTHBLOC

Remotely and Locally Hardware and Remotely and Locally Maintenance Blocked

Integrated Services Digital Network Trunk Termination Tests

This section describes the tests that can be performed on Integrated Services Digital Network (ISDN) trunk terminations. All terminations must be in the maintenance state for testing.

Step 1 Force the ISDN trunk termination into maintenance state:
control isdn-trunk-termination tgn-id=17; mode=forced; target-state=maint;
Step 2 Display the Test Menu.
diag isdn-trunk-termination
Reply Example:
Reply: Diagnostic ISDN Trunk Group Menu.
===
(1) ISDN MGCP Connectivity Test
(2) ISDN Termination Connection Test
(3) ALL
Note Test 1 tests if MGCP has access to the ISDN termination.

Test 2 tests if there is a path to the device (ping).

Test 3 performs tests 1 and 2.

Step 3 To perform a specific test, use the following examples as a guide:
diag isdn-trunk-termination test=1; tgn-id=17; cic=1;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 17
CIC -> 1
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
diag isdn-trunk-termination test=2; tgn-id=17; cic=1;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 17
CIC -> 1
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
Step 4 Force the ISDN trunk termination into MAINT state:
control isdn-trunk-termination tgn-id=17; mode=forced; target-state=maint;
Channel-Associated Signaling Trunk Termination Tests

This section describes the tests that can be performed on channel-associated signaling (CAS) trunk terminations. All terminations must be in the maintenance state for testing.

Step 1 Force the CAS trunk termination into maintenance state:
control cas-trunk-termination tgn-id=64; mode=forced; target-state=maint;
Step 2 Display the Test Menu.
diag cas-trunk-termination
Reply Example:
Reply: Diagnostic CAS Trunk Group Menu.
===
(1) CAS MGCP Connectivity Test
(2) CAS Termination Connection Test
(3) ALL
Note Test 1 tests if MGCP has access to the CAS termination.

Test 2 tests if there is a path to the device (ping).

Test 3 performs tests 1 and 2.

Step 3 To perform a specific test, use the following examples as a guide:
diag cas-trunk-termination tgn-id=64; cic=1; test=1;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 64
CIC -> 1
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
diag cas-trunk-termination tgn-id=64; cic=1; test=2;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 64
CIC -> 1
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 32
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
diag cas-trunk-termination tgn-id=64; cic=1; test=3;
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 64
CIC -> 1
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 11
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 64
CIC -> 1
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 32
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
Step 4 Force the CAS trunk termination into INS state:
control cas-trunk-termination tgn-id=64; mode=forced; target-state=ins;
Announcement Trunk Termination Tests

This section describes the tests that can be performed on Announcement trunk terminations. All terminations must be in the maintenance state for testing.

Step 1 Force the Announcement trunk termination into maintenance state:
control annc-trunk-termination tgn-id=13; mode=forced; target-state=maint;
Step 2 Display the Test Menu.
diag annc-trunk-termination;
Reply Example:
Reply: Diagnostic ANC Trunk Group Menu.
===
(1) ANC MGCP Connectivity Test
(2) ANC Termination Connection Test
(3) ALL
Note Test 1 tests if MGCP has access to the announcements module (ANC) termination.

Test 2 tests if there is a path to the device (ping).

Test 3 performs tests 1 and 2.

Step 3 To perform a specific test, use the following examples as a guide:
diag annc-trunk-termination test=1; tgn-id=13; cic=1
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 13
CIC -> 1
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 0
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
Reply: Diagnostic command executed.
diag annc-trunk-termination test=2; tgn-id=13; cic=1
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 13
CIC -> 1
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 33
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
diag annc-trunk-termination test=3; tgn-id=13; cic=1
Reply Example:
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 13
CIC -> 1
TEST-TYPE -> ADM-MGW-MGCP-CONNECTIVITY-TEST
TEST-DURATION -> 11
RESULT -> TEST-SUCCESS
REASON -> PASSED: Reason: AUEP-NACK received with RespCode = 510
TRUNK DIAGNOSTIC TEST EXECUTED -> diag trunk
TG-NUM -> 13
CIC -> 1
TEST-TYPE -> ADM-TERM-CONNECTION-TEST
TEST-DURATION -> 33
RESULT -> TEST-SUCCESS
REASON -> PASS successfully.
Reply: Diagnostic command executed.
Step 4 Force the Announcement trunk termination into INS state:
control annc-trunk-termination tgn-id=13; mode=forced; target-state=ins;
Troubleshooting Using Snoop

Caution Snoop should not be used on the Cisco BTS 10200 call agent itself in a production network. It can cause performance degradation.

Snoop can be used on the Cisco BTS 10200 call agent during test and turn-up phase during very low call volume periods. Snoop can always be used on a separate UNIX machine connected to a switch that has been properly set up for port span/mirroring. You must be logged in as "root" user to run snoop. Snoop can be used to decode text protocols or can be saved to a file and opened with Ethereal when binary protocols are used. Ethereal is open source software and can be downloaded from http://www.ethereal.com. To use Snoop to diagnose network problems, take the following steps:

Step 1 Find all routes to the destination in question. There are probably multiple roots, so multiple interfaces will need to be snooped. (Skip this step if you are snooping from a separate UNIX machine-you will just snoop the span destination interface in that case.) In this example, destination Internet Protocol (IP) 10.0.0.1 is in question. The fully qualified domain name (FQDN) can be used if it is resolvable by domain name system (DNS). Issue the snoop command several times as there may be redundant routes.
mssol-ca0-a# route get 10.0.0.1
   route to: 10.0.0.1
destination: default
       mask: default
    gateway: 10.0.0.253
 interface: qfe4
      flags: <UP,GATEWAY,DONE>
 recvpipe sendpipe ssthresh    rtt,ms rttvar,ms hopcount      mtu     expire
       0         0         0         0         0         0      1500         0
mssol-ca0-a# route get 10.0.0.1
   route to: 10.0.0.1
destination: default
       mask: default
    gateway: 10.0.0.253
 interface: qfe4
      flags: <UP,GATEWAY,DONE>
 recvpipe sendpipe ssthresh    rtt,ms rttvar,ms hopcount      mtu     expire
       0         0         0         0         0         0      1500         0
mssol-ca0-a# route get 10.0.0.1
   route to: 10.0.0.1
destination: default
       mask: default
    gateway: 10.20.0.253
 interface: qfe0
      flags: <UP,GATEWAY,DONE>
 recvpipe sendpipe ssthresh    rtt,ms rttvar,ms hopcount      mtu     expire
       0         0         0         0         0         0      1500         0
mssol-ca0-a# route get 10.0.0.1
   route to: 10.0.0.1
destination: default
       mask: default
    gateway: 10.20.0.253
 interface: qfe0
      flags: <UP,GATEWAY,DONE>
 recvpipe sendpipe ssthresh    rtt,ms rttvar,ms hopcount      mtu     expire
       0         0         0         0         0         0      1500         0
Note Each interface reported above must be snooped to catch all packets across redundant routes. In the example, interfaces qfe0 and qfe4 must be snooped.

Step 2 Issue the snoop command. The syntax might differ depending on protocol(s) that are being analyzed.

Session Initiation Protocol (SIP) example:

10.0.0.1 is a SIP phone. The goal is to monitor the SIP traffic between the Cisco BTS 10200 and the SIP phone.
# snoop -d qfe0 -x 42 host 10.0.0.1 and port 5060 and udp &
# snoop -d qfe4 -x 42 host 10.0.0.1 and port 5060 and udp &
MGCP/network-based call signaling (NCS) example:

10.0.0.1 is an integrated access device (IAD) running MGCP. The goal is to monitor MGCP traffic between the Cisco BTS 10200 and the IAD.
# snoop -d qfe0 -x 42 host 10.0.0.1 and port 2427 and udp &
# snoop -d qfe4 -x 42 host 10.0.0.1 and port 2427 and udp &
Stream Control Transmission Protocol (SCTP)/MTP3 user adaptation (M3UA)/ISDN user part (ISUP) example:

Since these protocols are not text based like those mentioned above, use the -o option with snoop to capture packets in an Ethereal readable format. Ethereal can decode SCTP/M3UA/ISUP or SCTP/SCCP user adapter (SUA)/Transaction Capabilities Application Part (TCAP). 10.0.0.1 is a Signaling Gateway acting as an M3UA peer with the Cisco BTS 10200.
# snoop -d qfe0 -o sctp.cap host 10.0.0.1 (this will capture all traffic)
Step 3 Use Control-C to stop the packet capture. Open the file in Ethereal and inspect. To capture sctp packets that contain M3UA information:

a. First, find the port M3UA will use to communicate with the signaling gateway (SG).
CLI> show sctp-assoc platform-id=CA146
ID=sgp1-itpa
SGP_ID=sgp1
SCTP_ASSOC_PROFILE_ID=sctp-prof1
REMOTE_PORT=2905 <-------------------this port
REMOTE_TSAP_ADDR1=10.0.0.1
PLATFORM_ID=CA146
DSCP=NONE
IP_TOS_PRECEDENCE=CRITICAL
LOCAL_RCVWIN=3000
MAX_INIT_RETRANS=3
MAX_INIT_RTO=500
STATUS=INS
ULP=XUA
# snoop -d qfe0 -o m3ua.cap host 10.0.0.1 and port 2905
b. Use Control-C to stop the packet capture. Open the file in Ethereal and inspect.

SCTP/SUA/TCAP example 1:

10.0.0.1 is a Signaling Gateway acting as an SUA peer with the Cisco BTS 10200. The goal is to capture all 800/local number portability (LNP) queries.

a. Follow the same syntax as for the M3UA case, except find which port SUA uses to communicate with the SG for Advanced Intelligent Network (AIN) features:
CLI> show sctp-assoc platform-id=FSAIN205
ID=sctp-ain-itpa
SGP_ID=sgp1
SCTP_ASSOC_PROFILE_ID=sctp-prof1
REMOTE_PORT=2907 <-------------------this port
REMOTE_TSAP_ADDR1=10.0.0.1
PLATFORM_ID=FSAIN205
DSCP=NONE
IP_TOS_PRECEDENCE=CRITICAL
LOCAL_RCVWIN=3000
MAX_INIT_RETRANS=3
MAX_INIT_RTO=500
STATUS=INS
ULP=XUA
# snoop -d qfe0 -o suaain.cap host 10.0.0.1 and port 2907
b. Use Control-C to stop the packet capture. Open the file in Ethereal and inspect.

SCTP/SUA/TCAP example 2:

10.0.0.1 is a Signaling Gateway acting as an SUA peer with the Cisco BTS 10200. The goal is to capture all offnet automatic callback and automatic rollback (ACAR) queries.

a. Follow the same syntax as for the M3UA case, except find the port SUA uses to communicate with the SG for plain old telephone service (POTS) features:
CLI> show sctp-assoc platform-id=FSPTC235
ID=sctp-ptc-itpa
SGP_ID=sgp2
SCTP_ASSOC_PROFILE_ID=sctp-prof1
REMOTE_PORT=2906 <------------------this port
REMOTE_TSAP_ADDR1=10.0.0.1
PLATFORM_ID=FSPTC235
DSCP=NONE
IP_TOS_PRECEDENCE=FLASH
LOCAL_RCVWIN=64000
MAX_INIT_RETRANS=5
MAX_INIT_RTO=1000
STATUS=INS
ULP=XUA
# snoop -d qfe0 -o suapots.cap host 10.0.0.1 and port 2906
b. Use Control-C to stop the packet capture. Open the file in Ethereal and inspect.

H.323 Protocol (H323) example:

10.0.0.1 is an H323 gateway. 10.0.0.129 is an H323 gatekeeper. Our goal is to monitor Registration, Admissions, Status (RAS), and H.225 messaging.

a. First, find the RAS port number and the H.225 port number.
CLI> show h323-gw
ID=ccm3_gw1
STATUS=INS
OPER_STATUS=NF
GW_H225_PORT=1720 <----------- this port
TGN_ID=4441
SECURITY=N
H245_TUNNELING=DEFAULT
TCP_MAX_LIMIT=5
TCP_MAX_AGE=30
MAX_VOIP_CALLS=65535
HIGH_WATER_MARK=0
LOW_WATER_MARK=0
IRR_BANDWIDTH_SUPP=N
IPTOS_SIG_LOWDELAY=Y
IPTOS_SIG_THROUGHPUT=N
IPTOS_SIG_RELIABILITY=N
IPTOS_SIG_PRECEDENCE=FLASH
BRQ_SUPP=Y
ANNEXE_RETRANSMIT_TIMER=500
ANNEXE_RETRANSMIT_MULTIPLIER=2
ANNEXE_RETRANSMIT_ATTEMPTS=8
CALL_START_MODE=FAST_START
ANNEXE_SUPP=N
ANNEXR_SUPP=N
STATUS_ENQ_TIMER=4
CODEC_NEG_TIMER=200
CODEC_NEG_ATTEMPTS=4
SOURCE_BASED_ROUTING=NONE
CLI> show h323-gw2gk
H323_GW_ID=ccm3_gw1
GK_ID=Metro-GK
PRIORITY=0
GK_IP_ADDR=10.0.0.129
GK_RAS_PORT=1719 <------------ this port
MULTICAST=N
TIME_TO_LIVE=60
# snoop -d qfe0 -o h323.cap host 10.0.0.1 and port 1720 or host 10.0.0.129 and port
1719
b. Use Control-C to stop the packet capture. Open the file in Ethereal and inspect.

COPs example:

10.0.0.1 is a cable modem termination system (CMTS) and is configured as an aggregation identification (AGGR-ID) in the Cisco BTS 10200. The goal is to monitor all Common Open Policy Service Protocol (COPS) messaging to and from the CMTS.

a. Issue the following command:
# snoop -d qfe0 -o cops.cap host 10.0.0.1 and port 2126 and tcp
b. Use Control-C to stop the packet capture. Open the file in Ethereal and inspect.

Step 4 Packets can be redirected to a file (not readable by Ethereal) in the following way:
# snoop -d qfe0 -x 42 host 10.0.0.1 and port 2427 and udp > mycapt.cap
Step 5 Stop the snoop processes.
# pkill snoop
# pgrep snoop (should not report any process ids)
Query Verification Tool and Translation Verification Tool

This section describes the Query Verification Tool (QVT) and the Translation Verification Tool (TVT) and is organized into the following sub-sections:

•Tool Requirements

•Query Verification Tool

•Translation Verification Tool

•Using Query Verification Tool and Translation Verification Tool Together

Tool Requirements

The following requirements are supported in the QVT and TVT:

•TVT—Provide a tool to find, diagnose, and trace call flow path decisions.

•Query Local Routing Number (QLRN) Tool—Provide the ability to enter a ten digit directory number and launch a query to the service control point (SCP) as though it was a number called from the signal switching point (SSP).

•Query Tool E800VER Command—Send a database query to the SCP as if it were an 800 called number from the SSP without initiating a call.

•Query Tool CNAMDVER and TESTSS CNAMD Commands—Provide the ability to query the SCP database for the calling name delivery (CNAM) display and privacy status associated with the name without initiating a call.

Query Verification Tool

This section describes the QVT and includes the following sections:

•Overview

•Command Format

•Response Format

•Query Errors

•Query Verification Tool Measurements

Overview

The QVT enables a user to generate TCAP queries to external databases through the command line interface (CLI) interface. The types of queries supported are:

•Line information database (LIDB)—Generated by the POTS Feature Server

•Toll-Free—Generated by the AIN Feature Server

•LNP—Generated by the AIN Feature Server

Command Format

The QVT command uses the following format:
query <lidb|toll-free|lnp> parameter=value;
Response Format

The system response to a query is in the following format:
Reply: <success|failure>; parameter=value;
Common Response Parameters

Successful response parameters include the following:

•OPC—Originating Point Code

•SSN—Subsystem Number

•TT—translation type

•SCP-Point-Code—Point Code of the SCP

•Automatic call gapping (ACG) component received

•ACG-Control-Code-Length

•Generic address parameter (GAP)-duration

•GAP-Interval

•Announcement-Cause-Code

An error message will be displayed if the query is not successful. For more information about error messages and problem resolution, refer to the "Query Errors" section.

Query Line Information Database Response Parameters

Additional parameters returned in response to a query lidb command include:

•Calling-DN

•Caller-ID Name String

•Caller-ID Name Privacy

Query Toll-Free Parameters

The following additional parameters are returned in response to a query toll-free command:

•Message-Type

•Original Number

•Translated Number

•Carrier

•Send-Notification-Received

Query Local Number Portability Parameters

The following additional parameters are returned in response to a query LNP command:

•Original Number

•Translated Number

Query Errors

An error can occur when a query command fails. This section specifies error responses and possible resolutions for problems.

Request Timeout

A query is sent to the feature server, but no response is received. The error response is similar to the one in the following example:
CLI> query lidb calling-dn=123247238723; opc-id=opc;
QUERY ON FEATURE SERVER FSPTC235 IS...->
FSPTC235 -> No Reply received!
Reply: Failure:
CLI>
The Feature Server did not respond to the query before a timeout occurred. Take the following steps to resolve the problem:

•If it was an LIDB query, execute the nodestat command on the POTS Feature Server to confirm that it is Active.

•If it was a Toll-Free or LNP query, execute the nodestat command on the AIN Feature Server to confirm that it is Active.

•If the platform is Active, execute the following command to confirm that the selective call acceptance (SCA) process is running:
ps -aef | grep sca
If the process is not running, start it through process debug manager (PDM) or by stopping and restarting the platform.

•If the platform is Active, execute the following command to confirm that the TCAP signaling adapter (TSA) process is running:
ps -aef | grep tsa
If the process is not running, start it through PDM or by stopping and restarting the platform.

•If the SCA and TSA processes are running on the Active platform, check the trace files for errors associated with the query.

Service Control Point Timeout

The SCP does not respond to a query. The error response is similar to the following example:
CLI> query lidb calling-dn=1232472387283; opc-id=opc;
QUERY ON FEATURE SERVER FSPTC235 IS...->
RESULT ->
QVT query has timed out
QUERYSTATUS -> Miscellaneous Failure
Reply: Success:
CLI>
There is no response from the SCP. Contact the SCP provider to find out why there is no error response returned from the SCP.

Missing Mandatory Parameter

The user performs a query but does not provide all required parameters. The error response is similar to the following example:
CLI> query toll-free called-dn=8002550002; user-type=calling-dn; user-id=2182640018;
lata=100; bearer-capability=speech; trigger-criteria=9;
Required attributes missing:
opc_id
CLI>
Supply all required parameters for the query. To view a list of parameters required for a command, enter a question mark (?) after the partial command. For example, query lidb? will display a list of required parameters for a LIDB query.

Advanced Intelligent Network 0.1 Query Attempted for IN/1 Configuration

An AIN0.1 Toll-Free query has been performed, but the system specifies that the Toll-Free subsystem is IN/1. The error response is similar to the following example:
CLI> query toll-free called-dn=8002550002; user-type=calling-dn; user-id=2182640018;
lata=100; bearer-capability=speech; trigger-criteria=9, opc-id=opc;
Reply: Failure: Missing CALLING_DN for the IN/1 query
CLI>
Reissue the command in the IN/1 format. To see what message type is specified for the Toll-Free subsystem, enter the following command:
CLI> query toll-free-msg-type opc-id=opc;
MESSAGE-TYPE=IN1
Reply: Success:
IN/1 Query Attempted for Advanced Intelligent Network 0.1 Configuration

An IN/1 Toll-Free query has been performed, but the system specifies that the Toll-Free subsystem is AIN 0.1. The error response is similar to the following example:
CLI> query toll-free: called-dn=8002550002; calling-dn=2182640018; lata=100;
trigger-criteria=9; opc-id=opc;
Reply: Failure: Missing USER_TYPE for the AIN 0.1 query
CLI>
Reissue the command in the AIN 0.1 format. To see what message type is specified for the Toll-Free subsystem, enter the following command:
CLI> query toll-free-msg-type; opc-id=opc;
MESSAGE-TYPE=AIN01
Reply: Success:
CLI>
Parameter Boundary Error

The query can fail if you enter invalid data for a specific parameter. In the following example, a value outside the boundary of expected values for the trigger-criteria parameter has been specified:
CLI> query toll-free; called-dn=8002550002; calling-dn=2182640018; lata=100;
trigger-criteria=12; opc-id=opc;
Invalid parameter value.
trigger_criteria=12; Enter one of the following values: [3,6,7,8,9,10].
CLI>
To resolve this error, enter a valid value for the specified parameter.

Record Does Not Exist

In the following example, a value has been entered for a lata that has not been provisioned:
CLI> query toll-free; called-dn=8002550002; calling-dn=2182640018; lata=101;
trigger-criteria=9; opc-id=opc;
Reply: Failure: LATA 101 does not exist
CLI>
To resolve this error, enter a provisioned local access and transport area (LATA).

Local Network Failure

When communication is lost between the Cisco BTS 10200 and the IP transfer point (ITP) gateway, a local network failure might occur. The most likely reason for this error is that the SCTP association is Out Of Service. The error response is similar to the following example:
CLI> query toll-free; called-dn=8002550002; calling-dn=2182640018; lata=100;
trigger-criteria=9; opc-id=opc;
QUERY ON FEATURE SERVER FSAIN205 IS...->
RESULT->
MTP failure - occurs at SP (PC7-44-1, SSN=254)
QUERYSTATUS -> Network Failure
Reply: Success:
CLI>
Perform the following to diagnose the problem:

•Execute the query again with the table-info option set to yes.

•Determine the status of the SCTP associations used for this command. If the associations are Out Of Service, control the associations back into service.

Remote Network Failure

A failure has occurred at a point code other than the OPC. The query response will specify what problem has occurred and at which point code the problem is detected. In the following example, the point code of the signal transfer point (STP) is reporting a failure because there is no Global Title Translation entry in the STP global title translation (GTT) database for the calling-dn.
CLI> query lidb; calling-dn=9823456789; opc-id=opc;
QUERY ON FEATURE SERVER FSPTC235 IS...->
RESULT ->
No translation for this specific address - occurs at SP (PC=1-101-0, SSN=0)
QUERYSTATUS -> Network Failure
Reply: Success:
CLI> status sctp-assoc;
To resolve this error, add an entry to the STP GTT database to translate the calling-dn and route the query request to the LIDB subsystem on the SCP.

Query Verification Tool Measurements

Table 15-2 identifies the measurements generated by the AIN Feature Server for the QVT feature.

Table 15-2 QVT AIN Tool Counters

Counter Label

Counter Description

TOOLS_LNP_QUERY_ATTMP

The total number of times the reporting feature server received a request to perform an LNP query from the QVT tool

TOOLS_LNP_QUERY_SUCC

The total number of times the reporting feature server received a request to perform an LNP query from the QVT tool and completed it successfully

TOOLS_TOLLFREE_QUERY_ATTMP

The total number of times the reporting feature server received a request to perform a Toll Free query from the QVT tool

TOOLS_TOLLFREE_QUERY_SUCC

The total number of times the reporting feature server received a request to perform a Toll Free query from the QVT tool and completed it successfully

Table 15-3 identifies the measurements generated by the POTS Feature Server for the QVT feature.

Table 15-3 QVT POTS Tool Counters

Counter Label

Counter Description

TOOLS_LIDB_QUERY_ATTMP

The total number of times the reporting feature server received a request to perform an LIDB query from the QVT tool

TOOLS_LIDB_QUERY_SUCC

The total number of times the reporting feature server received a request to perform an LIDB query from the QVT tool and completed it successfully

Translation Verification Tool

This section describes the TVT and includes the following sections:

•Overview

•Command Format

•Response Format

•Translation Verification Tool Measurements

Overview

The TVT is a diagnostic tool that simulates a call from the originator to a specific destination based on dialed digits. It enables a user to check system translations and determine if routing will occur as expected without making a call.

Command Format

The TVT command uses the following format:
translate <line|trunk>; parameter=value;
Response Format

Translation is the process of determining the destination of a call based on the dialed digits. The TVT performs translations and returns the tables traversed in order to reach the destination number. It does not complete a call but only allows you to view the route of the call.

The following example illustrates an incoming line call terminating to a trunk:
CLI> translate line calling-dn=9722331286; called-dn=7034321234;
TABLE: SUBSCRIBER
ID=sub1_ata2; CATEGORY=INDIVIDUAL; NAME=sub1; STATUS=ACTIVE; DN1=9722331003; PRIVACY=NONE;
RING_ TYPE_DN1=1; TERM_ID=a00/1; MGW_ID=ata2; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=northtexas; TERM_TYPE=TERM; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; SEND_BILLING_DN=N; SEND_BDN_AS_CPN=N; SEND_BDN_FOR_EMG=N;
TABLE: SUBSCRIBER_PROFILE
ID=northtexas; DIAL_PLAN_ID=dp1; LOCAL_PFX1_OPT=NR; TOLL_PFX1_OPT=RQ; POP_ID=1; OLI=0;
EA_USE_PIC1=Y;
TABLE: DIAL_PLAN_PROFILE
ID=dp1; Description=dialingplanprofile; NANP_DIAL_PLAN=Y; DNIS_DIGMAN_ID=dp1;
TABLE: DIAL_PLAN
ID=dp1; DIGIT_STRING=408555; DEST_ID=ssp1dest; SPLIT_NPA=NONE; DEL_DIGITS=0;
MIN_DIGITS=10; MAX_DIGITS=10; NOA=NATIONAL;
TABLE: DESTINATION
DEST_ID=ssp1dest; CALL_TYPE=LOCAL; ROUTE_TYPE=ROUTE; ROUTE_GUIDE_ID=ssp1rg; ZERO_PLUS=N;
INTRA_STATE=Y; GAP_ROUTING=N; CLDPTY_CTRL_REL_ALWD=N; TABLE: ROUTE_GUIDE ID=ssp1rg;
POLICY_TYPE=ROUTE; POLICY_ID=ssp1route;
TABLE: ROUTE
ID=ssp1route; TGN1_ID=1; DEL_DIGITS1=0; DEL_DIGITS2=0; EL_DIGITS3=0; DEL_DIGITS4=0;
DEL_DIGITS5=0; DEL_DIGITS6=0; DEL_DIGITS7=0; DEL_DIGITS8=0; DEL_DIGITS9=0; DEL_DIGITS10=0;
TG_SELECTION=RR;
TABLE: TRUNK_GRP
ID=1; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=1-12-1;
TG_PROFILE_ID=ssp1-tg-prof; STATUS=INS; DIRECTION=BOTH; SEL_POLICY=ASC; GLARE=EVEN;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=N; POP_ID=1; REMOTE_SWITCH_LRN=2122129999;
DIAL_PLAN_ID=dp19; Description=TG to BTS12; DEL_DIGITS=0; OPER_STATUS=NF;
TRAFFIC_TYPE=TANDEM; ANI_BASED_ROUTING=N; CLLI=DAL177DS3;
CALL_CTRL_ROUTE_ID=bts12-ccroute1; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
Reply: Success:
CLI>
Translation Verification Tool Measurements

Table 15-4 identifies the measurements generated by the TVT Tool.

Table 15-4 TVT Tool Counters

Counter Label

Counter Description

TOOLS_LNP_QUERY_ATTMP

The total number of times the reporting feature server received a request to perform an LNP query from the QVT tool

TOOLS_LNP_QUERY_SUCC

The total number of times the reporting feature server received a request to perform an LNP query from the QVT tool and completed it successfully

TOOLS_TOLLFREE_QUERY_ATTMP

The total number of times the reporting feature server received a request to perform a toll free query from the QVT tool

TOOLS_TOLLFREE_QUERY_SUCC

The total number of times the reporting feature server received a request to perform a toll free query from the QVT tool and completed it successfully

Using Query Verification Tool and Translation Verification Tool Together

It may be necessary to use both QVT and TVT queries to diagnose routing of a call. If the results of a translate command indicate that a toll-free or LNP query is generated, execute the QVT query. Use the results of the QVT query to generate another TVT query.

The following example illustrates verifying routing of a call from (972) 233-1286 to (800) 255-3002:

Step 1 Execute a TVT translate command:
CLI> translate line calling-dn=9722331286; called-dn=8002553002;
TRANSLATE LINE ON CALL AGENT CA146 IS...->
TABLEINFO ->
******TOLL FREE CALL NEEDS AN 800 QUERY******
Reply: Success:
CLI>
Step 2 The translate command indicates that a Toll-Free query is required. Perform the QVT query to do the number translation.
CLI> query toll-free called-dn=8002553002; calling-dn=9722331286; lata=100; opc-id=opc;
TOLL FREE QUERY ON FEATURE SERVER FSAIN520 IS...->
RESULT->
OPC=7-2-1
SSN=254
TT-254
SCP-Point-Code=1-101-0
Message-Type=IN/1
Called Number=8002553002
Translated Number=7034323002
Carrier=0000
Reply: Success:
CLI>
Step 3 The translated number returned by the QVT query can now be used in a TVT translate command to verify call routing.
CLI> translate line calling-dn=9722331286; called-dn=7034323002;
TRANSLATE LINE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sub_1_6; CATEGORY=INDIVIDUAL; NAME=sub16; STATUS=ACTIVE; ADDRESS1=1651 n glenville
suite 200; ADDRESS2=Richardson tx 75081; BILLING_DN=9722331286; DN1=9722331286;
PRIVACY=NONE; RING_TYPE_DN1=1; TERM_ID=aaln/S1/6; MGW_ID=c2421_1; PIC1=NONE; PIC2=NONE;
PIC3=NONE; GRP=N; USAGE_SENS=Y; SUB_PROFILE_ID=sub_pmlhg_prof1; TERM_TYPE=TERM;
IMMEDIATE_RELEASE=N; TERMINATING_IMMEDIATE_REL=N; SEND_BILLING_DN=N; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N;
TABLE: SUBSCRIBER_PROFILE
ID=sub_pmlhg_prof1; DIAL_PLAN_ID=dp1; LOCAL_PFX1_OPT=NR; TOLL_PFX1_OPT=RQ; LSA=9;
POP_ID=1; OLI=0; EA_USE_PIC1=N;
TABLE: DIAL_PLAN_PROFILE
ID=dp1; Description=dialing plan profile ID 1; NANP_DIAL_PLAN=Y; DNIS_DIGMAN_ID=dp_svc;
TABLE: DIAL_PLAN
ID=dp1; DIGIT_STRING=703432; DEST_ID=ssp1-dest; SPLIT_NPA=NONE; DEL_DIGITS=0;
MIN_DIGITS=7; MAX_DIGITS=10; NOA=NATIONAL;
TABLE: DESTINATION
DEST_ID=ssp1-dest; CALL_TYPE=LOCAL; ROUTE_TYPE=ROUTE; ROUTE_GUIDE_ID=ssp1-rg; ZERO_PLUS=N;
INTRA_STATE=Y; GAP_ROUTING=N; CLDPTY_CTRL_REL_ALWD=N;
TABLE: ROUTE_GUIDE
ID=ssp1-rg; POLICY_TYPE=ROUTE; POLICY_ID=ssp1-route;
TABLE: ROUTE
ID=ssp1-route; TGN1_ID=3; DEL_DIGITS1=0; DEL_DIGITS2=0; DEL_DIGITS3=0; DEL_DIGITS4=0;
DEL_DIGITS5=0; DEL_DIGITS6=0; DEL_DIGITS7=0; DEL_DIGITS8=0; DEL_DIGITS9=0; DEL_DIGITS10=0;
TG_SELECTION=RR;
TABLE: TRUNK_GRP
ID=3; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=1-12-1;
TG_PROFILE_ID=ssp1-tg-prof; STATUS=INS; DIRECTION=BOTH; SEL_POLICY=ASC; GLARE=EVEN;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=N; POP_ID=1; REMOTE_SWITCH_LRN=2122129999;
DIAL_PLAN_ID=dp19; Description=TG to BTS12; DEL_DIGITS=0; OPER_STATUS=NF;
TRAFFIC_TYPE=TANDEM; ANI_BASED_ROUTING=N; CLLI=DAL177DS3;
CALL_CTRL_ROUTE_ID=bts12-ccroute1; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
Reply: Success:
CLI>
LNP Examples

The following examples illustrate typical LNP call scenarios.

Example 1

This example illustrates a TVT command on a trunk origination, with CdPN resulting in an LNP query. QVT gets the RN and suggests the second translate command. The second TVT shows the route of the outgoing trunk group to the recipient switch.
btsadmin> translate trunk tgn-id=5; called-dn=11501160;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: TRUNK_GRP
ID=5; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-3;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=IN; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG IN from Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg5; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=Y;
TABLE: DIAL_PLAN_PROFILE
.
.
.
TABLE: OFFICE_CODE
DIGIT_STRING=11501; OFFICE_CODE_INDEX=15; DID=N; CALL_AGENT_ID=CA146; DIALAB
LE=Y; NDC=1; EC=150; DN_GROUP=1xxx; EC_DIGIT_STRING=1150;
TABLE: DN2SUBSCRIBER
OFFICE_CODE_INDEX=15; DN=1160; STATUS=PORTED_OUT; RING_TYPE=1; LNP_TRIGGER=N;
NP_RESERVED=N; LAST_CHANGED=2005-08-11 14:30:09.0; VIRTUAL_DN=N; PORTED_IN=N;
 ****** THIS CALL NEEDS AN LNP QUERY ******
****** LNP QUERY is needed (Onward Call Routing query), Suggested QUERY
Command to Run ******
QUERY LNP; tgn-id=5; called-dn=11501160
****** If query result is Routing Number (RN) Not Found,
       the above translation is valid
****** Otherwise, use the TRANSLATE command
       suggested by the query result
Reply: Success:
btsadmin> QUERY LNP tgn-id=5; called-dn=11501160;
QUERY ON FEATURE SERVER FSAIN205 IS... ->
RESULT ->
Called Number=11501160, Routing Number (RN) =4101
**** Suggested TRANSLATE Command ****
TRANSLATE TRUNK tgn_id=5; original_called_dn=11501160; called_dn=4101-11501160;
noa=PORTED_NUMBER_WITH_RN;
btsadmin> TRANSLATE TRUNK tgn_id=5; original_called_dn=11501160; called_dn=4101-11501160;
noa=PORTED_NUMBER_WITH_RN;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: TRUNK_GRP
.
.
.
ID=inet116_rg1; POLICY_TYPE=ROUTE; POLICY_ID=inet116_rte;
TABLE: ROUTE
ID=inet116_rte; TGN1_ID=6; DEL_DIGITS1=0; DEL_DIGITS2=0; DEL_DIGITS3=0; DEL_DIGITS4=0;
DEL_DIGITS5=0; DEL_DIGITS6=0; DEL_DIGITS7=0; DEL_DIGITS8=0; DEL_DIGITS9=0; DEL_DIGITS10=0;
TG_SELECTION=SEQ; NEXT_ACTION=NONE;
TABLE: TRUNK_GRP
ID=6; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-4;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=OUT; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG OUT to Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg6; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=N;
Reply: Success:
Example 2

In this example, a subscriber dials a DN ported-out of this switch. QVT gets the RN, and a second TVT shows the route of the outgoing trunk group to the recipient switch.

Because the called DN is ported-out, the call cannot be routed on this switch without an LNP query. If QVT does not find an RN, perhaps because the DN2RN table is incorrect temporarily during the porting transition, the call will be released due to cause unallocated number.
btsadmin> translate line calling-dn=11501511; called-dn=11501160;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sipata1; CATEGORY=INDIVIDUAL; NAME=h15 sipata1 Moe; STATUS=ACTIVE; BILLING_DN=11501511;
DN1=11501511; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501511@192.168.54.124; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
.
.
.
TABLE: DN2SUBSCRIBER
OFFICE_CODE_INDEX=15; DN=1160; STATUS=PORTED_OUT; RING_TYPE=1; LNP_TRIGGER=N;
NP_RESERVED=N; LAST_CHANGED=2005-08-11 14:30:09.0; VIRTUAL_DN=N; PORTED_IN=N;
 ****** THIS CALL NEEDS AN LNP QUERY ******
****** LNP QUERY is needed (Onward Call Routing query), Suggested QUERY Command to Run
******
QUERY LNP calling-dn=11501511; called-dn=11501160
****** If query result is Routing Number (RN) Not Found,
       the above translation is valid
****** Otherwise, use the TRANSLATE command
       suggested by the query result
Reply: Success:
btsadmin>
btsadmin>
btsadmin> QUERY LNP calling-dn=11501511; called-dn=11501160
QUERY ON FEATURE SERVER FSAIN205 IS... ->
RESULT ->
Called Number=11501160, Routing Number (RN) =4101
**** Suggested TRANSLATE Command ****
TRANSLATE LINE calling_dn=11501511; original_called_dn=11501160; called_dn=4101-11501160;
NOA=PORTED-NUMBER-WITH-RN;
QUERYSTATUS -> Query Success
Reply: Success:
btsadmin>
btsadmin>
btsadmin> TRANSLATE LINE calling_dn=11501511; original_called_dn=11501160;
called_dn=4101-11501160; NOA=PORTED-NUMBER-WITH-RN;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sipata1; CATEGORY=INDIVIDUAL; NAME=h15 sipata1 Moe; STATUS=ACTIVE; BILLING_DN=11501511;
DN1=11501511; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501511@192.168.54.124; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
.
.
.
TABLE: TRUNK_GRP
ID=6; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-4;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=OUT; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG OUT to Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg6; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=N;
Reply: Success:
btsadmin>
Example 3

In this example, the first TVT shows a translation but indicates that an LNP query is needed. The QVT does not find an RN, so the first TVT has the correct translation and routing information.
btsadmin> translate line calling-dn=11501511; called-dn=11501512;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sipata1; CATEGORY=INDIVIDUAL; NAME=h15 sipata1 Moe; STATUS=ACTIVE; BILLING_DN=11501511;
DN1=11501511; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501511@192.168.54.124; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
TABLE: SUBSCRIBER_PROFILE
ID=hungary_prof; DIAL_PLAN_ID=dp_sub_itu; LOCAL_PFX1_OPT=NR; TOLL_PFX1_OPT=RQ;
POP_ID=hun1; OLI=0; EA_USE_PIC1=Y; INTERLATA_PFX1_OPT=RQ;
.
.
.
TABLE: SUBSCRIBER
ID=sipata2; CATEGORY=INDIVIDUAL; NAME=h15 sipata2 Larry; STATUS=ACTIVE;
BILLING_DN=11501512; DN1=11501512; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE;
PIC3=NONE; GRP=N; USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP;
IMMEDIATE_RELEASE=N; TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501512@192.168.54.124;
SEND_BDN_AS_CPN=N; SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
****** LNP QUERY is needed (LNP-TRIGGER for ODBR), Suggested QUERY Command to Run ******
QUERY LNP calling-dn=11501511; called-dn=11501512
****** If query result is Routing Number (RN) Not Found,
       the above translation is valid
****** Otherwise, use the TRANSLATE command
       suggested by the query result
Reply: Success:
btsadmin>
btsadmin> QUERY LNP calling-dn=11501511; called-dn=11501512
QUERY ON FEATURE SERVER FSAIN205 IS... ->
RESULT ->
Called Number=11501512, Routing Number (RN) Not Found
QUERYSTATUS -> Query Success
Reply: Success:
Example 4

This example is for a QOR originating switch. A subscriber dials a DN that is ported-out of another (donor) switch. The call is translated and routed to the donor switch, as shown in the first translate TVT command below. The donor switch sends a REL with LNP QOR: Ported Number cause to the originating switch.

The originating switch receives the REL with LNP QOR: Ported Number cause, and then the originating switch does an LNP query. The QVT query finds an RN, and the RN and NOA are used as input to the TVT to show the routing after the QOR query, as shown in the second translated command below.
btsadmin> translate line calling-dn=11501511; called-dn=11161168
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sipata1; CATEGORY=INDIVIDUAL; NAME=h15 sipata1 Moe; STATUS=ACTIVE; BILLING_DN=11501511;
DN1=11501511; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501511@192.168.54.124; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
TABLE: SUBSCRIBER_PROFILE
ID=hungary_prof; DIAL_PLAN_ID=dp_sub_itu; LOCAL_PFX1_OPT=NR; TOLL_PFX1_OPT=RQ;
POP_ID=hun1; OLI=0; EA_USE_PIC1=Y; INTERLATA_PFX1_OPT=RQ;
.
.
.
TABLE: TRUNK_GRP
ID=6; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-4;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=OUT; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG OUT to Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg6; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=N;
Reply: Success:
btsadmin>
btsadmin>
btsadmin>
btsadmin>
btsadmin> query LNP calling-dn=11501511; called-dn=11161168;
QUERY ON FEATURE SERVER FSAIN205 IS... ->
RESULT ->
Called Number=11161168, Routing Number (RN) =4001
**** Suggested TRANSLATE Command ****
TRANSLATE LINE calling_dn=11501511; original_called_dn=11161168; called_dn=4001-11161168;
NOA=PORTED-NUMBER-WITH-RN;
QUERYSTATUS -> Query Success
Reply: Success:
btsadmin>
btsadmin>
btsadmin>
btsadmin>
btsadmin> TRANSLATE LINE calling_dn=11501511; original_called_dn=11161168;
called_dn=4001-11161168; NOA=PORTED-NUMBER-WITH-RN;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: SUBSCRIBER
ID=sipata1; CATEGORY=INDIVIDUAL; NAME=h15 sipata1 Moe; STATUS=ACTIVE; BILLING_DN=11501511;
DN1=11501511; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE; PIC3=NONE; GRP=N;
USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP; IMMEDIATE_RELEASE=N;
TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501511@192.168.54.124; SEND_BDN_AS_CPN=N;
SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
TABLE: SUBSCRIBER_PROFILE
ID=hungary_prof; DIAL_PLAN_ID=dp_sub_itu; LOCAL_PFX1_OPT=NR; TOLL_PFX1_OPT=RQ;
POP_ID=hun1; OLI=0; EA_USE_PIC1=Y; INTERLATA_PFX1_OPT=RQ;
.
.
.
TABLE: TRUNK_GRP
ID=6; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-4;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=OUT; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG OUT to Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg6; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=N;
Reply: Success:
Example 5

This example illustrates an incoming trunk call with an RN prefix and ported number NOA.

Note In this example, the Cisco BTS 10200 reminds you that the NOA and ORIGINAL-CALLED-DN tokens must both be specified.
btsadmin> translate trunk tgn-id=5; called-dn=400111501512; NOA=PORTED-NUMBER-WITH-RN;
Reply: Failure: NOA and ORIGINAL-CALLED-DN should be specified together
btsadmin>
btsadmin>
btsadmin> translate trunk tgn-id=5; called-dn=400111501512; NOA=PORTED-NUMBER-WITH-RN;
original-called-dn=11501512;
TRANSLATE ON CALL AGENT CA146 IS... ->
TABLEINFO ->
TABLE: TRUNK_GRP
ID=5; CALL_AGENT_ID=CA146; TG_TYPE=SS7; NUM_OF_TRUNKS=24; DPC=5-2-3;
TG_PROFILE_ID=tgprof_inet116; STATUS=INS; DIRECTION=IN; SEL_POLICY=DSC; GLARE=SLAVE;
ALT_ROUTE_ON_CONG=N; SIGNAL_PORTED_NUMBER=Y; POP_ID=hun1; DIAL_PLAN_ID=dp_trk_itu;
Description=TG IN from Inet 116; DEL_DIGITS=0; TRAFFIC_TYPE=LOCAL; ANI_BASED_ROUTING=N;
CALL_CTRL_ROUTE_ID=cc_rte_i116_tg5; MGCP_PKG_TYPE=T; ANI_SCREENING=N; SEND_RDN_AS_CPN=N;
STATUS_MONITORING=N; SEND_EARLY_BKWD_MSG=N; EARLY_BKWD_MSG_TMR=5; SCRIPT_SUPP=N;
VOICE_LAYER1_USERINFO=AUTO; VOICE_INFO_TRANSFER_CAP=AUTO; ACCESS_TYPE=COMBINED;
POI=INTER_ENDOFFICE; PERFORM_LNP_QUERY=Y;
TABLE: DIAL_PLAN_PROFILE
ID=dp_trk_itu; Description=Trunk Origination Local dial-plan (ITU); NANP_DIAL_PLAN=N;
ANI_DIGMAN_ID=dm_dpp_ani_itu; DNIS_DIGMAN_ID=dm_dpp_trk_itu; OVERDECADIC_DIGITS_SUPP=N;
NOA_BASED_ROUTING=Y; NOA_ROUTE_PROFILE_ID=noa_rt;
TABLE: DIGMAN
ID=dm_dpp_ani_itu; RULE=1; MATCH_NOA=ANY; REPLACE_NOA=NATIONAL;
TABLE: DIGMAN
ID=dm_dpp_trk_itu; RULE=1; MATCH_STRING=^4001; REPLACE_STRING=NONE;
MATCH_NOA=PORTED_NUMBER_WITH_RN; REPLACE_NOA=UNKNOWN;
TABLE: NOA_ROUTE_PROFILE
ID=noa_rt; Description=NOA Route profile (ITU) to RN dial-plan;
CONTINUE WITH EXISTING DIAL-PLAN
TABLE: DIAL_PLAN
ID=dp_trk_itu; DIGIT_STRING=1150; DEST_ID=dest_sub_itu; SPLIT_NPA=NONE; DEL_DIGITS=0;
MIN_DIGITS=8; MAX_DIGITS=8; NOA=UNKNOWN;
TABLE: DESTINATION
DEST_ID=dest_sub_itu; CALL_TYPE=LOCAL; ROUTE_TYPE=SUB; ZERO_PLUS=N; INTRA_STATE=Y;
Description=ITU Sub dest: Allow LNP query; GAP_ROUTING=N; ANI_DIGMAN_ID=dm_dest_sub_ani;
DNIS_DIGMAN_ID=dm_dest_rn; CLDPTY_CTRL_REL_ALWD=N; CALL_SUBTYPE=NONE;
ACQ_LNP_QUERY=PERFORM_LNP_QUERY;
TABLE: OFFICE_CODE
DIGIT_STRING=11501; OFFICE_CODE_INDEX=15; DID=N; CALL_AGENT_ID=CA146; DIALABLE=Y; NDC=1;
EC=150; DN_GROUP=1xxx; EC_DIGIT_STRING=1150;
TABLE: DN2SUBSCRIBER
OFFICE_CODE_INDEX=15; DN=1512; STATUS=ASSIGNED; RING_TYPE=1; LNP_TRIGGER=Y; NP_RESERVED=N;
SUB_ID=sipata2; LAST_CHANGED=2005-09-08 11:08:47.0; VIRTUAL_DN=N; PORTED_IN=N;
TABLE: SUBSCRIBER
ID=sipata2; CATEGORY=INDIVIDUAL; NAME=h15 sipata2 Larry; STATUS=ACTIVE;
BILLING_DN=11501512; DN1=11501512; PRIVACY=NONE; RING_TYPE_DN1=1; PIC1=NONE; PIC2=NONE;
PIC3=NONE; GRP=N; USAGE_SENS=Y; SUB_PROFILE_ID=hungary_prof; TERM_TYPE=SIP;
IMMEDIATE_RELEASE=N; TERMINATING_IMMEDIATE_REL=N; AOR_ID=11501512@192.168.54.124;
SEND_BDN_AS_CPN=N; SEND_BDN_FOR_EMG=N; PORTED_IN=N; BILLING_TYPE=NONE; VMWI=Y; SDT_MWI=Y;
Reply: Success:
btsadmin>
Network Loopback Test for Network-Based Call Signaling/Media Gateway Control Protocol Endpoints

This section describes the feature that provides the capability to perform network loopback tests on any line side PacketCable Network-based Call Signaling protocol specification/Media Gateway Control Protocol (NCS/MGCP) Residential Gateways. The network loopback tests can be initiated from designated test endpoints. This section also describes enhancements to the TDM bearer path test call feature.

This section contains the following:

•Overview

•Restrictions

•Installing

•Configuring

•Network Loopback Test for Network-Based Call Signaling/Media Gateway Control Protocol Endpoints

Overview

The Network Loopback Test for NCS/MGCP Endpoints feature provides a testing device with the capability to perform network loopback tests from any line side NCS/MGCP residential gateways or media termination adapters (MTAs). These loopback tests are initiated from designated test endpoints (subscribers) controlled by the Cisco BTS 10200.

The basic network loopback test feature is service affecting. In other words, while a network loopback call is in progress, the endpoint is considered busy.

The Cisco BTS 10200 network loopback and network continuity tests also have a service-not-affected mode. In this mode, the Cisco BTS 10200 will attempt to create coexisting test connections on the test device; however, if the endpoint does not have enough resources, the Cisco BTS 10200 gives preference to regular calls, processing them first before it processes any test calls.

In the service-affected mode the Cisco BTS 10200 will not try to initiate other calls, even if the MTA/TGW can set up multiple connections (PARALLEL-TEST-CONN-SUPP=Y).

The Cisco BTS 10200 allows the system level configuration to specify whether the network loopback and network continuity test calls will be service affecting or not service affecting.

Restrictions

Although you can test this feature by using the regular MTA as the testing device (by configuring the endpoints as subscriber terminations in Cisco BTS 10200), you need special test equipment such as BRIX if voice quality testing needs to be done.

You should configure the testing and tested devices on the same Call Agent. The Cisco BTS 10200 cannot perform network loopback test calls that originate from another switch and does not route calls from a testing device on an H.323 or SIP interface.

Note You cannot perform the network loopback test if the status of the subscriber to be tested is unequipped (UEQP) or operational-out-of-service (OOS).

Installing

The following items must be configured:

•Test origination endpoints as trunks instead of line

•Special dial plan and destination with CALL-TYPE TEST-CALL; CALL-SUBTYPE=NLB-TEST)

Configuring

In order for parallel test connections to work, the following settings need to be configured in the ca-config:
add ca-config type=NLB-TEST-SERVICE-AFFECTING; datatype=BOOLEAN; value=N;
add ca-config type=NCT-TEST-SERVICE-AFFECTING; datatype=BOOLEAN; value=N;
Configuration Examples

The following example shows the steps required to configure the originating line (media gateway profile) to identify a network loopback call.

Note These tasks include examples of CLI commands that illustrate how to provision the specific feature. Most of these tables have additional tokens that are not included in the examples. For a complete list of all CLI tables and tokens, see the Cisco BTS 10200 Softswitch CLI Database.

Global Configuration Example

Step 1 Add ca-config NLB-TEST-SERVICE-AFFECTING.
add ca-config type=NLB-TEST-SERVICE-AFFECTING; value=N
Step 2 Add ca-config NCT-TEST-SERVICE-AFFECTING.
add ca-config type=NCT-TEST-SERVICE-AFFECTING; value=N;
Step 3 Add ca-config TEST-TRUNK-GRP-DIGITS.
add ca-config type=TEST-TRUNK-GRP-DIGITS; value=4;
Step 4 Add ca-config TEST-TRUNK-MEMBER-DIGITS.
add ca-config type=TEST-TRUNK-MEMBER-DIGITS; value=4;
Dedicated NLB Testing Device Configuration Example

The following procedure is a dedicated NLB testing device configuration example. Change TEST-LINE-TYPE to different values (other than NTE) to change test origination type.

Step 1 Add MGW profile.
add mgw-profile id=BRIX; vendor=Tollgrade; mgcp-version=mgcp_1_0; MGCP-VARIANT=NCS-1-0;
Step 2 Add cas-tg-profile.
add cas-tg-profile id=BRIX_TG; sig-type=LINE; TEST-LINE=Y; TEST-LINE-TYPE=NLB-LINE-TEST
Step 3 Add MGW.
add mgw id=brix1; tsap-addr=<mgw DNS / IP address>; mgw-profile-id=BRIX; type=TGW;
call-agent id=CA146;
Step 4 Add trunk-grp.
add trunk-grp id=100; call-agent-id=CA146; tg-type=CAS; cas-tg-profile=BRIX_TG;
mgcp-pkg-type=LINE
Step 5 Add termination.
add termination prefix=aaln/; port-start=1; port-end=2; type=TRUNK; mgw-id=c925.172;
Step 6 Add trunk.
add trunk termination-prefix=aaln/; termination-port-start=1; termination-port-end=2;
cic-start=1; cic-end=2; tgn-id=100
Shared Testing Device Configuration Example

The following procedure is a shared testing device configuration example.

Step 1 Add MGW profile.
add mgw-profile id=BRIX; vendor=Tollgrade; mgcp-version=mgcp_1_0; MGCP-VARIANT=NCS-1-0;
Step 2 Add cas-tg-profile.
add cas-tg-profile id=BRIX_TG; sig-type=LINE; TEST-LINE=Y; TEST-LINE-TYPE=NTE
Step 3 Add MGW.
add mgw id=brix1; tsap-addr=<mgw DNS / IP address>; mgw-profile-id=BRIX; type=TGW;
call-agent id=CA146;
Step 4 Add trunk-grp.
add trunk-grp id=100; call-agent-id=CA146; tg-type=CAS; cas-tg-profile=BRIX_TG;
mgcp-pkg-type=LINE
Step 5 Add termination.
add termination prefix=aaln/; port-start=1; port-end=2; type=TRUNK; mgw-id=c925.172;
Step 6 Add trunk.
add trunk termination-prefix=aaln/; termination-port-start=1; termination-port-end=2;
cic-start=1; cic-end=2; tgn-id=100
Step 7 Add dial-plan-profile.
add dial-plan-profile id=dp1; description=NA_Default;
Step 8 Add dial-plan.
add dial-plan id=dp1; digit-string=919-392; dest-id=sub; noa=national;
Step 9 Add digit-map.
add digit-map id=test;
digit-pattern=[2-9]xx[2-9]xxxxxx|011xxxxxx.T|01xxxxxx.T|101xxxx|#|*xx|11xx|xxxxxxxxxxxxxxx
xxxx; description=default_pattern
Step 10 Add subscriber-profile.
add subscriber-profile id=subpf1; digit-map-id=test; dial-plan-id=DP1; POP-ID=1;
Step 11 Add subscriber.
add subscriber id=sub11; sub-profile-id= subpf1; category=individual; term-id=aaln/0;
mgw-id=c925.172; dn1=919-392-1235; name=RTP5;
Tested Line Device Configuration Example

The following procedure is a tested line device configuration example.

Step 1 Add MGW profile.
add mgw-profile id=UBR925; vendor=Cisco; mgcp-version=mgcp_1_0; MGCP-VARIANT=NCS_1_0;
Step 2 Add MGW.
add mgw id=c925.172; tsap-addr=<mgw DNS / IP address>; mgw-profile-id=UBR925; call-agent
id=CA103;
Step 3 Add termination.
add termination prefix=aaln/; port-start=0; port-end=1; type=line; mgw-id=c925.172;
mgcp-pkg-type=line-ncs;
Step 4 Add destination.
add destination dest-id=local-call; route-type=sub; call-type=local;
Step 5 Add dial-plan-profile.
add dial-plan-profile id=dp1; description=NA_Default;
Step 6 Add dial-plan.
add dial-plan id=dp1; digit-string=919-392; dest-id=sub; noa=national;
Step 7 Add subscriber-profile.
add subscriber-profile id=subpf1; dial-plan-id=dp1; pop-id=1;
Step 8 Add subscriber.
add subscriber id=sub11; sub-profile-id= subpf1; category=individual; term-id=aaln/0;
mgw-id=c925.172; dn1=919-392-1235; name=RTP5;
Routing for Shared trunk-grp IP Testing Flow Chart Configuration Example

The following procedure is a routing for shared trunk-grp IP testing flow chart configuration example.

Step 1 Add destination.
add destination dest-id=DEST_NLB_SUB; call-type=TEST-CALL; call-subtype=NLB-LINE-TEST;
route-type=SUB;
add destination dest-id=DEST_NCT_SUB; call-type=TEST-CALL; call-subtype=NCT-LINE-TEST;
route-type=SUB;
add destination dest-id=DEST_NLB_TRUNK; call-type=TEST-CALL; call-subtype=NLB-TRUNK-TEST;
route-type=ROUTE; route-guide-id=abc
add destination dest-id=DEST_NCT_TRUNK; call-type=TEST-CALL; call-subtype=NCT-TRUNK-TEST;
route-type=ROUTE; route-guide-id=abc
Step 2 Add call-subtype-profile.
add call-subtype-profile call-type=TEST_CALL; call-subtype=NONE; qos-id=1;
Step 3 Add dial-plan-profile.
add dial-plan-profile id=test; nanp-dial-plan=N
Step 4 Add dial-plan.
add dial-plan id=test; digit-string=151; dest-id=DEST_NLB_SUB; min-digits=13;
max-digits=13
add dial-plan id=test; digit-string=152; dest-id=DEST_NCB_SUB; min-digits=13;
max-digits=13
add dial-plan id=test; digit-string=153; dest-id=DEST_NLB_TRUNK; min-digits=13;
max-digits=13
add dial-plan id=test; digit-string=154; dest-id=DEST_NCT_TRUNK; min-digits=13;
max-digits=13
Testing Device Status and Control Flowchart Configuration Example

The following procedure is a testing device status and control flowchart configuration example.

Step 1 Control MGW.
control mgw id=c925.172; target-state=INS; mode=FORCED;
Step 2 Status MGW.
status mgw id=c925.172;
Step 3 Control trunk-grp.
control trunk-grp id=100; call-agent-id=CA146; 	target-state=INS; mode=forced;
Step 4 Equip trunk-termination.
equip trunk-termination tgn-id=100; cic=all;
Step 5 Control trunk-termination.
control trunk-termination tgn-id=100; cic=all; target-state=INS; mode=forced;
Step 6 Status trunk-termination.
status trunk-termination id=100; cic=all;
Step 7 Reset trunk-termination.
reset trunk-termination id=100; cic=all;
Network Loopback Test for Network-Based Call Signaling/Media Gateway Control Protocol Endpoints

This section describes network loopback testing for network-based call signaling and media gateway control protocol endpoints feature and includes descriptions of the following:

•Dedicated Test Trunk Group

•Shared Test Trunk Group

•Configuring the Originating Trunk Group

To use this feature, place a call from the testing device subscriber to any MGCP subscriber to be tested. For example, if the testing device is an MGCP telephone, dial the number of the subscriber to be tested.

Dedicated Test Trunk Group

The Cisco BTS 10200 allows NCS/MGCP endpoints in a trunk group to be provisioned as a dedicated test trunk group.

The provisioning of the test trunk group determines if incoming calls arriving on the dedicated test trunk groups trigger the Cisco BTS 10200 to complete the test call through a Network Loopback (NLB) or Network Continuity Test (NCT). The category of the test call is preprovisioned on the dedicated test trunk groups—all calls from a particular test trunk group invoke the same test category while calls from another test trunk group might invoke a different test category. A test call from a test device utilizes the eMTA directory number (DN) the same as any other regular dialed digit string.

The called party number format is:

<Test-data>

Where:

<Test-data> = DN (for example, the NCS/MGCP dialed digits signaled to the Cisco BTS 10200 are in the form of a 10-digit DN such as 2145261234, or <TG>TM> (Trunk group and trunk member)

The steps for configuring the originating trunk group are

Step 1 Add a trunk group for the testing device as CAS trunk group (TRUNK-GRP::TG-TYPE=CAS).

Step 2 Associate the trunk group to CAS-TG-PROFILE specific to network loopback test origination type (CAS-TG-PROFILE::TEST-LINE=Y; CAS-TG-PROFILE::TEST-LINE-TYPE=NLB-LINE/NCT-LINE/NLB-TRUNK/NCT-TRUNK.

Step 3 Add all test lines in the testing device as trunk termination.

Shared Test Trunk Group

In addition to dedicated test trunk groups, the Cisco BTS 10200 allows a shared test trunk group, where the category of the test to be run is specified by the test-prefix. Cisco BTS 10200 allows a test trunk group to be associated with a test dial plan. The test trunk group can be either the IP or CAS TDM trunks. Incoming calls from the network on these trunk groups are analyzed according to a preconfigured test dial plan. The following is the format of dialed digits for these incoming test calls.

Called party number format:

<Test-prefix><Test-data>

Where:

•<Test-prefix> is a string of digits that denote the test category. Operator must configure the definition (recommended as a pattern of 1 to 6 digits, the Cisco BTS 10200 Softswitch will perform the longest match) of the test prefix and its length, whether it is IP or TDM testing. If it is TDM testing, the traditional 1xx test type value is expected or the general TDM test category needs to be specified (for example, 199) when the route out DN testing is going to be used.

For example, test-prefix 152 may denote NLB IP testing, or 105 may convey the TDM 105 test-type, or 199 may be defined to specify the TDM route out DN testing, or 153 is the configured prefix for NCT.

•<Test-data> is a string that depends on the test-prefix content.

Configuring the Originating Trunk Group

The following are the steps for configuring the originating trunk group:

Step 1 Add a trunk-group for the testing device as CAS trunk-group (TRUNK-GRP::TG-TYPE=CAS).

Step 2 Associate the trunk-grp to CAS-TG-PROFILE specific to network loopback test origination (CAS-TG-PROFILE::TEST-LINE=Y; CAS-TG-PROFILE::TEST-LINE-TYPE=NTE.

Step 3 Configure all test lines in Testing device as trunk-termination.

Step 4 Configure the test dial plan destination with the exact type of test call.

Step 5 Configure the call subtype profile.

Step 6 Configure the main subscriber ID for testing trunk-grp.

Step 7 Configure the digit map for collecting prefixed digits and associate it to the SUBSCRIBER-PROFILE table.

Session Initiation Protocol Subscriber Registration Status Check

The SIP subscriber registration status check CLI command (sip-reg-contact) is used to check the registration status of a SIP subscriber. The need to check the registration status of a SIP subscriber can arise, for example, when a subscriber complains about not being able to receive calls. The first item to check would be the registration status; use the sip-reg-contact command. The next item would be to check for events regarding authentication failures and so on.

The following examples show the usage of the sip-reg-contact command. The first example shows an expired contact and the second example shows a registered contact or current contact.

Example 1:

Use CLI to check the registration status of an address of record (AOR).
CLI> status sip-reg-contact
CLI> AOR_ID=4692551119@sia-SYS44CA146.ipclab.cisco.com;
AOR ID -> 4692551119@sia-SYS44CA146.ipclab.cisco.com
USER -> 4692551119
HOST -> 10.89.220.21
PORT -> 5060
USER TYPE -> USER_PHONE_TYPE
EXPIRES -> 3600
EXPIRETIME -> Tue Oct 7 12:13:11 2003
STATUS -> EXPIRED CONTACT
Reply: Success:
Example 2:

Use CLI to check the registration status of an AOR.
CLI> status sip-reg-contact
CLI> AOR_ID=4692551001@sia-SYS44CA146.ipclab.cisco.com;
AOR ID -> 4692551001@sia-SYS44CA146.ipclab.cisco.com
USER -> 4692551001
HOST -> 10.89.223.193
PORT -> 5060
USER TYPE -> USER_IP_TYPE
EXPIRES -> 3600
EXPIRETIME -> Thu Oct 23 16:23:48 2003
STATUS -> REGISTERED CONTACT
Reply: Success:
System Health Report

The System Health Report (system-health) (SHR) allows the retrieval of the status of various processes within the Cisco BTS 10200.

Use the following example shows you how to run a SHR:
CLI> report system-health period=720;
Period

The length of time to collect in hours. INTEGER: 1-720 (Default = 24).

The SHR command can be used in conjunction with the command scheduler. Using the command scheduler, the SHR runs at periodic intervals collecting the last 24 hours (configurable) worth of data. Upon initial installation and startup of the Cisco BTS 10200, an SHR command is scheduled to execute at midnight every 24 hours.

To schedule multiple SHR command(s) at different times, you can use the command scheduler add command multiple times:
CLI> add scheduled-command verb=report; noun=system-health; <recurrence=daily>;
<start-time=...>; <keys=period>; <values=...>
Use the following command to remove any scheduled SHR command(s):
CLI> delete scheduled-command id=NNN
Use the following command to obtain an ID number and view the list of scheduled command(s):
CLI> show scheduled-command verb=report; noun=system-health
To reschedule an SHR command for another time, change the recurrence, or change the collection period, use the following command:
CLI> change scheduled-command id=NNN; <recurrence=daily>; <start-time=...>; <keys=period>;
<values=...>
Fast Audit and Sync Tool

The bts_audit and bts_sync process tools involve running two commands, bts_audit and bts_sync. The bts_audit and bts_sync tools are designed to improve speed and integrity of auditing and syncing the Cisco BTS 10200 databases. The tools can audit and synchronize all mismatches between network elements.

These tools are not a part of the CLI, but are UNIX programs that are run by the root user. They bypass the platform messaging paths and access the EMS, CA, FSPTC, and FSAIN databases directly using database tools. The data is manipulated and updates are applied directly to synchronize the databases.

The bts_audit tool is able to

•Find tables with mismatches

•Find rows missing in application database

•Find rows missing in EMS database

•Find rows with data mismatches between two databases

•Generate a report that lists these mismatches

•Generate the SQL to be used to correct the mismatches

The bts_sync tool is used to send the generated SQL statements to the appropriate destination to bring the databases into synchronization.

The Cisco BTS 10200 fast audit and sync tools feature consists of two UNIX shell scripts that use other UNIX scripts and utilities to perform full-database and table audits of the databases on the various network elements of the system. The database mismatches are synchronized using the bts_sync tool.

The bts_audit tool determines the table sizes when performing full database audit by analyzing the catalog of the CA, FSPTC and FSAIN databases. The scripts will create copies of the data from the tables in a standardized format. The data files are used to generate a checksum for each table. The checksums are compared, and if they are not equal, the network element data file is transferred to the EMS. On the EMS, the data is compared row by row, and mismatches are printed to a file that can be used by the bts_sync tool to restore synchronization of the table on the network element.

Restrictions and Limitations

The Cisco BTS 10200 fast audit and sync tools feature has the following restrictions and limitations:

•The bts_audit/bts_sync tools are unable to audit and synchronize certain scenarios, such as when a termination record points to an invalid mgw.

•The bts_sync tool should only be run to synchronize the data mismatches between the active platforms.

•If an audit is given a list of tables, and a table references a missing row in another table, the mismatch will not be resolved by the sync.

Using the bts_audit Tool

To use the bts_audit tool, log in at the UNIX root prompt and execute the bts_audit command.

Using the bts_sync Tool

To use the bts_sync tool, the bts_audit command must be executed first. Log in at the unix root prompt and execute the bts_audit command. Once the bts_audit command is execution is complete, execute the bts_sync command to synchronize the system databases.

Command Parameters

This section describes the parameters for the bts_audit and bts_sync commands. The following is an example of the bts_audit command parameters:

Example:
bts_audit -ems <ems> -ca <ca> [-platforms <platforms>] [-tables <tables>]
Where:

ems is the hostname of the active EMS machine.

ca is the hostname of the active CA machine.

platforms is a list of the platforms to be audited without spaces and separated by commas

tables is a list of tables to be audited without spaces and separated by commas.

Example:
bts_audit -ems priems01 -ca prica01 -platforms CA146,FSAIN205 -tables
SUBSCRIBER,MGW_PROFILE
The bts_sync command takes a list of filenames to be used for correcting errors found by the audit.

Example:
bts_sync /opt/ems/report/Audit_CA146_root.sql
or
bts_sync /opt/ems/report/Audit_*_root.sql
Command Responses

The execution of the bts_audit command will output a list of database mismatches found.

Database Out of Synchronization

To troubleshoot database out of synchronization alarms, take the following steps:

Step 1 Log in the system at the unix root prompt.

Step 2 Execute the bts_audit command.

Step 3 Once the audit is completed, execute the bts_sync command.

ISDN Network Loopback Test

This section describes the Network Loopback (NLB) Test for ISDN PRI trunks (ISDN NLB) feature. Network Loopback Test for ISDN-PRI trunks (ISDN NLB) feature allows operators to conduct network loopback testing originating from shared ISDN PRI trunks. The shared test trunk group accepts both normal and test calls. Test calls are identified by provisioning the call-type and call-subtype tokens in the Destination table.

The Cisco BTS 10200 cannot perform network loopback test calls that originate from another switch and does not route calls from a testing device on an H.323 or SIP interface.

Note The network loopback test cannot be performed if the status of the subscriber to be tested is unequipped (UEQP) or operational-out-of-service (OOS).

Configuring

The following items must be configured:

•Test origination endpoints as trunks instead of lines.

•Special dial plan and destination with call-type=test-call.

•Call-subtype must be configured as one of:

–nlb-line-test

–nct-line-test

–nlb-trunk-test

–nct-trunk-test

Originating Trunk Group

The ISDN NLB feature uses a shared test trunk group, where the type of test is specified by the test-prefix. Cisco BTS 10200 allows a test trunk group to be associated with a test dial plan. The test trunk group is an ISDN PRI trunk. Incoming calls from the network on an ISDN PRI trunk are analyzed according to a preconfigured test dial plan. The following is the format of dialed digits for these incoming test calls.

Called party number format:

<Test-prefix> <Test-data>

Where:

•<Test-prefix> is a string of digits that denote the test category. Operator must configure the definition of the test prefix and its length. We recommend a pattern of 1 to 6 digits—but the first digit cannot be "1", the Cisco BTS 10200 performs the longest match.

•<Test-data> is a string that depends on the test-prefix content. The following steps configure the originating trunk group:

Step 1 Add a trunk-group for the testing device as an ISDN PRI trunk-group if it does not already exist.
trunk-grp tg-type=isdn;
Step 2 Configure the test dial plan destination with the exact type of test call.

Step 3 Configure the call type subprofile.

Step 4 Configure a main subscriber ID for the testing trunk group if necessary.

Call Agent Configuration Table

The system defaults for the Call Agent Configuration (ca-config) table may require changing, based on the needs of the test. Take the following steps to change the service affect of the test.

Step 1 Execute the following commands to change service affect for either NCT or NLB testing. The default service affect is Y.
change ca-config nct-test-service-affecting=n;
change ca-config nlb-test-service-affecting=n;
–Y—Subscriber under test cannot make or receive calls.

–N—Subscriber under test can make or receive calls; test calls are dropped.

Step 2 Define the number of digits for the trunk group and CICs that are under test. The defaults for both are 4.
change ca-config test-trunk-grp-digits=<x>;
change ca-config test-trunk-member-digits=<x>;
Dial Plan

If the nanp-dial-plan token in the Dial Plan Profile table is set to Y, then the nature of address (NOA) in the Dial Plan table cannot be unknown. The NOA can be set to national. The first digit of the prefix cannot be 1—use any number between 2 and 9.

Sample Configurations

The following sample configurations illustrate how to configure the Cisco BTS 10200 for ISDN NLB with network terminating equipment (NTE).

Note In these samples, digit-string=nnn (where nnn = 551 and so forth), nnn is the test-prefix.

Note These tasks include examples of CLI commands that illustrate how to provision the specific feature. Most of these tables have additional tokens that are not included in the examples. For a complete list of all CLI tables and tokens, see the Cisco BTS 10200 Softswitch CLI Database.

Line Loopback Tests Over an ISDN Trunks

This section provides examples of Network Test Equipment (NTE) line loopback over ISDN trunks.

NLB Tests

This section provides examples of network loopback (NLB) line loopback tests over ISDN trunks.

NLB Line Loopback Test Over an ISDN Trunk

This section provides sample steps for the NTE NLB trunk test over an ISDN trunk feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nlb-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=551;
dest-id=nlb-trunk-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 551) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
From the test equipment, dial the NTE NLB trunk test
call (551+xxx-xxx-xxxx)
The BCM does not notify the Feature Server of this call and the call is looped back.
Step 5
Hang up the test call and verify the Billing call type.
—
NLB Line Loopback Test Over an ISDN Trunk With Service Affecting Turned On

This section provides sample steps for the NTE NLB line test over an ISDN trunk with "service affecting" turned on feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nlb-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=551;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 551) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=y;
datatype=boolean; value=y;
Provision the Call Agent Configuration table with service affecting on.
Step 5

From the test equipment, dial the NTE NLB line test call (551+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 6

Take the subscriber under test off-hook.

There is no dial tone.

Step 7

Call the subscriber under test from another subscriber.

Call is treated, and the test call is still active.

Step 8

Hang up the test call and verify the Billing call type.

—
NLB Line Loopback Test Over an ISDN Trunk With Service Affecting Turned Off and Parallel Test Connection Support Turned Off

This section provides sample steps for the NTE NLB line test over an ISDN trunk with "service affecting" turned off feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nlb-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=551;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 551) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5

From the test equipment, dial the NTE NLB-LINE test call (551+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 6

Take the subscriber under test off-hook.

There is a dial tone.

Step 7

Call the subscriber under test from another subscriber.

Call is set up, and the test call is released.

Step 8

Hang up the test call and verify the Billing call type.

—
NLB Line Loopback Test Over an ISDN Trunk With Service Affecting Turned Off and Parallel Test Connection Support Turned On: Call from Subscriber Under Test

This section provides sample steps for the NTE NLB line test over an ISDN trunk with "service affecting" turned on and parallel test connection support turned on feaure. The call is from the subscriber under test.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nlb-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=551;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 551) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5
change mgw-profile id=isdnNLB;
parallel-test-conn-supp=y;
Turn on support parallel test connection in the Media Gateway Profile table.
Step 6

From the test equipment, dial the NTE NLB line test call (551+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 7

Take the subscriber under test off-hook.

There is a dial tone.

Step 8

Call the subscriber under test from another subscriber.

Call is set up, and the test call is still active.

Step 9

Hang up the test call and verify the Billing call type.

—
NLB Line Loopback Test Over an ISDN Trunk With Service Affecting Turned Off and Parallel Test Connection Support Turned On: Call to Subscriber Under Test

This section provides sample steps for the NTE NLB line test over an ISDN trunk with "service affecting" turned off and parallel test connection support turned on feaure. The call is to the subscriber under test.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nlb-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=551;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 551) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5
change mgw-profile id=isdnNLB;
parallel-test-conn-supp=y;
Turn on support parallel test connection in the Media Gateway Profile table.
Step 6

From the test equipment, dial the NTE NLB-LINE test call (551+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 7

Take the subscriber under test off-hook.

There is a dial tone.

Step 8

Call the subscriber under test from another subscriber.

Call is set up, and the test call stays up.

Step 9

Verify the Billing call type.

—
NCT Tests

This section provides examples of line loopback network continuity tests (NCT) over ISDN.

NCT Line Loopback Test Over an ISDN Trunk

This section provides sample steps for the NTE NLB trunk test over an ISDN trunk feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nct-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=552;
dest-id=nlb-trunk-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 552) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4

From the test equipment, dial the NTE NLB trunk test call (552+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 5

Hang up the test call and verify the Billing call type.

—
NCT Line Loopback Test Over an ISDN Trunk With Service Affecting Turned On

This section provides sample steps for NTE NCT line test over an ISDN trunk with "service affecting" turned on feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nct-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=552;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 552) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=y;
datatype=boolean; value=y;
Provision the Call Agent Configuration table with service affecting on.
Step 5

From the test equipment, dial the NTE NLB line test call (552+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 6

Take the subscriber under test off-hook.

There is no dial tone.

Step 7

Call the subscriber under test from another subscriber.

Call is treated, and the test call is still active.

Step 8

Hang up the test call and verify the Billing call type.

—
NCT Line Loopback Test Over an ISDN Trunk With Service Affecting Turned Off and Parallel Test Connection Support Turned Off

This section provides sample steps for the NTE NCT line test over an ISDN trunk with "service affecting" turned off feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nct-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=552;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match to the LB test prefix (for example 552) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5

From the test equipment, dial the NTE NLB-LINE test call (552+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 6

Take the subscriber under test off-hook.

There is a dial tone.

Step 7

Call the subscriber under test from another subscriber.

Call is set up, and the test call is released.

Step 8

Hang up the test call and verify the Billing call type.

—
NCT Line Loopback Test Over an ISDN Trunk with Service Affecting Turned Off and Parallel Test Connection Support Turned On: Call from Subscriber Under Test

This section provides sample steps for the NTE NCT line test over an ISDN trunk with service "affecting turned" on and parallel test connection support turned on feature. The call is from the subscriber under test.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nct-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=552;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 552) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5
change mgw-profile id=isdnNLB;
parallel-test-conn-supp=y;
Turn on support parallel test connection in the Media Gateway Profile table.
Step 6

From the test equipment, dial the NTE NLB line test call (552+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 7

Take the subscriber under test off-hook.

There is a dial tone.

Step 8

Call the subscriber under test from another subscriber.

Call is set up, and the test call is still active.

Step 9

Hang up the test call and verify the Billing call type.

—
NCT Line Loopback Test Over an ISDN Trunk With Service Affecting Turned Off and Parallel Test Connection Support Turned On: Call to Subscriber Under Test

This section provides sample steps for the NTE NCT line test over an ISDN trunk with "service affecting" turned off and parallel test connection support turned on feature. The call is to the subscriber under test.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-line-test;
call-type=test-call; call-subtype=nct-line-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=552;
dest-id=nlb-line-test; split-npa=none;
del-digits=0; min-digits=13; max-digits=13;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match to the LB test prefix (for example 552) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add ca-config type=nlb-test-service-affecting=n;
datatype=boolean; value=n;
Provision the Call Agent Configuration table with service affecting off.
Step 5
change mgw-profile id=isdnNLB;
parallel-test-conn-supp=y;
Turn on support parallel test connection in the Media Gateway Profile table.
Step 6

From the test equipment, dial the NTE NLB-LINE test call (552+xxx-xxx-xxxx).

The BCM does not notify the Feature Server of this call and the call is looped back.

Step 7

Take the subscriber under test off-hook.

There is a dial tone.

Step 8

Call the subscriber under test from another subscriber.

Call is set up, and the test call stays up.

Step 9

Verify the Billing call type.

—
Trunk Loopback Tests Over an ISDN Trunk

For trunk loopback testing when the test call and normal call are on the same circuit, the normal call always has precedence. For example:

1. If the test call is on circuit xxx and a normal call comes in on the same circuit, then the normal call is set up and the test call is released.

2. If a normal call is on circuit xxx and a test call comes in on same circuit, then the normal call stays up and the test call is released.

NLB Trunk Loopback Test Over an ISDN Trunk

This section provides sample steps for the NTE NLB trunk test over an ISDN trunk feature.
Perform the Following Command or Action:

Purpose and Comments
Step 1
add destination dest-id=nlb-trunk-test;
call-type=test-call;
call-subtype=nlb-trunk-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=553;
dest-id=nlb-trunk-test; split-npa=none;
del-digits=0; min-digits=11; max-digits=11;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 553) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4

From the test equipment, dial the NTE NLB trunk test call (553+trunk digits+members).

—

Step 5

Hang up the test call and verify the Billing call type.

—
NCT Trunk Loopback Test Over an ISDN Trunk

This section provides sample steps for the NTE NLB trunk test over an ISDN trunk feature.
Perform the Following Command or Action:

Purpose
Step 1
add destination dest-id=nct-trunk-test;
call-type=test-call;
call-subtype=nct-trunk-test;
Provision the Destination table.
Step 2
add call-subtype-profile call-type=TEST_CALL;
call-subtype=NONE; qos-id=1;
Provision the Call Subtype Profile table.
Step 3
add dial plan id=<xxx>; digit-string=554;
dest-id=nlb-trunk-test; split-npa=none;
del-digits=0; min-digits=11; max-digits=11;
noa=national;
Note Where <xxx> is an existing dial plan. The dial plan id must match the LB test prefix (for example 554) in the digit string.
Provision the Dial Plan table. The digit-string plus the min-digits and max-digits total depends on the settings configured (if any) in the "Call Agent Configuration Table" section.
Step 4
add trunk-grp id=nte; call-agent-id=CA146;
tg-type=isdn; dial-plan-id=nte; dpc=101-55-103;
tg-profile-id=ISDN1; call-ctrl-route-id=ccr1;
Provision the Trunk Group table.
Step 5

From the test equipment, dial the NTE NLB trunk test call (554+trunk digits+members) (trunk).

—

Step 6

Hang up the test call and verify the Billing call type.

—
Enhanced Traffic Measurement

The Cisco BTS 10200 supports traditional PSTN measurements as well as additional requirements demanded by the IP and ATM backbones over which the services are offered. Many of the informational elements within the measurement data find their basis in the traditional PSTN TDM network implementations with modifications and additions caused by the expanded needs and capabilities of the converged network environment. The Cisco BTS 10200 measurement information includes both statistical and performance details. The mechanism used to manage the data generated and transported from the Cisco BTS 10200 system follows legacy type procedures and is documented in the following sections.

Measurement Data Transport and Access

The measurement data collected on the Cisco BTS 10200 can be accessed through several different mechanisms. The Command Line Interface, which runs over a telnet or SSH session, is used in the examples within this document. Measurement data is also available in CSV or XML format through the FTP or SFTP interface. The measurement data can be provisioned and is accessible through the SNMP MIB. The supported version of SNMP on the Cisco BTS 10200 is v2c. There is detailed information on both of these access mechanisms available in separate operations manuals.

Measurement Data Event Reports

The measurement subsystem within the Cisco BTS 10200 supports several events that are issued in various abnormal scenarios. Table 15-5 illustrates the event reports that the measurements subsystem supports and their significance.

Table 15-5 Event Reports Supported by Measurement Subsystem

Type and Number

Severity

Description

Meaning

Statistics (2)

Informational

Call Agent Measurement Collection Started

Issued whenever the traffic process running on the call agent platform begins a new collection cycle for the current interval

Statistics (3)

Informational

Call Agent Measurement Collection Finished

Issued whenever the traffic process running on the call agent platform completes a collection cycle for the current interval

Statistics (4)

Informational

POTS/CTX/TDM Measurement Collection Started

Issued whenever the traffic process running on the POTS Feature Server platform begins a new collection cycle for the current interval

Statistics (5)

Informational

POTS/CTX/TDM Measurement Collection Finished

Issued whenever the traffic process running on the POTS Feature Server platform completes a collection cycle for the current interval

Statistics (6)

Informational

AIN Measurement Collection Started

Issued whenever the traffic process running on the AIN Feature Server platform begins a new collection cycle for the current interval

Statistics (7)

Informational

AIN Measurement Collection Finished

Issued whenever the traffic process running on the AIN Feature Server platform completes a collection cycle for the current interval

Statistics (8)

Warning

Message Send Failure

Issued whenever the traffic manager process in the EMS or the traffic agent process in any element is unable to send an inter-process message

Statistics (9)

Warning

Measurement Table SQL Read Error

Issued whenever the traffic manager process in the EMS is unable to read from one of the measurement tables stored in Oracle

Statistics (10)

Warning

Measurement Table SQL Write Error

Issued whenever the traffic manager process in the EMS is unable to write to one of the measurement tables stored in Oracle

Statistics (11)

Warning

Measurement Collection API Failure

Issued whenever the traffic agent process in any of the Cisco BTS 10200 elements is unable to access the counter stored within shared memory by means of the standard API invocations

Statistics (12)

Major

Schemas out of Synchronization

Issued whenever system detects a mismatch between the counter schema in Oracle on the BDMS and the internal schema of the call agents and/or feature servers

Statistics (13)

Major

TMM API Failure

Issued whenever the TMM collection process is unable to initialize or attach to shared memory

Statistics (14)

Warning

MDII Trunk

Calls on the MDII trunk termination are not being successfully completed

Statistics (15)

Minor

Threshold Crossing Alert

A threshold crossing has occurred

Operating

The following sections provide detailed information on how to manage and control the measurement information generated by the Cisco BTS 10200 system. Actual examples are provided with explanations to illustrate the operational mechanics. These and other commands are documented in the Cisco BTS 10200 Softswitch CLI Database and the Cisco BTS 10200 Operations and Maintenance Guide, Release 6.0.x.

Provisioning Measurement Report Types

The Cisco BTS 10200 system provides a command line interface to manage the collection of the measurement information generated. This mechanism provides the ability to enable or disable the collection of measurement data and specify the reporting interval on a per report type basis. The factory default setting is to enable the collection of all measurement types and to set the reporting intervals to 15 minutes. Currently, there are 25 types of measurement data generated by the Cisco BTS 10200 (see the following list):

•ISDN—ISDN signaling protocol related information

•CALLP—Call Processing specific information

•MGCP—MGCP signaling protocol related information

•SIM—Service Interaction Manager related information

•POTS-SVC—POTS/Centrex/Tandem Feature Service related information

–POTS-LOCAL—Local Feature counters

–POTS-MISC—Miscellaneous Feature counters

–POTS-SLE—Screening List Editing counters

–POTS-ACAR—Auto Callback / Recall counters

–POTS-COS—Class Of Service counters

–POTS-COT—Customer Originated Trace counters

•AINSVC—AIN Feature Service related information

•ISUP—ISDN User Part (SS7) signaling protocol related information—in a Signaling Gateway configuration

•AUDIT—Auditing related information

•SIA—SIP Interface Adapter related information

•BILLING—Call Detail Data related information

•EM—Event Messaging Billing related information

•DQOS—Dynamic Quality of Service related information

•SNMP—SNMP agent protocol related information

•TG-USG—Trunk Group usage information

•ANM—Announcement server related information

•H323—H.323 signaling protocol related information

•M3UA—M3UA signaling protocol related information

•SUA—SUA signaling protocol related information

•SCTP—SCTP signaling protocol related information

•SCCP—SCCP protocol related information

•TCAP—TCAP related protocol information

•CALL-TOOLS—Metrics related to invocations of the Translation Verification Tools

•AIN-TOOLS—Metrics related to invocations of the Toll Free and LNP Query Verification Tools

•PCT-TOOLS—Metrics related to invocations of the LIDB Query Verification Tools

•ALL—All categories of measurements available on the Cisco BTS 10200

The following is an example of the command line used to provision the collection of the call processing measurement data:
change measurement-prov type=callp; enable=yes; time-interval=15;
The following is a list of the command line tokens associated with this command and the valid values and purpose of each:

•Type—An ASCII character string from 3 to 8 characters long. The string must match one of the types listed above. This is a mandatory token.

•Enable—An ASCII character string of Yes or No. This string specifies whether or not to perform collection on the specified measurement type. This is an optional token that is preprovisioned with a value of yes at the factory. Either this token and/or the time-interval token must be entered.

•Time-interval—A decimal value of 5, 15, 30, or 60. This value indicates the number of minutes each reporting interval is to encompass for the given report type. The reporting interval is always synchronized to 0 minutes after the hour for consistency. This is an optional token that is preprovisioned with a value of 15 at the factory. Changing this value does not take effect until the completion of the current collection interval based on the previous time-interval setting. Either this token and/or the enable token must be entered.

The following are examples of the command line invocations to display the current settings for the data described above:
show measurement-prov type=callp;
show measurement-prov type=anm;
show measurement-prov type=isdn;
show measurement-prov type=billing;
show measurement-prov type=em;
show measurement-prov type=snmp;
show measurement-prov type=mgcp;
show measurement-prov type=sim;
show measurement-prov type=pots-fs;
show measurement-prov type=ainsvc;
show measurement-prov type=tcap;
show measurement-prov type=m3ua;
show measurement-prov type=sua;
show measurement-prov type=sctp;
show measurement-prov type=sccp;
show measurement-prov type=isup;
show measurement-prov type=audit;
show measurement-prov type=sia;
show measurement-prov type=dqos;
show measurement-prov type=tg-usg;
show measurement-prov type=h323;
show measurement-prov type=call-tools;
show measurement-prov type=ain-tools;
show measurement-prov type=pct-tools;
Measurement Report Summaries

The Cisco BTS 10200 system provides a command line interface (CLI) command for querying summary reports of measurement data from the database on the Element Management System (EMS). This mechanism provides the ability for specifying an interval and the particular type and source of data. The time interval specified must be prior to the current collection interval.

The following are examples of the command line queries to generate reports on the various types of measurements collected from the designated call agents and feature servers from 10 am until noon on March 27th, 2007 and place the data into CSV files for FTP.

Note Any measurement counters that do not contain data for a given interval are kept out of the generated reports. Only counters that were pegged are presented in the resulting summaries.
report measurement-isdn-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=isdn-report; output-type=csv;
report measurement-callp-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id= CA146; output=callp-report; output-type=csv;
report measurement-mgcp-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id= CA146; output=mgcp-report; output-type=csv;
report measurement-sim-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id= CA146; output=sim-report; output-type=csv;
report measurement-pots-local-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-local-report; output-type=csv;
report measurement-pots-misc-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-misc-report; output-type=csv;
report measurement-pots-sle-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-sle-report; output-type=csv;
report measurement-pots-acar-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-acar-report; output-type=csv;
report measurement-pots-cos-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-cos-report; output-type=csv;
report measurement-pots-cot-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pots-cot-report; output-type=csv;
report measurement-ainsvc-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=AIN01; output=ainsvc-report; output-type=csv;
report measurement-sccp-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=AIN01; output=sccp-report; output-type=csv;
report measurement-tcap-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=AIN01; output=tcap-report; output-type=csv;
report measurement-m3ua-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; sgp-id=sg-001; output=m3ua-report; output-type=csv;
report measurement-sua-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; sgp-id=sg-001; output=sua-report; output-type=csv;
report measurement-sctp-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; sctp-assoc-id=assoc-001; output=sctp-report; output-type=csv;
report measurement-isup-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; tgn-id=dallas01; output=isup-report; output-type=csv;
report measurement-audit-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=audit-report; output-type=csv;
report measurement-sia-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=sia-report; output-type=csv;
report measurement-billing-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=billing-report; output-type=csv;
report measurement-em-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=em-report; output-type=csv;
report measurement-dqos-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; aggr-id=AGGR01; output=dqos-report; output-type=csv;
report measurement-snmp-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; output=snmp-report; output-type=csv;
report measurement-tg-usage-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; tgn-id=dallas01; call-agent-id=CA146; output=tg-report; output-type=csv;
report measurement-tg-usage-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; trkgrp-exchange=RONLVA31GT; trkgrp-name=RONKVACSDS0_LC; call-agent-id=CA146;
output=tg-report; output-type=csv; (this is a new reporting option to gather statistics on
a per Pop basis)
report measurement-anm-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=anm-report; output-type=csv;
report measurement-h323-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=h323-report; output-type=csv;
report measurement-call-tools-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; call-agent-id=CA146; output=call-tools-report; output-type=csv;
report measurement-ain-tools-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=AIN01; output=ain-tools-report; output-type=csv;
report measurement-pct-tools-summary start-time=2007-03-27 10:00:00; end-time=2007-03-27
12:00:00; feature-server-id=PCT01; output=pct-tools-report; output-type=csv;
Command Line Tokens

Table 15-6 lists the command line tokens associated with this command and the valid values and purpose of each.

Table 15-6 Command Line Tokens Associated with Measurement Report Summaries

Command Line Token

Description

start-time

A time stamp value in the format of YYYY-MM-DD HH:MM:SS. This value indicates the starting time for the search.

This is an optional token. When omitted, it results in the display of the last collected interval.

end-time

A time stamp value in the format of YYYY-MM-DD HH:MM:SS. This value indicates the stopping time for the search.

This is an optional token. When omitted, it results in the display of the last collected interval.

interval

This token is optional and is used to specify that a report be generated that contains counter information for the interval currently under collection (current) or all of the collected intervals persisted on disk (all).

If this token is used on the command line, it overrides start-time and end-time tokens that are specified. If entered, the corresponding call-agent-id or feature-server-id must be specified.

There is no default value for this token. If this token and the start-time token are not entered by the user, the last collected interval is reported.

sum

This token indicates whether the resulting report request contains the individual interval reports (N) or a summation of all interval reports into one composite report (Y).

The default value for this token is N. This token is not allowed in combination with the trunk group category.

output

This token indicates the name of the file to be created and the location where the resulting measurement data is placed. The file name is prepended with the string "Tm_" and placed in the /opt/ems/report directory on the active EMS.

output-type

The format of the output file, which can be in comma-separated value (CSV) or XML format.

display

Allows you to specify the columns of data to present in the resulting report. Only those columns specified are shown in the report. If you enter a value of "%", then a list of all possible column values are displayed, but the report itself is not created.

call-agent-id

The identity of the call agent that collected the measurement data.

This is an optional token that defaults to all call agents and is applicable only to the following measurement types:

•call-tools

•billing

•callp

•mgcp

•isdn

•audit

•sia

•sim

•anm

•h323

•tg-usage

•em

feature-server-id

The identity of the feature server that collected the measurement data.

This is an optional token that defaults to all feature servers and is applicable only to the following measurement types:

•pct-tools

•ain-tools

•ainsvc

•sccp

•tcap

•pots-local

•pots-misc

•pots-sle

•pots-acar

•pots-cos

•pots-cot

tgn-id

The trunk group numbers used to report measurement data.

This is an optional token that is applicable only to the following measurement types:

•tg-usage

•isup

When used with the trunk measurement type, it results in all trunks within the trunk group being reported.

sgp-id

The signaling gateway process for reporting measurement data.

This is an optional token that is applicable only to the following measurement types:

•m3ua

•sua

sctp-assoc-id

The sctp association ID for reporting measurement data.

This is an optional token that is applicable only to the following measurement type:

•sctp

aggr-id

The aggregation ID for reporting measurement data.

This is an optional token that is applicable only to the following measurement type:

•dqos

Reporting Current Interval Counts

The Cisco BTS 10200 system provides a CLI command for querying in-progress partial interval counts of measurement data from the actual source of the data. This mechanism provides the ability for specifying the current collection interval and the particular type and source of data. The start time specified must fall within the current collection interval.

Note This command is not supported for trunk and tg-usage measurement types.

The following are examples of the command line queries for generating reports on the various types of measurements currently being collected from call agents and feature servers on March 27th, 2007, assuming the time is presently 10:05 in the morning:
report measurement-isdn-summary call-agent-id=CA146; output=isdn-partial-report;
interval=current; output-type=csv;
report measurement-callp-summary call-agent-id=CA146; output=callp-partial-report;
interval=current; output-type=csv;
report measurement-mgcp-summary call-agent-id=CA146; output=mgcp-partial-report;
interval=current; output-type=csv;
report measurement-sim-summary call-agent-id=CA146; output=sim-partial-report;
interval=current; output-type=csv;
report measurement-pots-local-summary feature-server-id=PCT01;
output=pots-local-partial-report; interval=current; output-type=csv;
report measurement-pots-misc-summary feature-server-id=PCT01;
output=pots-misc-partial-report; interval=current; output-type=csv;
report measurement-pots-sle-summary feature-server-id=PCT01;
output=pots-sle-partial-report; interval=current; output-type=csv;
report measurement-pots-acar-summary feature-server-id=PCT01;
output=pots-acar-partial-report; interval=current; output-type=csv;
report measurement-pots-cos-summary feature-server-id=PCT01;
output=pots-cos-partial-report; interval=current; output-type=csv;
report measurement-pots-cot-summary feature-server-id=PCT01;
output=pots-cot-partial-report; interval=current; output-type=csv;
report measurement-ainsvc-summary call-agent-id=AIN01; output=ainsvc-partial-report;
interval=current; output-type=csv;
report measurement-sccp-summary call-agent-id=AIN01; output=sccp-partial-report;
interval=current; output-type=csv;
report measurement-tcap-summary call-agent-id=AIN01; output=tcap-partial-report;
interval=current; output-type=csv;
report measurement-audit-summary call-agent-id=CA146; output=audit-partial-report;
interval=current; output-type=csv;
report measurement-sia-summary call-agent-id=CA146; output=sia-partial-report;
interval=current; output-type=csv;
report measurement-billing-summary call-agent-id=CA146; output=billing-partial-report;
interval=current; output-type=csv;
report measurement-em-summary call-agent-id=CA146; output=em-partial-report;
interval=current; output-type=csv;
report measurement-snmp-summary output=snmp-partial-report; interval=current;
output-type=csv;
report measurement-anm-summary call-agent-id=CA146; output=anm-partial-report;
interval=current; output-type=csv;
report measurement-h323-summary call-agent-id=CA146; output=h323-partial-report;
interval=current; output-type=csv;
report measurement-call-tools-summary call-agent-id=CA146;
output=call-tools-partial-report; interval=current; output-type=csv;
report measurement-ain-tools-summary feature-server-id=AIN01;
output=ain-tools-partial-report; interval=current; output-type=csv;
report measurement-pct-tools-summary feature-server-id=PCT01;
output=pct-tools-partial-report; interval=current; output-type=csv;
Table 15-7 lists the command line tokens associated with this command and the valid values and purpose of each.

Table 15-7 Command Line Tokens Associated with Reporting Current Interval Counts

Command Line Token

Description

start-time

A time stamp value with the format of YYYY-MM-DD HH:MM:SS.

This value indicates the start time for the interval during which a search is made through the EMS database.

This is a mandatory token.

output

The name of the file to be created and location to place the resulting measurement data.

The file name is prepended with the string "Tm_" and placed in the /opt/ems/report directory on the active EMS.

output-type

The format of the output file—it can be in comma-separated value (CSV) format or XML format.

call-agent-id

The identity of the call agent that collected the measurement data.

This is an optional token that defaults to all call agents and is applicable only to the following measurement types:

•call-tools

•billing

•callp

•mgcp

•isdn

•audit

•sia

•sim

•anm

•h323

•em

feature-server-id

The identity of the feature server that collected the measurement data.

This is an optional token that defaults to all feature servers and is applicable only to the following measurement types:

•ain-tools

•pct-tools

•ainsvc

•sccp

•tcap

•pots-local

•pots-misc

•pots-sle

•pots-acar

•pots-cos

•pots-cot

interval

This token is optional and is used to specify that a report be generated that contains counter information for the interval currently under collection (current) or all of the collected intervals currently stored on the disk (all).

If this token is used on the command line, it overrides start-time and end-time tokens if they are specified. If entered, the corresponding call-agent-id or feature-server-id must be specified.

There is no default value for this token. If this token and the start-time token are not entered by the user, the last collected interval is reported.

Clearing Current Interval Counts

The Cisco BTS 10200 system provides a CLI command to clear in-progress partial counts of measurement data at the actual source of the data. This mechanism provides the ability for specifying the particular type and source of data.

Caution This is a destructive command that will erase the partial counts for the current interval permanently. Use this command with caution.

In the following examples, all of the currently accumulating counters in call agents and feature servers are cleared:
clear measurement-isdn-summary call-agent-id=CA146;
clear measurement-callp-summary call-agent-id=CA146;
clear measurement-mgcp-summary call-agent-id=CA146;
clear measurement-sim-summary call-agent-id=CA146;
clear measurement-pots-local-summary feature-server-id=PCT01;
clear measurement-pots-misc-summary feature-server-id=PCT01;
clear measurement-pots-sle-summary feature-server-id=PCT01;
clear measurement-pots-acar-summary feature-server-id=PCT01;
clear measurement-pots-cos-summary feature-server-id=PCT01;
clear measurement-pots-cot-summary feature-server-id=PCT01;
clear measurement-ainsvc-summary feature-server-id=AIN01;
clear measurement-sccp-summary feature-server-id=AIN01;
clear measurement-sccp-summary feature-server-id=AIN01;
clear measurement-tcap-summary feature-server-id=AIN01;
clear measurement-audit-summary call-agent-id=CA146;
clear measurement-sia-summary call-agent-id=CA146;
clear measurement-billing-summary call-agent-id=CA146;
clear measurement-em-summary call-agent-id=CA146;
clear measurement-snmp-summary
clear measurement-anm-summary call-agent-id=CA146;
clear measurement-h323-summary call-agent-id=CA146;
clear measurement-call-tools-summary call-agent-id=CA146;
clear measurement-ain-tools-summary feature-server-id=AIN01;
clear measurement-pct-tools-summary feature-server-id=PCT01;
Table 15-8 is a list of the command line tokens associated with this command and the valid values and purpose of each.

Table 15-8 Command Line Tokens Associated with Clearing Current Interval Counts

Command Line Token

Description

call-agent-id

The identity of the call agent that collected the measurement data.

This is an optional token that defaults to all call agents and is applicable only to the following measurement types:

•call-tools

•billing

•callp

•mgcp

•isdn

•audit

•sia

•sim

•anm

•H.323

•m3ua

•em

•sctp

feature-server-id

The identity of the feature server that collected the measurement data.

This is an optional token that defaults to all feature servers and is applicable only to the following measurement types:

•ain-tools

•pct-tools

•ainsvc

•sccp

•tcap

•m3ua

•sctp

•pots-local

•pots-misc

•pots-sle

•pots-acar

•pots-cos

•pots-cot

Measurements

This section provides detailed information on which counters are maintained within each measurement area. A description of the meaning of each counter is also provided. The name of each counter is an exact ASCII match to the label that is printed within the reports issued by the Cisco BTS 10200. These labels can then be used for automation purposes in testing and retrieving data from the Cisco BTS 10200 through the command line or FTP interfaces.

ISDN Protocol Counters

Table 15-9 identifies the ISDN protocol counters.

Table 15-9 ISDN Protocol Counters

Counter Label

Counter Context

ISDN_SETUP_TX

The number of ISDN setup messages sent from the reporting call agent.

ISDN_SETUP_RX

The number of ISDN setup messages received by the reporting call agent.

ISDN_SETUP_ACK_TX

The number of ISDN setup ACK messages sent from the reporting call agent. This counter is retained for use in a future release.

ISDN_SETUP_ACK_RX

The number of ISDN setup ACK messages received by the reporting call agent. This counter is retained for use in a future release.

ISDN_CALL_PROCEED_TX

The number of ISDN call proceed messages sent from the reporting call agent.

ISDN_CALL_PROCEED_RX

The number of ISDN call proceed messages received by the reporting call agent.

ISDN_ALERTING_TX

The number of ISDN alerting messages sent from the reporting call agent.

ISDN_ALERTING_RX

The number of ISDN alerting messages received by the reporting call agent.

ISDN_PROGRESS_TX

The number of ISDN progress messages sent from the reporting call agent.

ISDN_PROGRESS_RX

The number of ISDN progress messages received by the reporting call agent.

ISDN_CONNECT_TX

The number of ISDN connect messages sent from the reporting call agent.

ISDN_CONNECT_RX

The number of ISDN connect messages received by the reporting call agent.

ISDN_CONNECT_ACK_TX

The number of ISDN connect ACK messages sent from the reporting call agent.

ISDN_CONNECT_ACK_RX

The number of ISDN connect ACK messages received by the reporting call agent.

ISDN_DISCONNECT_TX

The number of ISDN disconnect messages sent from the reporting call agent.

ISDN_DISCONNECT_RX

The number of ISDN disconnect messages received by the reporting call agent.

ISDN_RELEASE_TX

The number of ISDN release messages sent from the reporting call agent.

ISDN_RELEASE_RX

The number of ISDN release messages received by the reporting call agent.

ISDN_RELEASE_COMPLETE_TX

The number of ISDN release complete messages sent from the reporting call agent.

ISDN_RELEASE_COMPLETE_RX

The number of ISDN release complete messages received by the reporting call agent.

ISDN_RESTART_TX

The number of ISDN restart messages sent from the reporting call agent.

ISDN_RESTART_RX

The number of ISDN restart messages received by the reporting call agent.

ISDN_RESTART_ACK_TX

The number of ISDN restart ACK messages sent from the reporting call agent.

ISDN_RESTART_ACK_RX

The number of ISDN restart ACK messages received by the reporting call agent.

ISDN_INFORMATION_TX

The number of ISDN information messages sent from the reporting call agent.

ISDN_INFORMATION_RX

The number of ISDN information messages received by the reporting call agent.

ISDN_NOTIFY_TX

The number of ISDN notify messages sent from the reporting call agent.

ISDN_NOTIFY_RX

The number of ISDN notify messages received by the reporting call agent.

ISDN_STATUS_TX

The number of ISDN status messages sent from the reporting call agent.

ISDN_STATUS_RX

The number of ISDN status messages received by the reporting call agent.

ISDN_STATUS_ENQUIRY_TX

The number of ISDN status enquiry messages sent from the reporting call agent.

ISDN_STATUS_ENQUIRY_RX

The number of ISDN status enquiry messages received by the reporting call agent.

ISDN_SRVC_TX

The number of ISDN service messages sent from the reporting call agent.

ISDN_SRVC_RX

The number of ISDN service messages received by the reporting call agent.

ISDN_SRVC_ACK_TX

The number of ISDN service ACK messages sent from the reporting call agent.

ISDN_SRVC_ACK_RX

The number of ISDN service ACK messages received by the reporting call agent.

ISDN_FACILITY_TX

The number of ISDN facility messages sent from the reporting call agent.

ISDN_FACILITY_RX

The number of ISDN facility messages received by the reporting call agent.

ISDN_SUSPEND_TX

The number of ISDN suspend messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SUSPEND_RX

The number of ISDN suspend messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SUSPEND_ACK_TX

The number of ISDN suspend ACK messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SUSPEND_ACK_RX

The number of ISDN suspend ACK messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SUSPEND_REJ_TX

The number of ISDN suspend reject messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SUSPEND_REJ_RX

The number of ISDN suspend reject messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_TX

The number of ISDN resume messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_RX

The number of ISDN resume messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_ACK_TX

The number of ISDN resume ACK messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_ACK_RX

The number of ISDN resume ACK messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_REJ_TX

The number of ISDN resume reject messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_RESUME_REJ_RX

The number of ISDN resume reject messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_USER_INFO_TX

The number of ISDN user information messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_USER_INFO_RX

The number of ISDN user information messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_CONG_CNTL_TX

The number of ISDN congestion control messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_CONG_CNTL_RX

The number of ISDN congestion control messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SEGMENT_TX

The number of ISDN segment messages sent from the reporting call agent.

Note This counter is applicable only to ETSI PRI.

ISDN_SEGMENT_RX

The number of ISDN segment messages received by the reporting call agent.

Note This counter is applicable only to ETSI PRI.

Call Processing Counters

Table 15-10 identifies the Call Processing counters and their meanings.

Table 15-10 Call Processing Counters

Counter Label

Counter Context

CALLP_ORIG_ATTMP

The number of originating call attempts of all types on the reporting call agent.

CALLP_TERM_ATTMP

The number of terminating call attempts of all types on the reporting call agent.

CALLP_ORIG_FAIL

The number of originating call attempts of all types that failed on the reporting call agent.

CALLP_TERM_FAIL

The number of terminating call attempts of all types that failed on the reporting call agent.

CALLP_CALL_SUCC

The number of successful originating and terminating call attempts of all types on the reporting call agent.

CALLP_CALL_ABAND

The number of originating call attempts of all types that were abandoned on the reporting call agent.

CALLP_ISDN_ORIG_ATTMP

The number of originating ISDN call attempts on the reporting call agent.

CALLP_ISDN_TERM_ATTMP

The number of ISDN terminating call attempts on the reporting call agent.

CALLP_ISDN_ORIG_FAIL

The number of ISDN originating call attempts that failed on the reporting call agent.

CALLP_ISDN_TERM_FAIL

The number of ISDN terminating call attempts that failed on the reporting call agent.

CALLP_ISDN_CALL_SUCC

The number of successful ISDN originating and terminating call attempts on the reporting call agent.

CALLP_ISDN_CALL_ABAND

The number of ISDN originating call attempts that were abandoned on the reporting call agent.

CALLP_SS7_ORIG_ATTMP

The number of originating SS7 call attempts on the reporting call agent.

CALLP_SS7_TERM_ATTMP

The number of SS7 terminating call attempts on the reporting call agent.

CALLP_SS7_ORIG_FAIL

The number of SS7 originating call attempts that failed on the reporting call agent.

CALLP_SS7_TERM_FAIL

The number of SS7 terminating call attempts that failed on the reporting call agent.

CALLP_SS7_CALL_SUCC

The number of successful SS7 originating and terminating call attempts on the reporting call agent.

CALLP_SS7_CALL_ABAND

The number of SS7 originating call attempts that were abandoned on the reporting call agent.

CALLP_SIP_ORIG_ATTMP

The number of originating SIP call attempts on the reporting call agent.

CALLP_SIP_TERM_ATTMP

The number of SIP terminating call attempts on the reporting call agent.

CALLP_SIP_ORIG_FAIL

The number of SIP originating call attempts that failed on the reporting call agent.

CALLP_SIP_TERM_FAIL

The number of SIP terminating call attempts that failed on the reporting call agent.

CALLP_SIP_CALL_SUCC

The number of successful SIP originating and terminating call attempts on the reporting call agent.

CALLP_SIP_CALL_ABAND

The number of SIP originating call attempts that were abandoned on the reporting call agent.

CALLP_MGCP_ORIG_ATTMP

The number of originating MGCP call attempts on the reporting call agent.

CALLP_MGCP_TERM_ATTMP

The number of MGCP terminating call attempts on the reporting call agent.

CALLP_MGCP_ORIG_FAIL

The number of MGCP originating call attempts that failed on the reporting call agent.

CALLP_MGCP_TERM_FAIL

The number of MGCP terminating call attempts that failed on the reporting call agent.

CALLP_MGCP_CALL_SUCC

The number of successful MGCP originating and terminating call attempts on the reporting call agent.

CALLP_MGCP_CALL_ABAND

The number of MGCP originating call attempts that were abandoned on the reporting call agent.

CALLP_CAS_ORIG_ATTMP

The number of originating CAS call attempts on the reporting call agent.

CALLP_CAS_TERM_ATTMP

The number of CAS terminating call attempts on the reporting call agent.

CALLP_CAS_ORIG_FAIL

The number of CAS originating call attempts that failed on the reporting call agent.

CALLP_CAS_TERM_FAIL

The number of CAS terminating call attempts that failed on the reporting call agent.

CALLP_CAS_CALL_SUCC

The number of successful CAS originating and terminating call attempts on the reporting call agent.

CALLP_CAS_CALL_ABAND

The number of CAS originating call attempts that were abandoned on the reporting call agent.

CALLP_ISDN_SS7_CALL

The number of successfully completed calls from an ISDN originator to an SS7 terminator on the reporting call agent.

CALLP_ISDN_ISDN_CALL

The number of successfully completed calls from an ISDN originator to an ISDN terminator on the reporting call agent.

CALLP_ISDN_SIP_CALL

The number of successfully completed calls from an ISDN originator to an SIP terminator on the reporting call agent.

CALLP_ISDN_MGCP_CALL

The number of successfully completed calls from an ISDN originator to an MGCP terminator on the reporting call agent.

CALLP_ISDN_CAS_CALL

The number of successfully completed calls from an ISDN originator to an CAS terminator on the reporting call agent.

CALLP_SS7_SS7_CALL

The number of successfully completed calls from an SS7 originator to an SS7 terminator on the reporting call agent.

CALLP_SS7_ISDN_CALL

The number of successfully completed calls from an SS7 originator to an ISDN terminator on the reporting call agent.

CALLP_SS7_SIP_CALL

The number of successfully completed calls from an SS7 originator to an SIP terminator on the reporting call agent.

CALLP_SS7_MGCP_CALL

The number of successfully completed calls from an SS7 originator to an MGCP terminator on the reporting call agent.

CALLP_SS7_CAS_CALL

The number of successfully completed calls from an SS7 originator to an CAS terminator on the reporting call agent.

CALLP_SIP_SS7_CALL

The number of successfully completed calls from a SIP originator to an SS7 terminator on the reporting call agent.

CALLP_SIP_ISDN_CALL

The number of successfully completed calls from a SIP originator to an ISDN terminator on the reporting call agent.

CALLP_SIP_SIP_CALL

The number of successfully completed calls from a SIP originator to an SIP terminator on the reporting call agent.

CALLP_SIP_MGCP_CALL

The number of successfully completed calls from a SIP originator to an MGCP terminator on the reporting call agent.

CALLP_SIP_CAS_CALL

The number of successfully completed calls from a SIP originator to an CAS terminator on the reporting call agent.

CALLP_MGCP_SS7_CALL

The number of successfully completed calls from an MGCP originator to an SS7 terminator on the reporting call agent.

CALLP_MGCP_ISDN_CALL

The number of successfully completed calls from an MGCP originator to an ISDN terminator on the reporting call agent.

CALLP_MGCP_SIP_CALL

The number of successfully completed calls from an MGCP originator to an SIP terminator on the reporting call agent.

CALLP_MGCP_MGCP_CALL

The number of successfully completed calls from an MGCP originator to an MGCP terminator on the reporting call agent.

CALLP_MGCP_CAS_CALL

The number of successfully completed calls from an MGCP originator to an CAS terminator on the reporting call agent.

CALLP_CAS_SS7_CALL

The number of successfully completed calls from a CAS originator to an SS7 terminator on the reporting call agent.

CALLP_CAS_ISDN_CALL

The number of successfully completed calls from a CAS originator to an ISDN terminator on the reporting call agent.

CALLP_CAS_SIP_CALL

The number of successfully completed calls from a CAS originator to an SIP terminator on the reporting call agent.

CALLP_CAS_MGCP_CALL

The number of successfully completed calls from a CAS originator to an MGCP terminator on the reporting call agent.

CALLP_CAS_CAS_CALL

The number of successfully completed calls from a CAS originator to a CAS terminator on the reporting call agent.

CALLP_INTERLA_ATTMP

The number of interLATA call attempts on the reporting call agent.

CALLP_INTERLA_FAIL

The number of interLATA call attempts that failed on the reporting call agent.

CALLP_INTERLA_SUCC

The number of interLATA call attempts that completed successfully on the reporting call agent.

CALLP_INTERLA_ABAND

The number of interLATA call origination attempts that were abandoned on the reporting call agent.

CALLP_INTRALA_ATTMP

The number of intraLATA call attempts on the reporting call agent.

CALLP_INTRALA_FAIL

The number of intraLATA call attempts that failed on the reporting call agent.

CALLP_INTRALA_SUCC

The number of intraLATA call attempts that completed successfully on the reporting call agent.

CALLP_INTRALA_ABAND

The number of intraLATA call origination attempts that were abandoned on the reporting call agent.

CALLP_INTL_ATTMP

The number of international call attempts on the reporting call agent.

CALLP_INTL_FAIL

The number of international call attempts that failed on the reporting call agent.

CALLP_INTL_SUCC

The number of international call attempts that completed successfully on the reporting call agent.

CALLP_INTL_ABAND

The number of international call origination attempts that were abandoned on the reporting call agent.

CALLP_EMGNCY_ATTMP

The number of emergency call attempts on the reporting call agent.

CALLP_EMGNCY_FAIL

The number of emergency call attempts that failed on the reporting call agent.

CALLP_EMGNCY_CALL_SUCC

The number of emergency call attempts that completed successfully on the reporting call agent.

CALLP_EMGNCY_CALL_ABAND

The number of emergency call origination attempts that were abandoned on the reporting call agent.

CALLP_LOCAL_ATTMP

The number of local call attempts on the reporting call agent.

CALLP_LOCAL_FAIL

The number of local call attempts that failed on the reporting call agent.

CALLP_LOCAL_SUCC

The number of local call attempts that completed successfully on the reporting call agent.

CALLP_LOCAL_ABAND

The number of local call origination attempts that were abandoned on the reporting call agent.

CALLP_TOLL_FREE_ATTMP

The number of toll free call attempts on the reporting call agent.

CALLP_TOLL_FREE_FAIL

The number of toll free call attempts that failed on the reporting call agent.

CALLP_TOLL_FREE_SUCC

The number of toll free call attempts that completed successfully on the reporting call agent.

CALLP_TOLL_FREE_ABAND

The number of toll free call origination attempts that were abandoned on the reporting call agent.

CALLP_H323_ORIG_ATTMP

The number of originating H.323 call attempts on the reporting call agent.

CALLP_H323_TERM_ATTMP

The number of terminating H.323 call attempts on the reporting call agent.

CALLP_H323_ORIG_FAIL

The number of originating H.323 call attempts that failed on the reporting call agent.

CALLP_H323_TERM_FAIL

The number of terminating H.323 call attempts that failed on the reporting call agent.

CALLP_H323_CALL_SUCC

The number of originating and terminating H.323 call attempts that completed successfully on the reporting call agent.

CALLP_H323_CALL_ABAND

The number of terminating and originating H.323 call attempts that were abandoned on the reporting call agent.

CALLP_ISDN_H323_CALL

The total number of successfully completed calls from an ISDN originator to an H.323 terminator on the reporting call agent.

CALLP_SS7_H323_CALL

The total number of successfully completed calls from an SS7 originator to an H.323 terminator on the reporting call agent.

CALLP_SIP_H323_CALL

The total number of successfully completed calls from a SIP originator to an H.323 terminator on the reporting call agent.

CALLP_MGCP_H323_CALL

The total number of successfully completed calls from an MGCP originator to an H.323 terminator on the reporting call agent.

CALLP_CAS_H323_CALL

The total number of successfully completed calls from a CAS originator to an H.323 terminator on the reporting call agent.

CALLP_H323_SIP_CALL

The total number of successfully completed calls from an H.323 originator to a SIP terminator on the reporting call agent.

CALLP_H323_ISDN_CALL

The total number of successfully completed calls from an H.323 originator to an ISDN terminator on the reporting call agent.

CALLP_H323_SS7_CALL

The total number of successfully completed calls from an H.323 originator to an SS7 terminator on the reporting call agent.

CALLP_H323_MGCP_CALL

The total number of successfully completed calls from an H.323 originator to an MGCP terminator on the reporting call agent.

CALLP_H323_CAS_CALL

The total number of successfully completed calls from an H.323 originator to a CAS terminator on the reporting call agent.

CALLP_H323_H323_CALL

The total number of successfully completed calls from an H.323 originator to an H.323 terminator on the reporting call agent.

CALLP_NAS_AUTH_SUCC

The total number of successful NAS authentication requests on the reporting call agent.

CALLP_NAS_AUTH_FAIL

The total number of failed NAS authentication requests on the reporting call agent.

CALLP_NAS_OP_FAIL

The total number of operation failures that occurred on the reporting call agent-typically indicative of a modem failure.

CALLP_NAS_ISP_PORT_LIMIT

The total number of NAS calls that failed on the reporting call agent due to the port limit of a modem being exceeded.

CALLP_NAS_NO_MODEMS

The total number of NAS calls that failed on the reporting call agent due to the unavailability of a modem.

CALLP_NAS_CLG_UNACC

The total number of NAS calls that failed on the reporting call agent due to the calling party number being blocked.

CALLP_NAS_CLD_UNACC

The total number of NAS calls that failed on the reporting call agent due to the called party number being blocked.

CALLP_NAS_USER_REQUEST

The total number of user requests (Reason Code 801) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_LOST_CARRIER

The total number of lost carrier hits (Reason Code 802) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_LOST_SERVICE

The total number of lost service hits (Reason Code 803) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_IDLE_TIMEOUT

The total number of idle timeouts (Reason Code 804) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_SESSION_TIMEOUT

The total number of session timeouts (Reason Code 805) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_ADMIN_RESET

The total number of adminstrator resets (Reason Code 806) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_ADMIN_REBOOT

The total number of adminstrator reboots (Reason Code 807) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_PORT_ERROR

The total number of port errors (Reason Code 808) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_NAS_ERROR

The total number of NAS errors (Reason Code 809) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_NAS_REQUEST

The total number of NAS requests (Reason Code 810) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_NAS_REBOOT

The total number of NAS reboots (Reason Code 811) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_PORT_UNNEEDED

The total number of port unneeded hits (Reason Code 812) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_PORT_PREEMPTED

The total number of port preempted hits (Reason Code 813) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_PORT_SUSPENDED

The total number of port suspended hits (Reason Code 814) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_SERVICE_UNAVAIL

The total number of service unavailable hits (Reason Code 815) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_CALLBACK

The total number of NAS callbacks (Reason Code 816) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_USER_ERROR

The total number of user errors (Reason Code 817) that are received in the DLCX messages on the reporting call agent.

CALLP_NAS_HOST_REQUEST

The total number of host requests (Reason Code 818) that are received in the DLCX messages on the reporting call agent.

CALLP_IVR_NETWORK_REQ

The total number of requests for network based IVR service on the reporting call agent.

CALLP_IVR_NATIVE_REQ

The total number of requests for native IVR service on the reporting call agent.

CALLP_IVR_RESOURCE_FAIL

The total number of IVR sessions that could not be established on the reporting call agent.

CALLP_TOTAL_TDISC_ORIG_ATTMP

The total number of origination attempts by subscribers that are marked as temporarily disconnected, detected by the reporting call agent.

CALLP_ NLB_TEST_SUCC

The total number of successful network loop back tests completed by the reporting call agent.

CALLP_ NLB_TEST_FAIL

The total number of failed network loop back tests completed by the reporting call agent. This counter includes both call setup failures and resource failures. These are test calls abnormally released by the call agent due to reasons such as resource priorities.

CALLP_NCT_TEST_SUCC

The total number of successful network continuity tests completed by the reporting call agent.

CALLP_ NCT_TEST_FAIL

The total number of failed network continuity tests completed by the reporting call agent. This counter includes both call setup failures and resource failures. These are test calls abnormally released by the call agent due to reasons such as resource priorities.

CALLP_LB_TEST_SUCC

The total number of successful TDM loop back tests (108) completed by the reporting call agent.

CALLP_TEST_ROUTE_SUCC

The total number of successful TDM loop back tests (108) with DN dialed out in outgoing message completed by the reporting call agent.

CALLP_T38_FAX_MEDIA_SETUP_SUCC

This counter is incremented when the T.38 media connection is established successfully between the endpoints for T.38 fax transmission.

CALLP_T38_FAX_MEDIA_SETUP_FAIL

This counter is incremented when a T.38 media connection is not established successfully between the endpoints for T.38 fax transmission.

MGCP Adapter Counters

Table 15-11 identifies the MGCP Adapter counters.

Table 15-11 MGCP Adapter Counters

Counter Label

Counter Context

MGCP_DECODE_ERROR

The number of MGCP messages received that failed decoding on the reporting call agent.

MGCP_ENCODE_ERROR

The number of MGCP messages to be sent that failed encoding on the reporting call agent.

MGCP_UNREACHABLE

The number of MGCP messages sent from the reporting call agent that failed due to the target gateway being unreachable.

MGCP_SEND_FAILED

The number of MGCP messages sent from the reporting call agent that failed while being sent to the target gateway.

MGCP_CRCX_ACK_RX

The number of MGCP CRCX acknowledgement messages received by the reporting call agent.

MGCP_CRCX_NACK_RX

The number of MGCP CRCX nonacknowledgement messages received by the reporting call agent.

MGCP_CRCX_TX

The number of MGCP CRCX messages sent by the reporting call agent.

MGCP_MDCX_ACK_RX

The number of MGCP MDCX acknowledgement messages received by the reporting call agent.

MGCP_MDCX_NACK_RX

The number of MGCP MDCX nonacknowledgement messages received by the reporting call agent.

MGCP_MDCX_TX

The number of MGCP MDCX messages sent by the reporting call agent.

MGCP_DLCX_RX

The number of MGCP DLCX messages received from gateways by the reporting call agent.

MGCP_DLCX_TX

The number of MGCP DLCX messages s.ent by the reporting call agent

MGCP_DLCX_ACK_RX

The number of MGCP DLCX acknowledgement messages received by the reporting call agent.

MGCP_DLCX_NACK_RX

The number of MGCP DLCX nonacknowledgement messages received by the reporting call agent.

MGCP_RQNT_ACK_RX

The number of MGCP RQNT acknowledgement messages received by the reporting call agent.

MGCP_RQNT_NACK_RX

The number of MGCP RQNT nonacknowledgement messages received by the reporting call agent.

MGCP_RQNT_TX

The number of MGCP RQNT messages sent by the reporting call agent.

MGCP_AUEP_ACK_RX

The number of MGCP AUEP acknowledgement messages received by the reporting call agent.

MGCP_AUEP_NACK_RX

The number of MGCP AUEP nonacknowledgement messages received by the reporting call agent.

MGCP_AUEP_TX

The number of MGCP AUEP messages sent by the reporting call agent.

MGCP_NTFY_RX

The number of MGCP NTFY messages received from gateways by the reporting call agent.

MGCP_RSIP_RX

The number of MGCP RSIP messages received from gateways by the reporting call agent.

MGCP_RSIP_ACK_TX

The number of MGCP RSIP acknowledgement messages sent by the reporting call agent.

MGCP_AUCX_TX

The number of AUCX (audit connection) messages that were sent by the reporting call agent.

MGCP_AUCX_ACK_RX

The number of AUCX ACK (audit connection acknowledgement) messages that were received by the reporting call agent.

MGCP_AUCX_NACK_RX

The number of AUCX NACK (audit connection nonacknowlegement) messages that were received by the reporting call agent.

Session Initiation Protocol Counters

Table 15-12 identifies the Session Initiation Protocol counters. These counters are common to several reporting types including SIM, AIN-SVC, POTS-MISC, and SIA.

Table 15-12 Session Initiation Protocol Counters

Counter Label

Counter Context

SIS_TOTAL_INCOM_MSG

The number of SIP messages the reporting call agent or feature server attempted to receive.

SIS_TOTAL_SUCC_INCOM_MSG

The number of SIP messages the reporting call agent or feature server successfully received.

SIS_TOTAL_OUTG_MSG_ATTMP

The number of SIP messages the reporting call agent or feature server attempted to send.

SIS_TOTAL_SUCC_OUTG_MSG

The number of SIP messages the reporting call agent or feature server successfully sent.

SIS_REQ_RETRAN_RX

The number of SIP request retransmission messages the reporting call agent or feature server received.

SIS_REQ_RETRAN_TX

The number of SIP request retransmission messages the reporting call agent or feature server sent.

SIS_RSP_RETRAN_RX

The number of SIP response retransmission messages the reporting call agent or feature server received.

SIS_RSP_RETRAN_TX

The number of SIP response retransmission messages the reporting call agent or feature server sent.

SIS_T1_TIMER_EXPIRED

The number of SIP T1 timer expirations that occurred on the reporting call agent or feature server received over the collection interval.

SIS_T2_TIMER_REACHED

The number of SIP T2 timer expirations that occurred on the reporting call agent or feature server received over the collection interval.

SIS_INVITE_RX

The number of SIP invite messages the reporting call agent or feature server received.

SIS_INVITE_TX

The number of SIP invite messages the reporting call agent or feature server sent.

SIS_CANCEL_RX

The number of SIP cancel messages the reporting call agent or feature server received.

SIS_CANCEL_TX

The number of SIP cancel messages the reporting call agent or feature server sent.

SIS_BYE_RX

The number of SIP bye messages the reporting call agent or feature server received.

SIS_BYE_TX

The number of SIP bye messages the reporting call agent or feature server sent.

SIS_ACK_RX

The number of SIP acknowledgement messages the reporting call agent or feature server received.

SIS_ACK_TX

The number of SIP ackknowledgement messages the reporting call agent or feature server sent.

SIS_OPTIONS_RX

The number of SIP options messages the reporting call agent or feature server received.

SIS_OPTIONS_TX

The number of SIP options messages the reporting call agent or feature server sent.

SIS_REGISTER_RX

The number of SIP register messages the reporting call agent or feature server received.

SIS_REGISTER_TX

The number of SIP register messages the reporting call agent or feature server sent.

SIS_INFO_RX

The number of SIP informational messages the reporting call agent or feature server received.

SIS_INFO_TX

The number of SIP informational messages the reporting call agent or feature server sent.

SIS_NOTIFY_RX

The number of SIP notify messages the reporting call agent or feature server received.

SIS_NOTIFY_TX

The number of SIP notify messages the reporting call agent or feature server sent.

SIS_100_RX

The number of 100 class (trying) messages the reporting call agent or feature server received.

SIS_100_TX

The number of 100 class (trying) messages the reporting call agent or feature server sent.

SIS_18x_RX

The number of 18x class (informational) messages the reporting call agent or feature server received.

SIS_18x_TX

The number of 18x class (informational) messages the reporting call agent or feature server sent.

SIS_200_RX

The number of 200 class (success) messages the reporting call agent or feature server received.

SIS_200_TX

The number of 200 class (success) messages the reporting call agent or feature server sent.

SIS_3xx_RX

The number of 3xx class (redirection) messages the reporting call agent or feature server received.

SIS_3xx_TX

The number of 3xx class (redirection) messages the reporting call agent or feature server sent.

SIS_4xx_RX

The number of 4xx class (request failures) messages the reporting call agent or feature server received.

SIS_4xx_TX

The number of 4xx class (request failures) messages the reporting call agent or feature server sent.

SIS_5xx_RX

The number of 5xx class (server failures) messages the reporting call agent or feature server received.

SIS_5xx_TX

The number of 5xx class (server failures) messages the reporting call agent or feature server sent.

SIS_6xx_RX

The number of 6xx class (global failures) messages the reporting call agent or feature server received.

SIS_6xx_TX

The number of 6xx class (global failures) messages the reporting call agent or feature server sent.

SIS_7xx_RX

The number of 7xx class (reserved) messages the reporting call agent or feature server received.

SIS_7xx_TX

The number of 7xx class (reserved) messages the reporting call agent or feature server sent.

SIS_PROV_RSP_RETRAN_RX

The number of SIP provisioning response retransmission messages the reporting call agent or feature server received.

SIS_PROV_RSP_RETRAN_TX

The number of SIP provisioning response retransmission messages the reporting call agent or feature server sent.

SIS_PRACK_RX

The number of SIP PRACK messages the reporting call agent or feature server received.

SIS_PRACK_TX

The number of SIP PRACK messages the reporting call agent or feature server sent.

SIS_SUBSCRIBE_RX

The number of SIP subscribe messages the reporting call agent or feature server received.

SIS_SUBSCRIBE_TX

The number of SIP subscribe messages the reporting call agent or feature server sent.

SIS_REFER_RX

The number of SIP refer messages the reporting call agent or feature server received.

SIS_REFER_TX

The number of SIP refer messages the reporting call agent or feature server sent.

SIS_REFER_W_REPLACES_RX

The number of SIP refer with replaces messages the reporting call agent or feature server received.

SIS_INVITE_REPLACES_TX

The number of SIP invite replaces messages the reporting call agent or feature server sent.

SIS_INVITE_REPLACES_RX

The number of SIP invite replaces messages the reporting call agent or feature server received.

SIS_REL100_RX

The number of REL100 class (trying) messages the reporting call agent or feature server received.

SIS_REL100_TX

The number of REL100 class (trying) messages the reporting call agent or feature server sent.

SIS_UNSUPPORTED_RX

The number of unsupported SIP messages the reporting call agent or feature server received.

SIS_UPDATE_RX

The number of SIP update messages the reporting call agent or feature server received.

SIS_UPDATE_TX

The number of SIP update messages the reporting call agent or feature server sent.

Cisco BTS 10200 Status

The Cisco BTS 10200 status (BTSSTAT) software utility provides status information for the entire Cisco BTS 10200 system. It can run on any Cisco BTS 10200 host and report the status of all the network elements in the Cisco BTS 10200 system, including those not on the same host. BTSSTAT is designed to be fast and secure.

The operator can execute the btsstat command from the UNIX shell on any host of a Cisco BTS 10200 system. The operator can be any valid UNIX user.

The output of BTSSTAT includes the network element id, side, host name, version, replication status, and redundancy status of all Cisco BTS 10200 network elements. All of the results appear in one screen. A sample of the output is shown in Table 15-13 .
Table 15-13 Sample BTSSTAT Output
prica16# btsstat
 -----------------------------------------------------------------------------
| ID-SIDE (HOST)  | CA146-A(prica16)            | CA146-B(secca16)            |
| VERSION         | 900-05.00.00.I06            | 900-05.00.00.I06            |
| RED, REPL STATE | STANDBY, Replicating        | ACTIVE, Replicating         |
|-----------------+-----------------------------+-----------------------------|
| ID-SIDE (HOST)  | FSAIN205-A(prica16)         | FSAIN205-B(s
