2.0.11 Version Software Release Notes
Cisco WAN MGX 8850 Software
About These Release Notes
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar, select Documentation, and click Enter the feedback form. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
About the 2.0.11 Release
Phased Release Strategy:
This is the fifth release of PXM45 and AXSM. Follow on releases are planned to add new feature contents and can be found in Marketing Road Map
Software Release 2.0.11 and related hardware:
AXSM Cards
The AXSM is a double height ATM service module that is compatible with release 2.0 and later PXM45 based versions of the MGX. The AXSM uses the serial line traces on MGX chassis to access the 45Gbp crosspoint fabric of the PXM45 and the STRATM48 ASIC technology to accommodate a full duplex throughput of OC48c/STM16.
The AXSM provides ATM switching and line functionality, and is compatible with the feature set of the BXM card of the BPX, the UXM on the IGX, and AUSM of the release 1 MGX8850. Other Cisco ATM platforms, and other ATM manufacturers equipment have proven to be compatible.
Line Interfaces for the AXSM Cards
•
T3/E3
8 ports per back card, 2 back cards per dual height slot
G.703/Accunet Conformance
•
OC3c/STM1
G.703/GR-253 Conformance
8 ports optical per back card, 2 back cards per dual height slot
MMF, SMF intermediate and long reach
4 port Electrical back card
•
OC12c/STM4
G.703/GR-253 Conformance
2 Ports per back card, 2 back cards per dual height slot
SMF intermediate and long reach
•
OC48c/STM16
G.703/GR-253 Conformance
Single port back card, one back card per slot
SMF Short, long and extra-long reach
ATM Layer Information
•
Usage policing supported on all interfaces except OC48c/STM16
•
T3 interfaces support both PLCP and direct cell mapping
•
64 Logical interfaces -- ports, trunks, or virtual trunks (future)
•
16 Class of Service queues for each class of service
•
Supports independent queues for each ATM class of service
Network Management Features
•
OAM functionality per ITU-T I.610
•
Fault management - AIS/RDI at F4 and F5 flow
•
User selectable continuity checking at connection endpoints
•
Loopback diagnostics
•
Automatic alarm generation and propagation for interface failures
The AXSM offers a complete ATM feature set and allows the MGX8850 to scale to the core of service provider networks from the T3/E3 edge to the OC48c core. Full line rate is achieved through the use of the serial line traces on the MGX8850 platform. The entirely standards based design and connection protocols enables the installation into any existing network, as well as building new ATM infrastructures.
PXM 45 Cards
The PXM-45 is a 45Gbps processor switch module. The architecture of the PXM-45 contains the CellBus fabric that is used in the current PXM-1, but adds the functionality of a 45Gbps cross point switching capacity. This allows for the use of the serial line broadband cards (AXSM) in the MGX8850. The PXM-45 provides a Stratum3 central clocking circuit conforming to GR-1244 and G.813 specifications. This is an improvement over the Stratum4 based PXM-1 design.
Reliability, Availability and Serviceability (RAS) Features
The PXM-45 is designed to be fully redundant, there are two dedicated slots in the 8850 (dual height slots 7 and 8) that will house the PXM-45. Highlight of the RAS features are listed below:
•
Switchover from active to standby is designed to result in no cell loss with the exception of cells that are physically on the fabric at the time of the swap.
•
In-band arbitration/grant mechanism ensures that service module failure does not stop traffic flow
•
Hardware design to ensure that if one or both hard disk fails, the cards will still pass traffic with no interruption, although provisioning could be suspended.
•
MTBF Goal is calculated using a 99.9999% availability model which assumes two PXMs in a system. This was calculated at greater than 100,000 hours.
PNNI
The PXM-45 will support PNNI software. There are two other components that make the complete card set these are:
•
PXM-UI-S3
The PXM-UI-S3 supports the following interfaces:
•
One RJ45 10Mbps 802.3 Ethernet port
•
Two RJ45 RS232 Data Termination Equipment (DTE) ports that can be Y cabled. Pinouts are as follows:
•
Two DB9 T1/E1 BITS input, with converted cables that can be Y cabled. The following connections are supported:
–
RJ48. Pin Out conforms to Accunet1.5 Specification
–
Wire Wrap
–
BNC
–
DB15
•
One DB15 Alarm interface. Contacts are normally open. This interface can be Y cabled.
–
PXM-HD
This contains the hard disk for the processor.
PNNI
Defined by the ATM Forum for ATM networks, PNNI provides a dynamic routing protocol, is responsive to changes in network resource availability, and will scale to very large networks.
PNNI includes two categories of protocols. PNNI defines a protocol for distributing topology information between switches and clusters of switches. This information is used to compute paths through the network. PNNI topology and routing are based on the well-known link-state routing technique.
PNNI also defines a second protocol for signaling, that is, message flows used to establish point-to-point connections across the ATM network. This protocol is based on the ATM Forum UNI 4.0 signaling, with mechanisms added to support source routing, crankback, and alternate routing of call setup requests in case of connection setup failure. Whereas the UNI signaling protocol distinguishes between the user and network sides of a connection, PNNI is a symmetrical protocol.
PNNI provides dynamic ATM routing with QoS support as defined by the ATM Forum. PNNI uses link-state and source state route technology, supports aggregation for private ATM addresses and links between switches, and has the ability to scale the network and its performance by means of configuring PNNI peer groups and hierarchical levels. A key feature of the PNNI mechanism is its ability to automatically configure itself in networks in which the address structure reflects the topology.
The functions of the PNNI routing protocol include the following:
•
Hello protocol (allows adjacent switches to exchange topology information)
•
PTSE (PNNI Topology State Elements) database synchronization and management
•
PTSE flooding
•
Address summarization and advertisement
•
Link and nodal aggregation
•
Pre-computation of routing tables
•
Quality of Service (QoS) based routing
•
Multiple Routing Metrics
•
Discovery of neighbors and link status
•
Synchronization of topology databases
•
Load balancing on equal cost paths
•
Load balancing on parallel links
•
Load balancing with redundant addresses
•
Alternate paths
The following PNNI features are supported in Release 2.0 of the MGX.
•
UNI 3.0/3.1
•
PNNI 1.0 Single Peer Group
•
ILMI 4.0
•
Point to point ATM SVCC and SVPC
•
Support for ABR, CBR, VBR, rt-VBR, and UBR
•
Alternate call routing (See separate feature description)
•
On demand call routing (See separate feature description)
•
Native E.164 and AESA (E.164, ICD, DCC) - formerly NSAP - address format
•
Enhanced CAC with per service class policy parameter (See separate feature description)
•
Per Class of service overbooking
•
Congestion control (See separate feature description)
•
PNNI connection and path trace
•
OAM fault management
•
Address Filtering (see separate feature description)
•
Intelligent CAC (see separate feature description)
•
Call Processor Redundancy
PNNI networks are highly resilient due to their ability to quickly reroute connections around failed network elements, and to update routes and network topology based upon availability of network resources. Connections will generally route quickly using pre-computed routing tables, but in the case of congestion or during a network failure, on-demand routes will be calculated for connections.
Special Installation/Upgrade Requirements
Upgrade Procedure
There are new SCT files that are being released with this version.
Note: When upgrading your node, upgrade in the following order
pxm45 backup boot
pxm45 runtime image
axsm runtime image
Loading the runtime images from 2.0.10 to 2.0.11
For Redundant Systems
Upgrade the standby PXM45 boot code by using the following steps:
Step 1
- type "sh" to go to the shellconn
Step 2
- issue "sysBackupBoot" command
Step 3
- hit return when prompted to do so to stop auto-boot, then issue the command sysPxmRemove()
Step 4
- issue the sysFlashBootBurn <"filename"> command where the filename includes the full path.
sysFlashBootBurn "C:FW/pxm45_002.000.011.001_bt.fw"- enter "y" to confirmStep 5
Reset the standby card by issuing "reboot" command. Wait until the standby card goes to "ready" state.
Step 6
Perform a switchcc. When the former active comes up standby, upgrade its boot code by following steps 1-5 above.
Step 7
Use the "LOADREV" command to load the 2.0.11 release on the standby card:
loadrev <slot number> <version>For example: loadrev 7 2.0(11.3)
Step 8
After the standby card comes back up with the new image in the ready state, use the "RUNREV command to load the 2.0.11 release on the active card. This command will bring your original standby card to active state.
runrev <slot number> <version>For example: runrev 8 2.0(11.3)
Step 9
After the redundant card comes up in standby ready, issue the command "COMMITREV" to commit your node to the current release.
commitrev <slot number> <version>For example: commitrev 8 2.0(11.3)
Step 10
Replace SCT.2 and SCT.3 with new SCT on Disk.
Step 11
To upgrade non-redundant AXSM cards with the new runtime image, issue the "LOADREV, RUNREV and COMMITREV" command for each AXSM card.
For example:
loadrev <axsm slot> 2.0(11.3)
runrev <axsm slot> 2.0(11.3)
commitrev <axsm slot> 2.0(11.3)
Repeat these steps for all non-redundant AXSM cards.
Step 12
To upgrade redundant AXSM cards with the new runtime image, issue the "LOADREV" command on for the standby card.
loadrev <slot number> <version>For example: loadrev <axsm slot> 2.0(11.3)
Step 13
After the standby AXSM card comes backup in standby mode, issue the "RUNREV" command for the active card.
runrev <slot number> <version>For example: runrev <axsm slot> 2.0(11.3)
Step 14
After the AXSM card comes backup in standby mode, issue the "COMMITREV" command for the AXSM cards.
commitrev <slot number> <version>For example: commitrev <axsm slot> 2.0(11.3)
Repeat this step 12-14 for all redundant AXSM cards.
For non-redundant (PXM45) systems, please follow these steps
Step 1
Upgrade the PXM45 boot code. - type "sh" to go to the shellconn
a.
- issue "sysBackupBoot" command
b.
- hit return when prompted to do so to stop auto-boot
c.
- issue the sysFlashBootBurn <"filename"> command where the filename includes the full path.
sysFlashBootBurn "C:FW/pxm45_002.000.011.001_bt.fw"d.
- enter "y" to confirm
Step 2
Use the "LOADREV, RUNREV, COMMITREV" commands to load the 2.0.11 release:
-- loadrev 7 2.0(11.3)-- runrev 7.2.0(11.3)-- commitrev 7 2.0(11.3)Step 3
Replace SCT.2 and SCT.3 with new SCT on Disk.
Step 4
To upgrade non-redundant AXSM cards with the new runtime image, issue the "LOADREV" command for each AXSM card.
For example:
loadrev <axsm slot> 2.0(11.3)
runrev <axsm slot> 2.0(11.3)
commitrev <axsm slot> 2.0(11.3)
Repeat these steps for all non-redundant AXSM cards.
Step 5
To upgrade redundant AXSM cards with the new runtime image, issue the "LOADREV" command on for the standby card.
loadrev <slot number> <primary version>For example: loadrev <axsm slot> 2.0(11.3)
Step 6
After the standby AXSM card comes backup in standby mode, issue the "RUNREV" command for the active card.
runrev <slot number> <primary version>For example: runrev <axsm slot> 2.0(11.3)
Step 7
After the AXSM card comes backup in standby mode, issue the "COMMITREV" command for the AXSM cards.
commitrev <slot number> <version>For example: commitrev <axsm slot> 2.0(11.3)
Repeat steps 6-7 for all redundant AXSM cards.
Loading the runtime images from 2.0.02 to 2.0.11
For Redundant Systems
Upgrade the standby PXM45 boot code by using the following steps:
Step 1
- type "sh" to go to the shellconn
Step 2
- issue "sysBackupBoot" command
Step 3
- hit return when prompted to do so to stop auto-boot, then issue the command sysPxmRemove()
Step 4
- issue the sysFlashBootBurn <"filename"> command where the filename includes the full path.
sysFlashBootBurn "C:FW/pxm45_002.000.011.001_bt.fw"- enter "y" to confirmStep 5
Reset the standby card by issuing "reboot" command. Wait until the standby card goes to "ready" state.
Step 6
Perform a switchcc. When the former active comes up standby, upgrade its boot code by following steps 1-5 above.
Step 7
Use the "SETREV" command to load the 2.0.11 release:
setrev <slot number> <primary version>For example: setrev 7 2.0(11.3)
Step 8
Replace SCT.2 and SCT.3 with new SCT on Disk.
Step 9
To upgrade the AXSM runtime, issue the "setrev" command for the AXSM.
For example: setrev <axsm slot> 2.0(11.3)
For non-redundant systems, please follow these steps
Step 1
Upgrade the PXM45 boot code. - type "sh" to go to the shellconn
a.
- issue "sysBackupBoot" command
b.
- hit return when prompted to do so to stop auto-boot
c.
- issue the sysFlashBootBurn <"filename"> command where the filename includes the full path.
sysFlashBootBurn "C:FW/pxm45_002.000.011.001_bt.fw"d.
- enter "y" to confirm
Step 2
Use the "SETREV" command to load the 2.0.11 release:
-- setrev 7 2.0(11.3)Step 3
Replace SCT.2 and SCT.3 with new SCT on Disk.
Step 4
To upgrade the AXSM runtime, issue the "setrev" command for the AXSM.
setrev <axsm slot> 2.0(11.3)Repeat this step for all AXSMs on the card.New CLI Commands
1.
Two new CLI commands have been added on the AXSM card.
a.
clrportcnts: There are no parameters to be entered. This command will clear the counts on all the ports.
b.
clrchancnts: There are no parameters to be entered. This command will clear the counts on all the connections.
2.
The CLI command "clrcnf" has been added to clear a portion of a node's configuration. The following information is retained:
a.
IP Connectivity configuration for LAN and ATM
b.
nodename
c.
Correct primary and secondary software version for all slots
d.
SNMP community string, contact and location.
e.
timezone
f.
GMT offset
g.
date and time
3.
When a command name is abbreviated, the prompt is issued, "Do You Want To Proceed". without including the full command name. This has been changed to reflect the command that was issued. Note, this fix will work for those CLI commands that currently call the areYouSure () function to throw the prompt "Do you want to proceed?". However those CLI commands that don't use the areYouSure () function will continue to throw their own confirmation prompt.
4.
Two additional commands have been added for the AXSM card.
a.
dspbecnt
b.
clrbecnt
Changed CLI Commands
1.
The switchcc command has been changed to reject the pxm switchover if the node is not in a stable state. The node is considered not stable if some of the cards in the node are in the process of transitioning to ready state.
2.
The dsptasks command now has screen prompting to continue or exit from viewing the information.
3.
Before, the card alarms and slot alarms (for the same slot that the card resides in) were being reported by different CLIs i.e., dspcdalms and dspslotalms. Now, both these CLIs have been merged to show both card and slot alarms via dspcdalms. As a result of this change, dspslotalms will no longer be available. Further,
•
- dspcdalm <slot> provides alarm type-level information for the slot specified
•
- dspndalms contains both slot and card alarms under alarm type "Card Alarms"
–
For Example:
Unknown.7.PXM.a > dspcdalms
Card Alarm Summary:
Slot Critical Major Minor
---- -------- ------- -------
1 0 0 1
2 0 0 0
3 0 0 0
4 0 0 0
5 0 0 0
6 0 0 0
7 3 4 5
8 0 2 0
9 0 0 0
10 0 0 0
11 0 0 0
12 0 0 0
13 0 0 0
14 0 0 0
Use dspcdalms <slot> to see more detail.
Unknown.7.PXM.a > dspcdalm 7
Card Alarm Summary
Alarm Type Critical Major Minor
---------- -------- ------- -------
Hardware Alarm 0 0 0
Card State Alarm 0 0 0
Disk Alarm 3 4 5
Line Alarm 0 0 0
Port Alarm 0 0 0
Feeder Alarm 0 0 0
Channel Alarm 0 0 0
Unknown.7.PXM.a > dspndalms
Node Alarm Summary
Alarm Type Critical Major Minor
---------- -------- ------- -------
Clock Alarms 0 0 0
Switching Alarms 4 5 6
Environment Alarms 3 4 5
Card Alarms 3 6 6
Features Not Supported
Committed (but not delivered in this release)
1.
AXSM cards with STM1 electrical interface.
2.
Inter operability with LS1010 and BPX-SES (BPX-SES is in beta phase).
3.
Connection density: 50K connection per node. 40K connections is supported in this release.
Obsoleted:
none
Notes & Cautions
1.
Note upgrading from the 2.0.02 release to 2.0.11 is non-graceful. Upgrading from 2.0.10 to 2.0.11 is graceful.
2.
PNNI default min VCI is 35 unless changed explicitly. The reason for the default is to reserve VCI=32-34 for other control purposes (e.g. MPLS and NCDP). For users who would like to add MPLS controller in release 2.1, it is highly recommend to set the min-vci value to be 35 or more for all partitions on the port where the MPLS partition will be added. By doing so, the TDP sig vc for MPLS will be established automatically on 0/32.
3.
By default, 900 cps and 543 cps will be reserved for SSCOP and PNNI Signalling VC respectively even when you disable SSCOP and PNNI. These values are configurable by the cnfpnctlvc command.
4.
The database stores the backplane serial number and backcard serial numbers. Therefore if cards are moved from one node to other, console will display "SHM Alert!! Alert!!." In this situation follow the steps below:
a.
enter "shmFailDisplay." Display table will show that BRAM is not native.
b.
enter "shmFailRecoveryHelp". This will indicate that to "Ignore Nativity and Rebuild from Disk" the command to use is "shmRecoverIgRblDisk".
c.
enter "shmRecoverIgRbldDisk".
5.
Do not execute the "delcontroller" CLI when connections/ports still exists. The impact of executing delcontroller with connections is that the connections can not be recovered until the controller is readded via addcontroller and the AXSM cards or the entire node has to be reset (otherwise ports remain in provisioning state). There is now a warning to the user of the impact of the command when there are existing connections/ports.
6.
Currently, Humvee error reporting is turned off for the AXSM cards. They are however logged.
7.
Analysis of the code has identified a situation which has a low probability of occurring and in fast has not been encountered in any test scenarios to date. This caution and associated workaround is provided as a precautionary measure. When the link bandwidth for SPVC connections is reaching full capacity, thus minimal bandwidth is available for new SPVC connections, there is a condition which can be encountered where, the initial software check believes there is sufficient bandwidth for the new SPVC connection; however, the final software confirmation for available bandwidth may be rejected because there is no bandwidth available. If this problem occurs, the system will recover when the PNNI updates are refreshed. (This will happen at the default time of 30 minutes.) The user can recover from this problem by making the Administrative weight of that link very high to avoid that link from being used.
8.
To replace one type of AXSM front card with other type, it is required to delete all connections, partitions, ports and down lines. In case of AXSM card failure, same type of AXSM card must be installed in that slot.
9.
If a user has upgraded already to 2.0.11 and then decides to fall back to 2.0.10 he/she should run the following command on the active PXM after falling back to 2.0.10 - gShmRebuildFlagSet(2).
Limitations
1.
If the destination address is reachable for both a IISp and a PNNI link from the same node, ABR connections will not route. The current routing algorithm will always choose IISP links over PNNI links because it is local. Since IISP does not support ABR connections, the connection setup will fail.
2.
SCT can be changed with connections present in this release. However, if service affecting the connections will be rerouted.
3.
Connection statistics at CLI and Bucket level is not available in AXSM-1-2488 cards. However, connection debug statistics are available in all types of cards.
4.
When CWM is connecting to the network, the IP address 10.0.x.x cannot be used for MGX-8850 PXM45 as lnPci address.
5.
For users who would like to add MPLS controller in release 2.1, it is highly recommended to set the min-vci value to be 35 or more for all partitions on the port where the MPLS partition will be added. By doing so, the TDP sig vc for MPLS will be automatically established on 0/32.
6.
For users who would like to add MPLS partition on a port where other partitions has already been added and have set the min-vci value to be 32, then the users has two options:
a.
After the MPLS controller is added, explicitly add the TDP sig vc using a vpi/vci pair within its partition's resource range.
b.
Do a dnport and cnfpart to move the min-vci to 35 for all partitions on the port.
7.
If 50 users (the maximum is 50) is added and the pxm card is reset, the card does not come back up.
8.
Changing or reseating the backcard several times on the AXSM may sometimes cause the front card to reset and cause loss of service. The PhyTask also gets suspended. To avoid this problem, try not to reseat the backcard too often. If the front card gets stuck during the power-on, try to reseat the front and back card to bring the system.
Recommendations:
•
It is recommended to apply the default values for PCR, SCR, etc. to the Control VC. If the values are decreased to a low value, there is a chance that the Control VC (SSCOP or PNNI) will not come up. Note, you must use the SCT files released with 2.0.11 (number 2 and 3) for the Control VC feature.
Compatibility Notes
Compatibility Matrix
MGX 2.0.11 interoperates with CWM 10.3.
MGX 2.0.11 operates with MGX 1.1.31 as a feeder. Please see 1.1.31 release notes for bugs related to the feeder features.
MGX 2.0.11 operates with Cisco View 5.1x (package 3.3x).
Release 2.0.11 System Content
Switch Software and Boot Codes
The following four images are applicable to the 2.0.11 release:
•
Boot Images
–
axsm_002.000.010.000_bt.fw
–
pxm45_002.000.011.001_bt.fw
Runtime Images
–
axsm_002.000.011.003.fw
–
pxm45_002.000.011.003_mgx.fw
Hardware Products
Support hardware for Release 2.0.11:
Known Anomalies
The following is the list of known anomalies in this MGX 8850 software delivery. Included with each is a brief discussion of the problem. A more in depth discussion is available in the release note enclosure of the problem record in Bug Navigator.
