Cisco® Catalyst IW6300 Heavy Duty シリーズ アクセス ポイント モデル
IW-6300H
Cisco® Catalyst IW6300 Heavy Duty シリーズ アクセスポイント PID
-
IW-6300H-AC-A-K9
-
IW-6300H-DC-A–K9
-
IW-6300H-DCW-A-K9
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil contient des émetteurs / récepteurs exemptés de licence qui sont conformes aux RSS exempts de licence d'Innovation,
Sciences et Développement économique Canada. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
Cisco® Catalyst IW6300 Heavy Duty Series Access Points are certified to the requirements of RSS-247. The use of this device
in a system operating either partially or completely outdoors may require the user to obtain a license for the system according
to the Canadian regulations. For further information, contact your local Industry Canada office.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (EIRP) is not more than that permitted for successful communication.
この無線トランスミッタ IC-ID 2461N-ESW6300 は、以下に示すアンテナタイプで動作するように、イノベーション・科学経済開発省(カナダ)によって承認されており、最大許容ゲインが示されています。このリストに含まれてなく、リストにあるすべてのタイプの最大ゲインを超えるゲインを持つアンテナタイプは、このデバイスとともに使用することは固く禁止されています。
表 1. IW-6300H アクセスポイントでサポートされる外部アンテナ
製品 ID
|
周波数帯域
|
ゲイン
|
タイプ
|
AIR-ANT2547V-N
|
2.4 / 5 GHz
|
4 / 7 dBi
|
全方向性、垂直偏波、白色
|
AIR-ANT2547VG-N
|
2.4 / 5 GHz
|
4 / 7 dBi
|
全方向性、垂直偏波、灰色
|
AIR-ANT2547V-N-HZ
|
2.4 / 5 GHz
|
4 / 7 dBi
|
全方向性、垂直偏波、白色、危険な場所用
|
AIR-ANT2568VG-N
|
2.4 / 5 GHz
|
6 / 8 dBi
|
全方向性、垂直偏波、灰色
|
AIR-ANT2588P3M-N=
|
2.4 / 5 GHz
|
6 / 8 dBi
|
指向性、デュアル偏波、3 ポート
|
AIR-ANT2513P4M-N=
|
2.4 / 5 GHz
|
13 / 13 dBi
|
指向性、デュアル偏波、4 ポート
|
AIR-ANT2450V-N=
|
2.4 GHz
|
5 dBi
|
全方向性、垂直偏波、白色
|
AIR-ANT2450V-N-HZ=
|
2.4 GHz
|
5 dBi
|
全方向性、垂直偏波、白色、危険な場所用
|
AIR-ANT2450VG-N=
|
2.4 GHz
|
5 dBi
|
全方向性、垂直偏波、灰色
|
AIR-ANT2450HG-N=
|
2.4 GHz
|
5 dBi
|
全方向性、水平偏波、灰色
|
AIR-ANT2480V-N=
|
2.4 GHz
|
8 dBi
|
全方向性、垂直偏波
|
AIR-ANT2413P2M-N=
|
2.4 GHz
|
13 dBi
|
指向性、デュアル偏波、2 ポート
|
AIR-ANT5150VG-N=
|
5 GHz
|
5 dBi
|
全方向性、垂直偏波、灰色
|
AIR-ANT5150HG-N=
|
5 GHz
|
5 dBi
|
全方向性、水平偏波、灰色
|
AIR-ANT5180V-N=
|
5 GHz
|
8 dBi
|
全方向性、垂直偏波
|
AIR-ANT5114P2M-N=
|
5 GHz
|
13 dBi
|
指向性、デュアル偏波、2 ポート
|
適合性を維持するために、アンテナは人体から 60 cm(23.6 インチ)以上の距離をあけて設置する必要があります。
La distance minimale de séparation de toute personne est de 60 cm (23.6") pour assurer le respect.
(注)
|
|
