Release Notes for Analog Modem Firmware Version 1.0.1
September 28, 1998
These release notes document firmware version 1.0.1 for analog modem network modules for Cisco 2600 series and Cisco 3600 series routers. Use this document in conjunction with your router installation and configuration guide, the Network Module Hardware Installation Guide, the Software Configuration Guide, the Regulatory Compliance and Safety Information document for your router, and the Cisco IOS configuration guides and command references.
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
If you have questions or need help, refer to the "Cisco Connection Online" section for further information.
This document includes the following sections:
Modem firmware is downloaded to the modems at startup. A version of firmware is always bundled with the Cisco IOS image. A separate file can be stored in Flash memory to override this firmware with one that contains newer features. If the router finds more than one version of modem firmware at startup, it automatically loads the latest version.
Table 1 Firmware Compatibility
Firmware Version Cisco IOS Release
11.3(4)T and higher
11.3(5)T and higher
Features of Firmware Version 1.0.1
Firmware version 1.0.1 provides support for the following protocols:
•ITU-T V.34 Annex 12 at 33600 and 31200 bps
•ITU-T V.34 at 28,800, 26,400, 24,000, 21,600, 19,200, 16,800, 14,400, 12,000, 9,600, 7,200, 4,800, and 2,400 bps
•ITU-T V.32bis at 14,400, 12,000, 9,600, 7,200, and 4,800 bps
•V.32 terbo up to 19,200 bps
•ITU-T V.32 at 9,600 and 4,800 bps
•ITU-T V.23 in two modes: split speed and half-duplex 1,200/75 (backchannel) bps
•ITU-T V.22bis at 2,400 and 1,200 bps
•ITU-T V.22 at 1,200 bps
•ITU-T V.21 at 300 bps
•Bell 212A at 1,200 bps
•Bell 103A at 300 bps (asynchronous)
•ITU-T V.42 (including MNP 2 to 4 and LAPM) error correction
•ITU-T V.42bis and MNP 5 data compression
Problems Resolved in Firmware Version 1.0.1
The following problems in firmware version 1.0.0 are fixed in version 1.0.1:
•CSCdk35161—Fails V.42bis negotiation with U.S. Robotics internal modem.
•CSCdk31146—Hardware homologation changes to add TBR 21 support.
Known Problems in Firmware Version 1.0.1
Firmware version 1.0.1 has the following known problem:
•CSCdk43602—Bell 103 connections fail.
For the latest information on known problems, follow these steps to consult Cisco Connection Online (CCO):
Step 1 Connect to CCO as directed in the "Cisco Connection Online" section.
Step 2 On the CCO home page, click LOGIN, which appears in green in the menu bar at the top of the page, and log into CCO. (If you are not a registered CCO user, follow the instructions to register so you can log in.)
Step 3 Click Software & Support on the CCO home page.
Step 4 On the Software & Support page, click Technical Tools.
Step 5 On the Technical Tools page, click Bug Toolkit II.
Step 6 Use one of the tools to get up-to-date bug information. For example, click Search for Bug by ID Number, then enter a bug ID, such as CSCdj80580, when prompted.
Note For instructions on using the bug tools, click Help—How to Use the Bug Toolkit at the bottom of the Bug Toolkit II page.
Determining Your Firmware Version
To find out what modem firmware version you have now, enter the show modem version command at the EXEC prompt, Router> or Router#:Router> show modem versionSlot1: MCOM Analog Integrated Modem FirmwareSource: IOSBoot firmware: 1.1.0 MIMIC firmware: 1.2.7Modem firmware: 2.2.44DSP firmware: 0.0.2
A "modem firmware" value of 2.2.44 indicates modem firmware version 1.0.0. A value of 2.2.46 indicates modem firmware version 1.0.1.
Firmware Download Instructions
For firmware download instructions, see the Cisco 2600 Series and 3600 Series Analog Modem Firmware Upgrade Configuration Note in printed form or at the URL:
