Configuring an External Server for Authorization and Authentication

This appendix describes how to configure an external LDAP, RADIUS, or TACACS+ server to support AAA on the security appliance. Before you configure the security appliance to use an external server, you must configure the server with the correct security appliance authorization attributes and, from a subset of these attributes, assign specific permissions to individual users.

This appendix includes the following sections:

•Understanding Policy Enforcement of Permissions and Attributes

•Configuring an External LDAP Server

•Configuring an External RADIUS Server

•Configuring an External TACACS+ Server

Understanding Policy Enforcement of Permissions and Attributes

You can configure the security appliance to apply user attributes obtained from a RADIUS or LDAP authentication server, user attributes set in group policies on the security appliance, or both. If the security appliance receives attributes from both sources, the attributes are aggregated and applied to the user policy. If there are conflicts between attributes coming from the server and from a group policy, those attributes obtained from the Dynamic Access Policy (DAP) always take precedence.

To summarize, the VPN permission policy for user authorization is the aggregate of the DAP access attributes and the group-policy inheritance hierarchy.

The security appliance applies attributes in the following order:

1. DAP attributes—Take precedence over all others.

2. User attributes—The AAA server returns these after successful user authentication or authorization.

3. Group policy attributes —These attributes come from the group policy associated with the user. You identify the user group policy name in the local database by the vpn-group-policy attribute or from a RADIUS or LDAP server by the value of the RADIUS CLASS attribute (25) in the OU=GroupName. The group policy provides any attributes that are missing from the DAP or user attributes.

4. Connection profile (tunnel group) default-group-policy attributes —These attributes come from the default group policy associated with the connection profile. This group policy provides any attributes that are missing from the DAP, user or group policy.

5. System default attributes—System default attributes provide any values that are missing from the DAP, user, group policy, or connection profile.

Configuring an External LDAP Server

This section describes the structure, schema, and attributes of an LDAP server. It includes the following topics:

•Reviewing the LDAP Directory Structure and Configuration Procedure

•Organizing the Security Appliance LDAP Schema

•Defining the Security Appliance LDAP Schema

•Loading the Schema in the LDAP Server

•Defining User Permissions

•Reviewing Examples of Active Directory Configurations

Note For more information on the LDAP protocol, see RFCs 1777, 2251, and 2849.

Reviewing the LDAP Directory Structure and Configuration Procedure

An LDAP server stores information as entries in a directory. An LDAP schema defines what types of information such entries store. The schema lists classes and the set of required and optional attributes that objects of each class can contain.

To configure your LDAP server to interoperate with the security appliance, define a security appliance authorization schema. A security appliance authorization schema defines the class and attributes of that class that the security appliance supports. Specifically, it comprises the object class (User-Authorization) and all its possible attributes that may be used to authorize a security appliance user (such as access hours, primary DNS, and so on). Each attribute comprises the attribute name, number (called an object identifier or OID), type, and possible values.

Once you have defined the security appliance authorization schema and loaded it on your server, define the security appliance attributes and permissions and their respective values for each user who will be authorize use of the server.

In summary, to set up your LDAP server:

•Design your security appliance LDAP authorization schema based on the hierarchical set-up of your organization.

•Define the security appliance authorization schema.

•Load the schema on the LDAP server.

•Define permissions for each user on the LDAP server.

The specific steps of these processes vary, depending on which type of LDAP server you are using.

Organizing the Security Appliance LDAP Schema

This section describes how to perform searches within the LDAP hierarchy and authenticated binding to the LDAP server on the security appliance. It includes the following topics:

•Searching the Hierarchy

•Binding the Security Appliance to the LDAP Server

Before you actually create your schema, think about how your organization is structured. Your LDAP schema should reflect the logical hierarchy of your organization.

For example, suppose an employee at your company, Example Corporation, is named Terry. Terry works in the Engineering group. Your LDAP hierarchy could have one or many levels. You might decide to set up a shallow, single-level hierarchy in which Terry is considered a member of Example Corporation. Or, you could set up a multi-level hierarchy in which Terry is considered to be a member of the department Engineering, which is a member of an organizational unit called People, which is itself a member of Example Corporation. See Figure E-1 for an example of this multi-level hierarchy.

A multi-level hierarchy has more granularity, but a single level hierarchy is quicker to search.

Figure E-1 A Multi-Level LDAP Hierarchy

Searching the Hierarchy

The security appliance lets you tailor the search within the LDAP hierarchy. You configure the following three fields on the security appliance to define where in the LDAP hierarchy your search begins, the extent, and the type of information it is looking for. Together these fields allow you to limit the search of the hierarchy to only the part of the tree that contains the user permissions.

•LDAP Base DN defines where in the LDAP hierarchy the server should begin searching for user information when it receives an authorization request from the security appliance.

•Search Scope defines the extent of the search in the LDAP hierarchy. The search proceeds this many levels in the hierarchy below the LDAP Base DN. You can choose to have the server search only the level immediately below, or it can search the entire subtree. A single level search is quicker, but a subtree search is more extensive.

•Naming Attribute(s) defines the RDN that uniquely identifies an entry in the LDAP server. Common naming attributes are: cn (Common Name) and ui (user identification).

Figure E-1 shows a possible LDAP hierarchy for Example Corporation. Given this hierarchy, you could define your search in different ways. Table E-1 shows two possible search configurations.

In the first example configuration, when Terry establishes the IPSec tunnel with LDAP authorization required, the security appliance sends a search request to the LDAP server indicating it should search for Terry in the Engineering group. This search is quick.

In the second example configuration, the security appliance sends a search request indicating the server should search for Terry within Example Corporation. This search takes longer.

Table E-1 Example Search Configurations

#

LDAP Base DN

Search Scope

Naming Attribute

Result

1

group= Engineering,ou=People,dc=ExampleCorporation, dc=com

One Level

cn=Terry

Quicker search

2

dc=ExampleCorporation,dc=com

Subtree

cn=Terry

Longer search

Binding the Security Appliance to the LDAP Server

Some LDAP servers (including the Microsoft Active Directory server) require the security appliance to establish a handshake via authenticated binding before they accept requests for any other LDAP operations. The security appliance identifies itself for authenticated binding by attaching a Login DN field to the user authentication request. The Login DN field defines the authentication characteristics of the security appliance; these characteristics should correspond to those of a user with administrative privileges. An example Login DN field could be: cn=Administrator, cn=users, ou=people, dc=example, dc=com.

Defining the Security Appliance LDAP Schema

This section describes how to define the LDAP schema and AV-pair attribute syntax. It includes the following topics:

•Cisco-AV-Pair Attribute Syntax

•Example Security Appliance Authorization Schema

Once you have decided how to structure your user information in the LDAP hierarchy, define this organization in a schema. To define the schema, begin by defining the object class name. The class name for the security appliance directory is User-Authorization. The class has the object identifier (OID) 1.2.840.113556.1.8000.795.1.1. Every entry or user in the directory is an object of this class.

Some LDAP servers (for example, the Microsoft Active Directory LDAP server) do not allow you to reuse the class OID once you have defined it. Use the next incremental OID. For example, if you incorrectly defined the class name as Usr-Authorization with OID 1.2.840.113556.1.8000.795.1.1, you can enter the correct class name User-Authorization with the next OID, for example, 1.2.840.113556.1.8000.795.1.2.

For the Microsoft Active Directory LDAP server, define the schema in text form in a file using the LDAP Data Interchange Format (LDIF). This file has an extension of .ldif, for example: schema.ldif. Other LDAP servers use graphical user interfaces or script files to define the object class and its attributes. For more information on LDIF, see RFC-2849.

Note The appliances enforce the LDAP attributes based on attribute name, not numeric ID. RADIUS attributes, on the other hand, are enforced by numeric ID, not by name.

Authorization refers to the process of enforcing permissions or attributes. An LDAP server defined as an authentication or authorization server will enforce permissions or attributes if they are configured.

For a complete list of attributes for the security appliance, see Table E-2.

All strings are case-sensitive and you must use an attribute name as capitalized in the table even if it conflicts with how a term is typically written.

Note For software Version 7.0, LDAP attributes include the cVPN3000 prefix. For Version 7.1 and later, this prefix was removed.

Table E-2 Security Appliance Supported LDAP Cisco Schema Attributes

Attribute Name/

OID (Object Identifier)

ASA

PIX

Attr. OID¹

Syntax/
Type

Single or Multi-
Valued

Possible Values

Access-Hours

Y

Y

1

String

Single

Name of the time-range (for example, Business-Hours)

Allow-Network-Extension- Mode

Y

Y

46

Boolean

Single

0 = Disabled

1 = Enabled

Authenticated-User-Idle- Timeout

Y

Y

36

Integer

Single

1 - 35791394 minutes

Authorization-Required

67

Integer

Single

0 = No

1 = Yes

Authorization-Type

68

Integer

Single

0 = None

1 = RADIUS

2 = LDAP

Auth-Service-Type

Cisco-AV-Pair

Y

Y

48

String

Multi

An octet string in the following format:

[Prefix] [Action] [Protocol] [Source] [Source Wildcard Mask] [Destination] [Destination Wildcard Mask] [Established] [Log] [Operator] [Port]

For more information, see "Cisco-AV-Pair Attribute Syntax."

Cisco-IP-Phone-Bypass

Y

Y

37

Integer

Single

0 = Disabled

1 = Enabled

Cisco-LEAP-Bypass

Y

Y

53

Integer

Single

0 = Disabled

1 = Enabled

Client-Intercept-DHCP- Configure-Msg

Y

Y

44

Boolean

Single

0 = Disabled

1 = Enabled

Client-Type-Version-Limiting

Y

Y

55

String

Single

IPSec VPN client version number string

Confidence-Interval

Y

Y

52

Integer

Single

10 - 300 seconds

DHCP-Network-Scope

Y

Y

54

String

Single

IP address

DN-Field

Y

Y

69

String

Single

Possible values: UID, OU, O, CN, L, SP, C, EA, T, N, GN, SN, I, GENQ, DNQ, SER, use-entire-name.

Firewall-ACL-In

Y

Y

93

String

Single

Access list ID

Firewall-ACL-Out

Y

Y

94

String

Single

Access list ID

IKE-DPD-Retry-Interval

IKE-Keep-Alives

Y

Y

29

Boolean

Single

0 = Disabled

1 = Enabled

IPSec-Allow-Passwd-Store

Y

Y

12

Boolean

Single

0 = Disabled

1 = Enabled

IPSec-Authentication

10

Integer

Single

0 = None

1 = RADIUS

2 = LDAP (authorization only)

3 = NT Domain

4 = SDI

5 = Internal

6 = RADIUS with Expiry

7 = Kerberos/Active Directory

IPSec-Auth-On-Rekey

Y

Y

30

Boolean

Single

0 = Disabled

1 = Enabled

IPSec-Backup-Server-List

Y

Y

43

String

Single

Server Addresses (space delimited)

IPSec-Backup-Servers

Y

Y

42

String

Single

1 = Use Client-Configured list

2 = Disabled and clear client list

3 = Use Backup Server list

IPSec-Banner1

Y

Y

11

String

Single

Banner string

IPSec-Banner2

Y

Y

24

String

Single

Banner string

IPSec-Client-Firewall-Filter- Name

40

String

Single

Specifies the name of the filter to be pushed to the client as firewall policy.

IPSec-Client-Firewall-Filter- Optional

Y

Y

41

Integer

Single

0 = Required

1 = Optional

IPSec-Default-Domain

Y

Y

17

String

Single

Specifies the single default domain name to send to the client (1 - 255 characters).

IPSec-IKE-Peer-ID-Check

Y

Y

28

Integer

Single

1 = Required

2 = If supported by peer certificate

3 = Do not check

IPSec-IP-Compression

Y

Y

27

Integer

Single

0 = Disabled

1 = Enabled

IPSec-Mode-Config

Y

Y

20

Boolean

Single

0 = Disabled

1 = Enabled

IPSec-Over-UDP

Y

Y

22

Boolean

Single

0 = Disabled

1 = Enabled

IPSec-Over-UDP-Port

Y

Y

23

Integer

Single

4001 - 49151; default = 10000

IPSec-Required-Client-Firewall-Capability

Y

Y

39

Integer

Single

0 = None

1 = Policy defined by remote FW Are-You-There (AYT)

2 = Policy pushed CPP

4 = Policy from server

IPSec-Sec-Association

9

String

Single

Name of the security association

IPSec-Split-DNS-Names

Y

Y

18

String

Single

Specifies the list of secondary domain names to send to the client (1 - 255 characters).

IPSec-Split-Tunneling-Policy

Y

Y

38

Integer

Single

0 = Tunnel everything

1 = Split tunneling

2 = Local LAN permitted

IPSec-Split-Tunnel-List

Y

Y

16

String

Single

Specifies the name of the network or access list that describes the split tunnel inclusion list.

IPSec-Tunnel-Type

Y

Y

19

Integer

Single

1 = LAN-to-LAN

2 = Remote access

IPSec-User-Group-Lock

21

Boolean

Single

0 = Disabled

1 = Enabled

L2TP-Encryption

15

Integer

Single

Bitmap:

1 = Encryption required

2 = 40 bit

4 = 128 bits

8 = Stateless-Req

15 = 40/128-Encr/Stateless-Req

L2TP-MPPC-Compression

26

Integer

Single

0 = Disabled

1 = Enabled

LDAP-Base-DN

LDAP-CRL-Data

LDAP-Filter

LDAP-Host-Name

LDAP-Host-Port

LDAP-Login

LDAP-Password

LDAP-Request-Type

LDAP-Scope

LDAP-Version

MS-Client-Subnet-Mask

Y

Y

45

String

Single

An IP address

PFS-Required

Y

Y

95

Boolean

Single

0 = No

1 = Yes

Port-Forwarding-Name

Y

60

String

Single

Name string (for example, "Corporate-Apps")

PPTP-Encryption

14

Integer

Single

Bitmap:

1 = Encryption required

2 = 40 bits

4 = 128 bits

8 = Stateless-Required

Example: 15 = 40/128-Encr/Stateless-Req

PPTP-MPPC-Compression

25

Integer

Single

0 = Disabled

1 = Enabled

Primary-DNS

Y

Y

3

String

Single

An IP address

Primary-WINS

Y

Y

5

String

Single

An IP address

Privilege-Level

Required-Client- Firewall-Vendor-Code

Y

Y

31

Integer

Single

1 = Cisco Systems (with Cisco Integrated Client)

2 = Zone Labs

3 = NetworkICE

4 = Sygate

5 = Cisco Systems (with Cisco Intrusion Prevention Security Agent)

Required-Client-Firewall- Description

Y

Y

33

String

Single

String

Required-Client-Firewall- Product-Code

Y

Y

32

Integer

Single

Cisco Systems Products:

1 = Cisco Intrusion Prevention Security Agent or Cisco Integrated Client (CIC)

Zone Labs Products:

1 = Zone Alarm

2 = Zone AlarmPro

3 = Zone Labs Integrity

NetworkICE Product:

1 = BlackIce Defender/Agent

Sygate Products:

1 = Personal Firewall

2 = Personal Firewall Pro

3 = Security Agent

Require-HW-Client-Auth

Y

Y

35

Boolean

Single

0 = Disabled

1 = Enabled

Require-Individual-User-Auth

Y

Y

34

Integer

Single

0 = Disabled

1 = Enabled

Secondary-DNS

Y

Y

4

String

Single

An IP address

Secondary-WINS

Y

Y

6

String

Single

An IP address

SEP-Card-Assignment

7

Integer

Single

Not used

Simultaneous-Logins

Y

Y

2

Integer

Single

0-2147483647

Strip-Realm

Y

Y

47

Boolean

Single

0 = Disabled

1 = Enabled

TACACS-Authtype

TACACS-Privilege-Level

Tunnel-Group-Lock

Y

Y

92

String

Single

Name of the tunnel group or "none"

Tunneling-Protocols

Y

Y

8

Integer

Single

1 = PPTP

2 = L2TP

4 = IPSec

8 = L2TP/IPSec

16 = Clientless SSL VPN.

8 and 4 are mutually exclusive

(0 - 11, 16 - 27 are legal values)

Use-Client-Address

13

Boolean

Single

0 = Disabled

1 = Enabled

User-Auth-Server-Name

49

String

Single

IP address or hostname

User-Auth-Server-Port

50

Integer

Single

Port number for server protocol

User-Auth-Server-Secret

51

String

Single

Server password

WebVPN-ACL-Filters

Y

72

String

Single

Access-List name

WebVPN-Apply-ACL-Enable

Y

84

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Citrix-Support-Enable

Y

83

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Content-Filter- Parameters

Y

56

Integer

Single

1 = Java & ActiveX

2 = Java scripts

4 = Images

8 = Cookies in images

Add the values to filter multiple parameters. For example: enter 10 to filter both Java scripts and cookies. (10 = 2 + 8)

WebVPN-Enable-functions

57

Integer

Single

Not used - deprecated

WebVPN-Exchange-Server- Address

58

String

Single

Not used - deprecated

WebVPN-Exchange-Server- NETBIOS-Name

59

String

Single

Not used - deprecated

WebVPN-File-Access-Enable

Y

76

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-File-Server-Browsing-Enable

Y

78

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-File-Server-Entry- Enable

Y

77

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Forwarded-Ports

Y

71

String

Single

Port-Forward list name

WebVPN-Homepage

Y

73

String

Single

A URL such as http://example-portal.com.

WebVPN-Macro-Substitution-Value1

WebVPN-Macro-Substitution-Value2

WebVPN-Port-Forwarding- Auto-Download-Enable

Y

82

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Port-Forwarding- Enable

Y

79

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Port-Forwarding- Exchange-Proxy-Enable

Y

80

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Port-Forwarding- HTTP-Proxy-Enable

Y

81

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Port-Forwarding-Enable

WebVPN-Port-Forwarding-Exchange-Proxy-Enable

WebVPN-Port-Forwarding-HTTP-Proxy-Enable

WebVPN-Port-Forwarding-Name

WebVPN-Single-Sign-On- Server-Name

Y

74

String

Single

Name of the SSO Server (1 - 31 characters).

WebVPN-SVC-Client-DPD

Y

97

Integer

Single

0 = Disabled

n = Dead Peer Detection value in seconds (30 - 3600)

WebVPN-SVC-Compression

Y

101

Integer

Single

0 = None

1 = Deflate Compression

WebVPN-SVC-Enable

Y

85

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-SVC-Gateway-DPD

Y

98

Integer

Single

0 = Disabled

n = Dead Peer Detection value in seconds (30 - 3600)

WebVPN-SVC-Keepalive

Y

96

Integer

Single

0 = Disabled

n = Keepalive value in seconds (15 - 600)

WebVPN-SVC-Keep-Enable

Y

87

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-SVC-Rekey-Method

Y

100

Integer

Single

0 = None

1 = SSL

2 = New tunnel

3 = Any (sets to SSL)

WebVPN-SVC-Rekey-Period

Y

99

Integer

Single

0 = Disabled

n = Retry period in minutes
(4 - 10080)

WebVPN-SVC-Required-Enable

Y

86

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-Unix-GID

WebVPN-Unix-UID

WebVPN-URL-Entry-Enable

Y

75

Integer

Single

0 = Disabled

1 = Enabled

WebVPN-URL-List

Y

70

String

Single

URL-list name

X509-Cert-Data

¹To get the complete Object Identifier of each attribute, append the number in the column to the end of 1.2.840.113556.8000.795.2. Thus, the OID of the first attribute in the table, Access-Hours, is 1.2.840.113556.8000.795.2.1. Likewise, the OID of the last attribute in the table, WebVPN-SVC-Compression, is 1.2.840.113556.8000.795.2.115.

Cisco-AV-Pair Attribute Syntax

The syntax of each Cisco-AV-Pair rule is as follows:
[Prefix] [Action] [Protocol] [Source] [Source Wildcard Mask] [Destination] [Destination
Wildcard Mask] [Established] [Log] [Operator] [Port]
Table E-3 describes the syntax rules.

Table E-3 AV-Pair Attribute Syntax Rules

Field

Description

Prefix

A unique identifier for the AV pair. For example: ip:inacl#1= (used for standard access lists) or webvpn:inacl# (used for clientless SSL VPN access lists). This field only appears when the filter has been sent as an AV pair.

Action

Action to perform if rule matches: deny, permit.

Protocol

Number or name of an IP protocol. Either an integer in the range 0 - 255 or one of the following keywords: icmp, igmp, ip, tcp, udp.

Source

Network or host that sends the packet. It is specified as an IP address, a hostname, or the keyword "any". If specified as an IP address, the source wildcard mask must follow.

Source Wildcard Mask

The wildcard mask applied to the source address.

Destination

Network or host that receives the packet. It is specified as an IP address, a hostname, or the keyword "any." If specified as an IP address, the source wildcard mask must follow.

Destination Wildcard Mask

The wildcard mask applied to the destination address.

Log

Generates a FILTER log message. You must use this keyword to generate events of severity level 9.

Operator

Logic operators: greater than, less than, equal to, not equal to.

Port

The number of a TCP or UDP port in the range 0 - 65535.

For example:
ip:inacl#1=deny ip 10.155.10.0 0.0.0.255 10.159.2.0 0.0.0.255 log
ip:inacl#2=permit TCP any host 10.160.0.1 eq 80 log
webvpn:inacl#1=permit url http://www.website.com
webvpn:inacl#2=deny smtp any host 10.1.3.5
webvpn:inacl#3=permit url cifs://mar_server/peopleshare1
Note Use Cisco-AV pair entries with the ip:inacl# prefix to enforce access lists for remote IPSec and SSL VPN Client (SVC) tunnels.

Use Cisco-AV pair entries with the webvpn:inacl# prefix to enforce access lists for clientless SSL (browser-mode) tunnels.

Table E-4 lists the tokens for the Cisco-AV-pair attribute:

Table E-4 Security Appliance-Supported Tokens

Token

Syntax Field

Description

ip:inacl#Num=

N/A (Identifier)

(Where Num is a unique integer.) Starts all AV pair access control lists. Enforces access lists for remote IPSec and SSL VPN (SVC) tunnels.

webvpn:inacl#Num=

N/A (Identifier)

(Where Num is a unique integer.) Starts all clientless SSL AV pair access control lists. Enforces access lists for clientless SSL (browser-mode) tunnels.

deny

Action

Denies action. (Default)

permit

Action

Allows action.

icmp

Protocol

Internet Control Message Protocol (ICMP)

1

Protocol

Internet Control Message Protocol (ICMP)

IP

Protocol

Internet Protocol (IP)

0

Protocol

Internet Protocol (IP)

TCP

Protocol

Transmission Control Protocol (TCP)

6

Protocol

Transmission Control Protocol (TCP)

UDP

Protocol

User Datagram Protocol (UDP)

17

Protocol

User Datagram Protocol (UDP)

any

Hostname

Rule applies to any host.

host

Hostname

Any alpha-numeric string that denotes a hostname.

log

Log

When the event is hit, a filter log message appears. (Same as permit and log or deny and log.)

lt

Operator

Less than value

gt

Operator

Greater than value

eq

Operator

Equal to value

neq

Operator

Not equal to value

range

Operator

Inclusive range. Should be followed by two values.

Example Security Appliance Authorization Schema

This section provides a sample of an LDAP schema. This schema supports the security appliance class and attributes. It is specific to the Microsoft Active Directory LDAP server. Use it as a model, with Table E-2, to define your own schema for your own LDAP server.

Schema 3k_schema.ldif
dn: CN=Access-Hours,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
changetype: add
adminDisplayName: Access-Hours
attributeID: 1.2.840.113556.1.8000.795.2.1
attributeSyntax: 2.5.5.3
cn: Access-Hours
instanceType: 4
isSingleValued: TRUE
lDAPDisplayName: Access-Hours
distinguishedName:
 CN=Access-Hours,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
objectCategory:
 CN=Attribute-Schema,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
objectClass: attributeSchema
oMSyntax: 27
name: Access-Hours
showInAdvancedViewOnly: TRUE
.....
.... (define subsequent security appliance authorization attributes here)
....
dn: CN=Primary-DNS,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
changetype: add
adminDisplayName: Primary-DNS
attributeID: 1.2.840.113556.1.8000.795.2.3
attributeSyntax: 2.5.5.3
cn: Primary-DNS
instanceType: 4
isSingleValued: TRUE
lDAPDisplayName: Primary-DNS
distinguishedName:
 CN=Primary-DNS,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
objectCategory:
 CN=Attribute-Schema,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
objectClass: attributeSchema
oMSyntax: 27
name: Primary-DNS
showInAdvancedViewOnly: TRUE
.....
.... (define subsequent security appliance authorization attributes here)
....
dn:
CN=Confidence-Interval,CN=Schema,CN=Configuration,OU=People,DC=ExampleCorporation,DC=com
changetype: add
adminDisplayName: Confidence-Interval
attributeID: 1.2.840.113556.1.8000.795.2.52
attributeSyntax: 2.5.5.9
cn: Confidence-Interval
instanceType: 4
isSingleValued: TRUE
