Cisco® Video Surveillance Encoders are standalone devices that can be used to convert analog video sources into digital formats so they can be integrated into a networked, IP-based video surveillance system. The 4-port model (CIVS-SENC-4P) supports four analog video inputs and can be stacked, wall mounted, or rack-mounted. A power supply is included.
Figure 1. Cisco Video Surveillance 4-Port Encoder
The 4-port encoder supports two simultaneous video streams. The streams can be compressed in H.264, MPEG-4, or MJPEG formats and in various resolution, frame-rate, and bit-rate combinations.
The encoder provides an RS-485 interface to allow for connection to PTZ control units supporting the Pelco-D protocol, in order to control PTZ functions in an external camera or PTZ mount.
Digital Inputs/ Outputs
The encoder has four digital outputs and four digital inputs to connect to and from external sensors.
The encoders supports Internet Explorer® 8.0 for remote setup and administration.
The encoder connects to Cisco Video Surveillance Manager Version 6.3.2 and later.
Features and Benefits
Features include the following:
• Up to D1 resolution per port
• Up to 30 frames per second (FPS) at D1 resolution (180 FPS maximum across all ports/channels)
• H.264, MPEG-4, and MJPEG compression options
• Up to two simultaneous video streams per port
• Up to five privacy mask windows per port
• Up to three motion detection windows per port
Table 1 lists product specifications for the Cisco Video Surveillance 4-Port Encoder.
Table 1. Product Specifications
Analog Video Input Ports
Digital Alarm Inputs
Digital Alarm Outputs
4 (maximum voltage 12V; maximum sync 100mA)
Password-protected administrative interface;
HTTPS access to the administrative interface
CE, FCC Class B, C-Tick UL/cUL listed
RJ-45 connector for 100/1000 BASE-TX
Cat5 or better
12 VDC/24 VAC (power supply included)
50° to 122°F (10° to 50°C)
20% to 80%, noncondensing
189 x 153 x 49.3 mm
Video and Audio
H.264, MPEG-4, and MJPEG (for both PAL and NTSC)
Up to two simultaneous streams; the second stream is variable based on the setup of the primary stream
The Cisco Video Surveillance 4-Port Encoder is available through Cisco Advanced Technology Provider (ATP) program partners. Table 4 lists ordering information.
Table 4. Ordering Information
Cisco Video Surveillance 4-Port Encoder (standalone)
Cisco offers a wide range of services programs to accelerate customer success. These innovative programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you to protect your network investment, optimize network operations, and prepare your network for new applications to extend network intelligence and the power of your business. For more information about Cisco Services, see Cisco Technical Support Services or Cisco Advanced Services.
For More Information
For more information about the Cisco Video Surveillance Encoder products, visit http://www.cisco.com or contact your local account representative.
