As businesses increasingly use networking technology as a productivity tool, they are adding more applications and functions to their IP networks. With voice and other delay-sensitive data traveling on their networks, customers demand reliable network services and often turn to service-level agreements to help ensure network operating performance. Cisco IOS® IP Service Level Agreements (SLAs) is a capability embedded Cisco IOS Software, which allows Cisco customers to increase productivity, lower operational costs, and reduce the frequency of network outages.
IP and SLAs are converging, and extending IP performance monitoring to be application-aware is critical for new IP network applications such as voice over IP (VoIP), audio and video, enterprise resource planning (ERP), customer relationship management (CRM), material requirements planning (MRP), VPNs, and other business-critical applications. Cisco IOS IP SLAs can perform network assessments; verify quality of service (QoS), ease deployment of new services, and assist administrators with network troubleshooting. Cisco IOS IP SLAs use unique service-level assurance metrics and methodology to provide highly accurate, precise service-level assurance measurements.
This document details the new command-line interface (CLI) for Cisco IOS IP SLAs. IP SLAs take full advantage of past Cisco IOS Software service assurance functionality and added recent enhancements, including capabilities related to VoIP, Multiprotocol Label Switching (MPLS), and IP service monitoring. The new CLI eases the deployment of service monitoring and simplifies configuration of IP SLAs measurements and enhances command-line views for the service-level measurement data. This CLI will be introduced over three phases, with the first phase releasing in both Cisco IOS Software Releases 12.4 Mainline and 12.4T. The following list summarizes the CLI changes:
• The first phase includes the new "ip sla" Cisco IOS Software keyword and new show commands to increase usability of the data associated with IP SLAs measurements (by March 2005).
• The second phase includes ease-of-use improvements associated with measurements and the operation of measurement configuration and includes the deprecation of some show commands (by June 2005).
• The final phase of improvements will produce integration between IP SLAs and Modular QoS CLI (MQC), allowing automation and ease of use in the generation of IP SLAs measurements. The QoS integration allows the user to set up a class of service and then quickly and easily measure how the class of service is performing.
PHASE 1 CLI UPDATE: INTRODUCTION OF THE "IP SLA" KEYWORD
Phase 1 Cisco IOS Software Releases 12.4 Mainline and 12.4(1)T, by March 2005
Planned Releases 12.2SX and 12.2SB
The following list describes changes in phase 1:
• The "rtr" keyword has been changed to "ip sla monitor." Therefore, all commands that use "rtr" are now replaced by the keywords "ip sla monitor."
• The "show ip sla monitor statistics [details]" command is introduced, and this command replaces the "show rtr operational-state" command. The "show rtr operational-state" command is available in this release but will be removed in a later phase.
• The "show ip sla monitor statistics aggregated [details]" command is introduced, and this command replaces the "show rtr collection-history" command. This command is very similar to the "show ip sla monitor statistics" command but includes distribution statistics and an aggregated view of data.
• The previous CLI formats are accepted in configuration mode, but a "show run" or "show start" command will output the new CLI formats.
Table 1. A Summary of the New CLI Changes for IP SLAs in Phase 1
Description
Previous CLI Information
IP SLAs CLI
Keyword
rtr
ip sla monitor
rtr responder
ip sla monitor responder
Show Commands
show rtr operation-state
*show ip sla monitor statistics
*show ip sla monitor statistics detail
show rtr collection-statistics
show ip sla monitor collection-statistics
Release 12.4(1)T and above
show rtr collection-statistics
*show ip sla monitor statistics aggregated
*show ip sla monitor statistics aggregated detail
show rtr application
show ip sla monitor application
show rtr configuration
show ip sla monitor configuration
show rtr distribution-statistics
show ip sla monitor distribution-statistics
Release 12.4(1)T and above
show rtr distribution-statistics
*show ip sla monitor statistics aggregated detail
*show ip sla monitor statistics aggregated detail
show rtr enhanced-history
show ip sla monitor enhanced-history
show rtr reaction-configuration
show ip sla monitor reaction- configuration
show rtr reaction-trigger
show ip sla monitor reaction- trigger
show rtr responder
show ip sla monitor responder
show rtr total-statistics
show ip sla monitor total-statistics
show rtr authentication
show ip sla monitor authentication
show rtr apm
show ip sla monitor apm
* New show command.
Example 1
The following example shows a configuration of the User Datagram Protocol (UDP) jitter operation to demonstrate the phase 1 CLI changes.
Previous CLI:
rtr 1
type jitter dest-ipaddr 172.29.139.134 dest-port 5000 num-packets 20
frequency 30
rtr schedule 1 life 300 start-time after 00:05:00
New CLI:
ip sla monitor 1
type jitter dest-ipaddr 172.29.139.134 dest-port 5000 num-packets 20
ip sla monitor schedule 1 life 300 start-time after 00:05:00
Example 2
The following example shows how the "rtr" keyword has been replaced by "ip sla monitor."
Previous CLI:
router(config)#rtr ?
<1-2147483647> Entry number
group Group configuration or group scheduling
key-chain Use MD5 authentication for RTR control message
logging Enable logging
low-memory Configure low-water memory mark
reaction-configuration RTR reaction configuration
reaction-trigger RTR trigger assignment
reset RTR reset
responder Enable RTR responder
restart Restart an active entry
schedule RTR entry scheduling
slm Service-level management
New CLI:
router(config)#ip sla monitor ?
<1-2147483647> Entry number
apm IP SLAs monitor APM configuration
group Group configuration or group scheduling
key-chain Use MD5 authentication for IP SLAs monitor control message
logging Enable logging
low-memory Configure low-water memory mark
reaction-configuration IP SLAs monitor reaction configuration
reaction-trigger IP SLAs monitor trigger assignment
reset IP SLAs monitor reset
responder Enable IP SLAs monitor responder
restart Restart an active entry
schedule IP SLAs monitor entry scheduling
slm Service-level management
Example 3: The "ip sla monitor statistics" show Command
A new show command, "show ip sla monitor statistics," and its variant "show ip sla monitor statistics detail" have been introduced. This command improves the legibility of IP SLAs measurement data. This new show command replaces the previous "show rtr operational-state" command. The previous show commands are still available in the phase 1 CLI, but the new keyword "ip sla monitor" can be used to access the previous formatted output of these commands-for example, "show ip sla monitor operational-state":
router#show ip sla monitor statistics 1
Round trip time (RTT) Index 1
Latest RTT: NoConnection/Busy/Timeout
Latest operation start time: *16:21:32.539 PST Fri Dec 10 2004
Latest operation return code: No connection
RTT Values
Number Of RTT: 0
RTT Min/Avg/Max: 0/0/0 ms
Latency one-way time milliseconds
Number of one-way Samples: 0
Source to Destination one way Min/Avg/Max: 0/0/0 ms
Destination to Source one way Min/Avg/Max: 0/0/0 ms
Jitter time milliseconds
Number of Jitter Samples: 0
Source to Destination Jitter Min/Avg/Max: 0/0/0 ms
Destination to Source Jitter Min/Avg/Max: 0/0/0 ms
Packet Loss Values
Loss Source to Destination: 0 Loss Destination to Source: 0
Out Of Sequence: 0 Tail Drop: 0 Packet Late Arrival: 0
Voice Score Values
Calculated Planning Impairment Factor (ICPIF): 0
Mean Opinion Score (MOS): 0
Number of successes: 0
Number of failures: 2
Operation time to live: 3496 sec
Example 4: The "ip sla monitor statistics detail" show command
router#show ip sla mon statistics 1 detail
Round trip time (RTT) Index 1
Latest RTT: NoConnection/Busy/Timeout
Latest operation start time: *16:23:32.559 PST Fri Dec 10 2004
Latest operation return code: No connection
Over thresholds occurred: FALSE
RTT Values
Number Of RTT: 0
RTT Min/Avg/Max: 0/0/0 ms
Latency one-way time milliseconds
Number of one-way Samples: 0
Source to Destination one way Min/Avg/Max: 0/0/0 ms
Destination to Source one way Min/Avg/Max: 0/0/0 ms
Source to Destination one way Sum/Sum2: 0/0
Destination to Source one way Sum/Sum2: 0/0
Jitter time milliseconds
Number of Jitter Samples: 0
Source to Destination Jitter Min/Avg/Max: 0/0/0 ms
Destination to Source Jitter Min/Avg/Max: 0/0/0 ms
Source to destination positive jitter Min/Avg/Max: 0/0/0 ms
Source to destination positive jitter Number/Sum/Sum2: 0/0/0
Source to destination negative jitter Min/Avg/Max: 0/0/0 ms
Source to destination negative jitter Number/Sum/Sum2: 0/0/0
Destination to Source positive jitter Min/Avg/Max: 0/0/0 ms
Destination to Source positive jitter Number/Sum/Sum2: 0/0/0
Destination to Source negative jitter Min/Avg/Max: 0/0/0 ms
Destination to Source negative jitter Number/Sum/Sum2: 0/0/0
Loss Source to Destination: 0 Loss Destination to Source: 0
Out Of Sequence: 0 Tail Drop: 0 Packet Late Arrival: 0
Number of successes: 0
Number of failures: 1
Failed Operations due to over threshold: 0
Failed Operations due to Disconnect/TimeOut/Busy/No Connection: 0/0/0/1
Failed Operations due to Internal/Sequence/Verify Error: 0/0/0
Distribution Statistics:
Bucket Range: 0-19 ms
Avg. Latency: 0 ms
Percent of Total Completions for this Range: 0 %
Number of Completions/Sum of Latency: 0/0
Sum of RTT squared low 32 Bits/Sum of RTT squared high 32 Bits: 0/0
Operations completed over thresholds: 0
PHASE 2 CLI UPDATE: UPDATE OF MEASUREMENT OPERATION SYNTAX
In phase 2 the individual operation syntax will be updated to enhance ease of use, the details are shown below.
Phase 2 is included in Cisco IOS Software Releases 12.4(2)T by June 2005.
Planned in Releases 12.2SX and 12.2SB
The following list describes changes in phase 2:
• Removal of the "type" keyword allows the user to enter operations directly under the IP SLAs definition.
• The number of Cisco IOS Software sublevels has been reduced, so that individual operations are easy to configure. For example, the "protocol" keyword for Internet Control Message Protocol (ICMP) operations has been removed.
• Redundant and older show commands have been removed and have been replaced by new show commands-for example, "show rtr operational-state." The show commands will be hidden in this release and later removed in a follow-on release.
• History features are grouped together under the "history" keyword.
• The "monitor" keyword has been removed. The "ip sla monitor" keywords are replaced by "ip sla" keywords. The "monitor" keyword in Cisco IOS Software Releases 12.4 Mainline and 12.4(1)T was verbose and the decision was made to remove it.
The following example shows the configuration without the "type" keyword and some new definitions used to define measurement operations.
Hostname or A.B.C.D Destination IP address or hostname
source-ip Source address
ip sla 1
icmp-echo 172.29.139.134
Example 3: Removal of Legacy show Commands
The show commands listed in Table 2 are hidden in this release and are being replaced with new commands in Cisco IOS Software Release 12.4(2nd)T. The new commands will be used in this release and beyond.
Table 2. Deprecated show Commands for Cisco IOS Software Release 12.4(1)T
Deprecated show Commands
IP SLAs CLI
show rtr operation-state
show ip sla statistics
show ip sla statistics detail
show ip sla monitor operation-state
show ip sla statistics
show ip sla statistics detail
show rtr collection-statistics
show ip sla statistics aggregated
show ip sla statistics aggregated details
show rtr distribution-statistics
show ip sla statistics aggregated detail
show rtr total-statistics
show ip sla statistics aggregated detail
Example 4: History Commands with One Keyword
The following example shows the configuration in which all the history commands are grouped under a single keyword.
frequency Frequency in milliseconds of an operation to active
no Negates a command or sets its defaults
request-data-size Requests data size, not including protocol of IP header
threshold Operation threshold in milliseconds
timeout Timeout in milliseconds for an operation
tos Type of service setting for QoS
verify-data Verifies the integrity of data payload
history IP SLAs history commands
router(config-sla-monitor)#icmp-echo 1.1.1.1 source-ipaddr 3.3.3.3 history
router(config-sla-monitor-echo)#?
IP SLAs echo configuration commands:
buckets-kept Maximum number of history buckets to collect
distributions-of-statistics-kept Maximum number of statistics distribution buckets to capture
enhanced Enable enhanced history collection
filter Adds operation to history when...
hours-of-statistics-kept Maximum number of statistics hour groups to capture
lives-kept Maximum number of history lives to collect
statistics-distribution-interval Statistics distribution interval size
Example 5: Removal of the "monitor" Keyword for Configuration
The following two examples show the removal of the monitor keyword that was introduced in Cisco IOS Software Release 12.4 Mainline. One example is a configuration command, and the other example is a show command. It is thought that the monitor keyword is verbose, and so it was removed.
Previous CLI:
ip sla monitor 1
type jitter dest-ipaddr 172.29.139.134 dest-port 5000 num-packets 20
frequency 30
ip sla monitor schedule 1 life 300 start-time after 00:05:00
ip sla monitor reaction-configuration 1 timeout-enable action-type trapOnly
New CLI:
ip sla 1
type jitter dest-ipaddr 172.29.139.134 dest-port 5000 num-packets 20
ip sla schedule rtr schedule 1 life 300 start-time after 00:05:00
ip sla reaction-configuration 1 timeout-enable action-type trapOnly
Monitor Keyword Removal for a show Command
Previous CLI:
router#show ip sla monitor statistics aggregated 10
New CLI:
router#show ip sla statistics aggregated 10
PHASE 3 CLI UPDATE: INTEGRATION OF IP SLAS WITH MODULAR QOS CLI (MQC)
The following list describes changes in phase 3:
• A macro capability will be used to generate and schedule IP SLAs operations, and these operations will be configured with a new CLI that will utilize QoS CLI.
• The capability will initially allow configuration and measurement of QoS performance.
• This capability will be outlined at a later date in this document.
