Cisco IOS Embedded Event Manager (EEM)

EEM Configuration for Cisco Integrated Services Router Platforms

Last updated: February 2008

Abstract

This document describes how to configure Cisco IOS® Embedded Event Manager (EEM) to match the scenarios in which Cisco® integrated-services-router platforms will be deployed. It also describes how to program EEM Tool Command Language (TCL) policies.

Introduction

Cisco IOS Embedded Event Manager (EEM) is a powerful tool integrated with Cisco IOS Software for system management from within the device itself. EEM offers the ability to monitor events and take informational, corrective, or any desired action when the monitored events occur or when a threshold is reached. Capturing the state of the router during such situations can be invaluable in taking immediate recovery actions and gathering information to perform root-cause analysis. Network availability is also improved if automatic recovery actions are performed without the need to fully reboot the routing device.
EEM consists of three main components: EEM server, event publisher (event detector; Figure 1), and event Subscriber (policies).

Figure 1. EEM Core Event Detector

Event Detectors

The event detector notifies the EEM server when an event of interest occurs. Event detectors are separate systems that provide an interface between the agent being monitored (for example, Simple Network Management Protocol [SNMP]), and the EEM policies where an action can be implemented (refer to Table 1).

Table 1. Event Detector

Event Detector

Description

Application-Specific Event Detector

Allows any EEM policy to publish an event

Command-Line Interface (CLI) Event Detector

Triggers policies based on commands entered through the CLI; uses a regular expression match

Counter Event Detector

Triggers policies based on a change of the designated counter; is used to manipulate counters named by the policy writer and is internal to EEM

Enhanced-Object-Tracking Event Detector*

Triggers policies when the status of tracked object changes

Interface-Counter Event Detector

Triggers policies when the Cisco IOS interface counter for a specific interface crosses a threshold

Online Insertion and Removal (OIR) Event Detector

Triggers policy when hardware is installed or removed

Resource Event Detector*

Triggers policies when Embedded Resource Manager (ERM) reports an event for specified policy; tracks resource depletion within a system

SNMP Event Detector

Triggers policies based on the associated SNMP MIB variable; includes MIB variable thresholds

Syslog Event Detector

Triggers policies based on the regular expression match of a local syslog message

Timer Event Detector

Triggers policies based on timer that includes:

Absolute day and time
Countdown timer down to zero
Watchdog timer
UNIX cron mechanism

None Event Detector

Triggers when the Cisco IOS event manager run CLI command executes an EEM policy

Watchdog System Monitor Event Detector

Triggers policies based on certain conditions relative to a certain Cisco IOS Software process or activity of a subsystem

* Introduced in EEM Version 2.2

EEM Policy

When an event or fault is detected, EEM policy (subscriber) implements the recovery action on the basis of the current state of the system and the actions specified in the policy for the given event. Two policy engines are defined: the Cisco IOS Software CLI applet interface and the TCL subsystem and interpreter.
The recovery action could be any of the following:

• Executing a Cisco IOS CLI command

• Generating a Cisco Networking Services (CNS) event for upstream processing by Cisco CNS devices

• Setting or modifying a named counter

• Requesting system information when an event occurs

• Sending a short e-mail

• Manually running an EEM policy

• Publishing an application-specific event

• Reloading the Cisco IOS Software

• Generating an SNMP trap

• Generating prioritized syslog messages

• Reading the state of a tracked object

• Setting the state of a tracked object

EEM Environmental Variables

EEM allows you to use environment variables in EEM policies. TCL allows you to define global variables that are known to all procedures within a TCL script. EEM allows you to define environment variables using a CLI command (event manager environment) for use within an EEM policy. All EEM environment variables are automatically assigned to TCL global variables before a TCL script is run. Three different types of environment variables are associated with Embedded Event Manager:

• User-defined: You can define an environment variable if you create it in a policy that you write.

• Cisco-defined: Cisco can define an environment variable for a specific sample policy.

• Cisco built-in (available in EEM applets): Cisco can define an environment variable to be read-only or read/write. The read-only variables are set by the system before an applet starts to execute. The single read/write variable (_exit_status) allows you to set the exit status at policy exit for policies triggered from synchronous events.

EEM Applet

An EEM applet is a simple form of policy defined within the CLI configuration. In EEM applet configuration mode, three types of configuration statements are supported. The event commands are used to specify the event criteria to trigger the applet to run, the action commands are used to specify an action to perform when the EEM applet is triggered, and the set command is used to set the value of an EEM applet variable. Use the show event manager policy registered command to display a list of registered applets.

EEM Script

A script is defined off the networking device using an ASCII editor. The script is then copied to the networking device and registered with EEM. TCL scripts are supported by EEM.
EEM allows you to write and implement your own policies using TCL. Writing an EEM policy involves:

• Selecting the event for which the policy is run

• Defining the event-detector options associated with logging and responding to the event

• Choosing the actions to be followed when the event occurs

Cisco provides enhancements to TCL in the form of keyword extensions that facilitate the development of EEM policies. The main categories of keywords identify the detected event, the subsequent action, utility information, counter values, and system information. For more details about the EEM event detectors and about creating EEM policies, refer to the Writing Embedded Event Manager Policies document.
Cisco includes a set of sample policies. You can copy the sample policies to a user directory and then modify the policies, or you can write your own policies. TCL is currently the only scripting language that Cisco supports for policy creation. You can modify TCL policies by using a text editor such as Emacs. Policies must execute within a defined number of seconds, and you can configure the time variable. The default is currently 20 seconds.

EEM Sample Configuration: EEM with Applet Policy

Tables 2 and 3 show the commands to configure the applet and the output, respectively. Then Table 4 show the command to configure EEM with TCL script

Table 2. Applet Configuration

Command

Purpose

ROUTER(config)#event manager applet ISR_CISCO

Creates and registers the applet with EEM

ROUTER(config-applet)# event syslog pattern "Interface GigabitEthernet0/0, changed state to down"

Configures syslog event detector to match the interface message

ROUTER(config-applet)# action 1.0 cli command "enable"

ROUTER(config-applet)# action 1.1 cli command "configure term"

ROUTER(config-applet)# action 1.2 cli command "interface g0/1"

ROUTER(config-applet)# action 1.3 cli command "no shut"

ROUTER(config-applet)#

Configures action to enable the g0/1 interface on seeing the g0/0 interface going down

Table 3. Applet Output

Steps

Description

ROUTER#sh int g0/1 | inc proto

GigabitEthernet0/1 is administratively down, line protocol is down

The interface is manually shut down by the administrator

ROUTER(config)#int g0/0

ROUTER(config-if)#shut

ROUTER(config-if)#

*Nov 12 07:23:21.684: %LINK-5-CHANGED: Interface GigabitEthernet0/0, changed state to administratively down

*Nov 12 07:23:22.684: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet0/0, changed state to down

Syslog message triggers the EEM and the configured action is implemented

*Nov 12 07:32:38.568: %SYS-5-CONFIG_I: Configured from console by vty0

*Nov 12 07:32:40.556: %LINK-3-UPDOWN: Interface GigabitEthernet0/1, changed state to up

ROUTER(config-if)#do sh int g0/1 | inc proto

GigabitEthernet0/1 is up, line protocol is up

ROUTER(config-if)#



Table 4. EEM with TCL Script Policy

Command

Purpose

event manager environment variable-name string

Example:

Router(config)# event manager environment _cron_entry 0-59/2 0-23/1 * * 0-6

Configures the value of the specified EEM environment variable

Note: In this example, the software assigns a cron timer environment variable to be set to every second, minute, and every hour of every day.

event manager directory user policy Path

Example:

Router(config)# event manager directory user policy flash:/

Configures the location where the user-defined TCL script is stored

event manager policy policy-filename [type {system | user}] [trap]

Example:

Router(config)# event manager policy tm_cli_cmd.tcl type system

Registers the EEM policy to be run when the specified event defined within the policy occurs

• Use the system keyword to register a Cisco-defined system policy.
• Use the user keyword to register a user-defined system policy.

Note: In this example, the sample EEM policy named tm_cli_cmd.tcl is registered as a system policy.

Case Studies

The following case studies can help you understand how and where to use EEM efficiently.

Example 1: Command Execution with Logged Event

This example illustrates the use of EEM to execute show commands when a particular event occurs and collect the output and save it in some location that you can use for troubleshooting later. Figure 2 shows the topology.

Figure 2. Topology Diagram

Challenge

This example shows how to collect CPU usage and interface output when the Open Shortest Path First (OSPF) neighbor is down in router B.

Solution

EEM is configured to check for an OSPF-neighbor-down syslog message; if it occurs, it executes the following command and saves the output in flash memory:

show cpu process

show interfaces

The configuration follows:
RouterB#sh run
Building configuration...
Current configuration : 1137 bytes
!
version 12.4
service timestamps debug datetime msec
service timestamps log datetime msec
no service password-encryption
!
hostname RouterB
ip cef
!
interface Loopback0
ip address 2.2.2.2 255.255.255.0
!
interface GigabitEthernet0/0
ip address 192.168.1.1 255.255.255.0
duplex auto
speed auto
!
interface GigabitEthernet0/1
no ip address
shutdown
duplex auto
speed auto
!
router ospf 1
log-adjacency-changes
network 192.168.1.0 0.0.0.255 area 0
line con 0
exec-timeout 0 0
line aux 0
line vty 0 4
login
!
scheduler allocate 20000 1000
!
webvpn cef
!
event manager applet OSPF
event syslog pattern "Neighbor Down: Dead timer expired"
action 1.0 cli command "enable"
action 1.1 cli command "sh proc cpu | append flash:cpu_info"
action 1.2 cli command "show interface | append flash:interface_info"
action 1.6 syslog msg "OSPF NEIGHBOR DOWN"
!
end
RouterB#
The event logs for this example follow:
RouterB#
RouterB#sh flas
-#- --length-- -----date/time------ path
1 1902 Nov 12 2007 07:54:16 +00:00 test.tcl
3 50938004 Sep 10 2007 11:25:20 +00:00 c2800nm-advipservicesk9-mz.124-15.T1.bin
12931072 bytes available (50946048 bytes used)
RouterB#
RouterB#
RouterB#
RouterB#sh ip ospf nei
Neighbor ID Pri State Dead Time Address Interface
192.168.1.2 1 FULL/BDR 00:00:31 192.168.1.2 GigabitEthernet0/0
RouterB#sh flas
-#- --length-- -----date/time------ path
1 1902 Nov 12 2007 07:54:16 +00:00 test.tcl
3 50938004 Sep 10 2007 11:25:20 +00:00 c2800nm-advipservicesk9-mz.124-15.T1.bin
12931072 bytes available (50946048 bytes used)
RouterB#
*Nov 13 07:11:26.019: %OSPF-5-ADJCHG: Process 1, Nbr 192.168.1.2 on GigabitEthernet0/0 from FULL to DOWN, Neighbor Down: Dead timer expired
*Nov 13 07:11:26.563: %HA_EM-6-LOG: OSPF: OSPF NEIGHBOR DOWN
RouterB#
RouterB#sh flas
-#- --length-- -----date/time------ path
1 1902 Nov 12 2007 07:54:16 +00:00 test.tcl
3 50938004 Sep 10 2007 11:25:20 +00:00 c2800nm-advipservicesk9-mz.124-15.T1.bin
4 22016 Nov 13 2007 07:11:26 +00:00 cpu_info
5 3532 Nov 13 2007 07:11:26 +00:00 interface_info
12902400 bytes available (50974720 bytes used)
RouterB#

Example 2: Secondary MLPPP Interface Enabled when Traffic Exceeds Threshold

The Cisco integrated services router as a customer edge router plays a significant part in WAN bandwidth management. This example can help you understand the use of EEM to enable the secondary interface into Multilink Point-to-Point Protocol (MLPPP) and increase the bandwidth when the traffic exceeds the threshold. Figure 3 shows the topology.

Figure 3. Topology Diagram

Challenge

The challenge is to bring line 2 into the MLPPP bundle only when the traffic flow exceeds the configured threshold. When the traffic falls below the threshold, line 2 is unconfigured from the MLPPP bundle.

Solution

EEM is configured to check the tx_load parameter every 30 seconds, and if the parameter exceeds the configured threshold, the line 2 serial interface is configured into the MLPPP bundle. If the tx_load parameter falls below the threshold, the second line is unconfigured.
The configuration follows:
ISR#sh run
Building configuration...
Current configuration : 1962 bytes
!
version 12.4
hostname ISR
card type t1 0 0
!
no aaa new-model
no network-clock-participate wic 0
!
ip cef
!
voice-card 0
no dspfarm
controller T1 0/0/0
framing esf
linecode b8zs
channel-group 1 timeslots 1-24
!
controller T1 0/0/1
framing esf
linecode b8zs
channel-group 1 timeslots 1-24
!
interface Multilink1
ip address 10.1.1.2 255.255.255.0
ppp multilink
ppp multilink group 1
!
interface GigabitEthernet0/0
ip address 16.16.16.1 255.255.255.0
duplex full
speed 100
interface Serial0/0/0:1
no ip address
encapsulation ppp
ppp multilink
ppp multilink group 1
!
interface Serial0/0/1:1
no ip address
encapsulation ppp
shutdown
ppp multilink
!
router ospf 1
log-adjacency-changes
network 0.0.0.0 255.255.255.255 area 0
!
line con 0
line aux 0
line vty 0 4
login
event manager environment errim_period 30 ##This environment variable specifies the frequency to check the tx_load##
event manager environment errim_int multilink1 ##This environment variable specifies the target interface##
event manager environment sec_interface Se0/0/1:1 ##This environment variable specifies the Second serial interface##
event manager directory user policy flash:/ ##This specifies the location of policy TCL file##
event manager policy TX_LOAD.tcl type user ##This command register the policy##
!
end
ISR#
The event logs follow:
ISR#sh interface multilink 1 | inc tx
reliability 255/255, txload 1/255, rxload 1/255
ISR#
ISR#sh ppp multilink | inc Se0/0/1:1
ISR#sh run int Se0/0/1:1
Building configuration...
Current configuration : 90 bytes
!
interface Serial0/0/1:1
no ip address
encapsulation ppp
shutdown
ppp multilink
end
ISR#
*Nov 15 04:35:30.386: %HA_EM-5-LOG: system:/lib/tcl/eem_scripts_registered/TX_LOAD.tcl: TX Load exceeds the threshold
*Nov 15 04:35:31.986: %HA_EM-6-LOG: system:/lib/tcl/eem_scripts_registered/TX_LOAD.tcl: SECOND SERIAL INTERFACE IS CONFIGURED
*Nov 15 04:35:32.030: %SYS-5-CONFIG_I: Configured from console by vty0
*Nov 15 04:35:33.210: %LINK-3-UPDOWN: Interface Serial0/0/1:1, changed state to up
*Nov 15 04:35:34.214: %LINEPROTO-5-UPDOWN: Line protocol on Interface Serial0/0/1:1, changed state to up
ISR#sh interface multilink 1 | inc tx
reliability 247/255, txload 14/255, rxload 14/255
ISR#sh ppp multilink | inc Se0/0/1:1
Se0/0/1:1, since 00:00:29
ISR#sh run int se0/0/1:1
Building configuration...
Current configuration : 103 bytes
!
interface Serial0/0/1:1
no ip address
encapsulation ppp
ppp multilink
ppp multilink group 1
end
ISR#
ISR#
ISR#sh interface multilink 1 | inc tx
reliability 232/255, txload 7/255, rxload 7/255
ISR#
*Nov 15 04:38:30.414: %HA_EM-5-LOG: system:/lib/tcl/eem_scripts_registered/TX_LOAD.tcl: TX Load below the threshold. So Unconfiguring the secondary interface
*Nov 15 04:38:32.014: %HA_EM-6-LOG: system:/lib/tcl/eem_scripts_registered/TX_LOAD.tcl: SECOND SERIAL INTERFACE IS UNCONFIGURED
*Nov 15 04:38:32.058: %SYS-5-CONFIG_I: Configured from console by vty0
*Nov 15 04:38:32.614: %LINEPROTO-5-UPDOWN: Line protocol on Interface Serial0/0/1:1, changed state to down
*Nov 15 04:38:33.618: %LINK-5-CHANGED: Interface Serial0/0/1:1, changed state to administratively down
ISR#sh ppp multilink | inc Se0/0/1:1
ISR#sh run int s0/0/1:1
Building configuration...
Current configuration : 90 bytes
!
interface Serial0/0/1:1
no ip address
encapsulation ppp
shutdown
ppp multilink
end
