RV320 Product Family Model Comparison

RV320

RV325

RV320 WF

RV325 WF

Expand all

General
Device TypeRouter - 4-port switch (integrated)Router - 14-port switch (integrated)Router - 4-port switch (integrated)Router - 14-port switch (integrated)
Enclosure TypeDesktopDesktop, rack mountDesktopDesktop, rack mount
Connectivity TechnologyWiredWiredWiredWired
Data Link ProtocolEthernet, Fast Ethernet, Gigabit EthernetEthernet, Fast Ethernet, Gigabit EthernetEthernet, Fast Ethernet, Gigabit EthernetEthernet, Fast Ethernet, Gigabit Ethernet
Frequency BandN/AN/AN/AN/A
PerformanceVPN throughput: 75 MbpsVPN throughput: 75 MbpsVPN throughput: 75 MbpsVPN throughput: 75 Mbps
Selectable Channels quantityN/AN/AN/AN/A
CapacityIPsec VPN tunnels : 25 ¦ PPTP VPN tunnels : 10 ¦ SSL VPN tunnels : 10IPsec VPN tunnels : 25 ¦ PPTP VPN tunnels : 10 ¦ SSL VPN tunnels : 10IPsec VPN tunnels : 25 ¦ PPTP VPN tunnels : 10 ¦ SSL VPN tunnels : 10IPsec VPN tunnels : 25 ¦ PPTP VPN tunnels : 10 ¦ SSL VPN tunnels : 10
Network / Transport ProtocolPPTP, Layer 2 Transport Protocol (L2TP), IPsec, Point-to-Point Protocol over Ethernet (PPPoE), DHCPPPTP, Layer 2 Transport Protocol (L2TP), IPsec, Point-to-Point Protocol over Ethernet (PPPoE), DHCPPPTP, Layer 2 Transport Protocol (L2TP), IPsec, Point-to-Point Protocol over Ethernet (PPPoE), DHCPPPTP, Layer 2 Transport Protocol (L2TP), IPsec, Point-to-Point Protocol over Ethernet (PPPoE), DHCP
Routing ProtocolRIP-1, RIP-2, static IP routingRIP-1, RIP-2, static IP routingRIP-1, RIP-2, static IP routingRIP-1, RIP-2, static IP routing
Remote Management ProtocolSNMP 1, SNMP 2, SNMP 3, HTTP, HTTPSSNMP 1, SNMP 2, SNMP 3, HTTP, HTTPSSNMP 1, SNMP 2, SNMP 3, HTTP, HTTPSSNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS
Encryption AlgorithmTriple DES, Secure Hash Algorithm, Message Digest Algorithm (MD5), AESTriple DES, Secure Hash Algorithm, Message Digest Algorithm (MD5), AESTriple DES, Secure Hash Algorithm, Message Digest Algorithm (MD5), AESTriple DES, Secure Hash Algorithm, Message Digest Algorithm (MD5), AES
Authentication methodN/AN/AN/AN/A
FeaturesFirewall protection, NAT support, Port Address Translation (PAT) support, Network Address Port Translation (NAPT) support, SPI, DoS attack prevention, port mirroring, IPv6 support, VPN passthrough, URL filtering, domain blocking, RSTP support, QoS, DHCP server, port forwarding, port triggering, DHCP client, USB 3G/4G modem broadband supportFirewall protection, NAT support, Port Address Translation (PAT) support, Network Address Port Translation (NAPT) support, SPI, DoS attack prevention, port mirroring, IPv6 support, VPN passthrough, URL filtering, domain blocking, RSTP support, QoS, DHCP server, port forwarding, port triggering, DHCP client, USB 3G/4G modem broadband supportWeb filtering, firewall protection, NAT support, Port Address Translation (PAT) support, Network Address Port Translation (NAPT) support, SPI, DoS attack prevention, port mirroring, IPv6 support, VPN passthrough, URL filtering, domain blocking, RSTP support, QoS, DHCP server, port forwarding, port triggering, DHCP client, USB 3G/4G modem broadband supportWeb filtering, firewall protection, NAT support, Port Address Translation (PAT) support, Network Address Port Translation (NAPT) support, SPI, DoS attack prevention, port mirroring, IPv6 support, VPN passthrough, URL filtering, domain blocking, RSTP support, QoS, DHCP server, port forwarding, port triggering, DHCP client, USB 3G/4G modem broadband support
Compliance standardsIEEE 802.3, IEEE 802.3u, and IEEE 802.3abIEEE 802.3, IEEE 802.3u, and IEEE 802.3abIEEE 802.3, IEEE 802.3u, and IEEE 802.3abIEEE 802.3, IEEE 802.3u, and IEEE 802.3ab
Status IndicatorsPort status, system, DMZ, DMZ/Internet, diagnosticPort status, system, DMZ, DMZ/Internet, diagnosticPort status, system, DMZ, DMZ/Internet, diagnosticPort status, system, DMZ, DMZ/Internet, diagnostic
IP Telephony
Voice over IP (VoIP) protocolsN/AN/AN/AN/A
Line Properties
Line Coding FormatN/AN/AN/AN/A
Expansion and Connectivity
InterfacesLAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Antenna
AntennaN/AN/AN/AN/A
Antenna quantityN/AN/AN/AN/A
DirectivityN/AN/AN/AN/A
Gain LevelsN/AN/AN/AN/A
Power
Power DevicePower adapter - externalPower adapter - externalPower adapter - externalPower adapter - external
Voltage RequiredN/AN/AN/AN/A
Electric Current RequiredN/AN/AN/AN/A
Miscellaneous
Width8.1 in.9.6 in.8.1 in.9.6 in.
Depth5.2 in.6.9 in.5.2 in.6.9 in.
Height1.75 in.1.75 in.1.75 in.1.75 in.
Weight1.4 lbs2.1 lbs1.4 lbs2.1 lbs
Cables Included1 x network cable1 x network cable1 x network cable1 x network cable
Compliance standardsFCC Class B certified, C-Tick, cULFCC Class B certified, C-Tick, cULFCC Class B certified, C-Tick, cULFCC Class B certified, C-Tick, cUL
LocalizationNorth AmericaNorth AmericaNorth AmericaNorth America
Rack Mounting KitN/AN/AN/AN/A
Software and System Requirements
OS ProvidedN/AN/AN/AN/A
Software Included
Manufacturer warranty
Service and SupportLimited lifetime warrantyLimited lifetime warrantyLimited lifetime warrantyLimited lifetime warranty
Service and support detailsLimited lifetime warrantyLimited lifetime warrantyLimited lifetime warrantyLimited lifetime warranty
Environmental Parameters
Minimum operating temperature32°F32°F32°F32°F
Max Operating Temperature104°F104°F104°F104°F
Humidity Range Operating10 - 85% (non-condensing)10 - 85% (non-condensing)10 - 85% (non-condensing)10 - 85% (non-condensing)
