Release Notes for the Cisco 1700 Series Routers for Cisco IOS Release 12.1(3)XT
March 9, 2001
These release notes for the Cisco 1700 series routers describe the enhancements provided in Cisco IOS Release 12.1(3)XT2. These release notes are updated as needed.
For a list of the software caveats that apply to Cisco IOS Release 12.1(3)XT1, see the "Caveats" section and Caveats for Cisco IOS Release 12.1 T. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 located on CCO and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
•
System Requirements
•New and Changed Information
•Important Notes
•Caveats
•Related Documentation
•Obtaining Documentation
•Obtaining Technical Assistance
System Requirements
This section describes the system requirements for Release 12.1(3)XT2 and includes the following sections:
•Memory Requirements
•Hardware Supported
•Determining Your Software Release
•Upgrading to a New Software Release
•Feature Set Tables
Memory Requirements
Table 1 Memory Requirements for the Cisco 1700 Series Routers
Feature Sets
|
Image Name
|
Software Image
|
Recommended Flash Memory
|
Recommended DRAM Memory
|
IP Feature Sets
|
IP
|
c1700-y-mz
|
4 MB
|
24 MB
|
IP ADSL
|
c1700-y7-mz
|
8 MB
|
24 MB
|
| |
IP Plus ADSL
|
c1700-sy7-mz
|
8 MB
|
24 MB
|
| |
IP/Voice Plus ADSL
|
c1700-sv3y7-mz
|
8 MB
|
32 MB
|
| |
IP Plus IPSec 56 (DES) ADSL
|
c1700-sy756i-mz
|
8 MB
|
32 MB
|
| |
IP/Voice Plus IPSec 56 (DES) ADSL
|
c1700-sv3y756i-mz
|
8 MB
|
32 MB
|
| |
IP/FW/IDS
|
c1700-o3y-mz
|
4 MB
|
24 MB
|
| |
IP/FW/Voice Plus IPSec 56 (DES) ADSL
|
c1700-o3sv3y7-mz
|
8 MB
|
32 MB
|
| |
IP/FW Plus IP Sec 56 (DES) ADSL
|
c1700-o3sy756i-mz
|
8 MB
|
32 MB
|
| |
IP/Voice/FW/IDS Plus IPSec 56 ADSL
|
c1700-o3sv3y756i-mz
|
8 MB
|
32 MB
|
| |
IP/IPX
|
c1700-ny-mz
|
4MB
|
24 MB
|
| |
IP/IPX/FW/IDS Plus ADSL
|
c1700-no3sy7-mz
|
8 MB
|
24 MB
|
| |
IP/IPX/Voice/FW/IDS Plus ADSL
|
c1700-no3sv3y7-mz
|
8 MB
|
32 MB
|
| |
IP Plus IPSec 3DES ADSL
|
c1700-k2sy7-mz
|
8 MB
|
32 MB
|
| |
IP/Voice Plus IPSec 3DES ADSL
|
c1700-k2sv3y7-mz
|
8 MB
|
32 MB
|
| |
IP/FW Plus IPSec 3DES ADSL
|
c1700-k2o3sy7-mz
|
8 MB
|
32 MB
|
| |
IP/FW/Voice Plus IPSec 3DES ADSL
|
c1700-k2o3sv3y7-mz
|
8 MB
|
32 MB
|
| |
IP/IPX/AT/IBM
|
c1700-bnr2y-mz
|
8 MB
|
24 MB
|
| |
IP/IPX/AT/IBM Plus ADSL
|
c1700-bnr2sy7-mz
|
8 MB
|
32 MB
|
| |
IP/IPX/AT/IBM/FW Plus IPSec 56 (DES) ADSL
|
c1700-bno3r2sy756i-mz
|
8 MB
|
32 MB
|
IP Feature Sets
|
IP/IPX/AT/IBM/FW/Voice Plus IPSec 56 (DES) ADSL
|
c1700-bno3r2sv3y756i-mz
|
16 MB
|
48 MB
|
IP/IPX/AT IBM/FW Plus IPSec 3DES ADSL
|
c1700-bk2no3r2sy7-mz
|
8 MB
|
32 MB
|
| |
IP/IPX/AT/IBM/FW/Voice Plus IPSec 3DES ADSL
|
c1700-bk2no3r2sv3y7-mz
|
16 MB
|
48 MB
|
Hardware Supported
Cisco IOS Release 12.1(3)XT2 supports the Cisco 1700 series routers:
•Cisco 1720—Runs data images only.
•Cisco 1750—Runs data and data-plus-voice images.
For detailed descriptions of the new hardware features, see the documents listed in the "Platform-Specific Documents" section.
Cisco 1720
The 1720 router provides Internet and intranet access, and includes the following:
•Support for virtual private networking
•Modular architecture
•Network device integration
The Cisco 1720 router has the following hardware components:
•One autosensing 10/100 Fast Ethernet port
•Two WAN interface card slots
•One auxiliary (AUX) port (up to 115.2 kbps asynchronous serial)
•One console port
•RISC Processor for high performance encryption
•One internal expansion slot for support of hardware-assisted services such as encryption (up to T1/E1) and, in the future, compression
•DRAM memory: 16 MB default, expandable to 48 MB
•Flash memory: 4 MB default, expandable to 16 MB
•Desktop form factor
The Cisco 1720 router supports any combination of one or two of the following WAN interface cards, which are shared with the Cisco 1600, 2600, and 3600 routers:
•WIC-1T: One port high speed serial (sync/async)
•WIC-2T: Two port high speed serial (sync/async)
•WIC-2A/S: Two port low speed serial (sync/async) (up to 128 kbps)
•WIC-1B-S/T: One port ISDN BRI S/T
•WIC-1B-U: One port ISDN BRI U
•WIC-1DSU-56K4: One port integrated 56/64 kbps 4-wire DSU/CSU
•WIC-1DSU-T1: One port integrated T1 / Fractional T1 DSU/CSU
•WIC-1ADSL: One-port asymmetric digital subscriber line (supported on the Cisco 1700, 2600, and 3600 series routers only)
•WIC-1ENET: One-port 10Base-T Ethernet interface
Cisco 1750
The voice-and-data capable Cisco 1750 router provides global Internet and company intranet access, and includes the following:
•Voice-over-IP (VoIP) voice-and-data functionality; the router can carry voice traffic (for example, telephone calls and faxes) over an IP network
•Support for virtual private networking
•Modular architecture
•Network device integration
The Cisco 1750 router has the following hardware components:
•One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with manual override available)
•One Voice interface card slot—Supports a single voice interface card with two ports per card
•Two WAN interface card slots for either WAN interface cards (WICs) or voice interface cards (VICs)
•Synchronous serial interfaces on serial WAN interface cards
•Asynchronous serial interfaces on serial WAN interface cards
•ISDN WAN interface cards—ISDN dialup and ISDN leased line (IDSL) at 144 kbps; encapsulation over ISDN leased line: Frame Relay and PPP
•One auxiliary (AUX) port (up to 115.2 kbps asynchronous serial)
•One console port
•One internal expansion slot—Supports hardware-assisted services such as encryption (up to T1/E1) and, in the future, compression
•RISC Processor—Motorola MPC860T PowerQUICC at 48 MHz
•One security slot that supports Kensington or similar lockdown equipment
•DRAM memory: 16 MB default, expandable to 48 MB
•Flash memory: 4 MB default, expandable to 16 MB
•Desktop form factor
The Cisco 1750 router supports any combination of one or two of the following WAN interface cards, which are shared with the Cisco 1600, 1720, 2600, and 3600 routers:
•WIC-1T: One port high speed serial (sync/async)(T1/E1)
•WIC-2T: Two port high speed serial (sync/async) (T1/E1)
•WIC-2A/S: Two port low speed serial (sync/async) (up to 128 kbps)
•WIC-1B-S/T: One port ISDN BRI S/T
•WIC-1B-U: One port ISDN BRI U with integrated NT1
•WIC-1DSU-56K4: One port integrated 56/64 kbps 4-wire DSU/CSU
•WIC-1DSU-T1: One port integrated T1 / Fractional T1 DSU/CSU
•WIC-1ADSL: One-port asymmetric digital subscriber line (supported on the Cisco 1700, 2600, and 3600 series routers only)
•WIC-1ENET: One-port 10Base-T Ethernet interface
The Cisco 1750 router supports any combination of one or two of the following voice interface cards, which are shared with the Cisco 2600 and 3600 routers:
•VIC-2FXS: Two port Foreign Exchange Station (FXS) voice/fax interface card for voice/fax network module
•VIC-2FXO: Two port Foreign Exchange Office (FXO) voice/fax interface card for voice/fax network module
•VIC-2FXO-EU: Two port FXO voice/fax interface card for Europe
•VIC-2E/M: Two port Ear & Mouth (E&M) voice/fax interface card for voice/fax network module
Determining Your Software Release
To determine the version of Cisco IOS software running on your Cisco 1700 series router, log in to the platform and enter the show version EXEC command:
Cisco Internetwork Operating System Software
IOS (tm) 12.1 XT Software (c1700-y-mz), Version 12.1(3)XT1, RELEASE SOFTWARE
Upgrading to a New Software Release
For general information about upgrading to a new software release, see Software Installation and Upgrade Procedures located at: http://www.cisco.com/warp/public/130/upgrade_index.shtml.
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.1(3)XT2 supports the same feature sets as Releases 12.1 and 12.1 T, but Release 12.1(3)XT2 can include new features supported by the Cisco 1700 series routers.
Caution Cisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, the purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
Table 2 through Table 5 list the features and feature sets supported by the Cisco 1700 series routers in Cisco IOS Release 12.1(3)XT2. The tables use the following conventions:
•Yes—The feature is supported in the software image.
•No—The feature is not supported in the software image.
•In—The number in the "In" column indicates the Cisco IOS release in which the feature was introduced. For example, (2) means a feature was introduced in 12.1(2)T. If a cell in this column is empty, the feature was included in the initial base release.
Note These tables might not be cumulative or list all the features in each image. You can find the most current Cisco IOS documentation on CCO. These electronic documents may contain updates and modifications made after the hardcopy documents were printed.
Table 2 Feature List by Feature Set for the Cisco 1700 Series Routers, Part 1 of 4
| |
In
|
Feature Sets
|
Features
|
IP
|
IP/ADSL
|
IP/Plus/ ADSL
|
IP/Voice/ Plus/
ADSL
|
IP/Plus/ IPSec 56 (DES)/ ADSL
|
IP/Voice/Plus/ IPSec 56 (DES)/ ADSL
|
IP Multicast
|
|
|
|
|
|
|
|
Bidirectional PIM
|
(2T)
|
No
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing Protocols
|
|
|
|
|
|
|
|
OSPF Flooding Reduction
|
(2T)
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Multimedia and Quality of Service
|
|
|
|
|
|
|
|
H.323 V2 Enhancements
|
(3T)
|
No
|
No
|
No
|
Yes
|
No
|
Yes
|
Quality of Service Voice Enhancements
|
(3T)
|
No
|
No
|
No
|
Yes
|
No
|
Yes
|
Multiservice Applications
|
|
|
|
|
|
|
|
Voice over Frame Relay (Cisco 1750 only)
|
(2T)
|
No
|
No
|
No
|
Yes
|
No
|
Yes
|
Security
|
|
|
|
|
|
|
|
Secure Shell Version 1 Integrated Client
|
(3T)
|
No
|
No
|
No
|
No
|
Yes
|
Yes
|
SSH Version 1 Server Support
|
|
No
|
No
|
No
|
No
|
Yes
|
Yes
|
Virtual Private Network (VPN) Module for the Cisco 1700 Series Routers
|
(2T)
|
No
|
No
|
No
|
No
|
Yes
|
Yes
|
WAN
|
|
|
|
|
|
|
|
Frame Relay Switching Enhancements: Shaping and Policing
|
(2T)
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Single Port Ethernet WAN Interface Card for Cisco 1700 Series Routers
|
(3XT)
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 3 Feature List by Feature Set for the Cisco 1700 Series Routers, Part 2 of 4
| |
Feature Sets
|
Features
|
IP/FW/IDS
|
IP/FW/Voice/Plus/IPSec 56 (DES)/ADSL
|
IP/FW/Plus/ IP Sec 56 (DES)/ADSL
|
IP/Voice/FW/IDS/Plus/ IPSec 56/ ADSL
|
IP/IPX
|
IP/IPX/FW/IDS/Plus/ADSL
|
IP Multicast
|
|
|
|
|
|
|
Bidirectional PIM
|
No
|
Yes
|
Yes
|
Yes
|
No
|
Yes
|
IP Routing Protocols
|
|
|
|
|
|
|
OSPF Flooding Reduction
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Multimedia and Quality of Service
|
|
|
|
|
|
|
H.323 V2 Enhancements
|
No
|
Yes
|
No
|
Yes
|
No
|
No
|
Quality of Service Voice Enhancements
|
No
|
Yes
|
No
|
Yes
|
No
|
No
|
Multiservice Applications
|
|
|
|
|
|
|
Voice over Frame Relay (Cisco 1750 only)
|
No
|
Yes
|
No
|
Yes
|
No
|
No
|
Security
|
|
|
|
|
|
|
Secure Shell Version 1 Integrated Client
|
No
|
Yes
|
Yes
|
Yes
|
No
|
No
|
SSH Version 1 Server Support
|
No
|
Yes
|
Yes
|
Yes
|
No
|
No
|
Virtual Private Network (VPN) Module for the Cisco 1700 Series Routers
|
No
|
Yes
|
Yes
|
Yes
|
No
|
No
|
WAN
|
|
|
|
|
|
|
Frame Relay Switching Enhancements: Shaping and Policing
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Single Port Ethernet WAN Interface Card for Cisco 1700 Series Routers
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 4 Feature List by Feature Set for the Cisco 1700 Series Routers, Part 3 of 4
| |
Feature Sets
|
Features
|
IP/IPX/ Voice/FW/ IDS/Plus/
ADSL
|
IP/Plus/ IPSec 3DES/ ADSL
|
IP/Voice/Plus/ IPSec 3DES/ ADSL
|
IP/FW/Plus/ IPSec 3DES/ ADSL
|
IP/FW/ Voice/Plus/ IPSec 3DES/ ADSL
|
IP/IPX/AT/ IBM
|
IP Multicast
|
|
|
|
|
|
|
Bidirectional PIM
|
Yes
|
Yes
|
Yes
|
No
|
Yes
|
No
|
IP Routing Protocols
|
|
|
|
|
|
|
OSPF Flooding Reduction
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Multimedia and Quality of Service
|
|
|
|
|
|
|
H.323 V2 Enhancements
|
Yes
|
No
|
Yes
|
No
|
Yes
|
No
|
Quality of Service Voice Enhancements
|
Yes
|
No
|
Yes
|
Yes
|
Yes
|
No
|
Multiservice Applications
|
|
|
|
Yes
|
Yes
|
|
Voice over Frame Relay (Cisco 1750 only)
|
Yes
|
No
|
Yes
|
Yes
|
Yes
|
No
|
Security
|
|
|
|
|
|
|
Secure Shell Version 1 Integrated Client
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
No
|
SSH Version 1 Server Support
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
No
|
Virtual Private Network (VPN) Module for the Cisco 1700 Series Routers
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
No
|
WAN
|
|
|
|
|
|
|
Frame Relay Switching Enhancements: Shaping and Policing
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Single Port Ethernet WAN Interface Card for Cisco 1700 Series Routers
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 5 Feature List by Feature Set for the Cisco 1700 Series Routers, Part 4 of 4
| |
Feature Sets
|
Features
|
IP/IPX/AT/ IBM/Plus/ ADSL
|
IP/IPX/AT/ IBM/FW/Plus/ IPSec 56 (DES)/ ADSL
|
IP/IPX/AT/ IBM/FW/ Voice/Plus/ IPSec 56 (DES)/ ADSL
|
IP/IPX/AT/ IBM/FW/Plus/ IPSec 3DES/ ADSL
|
IP/IPX/AT/ IBM/FW/ Voice/Plus/ IPSec 3DES/ ADSL
|
IP Multicast
|
|
|
|
|
|
Bidirectional PIM
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing Protocols
|
|
|
|
|
|
OSPF Flooding Reduction
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Multimedia and Quality of Service
|
|
|
|
|
|
H.323 V2 Enhancements
|
No
|
No
|
Yes
|
No
|
Yes
|
Quality of Service Voice Enhancements
|
No
|
No
|
Yes
|
No
|
Yes
|
Multiservice Applications
|
|
|
|
|
|
Voice over Frame Relay (Cisco 1750 only)
|
No
|
No
|
No
|
No
|
No
|
Security
|
|
|
|
|
|
Secure Shell Version 1 Integrated Client
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
SSH Version 1 Server Support
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
Virtual Private Network (VPN) Module for the Cisco 1700 Series Routers
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
|
|
|
|
|
Frame Relay Switching Enhancements: Shaping and Policing
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Single Port Ethernet WAN Interface Card for Cisco 1700 Series Routers
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 1700 series routers for Release 12.1(3)XT2.
New Hardware Features in Release 12.1(3)XT
The following new hardware feature is supported by the Cisco 1700 series routers for Cisco IOS Release 12.1(3)XT:
1-Port 10Base-T Ethernet WAN Interface Card
The 10Base-T Ethernet WAN Interface Card is a 1-port WAN interface card for the Cisco 1700 series of modular access routers. It provides the Cisco 1700 series routers with an optional second Ethernet interface for small and branch office customers deploying a second perimeter local area network (LAN) for public access or to connect a cable/DSL modem for broadband access. It connects to the Cisco 1700 series router platform through a WAN interface card slot, and to a line-side twisted pair connection through an RJ-45 connector.
For configuration instructions, refer to the document Configuring a Single-Port Ethernet WIC on a Cisco 1700 Series Router.
Important Notes
The following sections contain important notes that can apply to the Cisco 1700 series routers.
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software causes a Cisco router or switch to halt and reload if the IOS HTTP service is enabled and you browse to http://router-ip/anytext?/ and enter the enable password when it is requested. This defect can be exploited to produce a denial of service (DoS) attack. This vulnerability can only be exploited if the enable password is known or not set.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Cisco urges all customers to upgrade to releases that are not vulnerable to this defect as listed in the complete advisory, which is available at: http://www.cisco.com/warp/public/707/ ioshttpserverquery-pub.shtml. You are strongly encouraged to read the complete advisory.
Cisco Express Forwarding
When installed in a Cisco 1720 or 1750 router, the Cisco Virtual Private Network (VPN) module does not support Cisco express forwarding (CEF).
Fan Operation in Cisco 1700 Series Routers
The fans in Cisco 1700 series routers stay off until thermally activated.
Flash defaults to Flash:1 on Multipartition Flash
When using a multipartition flash card, the various flash partitions are referred to as "flash:1:", "flash:2:", etc. If you specify only "flash" in a multipartition flash, the parser assumes "flash:1:." For example, if you enter show flash all, the parser defaults to "show flash:1: all" and only the flash information for the first partition displays. To see information for all flash partitions, enter show flash ?. This will list all of the valid partitions. Then enter show flash:xx: all on each valid partition.
Peak Cell Rate and Sustainable Cell Rate Values
On Cisco 1700 routers, specify the Peak Cell Rate (PCR) and Sustainable Cell Rate (SCR) as multiples of 32 Kbps. Other rates are treated as the next lower value of a multiple of 32. For example, an entered PCR value of 150 is considered 128.
Using the boot flash Command
Booting a Cisco 1700 series router with the commands boot flash or boot system flash results in unpredictable behavior. To work around this problem, be sure to enter a colon (:) following both commands (for example, boot flash: or boot system flash:.)
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious of these three severity levels.
All caveats in Cisco IOS Release 12.1 and Cisco IOS Release 12.1 T are also in Cisco IOS Release 12.1(3)XT1.
For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1.
For information on caveats in Cisco IOS Release 12.1 T, see Caveats for Cisco IOS Release 12.1 T, which lists severity 1 and 2 caveats and is located on CCO and the Documentation CD-ROM.
Note If you have an account with CCO, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, Login to CCO and click Software Center: Cisco IOS Software: Cisco Bugtool Navigator II. Another option is to go directly to http://www.cisco.com/support/bugtools.
Caveats for Release 12.1(3)XT2
This section describes possibly unexpected behavior by Release 12.1(3)XT2.
CSCds04747
Connection setup improvements.
CSCds32217
D-write community string readable with read-only community, Cisco IOS.
Caveats for Release 12.1(3)XT1
This section describes possibly unexpected behavior by Release 12.1(3)XT1.
CSCds46022
If you are using a 1-Port ADSL WAN Interface Card and IOS software Release 12.1(3)XT1, two debug traceback messages appear during boot-up.
12.1 XT
12.1(3)XT1
Related Documentation
The following sections describe the documentation available for the Cisco 1700 series routers. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with the documents listed in the following sections:
•Release-Specific Documents
•Platform-Specific Documents
•Feature Modules
•Cisco IOS Software Documentation Set
Release-Specific Documents
The following documents are specific to Release 12.1. They are located on CCO and the Documentation CD-ROM.
•Release Notes for Cisco IOS Release 12.1
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•Product bulletins, field notices, and other release-specific documents on CCO at:
Technical Documents: Product Bulletins
•Caveats for Cisco IOS Release 12.1 and 12.1 T
As a supplement to the caveats listed in the "Caveats" section section in these release notes, see the Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1 T documents, which contain caveats applicable to all platforms for all maintenance releases of IOS Releases 12.1 and 12.1 T.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
Note If you have an account with CCO, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, Login to CCO and click Software Center: Cisco IOS Software: Cisco Bugtool Navigator II. Another option is to go directly to http://www.cisco.com/support/bugtools.
Platform-Specific Documents
Cisco 1720
These documents are available for the Cisco 1720 router on CCO and the Documentation CD-ROM:
•Installing Your Cisco 1720
•Cisco 1720 Router Hardware Installation Guide
•Cisco 1700 Router Software Configuration Guide
•Regulatory Compliance and Safety Information
•Configuration Notes
•Release Notes for the Cisco 1720 Router
•WAN Interface Cards Hardware Installation Guide
On CCO at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 1720 Router
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 1720 Router
Cisco 1750
These documents are available for the Cisco 1750 router on CCO and the Documentation CD-ROM:
•Cisco 1750 Router Hardware Installation Guide
•Voice-over-IP Quick Start Guide
•Cisco 1750 Software Configuration Guides
•Cisco WAN Interface Cards Hardware Installation Guide
•Cisco 1700 Series Routers Configuration Notes
•Release Notes for the Cisco 1750 Router
•Safety Information for Cisco 1600 and 1700 Routers
On CCO at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 1750 Router
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 1750 Router
Feature Modules
Feature modules describe new features supported by Release 12.1(3)XT2 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in 12.1-Based Limited Lifetime Releases: New Features in 12.1X Releases
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in 12.1-Based Limited Lifetime Releases: New Features in 12.1X Releases
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two types of books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
The Cisco IOS software documentation set is available on CCO and on the Documentation CD-ROM.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Release 12.1 Documentation Set
Table 6 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is available in both electronic and printed form.
Note You can find the most current Cisco IOS documentation on CCO and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
Table 6 Cisco IOS Software Release 12.1 Documentation Set
Books
|
Chapter Topics
|
•Cisco IOS Configuration Fundamentals Configuration Guide
•Cisco IOS Configuration Fundamentals Command Reference
|
Configuration Fundamentals Overview
Using the Command-Line Interface (CLI)
Using Configuration Tools
Configuring Operating Characteristics
Managing Connections, Menus, and System Banners
Using the Cisco Web Browser
Using the Cisco IOS File System
Modifying, Downloading, & Maintaining Configuration Files
Loading and Maintaining System Images
Maintaining Router Memory
Rebooting a Router
Configuring Additional File Transfer Functions
Monitoring the Router and Network
Troubleshooting a Router
Performing Basic System Management
System Management Using System Controllers
Web Scaling Using WCCP
Managing Dial Shelves
|
|
•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide
•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference
|
Overview of Apollo Domain, Banyan VINES, DECNET, ISO
CLNS, and XNS
Configuring Apollo Domain
Configuring Banyan VINES
Configuring DECnet
Configuring IOS CLNS
Configuring XNS
|
|
•Cisco IOS AppleTalk and Novell IPX Configuration Guide
•Cisco AppleTalk and Novell IPX Command Reference
|
AppleTalk and Novel IPX Overview
Configuring AppleTalk
Configuring Novell IPX
|
•Cisco IOS Bridging and IBM Networking Configuration Guide
•Cisco IOS Bridging and IBM Networking Command Reference, Volume I
•Cisco Bridging and IBM Networking Command Reference, Volume II
|
Configuring Remote Source-Route Bridging
Configuring Data-Link Switching Plus+
Configuring Serial Tunnel and Block Serial Tunnel
Configuring LLC2 and SDLC Parameters
Configuring IBM Network Media Translation
Configuring Frame Relay Access Support
Configuring NCIA Server
Configuring the Airline Product Set
Configuring DSPU and SNA Service Point Support
Configuring SNA Switching Services
Configuring Cisco Transaction Connection
Configuring Cisco Mainframe Channel Connection Adapters
Configuring CLAW and TCP/IP Offload Support
Configuring CMPC and CSNA
Configuring CMPC+
Configuring the TN3270 Server
|
•Cisco IOS Dial Services Configuration Guide: Terminal Services
•Cisco IOS Dial Services Configuration Guide: Network Services
•Cisco IOS Dial Services Command Reference
|
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Networks
X.25 on ISDN Solutions
Telco Solutions
Dial-Related Addressing Services
Internetworking Dial Access Scenarios
Preparing for Dial Access
Modem Configuration and Management
ISDN and Signalling Configuration
PPP Configuration
Dial-on-Demand Routing Configuration
Dial-Backup Configuration
Terminal Service Configuration
|
•Cisco IOS Interface Configuration Guide
•Cisco IOS Interface Command Guide
|
Interface Configuration Overview
Configuring LAN Interfaces
Configuring Serial Interfaces
Configuring Logical Interfaces
|
•Cisco IOS IP and IP Routing Configuration Guide
•Cisco IOS IP and IP Routing Command Reference
|
IP Overview
Configuring IP Addressing
Configuring DHCP
Configuring IP Services
Configuring Mobile IP
Configuring On-Demand Routing
Configuring RIP
Configuring IGRP
Configuring OSPF
Configuring IP Enhanced IGRP
Configuring Integrated IS-ISConfiguring BGP
Configuring Multicast BGP (MBGP)
Configuring IP Routing Protocol-Independent Features
Configuring IP Multicast Routing
Configuring Multicast Source Discovery Protocol
Configuring PGM Router Assist
Configuring Unidirectional Link Routing
Using IP Multicast Tools
|
|
|
|
|
•Cisco IOS Multiservice Applications Configuration Guide
•Cisco IOS Multiservice Applications Command Reference
|
Multiservice Applications Overview
Configuring Voice over IP
Configuring Gatekeepers (Multimedia Conference Manager)
Configuring Voice over Frame Relay
Configuring Voice over ATM
Configuring Voice over HDLC
Configuring Voice-Related Support Features
Configuring PBX Signaling
Configuring Store and Forward Fax
Configuring Video Support
Configuring Head-End Broadband Access Router Features
Configuring Subscriber-End Broadband Access Router
Features
Configuring Synchronized Clocking
|
•Cisco Quality of Service Solutions Configuration Guide
•Cisco IOS Quality of Service Solutions Command Reference
|
Quality of Service Overview
Classification Overview
Configuring Policy-Based Routing
Configuring QoS Policy Propagation via Border Gateway
Protocol
Configuring Committed Access Rate
Congestion Management Overview
Configured Weighted Fair Queueing
Configuring Custom Queueing
Configuring Priority Queueing
Congestion Avoidance Overview
Configuring Weighted Random Early Detection
Policing and Shaping Overview
Configuring Generic Traffic Shaping
Configuring Frame Relay and Frame Relay Traffic Shaping
Signalling Overview
Configuring RSVP
Configuring Subnetwork Bandwidth Manager
Configuring RSVP-ATM Quality of Service Internetworking
Link Efficiency Mechanisms Overview
Configuring Link Fragmentation and Interleaving for Multilink
PPP
Configuring Compressed Real-Time Protocol
IP to ATM CoS Overview
Configuring IP to ATM CoS
QoS Features for Voice Introduction
|
|
|
•Cisco IOS Security Configuration Guide
•Cisco IOS Security Command Reference
|
TACACS+ Commands
Access Control Lists: Overview and Guidelines
Cisco Secure Integrated Software Firewall Overview
Configuring Lock-and-Key Security (Dynamic Access Lists)
Configuring IP Session Filtering (Reflexive Access Lists)
Configuring TCP Intercept (Prevent Denial-of-Service Attacks)
Configuring Context-Based Access Control
Configuring Cisco Secure Integrated Software Intrusion
Detection System
Configuring Authentication Proxy
Configuring Port to Application Mapping
IP Security and Encryption Overview
Configuring IPSec Network Security
Configuring Certification Authority Interoperability
Configuring Internet Key Exchange Security Protocol
Configuring Passwords and Privileges
Neighbor Router Authentication: Overview and Guidelines
Configuring IP Security Options
|
|
|
|
•Cisco IOS Switching Services Configuration Guide
•Cisco IOS Switching Services Command Reference
|
Configuring MPLS
Configuring IP Multilayer Switching
Configuring IP Multicast Multilayer Switching
Configuring IPX Multilayer Switching
Configuring Multicast Distributed Switching
Routing Between VLANs Overview
Configuring Routing Between VLANs with ISL Encapsulation
Configuring Routing Between VLANs with IEEE 802.10
Encapsulation
Configuring Routing Between VLANs with IEEE 802.1Q Encapsulation
LAN Emulation Overview
Configuring LAN Emulation
Configuring Token Ring LANE
MPOA Overview
Configuring the MPOA Client
Configuring the MPOA Server
Configuring Token Ring LANE for MPOA
|
•Cisco IOS Wide-Area Networking Configuration Guide
•Cisco IOS Wide-Area Networking Command Reference
|
Wide-Area Networking Overview
Configuring ATM
Frame Relay
Frame Relay-ATM Internetworking
Configuring SMDS
Configuring X.25 and LAPB
|
•Cisco IOS Configuration Guide Master Index
•Cisco IOS Command Reference Master Index
•Cisco IOS Command Summary
•Cisco IOS Debug Command Reference
•Cisco IOS Dial Services Quick Configuration Guide
•Cisco IOS New Features Index
(CCO and Documentation CD only)
•Cisco IOS System Error Messages
|
|
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
•http://www.cisco.com
•http://www-china.cisco.com
•http://www-europe.cisco.com
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:
http://www.cisco.com/cgi-bin/order/order_root.pl
•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:
http://www.cisco.com/go/subscription
•Nonregistered CCO users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883
We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.
•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.
•P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
