Cisco® Video Surveillance Encoders are standalone devices that can be used to convert analog video sources into digital formats so they can be integrated into a networked, IP-based video surveillance system. The 8-port model (CIVS-SENC-8P) supports eight analog video inputs and can be stacked, wall mounted, or rack-mounted. A power supply is included.
Figure 1. Cisco Video Surveillance 8-Port Encoder
The 8-port encoder supports a single video stream per port. The stream can be compressed in H.264, MPEG-4, or MJPEG formats and can be configured with different resolutions, frame rates, and bit rates.
The encoder provides an RS-485 interface to allow for connection to PTZ control units supporting the Pelco-D protocol, in order to control PTZ functions in an external camera or PTZ mount.
Digital Inputs/ Outputs
The encoder has eight digital outputs and eight digital inputs to connect to and from external sensors.
The encoders support Internet Explorer® 8.0 for remote setup and administration.
The encoder connects to Cisco Video Surveillance Manager Version 6.3.2 and later.
Features and Benefits
Features include the following:
• Up to D1 resolution per port
• Up to 30 frames per second (FPS) at D1 resolution (180 FPS maximum across all ports/channels)
• H.264, MPEG-4, and MJPEG compression options
• Up to five privacy mask windows per port
• Up to three motion detection windows per port
Table 1 lists product specifications for the Cisco Video Surveillance 8-Port Encoder.
Table 1. Product Specifications
Analog Video Input Ports
Digital Alarm Inputs
8 (maximum voltage 12V; maximum sync 100mA)
Digital Alarm Outputs
Password-protected administrative interface;
HTTPS access to the administrative interface
CE, FCC Class B, C-Tick
RJ-45 connector for 100/1000 BASE-TX
The Cisco Video Surveillance 8-Port Encoder is available through Cisco Advanced Technology Provider (ATP) program partners. Table 4 lists ordering information.
Table 4. Ordering Information
Cisco Video Surveillance 8-Port Encoder (standalone)
Cisco offers a wide range of services programs to accelerate customer success. These innovative programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you to protect your network investment, optimize network operations and prepare your network for new applications to extend network intelligence and the power of your business. For more information about Cisco Services, see Cisco Technical Support Services or Cisco Advanced Services.
For More Information
For more information about the Cisco Video Surveillance Encoder products, visit http://www.cisco.com or contact your local account representative.
