DOCSIS 1.1 for Cisco uBR7200 Series
Universal Broadband Routers
Cisco IOS Release 12.1(7)CX1
October 1, 2001
OL-0564-02
This document describes the support for version 1.1 of the Data Over Cable System Interface Specifications (DOCSIS) in Cisco IOS Release 12.1(7)CX1 for the Cisco uBR7200 series universal broadband routers. This document focuses on the new software and the changes to the existing software architecture that provide DOCSIS 1.1 support. This document also describes Cable Modem Termination System (CMTS) to Cable Modem interoperability and provides instructions for migrating from DOCSIS 1.0 to DOCSIS 1.1.
This document includes the following sections:
•
Supported Standards, MIBs, and RFCs
Note
Feature Overview
DOCSIS 1.1 is the first major revision of the initial DOCSIS 1.0 standard for cable networks. Although the initial standard provided quality data traffic over the coaxial cable network, the demands of real-time traffic such as voice and video required many changes to the DOCSIS specification.
Note
Feature History
Table 1 summarizes the history of the DOCSIS 1.1 for Cisco uBR7200 series routers feature set.
Table 1 Cisco IOS 12.1 CX Feature History
12.1(4)CX
The DOCSIS 1.1 feature for Cisco uBR7200 series routers was introduced.
12.1(7)CX1
Several DOCSIS 1.1 MIBs were updated, reflecting changes in the DOCSIS 1.1 specification:
•
Note
•
•
•
The cable submgmt default command was also added, to set the default value of the attributes in DOCS-SUBMGT-MIB.
DOCSIS 1.1 Enhancements
The DOCSIS 1.1 specification provides the following functional enhancements over DOCSIS 1.0 coaxial cable networks:
•
–
–
–
–
•
–
–
–
–
–
•
•
•
•
•
•
•
DOCSIS 1.1 Quality of Service
The DOCSIS 1.1 QoS framework is based on the following objects:
•
•
•
•
In DOCSIS 1.1, the basic unit of QoS is the service flow, which is a unidirectional sequence of packets transported across the RF interface between the cable modem and CMTS. A service flow is characterized by a set of QoS parameters such as latency, jitter, and throughput assurances.
Every cable modem establishes a primary service flow in both the upstream and downstream directions. The primary flows maintain connectivity between the cable modem and CMTS at all times.
In addition, a DOCSIS 1.1 cable modem can establish multiple secondary service flows. The secondary service flows either can be permanently created (they persist until the cable modem is reset or powered off) or can be created dynamically to meet the needs of the on-demand traffic being transmitted.
Each service flow has a set of QoS attributes associated with it. These QoS attributes define a particular class of service and determine characteristics such as the maximum bandwidth for the service flow and the priority of its traffic. The class of service attributes can be inherited from a preconfigured CMTS local service class (class-based flows), or they can be individually specified at the time of the creation of the service flow.
Each service flow has multiple packet classifiers associated with it, which determine the type of application traffic allowed to be sent on that service flow. Each service flow can also have a Payload Header Suppression (PHS) rule associated with it to determine which portion of the packet header will be suppressed when packets are transmitted on the flow.
Figure 1 illustrates the mapping of packet classifiers.
Figure 1 Classification within the MAC Layer
Quality of Service Comparison
Quality of service (QoS) is a measure of performance for a transmission system that reflects its transmission quality and service availability. This section describes the differences in QoS between DOCSIS 1.0, 1.0+, and 1.1
DOCSIS 1.0
DOCSIS1.0 uses a static QoS model that is based on a class of service (CoS) that is preprovisioned in the TFTP configuration file for the cable modem. The CoS is a bidirectional QoS profile that has limited control, such as peak rate limits in either direction, and relative priority on the upstream.
DOCSIS 1.0 defines the concept of a service identifier (SID), which specifies the devices allowed to transmit and provided device identification and CoS. In DOCSIS 1.0, each cable modem is assigned only one SID, creating a one-to-one correspondence between a cable modem and the SID. All traffic originating from, or destined for, a cable modem is mapped to that cable modem's SID.
Typically, a DOCSIS 1.0 cable modem has one CoS and treats all traffic the same, which means that data traffic on a cable modem can interfere with the quality of a voice call in-progress. The CMTS, however, can prioritize downstream traffic based on IP precedent type-of-service (ToS) bits. For example, voice calls using higher IP precedence bits receive a higher queueing priority (but without a guaranteed bandwidth or rate of service). A DOCSIS 1.0 cable modem could increase voice call quality by permanently reserving bandwidth for voice calls, but then that bandwidth would be wasted whenever a voice call is not in progress.
DOCSIS 1.0+
In response to the limitations of DOCSIS 1.0 in handling real-time traffic, such as voice calls, Cisco created the DOCSIS 1.0+ extensions to provide the more important QoS enhancements that were expected in DOCSIS 1.1. In particular, the DOCSIS 1.0+ enhancements provide basic Voice-over-IP (VoIP) service over the DOCSIS link.
Cisco's DOCSIS 1.0+ extensions include the following DOCSIS 1.1 features:
•
•
•
•
•
Caution
DOCSIS 1.1
DOCSIS 1.1 implemented a number of changes to allow great flexibility in the ability of a cable modem and service provider to transmit almost any combination of data traffic and real-time traffic, such as voice and video. These changes required a fundamental shift in how a cable modem requests service and how traffic can be transmitted across the cable network.
In DOCSSI 1.1, a service flow gets created at the time of cable modem registration (a static service flow) or as a result of a dynamic MAC message handshake between the cable modem and the CMTS (a dynamic service flow). At any given time, a service flow might be in one of three states (provisioned, admitted, or active). Only active flows are allowed to pass traffic on the DOCSIS link.
Every service flow has a unique (unique per DOCSIS MAC domain) identifier called the service flow identifier (SFID). The upstream flows in the admitted and active state have an extra Layer 2 SID associated with them. The SID is the identifier used by the MAC scheduler when specifying time-slot scheduling for different service flows.
When a packet is presented to the DOCSIS MAC layer at the CMTS or cable modem, it is compared to a set of packet classifiers until a matching classifier is found. The SFID from this classifier is used to identify the service flow on which the packet will be sent. The packet is then transferred to the service flow manager for rate shaping and output queueing.
In the upstream direction, the output queues at the cable modem get remotely served by the CMTS MAC scheduler, based on DOCSIS 1.1 slot scheduling constraints such as grant-interval and grant-jitter. In the downstream direction, the CMTS packet scheduler serves the flow queues depending on the flow attributes like traffic priority, guaranteed rate, and delay bound.
The principal mechanism for providing enhanced QoS is to classify packets traversing the RF MAC interface into service flows. A service flow is a MAC-layer transport service that provides unidirectional transport of packets to upstream packets transmitted by the cable modem or to downstream packets transmitted by the CMTS.
DOCSIS 1.1 adds several new MAC scheduling disciplines to provide guaranteed QoS for real-time service flows on the multiple access upstream channel. Multiple grants per interval helps in supporting multiple subflows (such as voice calls) on the same SID. Multiple subflows per SID reduces the minimum SID requirement in cable modem hardware.
The CMTS is responsible for supporting QoS for all cable modems in its control. The traffic in the downstream is assumed to be a combination of voice, committed information rate (CIR) data, and excess burst best-effort data. To provide QoS support, the following functions must be performed:
•
•
•
•
The admission control block helps the overall downstream QoS block to track the current bandwidth reservation state on a per-downstream basis. Decisions can be made whether to admit or reject a request for a new service flow on that DS channel, based on this reservation state and the QoS guarantees requested by the new service-flow.
IP packet classifiers help in filtering out unique service flows on an interface for differential QoS treatment. Rather than doing per-cable modem downstream rate shaping, DOCSIS 1.1 software provides rate shaping at a much more granular level of individual service flows of the cable modem.
Note
DOCSIS 1.1 Features in Cisco IOS Release 12.1 CX
The following sections describe the DOCSIS 1.1 software features that appear in Cisco IOS Release 12.1 CX, including the commands used to implement the features.
Cable Modem Database Manager
The Cable Modem Database Manager is a new software module that manages cable modem information on the CMTS. This module can be queried to obtain different types of information on a single cable modem (or a group of cable modems). Information maintained on a per cable-modem basis includes DOCSIS MAC capabilities, counters, errors, QoS configuration, MAC state, connectivity statistics, and so on.
Commands
Router# show cable modemService Flow Manager
The Service Flow Manager is a new module that manages different activities related to service flows on a cable interface. Typical events include the creation of new DOCSIS service flows, modification of the attributes of existing service flows, and the deletion of service flows.
Commands
Router# show interface cable x/y service-flowRouter# debug cab qosService Template/Class Manager
The Service Template/Class Manager is a software module that controls the creation, updating, and cleanup of various QoS service templates and user-defined service classes on the CMTS.
Commands
Router# show cable service-classRouter# show int cx/y cable qos-paramsetRouter(config)# cable service class nRouter# debug cable qosTLV Parser/Encoder
The TLV parser/encoder is a new module that handles parsing and encoding TLVs on the CMTS. All old DOCSIS1.0/1.0+ TLVs are supported. In addition, many new TLVs have been added in DOCSIS1.1, such as service flow encodings, classifier encodings, and support for PHS rules. The new TLV parser features are used by different MAC message modules.
Commands
Router# debug cable tlvsEnhanced Registration
The registration module has been enhanced to support multiple registration styles (DOCSIS1.0/DOCSIS1.0+/DOCSIS1.1) seamlessly. Besides using services of new TLV parser/encoder, this module also supports the conditional registration-acknowledgment MAC message state machine.
Commands
Router# debug cable registrationRouter# debug cable tlvsDynamic MAC Messages
Dynamic Service MAC messages allow dynamic signaling of QoS between the cable modem and the CMTS. These messages are DOCSIS link layer equivalents of the higher layer messages that create, tear down, and modify a service flow. These messages are collectively known as DSX messages.
The DSX state machine module on the CMTS manages the several concurrent dynamic service transactions between cable modems and the CMTS. It include state machine support for all three DOCSIS1.1 DSX MAC messages:
•
•
•
Commands
Router# debug cable dynsrvRouter# debug cable tlvs
Note
Fragmentation
Grant fragmentation allows the upstream MAC scheduler to slice large data requests to fit into the scheduling gaps between UGS (voice slots). This reduces the jitter experienced by the UGS slots when large data grants preempt the UGS slots. The grant fragmentation gets triggered in the MAC scheduler, and fragment reassembly happens in the upstream receive driver.
Note
Commands
Router# show interface cable x/y sid [n] counters [verbose]Router(config-if)# [no] cable upstream n fragmentationRouter# debug cable errorsPayload Header Suppression and Restoration
The PHS feature is used to suppress repetitive or redundant portions in packet headers before transmission on the DOCSIS link. This is a new feature in the DOCSIS1.1 MAC driver. The upstream receive driver is now capable of restoring headers suppressed by cable modems, and the downstream driver is capable of suppressing specific fields in packet headers before forwarding the frames to the cable modem.
Commands
Router# show interface cable x/0 service-flow [sfid] phsRouter# debug cable errorRouter# debug cable phsConcatenation
Concatenation allows the cable modem to make a single time-slice request for multiple packets and send all packets in a single large burst on the upstream. Concatenation was introduced in the upstream receive driver in the DOCSIS1.0+ releases. Per-SID counters have now been added in Cisco IOS Release 12.1(4)CX for debugging concatenation activity.
Commands
Router# show interface cable x/y sid [n] counters [verbose]Router# show controller cable x/yRouter(config-if)# [no] cable upstream n concatenationRouter# debug cable errorsNew MAC Scheduler
The MAC scheduler controls all time-slot assignment on the shared upstream channel. This block has been redesigned to support several new scheduling disciplines of DOCSIS1.1. Important enhancements include:
•
•
•
•
All old Cisco features, such as dynamic contention control are supported in the new design.
Commands
Router# show interface cable x/y mac-scheduler nRouter(config-if)# [no] cable upstream n fragmentationRouter(config-if)# [no] cable upstream n unfrag-slot-jitterRouter# cable service flow inactivity-threshold nRouter# debug cable mac-schedulerDownstream Packet Classifier
Packet classifiers help to map packets into DOCSIS service flows. The CMTS supports downstream IP packet classifiers.
Commands
Router# show interface cable x/y classifierRouter# show interface cable x/y service-flow [n] classifiersRouter# debug cable qosDownstream Packet Scheduler
The Downstream Packet Scheduler is a new module that controls all output packet queueing service on the downstream link of each cable interface.
Commands
Router# debug cable qosRouter# show interface cable x/y downstreamBaseline Privacy Interface Plus
DOCSIS 1.0 included a Baseline Privacy Interface (BPI) to protect user data privacy across the shared-medium cable network and to prevent unauthorized access to DOCSIS-based data transport services across the cable network. BPI encrypts traffic across the RF interface between the cable modem and CMTS, and also includes authentication, authorization, and accounting (AAA) features.
BPI supports access control lists (ACLs), tunnels, filtering, protection against spoofing, and commands to configure source IP filtering on RF subnets to prevent subscribers from using source IP addresses that are not valid. For a detailed description of how BPI was implemented in DOCSIS 1.0, see the Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide.
DOCSIS 1.1 enhances these security features with BPI Plus (BPI+), which includes the following enhancements:
•
•
•
•
•
Note
Additional DOCSIS 1.1 Features in Cisco IOS Release 12.1(7)CX1
Cisco IOS Release 12.1(7)CX1 enhances DOCSIS 1.1 support with the following new or changed MIBs:
Note
•
Note
•
•
•
•
In addition, the CLI supports a new command (cable submgmt default) to set the default value of attributes in DOCS-SUBMGT-MIB. This command can be included in the Cisco IOS configuration file so that the new values are automatically set after a reboot or reload of the Cisco uBR7200 series router.
Migrating from Earlier Versions of DOCSIS
DOCSIS 1.1 cable modems have additional features and better performance than earlier DOCSIS 1.0 and 1.0+ models, but all three models can coexist in the same network. DOCSIS 1.0 and 1.0+ cable modems will not hamper the performance of a DOCSIS 1.1 CMTS, nor will they interfere with operation of DOCSIS 1.1 features. There is full forward and backward compatibility in the standards.
Benefits
DOCSIS 1.1 includes a rich set of features that provide advanced and flexible QoS capabilities for various types of traffic (voice, data, and video) over the cable network. It also provides enhanced security and authentication features.
Baseline Privacy Interface Plus Enhancement
The Plus (+) version of the Baseline Privacy Interface (BPI+) in DOCSIS 1.1 provides a set of extended services within the MAC sublayer that increase performance and system security. Digital certificates provide secure authentication for each cable modem, to prevent identity theft on the basis of MAC and IP addresses. Advanced encryption provides a secure channel between the cable modem and CMTS, and secure software download allows a service provider to upgrade the software on cable modems, without the threat of interception, interference, or alteration of the software code.
Note
Dynamic Service Flows
The dynamic creation, modification, and deletion of service flows allows for on-demand reservation on Layer 2 bandwidth resources. The CMTS can now provide special QoS to the cable modem dynamically for the duration of a voice call or video session, as opposed to the static provisioning and reservation of resources at the time of cable modem registration. This provides a more efficient use of the available bandwidth.
Concatenation
The cable modem concatenates multiple upstream packets into one larger MAC data frame, allowing the cable modem to make only one time-slot request for the entire concatenated MAC frame, as opposed to requesting a time slot for each individual packet. This reduces the delay in transferring the packet burst upstream.
Enhanced QoS
Extensive scheduling parameters allow the CMTS and the cable modem to communicate QoS requirements and achieve more sophisticated QoS on a per service-flow level.
Different new time-slot scheduling disciplines help in providing guaranteed delay and jitter bound on shared upstream. Activity detection helps to conserve link bandwidth by not issuing time slots for an inactive service flow. The conserved bandwidth can then be reused for other best-effort data slots.
Packet classification helps the CMTS and cable modem to isolate different types of traffic into different DOCSIS service flows. Each flow could be receiving a different QoS service from CMTS.
Fragmentation
The MAC scheduler fragments data slots to fill the gaps inbetween UGS slots. Fragmentation reduces the jitter experienced by voice packets when large data packets are transmitted on the shared upstream channel and preempt the UGS slots used for voice. Fragmentation splits the large data packets so that they fit into the smaller time slots available around the UGS slots.
Multiple Subflows per SID
This feature allows the cable modem to have multiple calls on a single hardware queue. This approach scales much better than requiring a separate SID hardware queue on the cable modem for each voice call.
Payload Header Suppression
Payload Header Suppression (PHS) allows the CMTS/cable modem to suppress repetitive or redundant portions in packet headers before transmitting on the DOCSIS link. This helps to conserve link bandwidth, especially with types of traffic, such as voice, where the header size tends to be as large as the size of the actual packet.
Service Classes
The QoS attributes of a service flow can be specified in two ways: either explicitly by defining all attributes, or implicitly by specifying a service class name. A service class name is a string that the CMTS associates with a QoS parameter set.
The service class serves the following purposes:
•
•
•
Note
Any service flow can have its QoS parameter set specified in any of three ways:
· By explicitly including all traffic parameters.
· By indirectly referring to a set of traffic parameters by specifying a service class name.
· By specifying a service class name along with modifying parameters.
The service class name is expanded to its defined set of parameters at the time the CMTS successfully admits the service flow.
Restrictions
In addition to the interoperability issues listed here, the CMTS must be running Cisco IOS Release 12.1(4)CX or Cisco IOS Release 12.1(7)CX1 to support DOCSIS 1.1 and the cable modem must also support the DOCSIS 1.1 feature set.
Limitations
Cisco IOS Release 12.1(7)CX1 supports the features listed in the DOCSIS 1.1 specification SP-RFIv1.1-IO3-991105. Additional features will be supported as they are added to the specification and as the specification is finalized.
DOCSIS 1.1 traffic is supported on Cisco uBR-MC1xC and Cisco uBR-MC28C cable interface line cards. The Cisco uBR-MC11 (FPGA) and Cisco uBR-MC16B line cards do not support DOCSIS 1.1.
In particular, the following DOCSIS 1.1 features are not supported in Cisco IOS Release 12.1(7)CX1:
•
•
•
•
In addition, 1+1 redundancy and the HCCP protocol are not supported during DOCSIS 1.1 operation.
Interoperability Issues
This section describes some of the differences between DOCSIS 1.0, DOCSIS 1.0 with extensions, and DOCSIS 1.1.
Baseline Privacy Interface Plus
BPI+ encryption and authentication must be supported and enabled by both the cable modem and CMTS. In addition, the cable modem must contain a digital certificate that conforms to the DOCSIS 1.1 and BPI+ specifications.
Also, ensure that the system clocks on the CMTS and on the time-of-day (ToD) servers are synchronized. If this does not occur, the clocks on the CMs will not match the clocks on the CMTS, which could interfere with BPI+ operations. In particular, this could prevent the proper verification of the digital certificates on the CM.
Maximum Burst Size
Previously, the maximum concatenated burst size parameter could be set to zero to specify an unlimited value. In a DOCSIS 1.1 environment, this parameter should be set to a nonzero value, with a maximum value of 1522 bytes for DOCSIS 1.0 cable modems.
If a cable modem attempts to register with a maximum concatenation burst size of zero, the DOCSIS 1.1 CMTS will refuse to allow the cable modem to come online. This avoids the possibility that a DOCSIS 1.0 cable modem could interfere with voice traffic on the upstream by sending extremely large data packets. Since DOCSIS 1.0 does not support fragmentation, transmitting such data packets could result in unwanted jitter in the voice traffic.
In addition, DOCSIS 1.1 requires that the maximum transmit burst size be set to either 1522 bytes or the maximum concatenated burst size, whichever is larger. Do not set the maximum concatenation burst size to values larger than 1522 bytes for DOCSIS 1.0 cable modems.
Note
Provisioning
The format and content of the TFTP configuration file for a DOCSIS 1.1 cable modem are significantly different from the file for a DOCSIS 1.0 cable modem. A dual-mode configuration file editor is used to generate a DOCSIS 1.0 style configuration file for DOCSIS 1.0 cable modems and a DOCSIS 1.1 configuration file for DOCSIS 1.1 cable modems.
Registration
A DOCSIS 1.1 CMTS is designed to handle the existing registration TLVs from DOCSIS 1.0 cable modems as well as the new type TLVs from DOCSIS 1.1 cable modems. A DOCSIS 1.0 and DOCSIS 1.1 cable modem can successfully register with the same DOCSIS 1.1 CMTS.
A DOCSIS 1.1 cable modem can be configured to make an indirect reference to a service class that has been statically defined at the CMTS instead of explicitly asking for the service class parameters. When this registration request is received by a DOCSIS 1.1 CMTS, it encodes the actual parameters of the service class in the registration response and expects a DOCSIS 1.1-specific registration-acknowledge MAC message from the cable modem.
When a DOCSIS 1.0 cable modem registers with a DOCSIS 1.1 CMTS, the registration request explicitly requests all nondefault service-class parameters in the registration. The absence of an indirect service class reference eliminates the need for the DOCSIS 1.1 TLVs and eliminates the need to establish a local registration acknowledge wait state.
When a DOCSIS 1.1 CMTS receives a registration request from a DOCSIS 1.0 cable modem, it responds with the DOCSIS 1.0 style registration response and does not expect the cable modem to send the registration-acknowledge MAC message.
Performance
DOCSIS 1.0 cable modems lack the ability to explicitly request and provide scheduling parameters for advanced DOCSIS 1.1 scheduling mechanisms, such as unsolicited grants and real-time polling. DOCSIS 1.1 cable modems on the same upstream channel can benefit from the advanced scheduling mechanisms and a DOCSIS 1.1 CMTS can still adequately support voice traffic from DOCSIS 1.1 cable modems with DOCSIS 1.0 cable modems on the same upstream channel.
Related Documents
•
•
•
•
•
Supported Platforms
•
•
•
•
•
Note
Supported Standards, MIBs, and RFCs
Standards
DOCSIS 1.1 specification SP-RFIv1.1-IO3-991105
Baseline Privacy Interface Plus Specification BPI+_I06-001215
MIBs
For DOCSIS 1.1 the new supported MIBs are:
•
This is revision 05 of this MIB and replaces the DOCS-BPI-MIB, which is supported only in DOCSIS 1.0. As required by the DOCSIS specifications, a DOCSIS 1.1 CMTS and CM support only the attributes in DOCS-BPI-PLUS-MIB and not the attributes in DOCS-BPI-MIB.
Note
•
This is revision 04 of the MIB.
Note
•
This is revision 02 of the MIB.•
Standard IGMP management MIB.•
This MIB was released as RFC 2669.•
Extends RFC 2669 (DOCS-CABLE-DEVICE-MIB).•
Extends RFC 2670 (DOCS-IF-MIB).In addition, the CLI supports a new command (cable submgmt default) to set the default value of attributes in DOCS-SUBMGT-MIB. This command can be included in the Cisco IOS configuration file so that the new values are automatically set after a reboot or reload of the Cisco uBR7200 series router.
Note
In addition, DOCS-IF-MIB (RFC 2670) has been modified.
RFCs
RFC 2669 (DOCS-CABLE-DEVICE-MIB)
Prerequisites
Before you power on and configure the CMTS:
•
•
•
•
•
•
•
After these prerequisites are met, you are ready to configure the CMTS. This includes, at a minimum, configuring a host name and password for the CMTS and configuring the CMTS to support IP over the cable plant and network backbone.
Caution
Configuration Tasks
Perform the configuration tasks outlined in your CMTS documentation to configure the CMTS. When the Cisco uBR7200 series has been upgraded to Cisco IOS Release 12.1 CX, it automatically enables all DOCSIS 1.1 features and sets them to their default values.
Command Reference
This section documents new or modified commands. All other commands are documented in the Cisco IOS Release 12.1 and Cisco IOS 12.1 T command reference publications. The following commands are new or have been modified to accommodate DOCSIS 1.1 functionality.
New Commands
•
•
•
•
•
•
Modified Commands
Debug and Test Commands
Replaced Commands
•
•
•
cable dci-response
To configure how a cable interface responds to DCI-REQ messages for cable modems on that interface, use the cable dci-response command in cable interface configuration mode.
cable dci-response [success | ignore | reject permanent | reject temporary]
Syntax Description
Defaults
The Cisco CMTS responds to DCI-REQ messages from all cable modems by sending a DCI-RSP response with the confirmation code of Success (0).
Command Modes
Cable interface configuration
Command History
Usage Guidelines
The Device Class Identification (DCI) messages are part of the Media Access Control Specification section of the DOCSIS 1.1 specification (revision SP-RFIv1.1-I05-000714 and above). A cable modem (CM) can optionally use the DCI-REQ message to inform the CMTS of certain capabilities, such as whether it is a CPE-controlled cable modem (CCCM).
The CMTS then responds with one of the following confirmation codes:
•
•
•
Note
Examples
The following example shows how to configure the CMTS so that it ignores all DCI-REQ messages from cable modems on the cable interface at slot 6:
router# config trouter(config)# int c6/0router(config-if)# cable dci-response ignorerouter(config-if)#The following example shows how to configure the CMTS so that it returns to its default behavior for the cable interface on slot 6, which is to respond to all DCI-REQ messages from cable modems by sending a DCI-RSP with a Success confirmation code:
router# config trouter(config)# int c6/0router(config-if)# cable dci-response successrouter(config-if)#
Note
Related Commands
cable dci-upstream-disable
To configure a cable interface so that it transmits a DOCSIS 1.1 Upstream Transmitter Disable (UP-DIS) message to a particular cable modem (CM), use the cable dci-upstream-disable command in cable interface configuration mode. To remove that configuration and return to the default configuration, use the no form of this command.
cable dci-upstream-disable mac-address [enable | disable]
no cable dci-upstream-disable mac-address [enable | disable]
Syntax Description
Defaults
The Cisco CMTS does not transmit UP-DIS messages to any cable modems.
Command Modes
Cable interface configuration
Command History
Usage Guidelines
The DOCSIS 1.1 specification (revision SP-RFIv1.1-I05-000714 and above) allows a CMTS to transmit an Upstream Transmitter Disable (UP-DIS) message to a CM. If the CM supports the UP-DIS message, it responds by immediately disabling its upstream transmitter circuitry. The CM must be power-cycled before it can begin transmitting on the upstream again.
Examples
The following example shows that the UP-DIS message is being enabled for the CM with the MAC address of 0123.4567.89ab.
router# config trouter(config)# int c6/0router(config-if)# cable dci-upstream-disable 0123.4567.89ab enablerouter(config-if)#Related Commands
Configures how the cable interface responds to DCI-REQ messages from cable modems on that interface.
Enables debugging of DCI-REQ, DCI-RSP, and UP-DIS messages.
cable service class
To set parameters for cable service class, use the cable service class command in global configuration mode.
cable service class class_index [keyword-options]
Syntax Description
Defaults
Values that are not specified are set to their DOCSIS 1.1 defaults, if applicable to the service-class schedule type.
Command Modes
Global configuration
Command History
12.1(4)CX
This command was introduced. This command replaces the cable qos profile command that was used in previous versions.
Usage Guidelines
The sched-type option must always be specified for each class. When a certain scheduling type is selected, ensure that the mandatory parameters for that scheduling type are explicitly entered, while nonapplicable parameters must be explicitly removed.
If the service class is newly created, a service-class name must be defined before entering the parameters for the service class.
Examples
The following examples show configurations that use the cable service class command to create service classes. Based on the scheduling type specified, some command lines are mandatory, while others are optional.
Each example shown here is a complete configuration set for creating a service class.
The arrows indicate mandatory command lines.
Configuring a Service Class for Unsolicited Grant Scheduling Service
Router(config)# cable service class 1 name UP_UGSRouter(config)# cable service class 1 sched-type 6Router(config)# cable service class 1 grants-per-interval 1Router(config)# cable service class 1 min-packet-size 100Router(config)# cable service class 1 tos-overwrite 0xE0 0xA0Router(config)# cable service class 1 activity-timeout 30Router(config)# cable service class 1 admission-timeout 30Configuring a Service Class for Unsolicited Grant Scheduling with Activity Scheduling
Router(config)# cable service class 2 name UP_UGSADRouter(config)# cable service class 2 sched-type 5Router(config)# cable service class 2 poll-interval 10000Router(config)# cable service class 2 poll-jitter 4000Router(config)# cable service class 2 min-packet-size 100Router(config)# cable service class 2 tos-overwrite 0xE0 0xA0Router(config)# cable service class 2 activity-timeout 30Router(config)# cable service class 2 admission-timeout 30Configuring a Service Class with Real-Time Polling Service
Router(config)# cable service class 3 name UP_RTPSRouter(config)# cable service class 3 sched-type 4Router(config)# cable service class 3 poll-jitter 4000Router(config)# cable service class 3 min-rate 64000Router(config)# cable service class 3 max-rate 128000Router(config)# cable service class 3 max-burst 2000Router(config)# cable service class 3 max-concat-burst 1522Router(config)# cable service class 3 tos-overwrite 0xE0 0xA0Router(config)# cable service class 3 activity-timeout 30Router(config)# cable service class 3 admission-timeout 30Configuring a Service Class for Best-Effort Upstream Service
Router(config)# cable service class 4 name UP_BERouter(config)# cable service class 4 sched-type 2Router(config)# cable service class 4 priority 5Router(config)# cable service class 4 min-rate 0Router(config)# cable service class 4 max-rate 128000Router(config)# cable service class 4 max-burst 2000Router(config)# cable service class 4 max-concat-burst 1522Router(config)# cable service class 4 req-trans-policy 0x0Router(config)# cable service class 4 tos-overwrite 0xE0 0x00Router(config)# cable service class 4 activity-timeout 30Router(config)# cable service class 4 admission-timeout 30Configuring a Service Class for Best-Effort Downstream Service
Router(config)# cable service class 5 name DOWN_BERouter(config)# cable service class 5 priority 5Router(config)# cable service class 5 min-rate 0Router(config)# cable service class 5 max-rate 1000000Router(config)# cable service class 5 max-burst 3000Router(config)# cable service class 5 activity-timeout 30Router(config)# cable service class 5 admission-timeout 30Related Commands
cable qos profile
Creates a DOCSIS 1.0 QoS profile.
Displays the service classes that have been created.
cable service flow inactivity-threshold
To set the inactivity threshold value for service flows using Unsolicited Grant Service with Activity Detection (UGS-AD), use the cable service flow inactivity-threshold command in global configuration mode. To disable the inactivity timer, so that service flows revert to UGS activity only, use the no form of this command.
cable service flow inactivity-threshold n
no cable service flow inactivity-threshold n
Syntax Description
n
Specifies the threshold limit in seconds, with 10 seconds as the default. Configurable limits are 1 to 3600 seconds.
Defaults
The default is to enable the inactivity timer, with a default value of 10 seconds.
Command Modes
Global configuration
Command History
12.1(4)CX
This command replaced the cable service-flow inactivity-timeout command for DOCSIS 1.1 operation.
Usage Guidelines
DOCSIS 1.1 allows a cable modem (CM) to request Unsolicited Grant Service (UGS) for an upstream, allowing the CM to reserve a certain amount of Constant Bit Rate (CBR) bandwidth for real-time traffic, such as Voice over IP (VoIP) calls. The UGS-AD variation allows the CMTS to switch a service flow to Real Time Polling Service (RTPS) after a certain period of inactivity, so that bandwidth is not reserved when it is not needed. The CM can then request UGS service when the flow again becomes active.
Note
The cable service flow inactivity-threshold command sets the inactivity timer for how long a service flow must be inactive before the CMTS can switch it from UGS-AD to RTPS. The no cable service flow inactivity-threshold command disables the timer, so that the CMTS always provides UGS service to the service flow, even when the flow is idle.
Caution
Examples
The following example shows the inactivity timer being set to 20 seconds:
Router(config)# cable service flow inactivity-threshold 20Router(config)#The following command disables the inactivity timer, so that the service flow remains UGS, even during periods of inactivity:
Router(config)# no cable service flow inactivity-thresholdRouter(config)#Related Commands
cable submgmt default
To set the default values for attributes in the Subscriber Management MIB (DOCS-SUBMGT-MIB), use the cable submgmt default command in global configuration mode. To restore the original defaults, use the no form of this command.
cable submgmt default [active | learnable | max-cpe cpe-num]
cable submgmt default filter-group {cm | cpe} {downstream | upstream} group-id
no cable submgmt default [active | learnable | max-cpe cpe-num]
no cable submgmt default filter-group {cm | cpe} {downstream | upstream} group-id
Syntax Description
Defaults
The Subscriber Management MIB defaults to the following default values:
•
•
•
•
Command Modes
Global configuration
Command History
Usage Guidelines
The DOCSIS 1.1 Subscriber Management MIB (DOCS-SUBMGT-MIB) creates and maintains a number of tables that describe the state of subscriber management for the cable modems (CM) and customer premises equipment (CPE) devices being serviced by the Cisco CMTS. The CMTS creates rows in these tables for each CM and CPE device when the CM registers with the CMTS, and if the CM does not specify a value for an attribute in this table, the CMTS uses the defaults specified by the cable submgmt default command.
Timesaver
Note
The attributes in DOCS-SUBMGT-MIB control how the CMTS manages the CPE devices behind a CM and the filters that are applied to the traffic to and from a particular CM and its CPE devices. The following sections describe the relationship between the different forms of the cable submgmt default commands and the attributes in DOCS-SUBMGT-MIB.
CPE Management
The first form of the cable submgmt default command controls the default values for the entries in the docsSubMgtCpeControlTable, which controls how the CMTS manages the CPE devices for each CM:
cable submgmt default active
Sets the docsSubMgtCpeActiveDefault attribute, which is the default value for the docsSubMgtCpeControlActive attribute in docsSubMgtCpeControlTable. This attribute controls whether the CMTS performs CPE management for a particular CM.
•
•
cable submgmt default learnable
Sets the docsSubMgtCpeLearnableDefault attribute, which is the default value for the docsSubMgtCpeControlLearnable attribute in docsSubMgtCpeControlTable. This attribute controls whether the CMTS learns the IP addresses for CPE devices behind a particular CM.
•
•
cable submgmt default max-cpe cpe-num
Sets the docsSubMgtCpeMaxIpDefault attribute, which specifies the default value for the docsSubMgtCpeControlMaxCpeIp attribute in docsSubMgtCpeControlTable. This attribute specifies the maximum number of IP addresses that can transmit traffic through a particular CM. The possible range is 0 to 1024, and the original default is 16.
Note
Filter Group Management
The second form of the cable submgmt default command controls the default values for the entries in the docsSubMgtCmFilterTable, which assigns the CM to one or more filter groups. A filter group specifies what filters are applied to the traffic going to or coming from each particular CM or CPE device. Filter groups can be numbered 0 to 1024, where 0 specifies that no filtering is done for that particular traffic type.
Note
cable submgmt default filter-group cpe downstream group-id
Sets the ocsSubMgtSubFilterDownDefault attribute, which is the default value for the docsSubMgtSubFilterDownstream attribute in the docsSubMgtCmFilterTable. This attribute applies to downstream traffic that is sent to the CPE devices behind a particular CM.
cable submgmt default filter-group cpe upstream group-id
Sets the docsSubMgtSubFilterUpDefault attribute, which is the default value for the docsSubMgtSubFilterUpstream attribute in the docsSubMgtCmFilterTable. This attribute applies to upstream traffic that is sent by the CPE devices behind a particular CM.
cable submgmt default filter-group cm downstream group-id
Sets the docsSubMgtCmFilterDownDefault attribute, which is the default value for the docsSubMgtCmFilterDownstream attribute in the docsSubMgtCmFilterTable. This attribute applies to downstream traffic that is addressed to a particular CM.
cable submgmt default filter-group cm upstream group-id
Sets the docsSubMgtCmFilterUpDefault attribute, which is the default value for the docsSubMgtCmFilterUpstream attribute in the docsSubMgtCmFilterTable. This attribute applies to upstream traffic that is sent by a particular CM.
Examples
The following commands specify that the CMTS defaults to actively managing the CPE devices for each CM that registers, allowing and learning up to four IP addresses for the CPE devices behind that CM.
Router# config tRouter(config)# cable submgmt default activeRouter(config)# cable submgmt default learnableRouter(config)# cable submgmt default max-cpe 4Router(config)#The following commands specify that the CMTS defaults to actively managing the CPE devices for each CM that registers. Each CM, however, must specify its own MAX-CPE value; otherwise, that value defaults to 0 and all traffic to and from the CPE devices for that CM is blocked.
Router# config tRouter(config)# cable submgmt default activeRouter(config)# cable submgmt default max-cpe 0Router(config)#The following commands specify that the CMTS defaults to not actively managing the CPE devices for each CM that registers. However, if the CM at registration time indicates that the CMTS is to actively manage the CPE devices, the CMTS defaults to allowing only one CPE device. Learning is also disabled, so at least one CPE device must be specified in the DOCSIS configuration file that the CM uses to register.
Router# config tRouter(config)# no cable submgmt default activeRouter(config)# no cable submgmt default learnableRouter(config)# cable submgmt default max-cpe 1Router(config)#The following commands specify that the CMTS defaults to assigning three filter groups to each CM that registers. Unless the CM indicates otherwise at registration time, downstream and upstream traffic for the CPE devices behind the CM is filtered according to the rules for filter groups 20 and 21, respectively. Filter group 1 is applied to the downstream traffic addressed to the CM. Upstream traffic sent by the CM, however, is not filtered.
Router# config tRouter(config)# cable submgmt default filter-group cpe downstream 20Router(config)# cable submgmt default filter-group cpe upstream 21Router(config)# cable submgmt default filter-group cm downstream 1Router(config)# cable submgmt default filter-group cm upstream 0Router(config)#
Note
cable upstream fragmentation
To enable fragmentation, use the cable upstream fragmentation command in cable interface configuration mode. To disable fragmentation, use the no form of this command. Fragmentation is enabled by default.
cable upstream upstream-port fragmentation
no cable upstream upstream-port fragmentation
Syntax Description
Defaults
By default, fragmentation is enabled for all upstream ports on ASIC line cards (Cisco uBR-MC11C, Cisco uBR-MC12C, Cisco uBR-MC14C, Cisco uBR-MC16C, Cisco uBR-MC16S, and Cisco uBR-MC28C) and disabled for all upstream ports on FPGA line cards.
Note
Command Modes
Cable interface configuration
Command History
Usage Guidelines
This command enables and disables DOCSIS layer 2 fragmentation, which reduces run-time jitter experienced by constant bit rate (CBR) slots on the corresponding upstream. Disabling fragmentation increases the run-time jitter, but also reduces the fragmentation reassembly overhead for fragmented MAC frames. For ports running CBR traffic, fragmentation should be enabled (the default).
Note
Examples
The following command shows DOCSIS fragmentation being enabled on the c2/0 cable upstream:
Router# config tRouter(config)# int c2/0Router(config-if)# cable upstream 0 fragmentationRouter(config-if)#cable upstream unfrag-slot-jitter
To control how much jitter can be tolerated on the corresponding upstream due to unfragmentable slots, use the cable upstream unfrag-slot-jitter command in cable interface configuration mode. To disallow all jitter, use the no form of this command.
cable upstream n unfrag-slot-jitter [limit jitter | cac-enforce]
no cable upstream n unfrag-slot-jitter [limit jitter | cac-enforce]
Syntax Description
Defaults
By default, the limit is 0 microseconds and the cac-enforce option is enabled.
Command Modes
Cable interface configuration
Command History
Usage Guidelines
This command controls how much jitter due to unfragmented slots is to be tolerated on each port. If the specified value for the tolerated limit is less than the size of a maximum unfragmentable slot, the MAC scheduler automatically blocks the difference numbering of slots in the scheduling table so that the unfragmentable slot can be accommodated in the blocked space and avoid causing excessive jitter to CBR slots.
The cac-enforce option enforces the rule that service flows requesting run-time jitter less than unfragmentable slot jitter should be rejected.
Examples
The following example shows the jitter being set to 10 milliseconds (10000 microseconds) for upstream port 0 on cable interface 2/0:
Router# config tRouter(config)# int c2/0Router(config-if)# cable upstream 0 unfrag-slot-jitter limit 10000show cable modem
To display information for the registered and unregistered cable modems, use the show cable modem command in privileged EXEC mode.
show cable modem [ip-address | interface | mac-address] [options]
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Usage Guidelines
This command displays information for all cable modems, all cable modems attached to a specific CMTS cable interface, or for a particular CM that is identified by its IP address or MAC address.
Examples
The following sample output from the show cable modem command shows the default displays for individual CMs.
Router# show cable modemMAC Address IP Address I/F MAC Prim RxPwr Timing Num BPIState Sid (db) Offset CPEs Enbld0010.7b6b.58c1 0.0.0.0 C4/0/U5 offline 5 -0.25 2285 0 yes0010.7bed.9dc9 0.0.0.0 C4/0/U5 offline 6 -0.75 2290 0 yes0010.7bed.9dbb 0.0.0.0 C4/0/U5 offline 7 0.50 2289 0 yes0010.7b6b.58bb 0.0.0.0 C4/0/U5 offline 8 0.00 2290 0 yes0010.7bb3.fcd1 10.20.113.2 C5/0/U5 online 1 0.00 1624 0 yes0010.7bb3.fcdd 0.0.0.0 C5/0/U5 init(r1) 2 -20.00 1624 0 no0010.7b43.aa7f 0.0.0.0 C5/0/U5 init(r2) 3 7.25 1623 0 noRouter# show cable modem 0010.7bb3.fcd1MAC Address IP Address I/F MAC Prim RxPwr Timing Num BPIState Sid (db) Offset CPEs Enbld0010.7bb3.fcd1 10.20.113.2 C5/0/U5 online 1 0.00 1624 0 yesThe default cable modem displays show the following information for each modem:
Table 2 Descriptions for the Default show cable modem Fields
MAC Address
The MAC address for the CM.
IP Address
The IP address that the DHCP server has assigned to the CM.
I/F
The cable interface line card providing the upstream for this CM.
MAC State
The current state of the MAC layer (see Table 3).
Prim SID
The primary SID assigned to this CM.
RxPwr
The received power level (in dB) for the CM.
Timing Offset
The timing offset for the CM.
Num CPEs
Indicates the number of CPE devices for which the CM is providing services.
BPI Enbld
Indicates whether BPI encryption is enabled for the CM.
Table 3 shows the possible values for the MAC state field:
The following example shows sample output for the summary option:
Router# show cable modem summaryInterface Cable ModemTotal Registered Unregistered OfflineCable4/0/U5 4 0 4 4Cable5/0/U5 3 1 2 0The following example shows sample output for the summary option for all enabled cable interface line cards:
Router# show cable modem summary totalInterface Total Active RegisteredModems Modems ModemsCable5/0 746 714 711Cable6/0 806 764 759Total: 1552 1478 1470The following example shows sample output for the summary option for all enabled upstreams on a specific cable interface line card:
Router# show cable modem summary c5/0 totalInterface Total Active RegisteredModems Modems ModemsCable5/0/U0 294 272 271Cable5/0/U1 256 248 246Cable5/0/U2 196 194 194Total: 746 714 711The following example shows sample output for the phy option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 phyMAC Address USPwr USSNR Timing MicroReflec DSPwr DSSNR(dBmV) (dBmV) Offset (dBc) (dBmV) (dBmV)0010.7bb3.fcd1 0 25.16 0 0 -----The following example shows sample output for the mac option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 macMAC Address MAC Prim Ver Frag Concat PHS Priv DS USState Sid Saids Sids0010.7bb3.fcd1 online 1 DOC1.0 no no no BPI 0 0The following example shows sample output for the maintenance option for a particular CM:
Router# show cable modem 0010.7bb3.fcd1 maintenanceMAC Address I/F Prim SM Exhausted SM AbortedSid Count Time Count Time0010.7bb3.fcd1 C5/0/U5 1 3 Jun 1 10:24:52 0 Jan 1 00:00:00The following example shows sample output for the connectivity option for a particular cable modem:
Note
Router# show cable modem 0010.7bb3.fcd1 connectivityPrim 1st time Times %online Online time Offline timeSid online Online min avg max min avg max1 May 30 2000 4 99.85 48:20 11h34m 1d2h23m 00:01 00:59 03:00The following example shows sample output for the flap option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 flapMAC Address I/F Ins Hit Miss CRC P-Adj Flap Time0010.7bb3.fcd1 C5/0/U5 0 36278 92 0 369 372 Jun 1 13:05:23The following example shows sample output for the qos option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 qosSfid Dir Curr Sid Sched Prio MaxSusRate MaxBrst MinRsvRate ThroughputState Type3 US act 1 BE 7 2000000 1522 100000 04 DS act N/A BE 0 4000000 1522 0 0The following example shows sample output for the classifiers option for a particular cable modem:
Router# show cable modem 0010.7b6b.7215 classifiersCfrId SFID cable modem Mac Address Direction State Priority Matches2 1988 0010.7b6b.7215 US act 101The following example shows sample output for the counter option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 counterMAC Address US Packets US Bytes DS Packets DS Bytes0010.7bb3.fcd1 1452082 171344434 1452073 171343858The following example shows sample output for the errors option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 errorsMAC Address I/F CRC HCS0010.7bb3.fcd1 C5/0/U5 0 0The following example shows sample output for the cpe option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 cpeSID Priv bits Type State IP address method MAC address1 00 modem up 10.20.113.2 dhcp 0010.7bb3.fcd1The following example shows sample output for the access-group option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 access-groupMAC Address IP Address Access-group0010.7bb3.fcd1 10.20.113.2 N/AUpstream Power : 42 dBmV (SNR = 10 dBmV)Downstream Power : 15 dBmV (SNR = 15 dBmV)The following example shows sample output for the verbose option for a particular cable modem:
Router# show cable modem 0010.7bb3.fcd1 verboseMAC Address : 0010.7bb3.fcd1IP Address : 10.20.113.2Prim Sid : 1Interface : C5/0/U5Upstream Power : 42 dBmV (SNR = 10 dBmV)Downstream Power : 15 dBmV (SNR = 15 dBmV)Timing Offset : 1624Received Power : 0.25MAC Version : DOC1.0Capabilities : {Frag=N, Concat=N, PHS=N, Priv=BPI}Sid/Said Limit : {Max Us Sids=0, Max Ds Saids=0}Optional Filtering Support : {802.1P=N, 802.1Q=N}Transmit Equalizer Support : {Taps/Symbol= 0, Num of Taps= 0}Number of CPEs : 0(Max CPEs = 0)Flaps : 373(Jun 1 13:11:01)Errors : 0 CRCs, 0 HCSesStn Mtn Failures : 0 aborts, 3 exhaustedTotal US Flows : 1(1 active)Total DS Flows : 1(1 active)Total US Data : 1452082 packets, 171344434 bytesTotal US Throughput : 0 bits/sec, 0 packets/secTotal DS Data : 1452073 packets, 171343858 bytesTotal DS Throughput : 0 bits/sec, 0 packets/secThe following example shows sample output for the registered option, which can be used with or without a cable modem address. If you specify a cable modem address, information for that cable modem is displayed only if the cable modem has actually registered with the CMTS. The display for the unregistered option is identical to that shown for the registered option, except that it shows cable modems that have not yet registered with the CMTS.
Router# show cable modem 10.20.114.34 registeredInterface Prim Online Timing Rec QoS CPE IP address MAC addressSid State Offset PowerC6/0/U5 1 online 2808 0.25 2 1 10.20.114.34 00d0.ba77.7595
Note
The following example shows sample output for the cnr option for a particular cable modem:
Router# show cable modem 10.20.114.34 cnrMAC Address IP Address I/F MAC Prim cnrState Sid (db)00d0.ba77.7595 10.20.114.34 Cable3/0/U5 online 1 38.00show interface cable qos paramset
To display the attributes of the service flow QoS parameter set, use the show interface cable qos paramset command in privileged EXEC mode.
show interface cable slot/port qos paramset [paramset-index] [verbose]
Note
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
12.1(4)CX
This command replaces the show cable qos profile command for DOCSIS 1.1 operation.
Examples
The following sample output shows the standard and verbose formats of the show interface cable qos-paramset command:
Router# show int c6/0 qos paramsetIndex Name Dir Sched Prio MaxSusRate MaxBurst MinRsvRate1 US BE 0 64000 0 02 DS BE 0 1000000 0 03 US BE 7 2000000 1522 1000004 DS BE 0 4000000 1522 0Router# show int c6/0 qos paramset 1 verboseIndex: 1Name:Direction: UpstreamTraffic Priority: 0Maximum Sustained Rate: 64000 bits/secMax Burst: 0 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 0 bytesMaximum Concatenated Burst: 1522Scheduling Type: Best EffortRequest/Transmission Policy: 0x0Nominal Polling Interval: 0Tolerated Poll Jitter: 0Unsolicited Grant Size: 0 bytesNominal Grant Interval: 0 usecsTolerated Grant Jitter: 0 usecsGrants per Interval: 0IP ToS Overwrite [AND-mask,OR-mask]: 0x0,0x0Related Commands
show cable qos permission
Displays the status of permissions for changing quality-of-service (QoS) tables.
show cable qos profile
Displays the QoS profiles that have been defined.
show cable service-class
To display the parameters for cable service class, use the show cable service class command in privileged EXEC mode.
show cable service-class [sclass-index] [verbose]
Syntax Description
sclass-index
Identifies the index for a service class that has already been defined (1-255).
verbose
Displays all of the defined attributes for the service class.
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Usage Guidelines
You can display a summary of either one service class or all service classes. You can also display a complete listing of each service class and of all the defined service classes.
Examples
The following sample output shows the standard and verbose formats of the show cable service class command:
Router# show cable service-classIndex Name Dir Sched Prio MaxSusRate MaxBurst MinRsvRate1 UP_UGS US/DS UGS 0 0 1522 02 UP_UGSAD US/DS UGS_AD 0 0 1522 03 UP_RTPS US/DS RTPS 0 128000 2000 640004 UP_BE US/DS BE 5 128000 2000 05 DOWN_BE US/DS BE 5 1000000 3000 0Router# show cable service-class 1Index Name Dir Sched Prio MaxSusRate MaxBurst MinRsvRate1 UP_UGS US/DS UGS 0 0 1522 0Router# show cable service-class 1 verboseIndex: 1Name: UP_UGSDirection: Upstream/DownstreamTraffic Priority: 0Maximum Sustained Rate: 0 bits/secMax Burst: 1522 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 100 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsScheduling Type: Unsolicited Grant ServiceRequest/Transmission Policy: 0x1FFUnsolicited Grant Size: 100 bytesNominal Grant Interval: 20000 usecsTolerated Grant Jitter: 4000 usecsGrants per Interval: 1IP ToS Overwrite [AND-mask,OR-mask]: 0xE0,0xA0Max Latency: 0 usecsParameter Presence Bitfield: {0xE08, 0xBCC000}Router# show cable service-class verboseIndex: 1Name: UP_UGSDirection: Upstream/DownstreamTraffic Priority: 0Maximum Sustained Rate: 0 bits/secMax Burst: 1522 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 100 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsScheduling Type: Unsolicited Grant ServiceRequest/Transmission Policy: 0x1FFUnsolicited Grant Size: 100 bytesNominal Grant Interval: 20000 usecsTolerated Grant Jitter: 4000 usecsGrants per Interval: 1IP ToS Overwrite [AND-mask,OR-mask]: 0xE0,0xA0Max Latency: 0 usecsParameter Presence Bitfield: {0xE08, 0xBCC000}Index: 2Name: UP_UGSADDirection: Upstream/DownstreamTraffic Priority: 0Maximum Sustained Rate: 0 bits/secMax Burst: 1522 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 100 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsScheduling Type: Unsolicited Grant Service(AD)Request/Transmission Policy: 0x1FFNominal Polling Interval: 10000 usecsTolerated Poll Jitter: 4000 usecsUnsolicited Grant Size: 100 bytesNominal Grant Interval: 20000 usecsTolerated Grant Jitter: 4000 usecsGrants per Interval: 1IP ToS Overwrite [AND-mask,OR-mask]: 0xE0,0xA0Max Latency: 0 usecsParameter Presence Bitfield: {0xE08, 0xBFC000}Index: 3Name: UP_RTPSDirection: Upstream/DownstreamTraffic Priority: 0Maximum Sustained Rate: 128000 bits/secMax Burst: 2000 bytesMinimum Reserved Rate: 64000 bits/secMinimum Packet Size 64 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsMaximum Concatenated Burst: 1522 bytesScheduling Type: Realtime Polling ServiceRequest/Transmission Policy: 0x1FFNominal Polling Interval: 10000 usecsTolerated Poll Jitter: 4000 usecsIP ToS Overwrite [AND-mask,OR-mask]: 0xE0,0xA0Max Latency: 0 usecsParameter Presence Bitfield: {0xDC8, 0x83E000}Index: 4Name: UP_BEDirection: Upstream/DownstreamTraffic Priority: 5Maximum Sustained Rate: 128000 bits/secMax Burst: 2000 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 64 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsMaximum Concatenated Burst: 1522 bytesScheduling Type: Best EffortRequest/Transmission Policy: 0x0IP ToS Overwrite [AND-mask,OR-mask]: 0xE0,0x0Max Latency: 0 usecsParameter Presence Bitfield: {0xDE8, 0x80E000}Index: 5Name: DOWN_BEDirection: Upstream/DownstreamTraffic Priority: 5Maximum Sustained Rate: 1000000 bits/secMax Burst: 3000 bytesMinimum Reserved Rate: 0 bits/secMinimum Packet Size 64 bytesAdmitted QoS Timeout 30 secondsActive QoS Timeout 30 secondsMaximum Concatenated Burst: 0 bytesScheduling Type: Best EffortRequest/Transmission Policy: 0x0IP ToS Overwrite [AND-mask,OR-mask]: 0xFF,0x0Max Latency: 0 usecsParameter Presence Bitfield: {0xDE8, 0x0}Router#Related Commands
show interface cable downstream
To display the downstream packet queuing and the scheduling state, use the show interface cable downstream command.
show interface cable x/y downstream
Syntax Description
x/y
Identifies the cable interface by chassis slot number and downstream port number. Valid slot numbers for the cable interface in the Cisco uBR7200 series routers are from 3 to 6.
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Examples
The following example shows a typical display of downstream packet queueing statistics.
Router# show interface cable 4/0 downstreamCable4/0:Downstream is up54335436 packets output, 2854290447 bytes, 0 discarded0 output errors1 total active devices, 1 active modemsTotal downstream bandwidth: 27000000 bpsTotal downstream reserved bandwidth: 1000000 bpsWorst case latency for low latency queue: 0 usecsCurrent Upper limit for worst case latency: 0 usecsOutput Priority Queue Status:Priority Queue contains 0 packets[Queue 0]: 0/40, total packets 2394[Queue 1]: 0/40, total packets 0[Queue 2]: 0/40, total packets 0[Queue 3]: 0/40, total packets 0[Queue 4]: 0/40, total packets 0[Queue 5]: 0/40, total packets 0[Queue 6]: 0/40, total packets 0[Queue 7]: 0/40, total packets 0[Queue 8]: 0/40, total packets 0Rate Limit Statistics:Reserved rate exceeded packets: 1434101Peak rate exceeded packets: 441441Traffic shaped packets: 41444Rate limit drops: 112111show interface cable mac-scheduler
To display the current time-slot scheduling state and statistics, use the show interface cable mac-scheduler command in privileged EXEC mode.
show interface cable x/y mac-scheduler [usport]
Note
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Examples
The following example shows typical output for upstream port 0 on the indicated cable interface.
Router# show interface c3/0 mac-scheduler 0DOCSIS 1.1 MAC scheduler for Cable3/0/U0Queue[Rng Polls] 0/64, 0 dropsQueue[CIR Grants] 0/64, 0 dropsQueue[BE(7) Grants] 0/64, 0 dropsQueue[BE(6) Grants] 0/64, 0 dropsQueue[BE(5) Grants] 0/64, 0 dropsQueue[BE(4) Grants] 0/64, 0 dropsQueue[BE(3) Grants] 0/64, 0 dropsQueue[BE(2) Grants] 0/64, 0 dropsQueue[BE(1) Grants] 0/64, 0 dropsQueue[BE(0) Grants] 0/64, 0 dropsReq Slots 21992195, Req/Data Slots 0Init Mtn Slots 313764, Stn Mtn Slots 37638Short Grant Slots 3739132, Long Grant Slots 512Fragmentation count 5Fragmentation test disabledAvg upstream channel utilization : 2%Avg percent contention slots : 96%Avg percent initial ranging slots : 1%Avg percent minislots lost on late MAPs : 0%Sched Table Adm-State: Grants 1, Reqpolls 0, Util 2%UGS : 1 SIDs, Reservation-level in bps 80000UGS-AD : 0 SIDs, Reservation-level in bps 0RTPS : 0 SIDs, Reservation-level in bps 0NRTPS : Not SupportedBE : 4 SIDs, Reservation-level in bps 0show interface cable service-flow
To display the attributes of DOCSIS service flows on a given cable interface, use the show interface cable service-flow command in privileged EXEC mode.
show interface cable x/y service-flow [sfid] [classifiers | counters | phs | qos] [verbose]
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Usage Guidelines
The verbose keyword can be used with any of the other options or by itself.
Examples
The following examples show output from the show interface cable service-flow command:
Router# show int c3/0 service-flowSfid Sid Mac Address QoS Param Index Type Dir Curr ActiveProv Adm Act State Time4 N/A 0002.1685.ac63 5 5 5 prim DS act 8h09m1258 N/A 0002.1685.ac63 6 6 6 sec(S) DS act 8h09m3 1 0002.1685.ac63 3 3 3 prim US act 8h09m1257 22 0002.1685.ac63 4 4 4 sec(S) US act 8h09m6 N/A 0001.9659.51e1 5 5 5 prim DS act 10h30m1254 N/A 0001.9659.51e1 6 6 6 sec(S) DS act 10h30m5 2 0001.9659.51e1 3 3 3 prim US act 10h30m1253 20 0001.9659.51e1 4 4 4 sec(S) US act 10h30m8 N/A 0002.1685.ac3d 5 5 5 prim DS act 10h30m1250 N/A 0002.1685.ac3d 6 6 6 sec(S) DS act 10h30m7 3 0002.1685.ac3d 3 3 3 prim US act 10h30m1249 18 0002.1685.ac3d 4 4 4 sec(S) US act 10h30m10 N/A 0002.1685.ac5f 5 5 5 prim DS act 10h30m1252 N/A 0002.1685.ac5f 6 6 6 sec(S) DS act 10h30m9 4 0002.1685.ac5f 3 3 3 prim US act 10h30m1251 19 0002.1685.ac5f 4 4 4 sec(S) US act 10h30m16 N/A 0002.1685.ac67 2 2 2 prim DS act 00:2815 5 0002.1685.ac67 1 1 1 prim US act 00:2822 N/A 0050.f112.2224 5 5 5 prim DS act 40:111260 N/A 0050.f112.2224 6 6 6 sec(S) DS act 40:1121 6 0050.f112.2224 3 3 3 prim US act 40:11Table 4 shows the descriptions for the fields displayed by this command:
Router# show interface cable 3/0 service-flow 23456 verboseSfid : 23456MAC Address : 0010.7b6b.7215Type : PrimaryDirection : UpstreamCurrent State : ActiveActive Time : 9h:27mQoS Param timeout [Active, Admitted] : [200, 200] secsClassifiers : 123.3334, 556, 221Sid : 1000Traffic Priority : 5Maximum Sustained Rate : 128000 bits/secMaximum Burst : 1522 bytesMinimum Reserved Rate : 32000 bits/secPackets : 33445Bytes : 45612Packet Drops : 34Current Throughput : 100000 bits/sec, 200 packets/secRouter# show int c4/0 service-flow qosSfid Dir Curr Sid Sched Prio MaxSusRate MaxBrst MinRsvRate ThroughputState Type12 DS act N/A BE 0 1000000 0 0 011 US act 5 BE 0 64000 0 0 014 DS act N/A BE 0 1000000 0 0 013 US act 6 BE 0 64000 0 0 016 DS act N/A BE 0 1000000 0 0 015 US act 7 BE 0 64000 0 0 018 DS act N/A BE 0 1000000 0 0 017 US act 8 BE 0 64000 0 0 0
Note
Sample Downstream Flow
Router# show int c4/0 service-flow 12 qos verboseSfid : 12Current State : ActiveSid : N/ATraffic Priority : 0Maximum Sustained rate : 1000000 bits/secMaximum Burst : 0 bytesMimimum Reserved rate : 0 bits/secMinimum Packet Size : 0 bytesMaximum Latency : 0 usecsCurrent Throughput : 0 bits/sec, 0 packets/secSample Upstream Flow
Router# show int c4/0 service-flow 11 qos verboseSfid : 11Current State : ActiveSid : 5Traffic Priority : 0Maximum Sustained rate : 64000 bits/secMaximum Burst : 0 bytesMimimum Reserved rate : 0 bits/secMinimum Packet Size : 0 bytesMaximum Concatenated Burst : 1522Scheduling Type : Best EffortUnsolicited Grant Size : 0 bytesNominal Grant Interval : 0 usecsGrants per interval : 0Tolerated Grant Jitter : 0 usecsNominal Polling Interval : 0 usecsTolerated Polling Jitter : 0 usecsRequest/Transmission policy : 0x0IP ToS Overwrite[AND-mask, OR-mask] : 0x0, 0x0Current Throughput : 0 bits/sec, 0 packets/secRouter# show int c4/0 service-flow countersSfid Packets Bytes PacketDrops Bits/Sec Packets/Sec12 0 0 0 0 011 0 0 0 0 014 0 0 0 0 013 2 128 0 0 016 0 0 0 0 015 2 128 0 0 018 0 0 0 0 017 2 128 0 0 0
Note
Router# show int c4/0 service-flow 12 counters verboseSfid : 12Packets : 154Octets : 51656RateLimit Delayed Pkts : 0RateLimit Dropped Pkts : 0Bits/sec : 0Packets/Sec : 0Router# show int c4/0 service-flow classifiersCfrId SFID cable modem Mac Address Direction State Priority Matches2 14 00d0.bad3.c46b upstream active 8 01 14 00d0.bad3.c46b upstream inactive 5 0Router# show int c4/0 service-flow 14 classifiers verboseSfid : 14Classifier Id : 2Service Flow Id : 14cable modem Mac Address : 00d0.bad3.c46bDirection : upstreamActivation State : activeClassifier Matching Priority : 8PHSI : 0Number of matches : 0IP Classification Parameters:Destination Port Low : 1024Destination Port High : 65535Router# show interface cable 3/0 service-flow phsSfid PHSI PHSS PHSM PHSF9 1 24 F7 FF 00 00 00 00 00 00 08 90 A0 B0 C0 D0 E0 F0cmts#show interface cable 3/0 service-flow 9 phs verboseSfid: 9PHSI: 1PHSS: 24PHSM: F7 FF 00PHSF: 08 90 A0 B0 C0 D0 E0 F0 00 10 20 30 40 50 60 70 00 00 00 0000 00 00 00show interface cable sid
To display the service identifier (SID) for a cable modem, use the show interface cable sid command in Privileged EXEC mode.
show interface cable x/y sid [counters | qos] [verbose]
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Command History
Usage Guidelines
Data transport over the radio frequency (RF) link uses the registered SID address rather than the Ethernet address. This allows multiple hosts to access the network via a single cable modem.
The verbose keyword can be used with any of the other options or by itself.
Examples
The following sample output from the show interface cable sid command shows the various forms of the command.
Router# show int c4/0 sidSid Prim MAC Address IP Address Type Age Admin Sched SfidState Type5 0010.7b6b.58c1 0.0.0.0 stat 2d1h36menable BE 116 0010.7bed.9dc9 0.0.0.0 stat 2d1h36menable BE 137 0010.7bed.9dbb 0.0.0.0 stat 2d1h36menable BE 158 0010.7b6b.58bb 0.0.0.0 stat 2d1h34menable BE 17Router# show int c4/0 sid qosSid Pr MaxSusRate MinRsvRate Sched Grant Grant GPI Poll ThrputType Size Intvl Intvl5 0 64000 0 BE 0 0 0 0 06 0 64000 0 BE 0 0 0 0 07 0 64000 0 BE 0 0 0 0 08 0 64000 0 BE 0 0 0 0 0Router# show int c4/0 sid 5 qosSid Pr MaxSusRate MinRsvRate Sched Grant Grant GPI Poll ThrputType Size Intvl Intvl5 0 64000 0 BE 0 0 0 0 0
Router# show int c4/0 sid 5 qos verboseSid : 5Traffic Priority : 0Maximum Sustained Rate : 64000Maximum Burst : 0Minimum Reserved Rate : 0Minimum Packet Size : 0Maximum Concatenated Burst : 1522Scheduling Type : Best EffortNominal Grant Interval : 0Tolerated Grant Jitter : 0Nominal Polling Interval : 0Tolerated Polling Jitter : 0Unsolicited Grant Size : 0Grants per Interval : 0Request/Transmission Policy : 0x0IP ToS Overwrite [AND-mask, OR-mask] : 0x0, 0x0Current Throughput : 0 bits/sec, 0 packets/secRouter# show int c5/0 sid counter00:02:23: %ENVM-3-LASTENV: Cannot save environmental dataSid Req-polls BW-reqs Grants Packets Frag Concatpktsissued received issued received complete received1 0 22 22 22 0 02 0 3 3 2 0 03 0 0 0 0 0 0Router# show int c4/0 sid 3 counter verboseSid : 3Request polls issued : 0BW requests received : 1No grant buf BW request drops : 0Rate exceeded BW request drops : 0Grants issued : 1Packets received : 0Bytes received : 0Fragment reassembly completed : 0Fragment reassembly incomplete : 0Concatenated packets received : 0Queue-indicator bit statistics : 0 set, 0 grantedTable 5 describes the fields shown in the show interface cable sid display.
Related Commands
show interface cable signal-quality
Displays information about the cable signal quality.
Debug Commands
The support for DOCSIS 1.1 includes the following new debugging commands:
Caution
debug cable dci
To display information about DOCSIS 1.1 Device Class Identification (DCI) messages, use the debug cable dci command in Privileged EXEC mode. To disable debugging output for DCI messages, use the no form of this command.
debug cable dci
no debug cable dci
Syntax Description
This command has no arguments or keywords.
Command Modes
Privileged EXEC
Command History
Usage Guidelines
This command shows debugging messages about the DCI-REQ messages that the CMTS receives from cable modems.
Note
Examples
The following example shows typical output for the debug cable dci command:
Router# debug cable dciCMTS dci debugging is onRouter#DCI-REQ: CM->1234.5678.abcd SID->1Device Class 1st half->0000000000000000 Device Class 2nd half->0000000000000001Related Commands
debug cable mac-scheduler
To display information about the MAC scheduler's admission control activities, use the debug cable mac-scheduler command in Privileged EXEC mode. The no form of this command disables debugging output.
debug cable mac-scheduler [admission-control]
no debug cable mac-scheduler [admission-control]
Syntax Description
admission-control
Displays debugging output for the MAC scheduler's admission control activities, which controls the percentage of overbooking allowed on the upstream channel.
Command Modes
Privileged EXEC
Command History
Usage Guidelines
Do not use this command if you have a large number of modems on your network. The Cisco uBR7246 will become flooded with console printouts.
Examples
The following example shows debugging being turned on for the MAC scheduler:
Router# debug cable mac-scheduler admission-controlCMTS scheduler debugging is onRouter#Related Commands
cable upstream admission-control
Determines the percentage of overbooking allowed on the upstream channel.
debug cable phs
To display the activities of the payload header suppression and restoration (PHS) driver, use the debug cable phs command in Privileged EXEC mode. The no form of this command disables debugging output.
debug cable phs
no debug cable phs
Syntax Description
This command has no arguments or keywords.
Command Modes
Privileged EXEC
Command History
Usage Guidelines
This command displays the output for both the upstream and downstream drivers. The upstream receive driver restores headers that have been suppressed by cable modems, and the downstream driver suppresses specific fields in packet header before forwarding a frame to the cable modem.
Note
Examples
The following example shows typical output for PHS debugging:
Router# debug cable phsCMTS payload header suppression debugging is on00:02:55: New PHS rule: 1 (SFID: 9)size : 34mask : 00 00 00 03 FC 00 00 00 field: 00 00 00 00 00 00 00 00Add PHS rule 1 to CFR ID 100:02:57: New PHS rule: 1 (SFID: 11)size : 34mask : 00 00 00 03 FC 00 00 00 field: 00 00 00 00 00 00 00 00Add PHS rule 1 to CFR ID 1Router#debug cable tlvs
To display the TLVs parsed by the DOCSIS 1.1 TLV parser/encoder, use the debug cable tlvs command in Privileged EXEC mode. In particular, this command displays the TLVs for service flow encodings, classifier encodings, and PHS rules.
The no form of this command disables debugging output.
debug cable tlvs
no debug cable tlvs
Syntax Description
This command has no arguments or keywords.
Command Modes
Privileged EXEC
Command History
Usage Guidelines
Do not use this command when you have a large number of active cable modems on your network because it could generate a huge amount of output to the console port.
Examples
The following example shows typical output for the debug cable tlvs command:
Router# debug cable tlvsCMTS TLV encodings debugging is on00:02:06: Registration request from 0003.e350.9b8d, SID 3 on Cable3/0/U000:02:06: TLV-Block Bytes:00:02:06: 0x0000: 03 01 01 12 01 10 1D 01 00 16 0F 01 01 01 03 0200:02:06: 0x0010: 00 04 09 06 03 04 0A 0A 00 02 18 07 01 02 00 0100:02:06: 0x0020: 06 01 07 18 07 01 02 00 02 06 01 07 18 07 01 0200:02:06: 0x0030: 00 03 06 01 01 18 07 01 02 00 04 06 01 01 19 0700:02:06: 0x0040: 01 02 00 09 06 01 07 19 07 01 02 00 0A 06 01 0100:02:06: 0x0050: 19 07 01 02 00 0B 06 01 01 19 07 01 02 00 0C 0600:02:06: 0x0060: 01 01 06 10 33 E0 BA 7A DA 81 1B 9B 8E 37 F5 3300:02:06: 0x0070: 1C 84 E7 4D 07 10 01 0C C8 DB F9 26 B7 D2 DD 0A00:02:06: 0x0080: 00 58 1E 14 15 FD 0C 04 0A 0A 00 02 08 03 00 0300:02:06: 0x0090: E3 05 21 02 01 01 03 01 01 04 01 01 05 01 00 0600:02:06: 0x00A0: 01 01 07 01 00 08 01 04 09 01 00 0A 01 01 0B 0100:02:06: 0x00B0: 08 01 01 0100:02:06: Found Network Access TLV00:02:06: Ntw Access Control : 100:02:06: Found Max CPEs TLV00:02:06: Maximum Number Of CPEs : 1600:02:06: Found Privacy Enable TLV00:02:06: Privacy Enable : 000:02:06: Found Upstream Packet Classifier TLV00:02:06: Classifier Reference : 100:02:06: Service-Flow Reference : 400:02:06: Found IP Packet Classifier Sub-TLV00:02:06: Source Address : 10.10.0.200:02:06: Found Upstream Service Flow TLV00:02:06: Service Flow Reference : 100:02:06: QoS Parameter Set Type : 0x700:02:06: Found Upstream Service Flow TLV00:02:06: Service Flow Reference : 200:02:06: QoS Parameter Set Type : 0x700:02:06: Found Upstream Service Flow TLV00:02:06: Service Flow Reference : 300:02:06: QoS Parameter Set Type : 0x100:02:06: Found Upstream Service Flow TLV00:02:06: Service Flow Reference : 400:02:06: QoS Parameter Set Type : 0x100:02:06: Found Downstream Service Flow TLV00:02:06: Service Flow Reference : 900:02:06: QoS Parameter Set Type : 0x700:02:06: Found Downstream Service Flow TLV00:02:06: Service Flow Reference : 1000:02:06: QoS Parameter Set Type : 0x100:02:06: Found Downstream Service Flow TLV00:02:06: Service Flow Reference : 1100:02:06: QoS Parameter Set Type : 0x100:02:06: Found Downstream Service Flow TLV00:02:06: Service Flow Reference : 1200:02:06: QoS Parameter Set Type : 0x100:02:06: Found CM-MIC TLV00:02:06: CM MIC:00:02:06: 0x0000: 33 E0 BA 7A DA 81 1B 9B 8E 37 F5 33 1C 84 E7 4D00:02:06: Found CMTS-MIC TLV00:02:06: CMTS MIC:00:02:06: 0x0000: 01 0C C8 DB F9 26 B7 D2 DD 0A 00 58 1E 14 15 FD00:02:06: Found CM IP Address TLV00:02:06: Modem IP Address : 10.10.0.200:02:06: Vendor Id:00:02:06: 0x0000: 00 03 E300:02:06: Found Modem Capabilities TLV00:02:06: DOCSIS Version : 100:02:06: Fragmentation Support : 100:02:06: Payload Header Suppresion Support : 100:02:06: IGMP Support : 000:02:06: Privacy Support : 100:02:06: Downstream SAID Support : 000:02:06: Upstream SID Support : 400:02:06: Optional Filtering Support : 000:02:06: Tx Equalizer Taps Per Symbol : 100:02:06: Tx Equalizer Taps Support : 800:02:06: Concatenation Support : 100:02:06: Performing admission control check00:02:06: Added Modem Capabilities TLV:00:02:06: 0x0000: 05 21 02 01 01 03 01 01 04 01 01 05 01 00 06 0100:02:06: 0x0010: 01 07 01 00 08 01 04 09 01 00 0A 01 01 0B 01 0800:02:06: 0x0020: 01 01 0100:02:06: Sfref = 1, SFID = 700:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 18 11 01 02 00 01 02 04 00 00 00 07 03 02 00 0300:02:06: 0x0010: 06 01 0700:02:06: Sfref = 2, SFID = 4300:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 18 11 01 02 00 02 02 04 00 00 00 2B 03 02 00 0B00:02:06: 0x0010: 06 01 0700:02:06: Sfref = 3, SFID = 4400:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 18 0D 01 02 00 03 02 04 00 00 00 2C 06 01 0100:02:06: Sfref = 4, SFID = 4500:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 18 0D 01 02 00 04 02 04 00 00 00 2D 06 01 0100:02:06: Sfref = 9, SFID = 800:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 19 0D 01 02 00 09 02 04 00 00 00 08 06 01 0700:02:06: Sfref = 10, SFID = 4600:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 19 0D 01 02 00 0A 02 04 00 00 00 2E 06 01 0100:02:06: Sfref = 11, SFID = 4700:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 19 0D 01 02 00 0B 02 04 00 00 00 2F 06 01 0100:02:06: Sfref = 12, SFID = 4800:02:06: Added Service Flow Parameters TLV:00:02:06: 0x0000: 19 0D 01 02 00 0C 02 04 00 00 00 30 06 01 0100:02:06: Cfr-ref = 1, CFID = 1, SF-ref 4, SFID 4500:02:06: Added Classifier Parameters TLV:00:02:06: 0x0000: 16 19 01 01 01 03 02 00 04 02 02 00 01 04 04 0000:02:06: 0x0010: 00 00 2D 09 06 03 04 0A 0A 00 0200:02:06: REG-RSP Status : ok (0), REG-ACK required from CM (0)00:02:06: Reg-Ack wait state successfully created00:02:06: Registration Response:00:02:06: 0x0000: C2 00 00 D9 00 00 00 03 E3 50 9B 8D 00 00 00 0000:02:06: 0x0010: 30 30 00 C7 00 00 03 01 07 00 00 03 00 05 21 0200:02:06: 0x0020: 01 01 03 01 01 04 01 01 05 01 00 06 01 01 07 0100:02:06: 0x0030: 00 08 01 04 09 01 00 0A 01 01 0B 01 08 01 01 0100:02:06: 0x0040: 18 11 01 02 00 01 02 04 00 00 00 07 03 02 00 0300:02:06: 0x0050: 06 01 07 18 11 01 02 00 02 02 04 00 00 00 2B 0300:02:06: 0x0060: 02 00 0B 06 01 07 18 0D 01 02 00 03 02 04 00 0000:02:06: 0x0070: 00 2C 06 01 01 18 0D 01 02 00 04 02 04 00 00 0000:02:06: 0x0080: 2D 06 01 01 19 0D 01 02 00 09 02 04 00 00 00 0800:02:06: 0x0090: 06 01 07 19 0D 01 02 00 0A 02 04 00 00 00 2E 0600:02:06: 0x00A0: 01 01 19 0D 01 02 00 0B 02 04 00 00 00 2F 06 0100:02:06: 0x00B0: 01 19 0D 01 02 00 0C 02 04 00 00 00 30 06 01 0100:02:06: 0x00C0: 16 19 01 01 01 03 02 00 04 02 02 00 01 04 04 0000:02:06: 0x00D0: 00 00 2D 09 06 03 04 0A 0A 00 0200:02:06: Registration Response Transmitted00:02:06: Registration acknowledgement from 0003.e350.9b8d, SID 3 on Cable3/0/U000:02:06: REG-ACK confirmation code : 0Glossary
active service flow—An admitted service flow that is available for packet transmissions from the cable modem to the CMTS.
admitted service flow—A provisioned or dynamically signaled service flow that is authorized, and for which resources have been reserved, but that is not active.
amplifier—Used on coaxial segments of a CATV plant to restore signal levels lost due to attenuation through distance.
availability—The long term ratio of the actual Radio Frequency (RF) channel operation time to the scheduled RF channel operation time (expressed as a percentage) based on a bit error rate (BER) assumption.
ATM—Asynchronous Transfer Mode.
bandwidth allocation map—The MAC management message that the CMTS uses to allocate transmission opportunities to cable modems.
branch line—A coaxial cable that runs from a trunk line to a subscriber drop point. A branch line is also known as a feeder cable.
cable interface line card—The modem front-end card of the cable router headend device, plugged into the midplane. Each cable line card provides a number of Radio Frequency (RF) channels as external interfaces.
cable modem (CM)—A modulator/demodulator at subscriber locations that is used in conveying data communications on a cable television system.
cable modem termination system (CMTS)—A device that provides complementary functionality to cable modems to enable connectivity to a wide area network (WAN).
cable access router—A modular chassis-based router that is optimized for the data over CATV HFC application.
CATV—Refers to any cable (coaxial or fiber) based system of television services.
CLI—command line interface.
codec—coder-decoder. A device that typically uses pulse code modulation to transform analog signals into a digital bit stream and digital signals back into analog.
CPE—customer premises equipment. One or more PCs located at the customer site.
distribution hub—A smaller or remote headend distribution point for a CATV system. Video signals are received here from another site (headend) and are redistributed. Sometimes a small number of locally originated signals are added. These signals might be city of information channels, HFC cable modem signals, and so on.
DOCSIS—Data-over-Cable Service Interface Specifications. Defines technical specifications for equipment at both subscriber locations and cable operators' headends. Adoption of DOCSIS can accelerate deployment of data-over-cable services and ensure interoperability of equipment throughout system operators' infrastructures.
downstream—A set of frequencies used to send data from a headend to a subscriber.
drop—A subscriber access point; the actual coaxial connection in a subscriber's home.
fiber node (node)—An optical node (located in the outside plant distribution system) that terminates the fiber-based downstream signal as an electrical signal onto a coaxial RF cable. Each fiber node is defined to support a designated service area, defined either by the number of homes or by total amplifier cascade (the total number of active amplifiers in the longest line from the node to the end of the line).
Headend—The endpoint of a broadcast network and central distribution point for a CATV system. All stations transmit toward the headend; the headend then transmits toward the destination stations. Video signals are received from a satellite (either colocated or remote), and the frequency is converted to the appropriate channels where it is combined with locally originated signals and is rebroadcast onto the HFC plant. For a CATV data system, the headend is the typical place to link between the HFC system and any external data networks.
HFC—Hybrid fiber-coaxial. Older CATV systems were provisioned using only coaxial cable. Modern systems use fiber transport from the headend to an optical node located in the neighborhood to reduce system noise. Coaxial runs from the node to the subscriber. The fiber plant is generally a star configuration with all optical node fibers terminating at a headend. The coaxial part of the system is generally a trunk and branch configuration.
MAC—media access control. Typically refers to the lower of the two sublayers of the data link layer that is defined by the IEEE. The MAC sublayer handles access to shared physical transmission media. In DOCSIS networks, MAC also refers to the management messages that are sent between the CMTS and CM to maintain connectivity over the cable network.
optical node—A device used to convert broadband RF to and from a fiber-optic signal. An optical node is usually located in the outside field.
provisioning—The programming of allocatable resources, such as operating parameters, upstream and downstream frequencies, slot assignments, and logical identifiers, in headend and subscriber modems.
ranging—The adjustment of the subscriber modem upstream timing offset to ensure that an upstream packet inserted into a TDMA slot aligns correctly with the headend modem upstream frame.
registration—The process of a subscriber modem signing on to the cable network by identifying itself to the headend.
SAID—See security association identifier.
security association identifier—A Baseline Privacy security identifier between a CMTS and a cable modem.
service flow—A MAC-layer transport service that:
•
•
service identifier (SID)—A service flow identifier (14 bits) assigned by the CMTS to an active or admitted upstream service flow.
SFID—service flow identifier.
SGCP—Simple Gateway Control Protocol. Controls Voice-over-IP (VoIP) gateways by an external call control element (called a call-agent).
SID— See Service Identifier.
SNMP—Simple Network Management Protocol.
status request—The periodic querying of subscriber cable modems by the headend for alarm and service requests.
tap—A passive device that divides a signal between the trunk or feeder lines and splits the signal into ports for subscriber drop access.
TDM—Time-Division Multiplexing. A technique in which information from multiple channels can be allocated bandwidth on a single wire, based on preassigned time slots. Bandwidth is allocated to each channel regardless of whether the station has data to transmit.
TDMA—Time Division Multiple Access.
trunk line—A CATV backbone coaxial cable. This cable runs from an optical node through a specific neighborhood or service area.
UBR—Universal Broadband Router. Refers to the family line of DOCSIS Cisco CMTS routers.
upstream—The set of frequencies used to send data from a subscriber to the headend.
VoIP—Voice-over-IP. The ability to carry normal telephone-style voice over an IP-based Internet with POTS-like functionality, reliability, and voice quality. VoIP is a blanket term that generally refers to the Cisco standards-based (for example, H.323 or SGCP) approach to IP voice traffic.
.
Guest
