Release Notes for Catalyst 6500 Series Software Release 8.x

Current Releases
8.7(3)—September 11, 2009
Previous Releases: 8.7(2), 8.7(1), 8.6(6), 8.6 (5), 8.6(4), 8.6 (3), 8.6(2), 8.6(1), 8.5(9), 8.5(8), 8.5(7), 8.5(6), 8.5(5), 8.5(4), 8.5(3), 8.5(2), 8.5(1), 8.4(6), 8.4(5), 8.4(4), 8.4(3), 8.4(2a), 8.4(2), 8.4(1), 8.3(7), 8.3(6), 8.3(5), 8.3(4), 8.3(3), 8.3(2), 8.3(1), 8.2(2), 8.2(1), 8.1(3), 8.1(2), 8.1(1)

Caution Due to a compatibility issue between Supervisor Engine 32 hardware version 1.2 and Catalyst software releases prior to release 8.4(4) and MSFC2A Cisco IOS Releases prior to Release 12.2(17d)SXB9, you need to verify your Supervisor Engine 32 hardware version, and if necessary, take the appropriate action as described in the following paragraphs.

For Supervisor Engine 32 (WS-SUP32-GE-3B and WS-SUP32-10GE-3B), if the hardware version is 1.2, you must run software release 8.4(4) and later releases on the supervisor engine and Cisco IOS Release 12.2(17d)SXB9 and later releases on the MSFC2A. To determine the hardware version, enter the show module command and note the hardware (Hw) version for the supervisor engine.

When Supervisor Engine 32 with hardware version 1.2 is running software release 8.4(4) or later, if the MSFC2A image is not Cisco IOS Release 12.2(17d)SXB9 or later, the MSFC2A is placed in the "other" state and the following message is displayed on the supervisor engine:

%SYS-1-MOD_MSFC_FAILONLINE:MSFC Module 16 FAILED to come ONLINE
2005 Apr 21 01:31:46 %SYS-1-MOD_MSFC_INCOMPATIBLEIMAGE:MSFC Module 16
Image Upgrade Required to support Inband Port ASIC present in System

To correct this problem, you must upgrade the MSFC2A to Cisco IOS Release 12.2(17d)SXB9 and later releases.

Note that in redundant systems, if one Supervisor Engine 32 is hardware version 1.2, the other Supervisor Engine 32 must also be hardware version 1.2 and both supervisor engines must be running software release 8.4(4) or later on the supervisor engine and Cisco IOS release 12.2(17d)SXB9 or later on the MSFC2A.

Caution With software release 8.3(1), we recommend that you run Cisco IOS Release 12.2(17d)SXB1 on the Supervisor Engine 720/MSFC3. It is mandatory that you run Cisco IOS Release 12.2(17d)SXB1 if you plan on using any of the following software release 8.3(1) features: Bidirectional PIM, Policy Feature Card 3BXL, IGMP version 3 snooping with Multicast Multilayer Switching (MMLS), or Gateway Load Balancing Protocol (GLBP).

For Cisco IOS Release requirements for all supervisor engines and modules, see the "Release Notes for Cisco IOS on the MSFC" section at this URL: http://www.cisco.com/en/US/products/hw/switches/ps708/prod_release_notes_list.html

Caution Support for Optical Services Modules (OSMs) and the FlexWAN module in systems with Supervisor Engine 2 running software release 8.1(1) and later releases requires Cisco IOS Release 12.1(19)E and later releases. OSMs are only supported with Supervisor Engine 2; they are not supported with any other supervisor engine. Support for the FlexWAN module in systems with Supervisor Engine 1 and Supervisor Engine 2 running software release 8.1(1) and later releases requires Cisco IOS Release 12.1(19)E and later releases. Support for the FlexWAN module in systems with Supervisor Engine 720 running software release 8.2(1) and later releases requires Cisco IOS Release 12.2(14)SX2 and later releases.

Also note that with software release 8.1(1) and later releases you need to use the Cisco IOS Release 12.1(13)E4 or later version bootloader on the MSFC/MSFC2 to boot a Cisco IOS image reliably from sup-slot0 or sup-bootflash. The Cisco IOS Release 12.1(19)E train bootloader, or bootloaders earlier than Cisco IOS Release 12.1(13)E4, do not support booting the MSFC/MSFC2 from sup-slot0 or sup-bootflash due to caveats CSCeb36759, CSCdz60980, and/or CSCdz31321.

For a complete list of OSMs supported with Catalyst software, see the "Optical Services Modules" section.

Caution The MSFC3 on Supervisor Engine 720 requires Cisco IOS Release 12.2(14)SX2 and later releases.

Caution The 12.2(14r)S9 MSFC3 ROMMON software upgrade is required if you plan to run Catalyst software release 8.1(x) on Supervisor Engine 720 and Cisco IOS software on the MSFC3. For information on the 12.2(14r)S9 MSFC3 ROMMON software upgrade procedure, refer to this URL:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/rommon/OL_4497.html

Caution If stateful switchover (SSO) is enabled on the MSFC, you must enable high availability on the supervisor engine before upgrading to supervisor engine software release 8.5(1) and later releases. Use the set system highavailability enable command to enable high availability on the supervisor engine. For detailed information on configuring SSO on the MSFC, refer to the "Configuring NSF with SSO MSFC Redundancy" chapter of the Catalyst 6500 Series Software Configuration Guide at this URL:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/catos/8.x/configuration/guide/nde.html

Caution The Supervisor Engines 1 and 1A are not supported in Catalyst software release 8.5(4) or later releases. For more information, refer to Product Bulletin No. 2595 at this URL:

http://www.cisco.com/en/US/prod/collateral/switches/ps5718/ps708/prod_end-of-life_notice0900aecd8017a5d1.html

Caution The Supervisor Engine 2 is not supported in Catalyst software release 8.6(5) or later releases. For more information, refer to Product Bulletin No. 1031 at this URL:

http://www.cisco.com/en/US/prod/collateral/switches/ps5718/ps708/prod_end-of-life_notice0900aecd80423d31.html

Note Cisco IOS Release 12.2(18)SXF includes features that require Catalyst software release 8.5(1). For details, refer to the Release Notes for Cisco IOS Release 12.2 SX on the Catalyst 6500 Series MSFC at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/ios/12.2SXF/hybrid/release/notes/ol_4563.html

Contents

This document consists of these sections:

•Release 8.x DRAM Memory Requirements

•Boot ROM (ROMMON) Requirements

•Upgrading the Boot ROM

•Supervisor Engine Bootflash

•Redundant Supervisor Engine Configurations

•Product and Software Release Matrix

•Unsupported Hardware

•Orderable Software Images

•Software Image Version Compatibility

•Catalyst 6500 Series Features

•Usage Guidelines and Restrictions

•Open and Resolved Caveats in Software Release 8.7(3)

•Open and Resolved Caveats in Software Release 8.7(2)

•Open and Resolved Caveats in Software Release 8.7(1)

•Open and Resolved Caveats in Software Release 8.6(6)

•Open and Resolved Caveats in Software Release 8.6(5)

•Open and Resolved Caveats in Software Release 8.6(4)

•Open and Resolved Caveats in Software Release 8.6(3)

•Open and Resolved Caveats in Software Release 8.6(2)

•Open and Resolved Caveats in Software Release 8.6(1)

•Open and Resolved Caveats in Software Release 8.5(9)

•Open and Resolved Caveats in Software Release 8.5(8)

•Open and Resolved Caveats in Software Release 8.5(7)

•Open and Resolved Caveats in Software Release 8.5(6)

•Open and Resolved Caveats in Software Release 8.5(5)

•Open and Resolved Caveats in Software Release 8.5(4)

•Open and Resolved Caveats in Software Release 8.5(3)

•Open and Resolved Caveats in Software Release 8.5(2)

•Open and Resolved Caveats in Software Release 8.5(1)

•Open and Resolved Caveats in Software Release 8.4(6)

•Open and Resolved Caveats in Software Release 8.4(5)

•Open and Resolved Caveats in Software Release 8.4(4)

•Open and Resolved Caveats in Software Release 8.4(3)

•Open and Resolved Caveats in Software Release 8.4(2a)

•Open and Resolved Caveats in Software Release 8.4(2)

•Open and Resolved Caveats in Software Release 8.4(1)

•Open and Resolved Caveats in Software Release 8.3(7)

•Open and Resolved Caveats in Software Release 8.3(6)

•Open and Resolved Caveats in Software Release 8.3(5)

•Open and Resolved Caveats in Software Release 8.3(4)

•Open and Resolved Caveats in Software Release 8.3(3)

•Open and Resolved Caveats in Software Release 8.3(2)

•Open and Resolved Caveats in Software Release 8.3(1)

•Open and Resolved Caveats in Software Release 8.2(2)

•Open and Resolved Caveats in Software Release 8.2(1)

•Open and Resolved Caveats in Software Release 8.1(3)

•Open and Resolved Caveats in Software Release 8.1(2)

•Open and Resolved Caveats in Software Release 8.1(1)

•Catalyst Software Image Upgrade Procedure

•Troubleshooting

•Related Documentation

Release 8.x DRAM Memory Requirements

Supervisor Engine 32: The Catalyst 6500 series Supervisor Engine 32 ships with 256-MB DRAM, which fully supports software release 8.4(1) and later releases.

Supervisor Engine 720: The Catalyst 6500 series Supervisor Engine 720 ships with 512-MB DRAM, which fully supports software release 8.x.

Supervisor Engine 2: The Catalyst 6500 series Supervisor Engine 2 ships with 256-MB DRAM (WS-X6K-S2U-MSFC2) and the default 128-MB DRAM (WS-X6K-S2-MSFC2), both of which fully support software release 8.x.

Caution When running software release 8.x with a large number of routes configured, the Supervisor Engine 2 requires 256-MB DRAM. The exact number of routes supported by the Supervisor Engine 2 with 128-MB DRAM depends on the features you have configured.

Supervisor Engine 1: Early versions of the Catalyst 6500 series Supervisor Engine 1 shipped with 64-MB DRAM which does not support software release 8.x (currently, new Supervisor Engine 1 modules ship with 128-MB DRAM). To support software release 8.x, you need 128-MB DRAM.

With the exception of WS-X6K-SUP1A-MSFC, all other Supervisor Engine 1 modules can upgrade to 128-MB DRAM using the MEM-S1-128MB= upgrade kit. For detailed information on the MEM-S1-128MB= upgrade, refer to the Catalyst 6500 Series Switch Supervisor Engine 1A DRAM Upgrade Installation Note at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_14357.html

To upgrade to 128-MB DRAM on the WS-X6K-SUP1A-MSFC, use the MEM-S1-128MB-UPG= upgrade kit which also includes an MSFC2 upgrade.

Boot ROM (ROMMON) Requirements

For Supervisor Engine 1, the minimum boot ROM (ROMMON) required for software release 5.4(1) and later 5.x(x) releases is 5.2(1). The minimum boot ROM required for software releases 6.x(x), 7.x(x), and 8.x(x) is also 5.2(1). The default (shipping) image for software releases 6.x(x), 7.x(x), and 8.x(x) is 5.3(1).

For Supervisor Engine 2, the minimum boot ROM required for software release 6.2(2) and later releases is 6.1(3).

For Supervisor Engine 720, the minimum boot ROM required for software release 8.1(1) and later releases is 7.7(1).

Note The supervisor engine boot ROM versions must be identical in redundant systems.

Upgrading the Boot ROM

Follow these guidelines to upgrade the supervisor engine boot ROM (ROMMON) on Supervisor Engine 1 or 1A:

•For supervisor engines with an MSFC, due to the location of the boot ROM, upgrading the boot ROM could damage your supervisor engine. This hardware configuration is not field upgradable.

•For supervisor engines with an MSFC2 or no PFC, the boot ROM upgrade can be done in the field:

–The boot ROM upgrade kit part number is WS-X6K-BOOT=

Note The boot ROM upgrade kit is not orderable. If an upgrade is needed, contact the Technical Assistance Center (TAC) to verify your hardware configuration and arrange for delivery of the upgrade kit.

–For boot ROM installation information, refer to the Catalyst 6500 Series Switch Supervisor Engine NMP Boot ROM Upgrade Installation Note at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_10142.html

Note For Supervisor Engine 2 with boot ROM version 6.1(3) or later, the boot ROM software image can be upgraded through a software download from Cisco.com. Refer to the boot ROM software upgrade procedure at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_13488.html

FLASH PC CARD SUPPORT:

The following Flash PC cards are supported on Catalyst 6500 series switches:

•MEM-C6K-FLC16M(=)

Supported only on Supervisor Engine 1 and Supervisor Engine 2.

•MEM-C6K-FLC24M(=)

Supported only on Supervisor Engine 1 and Supervisor Engine 2.

•MEM-C6K-FLC64M(=)

Supported only on Supervisor Engine 1.

•MEM-C6K-ATA-1-64M(=)

Supported only on Supervisor Engine 2.

Prior to software release 7.5(1), Supervisor Engine 1 and Supervisor Engine 2 supported the following Flash PC cards:

•16-MB Flash PC card (MEM-C6K-FLC16M=). The device name is slot0:.

•24-MB Flash PC card (MEM-C6K-FLC24M=). The device name is slot0:.

With software releases 7.5(1) and later, additional Flash PC card support was added as follows:

•64-MB ATA Flash PC card (MEM-C6K-ATA-1-64M=)—Only supported on Supervisor Engine 2. The device name is disk0: and the card requires ROMMON version 7.1(1) and later releases.

•64-MB linear Flash PC card (MEM-C6K-FLC64M=)—Only supported on Supervisor Engine 1. The device name is slot0: and the card requires ROMMON software release 5.3(1) and later releases.

Note The MEM-C6K-ATA-1-64M(=) and MEM-C6K-FLC64M= Flash PC cards are not formatted. Although the cards appear to be formatted when first installed, you must format the cards to prevent possible data corruption.

Note The 16-MB MEM-C6K-FLC16M(=) and 24-MB MEM-C6K-FLC24M(=) linear Flash PC cards are not formatted. Supervisor Engine 1 and Supervisor Engine 2 do not support the same Flash PC card format. To use a Flash PC card with Supervisor Engine 2, you must format the card with Supervisor Engine 2. To use a Flash PC card with Supervisor Engine 1, you must format the card with Supervisor Engine 1.

The following Compact Flash cards are supported only on Supervisor Engine 720 with software release 8.1(1) and later releases and Supervisor Engine 32 with software release 8.4(1) and later releases:

•MEM-C6K-CPTFL64M=

•MEM-C6K-CPTFL128M=

•MEM-C6K-CPTFL256M=

•MEM-C6K-CPTFL512M=

MEM-C6K-CPTFL512M= is supported with Supervisor Engine 720 and Supervisor Engine 32 starting with software release 8.4(1).

Note For Supervisor Engine 720, a Compact Flash card can be installed only in the DISK 0 slot with software releases prior to release 8.4(1). With software releases 8.4(1) and later releases, you can use the DISK 1 slot.

Note For Supervisor Engine 1, software release 7.6(1) or later CV images need a 24-MB or 64-MB linear Flash PC card.

With the 24-MB linear Flash PC card with a Supervisor Engine 1/MSFC or a Supervisor Engine 1/MSFC2 with a 16-MB MSFC2 bootflash, you need to put the Catalyst image on the 24-MB linear Flash PC card, the IOS bootloader on the MSFC bootflash, and the Cisco IOS image on the 16-MB supervisor engine bootflash.

With the 64-MB linear Flash PC card with a Supervisor Engine 1/MSFC or a Supervisor Engine 1/MSFC2 with a 16-MB MSFC2 bootflash, you can put the Catalyst image and the MSFC/MSFC2 Cisco IOS image on the 64-MB linear Flash PC card, and the Cisco IOS bootloader on the MSFC bootflash.

With the 24-MB or 64-MB linear Flash PC card on a Supervisor Engine 1/MSFC2 with 32-MB MSFC2 bootflash, the MSFC2 bootloader and Cisco IOS image can be put on the MSFC2 bootflash, and the Catalyst image can be put on the 24-MB or 64-MB linear Flash PC cards.

Supervisor Engine Bootflash

Supervisor Engine 32: The Catalyst 6500 series Supervisor Engine 32 ships with a 256-MB bootflash device.

Supervisor Engine 720: The Catalyst 6500 series Supervisor Engine 720 ships with a 64-MB bootflash device.

Supervisor Engine 2: The Catalyst 6500 series Supervisor Engine 2 ships with a 32-MB bootflash device.

Note The default bootflash configuration on Supervisor Engine 2 shipped since late January 2001, is 32 MB. Enter the show version command to determine what size bootflash device is installed on the Supervisor Engine 2. If you have 16 MB, there is an upgrade to 32 MB available at this URL:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_12667.html

Supervisor Engine 1: The Catalyst 6500 series Supervisor Engine 1 (and 1A) ship with a 16-MB bootflash device. The Supervisor Engine 1 (and 1A) bootflash is not upgradeable.

Redundant Supervisor Engine Configurations

In systems with redundant supervisor engines, both supervisor engines must be identical and have the same daughter card configurations. For example, your switch can have the following configurations:

•Slot 1—Supervisor Engine 2, PFC2, MSFC2
Slot 2—Supervisor Engine 2, PFC2, MSFC2

•Slot 1—Supervisor Engine 2, PFC2
Slot 2—Supervisor Engine 2, PFC2

•Slot 1—Supervisor Engine 1, PFC, MSFC2
Slot 2—Supervisor Engine 1, PFC, MSFC2

•Slot 1—Supervisor Engine 1, PFC, MSFC1
Slot 2—Supervisor Engine 1, PFC, MSFC1

•Slot 1—Supervisor Engine 1, PFC
Slot 2—Supervisor Engine 1, PFC

•Slot 1—Supervisor Engine 1
Slot 2—Supervisor Engine 1

The slot locations for Supervisor Engine 720 (with PFC3 and MSFC3) and Supervisor Engine 32 (with PFC3B and MSFC2A) are chassis dependent:

•With a 3-slot chassis, install the active supervisor engine in slot 1 and the redundant supervisor engine in slot 2.

•With a 6-slot or a 9-slot chassis, install the active supervisor engine in slot 5 and the redundant supervisor engine in slot 6.

•With a 13-slot chassis, install the active supervisor engine in slot 7 and the redundant supervisor engine in slot 8.

These configuration requirements apply to all Catalyst 6500 series switches. We do not support configurations that are not identical.

Product and Software Release Matrix

These sections list the minimum supervisor engine version and the current recommended supervisor engine software release for Catalyst 6500 series modules, power supplies, fan trays, and chassis:

•Supervisor Engines

•Policy Feature Cards

•Switch Fabric Modules

•Small Form-Factor Pluggable Modules (SFPs)

•10-Gigabit Ethernet Switching Modules

•XENPAKs

•Gigabit Ethernet Switching Modules

•Gigabit Interface Converters (GBICs)

•Fast Ethernet Switching Modules

•Ethernet/Fast Ethernet (10/100) Switching Modules

•Ethernet Switching Modules

•Power Over Ethernet Daughter Cards

•Voice Modules

•FlexWAN Module

•Optical Services Modules

•Service Modules

•ATM Modules

•Multilayer Switch Module

•Power Supplies

•Fan Trays

•Modular Chassis

Note There might be additional minimum software release requirements for intelligent modules (those that run an additional, separate software image). Refer to the software release notes for the module type for more information.

Note Line modules and Service modules with different Hardware and Firmware can reside on the same chassis. To recognise the modules, you must know the minimum Supervisor Engine software release.

Supervisor Engines

Note Supervisor Engine 32 (WS-SUP32-GE-3B and WS-SUP32-10GE-3B) common features:

•Supports 32-Gbps non-fabric-enabled switching bus (the WS-C6500-SFM and WS-C6500-SFM2 modules are not supported)

•256-MB bootflash through an internal Compact Flash device (referred to as "bootdisk" in the CLI)

•Compact Flash slot (disk 0)

•One 10/100/1000 Mbps RJ-45 port (port 9)

•Two USB ports

–Host port (Type B port) interfaces with a standard host such as a PC

–Device port (Type A port) interfaces with devices such as USB disks or USB keys

Note The USB ports are not enabled. These ports will be enabled in a future software release.

•QoS port architecture (Rx/Tx): 2q8t/1p3q8t

•Eight Gigabit Ethernet SFP ports (ports 1 through 8) on WS-SUP32-GE-3B

Note For a list of supported SFPs, see the "Small Form-Factor Pluggable Modules (SFPs)" section.

•Two 10-Gigabit Ethernet uplink ports on WS-SUP32-10GE-3B (require XENPAKs)

•For Supervisor Engine 32 fan tray requirements, see the "Fan Trays" section

Note Supervisor Engine 720 common features:

•Integrated 720-Gbps Switch Fabric

•64-MB bootflash device

•2 Compact Flash slots (disk0 and disk1)

•Two Ethernet uplink ports:

–1-MB packet buffer per port

–Port 1—Gigabit Ethernet SFP

–Port 2—Configurable as Gigabit Ethernet SFP or 10/100/1000 Mbps RJ-45

Note For a list of supported SFPs, see the "Small Form-Factor Pluggable Modules (SFPs)" section.

•QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

•For Supervisor Engine 720 fan tray requirements, see the "Fan Trays" section

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

Supervisor Engine 32¹, ²

WS-SUP32-GE-3B

Supervisor Engine 32 with PFC3B:

•256-MB DRAM

•Policy Feature Card 3B; see the "Policy Feature Cards" section

•Multilayer Switch Feature Card 2A (MSFC2A)

–256-MB DRAM

–32-MB bootflash

8.4(1)

8.4(2)

WS-SUP32-10GE-3B

8.4(4)

8.4(4)

Supervisor Engine 7202

WS-SUP720-3B

Supervisor Engine 720 with PFC3B:

•512-MB DRAM

•Policy Feature Card 3B; see the "Policy Feature Cards" section

•Multilayer Switch Feature Card 3 (MSFC3):

–512-MB DRAM

–64-MB bootflash

8.7(1)

8.7(1)

Note

•There are no memory-only upgrade options for WS-SUP720-3B.

•Use WS-F6K-PFC3BXL= to upgrade a WS-SUP720-3B with a PFC3BXL. WS-F6K-PFC3BXL= includes 1 GB memory upgrades for the Supervisor Engine 720 and the MSFC3. Refer to this publication for more information:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_16220.html

WS-SUP720-3BXL

Supervisor Engine 720 with PFC3BXL:

•1-GB DRAM

•Policy Feature Card 3BXL; see the "Policy Feature Cards" section

•Multilayer Switch Feature Card 3 (MSFC3):

–1-GB DRAM

–64-MB bootflash

8.3(1)

8.3(3)

Note There are no memory upgrade options for WS-SUP720-3BXL.

WS-SUP720

Supervisor Engine 720 with the following features:

•512-MB DRAM

•Policy Feature Card 3A (PFC3A); see the "Policy Feature Cards" section

•Multilayer Switch Feature Card 3 (MSFC3) with 64-MB bootflash device and 512-MB DRAM

8.1(1)

8.3(3)

Supervisor Engine 2³

WS-X6K-S2U-MSFC2

Supervisor Engine 2, dual 1000BASE-X GBIC uplinks, fabric-enabled, CEF, PFC2, and MSFC2
256 MB on supervisor engine, 256 MB on MSFC2
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

6.1(1d)

6.4(21)

WS-X6K-S2-MSFC2

Supervisor Engine 2, dual 1000BASE-X GBIC uplinks, fabric-enabled, CEF, PFC2, and MSFC2
128 MB on supervisor engine, 128 MB on MSFC2
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

6.1(1d)

6.4(21)

WS-X6K-S2-PFC2

Supervisor Engine 2, dual 1000BASE-X GBIC uplinks, fabric-enabled, and PFC2
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

6.1(1d)

6.4(21)

Supervisor Engine 1⁴^, ⁵

WS-X6K-S1A-MSFC2

Supervisor Engine 1A, dual 1000BASE-X GBIC uplinks, PFC, and MSFC2
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.4(3)

6.4(21)

WS-X6K-SUP1A-MSFC

Supervisor Engine 1A, dual 1000BASE-X GBIC uplinks, PFC, and MSFC
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.3(1a)CSX

6.4(21)

WS-X6K-SUP1A-PFC

Supervisor Engine 1A, dual 1000BASE-X GBIC uplinks, and PFC
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.3(1a)CSX

6.4(21)

WS-X6K-SUP1A-2GE

Supervisor Engine 1A, dual 1000BASE-X GBIC uplinks
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.3(1a)CSX

6.4(21)

WS-X6K-SUP1-2GE

Supervisor Engine 1, dual 1000BASE-X GBIC uplinks, Layer 2 Switching Engine I (WS-F6020) or Layer 2 Switching Engine II (WS-F6020A)
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.1(1a)CSX

6.4(21)

¹Read the Cautionary information on page 1 of this document to verify your Supervisor Engine 32 hardware version. The hardware version determines the required software releases for Supervisor Engine 32.

²Supervisor Engine 720 and Supervisor Engine 32 require a 2500 W or larger power supply in all 6-, 9-, and 13-slot chassis.

³Not supported in software release 8.6(5) or later releases.

⁴Not supported in the WS-C6513 chassis.

⁵Not supported in software release 8.5(4). For more information, refer to Product Bulletin No. 2595 at this URL:
http://www.cisco.com/en/US/prod/collateral/switches/ps5718/ps708/prod_end-of-life_notice0900aecd8017a5d1.html

Policy Feature Cards

Note•The PFC2 supports a theoretical maximum of 128 K MAC addresses (32 K MAC addresses recommended maximum).

•The PFC3 supports a theoretical maximum of 64 K MAC addresses (32 K MAC addresses recommended maximum).

•You cannot use a PFC3BXL or a PFC3B on one supervisor engine and a PFC3A on the other supervisor engine for redundancy. You must use identical policy feature cards for redundancy.

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

PFC3B¹

Policy Feature Card 3B (PFC3B)

8.4(1)

8.4(1)

PFC3BXL1

Policy Feature Card 3BXL (PFC3BXL)

8.3(1)

8.3(3)

PFC3A²

Policy Feature Card 3A (PFC3A)

8.1(1)

8.3(3)

For PFC and PFC2 information, see the "Supervisor Engines" section.

¹Supported on Supervisor Engine 720 and Supervisor Engine 32.

²Supported only with Supervisor Engine 720.

Switch Fabric Modules

Note•The Switch Fabric Modules are not supported with Supervisor Engine 720 because the Supervisor Engine 720 has an integrated switch fabric.

•The WS-C6500-SFM2 and the WS-X6500-SFM are supported only in systems with a Supervisor Engine 2.

•Except in a 13-slot chassis, WS-X6500-SFM2 and WS-C6500-SFM can be used together to provide redundancy.

•3-slot chassis do not support WS-X6500-SFM2 or WS-C6500-SFM.

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-C6500-SFM

Switch Fabric Module to support fabric-enabled modules

6.1(1d)

6.4(11)

WS-X6500-SFM2

Switch Fabric Module version 2

6.2(2)

6.4(11)

Small Form-Factor Pluggable Modules (SFPs)

Note For a list of transceiver that support Digital Optical Monitoring (DOM), refer to the Cisco Digital Optical Monitoring Compatibility Matrix at this URL:
http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/compatibility/matrix/OL_8031.html

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

CWDM-SFP

1000BASE-CWDM SFP

8.3(1)

8.3(3)

GLC-T

1000BASE-T SFP

8.3(1)

8.3(3)

GLC-LH-SM

1000BASE-LX/LH SFP

8.1(1)

8.3(3)

GLC-SX-MM

1000BASE-SX SFP

8.1(1)

8.3(3)

GLC-ZX-SM

1000BASE-ZX SFP

8.2(1)

8.3(3)

GLC-FE-100FX

100BASE-FX SFP

8.4(1)

8.4(1)

GLC-FE-100LX

100BASE-LX SFP

8.4(1)

8.4(1)

GLC-FE-100BX-D

GLC-FE-100BX-U

100BASE-BX10 SFPs

8.4(1)

8.4(1)

GLC-BX-U

1000BASE-BX SFP, transmit 1310-nm, receive 1490-nm

8.5(1)

8.5(1)

GLC-BX-D

1000BASE-BX SFP, transmit 1490-nm, receive 1310-nm

8.5(1)

8.5(1)

10-Gigabit Ethernet Switching Modules

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6502-10GE

1-port 10GBASE-E Serial 10-Gigabit Ethernet, fabric-enabled
QoS port architecture (Rx/Tx): 1p1q8t/1p2q1t

Note The WS-X6502-10GE module does not support ISL encapsulation.

7.1(1)

7.6(9)

WS-G6483

10GBASE-ER Serial 1550-nm extended-reach Optical Interface Module (OIM)

7.2(2)

7.6(9)

WS-G6488

10GBASE-LR Serial 1310-nm long-haul OIM

7.1(1)

7.6(9)

WS-X6704-10GE ¹, ², ³

4-port 10-Gigabit Ethernet, requires XENPAKs, fabric-enabled
QoS port architecture (Rx/Tx): 1q8t/1p7q8t

Note For a list of supported XENPAKs, see the "XENPAKs" section.

8.1(2)

8.3(3)

¹Not supported in a 6503 chassis in software releases prior to release 8.4(1). Supported in the 6503-E chassis with software release 8.4(1) and later releases.

²In a 13-slot chassis, this module must be installed in slots 9, 10, 11, 12, or 13.

³Supported only with Supervisor Engine 720.

XENPAKs

Note For a list of transceivers that support Digital Optical Monitoring (DOM), refer to the Cisco Digital Optical Monitoring Compatibility Matrix at this URL:

http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/compatibility/matrix/OL_8031.html

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

XENPAK-10GB-LR

Up to 10-kilometer range, 10GBASE-LR Serial 1310-nm long-haul (SMF)

8.1(2)

8.3(3)

XENPAK-10GB-LX4

10GBASE-LX4 Serial 1310-nm multimode (MMF)

8.2(1)

8.3(3)

XENPAK-10GB-ER

10GBASE-ER Serial 1550-nm extended-reach (SMF)

8.2(1)

8.3(3)

XENPAK-10GB-SR

10GBASE-SR Serial 850-nm short-reach multi-mode (MMF)

8.3(1)

8.3(3)

XENPAK-10GB-CX4

10GBASE-CX4 provides support for copper up to 15 meters on CX4 cable

8.3(1)

8.3(3)

XENPAK-10GB-ZR

10GBASE-ZR XENPAK 1550-nm, SC connector (SMF)

8.5(1)

8.5(1)

XENPAK-10GB-LW

10GBASE-LW XENPAK 1310-nm, SC connector (SMF)

Note The XENPAK-10GB-LW operates at an interface speed compatible with SONET/SDH OC-192/STM-64 and supports transmission at a data rate of 9.6Gbps.

When used with the WS-X6704-10GE module:
8.3(1)

When used with the WS-SUP32-10GE-3B uplinks:
8.4(4)

8.5(3)

DWDM-XENPAK-xx.xx¹

Dense Wavelength Division Multiplexing (DWDM) XENPAK transceivers

8.5(1)

8.5(4)

¹For a list of the DWDM XENPAK product numbers, band, and channel assignments, refer to the Cisco DWDM XENPAK Transceiver Installation Note at this URL: http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/installation/note/78_15665.html

Gigabit Ethernet Switching Modules

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6148A-GE-TX WS-X6148A-GE-45AF

48-port 10/100/1000BASE-T switching module, RJ-45 (WS-X6148A-GE-45AF provides inline power to IP telephones using the voice daughter card WS-F6K-GE48-AF)
QoS port architecture (Rx/Tx): 1q2t/1p3q8t

8.4(1)

8.4(1)

WS-X6748-GE-TX¹, ², ³

48-port 10/100/1000BASETX switching module, RJ-45, fabric-enabled
QoS port architecture (Rx/Tx): 1q8t/1p3q8t

8.1(2)

8.3(3)

WS-X6748-SFP1, 2, 3

48-port Gigabit Ethernet switching module, requires SFPs, fabric enabled
QoS port architecture (Rx/Tx): 1q8t/1p3q8t

Note For a list of supported SFPs, see the "Small Form-Factor Pluggable Modules (SFPs)" section.

8.3(2)

8.3(3)

WS-X6724-SFP1, 3

24-port Gigabit Ethernet switching module, requires SFPs, fabric-enabled
QoS port architecture (Rx/Tx): 1q8t/1p3q8t

Note For the 24-port Gigabit Ethernet switching module hardware version 2.2 and earlier versions, the recommended supervisor engine software release is 8.1(2).

Note For the 24-port Gigabit Ethernet switching module hardware version 2.3 and later versions, the recommended supervisor software release is 8.3(3).

Note For a list of supported SFPs, see the "Small Form-Factor Pluggable Modules (SFPs)" section.

See the Notes in the Product Description.

See the Notes in the Product Description.

WS-X6148-GE-TX
WS-X6148V-GE-TX

48-port 10/100/1000BASE-TX switching module (WS-X6148V-GE-TX provides inline power to IP telephones using the voice daughter card WS-F6K-GE48-AF or WS-F6K-VPWR-GE)
QoS port architecture (Rx/Tx): 1q2t/1p2q2t

7.6(1)

7.6(9)

WS-X6148-GE-45AF

48-port 10/100/1000BASE-TX switching module, provides inline power to IP telephones using the voice daughter card WS-F6K-GE48-AF
QoS port architecture (Rx/Tx): 1q2t/1p2q2t

8.2(1)

8.3(3)

WS-X6548-GE-TX
WS-X6548V-GE-TX

48-port 10/100/1000BASE-TX switching module, fabric-enabled (WS-X6548V-GE-TX provides inline power to IP telephones using the voice daughter card WS-F6K-GE48-AF or WS-F6K-VPWR-GE)
QoS port architecture (Rx/Tx): 1q2t/1p2q2t

7.6(1)

7.6(9)

WS-X6548-GE-45AF

48-port 10/100/1000BASE-TX switching module, fabric-enabled, provides inline power to IP telephones using the voice daughter card WS-F6K-GE48-AF
QoS port architecture (Rx/Tx): 1q2t/1p2q2t

8.2(1)

8.3(3)

WS-X6516A-GBIC

16-port Gigabit Ethernet GBIC switching module, fabric-enabled, 1-MB per-port packet buffers
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

7.5(1)

7.6(9)

WS-X6516-GBIC⁴

16-port Gigabit Ethernet GBIC switching module, fabric-enabled
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

6.1(1d)

6.4(11)

WS-X6516-GE-TX

16-port 10/100/1000BASE-T Ethernet Module,
fabric-enabled
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

6.2(2)

6.4(11)

WS-X6416-GBIC

16-port Gigabit Ethernet GBIC switching module
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.4(2)

6.4(11)

WS-X6416-GE-MT

16-port Gigabit Ethernet MT-RJ
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.3(5a)CSX

6.4(11)

WS-X6316-GE-TX

16-port 1000BASE-TX RJ-45 Gigabit Ethernet
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.4(2)

6.4(11)

WS-X6408A-GBIC

8-port Gigabit Ethernet GBIC
QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t

5.3(1a)CSX

6.4(11)

WS-X6408-GBIC

8-port Gigabit Ethernet GBIC
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.1(1)CSX

6.4(11)

¹Not supported in a 6503 chassis in software releases prior to release 8.4(1). Supported in the 6503-E chassis with software release 8.4(1) and later releases.

²In a 13-slot chassis, this module must be installed in slots 9, 10, 11, 12, or 13.

³Supported only with Supervisor Engine 720.

⁴Hardware (Hw) revisions 5.0 through 5.4 are not supported with a Supervisor Engine 720 or a Supervisor Engine 32.

Gigabit Interface Converters (GBICs)

Note For a list of transceiver that support Digital Optical Monitoring (DOM), refer to the Cisco Digital Optical Monitoring Compatibility Matrix at this URL:

http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/compatibility/matrix/OL_8031.html

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-G5483

1000BASE-T GBIC transceiver module for Category 5 copper wire
RJ-45 connector

7.2(1)

7.6(17)

WS-G5484

1000BASE-SX GBIC transceiver module for MMF, 850-nm wavelength
SC connector

5.1(1)CSX

6.4(21)

WS-G5486

1000BASE-LX/LH GBIC transceiver for MMF and SMF, 1300-nm wavelength
SC connector

5.1(1)CSX

6.4(21)

WS-G5487

1000BASE-ZX GBIC transceiver module for SMF, 1550-nm wavelength
SC connector

5.1(1)CSX

6.4(21)

CWDM-GBIC-xxxx¹

1000BASE-CWDM GBIC

7.2(1)

7.6(17)

DWDM-GBIC-xx.xx²

1000BASE-DWDM GBIC

8.3(1)

8.5(4)

¹For a list of the CWDM GBIC product numbers and wavelengths, refer to the Cisco CWDM GBIC and CWDM SFP Installation Note at this URL:
http://www.cisco.com/en/US/products/hw/modules/ps4999/prod_installation_guides_list.html

²For a list of the DWDM GBIC product numbers, band, and channel assignments, refer to the DWDM Gigabit Interface Converter Installation Note at this URL:
http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/installation/note/78_15299.html

Fast Ethernet Switching Modules

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6148-FE-SFP

48-port 100BASE-FX, requires SFPs
QoS port architecture (Rx/Tx): 1p1q4t/1p3q8t

Note For a list of supported SFPs, see the "Small Form-Factor Pluggable Modules (SFPs)" section.

8.4(1)

8.4(1)

WS-X6524-100FX-MM

24-port 100BASE-FX multimode, fabric-enabled
QoS port architecture (Rx/Tx): 1p1q0t/1p3q1t

7.1(1)

7.6(9)

WS-X6324-100FX-SM
WS-X6324-100FX-MM

24-port 100BASE-FX single mode or multimode, MT-RJ with 128K per-port packet buffers
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.4(2)

6.4(11)

WS-X6224-100FX-MT

24-port 100BASE-FX multimode, MT-RJ
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.1(1)CSX

6.4(11)

Ethernet/Fast Ethernet (10/100) Switching Modules

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6196-RJ-21
WS-X6196-21AF

96-port, 10/100BASE-TX RJ-21 (WS-X6196-21AF provides inline power to IP telephones using the voice daughter card WS-F6K-FE48X2-AF)
QoS port architecture: 1p1q0t/1p3q1t

8.4(1)

8.4(1)

WS-X6148A-RJ-45
WS-X6148A-45AF

48-port 10/100BASE-TX RJ-45 with 5.3Mb per-port packet buffers (WS-X6148A-45AF provides inline power to IP telephones using the voice daughter card WS-F6K-48-AF)
QoS port architecture (Rx/Tx): 1p1q4t/1p3q8t

8.4(1)

8.4(1)

WS-X6148X2-RJ-45
WS-X6148X2-45AF

96-port 10/100BASE-TX RJ-45, (WS-X6148X2-45AF provides inline power to IP telephones using the voice daughter card WS-F6K-FE48X2-AF)
QoS port architecture (Rx/Tx): 1p1q0t/1p3q1t

8.2(1)

8.3(3)

WS-X6548-RJ-21

48-port 10/100BASE-TX RJ-21, fabric-enabled
QoS port architecture (Rx/Tx): 1p1q0t/1p3q1t

6.2(2)

6.4(11)

WS-X6548-RJ-45

48-port 10/100BASE-TX RJ-45, fabric-enabled
QoS port architecture (Rx/Tx): 1p1q0t/1p3q1t

6.2(2)

6.4(11)

WS-X6348-RJ21V

48-port 10/100BASE-TX RJ-21 with 128K per-port packet buffers (WS-X6348-RJ21V provides inline power to IP telephones using the voice daughter card WS-F6K-VPWR)
QoS port architecture (Rx/Tx): 1q4t/2q2t

6.2(2)

6.4(11)

WS-X6348-RJ-45 WS-X6348-RJ-45V

48-port 10/100BASE-TX RJ-45 with 128K per-port packet buffers (WS-X6348-RJ-45V provides inline power to IP telephones using the voice daughter card WS-F6K-VPWR)
QoS port architecture (Rx/Tx): 1q4t/2q2t

Without
WS-F6K-VPWR:
5.4(2)

With
WS-F6K-VPWR:
5.5(1)

Without
WS-F6K-VPWR:
6.4(11)

With
WS-F6K-VPWR:
6.4(11)

WS-X6148-RJ-45
WS-X6148-RJ-45V

48-port 10/100BASE-TX RJ-45 with 128K per-port packet buffers (WS-X6148-RJ-45V provides inline power to IP telephones using the voice daughter card WS-F6K-48-AF or WS-F6K-VPWR)
QoS port architecture (Rx/Tx): 1q4t/2q2t

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

WS-X6148-RJ-21
WS-X6148-RJ21V

48-port 10/100BASE-TX RJ-21 with 128K per-port packet buffers (WS-X6148-RJ21V provides inline power to IP telephones using the voice daughter card WS-F6K-48-AF or WS-F6K-VPWR)
QoS port architecture (Rx/Tx): 1q4t/2q2t

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

WS-X6148-45AF

48-port 10/100BASE-TX RJ-45 with 128K per-port packet buffers (WS-X6148-45AF has the WS-F6K-48-AF daughter card to provide inline power to IP telephones)
QoS port architecture (Rx/Tx): 1q4t/2q2t

8.2(1)

8.3(3)

WS-X6148-21AF

48-port 10/100BASE-TX RJ-21 with 128K per-port packet buffers (WS-X6148-21AF has the WS-F6K-48-AF daughter card to provide inline power to IP telephones)
QoS port architecture (Rx/Tx): 1q4t/2q2t

8.2(1)

8.3(3)

WS-F6K-VPWR

Inline-power field-upgrade module mounts on the 48-port 10/100BASE-TX RJ-45 and RJ-21 modules

5.5(1)

6.4(11)

WS-X6248-RJ-45

48-port 10/100BASE-TX RJ-45
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.1(1)CSX

6.4(11)

WS-X6248A-TEL

48-port 10/100BASE-TX RJ-21 with 128K per-port packet buffers
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.3(2)CSX

6.4(11)

WS-X6248-TEL

48-port 10/100BASE-TX RJ-21
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.2(1)CSX

6.4(11)

Ethernet Switching Modules

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6024-10FL-MT

24-port 10BASE-FL MT-RJ
QoS port architecture (Rx/Tx): 1q4t/2q2t

5.3(3)CSX

6.4(11)

Power Over Ethernet Daughter Cards

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-F6K-FE48X2-AF

IEEE 802.3af PoE daughter card for:

WS-X6148X2-45AF

8.2(1)

8.3(3)

WS-X6196-21AF

8.4(1)

8.4(1)

WS-F6K-GE48-AF

IEEE 802.3af PoE daughter card for:

WS-X6148A-GE-45AF

8.4(1)

8.4(1)

WS-X6148V-GE-TX

7.6(1)

7.6(9)

WS-X6148-GE-45AF

8.2(1)

8.3(3)

WS-X6548V-GE-TX

7.6(1)

7.6(9)

WS-X6548-GE-45AF

8.2(1)

8.3(3)

WS-F6K-48-AF

IEEE 802.3af PoE daughter card for:

WS-X6148A-45AF

8.4(1)

8.4(1)

WS-X6148-RJ-45V

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

WS-X6148-RJ21V

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

WS-F6K-VPWR-GE

PoE daughter card for:

WS-X6548V-GE-TX

7.6(1)

7.6(9)

WS-X6148V-GE-TX

7.6(1)

7.6(9)

WS-F6K-VPWR

PoE daughter card for:

WS-X6348-RJ-45V

5.5(1)

6.4(11)

WS-X6348-RJ21V

6.2(2)

6.4(11)

WS-X6148-RJ-45V

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

WS-X6148-RJ21V

For software releases 6.x: 6.4(1)

For software releases 7.x: 7.2(2)

For software releases 6.x: 6.4(11)

For software releases 7.x: 7.6(9)

Voice Modules

Product Number

append with
"=" for spares

Product Description¹

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-SVC-CMM

Communication Media Module

7.6(12)

8.3(3)

WS-SVC-CMM-6E

16-port E1 interface port adapter

7.6(12)

8.3(3)

WS-SVC-CMM-6T1

6-port T1 interface port adapter

7.6(12)

8.3(3)

WS-SVC-CMM-24FXS

24-port FXS interface port adapter

7.6(12)

8.3(3)

WS-SVC-CMM-ACT

Ad-hoc conferencing and transcoding port adapter

7.6(12)

8.3(3)

WS-X6624-FXS

24-port FXS analog interface module

5.5(1)

6.4(11)

WS-X6608-T1
WS-X6608-E1

8-port T1/E1 PSTN interface modules

5.5(1)

6.4(11)

¹The voice modules are not supported with Supervisor Engine 720 in software release 8.1(x). The voice modules are supported with Supervisor Engine 720 in software release 8.2(1) and later releases.

FlexWAN Module

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6582-2PA ¹

FlexWAN2, enhanced FlexWAN module

8.5(1)

8.5(1)

WS-X6182-2PA², ³

FlexWAN Module

5.4(2)

6.4(11)

¹For enhanced FlexWAN2 documentation, refer to this URL: http://www.cisco.com/en/US/docs/routers/7600/install_config/flexwan_config/flexwan-config-guide.html

²The WS-X6182-2PA FlexWAN module is not supported with Supervisor Engine 720 in software release 8.1(x). The WS-X6182-2PA FlexWAN module is supported with Supervisor Engine 720 in software release 8.2(1) and later releases. The WS-X6182-2PA FlexWAN module is not supported with Supervisor Engine 32. For detailed information on Cisco IOS Release requirements for the FlexWAN module, see the "Release Notes for Cisco IOS on the MSFC" section at this URL:
http://www.cisco.com/en/US/products/hw/switches/ps708/prod_release_notes_list.html

³Refer to the Catalyst 6500 Series Switch FlexWAN Module Installation and Configuration Note.

Optical Services Modules

Product Number

append with
"=" for spares

Product Description¹, ², ³

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

4-port Gigabit Ethernet WAN

OSM-4GE-WAN-GBIC

4-port Gigabit Ethernet Optical Services Module

6.1(2)

6.4(11)

OC-12 Packet over SONET⁴

OSM-2OC12-POS-MM

2-port OC-12c/STM-4c POS Optical Services Module, MM, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-2OC12-POS-SI

2-port OC-12c/STM-4c POS Optical Services Module, SM-IR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-2OC12-POS-SL

2-port OC-12c/STM-4c POS Optical Services Module, SM-LR⁵, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-4OC12-POS-MM

4-port OC-12c/STM-4c POS Optical Services Module, MM, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-4OC12-POS-SI

4-port OC-12c/STM-4c POS Optical Services Module, SM-IR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-4OC12-POS-SL

4-port OC-12c/STM-4c POS Optical Services Module, SM-LR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OC-3 Packet over SONET3

OSM-4OC3-POS-SI

4-port OC-3c/STM-1c POS Optical Services Module, SM-IR, with 4 Gigabit Ethernet ports

7.1(1)

7.6(9)

OSM-8OC3-POS-MM

8-port OC-3c/STM-1c POS Optical Services Module, MM, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-8OC3-POS-SI

8-port OC-3c/STM-1c POS Optical Services Module, SM-IR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-8OC3-POS-SL

8-port OC-3c/STM-1c POS Optical Services Module, SM-LR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-16OC3-POS-MM

16-port OC-3c/STM-1c POS Optical Services Module, MM, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-16OC3-POS-SI

16-port OC-3c/STM-1c POS Optical Services Module, SM-IR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OSM-16OC3-POS-SL

16-port OC-3c/STM-1c POS Optical Services Module, SM-LR, with 4 Gigabit Ethernet ports

6.1(2)

6.4(11)

OC-48 Packet over SONET3

OSM-1OC48-POS-SS

1-port OC-48c/STM-16c POS Optical Services
Module, SM-SR, with 4 Gigabit Ethernet ports

6.1(3)

6.4(11)

OSM-1OC48-POS-SI

1-port OC-48c/STM-16c POS Optical Services
Module, SM-IR, with 4 Gigabit Ethernet ports

6.1(3)

6.4(11)

OSM-1OC48-POS-SL

1-port OC-48c/STM-16c POS Optical Services
Module, SM-LR, with 4 Gigabit Ethernet ports

6.1(3)

6.4(11)

¹The OSMs are only supported with Supervisor Engine 2.

²Refer to the Optical Services Module Installation and Configuration Note.

³Channelized OSMs are not supported on Catalyst 6500 series switches; they are supported only on the Cisco 7600 series router platform.

⁴Also has four Layer 2 Gigabit Ethernet ports.

⁵Single-mode, long reach.

Service Modules

Product Number

append with
"=" for spares

Product Description¹

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

Intrusion Detection System Module (IDSM)²

WS-X6381-IDS³

Intrusion Detection System Module

6.1(1d)

6.4(11)

WS-SVC-IDSM2-BUN-K9

Intrusion Detection System Module 2

7.5(1)

7.6(9)

Network Analysis Module (NAM)⁴, ⁵

WS-X6380-NAM3

Network Analysis Module, 256-MB RAM

5.5(1)

6.4(11)

WS-SVC-NAM-1

Network Analysis Module, 512-MB RAM, fabric-enabled

7.3(1)

7.6(9)

WS-SVC-NAM-2

Network Analysis Module, 1-GB RAM, fabric enabled, accelerator daughter card

7.3(1)

7.6(9)

Firewall Services Module⁶

WS-SVC-FWM-1-K9

Firewall Services Module

7.5(1)

7.6(9)

SSL Services Module⁷

WS-SVC-SSL-1

SSL Services Module

7.5(1)

7.6(9)

Content Switching Module (CSM)⁸

WS-X6066-SLB-APC⁹

Content Switching Module

7.5(1)

7.6(9)

Content Services Gateway (CSG)¹⁰

WS-SVC-CSG-1

Content Services Gateway

7.6(1)

7.6(9)

Application-Oriented Networking (AON) Module¹¹

WS-SVC-AON-1-K9

Application-Oriented Networking (AON) Module

8.4(2a)

8.4(2a)

¹The service modules are not supported with supervisor engine WS-SUP720 in software release 8.1(x). The service modules are supported with supervisor engine WS-SUP720 in software release 8.2(1) and later releases. The service modules are supported with supervisor engine WS-SUP720-3BXL in software release 8.3(1) and later releases. The service modules are supported with supervisor engine WS-SUP720-3B in software releases 8.3(7) and later releases. The service modules are supported with supervisor engine WS-SUP32-GE-3B in software release 8.4(1) and later releases. The service modules are supported with supervisor engine WS-SUP32-10GE-3B in software releases 8.4(4) and later releases.

²Refer to the Catalyst 6500 Series Switch Intrusion Detection System Module Installation and Configuration Note.

³Not supported with Supervisor Engine 720 or Supervisor Engine 32.

⁴Refer to the Network Analysis Module Installation and Configuration Note.

⁵The Network Analysis Module (NAM) application image 1.1(1a) and NAM maintenance image 1.1(1a)m are not supported with supervisor engine software releases 6.3(2) and later. For supervisor engine software releases 6.3(2) and later, use the 1.2 NAM image.

⁶Refer to the Catalyst 6500 Series Switch and 7600 Series Firewall Services Module Installation and Configuration Note.

⁷Refer to the Catalyst 6500 Series Switch SSL Services Module Installation and Configuration Note.

⁸Refer to the Cisco Content Switching Module Installation and Configuration Guide.

⁹The WS-X6066-SLB-APC module is not supported with Supervisor Engine 32.

¹⁰Refer to the Cisco Content Services Gateway Installation and Configuration Guide.

¹¹Refer to the Application-Oriented Networking (AON) documentation at this URL:http://www.cisco.com/en/US/products/ps6692/Products_Sub_Category_Home.html

ATM Modules

Product Number

append with
"=" for spares

Product Description¹, ²

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6101-OC12-SMF

Single-port single-mode OC-12 ATM

5.3(2)CSX

6.4(11)

WS-X6101-OC12-MMF

Single-port multimode OC-12 ATM

5.3(2)CSX

6.4(11)

¹The ATM modules are not supported with the Supervisor Engine 720 in software release 8.1(x). The ATM modules are supported with Supervisor Engine 720 in software release 8.2(1) and later releases.

²Refer to the ATM Configuration Guide and Command Reference.

Multilayer Switch Module

Product Number

append with
"=" for spares

Product Description¹, ²

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-X6302-MSM

Multilayer Switch Module

5.2(1)CSX

6.4(11)

¹The Multilayer Switch Module is not supported with Supervisor Engine 720 or Supervisor Engine 32 (there will be no Supervisor Engine 720 or Supervisor Engine 32 support in any future software releases).

²Refer to the Multilayer Switch Module Release Notes.

Power Supplies

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-CAC-6000W¹

6000 W AC power supply

8.4(1)

8.4(1)

PWR-2700-AC²

2700 W AC power supply

8.4(1)

8.4(1)

PWR-2700-DC2

2700 W DC power supply

8.4(1)

8.4(1)

WS-CAC-1000W

1000 W AC power supply

5.1(1)CSX

6.4(11)

WS-CAC-1300W

1300 W AC power supply

5.1(1)CSX

6.4(11)

WS-CDC-1300W

1300 W DC power supply

5.1(1)CSX

6.4(11)

PWR-1400-AC³

1400 W AC power supply

8.1(1)

8.3(3)

WS-CAC-2500W

2500 W AC power supply

5.4(2)

6.4(11)

WS-CDC-2500W

2500 W DC power supply

5.4(2)

6.4(11)

WS-CAC-3000W

3000W AC power supply

7.5(1)

7.6(9)

WS-CAC-4000W

4000 W AC power supply

6.1(3)

6.4(11)

PWR-4000-DC⁴

4000 W DC power supply

6.1(3)

8.3(3)

PWR-950-AC3

950 W AC power supply

7.5(1)

7.6(9)

PWR-950-DC3

950 W DC power supply

7.5(1)

7.6(9)

PWR-1900-AC/6⁵

1900 W AC power supply

7.2(2)

7.6(9)

PWR-1900-DC5

1900 W DC power supply

7.2(2)

7.6(9)

¹Supported in all 65xx and 65xx-E chassis except for the 6503 and 6503-E (form-factor difference). Only the 6513 and -E chassis support the full 6000W; the other chassis rely on software to current limit the power supply.

²Supported in the 7606 chassis and the 6504-E chassis. Support in the 6504-E chassis requires software release 8.4(2) and later releases.

³Supported only on the WS-C6503, WS-C6503-E, and CISCO7603 chassis.

⁴The full 4000W is only available with software release 8.1(1) and later releases. With software release 6.1(3) and later 6.x and 7.x releases, the maximum wattage is 2506.56W.

⁵Supported only on the CISCO7606 chassis.

Fan Trays

Product Number

append with
"=" for spares

Product Description¹

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

FAN-MOD-3

Standard-capacity fan tray for 6503 chassis
Standard-capacity fan tray for 7603 chassis

7.4(2)
7.1(1)

7.6(9)
7.6(9)

FAN-MOD-3HS

High-capacity fan tray for 6503/7603 chassis

8.1(1)

8.3(3)

FAN-MOD-4HS

High-capacity fan tray for the 6504 chassis

8.4(2)

8.4(2)

WS-C6K-6SLOT-FAN

Standard-capacity fan tray for 6506 chassis

5.2(1)CSX

6.4(11)

WS-C6K-6SLOT-FAN2²

High-capacity fan tray for 6506 chassis

8.1(1)

8.3(3)

WS-C6K-9SLOT-FAN

Standard-capacity fan tray for 6509 chassis

5.1(1)CSX

6.4(11)

WS-C6K-9SLOT-FAN22, ³

High-capacity fan tray for 6509 chassis

8.1(1)

8.3(3)

WS-C6K-13SLOT-FAN

Standard-capacity fan tray for 6513 chassis
Standard-capacity fan tray for 7613 chassis

6.2(2)
7.6(1)

6.4(11)
7.6(9)

WS-C6K-13SLT-FAN22

High-capacity fan tray for 6513/7613 chassis

8.1(1)

8.3(3)

FAN-MOD-6

Standard-capacity fan tray for 7606 chassis

7.2(2)

7.6(9)

FAN-MOD-6HS2

High-capacity fan tray for 7606 chassis

8.1(1)

8.3(3)

WS-C6506-E-FAN2

High-capacity fan tray for WS-C6506-E chassis

6.3(7)

8.3(3)

WS-C6509-E-FAN2

High-capacity fan tray for WS-C6509-E chassis

6.3(7)

8.3(3)

WS-C6503-E-FAN2

High-capacity fan tray for WS-C6503-E chassis

6.3(7)

8.3(3)

FAN-MOD-09

Standard-capacity fan tray for 6509-NEB-A/7609 chassis

8.1(1)

8.3(3)

FAN-MOD-09-HS2

High-capacity fan tray for 6509-NEB-A/7609 chassis

8.1(1)

8.3(3)

WS-C6509-NEB-FAN

Standard-capacity fan tray for 6509-NEB chassis

5.4(2)

6.4(11)

¹Some chassis require a high capacity fan tray for use with Supervisor Engine 720 and Supervisor Engine 32. To determine which chassis require a fan tray for Supervisor Engine 720 and Supervisor Engine 32, see the "Modular Chassis" section.

²These fan trays require a 2500 W or 4000 W power supply.

³This fan tray is supported in all chassis (except for the 3-slot chassis) and all software releases. The minimum power supply requirement is 2500W. It is important that you determine the power requirements for your hardware configuration to ensure that your switch has adequate power for all modules. To determine power requirements, refer to the CCO power calculator at this URL: http://www.cisco.com/go/powercalculator.

Modular Chassis

Product Number

append with
"=" for spares

Product Description

Minimum Supervisor Engine
software release

Recommended
Supervisor Engine
software release

WS-C6513

Catalyst 6513 chassis:

•13 slots

•64 chassis MAC addresses

•Supported only with Supervisor Engine 2, Supervisor Engine 720, and Supervisor Engine 32

•Supervisor Engine 720 and Supervisor Engine 32 require WS-C6K-13SLT-FAN2. Each power supply in the chassis must be at least 2500 W

6.2(2)

6.4(11)

WS-C6509-E2

Catalyst 6509 chassis:

•9 slots

•1024 chassis MAC addresses

•Requires WS-C6509-E-FAN

8.3(1)

8.4(1)

WS-C6509

Catalyst 6509 chassis:

•9 slots

•1024 chassis MAC addresses

•Supervisor Engine 720 and Supervisor Engine 32 require WS-C6K-9SLOT-FAN2. Each power supply in the chassis must be at least 2500 W

5.1(1)CSX

6.4(11)

WS-C6509-NEB¹

Catalyst 6509-NEB chassis:

•9 vertical slots

•1024 chassis MAC addresses

5.4(2)

6.4(11)

WS-C6509-NEB-A²

Catalyst 6509-NEB-A chassis:

•9 vertical slots

•64 chassis MAC addresses

•No fan tray upgrade needed to use Supervisor Engine 720 and Supervisor Engine 32

8.1(1)

8.3(3)

WS-C6506-E2

Catalyst 6506 chassis:

•6 slots

•1024 chassis MAC addresses

•Requires WS-C6506-E-FAN

8.3(1)

8.4(1)

WS-C6506

Catalyst 6506 chassis:

•6 slots

•1024 chassis MAC addresses

•Supervisor Engine 720 and Supervisor Engine 32 require WS-C6K-6SLOT-FAN2. Each power supply in the chassis must be at least 2500 W

5.2(1)CSX

6.4(11)

WS-C6504-E

Catalyst 6504 chassis:

•4 slots

•64 chassis MAC addresses

•Does not support:

–WS-X6500-SFM2

–WS-C6500-SFM

–Supervisor Engine 2

–Supervisor Engine 1A

8.4(2)

8.4(2)

WS-C6503-E³

Catalyst 6503 chassis:

•3 slots

•64 chassis MAC addresses

•Supervisor Engine 720 and Supervisor Engine 32 require WS-C6503-E-FAN

•Does not support:

–WS-X6500-SFM2

–WS-C6500-SFM

8.3(1)

8.4(1)

WS-C6503

Catalyst 6503 chassis:

•3 slots

•64 chassis MAC addresses

•Does not support SFM

•Supervisor Engine 720 and Supervisor Engine 32 require FAN-MOD-3HS=

7.4(2)

7.6(9)

WS-C6009

Catalyst 6009 chassis:

•9 slots

•1024 chassis MAC addresses

5.1(1)CSX

6.4(11)

WS-C6006

Catalyst 6006 chassis:

•6 slots

•1024 chassis MAC addresses

5.2(1)CSX

6.4(11)

OSR-7609-AC, -DC1

Cisco 7609 router chassis:

•9 vertical slots

•1024 chassis MAC addresses

•Supported only with Supervisor Engine 2

6.1(1b)

6.4(11)

CISCO7603

Cisco 7603 router chassis:

•3 slots

•64 chassis MAC addresses

•Does not support SFM

•Supervisor Engine 720 and Supervisor Engine 32 require FAN-MOD-3HS=

7.1(1)

7.6(9)

CISCO7606

Cisco 7606 router chassis:

•6 slots

•64 chassis MAC addresses

•Supported only with Supervisor Engine 2 and Supervisor Engine 720

•Supervisor Engine 720 and Supervisor Engine 32 require FAN-MOD-6HS

7.2(2)

7.6(9)

CISCO76092

Cisco 7609 router chassis:

•9 vertical slots

•64 chassis MAC addresses

•No fan tray upgrade needed to use Supervisor Engine 720 and Supervisor Engine 32

8.1(1)

8.3(3)

CISCO7613

Cisco 7613 router chassis:

•13 slots

•64 chassis MAC addresses

•Supported only with Supervisor Engine 2 and Supervisor Engine 720

•Supervisor Engine 720 and Supervisor Engine 32 require WS-C6K-13SLT-FAN2. Each power supply in the chassis must be at least 2500 W

7.6(1)

7.6(9)

¹These chassis are not supported with Supervisor Engine 720 in Release 8.1(x) and 8.2(x).

²These chassis require a 2500 W or 4000 W power supply. Lower wattage power supplies are not supported.

³Supervisor Engine 720 requires software release 8.1(1) and later releases and the WS-C6503-E-FAN tray.

Unsupported Hardware

The following hardware is not supported:

•Compact Flash adapter (WS-CF-UPG=)

Note This part also appears as CF-ADAPTER-SP in the configuration tool.

•16-port Gigabit Ethernet switching module (WS-X6816-GBIC)

•Distributed forwarding cards (DFC) installed on WS-X67xx modules:

–WS-F6700-DFC3BXL

–WS-F6700-DFC3B

–WS-F6700-DFC3A

–WS-X6708-10G-3C

–WS-X6708-10G-3CXL

•DFC installed on dCEF256 and CEF256 modules:

–WS-F6K-DFC3BXL

–WS-F6K-DFC3B

–WS-F6K-DFC3A

–WS-F6K-DFC

•Supervisor Engine 720-10G-3C

•Supervisor Engine 720-10G-3CXL

•SPA interface processors (7600-SIP-200, 7600-SIP-400, 7600-SIP-600)

•Cisco Application Control Engine (ACE10-6500-K9)

•WebVPN Services Module (WS-SVC-WEBVPN-K9)

Unsupported modules remain powered down if detected and do not affect system behavior.

Orderable Software Images

Table 1 lists the software releases and applicable ordering information for the Catalyst 6500 series supervisor engine software.

Caution Always back up the switch configuration file before upgrading or downgrading the switch software to avoid losing all or part of the configuration stored in nonvolatile RAM (NVRAM). When downgrading switch software, you will lose your configuration. Use the write network command or the copy config tftp command to back up your configuration to a Trivial File Transfer Protocol (TFTP) server. Use the copy config flash command to back up the configuration to a Flash device.

Note CiscoView images are available approximately 2 weeks after the Flash images are released.

Table 1 Orderable Software Images

Software Release

Filename

Orderable Product Number¹

Supervisor Engine 32

8.7(3) Flash image

cat6000-sup720k8.8-7-3.bin

SC6K-S7K8-8.7

8.7(3) Flash image (Secure Shell)

cat6000-sup720k9.8-7-3.bin

SC6K-S7K9-8.7

8.7(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-7-3.bin

SC6K-S7CVK8-8.7

8.7(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-7-3.bin

SC6K-S7CVK9-8.7

8.7(2) Flash image

cat6000-sup720k8.8-7-2.bin

SC6K-S7K8-8.7

8.7(2) Flash image (Secure Shell)

cat6000-sup720k9.8-7-2.bin

SC6K-S7K9-8.7

8.7(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-7-2.bin

SC6K-S7CVK8-8.7

8.7(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-7-2.bin

SC6K-S7CVK9-8.7

8.7(1) Flash image

cat6000-sup720k8.8-7-1.bin

SC6K-S7K8-8.7

8.7(1) Flash image (Secure Shell)

cat6000-sup720k9.8-7-1.bin

SC6K-S7K9-8.7

8.7(1) Flash image (CiscoView)

cat6000-sup720cvk8.8-7-1.bin

SC6K-S7CVK8-8.7

8.7(1) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-7-1.bin

SC6K-S7CVK9-8.7

8.6(6) Flash image

cat6000-sup720k8.8-6-5.bin

SC6K-S7K8-8.6

8.6(6) Flash image (Secure Shell)

cat6000-sup720k9.8-6-5.bin

SC6K-S7K9-8.6

8.6(6) Flash image (CiscoView)

cat6000-sup720cvk8.8-6-5.bin

SC6K-S7CVK8-8.6

8.6(6) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-6-5.bin

SC6K-S7CVK9-8.6

8.6(5) Flash image

cat6000-sup720k8.8-6-5.bin

SC6K-S7K8-8.6

8.6(5) Flash image (Secure Shell)

cat6000-sup720k9.8-6-5.bin

SC6K-S7K9-8.6

8.6(5) Flash image (CiscoView)

cat6000-sup720cvk8.8-6-5.bin

SC6K-S7CVK8-8.6

8.6(5) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-6-5.bin

SC6K-S7CVK9-8.6

8.6(4) Flash image

cat6000-sup720k8.8-6-4.bin

SC6K-S7K8-8.6

8.6(4) Flash image (Secure Shell)

cat6000-sup720k9.8-6-4.bin

SC6K-S7K9-8.6

8.6(4) Flash image (CiscoView)

cat6000-sup720cvk8.8-6-4.bin

SC6K-S7CVK8-8.6

8.6(4) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-6-4.bin

SC6K-S7CVK9-8.6

8.6(3) Flash image

cat6000-sup720k8.8-6-3.bin

SC6K-S7K8-8.6

8.6(3) Flash image (Secure Shell)

cat6000-sup720k9.8-6-3.bin

SC6K-S7K9-8.6

8.6(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-3.bin

SC6K-S7CVK8-8.6

8.6(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-3.bin

SC6K-S7CVK9-8.6

8.6(2) Flash image

cat6000-sup32pfc3k8.8-6-2.bin

SC6K-S323K8-8.6

8.6(2) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-6-2.bin

SC6K-S323K9-8.6

8.6(2) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-6-2.bin

SC6K-S323CVK8-8.6

8.6(2) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-6-2.bin

SC6K-S323CVK9-8.6

8.6(1) Flash image

cat6000-sup32pfc3k8.8-6-1.bin

SC6K-S323K8-8.6

8.6(1) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-6-1.bin

SC6K-S323K9-8.6

8.6(1) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-6-1.bin

SC6K-S323CVK8-8.6

8.6(1) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-6-1.bin

SC6K-S323CVK9-8.6

8.5(9) Flash image

cat6000-sup32pfc3k8.8-5-9.bin

SC6K-S323K8-8.5

8.5(9) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-9.bin

SC6K-S323K9-8.5

8.5(9) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-9.bin

SC6K-S323CVK8-8.5

8.5(9) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-9.bin

SC6K-S323CVK9-8.5

8.5(8) Flash image

cat6000-sup32pfc3k8.8-5-8.bin

SC6K-S323K8-8.5

8.5(8) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-8.bin

SC6K-S323K9-8.5

8.5(8) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-8.bin

SC6K-S323CVK8-8.5

8.5(8) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-8.bin

SC6K-S323CVK9-8.5

8.5(7) Flash image

cat6000-sup32pfc3k8.8-5-7.bin

SC6K-S323K8-8.5

8.5(7) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-7.bin

SC6K-S323K9-8.5

8.5(7) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-7.bin

SC6K-S323CVK8-8.5

8.5(7) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-7.bin

SC6K-S323CVK9-8.5

8.5(6) Flash image

cat6000-sup32pfc3k8.8-5-6.bin

SC6K-S323K8-8.5

8.5(6) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-6.bin

SC6K-S323K9-8.5

8.5(6) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-6.bin

SC6K-S323CVK8-8.5

8.5(6) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-6.bin

SC6K-S323CVK9-8.5

8.5(5) Flash image

cat6000-sup32pfc3k8.8-5-5.bin

SC6K-S323K8-8.5

8.5(5) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-5.bin

SC6K-S323K9-8.5

8.5(5) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-5.bin

SC6K-S323CVK8-8.5

8.5(5) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-5.bin

SC6K-S323CVK9-8.5

8.5(4) Flash image

cat6000-sup32pfc3k8.8-5-4.bin

SC6K-S323K8-8.5

8.5(4) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-4.bin

SC6K-S323K9-8.5

8.5(4) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-4.bin

SC6K-S323CVK8-8.5

8.5(4) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-4.bin

SC6K-S323CVK9-8.5

8.5(3) Flash image

cat6000-sup32pfc3k8.8-5-3.bin

SC6K-S323K8-8.5

8.5(3) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-3.bin

SC6K-S323K9-8.5

8.5(3) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-3.bin

SC6K-S323CVK8-8.5

8.5(3) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-3.bin

SC6K-S323CVK9-8.5

8.5(2) Flash image

cat6000-sup32pfc3k8.8-5-2.bin

SC6K-S323K8-8.5

8.5(2) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-2.bin

SC6K-S323K9-8.5

8.5(2) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-5-2bin

SC6K-S323CVK8-8.5

8.5(2) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-5-2.bin

SC6K-S323CVK9-8.5

8.5(1) Flash image²

cat6000-sup32pfc3k8.8-5-1.bin

SC6K-S323K8-8.5

8.5(1) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-5-1.bin

SC6K-S323K9-8.5

8.4(6) Flash image

cat6000-sup32pfc3k8.8-4-6.bin

SC6K-S323K8-8.4

8.4(6) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-6.bin

SC6K-S323K9-8.4

8.4(6) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-6.bin

SC6K-S323CVK8-8.4

8.4(6) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-6.bin

SC6K-S323CVK9-8.4

8.4(5) Flash image

cat6000-sup32pfc3k8.8-4-5.bin

SC6K-S323K8-8.4

8.4(5) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-5.bin

SC6K-S323K9-8.4

8.4(5) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-5.bin

SC6K-S323CVK8-8.4

8.4(5) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-5.bin

SC6K-S323CVK9-8.4

8.4(4) Flash image

cat6000-sup32pfc3k8.8-4-4.bin

SC6K-S323K8-8.4

8.4(4) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-4.bin

SC6K-S323K9-8.4

8.4(4) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-4.bin

SC6K-S323CVK8-8.4

8.4(4) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-4.bin

SC6K-S323CVK9-8.4

8.4(3) Flash image

cat6000-sup32pfc3k8.8-4-3.bin

SC6K-S323K8-8.4

8.4(3) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-3.bin

SC6K-S323K9-8.4

8.4(3) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-3.bin

SC6K-S323CVK8-8.4

8.4(3) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-3.bin

SC6K-S323CVK9-8.4

8.4(2a) Flash image

cat6000-sup32pfc3k8.8-4-2a.bin

SC6K-S323K8-8.4

8.4(2a) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-2a.bin

SC6K-S323K9-8.4

8.4(2a) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-2a.bin

SC6K-S323CVK8-8.4

8.4(2a) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-2a.bin

SC6K-S323CVK9-8.4

8.4(2) Flash image

cat6000-sup32pfc3k8.8-4-2.bin

SC6K-S323K8-8.4

8.4(2) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-2.bin

SC6K-S323K9-8.4

8.4(2) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-2.bin

SC6K-S323CVK8-8.4

8.4(2) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-2.bin

SC6K-S323CVK9-8.4

8.4(1) Flash image

cat6000-sup32pfc3k8.8-4-1.bin

SC6K-S323K8-8.4

8.4(1) Flash image (Secure Shell)

cat6000-sup32pfc3k9.8-4-1.bin

SC6K-S323K9-8.4

8.4(1) Flash image (CiscoView)

cat6000-sup32pfc3cvk8.8-4-1.bin

SC6K-S323CVK8-8.4

8.4(1) Flash image (Secure Shell and CiscoView)

cat6000-sup32pfc3cvk9.8-4-1.bin

SC6K-S323CVK9-8.4

Supervisor Engine 720

8.6(2) Flash image

cat6000-sup720k8.8-6-2.bin

SC6K-S7K8-8.6

8.6(2) Flash image (Secure Shell)

cat6000-sup720k9.8-6-2.bin

SC6K-S7K9-8.6

8.6(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-6-2.bin

SC6K-S7CVK8-8.6

8.6(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-6-2.bin

SC6K-S7CVK9-8.6

8.6(1) Flash image

cat6000-sup720k8.8-6-1.bin

SC6K-S7K8-8.6

8.6(1) Flash image (Secure Shell)

cat6000-sup720k9.8-6-1.bin

SC6K-S7K9-8.6

8.6(1) Flash image (CiscoView)

cat6000-sup720cvk8.8-6-1.bin

SC6K-S7CVK8-8.6

8.6(1) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-6-1.bin

SC6K-S7CVK9-8.6

8.5(9) Flash image

cat6000-sup720k8.8-5-9.bin

SC6K-S7K8-8.5

8.5(9) Flash image (Secure Shell)

cat6000-sup720k9.8-5-9.bin

SC6K-S7K9-8.5

8.5(9) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-9.bin

SC6K-S7CVK8-8.5

8.5(9) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-9.bin

SC6K-S7CVK9-8.5

8.5(8) Flash image

cat6000-sup720k8.8-5-8.bin

SC6K-S7K8-8.5

8.5(8) Flash image (Secure Shell)

cat6000-sup720k9.8-5-8.bin

SC6K-S7K9-8.5

8.5(8) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-8.bin

SC6K-S7CVK8-8.5

8.5(8) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-8.bin

SC6K-S7CVK9-8.5

8.5(7) Flash image

cat6000-sup720k8.8-5-7.bin

SC6K-S7K8-8.5

8.5(7) Flash image (Secure Shell)

cat6000-sup720k9.8-5-7.bin

SC6K-S7K9-8.5

8.5(7) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-7.bin

SC6K-S7CVK8-8.5

8.5(7) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-7.bin

SC6K-S7CVK9-8.5

8.5(6) Flash image

cat6000-sup720k8.8-5-6.bin

SC6K-S7K8-8.5

8.5(6) Flash image (Secure Shell)

cat6000-sup720k9.8-5-6.bin

SC6K-S7K9-8.5

8.5(6) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-6.bin

SC6K-S7CVK8-8.5

8.5(6) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-6.bin

SC6K-S7CVK9-8.5

8.5(5) Flash image

cat6000-sup720k8.8-5-5.bin

SC6K-S7K8-8.5

8.5(5) Flash image (Secure Shell)

cat6000-sup720k9.8-5-5.bin

SC6K-S7K9-8.5

8.5(5) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-5.bin

SC6K-S7CVK8-8.5

8.5(5) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-5.bin

SC6K-S7CVK9-8.5

8.5(4) Flash image

cat6000-sup720k8.8-5-4.bin

SC6K-S7K8-8.5

8.5(4) Flash image (Secure Shell)

cat6000-sup720k9.8-5-4.bin

SC6K-S7K9-8.5

8.5(4) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-4.bin

SC6K-S7CVK8-8.5

8.5(4) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-4.bin

SC6K-S7CVK9-8.5

8.5(3) Flash image

cat6000-sup720k8.8-5-3.bin

SC6K-S7K8-8.5

8.5(3) Flash image (Secure Shell)

cat6000-sup720k9.8-5-3.bin

SC6K-S7K9-8.5

8.5(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-3.bin

SC6K-S7CVK8-8.5

8.5(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-3.bin

SC6K-S7CVK9-8.5

8.5(2) Flash image

cat6000-sup720k8.8-5-2.bin

SC6K-S7K8-8.5

8.5(2) Flash image (Secure Shell)

cat6000-sup720k9.8-5-2.bin

SC6K-S7K9-8.5

8.5(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-5-2.bin

SC6K-S7CVK8-8.5

8.5(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-5-2.bin

SC6K-S7CVK9-8.5

8.5(1) Flash image2

cat6000-sup720k8.8-5-1.bin

SC6K-S7K8-8.5

8.5(1) Flash image (Secure Shell)

cat6000-sup720k9.8-5-1.bin

SC6K-S7K9-8.5

8.4(6) Flash image

cat6000-sup720k8.8-4-6.bin

SC6K-S7K8-8.4

8.4(6) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-6.bin

SC6K-S7CVK8-8.4

8.4(6) Flash image (Secure Shell)

cat6000-sup720k9.8-4-6.bin

SC6K-S7K9-8.4

8.4(6) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-6.bin

SC6K-S7CVK9-8.4

8.4(5) Flash image

cat6000-sup720k8.8-4-5.bin

SC6K-S7K8-8.4

8.4(5) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-5.bin

SC6K-S7CVK8-8.4

8.4(5) Flash image (Secure Shell)

cat6000-sup720k9.8-4-5.bin

SC6K-S7K9-8.4

8.4(5) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-5.bin

SC6K-S7CVK9-8.4

8.4(4) Flash image

cat6000-sup720k8.8-4-4.bin

SC6K-S7K8-8.4

8.4(4) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-4.bin

SC6K-S7CVK8-8.4

8.4(4) Flash image (Secure Shell)

cat6000-sup720k9.8-4-4.bin

SC6K-S7K9-8.4

8.4(4) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-4.bin

SC6K-S7CVK9-8.4

8.4(3) Flash image

cat6000-sup720k8.8-4-3.bin

SC6K-S7K8-8.4

8.4(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-3.bin

SC6K-S7CVK8-8.4

8.4(3) Flash image (Secure Shell)

cat6000-sup720k9.8-4-3.bin

SC6K-S7K9-8.4

8.4(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-3.bin

SC6K-S7CVK9-8.4

8.4(2a) Flash image

cat6000-sup720k8.8-4-2a.bin

SC6K-S7K8-8.4

8.4(2a) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-2a.bin

SC6K-S7CVK8-8.4

8.4(2a) Flash image (Secure Shell)

cat6000-sup720k9.8-4-2a.bin

SC6K-S7K9-8.4

8.4(2a) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-2a.bin

SC6K-S7CVK9-8.4

8.4(2) Flash image

cat6000-sup720k8.8-4-2.bin

SC6K-S7K8-8.4

8.4(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-2.bin

SC6K-S7CVK8-8.4

8.4(2) Flash image (Secure Shell)

cat6000-sup720k9.8-4-2.bin

SC6K-S7K9-8.4

8.4(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-2.bin

SC6K-S7CVK9-8.4

8.4(1) Flash image

cat6000-sup720k8.8-4-1.bin

SC6K-S7K8-8.4

8.4(1) Flash image (CiscoView)

cat6000-sup720cvk8.8-4-1.bin

SC6K-S7CVK8-8.4

8.4(1) Flash image (Secure Shell)

cat6000-sup720k9.8-4-1.bin

SC6K-S7K9-8.4

8.4(1) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-4-1.bin

SC6K-S7CVK9-8.4

8.3(7) Flash image

cat6000-sup720k8.8-3-7.bin

SC6K-S7K8-8.3

8.3(7) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-7.bin

SC6K-S7CVK8-8.3

8.3(7) Flash image (Secure Shell)

cat6000-sup720k9.8-3-7.bin

SC6K-S7K9-8.3

8.3(7) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-7.bin

SC6K-S7CVK9-8.3

8.3(6) Flash image

cat6000-sup720k8.8-3-6.bin

SC6K-S7K8-8.3

8.3(6) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-6.bin

SC6K-S7CVK8-8.3

8.3(6) Flash image (Secure Shell)

cat6000-sup720k9.8-3-6.bin

SC6K-S7K9-8.3

8.3(6) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-6.bin

SC6K-S7CVK9-8.3

8.3(5) Flash image

cat6000-sup720k8.8-3-5.bin

SC6K-S7K8-8.3

8.3(5) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-5.bin

SC6K-S7CVK8-8.3

8.3(5) Flash image (Secure Shell)

cat6000-sup720k9.8-3-5.bin

SC6K-S7K9-8.3

8.3(5) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-5.bin

SC6K-S7CVK9-8.3

8.3(4) Flash image

cat6000-sup720k8.8-3-4.bin

SC6K-S7K8-8.3

8.3(4) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-4.bin

SC6K-S7CVK8-8.3

8.3(4) Flash image (Secure Shell)

cat6000-sup720k9.8-3-4.bin

SC6K-S7K9-8.3

8.3(4) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-4.bin

SC6K-S7CVK9-8.3

8.3(3) Flash image

cat6000-sup720k8.8-3-3.bin

SC6K-S7K8-8.3

8.3(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-3.bin

SC6K-S7CVK8-8.3

8.3(3) Flash image (Secure Shell)

cat6000-sup720k9.8-3-3.bin

SC6K-S7K9-8.3

8.3(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-3.bin

SC6K-S7CVK9-8.3

8.3(2) Flash image

cat6000-sup720k8.8-3-2.bin

SC6K-S7K8-8.3

8.3(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-3-2.bin

SC6K-S7CVK8-8.3

8.3(2) Flash image (Secure Shell)

cat6000-sup720k9.8-3-2.bin

SC6K-S7K9-8.3

8.3(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-3-2.bin

SC6K-S7CVK9-8.3

8.3(1) Flash image³

cat6000-sup720k8.8-3-1.bin

SC6K-S7K8-8.3

8.3(1) Flash image (Secure Shell)

cat6000-sup720k9.8-3-1.bin

SC6K-S7K9-8.3

8.2(2) Flash image

cat6000-sup720k8.8-2-2.bin

SC6K-S7K8-8.2

8.2(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-2-2.bin

SC6K-S7CVK8-8.2

8.2(2) Flash image (Secure Shell)

cat6000-sup720k9.8-2-2.bin

SC6K-S7K9-8.2

8.2(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-2-2.bin

SC6K-S7CVK9-8.2

8.2(1) Flash image

cat6000-sup720k8.8-2-1.bin

SC6K-S7K8-8.2

8.2(1) Flash image (CiscoView)

cat6000-sup720cvk8.8-2-1.bin

SC6K-S7CVK8-8.2

8.2(1) Flash image (Secure Shell)

cat6000-sup720k9.8-2-1.bin

SC6K-S7K9-8.2

8.2(1) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-2-1.bin

SC6K-S7CVK9-8.2

8.1(3) Flash image

cat6000-sup720k8.8-1-3.bin

SC6K-S7K8-8.1

8.1(3) Flash image (CiscoView)

cat6000-sup720cvk8.8-1-3.bin

SC6K-S7CVK8-8.1

8.1(3) Flash image (Secure Shell)

cat6000-sup720k9.8-1-3.bin

SC6K-S7K9-8.1

8.1(3) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-1-3.bin

SC6K-S7CVK9-8.1

8.1(2) Flash image

cat6000-sup720k8.8-1-2.bin

SC6K-S7K8-8.1

8.1(2) Flash image (CiscoView)

cat6000-sup720cvk8.8-1-2.bin

SC6K-S7CVK8-8.1

8.1(2) Flash image (Secure Shell)

cat6000-sup720k9.8-1-2.bin

SC6K-S7K9-8.1

8.1(2) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-1-2.bin

SC6K-S7CVK9-8.1

8.1(1) Flash image

cat6000-sup720k8.8-1-1.bin

SC6K-S7K8-8.1.1

8.1(1) Flash image (CiscoView)

cat6000-sup720cvk8.8-1-1.bin

SC6K-S7CVK8-8.1.1

8.1(1) Flash image (Secure Shell)

cat6000-sup720k9.8-1-1.bin

SC6K-S7K9-8.1.1

8.1(1) Flash image (Secure Shell and CiscoView)

cat6000-sup720cvk9.8-1-1.bin

SC6K-S7CVK9-8.1.1

Supervisor Engine 2

8.6(4) Flash image

cat6000-sup2k8.8-6-4.bin

SC6K-SUP2K8-8.6

8.6(4) Flash image (Secure Shell)

cat6000-sup2k9.8-6-4.bin

SC6K-SUP2K9-8.6

8.6(4) Flash image (CiscoView)

cat6000-sup2cvk8.8-6-4.bin

SC6K-S2CVK8-8.6

8.6(4) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-6-4.bin

SC6K-S2CVK9-8.6

8.6(2) Flash image

cat6000-sup2k8.8-6-2.bin

SC6K-SUP2K8-8.6

8.6(2) Flash image (Secure Shell)

cat6000-sup2k9.8-6-2.bin

SC6K-SUP2K9-8.6

8.6(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-6-2.bin

SC6K-S2CVK8-8.6

8.6(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-6-2.bin

SC6K-S2CVK9-8.6

8.6(1) Flash image

cat6000-sup2k8.8-6-1.bin

SC6K-SUP2K8-8.6

8.6(1) Flash image (Secure Shell)

cat6000-sup2k9.8-6-1.bin

SC6K-SUP2K9-8.6

8.6(1) Flash image (CiscoView)

cat6000-sup2cvk8.8-6-1.bin

SC6K-S2CVK8-8.6

8.6(1) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-6-1.bin

SC6K-S2CVK9-8.6

8.5(9) Flash image

cat6000-sup2k8.8-5-9.bin

SC6K-SUP2K8-8.5

8.5(9) Flash image (Secure Shell)

cat6000-sup2k9.8-5-9.bin

SC6K-SUP2K9-8.5

8.5(9) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-9.bin

SC6K-S2CVK8-8.5

8.5(9) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-9.bin

SC6K-S2CVK9-8.5

8.5(8) Flash image

cat6000-sup2k8.8-5-8.bin

SC6K-SUP2K8-8.5

8.5(8) Flash image (Secure Shell)

cat6000-sup2k9.8-5-8.bin

SC6K-SUP2K9-8.5

8.5(8) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-8.bin

SC6K-S2CVK8-8.5

8.5(8) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-8.bin

SC6K-S2CVK9-8.5

8.5(7) Flash image

cat6000-sup2k8.8-5-7.bin

SC6K-SUP2K8-8.5

8.5(7) Flash image (Secure Shell)

cat6000-sup2k9.8-5-7.bin

SC6K-SUP2K9-8.5

8.5(7) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-7.bin

SC6K-S2CVK8-8.5

8.5(7) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-7.bin

SC6K-S2CVK9-8.5

8.5(6) Flash image

cat6000-sup2k8.8-5-6.bin

SC6K-SUP2K8-8.5

8.5(6) Flash image (Secure Shell)

cat6000-sup2k9.8-5-6.bin

SC6K-SUP2K9-8.5

8.5(6) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-6.bin

SC6K-S2CVK8-8.5

8.5(6) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-6.bin

SC6K-S2CVK9-8.5

8.5(5) Flash image

cat6000-sup2k8.8-5-5.bin

SC6K-SUP2K8-8.5

8.5(5) Flash image (Secure Shell)

cat6000-sup2k9.8-5-5.bin

SC6K-SUP2K9-8.5

8.5(5) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-5.bin

SC6K-S2CVK8-8.5

8.5(5) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-5.bin

SC6K-S2CVK9-8.5

8.5(4) Flash image

cat6000-sup2k8.8-5-4.bin

SC6K-SUP2K8-8.5

8.5(4) Flash image (Secure Shell)

cat6000-sup2k9.8-5-4.bin

SC6K-SUP2K9-8.5

8.5(4) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-4.bin

SC6K-S2CVK8-8.5

8.5(4) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-4.bin

SC6K-S2CVK9-8.5

8.5(3) Flash image

cat6000-sup2k8.8-5-3.bin

SC6K-SUP2K8-8.5

8.5(3) Flash image (Secure Shell)

cat6000-sup2k9.8-5-3.bin

SC6K-SUP2K9-8.5

8.5(3) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-3.bin

SC6K-S2CVK8-8.5

8.5(3) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-3.bin

SC6K-S2CVK9-8.5

8.5(2) Flash image

cat6000-sup2k8.8-5-2.bin

SC6K-SUP2K8-8.5

8.5(2) Flash image (Secure Shell)

cat6000-sup2k9.8-5-2.bin

SC6K-SUP2K9-8.5

8.5(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-5-2.bin

SC6K-S2CVK8-8.5

8.5(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-5-2.bin

SC6K-S2CVK9-8.5

8.5(1) Flash image2

cat6000-sup2k8.8-5-1.bin

SC6K-SUP2K8-8.5

8.5(1) Flash image (Secure Shell)

cat6000-sup2k9.8-5-1.bin

SC6K-SUP2K9-8.5

8.4(6) Flash image

cat6000-sup2k8.8-4-6.bin

SC6K-SUP2K8-8.4

8.4(6) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-6.bin

SC6K-S2CVK8-8.4

8.4(6) Flash image (Secure Shell)

cat6000-sup2k9.8-4-6.bin

SC6K-SUP2K9-8.4

8.4(6) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-6.bin

SC6K-S2CVK9-8.4

8.4(5) Flash image

cat6000-sup2k8.8-4-5.bin

SC6K-SUP2K8-8.4

8.4(5) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-5.bin

SC6K-S2CVK8-8.4

8.4(5) Flash image (Secure Shell)

cat6000-sup2k9.8-4-5.bin

SC6K-SUP2K9-8.4

8.4(5) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-5.bin

SC6K-S2CVK9-8.4

8.4(4) Flash image

cat6000-sup2k8.8-4-4.bin

SC6K-SUP2K8-8.4

8.4(4) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-4.bin

SC6K-S2CVK8-8.4

8.4(4) Flash image (Secure Shell)

cat6000-sup2k9.8-4-4.bin

SC6K-SUP2K9-8.4

8.4(4) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-4.bin

SC6K-S2CVK9-8.4

8.4(3) Flash image

cat6000-sup2k8.8-4-3.bin

SC6K-SUP2K8-8.4

8.4(3) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-3.bin

SC6K-S2CVK8-8.4

8.4(3) Flash image (Secure Shell)

cat6000-sup2k9.8-4-3.bin

SC6K-SUP2K9-8.4

8.4(3) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-3.bin

SC6K-S2CVK9-8.4

8.4(2a) Flash image

cat6000-sup2k8.8-4-2a.bin

SC6K-SUP2K8-8.4

8.4(2a) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-2a.bin

SC6K-S2CVK8-8.4

8.4(2a) Flash image (Secure Shell)

cat6000-sup2k9.8-4-2a.bin

SC6K-SUP2K9-8.4

8.4(2a) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-2a.bin

SC6K-S2CVK9-8.4

8.4(2) Flash image

cat6000-sup2k8.8-4-2.bin

SC6K-SUP2K8-8.4

8.4(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-2.bin

SC6K-S2CVK8-8.4

8.4(2) Flash image (Secure Shell)

cat6000-sup2k9.8-4-2.bin

SC6K-SUP2K9-8.4

8.4(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-2.bin

SC6K-S2CVK9-8.4

8.4(1) Flash image

cat6000-sup2k8.8-4-1.bin

SC6K-SUP2K8-8.4

8.4(1) Flash image (CiscoView)

cat6000-sup2cvk8.8-4-1.bin

SC6K-S2CVK8-8.4

8.4(1) Flash image (Secure Shell)

cat6000-sup2k9.8-4-1.bin

SC6K-SUP2K9-8.4

8.4(1) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-4-1.bin

SC6K-S2CVK9-8.4

8.3(7) Flash image

cat6000-sup2k8.8-3-7.bin

SC6K-SUP2K8-8.3

8.3(7) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-7.bin

SC6K-S2CVK8-8.3

8.3(7) Flash image (Secure Shell)

cat6000-sup2k9.8-3-7.bin

SC6K-SUP2K9-8.3

8.3(7) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-7.bin

SC6K-S2CVK9-8.3

8.3(6) Flash image

cat6000-sup2k8.8-3-6.bin

SC6K-SUP2K8-8.3

8.3(6) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-6.bin

SC6K-S2CVK8-8.3

8.3(6) Flash image (Secure Shell)

cat6000-sup2k9.8-3-6.bin

SC6K-SUP2K9-8.3

8.3(6) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-6.bin

SC6K-S2CVK9-8.3

8.3(5) Flash image

cat6000-sup2k8.8-3-5.bin

SC6K-SUP2K8-8.3

8.3(5) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-5.bin

SC6K-S2CVK8-8.3

8.3(5) Flash image (Secure Shell)

cat6000-sup2k9.8-3-5.bin

SC6K-SUP2K9-8.3

8.3(5) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-5.bin

SC6K-S2CVK9-8.3

8.3(4) Flash image

cat6000-sup2k8.8-3-4.bin

SC6K-SUP2K8-8.3

8.3(4) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-4.bin

SC6K-S2CVK8-8.3

8.3(4) Flash image (Secure Shell)

cat6000-sup2k9.8-3-4.bin

SC6K-SUP2K9-8.3

8.3(4) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-4.bin

SC6K-S2CVK9-8.3

8.3(3) Flash image

cat6000-sup2k8.8-3-3.bin

SC6K-SUP2K8-8.3

8.3(3) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-3.bin

SC6K-S2CVK8-8.3

8.3(3) Flash image (Secure Shell)

cat6000-sup2k9.8-3-3.bin

SC6K-SUP2K9-8.3

8.3(3) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-3.bin

SC6K-S2CVK9-8.3

8.3(2) Flash image

cat6000-sup2k8.8-3-2.bin

SC6K-SUP2K8-8.3

8.3(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-3-2.bin

SC6K-S2CVK8-8.3

8.3(2) Flash image (Secure Shell)

cat6000-sup2k9.8-3-2.bin

SC6K-SUP2K9-8.3

8.3(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-3-2.bin

SC6K-S2CVK9-8.3

8.3(1) Flash image3

cat6000-sup2k8.8-3-1.bin

SC6K-SUP2K8-8.3

8.3(1) Flash image (Secure Shell)

cat6000-sup2k9.8-3-1.bin

SC6K-SUP2K9-8.3

8.2(2) Flash image

cat6000-sup2k8.8-2-2.bin

SC6K-SUP2K8-8.2

8.2(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-2-2.bin

SC6K-S2CVK8-8.2

8.2(2) Flash image (Secure Shell)

cat6000-sup2k9.8-2-2.bin

SC6K-SUP2K9-8.2

8.2(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-2-2.bin

SC6K-S2CVK9-8.2

8.2(1) Flash image

cat6000-sup2k8.8-2-1.bin

SC6K-SUP2K8-8.2

8.2(1) Flash image (CiscoView)

cat6000-sup2cvk8.8-2-1.bin

SC6K-S2CVK8-8.2

8.2(1) Flash image (Secure Shell)

cat6000-sup2k9.8-2-1.bin

SC6K-SUP2K9-8.2

8.2(1) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-2-1.bin

SC6K-S2CVK9-8.2

8.1(3) Flash image

cat6000-sup2k8.8-1-3.bin

SC6K-SUP2K8-8.1

8.1(3) Flash image (CiscoView)

cat6000-sup2cvk8.8-1-3.bin

SC6K-S2CVK8-8.1

8.1(3) Flash image (Secure Shell)

cat6000-sup2k9.8-1-3.bin

SC6K-SUP2K9-8.1

8.1(3) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-1-3.bin

SC6K-S2CVK9-8.1

8.1(2) Flash image

cat6000-sup2k8.8-1-2.bin

SC6K-SUP2K8-8.1

8.1(2) Flash image (CiscoView)

cat6000-sup2cvk8.8-1-2.bin

SC6K-S2CVK8-8.1

8.1(2) Flash image (Secure Shell)

cat6000-sup2k9.8-1-2.bin

SC6K-SUP2K9-8.1

8.1(2) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-1-2.bin

SC6K-S2CVK9-8.1

8.1(1) Flash image

cat6000-sup2k8.8-1-1.bin

SC6K-SUP2K8-8.1.1

8.1(1) Flash image (CiscoView)

cat6000-sup2cvk8.8-1-1.bin

SC6K-S2CVK8-8.1.1

8.1(1) Flash image (Secure Shell)

cat6000-sup2k9.8-1-1.bin

SC6K-SUP2K9-8.1.1

8.1(1) Flash image (Secure Shell and CiscoView)

cat6000-sup2cvk9.8-1-1.bin

SC6K-S2CVK9-8.1.1

Supervisor Engine 1

8.5(3) Flash image

cat6000-supk8.8-5-3.bin

SC6K-SUPK8-8.5

8.5(3) Flash image (Secure Shell)

cat6000-supk9.8-5-3.bin

SC6K-SUPK9-8.5

8.5(3) Flash image (CiscoView)

cat6000-supcvk8.8-5-3.bin

SC6K-SCVK8-8.5

8.5(3) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-5-3.bin

SC6K-SCVK9-8.5

8.5(2) Flash image

cat6000-supk8.8-5-2.bin

SC6K-SUPK8-8.5

8.5(2) Flash image (Secure Shell)

cat6000-supk9.8-5-2.bin

SC6K-SUPK9-8.5

8.5(2) Flash image (CiscoView)

cat6000-supcvk8.8-5-2.bin

SC6K-SCVK8-8.5

8.5(2) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-5-2.bin

SC6K-SCVK9-8.5

8.5(1) Flash image2

cat6000-supk8.8-5-1.bin

SC6K-SUPK8-8.5

8.5(1) Flash image (Secure Shell)

cat6000-supk9.8-5-1.bin

SC6K-SUPK9-8.5

8.4(6) Flash image

cat6000-supk8.8-4-6.bin

SC6K-SUPK8-8.4

8.4(6) Flash image (CiscoView)

cat6000-supcvk8.8-4-6.bin

SC6K-SCVK8-8.4

8.4(6) Flash image (Secure Shell)

cat6000-supk9.8-4-6.bin

SC6K-SUPK9-8.4

8.4(6) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-6.bin

SC6K-SCVK9-8.4

8.4(5) Flash image

cat6000-supk8.8-4-5.bin

SC6K-SUPK8-8.4

8.4(5) Flash image (CiscoView)

cat6000-supcvk8.8-4-5.bin

SC6K-SCVK8-8.4

8.4(5) Flash image (Secure Shell)

cat6000-supk9.8-4-5.bin

SC6K-SUPK9-8.4

8.4(5) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-5.bin

SC6K-SCVK9-8.4

8.4(4) Flash image

cat6000-supk8.8-4-4.bin

SC6K-SUPK8-8.4

8.4(4) Flash image (CiscoView)

cat6000-supcvk8.8-4-4.bin

SC6K-SCVK8-8.4

8.4(4) Flash image (Secure Shell)

cat6000-supk9.8-4-4.bin

SC6K-SUPK9-8.4

8.4(4) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-4.bin

SC6K-SCVK9-8.4

8.4(3) Flash image

cat6000-supk8.8-4-3.bin

SC6K-SUPK8-8.4

8.4(3) Flash image (CiscoView)

cat6000-supcvk8.8-4-3.bin

SC6K-SCVK8-8.4

8.4(3) Flash image (Secure Shell)

cat6000-supk9.8-4-3.bin

SC6K-SUPK9-8.4

8.4(3) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-3.bin

SC6K-SCVK9-8.4

8.4(2a) Flash image

cat6000-supk8.8-4-2a.bin

SC6K-SUPK8-8.4

8.4(2a) Flash image (CiscoView)

cat6000-supcvk8.8-4-2a.bin

SC6K-SCVK8-8.4

8.4(2a) Flash image (Secure Shell)

cat6000-supk9.8-4-2a.bin

SC6K-SUPK9-8.4

8.4(2a) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-2a.bin

SC6K-SCVK9-8.4

8.4(2) Flash image

cat6000-supk8.8-4-2.bin

SC6K-SUPK8-8.4

8.4(2) Flash image (CiscoView)

cat6000-supcvk8.8-4-2.bin

SC6K-SCVK8-8.4

8.4(2) Flash image (Secure Shell)

cat6000-supk9.8-4-2.bin

SC6K-SUPK9-8.4

8.4(2) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-2.bin

SC6K-SCVK9-8.4

8.4(1) Flash image

cat6000-supk8.8-4-1.bin

SC6K-SUPK8-8.4

8.4(1) Flash image (CiscoView)

cat6000-supcvk8.8-4-1.bin

SC6K-SCVK8-8.4

8.4(1) Flash image (Secure Shell)

cat6000-supk9.8-4-1.bin

SC6K-SUPK9-8.4

8.4(1) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-4-1.bin

SC6K-SCVK9-8.4

8.3(7) Flash image

cat6000-supk8.8-3-7.bin

SC6K-SUPK8-8.3

8.3(7) Flash image (CiscoView)

cat6000-supcvk8.8-3-7.bin

SC6K-SCVK8-8.3

8.3(7) Flash image (Secure Shell)

cat6000-supk9.8-3-7.bin

SC6K-SUPK9-8.3

8.3(7) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-7.bin

SC6K-SCVK9-8.3

8.3(6) Flash image

cat6000-supk8.8-3-6.bin

SC6K-SUPK8-8.3

8.3(6) Flash image (CiscoView)

cat6000-supcvk8.8-3-6.bin

SC6K-SCVK8-8.3

8.3(6) Flash image (Secure Shell)

cat6000-supk9.8-3-6.bin

SC6K-SUPK9-8.3

8.3(6) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-6.bin

SC6K-SCVK9-8.3

8.3(5) Flash image

cat6000-supk8.8-3-5.bin

SC6K-SUPK8-8.3

8.3(5) Flash image (CiscoView)

cat6000-supcvk8.8-3-5.bin

SC6K-SCVK8-8.3

8.3(5) Flash image (Secure Shell)

cat6000-supk9.8-3-5.bin

SC6K-SUPK9-8.3

8.3(5) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-5.bin

SC6K-SCVK9-8.3

8.3(4) Flash image

cat6000-supk8.8-3-4.bin

SC6K-SUPK8-8.3

8.3(4) Flash image (CiscoView)

cat6000-supcvk8.8-3-4.bin

SC6K-SCVK8-8.3

8.3(4) Flash image (Secure Shell)

cat6000-supk9.8-3-4.bin

SC6K-SUPK9-8.3

8.3(4) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-4.bin

SC6K-SCVK9-8.3

8.3(3) Flash image

cat6000-supk8.8-3-3.bin

SC6K-SUPK8-8.3

8.3(3) Flash image (CiscoView)

cat6000-supcvk8.8-3-3.bin

SC6K-SCVK8-8.3

8.3(3) Flash image (Secure Shell)

cat6000-supk9.8-3-3.bin

SC6K-SUPK9-8.3

8.3(3) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-3.bin

SC6K-SCVK9-8.3

8.3(2) Flash image

cat6000-supk8.8-3-2.bin

SC6K-SUPK8-8.3

8.3(2) Flash image (CiscoView)

cat6000-supcvk8.8-3-2.bin

SC6K-SCVK8-8.3

8.3(2) Flash image (Secure Shell)

cat6000-supk9.8-3-2.bin

SC6K-SUPK9-8.3

8.3(2) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-3-2.bin

SC6K-SCVK9-8.3

8.3(1) Flash image3

cat6000-supk8.8-3-1.bin

SC6K-SUPK8-8.3

8.3(1) Flash image (Secure Shell)

cat6000-supk9.8-3-1.bin

SC6K-SUPK9-8.3

8.2(2) Flash image

cat6000-supk8.8-2-2.bin

SC6K-SUPK8-8.2

8.2(2) Flash image (CiscoView)

cat6000-supcvk8.8-2-2.bin

SC6K-SCVK8-8.2

8.2(2) Flash image (Secure Shell)

cat6000-supk9.8-2-2.bin

SC6K-SUPK9-8.2

8.2(2) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-2-2.bin

SC6K-SCVK9-8.2

8.2(1) Flash image

cat6000-supk8.8-2-1.bin

SC6K-SUPK8-8.2

8.2(1) Flash image (CiscoView)

cat6000-supcvk8.8-2-1.bin

SC6K-SCVK8-8.2

8.2(1) Flash image (Secure Shell)

cat6000-supk9.8-2-1.bin

SC6K-SUPK9-8.2

8.2(1) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-2-1.bin

SC6K-SCVK9-8.2

8.1(3) Flash image

cat6000-supk8.8-1-3.bin

SC6K-SUPK8-8.1

8.1(3) Flash image (CiscoView)

cat6000-supcvk8.8-1-3.bin

SC6K-SCVK8-8.1

8.1(3) Flash image (Secure Shell)

cat6000-supk9.8-1-3.bin

SC6K-SUPK9-8.1

8.1(3) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-1-3.bin

SC6K-SCVK9-8.1

8.1(2) Flash image

cat6000-supk8.8-1-2.bin

SC6K-SUPK8-8.1

8.1(2) Flash image (CiscoView)

cat6000-supcvk8.8-1-2.bin

SC6K-SCVK8-8.1

8.1(2) Flash image (Secure Shell)

cat6000-supk9.8-1-2.bin

SC6K-SUPK9-8.1

8.1(2) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-1-2.bin

SC6K-SCVK9-8.1

8.1(1) Flash image

cat6000-supk8.8-1-1.bin

SC6K-SUPK8-8.1.1

8.1(1) Flash image (CiscoView)

cat6000-supcvk8.8-1-1.bin

SC6K-SCVK8-8.1.1

8.1(1) Flash image (Secure Shell)

cat6000-supk9.8-1-1.bin

SC6K-SUPK9-8.1.1

8.1(1) Flash image (Secure Shell and CiscoView)

cat6000-supcvk9.8-1-1.bin

SC6K-SCVK9-8.1.1

¹Installed on system; append with "=" for spare on floppy media.

²There are no CiscoView images in software release 8.5(1). CiscoView images are scheduled for software release 8.5(2).

³There are no CiscoView images in software release 8.3(1). CiscoView images are scheduled for software release 8.3(2).

Software Image Version Compatibility

With high-availability versioning enabled, you can have two different but compatible images on the active and standby supervisor engines. The active supervisor engine exchanges image version information with the standby supervisor engine and determines whether the images are compatible for enabling high availability. If the active and standby supervisor engines are not running compatible image versions, you cannot enable high availability.

Image versioning is supported in supervisor engine software releases 5.4(1) and later. With versioning enabled, high availability is fully supported with the active and standby supervisor engines running different images as long as the images are compatible. The only fully compatible images are as follows:

Note There is no software image version compatibility in the 8.x software release train. This includes major releases such as 8.1(x) to 8.2(x) to 8.3(x) and so on. This also includes subreleases such as 8.1(1) to 8.1(2), 8.2(1) to 8.2(2) and so on.

•Supervisor Engine 1

–5.5(3) and 5.5(4)

–6.1(3) and 6.1(4)

–6.2(2) and 6.2(3)

–6.3(2) and 6.3(3)

–6.3(4) and 6.3(5)

–6.3(6) and 6.3(7)

•Supervisor Engine 2

–6.1(3) and 6.1(4)

–6.2(2) and 6.2(3)

–6.3(2) and 6.3(3)

Images that are compatible with all modules except Gigabit Ethernet switching modules are as follows:

•Supervisor Engine 1

–5.4(3) and 5.4(4)

–5.5(3) and 5.5(5)

–5.5(4) and 5.5(5)

Images that are compatible with Gigabit Ethernet switching modules but not compatible with 10/100BASE-T modules are as follows:

•Supervisor Engine 1

–5.5(6a) and 5.5(7)

Images that are compatible with all modules except the SFM/SFM2 and fabric-enabled modules are as follows:

•Supervisor Engine 2

–6.3(4) and 6.3(5)

–6.3(6) and 6.3(7)

Note Attempting to run incompatible image versions could result in configuration loss.

Catalyst 6500 Series Features

Note For complete hardware requirements for the software features listed, see the Catalyst 6500 Series Software Configuration Guides.

These sections describe the Catalyst 6500 series features:

•Features for Supervisor Engine Software Release 8.7

•Features for Supervisor Engine Software Release 8.6

•Features for Supervisor Engine Software Release 8.5

•Features for Supervisor Engine Software Release 8.4

•Features for Supervisor Engine Software Release 8.3

•Features for Supervisor Engine Software Release 8.2

•Features for Supervisor Engine Software Release 8.1

•Features for Supervisor Engine Software Releases 7.1 Through 7.6

•Features for Supervisor Engine Software Releases 6.1 Through 6.4

•Features for Supervisor Engine Software Releases 5.1 Through 5.5

Features for Supervisor Engine Software Release 8.7

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.7, 23 April 2008:

•Software Release 8.7 Hardware Features

•Software Release 8.7 Software Features

•Software Release 8.7 Unsupported Software Features

Software Release 8.7 Hardware Features

Software release 8.7 provides support for these hardware features:

•A 512-MB CompactFlash memory card on Supervisor Engine 720 with a Melody adapter card.

•LR+/ER+ XENPAKs with DOM support.

Software Release 8.7 Software Features

Software release 8.7 provides support for the following software features:

•IEEE 802.1ag draft 8.0 Metro Ethernet Connectivity Fault Management (CFM) Protocol. CFM incorporates several OAM facilities that allow you to manage Metro Ethernet networks, including an Ethernet continuity check, an end-to-end Ethernet traceroute, a Link Trace Message (LTM), a Loopback Message (LBM), and a Loopback Reply (LBR). These Metro Ethernet CFM elements allow you to identify problems in your network. This protocol replaces IEEE 802.1: 802.1ag-Connectivity Fault Management protocol.

•Ethernet Local Management Protocol (ELMI). The ELMI protocols are as follows:

1. Ethernet Virtual Connections (EVC).

2. Ethernet Local Management Interface (ELMI).

•The Ethernet Alarm Indication function (ETH-AIS) and the Ethernet Remote Defect Indication (ETH-RDI) are new functional extensions to Metro Ethernet Connectivity Fault Management (CFM). The ETH-AIS is a standard defined by ITU Y.1731 and the ETH-RDI is part of IEEE 802.1ag. AIS-RDI works together to help reduce the management complexity of large SPAN networks and multiple constituent networks that belong to separate organizations.

•IEEE 802.1ak Multiple VLAN Registration Protocol (MVRP).

This protocol replaces GVRP in VLAN pruning and dynamic VLAN creation on trunk ports with faster and smaller transmissions, and extends support to larger networks and 4k (4094) VLANs.

1. MVRP default timers need to be tuned appropriately for a high number of VLANs. MVRP is a CPU-intensive protocol that requires an adequate processing interval between PDUs for processing a high number of VLAN states.

2. MVRP does not support Flex link.

3. MVRP does not interoperate with L2PT.

•Agentless Hosts Audit Support with MAB

This feature facilitates NAC auditing for agentless hosts with MAB- enabled NAD ports using external audit servers.

•QoS and Security ACL assignment with MAB

MAB-enabled ports support ACL assignments similar to 802.1X-enabled ports.

•IP Device Tracking (Host Aging using MAB)

This feature tracks the existence of the host and removes aged entries in the CAM table, which ensure that the hosts are removed from the EARL.

•MAC Utilization Rate

This feature displays the packet rate, bit rate, and octet rate per port, per module, and per VLAN, based on the load interval that can be specified.

•MAC Duplication Indicator

This feature displays an indicator (&) next to the MAC entries that appear more than once in the CAM table.

•Mini Protocol Analyzer Enhancements

The Mini Protocol Analyzer Enhancements also capture double tagged frames on dot1qtunnel, PAgP and LACP channel ports, and RFI Link Fault Recovery (OAM Enhancements).

•This feature changes the port to the blocking state when a remote link failure is encountered and then automatically changes the port to forwarding state whenever the remote link becomes operational.

Software Release 8.7 Unsupported Software Features

This section lists the unsupported software features in software release 8.7(x):

•IEEE P802.1ag/D1 Draft Standard for the Local and Metropolitan Area Networks is not supported.

•IEEE P802.1ag/D1 to Draft 8.1 interoperability is not supported.

•Change in channel configuration is not supported with Connectivity Fault Management (CFM) enabled.

•PVST+ simulation with CFM enabled is not supported.

•VTP pruning interoperability with MVRP is not supported.

Features for Supervisor Engine Software Release 8.6

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

The following sections describe the features in software release 8.6, 28 February 2007:

•Software Release 8.6 Hardware Features

•Software Release 8.6 Software Features

•Software Release 8.6 Unsupported Software Features

Software Release 8.6 Hardware Features

There are no new hardware features in software release 8.6(x).

Software Release 8.6 Software Features

Software release 8.6 provides support for the following software features:

•Policy-Based Forwarding (PBF) macro enhancement

The PBF macro enhancement feature stores macros that were are to create security and adjacency ACLs associated with PBF clients, gateways, and maps in a switch configuration. The set pbf macro commands are included in the output of show config and related commands.

•IEEE 802.1ag Ethernet OAM CFM

This protocol provides end-to-end Ethernet connectivity fault management.

•Mini Protocol Analyzer

The Mini Protocol Analyzer captures data and control traffic in a flash file that can be read offline using an ethereal client for analysis and troubleshooting purposes.

•Digital Optical Monitoring (DOM)

This feature monitors optical power and related information for SFP, GBIC, and XENPAK modules.

•Additional QoS statistics

This feature provides peak/maximum QoS statistics for a specified time interval.

•Bridge learning MAC move counters

This feature provides a running count of how many times MACs move from one port to another within a VLAN.

•Show port per VLAN

This feature displays all ports in a specific VLAN.

•Topology change in show spantree

This feature provides the addition of topology change information to show spantree command output. This includes the number of topology changes, the last topology change, the initiator of a topology change, and the time of topology changes.

•Downloadable ACLs with 802.1X and webauth

This feature provides the ability to define per-user ACLs in a central location on the AAA server and have the ACLs downloaded on the switch port to enforce access control on the port.

•802.1X with PVLAN

This feature provides the ability to use 802.1X on private VLAN ports.

•NAC LAN Port 802.1X enhancements

This feature provides support for non-responsive devices (those without Cisco Trust Agents). All the features of LAN port 802.1X are available for these devices.

•Inaccessible authentication bypass (IAB)

This feature provides MAC authentication bypass enhancements and web authentication bypass for IAB.

•NAC LAN port IP enhancements

This feature provides support for non-responsive or exception devices and URL redirects.

•DAI enhancements

This feature adds PACLs that co-exist with dynamic ARP inspection and increase the limit for the maximum number of hosts that can be supported on a port.

•SCP w/SSHv2

This feature upgrades SCP so that it can use SSHv2 for enhanced security.

•SFTP w/SSHv2

This feature upgrades SFTP to use SSHv2 for enhanced security.

Software Release 8.6 Unsupported Software Features

This section lists the unsupported software features in software release 8.6(x):

•IEEE 802.1ad provider bridge

•MRP

•CAM use optimization

•MAC age timeout statistics

•Per VLAN MAC address limiting

•MAC utilization rate

•Counters for unknown frames

•HTTPS transport for web authorization proxy

Features for Supervisor Engine Software Release 8.5

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.5, 25 October 2005:

•Software Release 8.5 Hardware Features

•Software Release 8.5 Software Features

•Software Release 8.5 Unsupported Software Features

Software Release 8.5 Hardware Features

Software release 8.5 provides initial support for these modules and chassis:

•FlexWAN2—enhanced FlexWAN module (WS-X6582-2PA)

•Inline power daughter card (WS-F6K-48-AF)

•ZR XENPAK—10GBASE-ZR XENPAK transceiver module for SMF, 1550-nm wavelength, SC connector (XENPAK-10GE-ZR)

•Dense Wavelength Division Multiplexing (DWDM) XENPAK

Software Release 8.5 Software Features

Software release 8.5 provides support for these software features:

•NAC - L2 IP:

Network Admission Control (NAC) L2 IP extends NAC support to Layer 2 switches and is intended to be deployed on Layer 2 Ethernet access ports at the network edge. The device to be validated must be attached to the Layer 2 port within the first Layer 3 hop. NAC L2 IP does not require 802.1X support on the hosts. Performing posture validation at the edge maximizes the portion of the network that is protected by the access control, and allows posture validation to be performed within a VLAN. NAC - L2 IP acts at the same point in the network as the NAC - L2 IEEE 802.1X feature, but uses different mechanisms to initiate posture validation, to carry the communication between host and authentication server, and to enforce the resulting access limitations.

•NAC - L2 IEEE 802.1X:

NAC L2 IEEE 802.1X extends NAC support to Layer 2 switches and wireless access points. Combining it with 802.1X provides a unified authentication and posture validation mechanism at the Layer 2 network edge. This helps protect the network from attack by machines with an insufficient antivirus posture. Performing posture validation at the edge maximizes the portion of the network that is protected and allows posture validation to be performed within a VLAN.

•Web Authentication Proxy:

Web-based authentication proxy is an HTTP-based authentication mechanism that allows clients that do not support the 802.1X supplicant functionality to integrate into the Cisco Identity Based Networking Services (IBNS) and NAC strategy using a standard web browser. This feature addresses network environments in which a supplicant code is not available for the given client platform, and environments in which the configuration of the end client is not under administrative control (where the installation and use of an IEEE 802.1X supplicant cannot be enforced despite its availability) and yet controlled access to the network is desired.

•IEEE 802.1X - Inaccessible Authentication Bypass:

On an 802.1X-enabled port, if a device fails authentication because access to the back-end authentication server is not available, the port is denied network access. Inaccessible authentication bypass allows network access to critical user-designated servers when access to the back-end authentication server is not available.

•MAC Authentication Bypass:

MAC authentication bypass is a MAC address-based authentication mechanism that allows clients that do not support the 802.1X supplicant functionality to integrate into the Cisco Identity Based Networking Services (IBNS) and NAC strategy using the client MAC address. MAC authentication bypass addresses network environments in which a supplicant code is not available for a given client platform and environments in which the configuration of the end client is not under administrative control (where the installation and use of an IEEE 802.1X supplicant cannot be enforced despite its availability) and yet controlled access to the network is desired.

•GOLD - Generic Online Diagnostics:

GOLD implements a number of health checks both at system startup and while the system is running. GOLD runs in the background and complements the high-availability features, such as NSF/SSO, alerting them if a disruption occurs. GOLD provides a variety of diagnostic tests; some tests run nonintrusively in the background while other tests can be triggered on demand.

•IEEE 802.3ah Ethernet OAM - Operations Administration and Maintenance:

Support for Ethernet OAM refers to a suite of tools designed to install, monitor, and troubleshoot Ethernet networks. Ethernet OAM relies on a new sublayer in the data link layer to provide a way to assist in detecting failing links or fault conditions. This feature provides some key capabilities that enable you to monitor the health of the network and pinpoint the location of the failing links.

•Flex Links:

Flex links are a pair of Layer 2 interfaces (switch ports or port channels) configured to act as a backup to another Layer 2 interface. Flex links provide an alternative solution to the Spanning Tree Protocol (STP), allowing you to turn off STP and still provide basic link redundancy.

•SmartPorts - Customizable Configuration:

Provides you with a convenient way to save and share common, customizable configurations. It extends the functionality of both SmartPorts and the set alias command by providing a way to define and name a macro and associate one or more commands to that macro. You create a macro using a CLI command and then enter a list of commands that are part of that macro.

•Text Configuration Mode Optimization:

Reduces the amount of time required for the system to boot up when you use the text configuration mode. This enhancement ensures that downtime, planned or otherwise, will be shorter.

•Firewall Autostate Capability:

The existing autostate feature has been extended as part of this enhancement to add the capability to inform the FWSM when either the first or last port has joined or left a VLAN assigned to that FWSM, excluding the FWSM port channel and trunk port to the MSFC. The FWSM responds to a VLAN down condition by marking the interfaces associated with that VLAN as "Autostate Down." An interface marked as "Autostate Down" is considered a failed interface for purposes of interface-monitoring health status and may cause a failover if the interface-policy threshold is met.

•WCCP:

The Web Cache Communication Protocol (WCCP) is a Cisco-developed content-routing technology that allows you to integrate cache engines (such as the Cisco Cache Engine 550) into your network infrastructure.

Software Release 8.5 Unsupported Software Features

This section lists the unsupported software features in software release 8.5(x):

•The following QoS features and the commands that are used to configure them are not supported in a system with a Supervisor Engine 720 in software release 8.5(x):

–RSVP

–COPS

–NBAR

Features for Supervisor Engine Software Release 8.4

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.4, 29 December 2004:

•Software Release 8.4 Hardware Features

•Software Release 8.4 Software Features

•Software Release 8.4 Unsupported Software Features

Software Release 8.4 Hardware Features

Software release 8.4 provides initial support for these modules and chassis:

•Supervisor Engine 32 (WS-SUP32-GE-3B) with PFC3B and MSFC2A

•6000 W power supply (WS-CAC-6000W)

Supported in all Catalyst 65xx and Catalyst 65xx-E chassis except for the 6503 and 6503-E (form-factor difference). Only the 6513 and -E chassis support the full 6000 W; the other chassis rely on software to current limit the power supply.

•2700 W power supply (PWR-2700-AC, PWR-2700-DC)

Supported in the Cisco 7606 chassis. Cannot be used in the 65xx chassis.

•Catalyst 6500 E-series chassis enhancements

Enhanced power capacity allowing higher-powered modules to be installed (including PoE support for 30 W per-port devices). Additionally, support for the 67xx switching modules in the 6503-E chassis is provided with software release 8.4(1) and later releases.

•WS-X6148A-GE-TX, WS-X6148A-GE-45AF

48-port 10/100/1000BASE-T, RJ-45 connectors. WS-X6148A-GE-45AF provides inline power for IP telephones with the WS-F6K-GE48-AF daughter card.

•WS-X6148-FE-SFP

48-port 100FX Ethernet, requires SFPs. The following SFPs are introduced with the WS-X6148-FE-SFP module:

–GLC-FE-100FX (100BASE-FX SFP)

–GLC-FE-100LX (100BASE-LX SFP)

–GLC-FE-100BX-U, GLC-FE-100BX-D (100BASE-BX SFP)

•WS-X6148A-RJ-45, WS-X6148A-45AF

48-port 10/100BASE-TX, RJ-45 connectors. WS-X6148A-45AF provides inline power for IP telephones with the WS-F6K-GE48-AF daughter card.

•WS-X6196-RJ-21, WS-X6196-21AF

96-port 10/100BASE-TX, RJ-21 connectors. WS-X6196-21AF provides inline power for IP telephones with the WS-F6K-FE48X2-AF daughter card.

•1000BASE-BX SFP (GLC-BX-1310, GLC-BX-1490)

•4-slot 6504-E chassis (WS-C6504-E) (Supported in software release 8.4(2) and later releases.)

Software Release 8.4 Software Features

Software release 8.4 provides support for these software features:

•EtherChannel enhancements:

Provides for an automatic failover of traffic from one port in an EtherChannel to another port in the same EtherChannel when one of the ports in the channel exceeds a configurable error threshold within the specified interval. The port failover only occurs if there is an operational port left in the EtherChannel. If the failed port is the last port in the EtherChannel, the port does not enter the "port failover" state and continues to pass traffic regardless of the type of errors being received. Single, nonchanneling ports do not go into the port failover state; these ports go into the errdisable state when the error threshold is exceeded within the specified interval.

•VLAN translation:

VLAN mapping has been enhanced to allow you to map any type of VLAN to any other type of VLAN without any VLAN range restrictions. VLAN mapping is now configurable on a per-port or per-ASIC basis.

•MAC-based ACLs:

PFC3B and PFC3BXL allow the ACL lookups on all packet types using the MAC ACL. This feature is useful for doing MAC-based matching on all packets regardless of whether the packet is IP version 4, IP version 6, IPX, MPLS, and so on. You can utilize this feature to rate limit all traffic ingressing a VLAN to some specific value by coupling an aggregate policer with a match-all MAC ACL.

•SmartPorts enhancements:

–Ciscorouter SmartPorts template

–Ciscoswitch SmartPorts template

–Ciscodesktop SmartPorts template

–Ciscoipphone SmartPorts template

–Ciscosoftphone SmartPorts template

–Global SmartPorts template

•System profiles (lockdown profiles):

With the profile files, you can eliminate the features or processes that may pose security risks (for example, disabling CDP or turning off auto-trunking on a port) to your switch. A profile file that has most of the security risks disabled is also known as a "lockdown" profile. A lockdown profile changes the functionality of the switch from enabling access to preventing access by default. When a lockdown profile is applied, you must manually enable the features that were disabled by the profile file.

•CRAM algorithm:

The compression and reordering of the ACL masks (CRAM) feature optimizes the mask usage across the different ACLs. This optimization promotes mask sharing and results in more efficient usage of the TCAM and the ability to program more ACLs in the TCAM.

•ACL statistics:

When you select the statistics keyword with the set security acl command set, the statistics are stored for the ACEs or the ACLs (VACLs and PACLs). The ACL statistics are disabled by default and can be enabled on a per-ACL, per-VLAN, or per-ACE basis.

•NetFlow top talkers:

The show mls statistics entry ip top-talkers command can display the statistics for the netflows with the maximum amount of network usage. The NetFlow entries are pulled out of the NetFlow table based on the number of packets that each flow has. The results are displayed in descending order with the top talkers being the entries with the largest packet count. You can get the statistics for the network (the top 32 talkers will be displayed) or for a specified number of flows such as the top 1 or 2 talkers.

•Configuration rollback:

Provides for rolling back the current switch configuration file to a previously saved configuration file if the current file produces undesirable system results. This rollback feature provides a command to set multiple configuration "checkpoint" files. If you no longer want the current configuration file to run on the switch, you can return to one of these configuration checkpoint files quickly and with the least possible disturbance to switch functionality.

•SPAN—Multiple destination ports can be specified in each local SPAN session.

•NetFlow—Create NetFlow table entries on a per-VLAN basis.

•Time domain reflectometer (TDR) support added for the following modules: WS-X6748-GE-TX, WS-X6148A-GE-TX, WS-X6148A-GE-45AF, WS-X6148A-RJ-45, and WS-X6148A-45AF.

•Layer 2 protocol tunneling enhancements:

Provides for specifying the drop and shutdown thresholds for individual protocols on a per-port basis. If you configure thresholds only and do not specify a protocol, the packets are rate limited cumulatively irrespective of protocols. If you specify a threshold for a protocol on a port, the packets are rate limited on a cumulative basis and then per-protocol thresholds are applied to the packets.

•802.1X authentication failure VLAN:

On a traditional 802.1X port, the switch does not provide access to the network until the supplicant that is connected to the port is authenticated by verifying its identity information with an authentication server. With the authentication failure VLAN feature, you can configure the authentication failure VLAN on a per-port basis and after three failed 802.1X authentication attempts by the supplicant, the port is moved to the authentication failure VLAN where the supplicant can access the network.

•802.1X RADIUS server failover enhancements:

Before software release 8.4(1), when the active RADIUS server went down or was unreachable, the 802.1X authentication timed out before the backup RADIUS server could become active. With software release 8.4(1) and later releases, some RADIUS server timer values are now configurable and the show radius command has been enhanced to show the active RADIUS server.

•Shaped round robin (SRR):

Provides egress traffic shaping and is supported as an option on Supervisor Engine 32 1p3q8t ports. If you do not enable SRR, weighted round robin (WRR) is used. SRR only allows a queue to use the specific amount of bandwidth that the weight allocates.

•Support for the following MIBs:

–CISCO-SECURE-SHELL-MIB

–CISCO-RADIUS-MIB

–CISCO-COPY-CONFIG-MIB

–CISCO-VLAN-TRANSLATION-MIB

–MAU-MIB

–CISCO-MAU-EXT-MIB

–POWER-ETHERNET-MIB

–CISCO-POWER-ETHERNET-EXT-MIB

–CISCO-NETFLOW-MIB

–HC-ALARM-MIB

–CISCO-VMPS-MIB enhancement

–RMON-MIB enhancement

–CISCO-STP-EXTENSIONS-MIB enhancement

–CISCO-CATOS-ACL-QOS-MIB enhancement

–SMON-MIB/CISCO-RMON-CONFIG-MIB enhancement

–CISCO-QOS-PIB-MIB enhancement

–CISCO-SWITCH-ENGINE-MIB enhancement

–CISCO-L2-TUNNEL-CONFIG-MIB enhancement

Software Release 8.4 Unsupported Software Features

This section lists the unsupported software features in software release 8.4(x):

•The following QoS features and the commands that are used to configure them are not supported in a system with a Supervisor Engine 720 in software release 8.4(x):

–RSVP

–COPS

–NBAR

•The following features are not supported with a Supervisor Engine 720 or Supervisor Engine 32 in software release 8.4(x):

–TCP Intercept.

–WCCP.

Features for Supervisor Engine Software Release 8.3

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.3, 3 May 2004:

•Software Release 8.3 Hardware Features

•Software Release 8.3 Software Features

•Software Release 8.3 Unsupported Software Features

Software Release 8.3 Hardware Features

Software release 8.3 provides initial support for these modules and chassis:

Note With software release 8.3(1), WS-SUP720-3BXL and WS-SUP720-3B support the same feature set and have the same performance characteristics as WS-F6K-PFC3A.

•WS-SUP720-3BXL—Supervisor Engine 720 with PFC3BXL:

–1-GB DRAM

–Policy Feature Card 3BXL

–Multilayer Switch Feature Card 3 (MSFC3):

1-GB DRAM

64-MB bootflash

•WS-F6K-PFC3BXL—Policy Feature Card 3BXL:

Use WS-F6K-PFC3BXL= to upgrade a WS-SUP720 with a PFC3BXL. WS-F6K-PFC3BXL= includes 1-GB memory upgrades for the Supervisor Engine 720 and the MSFC3. Refer to this publication for more information:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_16220.html

•WS-SUP720-3B—Supervisor Engine 720 with PFC3B:

–512-MB DRAM

–Policy Feature Card 3B

–Multilayer Switch Feature Card 3 (MSFC3):

256-MB DRAM

32-MB bootflash

•WS-F6K-PFC3B—Policy Feature Card 3B:

There are no memory-only upgrade options for WS-SUP720-3B.

Use WS-F6K-PFC3BXL= to upgrade a WS-SUP720-3B with a PFC3BXL. WS-F6K-PFC3BXL= includes 1 GB memory upgrades for the Supervisor Engine 720 and the MSFC3. Refer to this publication for more information:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_16220.html

•Dense Wavelength Division Multiplexing (DWDM) GBIC transceivers

•Coarse Wave Division Multiplexer SFP (CWDM-SFP) (1000BASE-CWDM SFP)

•GLC-T (1000BASE-T SFP)

•XENPAKs:

XENPAK-10GB-SR—10GBASE-SR Serial 850-nm short-reach multimode (MMF)

XENPAK-10GB-CX4—10GBASE-CX4 provides support for copper up to 15 meters

•WS-X6748-SFP module (48-port Gigabit Ethernet SFP)

Note Support for the WS-X6748-SFP module started in software release 8.3(2) and later releases.

Software Release 8.3 Software Features

Software release 8.3 provides support for these software features:

•DHCP snooping:

DHCP snooping provides security against Denial-Of-Service (DoS) attacks that are launched using DHCP messages by filtering DHCP packets and building and maintaining a DHCP-snooping binding table. DHCP snooping uses trusted and untrusted ports to filter the DHCP packets that are received by the switch.

•IP source guard:

IP source guard prevents IP spoofing by allowing only the IP addresses that are obtained through DHCP snooping on a particular port.

•Dynamic ARP inspection:

Dynamic ARP inspection (DAI) uses the binding information that is built by DHCP snooping to enforce the advertisement of bindings to prevent "man-in-the-middle" attacks. These attacks can occur when an attacker intercepts and selectively modifies communicated data to masquerade as one or more of the entries in a communication association. DAI adds an extra layer of security to ARP inspection by verifying that the ARP packet's MAC address and IP address match an existing DHCP snooping binding in the same VLAN.

•Port ACLs (PACLs):

Prior to software release 8.3(1), there were two types of access-lists—VACLs and IOS ACLs. The VACLs are applied to Layer 2 and Layer 3 forwarded traffic while the Cisco IOS ACLs are only applied to Layer 3 forwarded packets. Both access list types are applied to VLANs and filter traffic based on the packet header information.

Typically, a VLAN is composed of many physical ports. A PACL provides you with the extra granularity to filter traffic on a specific physical port. A PACL is an access list that is mapped to a physical port. Like VACLs, PACLs are applied to both Layer 2 and Layer 3 forwarded packets.

•Fabric enhancements with Supervisor Engine 720:

The integrated 720-Gbps switch fabric supports a high-availability failover to the standby switch fabric.

•Automatic QoS enhancement:

Allows you to clear the automatic QoS configuration by using a port-based clear command and a global clear command.

•Multiple collectors for NDE:

Allows NetFlow export data to be sent to two destinations simultaneously.

•PBF enhancements:

Simplifies the process of setting and committing the security ACLs and adjacency information.

•EtherChannel enhancements:

Clears and restores channel-based counters on a per-protocol and per-channel basis.

•Disables an auxiliary VLAN until an IP phone is detected:

Provides security for the auxiliary VLANs by ensuring that the auxiliary VLAN is not enabled until an IP phone is detected. As soon the switch detects the presence of an IP phone, the auxiliary VLAN is enabled.

•802.1X unidirectional controlled port:

Allows you to use wake-on LAN technology (also referred to as remote wake-up) to perform unattended system backups or software upgrades on hosts attached to the switch.

•802.1X with ACL assignments:

When you configure 802.1X with ACL assignments, you can automatically configure the QoS ACLs and VACLs to a user once the user is authenticated. The RADIUS server sends a QoS VLAN-based ACL, QoS port-based ACL, or VACL policy name with the authentication success packet. The policy that is associated with the policy name is already configured on the switch through the CLI. The policy is converted into a set of ACEs and then installed on the switch. Once you configure the 802.1X ACL assignments, the switch does the following:

–Authenticates the user(s)

–Uses DHCP snooping or dynamic ARP inspection to obtain the IP address of the user(s)

–Expands the ACL using the IP address(es) and programs the PFC

•802.1X user distribution:

Configuring the 802.1X user distribution feature allows you to distribute users that have the same group name across multiple VLANs. Prior to software release 8.3(1), the RADIUS VLAN assignment feature supported by 802.1X took the VLAN number obtained from the RADIUS server and added all users to that VLAN. With software release 8.3(1) and later releases, you can load balance 802.1X-authenticated users that are configured under one group name by distributing them evenly between VLANs.

•802.1X RADIUS accounting and tracking:

Allows you to send 802.1X user accounting information to the RADIUS server.

•802.1X authenticated identity-to-port description mappings:

Assigns a port description to the 802.1X port based on the information received from the RADIUS server. This feature makes use of an AV-Pair, "Supplicant Name," to uniquely assign a port description for an authenticated user.

•DNS resolution for a RADIUS server configuration:

Allows you to configure the RADIUS server using a DNS name in addition to IP addresses.

•VTP version 3 enhancement—MST mapping propagations:

Provides the ability to distribute the MST database across the network using VTP version 3.

•802.1s:

The Multiple Spanning Tree (MST) feature is the IEEE 802.1s and is an amendment to 802.1Q. MST extends the 802.1w Rapid Spanning Tree (RST) algorithm to multiple spanning trees. This extension provides for both rapid convergence and load balancing in a VLAN environment. In software release 8.3(1), the MST protocol is compliant with IEEE 802.1s and is backward compatible with 802.1D STP, 802.1w, the Rapid Spanning Tree Protocol (RSTP), and the Cisco PVST+ architecture that was implemented in previous software releases.

•Layer 2 PDU rate limiting:

The Layer 2 PDU rate limiters are supported in hardware, and they rate limit traffic on the Local Target Logic (LTL) index. You can configure up to four rate limiters. You can configure rate limiters to limit the following PDU types globally on the switch:

–Spanning-tree BPDUs—IEEE and SSTP, CDP, UDLD, VTP, and PAgP

–Layer 2 protocol tunnel-encapsulated PDUs

–802.1X port security

•Automatic module shutdown:

Automatically shut down any module based on the number of times that the module resets itself within a specified time frame. A module that frequently resets itself can disrupt traffic load balancing. By setting the automatic module shutdown, you can limit the number of times that the module resets itself before shutting down completely.

•System crash-info files:

The crash-info file contains extended system information that is captured very quickly when the system reloads due to an error condition. Like the core-dump file, the crash-info file is stored in the file system. The information in the crash-info file should be used in addition to the core-dump information and does not replace that information. By examining both the crash-info file and core-dump file, Cisco TAC can better analyze the error condition.

•MSFC autostate enhancements:

–Normal autostate mode—Autostate shuts down (or brings up) Layer 3 interfaces/subinterfaces on the MSFC and the Multilayer Switch Module (MSM) when specific port configuration changes occur on the switch.

–Autostate exclude mode—Allows you to specify the ports to exclude from autostate.

–Autostate track mode—Tracks key VLAN or port connections to the MSFC.

•Port security on trunk ports

•MAC address monitoring:

Because the Catalyst 6500 series switches learn the source MAC addresses automatically, the system is vulnerable to flooding of spoofed traffic and potential Denial of Service (DoS) attacks. To prevent traffic flooding and DoS attacks, you can monitor the number of MAC addresses that are learned by the system on a per-port, per-VLAN, or per-port-per-VLAN basis.

•CoS-to-CoS maps on IEEE 802.1Q tunnel ports:

Ingress Cos-to-CoS mapping is supported on 802.1Q tunnel ports on WS-X6704-10GE, WS-X6724-SFP, and WS-X6748-GE-TX switching modules. The CoS-to-CoS mapping feature is disabled on ports that are not configured as 802.1Q tunnel ports.

•Back up the VMPS configuration file:

When you reboot a Catalyst 6500 series switch that is configured as a VMPS server, the VMPS requests that are sent by the clients are queued by the TFTP server until the VMPS server downloads the VMPS configuration file from the VMPS server. To ensure that client access is not delayed during a system reboot, you can configure the switch to back up the VMPS configuration file locally and use this file until it is has downloaded the current VMPS configuration file from the remote TFTP server.

•SCP:

Secure Copy (SCP) provides a secure method for copying crypto image files. SCP relies on Secure Shell (SSH) and allows you to copy a crypto file to and from the system through an encrypted channel.

•Comparing configuration files:

You can compare the configuration files that are stored on the system to determine the differences between the configuration files or to check if changes have been made to the system configuration.

•Using Secure Shell Encryption for Telnet sessions (support for SSH version 2)

Secure Shell encryption provides security for Telnet sessions and other remote connections to the switch. Secure Shell encryption is supported for remote logins to the switch only. Telnet sessions that are initiated from the switch cannot be encrypted. To use this feature, you must install the application on the client accessing the switch, and you must configure Secure Shell encryption on the switch. The current implementation of Secure Shell encryption supports SSH version 1and version 2. SSH version 1 supports the DES and 3DES encryption methods, and SSH version 2 supports the 3 DES and AES encryption methods. Secure shell encryption can be used with RADIUS and TACACS+ authentication.

•GLBP:

Gateway Load Balancing Protocol (GLBP) provides load-balancing over multiple gateways through a single virtual IP address and multiple virtual MAC addresses. This protocol is similar to Host Standby Router Protocol (HSRP) and Virtual Router Redundancy Protocol (VRRP). GLBP protects data traffic from a failed router or circuit, while allowing packet load sharing between a group of redundant routers.

•IGMP version 3 snooping with Multicast Multilayer Switching (MMLS):

Prior to software release 8.3(1), IGMP version 3 snooping operated only with MMLS disabled on the supervisor engine. This resulted in the IGMP version 3 snooping capability being available on individual bridged VLANs but there was no IGMP version 3 snooping support for hardware-switched Layer 3 flows. Software release 8.3(1) and later releases provides IGMP version 3 snooping with MMLS integration.

•CLI command logging:

Entering the show log command displays recorded commands executed from the CLI through Telnet, SSH, or console sessions. The log provides a history of the events and operations performed by users.

•Generic Attribute Registration Protocol (GARP) VLAN Registration Protocol (GVRP) support on Supervisor Engine 720

•Verify software images:

Because a software image goes through a sequence of transfers before it is copied into the memory of the switch, the integrity of the image is at risk each time that it is downloaded from Cisco.com. The image size and checksum are automatically checked when the image is copied, but these types of checks do not ensure that the downloaded image has not been corrupted. To ensure the integrity of any images that you download, you can use the set image-verification command. You can set image verification to work when booting, after the image has been copied, or before a system reset.

•Bidirectional PIM:

Supervisor Engine 720 supports hardware forwarding of bidirectional PIM groups. To support bidirectional PIM groups, the Supervisor Engine 720 implements a new mode called designated forwarder (DF) mode. The designated forwarder is the router that is elected to forward packets to and from a segment for a bidirectional PIM group. In DF mode, the supervisor engine accepts packets from the reverse path forwarding (RPF) interface and from the DF interface.

•VLAN manager enhancements:

Instead of reserved VLANs, we now have only user and internal VLANs. VLAN manager no longer permanently sets aside VLANs for features that require them; they are now dynamically assigned as needed. The entire VLAN range (1 to 4094) is now available for user (and internal) VLANs.

•QoS policer burst value change:

The burst value changed from 1-32000 (1 Kb to 32 Kb) to 1-256000 (1 Kb to 256 Mb)

•PFC3 output QoS ACLs trust change:

Egress traffic uses the same trust values as ingress traffic when attaching ACLs to a VLAN. Any traffic trusted at ingress will also be trusted at egress.

•UDI - Unique Device Identifier:

The Cisco Unique Device Identifier (UDI) provides inventory identification in the output of the show inventory command.

•System sanity check:

The show system sanity command runs a series of checks on the configuration and highlights possible conditions that could lead to problems with your configuration.

•System health check:

The show system health command tracks registers, counters, and software patch "kick-ins" and compiles a list of entities it considers as "unhealthy" for the system. The feature also lists CPU and memory utilization.

•Expanded memory support:

Software release 8.3(1) and later releases support up to 1-GB DRAM on the Supervisor Engine 720.

•SmartPort macros:

SmartPort macros provide a convenient way to save and share common configurations. You can use SmartPort macros to enable features and settings based on the location of a switch in the network and for mass configuration deployments across the network.

•Virtual Router Redundancy Protocol (VRRP)

VRRP eliminates the single point of failure inherent in the static default routed environment.

Software Release 8.3 Unsupported Software Features

This section lists the unsupported software features in software release 8.3(x):

•The following QoS features and the commands that are used to configure them are not supported in a system with a Supervisor Engine 720 in software release 8.3(x):

–RSVP

–COPS

–NBAR

•The following features are not supported with a Supervisor Engine 720 in software release 8.3(x):

–TCP Intercept.

–WCCP.

Features for Supervisor Engine Software Release 8.2

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.2, 4 December 2003:

•Software Release 8.2 Hardware Features

•Software Release 8.2 Software Features

•Software Release 8.2 Unsupported Software Features

Software Release 8.2 Hardware Features

Software release 8.2 provides initial support for these modules and chassis:

•The 96-port 10/100BASE-TX switching module (WS-X6148X2-RJ-45) is supported. WS-X6148X2-45AF has the voice daughter card (WS-F6K-FE48X2-AF).

Voice daughter card features include the following:

–Inline power for Cisco IP phones, Cisco Aironet wireless access points, and IEEE 802.3af-compliant devices

–Power to any of the 96 ports

–Up to 15.4 W per port (limited to a total of 740 W per daughter card)

–48 ports may be powered at 15.4 W each

–96 ports may be powered at 7 W each

•Two additional voice daughter cards are supported:

–WS-F6K-48-AF for the WS-X6148-RJ-45 and WS-X6148-RJ-21 48-port 10/100BASE-TX switching modules

–WS-F6K-GE48-AF for the WS-X6148-GE-TX and WS-X6548-GE-TX 48-port 10/100/1000BASE-TX switching modules

These voice daughter card features are supported:

–Inline power for Cisco IP phones, Cisco Aironet wireless access points, and IEEE 802.3af-compliant devices.

–Power to all 48 ports (up to 15.4 W per port)

Note To determine your exact power needs, use the CCO power calculator at this URL:

http://www.cisco.com/go/powercalculator

•The 1000BASE-ZX SFP (GLC-ZX-SM), single mode only, dual LC connector is supported.

•XENPAK-10GB-LX4—10GBASE-LX4 Serial 1310-nm multimode (MMF)

•The Catalyst 6500 series switch service modules are supported with Supervisor Engine 720 in software release 8.2(1) and later releases. The "Service Modules" section lists the service modules.

•The Catalyst 6500 series switch voice modules are supported with Supervisor Engine 720 in software release 8.2(1) and later releases. The "Voice Modules" section lists the voice modules.

•The ATM modules are supported with Supervisor Engine 720 in software release 8.2(1) and later releases. The "ATM Modules" section lists the ATM modules.

•The FlexWAN module is supported with Supervisor Engine 720 in software release 8.2(1) and later releases. The "FlexWAN Module" section lists the FlexWAN module.

Software Release 8.2 Software Features

Software release 8.2 provides support for these software features:

•Specifying a custom 802.1Q EtherType field

By specifying a custom EtherType field, your network can support Cisco and non-Cisco switches that do not use the standard 0x8100 EtherType to identify 802.1Q-tagged frames.

•Supervisor Engine 720 supports these QoS-related features:

–Egress QoS

–Egress DSCP mutation

–Optional egress DSCP rewrite

–Disable DSCP rewrite

–QDE

–Automatic QoS

•IEEE 802.3af power compliance

•Cisco IP Phone support enhancements:

–Support for a high-powered phone to negotiate a low-power mode (dimmed screen) when powered by a pre-standard Cisco PoE daughter card.

–Support for a high-powered phone to negotiate a high-power mode (full screen brightness) when powered by a IEEE 802.3af Cisco PoE daughter card.

•Support for new SFPs and XENPAKs:

For information on SFP and XENPAK support, see the "SFP, XENPAK, and GBIC Behavior" section.

•New auto-10-100 keyword for the set port speed command:

Use the auto-10-100 keyword on ports that support speeds of 10/100/1000 Mbps. Using the auto-10-100 keyword makes the port behave the same as a 10/100-Mbps port that has the speed set to auto. The speed and duplex are negotiated (the 1000-Mbps speed does not take part in the negotiation).

•New auto-configure keyword for the set port security command:

Automatically configured addresses are not aged out and are retained across reboots. These addresses are retained if a secure port shuts down because of a security violation, if the port is administratively disabled, or if port security is disabled.

•Auto-MDI/MDIX capability:

You can use either straight or crossover cable, and the module will automatically detect and adjust for the cable type. For complete details, see the "Auto-MDI/MDIX" section.

•In software release 8.2.2, improved supervisor engine failover rates with high-availability enabled are as follows:

–In flow-through, truncated and compact modes, the Supervisor Engine 1 and Supervisor Engine 2 failover time is less than 500 ms.

–In flow-through mode, the Supervisor Engine 720 failover time is about 1.5 seconds. In truncated or compact mode, the Supervisor Engine 720 failover time is less than 3 seconds.

•In software release 8.2.1, the supervisor engine failover rates with high-availability enabled are as follows:

–In flow-through mode, the Supervisor Engine 1 and Supervisor Engine 2 failover time is less than 500 ms. With Supervisor Engine 720, the failover time is approximately 1.5 seconds.

–In truncated or compact mode, the Supervisor Engine 2 failover time is about 1.5 seconds. With Supervisor Engine 720, the failover time is approximately 3.5 seconds.

•The maximum number of permanent CAM entries has been increased from 128 to 256.

•Support for the following MIBs:

–CISCO-VLAN-MEMBERSHIP-MIB enhancement

–CISCO-CATOS-ACL-QOS-MIB enhancement

Software Release 8.2 Unsupported Software Features

This section lists the unsupported software features in software release 8.2(x):

•The following QoS features and the commands that are used to configure them are not supported in a system with a Supervisor Engine 720 in software release 8.2(x):

–RSVP

–COPS

–NBAR

•The following automatic QoS clear commands are visible in the CLI but are not supported in software release 8.2(x):

–clear qos autoqos

–clear port qos mod/port autoqos

•The following features are not supported with a Supervisor Engine 720 in software release 8.2(x):

–TCP Intercept.

–WCCP.

–IGMP version 3.

Features for Supervisor Engine Software Release 8.1

Note Maximum switching performance is achieved when all switch components are fabric enabled. The presence of nonfabric-enabled switching modules might impact overall switching performance.

These sections describe the features in software release 8.1, 30 June 2003:

•Software Release 8.1 Hardware Features

•Software Release 8.1 Software Features

•Software Release 8.1 Unsupported Software Features

Software Release 8.1 Hardware Features

Software release 8.1 provides initial support for these modules and chassis:

•Supervisor Engine 720 (WS-SUP720)

•4000 W DC-power supply (PWR-4000-DC)

•Cisco 7609 router chassis, 9 vertical slots (CISCO7609)

•Catalyst 6509-NEB-A chassis, 9 vertical slots (6509-NEB-A)

•48-port 10/100/1000 Ethernet Module, RJ-45, fabric enabled (WS-X6748-GE-TX)

•24-port Gigabit Ethernet Module, requires SFPs, fabric enabled (WS-X6724-SFP)

•4-port 10-Gigabit Ethernet Module, requires XENPAKs, fabric enabled (WS-X6704-10GE)

•XENPAK—Up to 10-kilometer range, 10GBASE-LR Serial 1310-nm long-haul (SMF) (XENPAK-10GB-LR)

Software Release 8.1 Software Features

Software release 8.1 provides support for these software features:

•VTP version 3—VTP version 3 differs from earlier VTP versions in that it does not directly handle VLANs. VTP version 3 is a protocol that is only responsible for distributing a list of opaque databases over an administrative domain. When enabled, VTP version 3 provides the following enhancements to previous VTP versions:

–Support for extended VLANs.

–Support for the creation and advertising of private VLANs.

–Improved server authentication.

–Protection from the "wrong" database accidentally being inserted into a VTP domain.

–Interaction with VTP version 1 and VTP version 2.

–Ability to be configured on a per-port basis.

•CallHome—You can use the CallHome feature to set your switch to e-mail or you can page a syslog message of a specified severity to a specified e-mail or pager address or a set of e-mail or pager addresses.

•Logging system information to a TFTP, FTP, or rcp server—You can configure your system to periodically execute up to 15 show commands and log the output of these commands in a file on a specified server. The information in the output can be used for debugging and troubleshooting purposes.

•TCL scripting—Tool Command Language (TCL) is a simple, programmable, text-based language that allows you to write command procedures that expand the capabilities of the built in set of commands. It is used primarily with interactive programs such as text editors, debuggers, illustrators, and shells. The Catalyst 6500 series switch software supports TCL version 7.4.

•VLAN port-provisioning verification—When VLAN port-provisioning verification is enabled, you must specify the VLAN name in addition to the VLAN number when assigning switch ports to VLANs. Because you are required to specify both the VLAN name and the VLAN number, this verification feature helps ensure that ports are not inadvertently placed in the wrong VLAN.

•FTP support for downloading software images.

•Increased number of command aliases—Use the set alias command to define up to 100 command aliases (shorthand versions of commands) for frequently used or long and complex commands.

•Increased number of MAC addresses supported (4097) for port security.

•Configure 802.1X guest VLANs on a per-port basis.

•Pipe command—Introduces a UNIX style output piping functionality to the Catalyst software. This feature enables you to pipe the output of a command, such as show port, to another command for post-processing.

•CMM online diagnostics are supported in software release 8.1(1) and later releases.

•Support for the following MIBs:

–ENTITY-MIB enhancement

–CISCO-UDLDP-MIB enhancement

–CISCO-RF-MIB

–CISCO-CALLHOME-MIB

–CISCO-VTP-MIB enhancement

–CISCO-SYS-INFO-LOG-MIB

–CISCO-CAT6K-CROSSBAR-MIB enhancement

–CISCO-ENTITY-ASSET-MIB

–CISCO-SWITCH-ENGINE-MIB enhancement

–CISCO-CATOS-ACL-QOS-MIB enhancement

–CISCO-PAGP-MIB enhancement

–CISCO-LAG-MIB enhancement

–CISCO-IGMP-SNOOPING-MIB enhancement

Software Release 8.1 Unsupported Software Features

This section lists unsupported software features:

•The following QoS commands are present in software release 8.1(x) images, but are not tested or supported:

–set qos dscp-rewrite enable

–set qos dscp-rewrite disable

–output keyword for the set qos acl and clear qos acl commands

–set qos dscp-mutation-map

–clear qos dscp-mutation-map

–dscp-mutation-map keyword for the show qos commands

•The following QoS features and the commands used to configure them are not supported in a system with a Supervisor Engine 720 in software release 8.1(x):

–No DSCP rewrite

–Egress QoS

–PFC3 egress DSCP mutation

–Automatic QoS

–RSVP

–COPS

–QoS and voice macros

–NBAR

–QDE

•The following features are not supported with a Supervisor Engine 720 in software release 8.1(x):

–TCP Intercept.

–WCCP.

–IGMP version 3.

Features for Supervisor Engine Software Releases 7.1 Through 7.6

For a complete list of hardware and software features for software releases 7.1 through 7.6, refer to the Release Notes for Catalyst 6500 Series Switch Software Release 7.x at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/catos/7.x/release/notes/OL_1982.html

Features for Supervisor Engine Software Releases 6.1 Through 6.4

For a complete list of hardware and software features for software releases 6.1 through 6.4, refer to the Release Notes for Catalyst 6500 Series Switch Software Release 6.x at at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/catos/6.x/release/notes/78_11235.html

Features for Supervisor Engine Software Releases 5.1 Through 5.5

For a complete list of hardware and software features for software releases 5.1 through 5.5, refer to the Release Notes for Catalyst 6500 Series Switch Software Release 5.x at this URL:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/catos/5.x/release/notes/78_6218.html

Usage Guidelines and Restrictions

These sections provide usage guidelines and restrictions for the Catalyst 6500 series switches:

•System and Supervisor Engine

•Modules and Switch Ports

•SFP, XENPAK, and GBIC Behavior

•EtherChannel

•Quality of Service

•Automatic Quality of Service with Cisco IP Phones

•Multicast

–IGMP Version 3 with MMLS

•Spanning Tree

•Access Control

•High Availability

•Multilayer Switching

•MIBs

•VLANs, VTP, MVRP, and VLAN Trunks

•Authentication, Authorization, and Accounting

•TDR

•Auto-MDI/MDIX

•Bidirectional PIM

•Binary and Text File Configuration Modes

•802.1X Authentication

•NetFlow Data Export

•Network Admission Control

•Connectivity Fault Management

•CiscoView

System and Supervisor Engine

This section contains usage guidelines, restrictions, and troubleshooting information that apply to the supervisor engine and to the switch at the system level:

Note For information about AC power requirements and heat dissipation, refer to Chapter 2, "Preparing for Installation," of the Catalyst 6500 Series Switch Installation Guide:

http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Chassis_Installation/Cat6500/6500_ins.html

•On a Catalyst 6500 series switch that runs software release 8.7(3), the 10-Gigabit Ethernet uplink ports on a WS-SUP32-10GE-3B engine cannot transfer frames over 10100 bytes. The switch that operates with Supervisor Engine 720 does not support large frames over 9760 byte maximum transmission units (MTUs).

Note The large frames with 10100 bytes is not supported in Cisco IOS software.

Workaround: None. (CSCsg73697)

•On a Catalyst 6500 series switch that runs software release 8.7(3), enabling set cam zero-mac-filter using set cam zero-mac-filter enable command discards all the traffic that comes with the destination MAC address 00-00-00-00-00-00, and it is not seen in CAM table. The MAC address is learnt when the set cam zero-mac-filter is disabled.

Workaorund: None. (CSCsw16568)

•On a Catalyst 6500 series switch with WS-SUP32-10GE-3B that runs software release 8.7(1) or later, the configuration of the supervisor module is lost during an upgrade. This problem occurs when the switch operates in binary configuration mode.

Workaround: Upgrade the software in text configuration mode. (CSCsx47569)

•For Software Release 8.3(1) and later, the total power available in a system running combined mode will be equal to the larger of a) 1.67 * the smaller supply or b) the larger supply. The previous behavior was to add the output of both supplies. (CSCea60961)

•If a high percentage of traffic over 32 Gbps is switched through a 13-slot chassis, protocols such as UDLD, CDP, and STP, may fail and result in network downtime. Both Supervisor Engine 2 and Supervisor Engine 720 systems are affected. This problem affects only the 13-slot chassis. This problem is usually seen when the uplink ports on the Supervisor Engine are passing traffic but there needs to be traffic on other modules to reach 32 Gbps. (CSCee23154)

•Moving a Supervisor Engine 2 and MSFC2 between a Catalyst 6509 switch and a Catalyst 6503 switch may corrupt the MSFC2 NVRAM.

Workaround: Save the configuration to Flash memory and restore the configuration after the move. (CSCdy83320)

•Cisco 1200 series wireless access points may not receive power from a Catalyst 6500 series switch. This problem usually happens if the switch is reset or power cycled, if the module in the switch to which the access point is connected is reset or power cycled, or if a fast switchover occurs.

When this problem happens, a system message such as the following is displayed:

%SYS-3-PORT_DEVICENOLINK Device on port m/p powered but no link up

However, this system message may not always be seen depending on the type of module used.

Workaround: Disable the Ethernet port that the access point is connected to for 2 to 3 minutes and then enable the port again. If this does not resolve the problem, replace the AIR-RM20A radio module with the AIR-RM21A module. (CSCeg05847)

•The broadcast suppression counter undercounts packets that have a size evenly divisible by 16:

–A 64-byte packet should be counted as 4 but is counted as 3

–65- to 79-byte packets are correctly counted as 4

–An 80-byte packet should be counted as 5 but is counted as 4

–81- to 95-byte packets are correctly counted as 5

–A 96-byte packet should be counted as 6 but is counted as 5

(CSCdr56784)

•For software release 8.3(4) and later releases, the show fabric status command does not indicate the fabric speed.

•The set option command set was inadvertently removed from software releases 7.6(7) and 8.3(1). The set option command set will be available again (engineering mode only) in software releases 7.6(8) and 8.3(3).

•If you are running software release 8.3(1) or later on a Supervisor Engine 720 in text configuration mode and downgrade to software releases 8.1(x) or 8.2(1), the switch will crash with a TLB exception when the downgraded image is booted.

Workaround: To prevent this problem, enter the clear config all command before doing the downgrade. This problem is applicable only to the Supervisor Engine 720 in text configuration mode. Note that you do not see this problem when downgrading to software release 8.2(2). (CSCec56329)

•With Supervisor Engine 720, there is a CLI inconsistency between Cisco IOS images for the MSFC and Catalyst images for the supervisor engine due to changes to rate-limiter groups. The inconsistency does not affect rate limiting; it only affects the data displayed using the show mls rate command on the MSFC and show rate limit command on the supervisor engine. The inconsistency may cause the supervisor engine to enable/disable TTL Fail rate limiters as a side effect when some rate limiters, including RPF Fail, No-route, and ICMP unreachable, are enabled/disabled.

The inconsistency is due to a group change on the MSFC. There are two rate-limiter groups that were previously defined as follows:

a) ACL input and ACL output

b) RPF Fail, No-route, ICMP unreachable, and TTL Fail

In group b, for the MSFC, "TTL Fail" was replaced with "IP errors" in Cisco IOS Release 12.2(17a)SX1 but this change was not made in the supervisor engine software until software release 8.3(1).

If the MSFC and Catalyst images do not use the same grouping policy, the inconsistency problem remains. To avoid the inconsistency, note the following software guidelines:

–With Catalyst software release 8.3(1) and later releases, you must use Cisco IOS Release 12.2(17a)SX1 or later images.

–With Catalyst software releases 8.1(x) and 8.2(x), you must use images earlier than Cisco IOS Release 12.2(17a)SX1.

•When you save your configuration to a file when running software release 8.3(1), all trunk configurations are saved with the allowed VLAN range of 1 to 4094. If you try to reuse this configuration when downgrading to an earlier software release, all trunk-related commands fail because the earlier software release is expecting a VLAN range of 1 to 1005 and 1025 to 4094.

•MAC addresses—Theoretical and recommended limits

–PFC/PFC2: 128K theoretical maximum, 32K recommended

–PFC3: 64K theoretical maximum, 32K recommended

•A Supervisor Engine 2 might show 100 percent traffic utilization in the show system and show traffic command displays. This problem is cosmetic and does not indicate true traffic utilization. To correct the problem, you need to reprogram the Supervisor Engine 2 EPLD. To reprogram the EPLD, download the epld-sup2-trafficmeter-swupdate.hZ image and follow the instructions documented in the README.epld_update file. (CSCdx54751)

•The standby use-bia option should not be used in an HSRP configuration. MLS entries are not created when you us

Hierarchical Navigation

Cisco Catalyst 6500 Series Switches

Release Notes for Catalyst 6500 Series Software Release 8.x

Downloads

Table Of Contents

Release Notes for Catalyst 6500 Series Software Release 8.x

Contents

Release 8.x DRAM Memory Requirements

Boot ROM (ROMMON) Requirements

Upgrading the Boot ROM

Supervisor Engine Bootflash

Redundant Supervisor Engine Configurations

Product and Software Release Matrix

Supervisor Engines

Policy Feature Cards

Switch Fabric Modules

Small Form-Factor Pluggable Modules (SFPs)

10-Gigabit Ethernet Switching Modules

XENPAKs

Gigabit Ethernet Switching Modules

Gigabit Interface Converters (GBICs)

Fast Ethernet Switching Modules

Ethernet/Fast Ethernet (10/100) Switching Modules

Ethernet Switching Modules

Power Over Ethernet Daughter Cards

Voice Modules

FlexWAN Module

Optical Services Modules

Service Modules

ATM Modules

Multilayer Switch Module

Power Supplies

Fan Trays

Modular Chassis

Unsupported Hardware

Orderable Software Images

Software Image Version Compatibility

Catalyst 6500 Series Features

Features for Supervisor Engine Software Release 8.7

Software Release 8.7 Hardware Features

Software Release 8.7 Software Features

Software Release 8.7 Unsupported Software Features

Features for Supervisor Engine Software Release 8.6

Software Release 8.6 Hardware Features

Software Release 8.6 Software Features

Software Release 8.6 Unsupported Software Features

Features for Supervisor Engine Software Release 8.5

Software Release 8.5 Hardware Features

Software Release 8.5 Software Features

Software Release 8.5 Unsupported Software Features

Features for Supervisor Engine Software Release 8.4

Software Release 8.4 Hardware Features

Software Release 8.4 Software Features

Software Release 8.4 Unsupported Software Features

Features for Supervisor Engine Software Release 8.3

Software Release 8.3 Hardware Features

Software Release 8.3 Software Features

Software Release 8.3 Unsupported Software Features

Features for Supervisor Engine Software Release 8.2

Software Release 8.2 Hardware Features

Software Release 8.2 Software Features

Software Release 8.2 Unsupported Software Features

Features for Supervisor Engine Software Release 8.1

Software Release 8.1 Hardware Features

Software Release 8.1 Software Features

Software Release 8.1 Unsupported Software Features

Features for Supervisor Engine Software Releases 7.1 Through 7.6

Features for Supervisor Engine Software Releases 6.1 Through 6.4

Features for Supervisor Engine Software Releases 5.1 Through 5.5

Usage Guidelines and Restrictions

System and Supervisor Engine
