Cisco 100-Megabit Ethernet SFP Modules Compatibility Matrix
Revised: March 11, 2013
Note
For the clearest readability of these tables, please use the PDF version provided in the upper right side of your browser screen. The HTML version may have confusing alignment of table data.
Note
Requirements and procedures for initial configurations and software upgrades tend to change and therefore appear only in the switch or router software release notes. Before installing, configuring, or upgrading a switch, refer to the product release notes on Cisco.com for the latest information. This matrix does not replace or supercede the release notes.
This document describes the Cisco platforms and software versions that support the 100-Megabit Ethernet Small Form-Factor Pluggable (SFP) modules. Table 1 lists the model numbers and operating wavelengths for the modules. The other tables are as follows:
•
Table 2, Router Support and Minimum Software Requirements
•
Table 3, Catalyst 6500 Series Support and Minimum Software Requirements
•
Table 4, Metro Ethernet Support and Minimum Software Requirements
•
Table 5, Catalyst 4500 Series and Catalyst 4900 Series Support and Minimum Software Requirements
•
Table 6, Cisco Industrial Ethernet and Smart Grid Series Support and Minimum Software Requirements
•
Table 7, Catalyst 3XXX Series Support and Minimum Software Requirements
•
Table 8, Catalyst 2XXX Series Support and Minimum Software Requirements
•
Table 9, Catalyst Express 500 Support and Minimum Software Requirements
Table 1 100-MB Ethernet SFP Transceiver Module Models
Model Number
|
Description
|
GLC-GE-100FX=
|
100BASE-FX SFP module for Gigabit Ethernet ports, 1310 nm wavelength, 2 km over MMF1
|
GLC-FE-100FX=
|
100BASE-FX SFP module for 100-MB ports, 1310 nm wavelength, 2 km over MMF
|
GLC-FE-100EX=
|
100BASE-FX SFP module for 100-MB ports, 1310 nm wavelength, 40 km over SMF
|
GLC-FE-100LX=
|
100BASE-FX SFP module for 100-MB ports, 1310 nm wavelength, 10 km over SMF2
|
GLC-FE-100BX-D=
|
100BASE-BX10-D SFP module for 100-MB ports, 1550 nm TX3 /1310 nm RX4 wavelength, 10 km over single-strand SMF
|
GLC-FE-100BX-U=
|
100BASE-BX10-U SFP module for 100-MB ports, 1310 nm TX/1550 nm RX wavelength, 10 km over single-strand SMF
|
GLC-FE-100ZX=
|
100BASE-ZX SFP module for 100-MB ports, 1550 nm wavelength, 80 km over SMF
|
GLC-FE-100FX-RGD=
|
100BASE-FX SFP module for Industrial Ethernet 100-MB ports, 1310 nm wavelength, 2 km over MMF
|
GLC-FE-100LX-RGD=
|
100BASE-LX SFP module for Industrial Ethernet 100-MB ports, 1310 nm wavelength, 10 km over SMF
|

Note
When you order one of the devices listed, you must order the SFP modules separately.
Table 2 Router Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Cisco 892F Series
|
CISCO892F-K9 CISCO892FW-K9
|
GLC-GE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.1(2)T
|
Cisco 1921 Series Router
|
EHWIC-1GE-SFP-CU
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.1(4)M
|
Cisco 1941 Series Router
|
EHWIC-1GE-SFP-CU
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.1(4)M
|
Cisco 2900 Series Router
|
Cisco 2921 Cisco 2951
|
GLC-GE-100FX
|
—
|
15.0(1)M
|
| |
SM-D-ES3G-48-P SM-D-ES3-48-P SM-D-ES2-48
|
GLC-GE-100FX
|
—
|
15.0(1)M
|
| |
EHWIC-1GE-SFP-CU
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.1(4)M
|
Cisco 3900 Series Router
|
Cisco 3925 Cisco 3945
|
GLC-GE-100FX
|
—
|
15.0(1)M
|
| |
SM-D-ES3G-48-P SM-D-ES3-48-P SM-D-ES2-48
|
GLC-GE-100FX
|
—
|
15.0(1)M
|
| |
EHWIC-1GE-SFP-CU
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.1(4)M
|
Cisco 7200 Series
|
NPE-G2 Native Gigabit Ethernet Port and 72011 series
|
GLC-GE-100FX
|
—
|
12.2(33)SRC2 12.4(15)T7 12.4(20)T1
|
Cisco 7600 Series
|
WS-X6148-FE-SFP
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(18)SXF
|
| |
7600-ES+20G3C
7600-ES+20G3CXL
76-ES+T-20G
76-ES+XC-20G3C
76-ES+XC-20G3CXL
Note On ES+ line cards, only 1GE port encoding is supported.
|
GLC-GE-100FX
|
—
|
15.0(1)S
|
ASR_1000 Series Router
|
ASR1001 ASR1002 ASR1002-F
|
GLC-GE-100FX
|
—
|
XE 2.5
|
ASR 9000 Series Router
|
A9K-40GE-B A9K-40GE-E
|
GLC-GE-100FX
|
—
|
XR 3.7.3
|
| |
A9K-2T20GE-B A9K-2T20GE-E A9K-2T20GE-L A9K-40GE-L
|
GLC-GE-100FX
|
—
|
XR 3.9.0
|
| |
A9K-MPA-20X1GE
|
GLC-GE-100FX
|
—
|
XR 4.2.0
|
| |
ASR-9001
|
GLC-GE-100FX
|
—
|
XR 4.2.1
|
Cisco ASR 901 Series
|
A901-4C-F-D A901-4-C-FT-D A901-6CZ-F-D A901-6-CZ-FT-D A901-6CZ-F-A A901-6-CZ-FT-A
|
GLC-FE-100FX-RGD
|
—
|
15.2(2)SNH1
|
Cisco ASR 903 Series
|
A900-IMA8S
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD
|
—
|
XE 3.5.0S
|
Shared Port Adapters (SPAs)
|
SPA-5X1GE-V2 SPA-8X1GE-V2 SPA-10X1GE-V2
|
GLC-GE-100FX
|
SPA software support is determined by the platform on which the SPA is installed. Refer to the SPA release notes for the correct software release.
|
Table 3 Catalyst 6500 Series Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Catalyst 6500 series
|
WS-X6148-FE-SFP
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-FE-100EX GLC-FE-100ZX
|
8.4(1) 8.4(1) 8.4(1) 8.4(1) 8.5(1) 8.5(1)
|
12.2(18)SXF 12.2(18)SXF 12.2(18)SXF 12.2(18)SXF 12.2(18)SXF3 12.2(18)SXF3
|
Table 4 Metro Ethernet Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
ME 6500 Series
|
ME-C6524GS-8S ME-C6524GT-8S
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(18)ZU
|
Catalyst 3750 Metro
|
ME-C3750-24TE-MA (non-ES ports only)
ME-C3750-24TE-MD (non-ES ports only)
|
GLC-GE-100FX
|
—
|
12.2(25)EY
|
Cisco ME 3400
|
ME-3400-24TS-A ME-3400-24TS-D
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(25)EX
12.2(46)SE
|
| |
ME-3400G-12CS-A ME-3400G-12CS-D
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(25)SEG1
12.2(46)SE
|
| |
ME-3400G-2CS-A
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(35)SE1
12.2(46)SE
|
|
ME-3400-24FS-A
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(40)SE
12.2(46)SE
|
| |
ME-3400E-24TS-M ME-3400EG-2CS-A ME-3400EG-12CS-M
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(44)EY
|
Cisco ME 2400
|
ME-2400-24TS-A ME-2400-24TS-D
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(25)EX
|
Cisco ME 3600X
|
ME-3600X-24FS-M (client ports only)
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(52)EY
|
| |
ME-3600X-24CX-M
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD
|
15.2(2)S
|
15.2(2)S
|
Cisco ME 3800X
|
ME-3800X-24FS-M (client ports only)
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(52)EY
|
Table 5 Catalyst 4500 Series and Catalyst 4900 Series Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Catalyst 4500 series
|
WS-X4248-FE-SFP
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX GLC-FE-100ZX
|
—
—
|
12.2(25)SG
12.2(53)SG8
|
| |
WS-X4640-CSFP-E WS-4624-SFP-E WS-X4612-SFP-E
|
GLC-GE-100FX
|
—
|
15.1(1)SG
|
Catalyst 4900 Series
|
WS-C4948E WS-X4908 With CVR-X2-SFP Twin Gig converter in a WS-C4900M
|
GLC-GE-100FX
|
—
|
15.1(1)SG
|
Table 6 Cisco Industrial Ethernet and Smart Grid Series Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Cisco IE2000 Series
|
IE-2000-4TS-L IE-2000-4TS-B IE-2000-8TC-L IE-2000-8TC-B IE-2000-16TC-L IE-2000-16TC-B IE-2000-16TC-G-L IE-2000-16TC-G-E IE-2000-16TC-G-X IE-2000-16TC-G-N
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD GLC-FE-100FX GLC-FE-100LX GLC-FE-100EX1 GLC-FE-100ZX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.0(1)EY
|
Cisco IE3000 Series
|
IE-3000-4TC
IE-3000-8TC
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD
GLC-FE-100BX-D GLC-FE-100BX-U
GLC-FE-100EX1
|
—
|
12.2(44)EX
12.2(50)SE
12.2(55)SE
|
Cisco IE3010 Series
|
IE-3010-16S-8PC
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(53)EZ
|
Cisco 2500 Connected Grid Switch Series
|
CGS-2520-24TC
CGS-2520-16S-8PC
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-FE-100EX GLC-FE-100ZX
|
—
|
12.2(53)EX
|
Cisco 2000 Connected Grid Router Series
|
CGR 2010
|
GLC-FE-100FX-RGD GLC-FE-100LX-RGD
|
—
|
15.1(1)T
|
Table 7 Catalyst 3XXX Series Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Catalyst 3750 Series
|
WS-C3750-24PS WS-C3750-24TS WS-C3750-48PS WS-C3750-48TS WS-C3750G-12S WS-C3750G-24PS WS-C3750G-24TS WS-C3750G-24TS-E1U WS-C3750G-24TS-S1U WS-C3750G-48PS WS-C3750G-48TS
|
GLC-GE-100FX
|
—
|
12.2(20)SE 12.2(20)SE 12.2(20)SE 12.2(20)SE 12.2(20)SE 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3
|
| |
WS-C3750-24FS-S
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(25)SEB
|
| |
WS-C3750V2-24PS WS-C3750V2-24TS WS-C3750V2-48PS WS-C3750V2-48TS
|
GLC-GE-100FX
|
—
|
12.2(50)SE
|
| |
WS-C3750V2-24FS-S
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(50)SE
|
Catalyst 3750-E Series
|
WS-C3750E-24TD WS-C3750E-24PD WS-C3750E-48TD WS-C3750E-48PD WS-C3750E-48PDF
|
GLC-GE-100FX
|
Not supported
|
12.2(35)SE2
|
Catalyst 3750-X Series
|
WS-C3750X-24T WS-C3750X-48T WS-C3750X-24P WS-C3750X-48P WS-C3750X-48PF
With C3KX-NM-1G and C3KX-NM-10G (slots 1 and 3) network modules
|
GLC-GE-100FX
|
—
|
12.2(53)SE
|
| |
WS-C3750X-12S WS-C3750X-24S
Client ports and uplink ports with C3KX-NM-1G and C3KX-NM-10G (slots 1 and 3) network modules
|
GLC-GE-100FX
|
—
|
12.2(58)SE1
|
Catalyst 3560 Series
|
WS-C3560-24PS WS-C3560-48PS WS-C3560-24TS WS-C3560-48TS WS-C3560G-24PS WS-C3560G-24TS WS-C3560G-48PS WS-C3560G-48TS
|
GLC-GE-100FX
|
—
|
12.2(20)SE 12.2(20)SE 12.2(20)SE 12.2(20)SE 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3 12.2(20)SE3
|
| |
WS-C3560-8PC
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(35)SE
|
| |
WS-C3560-12PC-S
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(46)SE
|
| |
WS-C3560V2-24PS WS-C3560V2-24TS WS-C3560V2-48PS WS-C3560V2-48TS
|
GLC-GE-100FX
|
—
|
12.2(50)SE
|
Catalyst 3560-E Series
|
WS-C3560E-24TD WS-C3560E-24PD WS-C3560E-48TD WS-C3560E-48PD WS-C3560E-48PDF
|
GLC-GE-100FX
|
Not supported
|
12.2(35)SE2
|
| |
WS-C3560E-12SD WS-C3560E-12D
|
GLC-GE-100FX
|
Not supported
|
12.2(44)SE
|
Catalyst 3560-X Series
|
WS-C3560X-24T WS-C3560X-48T WS-C3560X-24P WS-C3560X-48P WS-C3560X-48PF
With C3KX-NM-1G and C3KX-NM-10G (slots 1 and 3) network modules
|
GLC-GE-100FX
|
—
|
12.2(53)SE
|
Catalyst 3560-C Series
|
WS-C3560CG-8TC-S WS-C3560CG-8PC-S
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(55)EX
|
| |
WS-C3560C-8PC-S WS-C3560C-12PC-S
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(55)EX3
|
Table 8 Catalyst 2XXX Series Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Catalyst Operating System
|
Cisco IOS Release
|
Catalyst 2970 Series
|
WS-C2970G-24TS-E
|
GLC-GE-100FX
|
—
|
12.2(20)SE
|
Catalyst 2960 Series
|
WS-C2960-24TC-L WS-C2960-48TC-L WS-C2960G-24TC-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(25)FX
|
| |
WS-C2960-24TC-S WS-C2960-48TC-S WS-C2960-24LC-S
|
GLC-GE-100FX GLC-FE-100FX
|
—
|
12.2(37)EY
|
| |
WS-C2960-8TC-L WS-C2960G-8TC-L
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(35)SE
|
| |
WS-C2960G-48TC-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(25)SEE
|
Catalyst 2960 Series
(continued)
|
WS-C2960-24PC-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(44)SE
|
| |
WS-2960-8TC-S
|
GLC-FE-100FX
|
—
|
12.2(46)SE
|
| |
WS-2960-48PST-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(46)SE
|
Catalyst 2960-S Series
|
WS-C2960S-24TS-S WS-C2960S-48TS-S
|
GLC-GE-100FX GLC-FE-100FX
|
—
|
12.2(53)SE1
|
| |
WS-C2960S-48FPS-L WS-C2960S-48LPS-L WS-C2960S-24PS-L WS-C2960S-48TS-L WS-C2960S-24TS-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
12.2(53)SE1
|
Catalyst 2960-SF Series
|
2960S-F48TS-S 2960S-F24TS-S
|
GLC-GE-100FX GLC-FE-100FX
|
—
|
15.0(2)SE
|
| |
WS-C2960S-F48FPS-L WS-C2960S-F48LPS-L WS-C2960S-F24PS-L WS-C2960S-F48TS-L WS-C2960S-F24TS-L
|
GLC-GE-100FX GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
—
|
15.0(2)SE
|
Catalyst 2960-C Series
|
WS-C2960CG-8TC-L
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
Not supported
|
12.2(55)EX1
|
WS-C2960C-8TC-S
|
GLC-FE-100FX
|
Not supported
|
12.2(55)EX3
|
WS-C2960C-8TC-L WS-C2960C-8PC-L WS-C2960C-12PC-L
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U
|
Not supported
|
12.2(55)EX3
|
Table 9 Catalyst Express 500 Support and Minimum Software Requirements
| |
|
|
Minimum Software Release Required
|
Platform
|
Switch or Module
|
Transceiver Model
|
Cisco IOS Release
|
DOM Support
|
Catalyst Express 500
|
WS-CE500-24LC WS-CE500-24PC WS-CE500G-12TC
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-GE-100FX
|
12.2(25)FY
|
—
|
Catalyst Express 520
|
WS-CE520-8PC-K9
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-GE-100FX
|
12.2(35)EX
|
—
|
| |
WS-CE520-24LC-K9 WS-CE520-24PC-K9 WS-CE520G-24TC-K9
|
GLC-FE-100FX GLC-FE-100LX GLC-FE-100BX-D GLC-FE-100BX-U GLC-GE-100F
|
12.2(37)EX
|
—
|
Related Documentation
Refer to the Cisco Small Form-Factor Pluggable Modules Installation Notes for hardware information.
Other documents that provide compatibility information about the SFP modules and the devices supporting them are available from this URL:
http://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_support_tables_list.html
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What's New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What's New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS Version 2.0
.
