1.1.35 Version Software Release Notes Cisco WAN MGX 8850, 8230, and 8250 Software


About These Release Notes

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.

Note that for Release 1.1.35, the product documents (Command Reference, Overview, and Installation and Configuration Guides) were not updated. Use the Release 1.1.3 documents in addition to the 1.1.35 Version Software Release Notes Cisco WAN MGX 8850, 8230, and 8250 Software.

Product documentation for MGX 8850 is at:

http://cisco.com/univercd/cc/td/doc/product/wanbu/mgx8850/1_1_31/index.htm

Product documentation for MGX 8230 is at: http://cisco.com/univercd/cc/td/doc/product/wanbu/mgx8230/1_1_31/index.htm

Product documentation for MGX 8250 is at:

http://cisco.com/univercd/cc/td/doc/product/wanbu/mgx8250/1_1_31/index.htm

If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar, select Documentation, and click Enter the feedback form. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.

Features Introduced in Release 1.1.35

None. This is a maintenance release including all features supported up to release 1.1.34.

Features Introduced in Release 1.1.34

Release 1.1.34 is a feature release. The following Reliability, Availability, and Serviceability (RAS) features are available for the MGX 8850, MGX 8250, and MGX 8230 with Release 1.1.34.

Features that require 1.1.34 and above
Feature
Availability
IOS
CWM

Online Diagnostics on PXM

Release 1.1.34

12.2(2)T2

10.4.01 patch 1

Power on self test (POST) for PXM

Release 1.1.34

12.2(2)T2

10.4.01 patch 1

Enhanced ATM-LMI

Release 1.1.34

12.2(2)T2

10.4.01 patch 1

Buffer allocation priority

Release 1.1.34

12.2(2)T2

10.4.01 patch 1

VISM 2.1(0) support

Release 1.1.34

--

--


Online Diagnostics

The online diagnostics feature provides you with the tools to proactively monitor the hardware and software components on the PXM. While diagnostics usually focuses solely on hardware, equally critical software resources can impact network availability. The online diagnostics feature provides support in critical software areas and allows you to:

Run non-destructive tests on some of the hardware and software components on the PXM.

Execute tests periodically in the background on either the Active and Standby PXM, with a minimum time interval of 1 minute.

Choose from a series of available, configurable diagnostic tests, that can be used as part of online diagnostics

Configure start times, iterations and in some cases parameters, for each test.

View test results from various interfaces (CLI, CWM). Tests will generate logs, card alarms, and traps.

Table 1 lists the commands used to configure, run, and display the online diagnostics. More information about each command, along with examples of the command, are found in the sections that follow the table.

Table 1 Online Diagnostics Commands

New Command
Description
See

adddiagtest

Adds a test as part of the online diagnostics.

adddiagtest

cnfdiagparams

Configures diagnostic test parameters.

cnfdiagparams

deldiagtest

Deletes a test configured as part of online diagnostics.

deldiagtest

cnfdiagtest

Modifies the parameters of a diagnostic test.

cnfdiagtest

dspdiagresults

Displays the results of the configured tests.

dspdiagresults

dspdiagtests

Displays the configured tests and their parameters.

dspdiagtests

showdiagtests

Displays the list of available tests

showdiagtests

rundiagtest

Executes individual diagnostics tests.

rundiagtest

clralldiagtests

Deletes all diagnostics tests currently configured.

clralldiagtests

clrdiagresults

Clears diagnostics test results.

clrdiagresults

pausediag

Temporarily stops the diagnostics test.

pausediag/resumediag

resumediag

Resume a diagnostics test that was paused.

pausediag/resumediag


adddiagtest

Description

Adds a test as part of the online diagnostics on ASC.

Syntax

adddiagtest <testNumber> <testState>

Parameter
Description

<testNumber>

A test number, 1-15. Use the command showdiagtests to display a list of tests and their corresponding numbers. Run showdiagtests <testNumber> to see a description of the test.

1-BRAM Checksum (software)

2-Hard Disk Access (hardware)

3-Framer Access (hardware)

4-CBC Access (hardware)

5-QE Access (hardware)

6-RCMP Access (hardware)

7-Ethernet Test (hardware)

8-SRM M13 Access (hardware)

9-DRAM Memory Availability (software)

10-SAR Buffer Availability (software)

11-CPU Performance Monitor (software)

12-Trap Frequency Monitor (software)

13-QE ASIC Error Counter Monitor (hardware)

14-CBC ASIC Monitor (hardware)

15-CBC Path Test (hardware)

<testState>

Card state in which to execute the command.

1-active PXM

2-standby PXM

3-active and standby PXM


Example

PXM.a > adddiagtest 1 3
Test Number 1 ? "BRAM Checksum" added to Online Diagnostics
Use Unique Test ID 16 to refer to this test

cnfdiagtest

Description

Modifies the parameters of a diagnostic test that is configured as part of online diagnostics.

Syntax

cnfdiagtest <Unique Test ID> <startTime> <period> <iterations>

Parameter
Description

<Unique Test ID>

An ID value obtained from the command dspdiagtests.

<startTime>

Specify the test start time in the format HH:MM, or specify "Now" to execute the test immediately.

<period>

Frequency with which the test needs to be executed. The minimum time period that can be configured is 1 minute. The range is 1-1439.Period in minutes

<iterations>

Number of times the test should be repeated. When the value is specified as -1, the test will continue to execute.


Example

PXM.a > cnfdiagtest   10   NOW   15     -1
PXM.a >
Test added to start executing immediately, every 15 minutes, forever.
cnfdiagtest (Contd..)
Sample Output 2
PXM.a > cnfdiagtest   5   12:00   1440    -1
PXM.a >

cnfdiagparams

Description

Modifies test input parameters of a test added as part of online diagnostics

Syntax

cnfdiagparams <Unique Test ID> <param1> <param2>

Parameter
Description

<Unique Test ID>

An ID value obtained from the command dspdiagtests.

<param1>

First parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>.

<param2>

Second parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>. If the second parameter is not entered, the value will be zero.


Example

PXM.a > cnfdiagparams 10 10 0
PXM.a >

dspdiagtests

Description

Displays the configured tests and their parameters.

Syntax

dspdiagtests

Output Field
Description

ID

A test number, 1-15.

Test Name

One of the following tests:

BRAM Checksum

Hard Disk Access

Framer Access

CBC Access

QE Access

RCMP Access

Ethernet Test

SRM M13 Access

DRAM Memory Availability

SAR Buffer Availability

CPU Performance Monitor

Trap Frequency Monitor

QE ASIC Error Counter Monitor

CBC ASIC Monitor

CBC Path Test

State

Card state in which test is executed. Values are, Active, Standby, or Act/Stb (active and standby).

Start Time

Specify the test start time in the format HH:MM, or specify "Now" to execute the test immediately.

Period

Frequency with which the test needs to be executed. The minimum time period that can be configured is 1 minute. The range is 1-1439.Period in minutes

Iteratns

Number of times the test should be repeated. When the value is specified as -1, the test will continue to execute.

Param1

First parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>.

Param2

Second parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>. If the second parameter is not entered, the value will be zero.


Example

	PXM.a > dspdiagtests

	ID Test Name                         State    Start Time      Period     Iteratns    Param1      Param2
	--  -------------------------------  -------  --------------- ---------  ----------  ----------- -----------
	1   BRAM Checksum                    Act/Stb  FOREVER         1          FOREVER     N/A         N/A
	2   Trap Frequency Monitor           Active   FOREVER         1          FOREVER     50          N/A
	3   Hard Disk Access                 Standby  FOREVER         1          FOREVER     N/A        N/A
	4   Framer Access                    Act/Stb  FOREVER         1          FOREVER     N/A        N/A

	Online Diagnostics : RUNNING

	PXM.a >

dspdiagresults

Description

Display the results of the configured tests.

Syntax

dspdiagresults

Output Field
Description

ID

A test number, 1-15.

Test Name

Name of the test.

Result

Status of the test; whether it has passed or failed.

Pass Count

Number of times the test has passed.

Fail Count

Number of times the test has failed.


Example

PXM.a > dspdiagresults

	ID Test Name                          Result       Pass Count          Fail Count
	-- -------------------------------    ---------    ---------------     --------------
	1  BRAM Checksum                      PASS         5603                0
	2  Trap Frequency Monitor             FAIL         5602                1
	3  Hard Disk Access                   PASS         5603                0
	4  Framer Access                      PASS         5603                0
	PXM.a >

clrdiagresults

Description

Clears the results of all the configured tests. To confirm that the results have been cleared, you can run the command dspdiagresults.

Syntax

clrdiagresults

Example

	PXM.a > dspdiagresults

	ID Test Name                          Result       Pass Count         Fail Count
	-- -------------------------------    ---------    ---------------    --------------
	1  BRAM Checksum                      PASS         5603               0
	2  Trap Frequency Monitor             FAIL         5602               1
	3  Hard Disk Access                   PASS         5603               0
	4  Framer Access                      PASS         5603               0

	PXM.a  >clrdiagresults

	PXM.a > dspdiagresults
	ID Test Name                          Result       Pass Count         Fail Count
	-- -------------------------------    ---------    ---------------    --------------
	1  BRAM Checksum                      N/A          0                  0
	2  Trap Frequency Monitor             N/A          0                  0
	3  Hard Disk Access                   N/A          0                  0
	4  Framer Access                      N/A          0                  0

	PXM.a >

showdiagtests

Description

Displays the list of available tests when executed without the optional parameter. When the optional parameter Test Number is used, displays the meaning of the test, as well as test parameter options.

Syntax

showdiagtests [<Test Number>]

Parameter
Description

Test Number

A test number, 1-15.


Example 1

	PXM.a > showdiagtests
Test Number             Test Name
------------------      ---------
1                       BRAM Checksum
2                       Hard Disk Access
3                       Framer Access
4                       CBC Access
5                       QE Access
6                       RCMP Access
7                       Ethernet Test
8                       SRM M13 Access
9                       DRAM Memory Availability
10                      SAR Buffer Availability
11                      CPU Performance Monitor
12                      Trap Frequency Monitor
13                      QE ASIC Error Counter Monitor
14                      CBC ASIC Monitor
15                      CBC Path Test
	XM.a  >

Example 2

	PXM.a > showdiagtests 12
	Function : Monitors the Trap Frequency
			An Alarm is reported if Trap Frequency cross the threshold.
	Input Parameter : Threshold : (0 > = 0) Th4reshold for permissible
			trap numbers to be sent per second.

Example 3

	PXM.a > showdiagtests 1
	Function : Performs BRAM Checksum Test
	Input Parameter : None.
	PXM.a >

deldiagtest

Description

Removes a test from being executed in the background.

Syntax

deldiagtest <Unique Test ID>

Parameter
Description

Unique Test Id

A test number, 1-15.


Example

	PXM.a > deldiagtest 1
	PXM.a >

rundiagtest

Description

Executes an individual diagnostics test.

Syntax

rundiagtest <Test Number> <param1> <param2>

Output Field
Description

Test Number

A test number, 1-15.

Param1

First parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>.

Param2

Second parameter for the diagnostics test. The meaning of this parameter differs for different tests. To find the meaning of the parameter, use the command showdiagtests <testNumber>. If the second parameter is not entered, the value will be zero.


Example

	PXM.a > rundiagtest 10 10 0
	SAR Buffer Availability    PASSED
	PXM.a >

pausediag/resumediag

Description

The pausediag command temporarily pauses diagnostic test execution. After running this command, you can execute the dspdiagtests command; "online diagnostics" at the bottom of the display will indicate PAUSED.

Run the resumediag command to remove the pause and resume the diagnostics test.

Syntax

pausediag

Example

	PXM.a > pausediag
	Online Diagnostic Tests are Paused
	PXM.a > dspdiagtests

	ID Test Name                         State        Start Time      Period     Iteratns    Param1       Param2
-- -------------------------------   -------      --------------- ---------  ----------  -----------
-----------
	1   BRAM Checksum            Act/Stb      FOREVER         1          FOREVER     N/A          N/A
	2   Trap Frequency Monitor   Active       FOREVER         1          FOREVER     50           N/A
	3   Hard Disk Access         Standby      FOREVER         1          FOREVER     N/A          N/A
	4   Framer Access            Act/Stb      FOREVER         1          FOREVER     N/A          N/A

	Online Diagnostics : PAUSED
	PXM.a > resumediag

clralldiagtests

Description

Deletes all tests from online diagnostics that are currently configured. Confirmation of this command can be seen by running the dspdiagtests command, which will show "No tests configured to run online."

Syntax

clralldiagtests

Example

	PXM.a > clralldiagtests
	Cleared all Online Diagnostic tests
	PXM.a > dspdiagtests
	Online Diagnostics : No tests configured to run online
	PXM.a >

Diagnostics Failure Reporting

The following examples show the log and card output. Both examples show the alarms generated by failed diagnostics test.

Example 1 log output

PXM.a > dsplog
	05/29/2001-16:19:56 08 tOnlnDiag  ONLI-7-ONLNDIAG_CARDIN
  	Card in alarm: Online Diag Test SAR Buffer Availability Unique ID: 1 Failed
	05/29/2001-16:19:56 08 tOnlnDiag  ONLI-7-ONLNDIAG_TEST_F
  	Online Diag Test SAR Buffer Availability Unique ID: 1 Failed
	05/29/2001-16:19:56 08 tOnlnDiag  ONLI-7-ONLNDIAG_TEST_F       Online Diag test Failed.
	SAR Buffer Availability Unique ID: 1 Pool: 0. PctAvlSarBuf = 99, Threshold = 100

Example 2 card output

PXM.a > dspcd
ModuleSlotNumber:                    8
FunctionModuleState:                 Active
FunctionModuleType:                  PXM1-T3E3
FunctionModuleSerialNum:             SBK042500A3
FunctionModuleHWRev:                 A0
FunctionModuleFWRev:                 1.1.34l
FunctionModuleResetReason:           Upgrade Reset
LineModuleType:                      PXM-UI
LineModuleState:                     Present
SecondaryLineModuleType:             LM-BNC-2T3
SecondaryLineModuleState:            Present
mibVersionNumber:                    0.0.22
configChangeTypeBitMap:              No changes
cardIntegratedAlarm:                 Minor
cardMajorAlarmBitMap:                Clear
cardMinorAlarmBitMap:                Online Diags Failure on slot 8
BkCardSerialNum:                     SBK043601D1
TrunkBkCardSerialNum:                SBK0310007T
FrontCardPCBNumber:                  800-05760-02
TrunkBkCardPCBNumber:                800-04057-02

Power On Self Test (POST) on PXM

The Power On Self Tests (POST) on the PXM are destructive tests executed on key components, and are used to detect component failure. The PXM Boot code executes the POST tests, and therefore, are executed on every reset.

Because some components cannot be turned on during the bootup, POST is limited to testing the components that are on during the bootup phase.

POST Failure is reported through the CLI, log messages, card alarms, and traps.

POST Tests on PXM include:

BRAM Checksum test

QE RAM test

CBC RAM test

Ethernet Register test

PCI_IDE Register test

Clock Mux test

Framer Access test

RCMP RAM test

Example 1 PXM boot capture

z16c30DevInit.Done
POST: BRAM checksum...PASSED
POST: QE ram...PASSED
POST: CBC ram...PASSED
POST: Ethernet reg...PASSE
POST: PCI-IDE reg...PASSED
sysHwInit2
z16c30DevInit2
POST: Clock mux...PASSED
POST: Framer access...PASSED
POST: RCMP ram...PASSED
Copied POST results to 0x80001000, 704 bytes
Initializing the disk driver ...

......................................

Example 2 dsppostresults and dspcd commands

Use the command dsppostresults on Active and Standby PXM to determine the POST results for the respective PXM cards.

8.PXM.s > dsppostresults
Test Description                         Result     Detail Description
----------------                         ------     ------------------
BRAM checksum                            PASS
QE ram                                   PASS
CBC ram                                  PASS
Ethernet reg                             PASS
PCI-IDE reg                              PASS
Clock mux                                PASS
Framer access                            PASS
RCMP ram                                 PASS

Use the command dspcd to display the card alarms. Notice the alarm Post Failure on slot 8.

PXM.a > dspcd
ModuleSlotNumber:                    8
FunctionModuleState:                 Active
FunctionModuleType:                  PXM1-T3E3
FunctionModuleSerialNum:             SBK042500A3
FunctionModuleHWRev:                 A0
FunctionModuleFWRev:                 1.1.34l
FunctionModuleResetReason:           Upgrade Reset
LineModuleType:                      PXM-UI
LineModuleState:                     Present
SecondaryLineModuleType:             LM-BNC-2T3
SecondaryLineModuleState:            Present
mibVersionNumber:                    0.0.22
configChangeTypeBitMap:              No changes
cardIntegratedAlarm:                 Minor
cardMajorAlarmBitMap:                Clear
cardMinorAlarmBitMap:                POST Failure on slot 8
BkCardSerialNum:                     SBK043601D1
TrunkBkCardSerialNum:                SBK0310007T
FrontCardPCBNumber:                  800-05760-02
TrunkBkCardPCBNumber:                800-04057-02

Enhanced ATM-LMI

Enhanced ATM-LMI is designed to protect data traffic in the case of a ATM-LMI failure. ATM-LMI is an important protocol used between a feeder and a switch; for example, the MGX 8230 used as a feeder and connected to a BPX 8600. Motivation. Any failure of this protocol fails all the PVCs on the node; therefore, this protocol should be highly reliable and fail only for genuine reasons.

When a ATM-LMI protocol failure occurs, and enhanced ATM-LMI is enabled, the data continuity will be checked before conditioning the PVC's into alarm.

In order for the feature to provide full coverage, the similar feature must exist in the version of software running on the BPX 8600 or other ATM switch. Also, it depends on the presence of data traffic.

Use the commands cnfenhlmi and dspenhlmi to configure and display Enhanced ATM-LMI.

Syntax

cnfenhlmi <slot.port> <EnhLmiEnable> <dataContRetry>

Parameters
Description

<slot.port>

A slot number 1-32; a port number 1-256.

<EnhLmiEnable>

Enable or disable enhanced ATM-LMI feature; enter Yes or No. The default is No; disabled.

<dataContRetry>

The data continuity retry in seconds. The range is 1-600 seconds. The recommended retry is 5 secs.


Example

PXM.a > cnfenhlmi 7 1 Yes 5
PXM.a > dspenhlmi
TRK     ENHANCED LMI ENABLED    CNF RETRY
-----------------------------------------
7.1      No         0
PXM.a >

Buffer Allocation Priority

SAR buffers are shared by all applications on the PXM. If a low priority application operates inefficiently and overutilizes SAR buffers, it impacts higher priority and more critical applications by forcing them to operate without adequate buffers. Such conditions impact it impact network availability.

The buffer allocation priority feature distinguishes SAR buffer allocation between high priority and low priority applications. This directly supports ATM-LMI and SCM polling, both of which are considered high priority applications.

The feature is available once a successful upgrade to Release 1.1.34 is completed, and cannot be enabled or disabled.

VISM 2.1(0) on MGX 8250/8850/8230

VISM 2.1(0) is supported on MGX 8250, MGX 8230, and MGX 8850 switches for Release 1.1.34. For VISM upgrade instructions see the Release Notes for Cisco Voice Interworking Service Module Release 2.1(0).

This section describes the VoIP, ATM Adaptation Layer 2 (AAL2), and general features introduced for the VISM 2.1(0) release.

VoIP Features

The following VoIP features are included in VISM Release 2.1(0):

Verified MGCP 0.1 protocol compliance.

PBX CAS event delivery to a Call Agent using MGCP 0.1:

DTMF: Wink and ground start.

MF: Wink.

RFC 3064 CAS packages: BL, MS, DT.

TFTP download of CAS variant state machine.

Interoperability enhancements:

Configurable codec strings (IANA naming conventions as well as customized ones).

Codec negotiation with configurable preference order.

Exponential backoff for:

XGCP retry timers.

SRCP retry timers.

Configurable per CAS variant.

DTMF Relay using Cisco-rtp (FRF-11 Annex A based).

Enhancement to Fax/modem up-speed/pass-through procedures:

Configurable CAC failure and carrier loss policies.

Up-speed to clear channel.

Added support for G.726: 16, 24, 32, and 40 kbps, with packetization periods ranging from 10 to 40 msec.

Support for VBR-rt (Variable Bit Rate-Real Time) and VBR-nrt (nonreal time) ATM traffic classes, including traffic shaping to the relevant traffic descriptors.

Configurable VAD model parameter for traffic engineering.

In E1 applications, support for 31 DS0 per span and a total of 248 channels per card.

Tested CRTP support through RPM for voice and voice band data calls.

Verified bearer interoperability with 3810.

AAL2 Features

The following AAL2 features are included in VISM Release 2.1(0):

Switched PVCs using SGCP 1.5

SDP and SGCP extensions allowing xGCP Call Agent control of AAL2 bearers.

Support of SGCP 1.5 digit maps and error codes.

Support for card level coexistence of switched AAL2 mode (under Call Agent control) and trunked AAL2 mode on PVCs, on an endpoint (DS0) basis.

PBX CAS event delivery to a Call Agent using SGCP 1.5:

DTMF: Wink and ground start.

MF: Wink.

TFTP download of CAS variant state machine.

Interoperability and configurability enhancements:

Configurable codec strings (IANA naming conventions as well as customized ones).

Profile negotiation and configurable preference order.

Configurable voice and VBD (i.e., up-speed codec) per profile.

Exponential backoff for:

XGCP retry timers.

SRCP retry timers.

Configurable per CAS variant.

Added support for custom profile 110 and 200 (clear channel), ITU profiles 3 and 8.

User-configurable AAL2 Silence Indicator Description (SID) for all profiles.

Type 3 Packet Support for proxy ringback (xrbk), packet side bearer continuity check (co3/co4 COT), and midcall DTMF relay.

Enhancement to Fax/modem up-speed/pass-through procedures:

Configurable CAC failure and carrier loss policies.

Up-speed to clear channel.

Supports VBR-rt (Variable Bit Rate-Real Time) and VBR-nrt (nonreal time) ATM traffic classes, including traffic shaping to the relevant traffic descriptors.

Connection admission control (CAC) enhancements:

Patented CAC method factoring in VAD and subcell multiplexing savings.

Configurable VAD model parameter for traffic engineering.

Configurable AAL2 cell fill timer.

AAL2 alarm enhancements: per span, VC, and per channel (CID) conditioning.

Display, clear, and reset AAL2 performance related counters.

In E1 AAL2 trunking applications, support for 31 DS0 per span and a total of 248 channels per card.

Verified bearer interoperability with 3810 and third-party vendors.

General Features

The following general features are included in VISM Release 2.1(0):

Infrastructure work and enhanced support for three operating modes: VoIP switching, AAL2 trunking, and Switched AAL2 PVC.

Graceful upgrade VISM 2.0 and 2.0(1) to VISM 2.1(0).

About the 1.1.32 Release

This is a maintenance release including all features supported up to release 1.1.25.

Features Introduced in Release 1.1.32

RPM features that require 1.1.32 bundled with IOS 12.1(5.3)T_XT
Feature
Availability
IOS
CWM

Support for Multiple RPM Card Types

Release 1.1.32

12.1(5.3)T_XT

10.4.01

Support for RPM-PR module for MGX-PXM1

Release 1.1.32*

12.1(5.3)T_XT

10.4.01

Support for RPM/B in MGX 8230

Release 1.1.32

12.1(5.3)T_XT

10.4.01

*Support for RPM-PR was FCS with Release 1.1.32, and General Availability with Release 1.1.34.


Feature Descriptions


Note Please refer to the "Route Processor Module (RPM) Addendum" section for additional information and special instructions on the installation of RPM modules with Release 1.1.32.


Support for Multiple RPM Card Types

When multiple RPM card types are present in the network, the PXM1 will recognize and display the correct RPM card type. The current RPM card types are RPM/B and RPM-PR. The MGX 1.1.32 Release contains PXM code base changes that recognize the multiple RPM card types.

Support for RPM-PR Module with MGX-PXM1

The RPM-PR provides the following features:

More than twice the forwarding performance of the RPM/B.

Supports up to 512 Mbytes SDRAM.

Provides integrated ATM SAR with OC-6 cell bus rates to the PXM1.

Flash memory increased to 32M.

The higher-performance RPM requires Software Release 1.1.32, IOS version12.1(5.3)T_XT, and a minimum CWM version of 10.4.01.

Support for RPM/B in MGX 8230

Installation of the RPM/B in the MGX 8230 requires Release 1.1.32 and IOS version 12.1(5.3)T_XT

.


Note Customers planning to use RPM/B in the MGX 8230 should upgrade to MGX Software Release 1.1.32 and CWM 10.4.01.
Features Introduced in Release 1.1.31


The following features are available for the MGX 8850, MGX 8250, and MGX 8230 with Release 1.1.31 and IOS 12.1(3)T:

Features that require 1.1.31 bundled with IOS 12.1(3)T
Feature
Availability

CoS Map for FRSM-8

Release 1.1.31

DS3 Loopback on PXM-T3

Release 1.1.31

ForeSight and Standard ABR Coexistence Guidelines

Release 1.1.31

Independent Service Rate on FRSM-HS1/B

Release 1.1.31

Online Diagnostics for PXM

Release 1.1.31

SRM in MGX 8230

Release 1.1.31

Standard ABR on AUSM

Release 1.1.31

Standard ABR on FRSM-8 and FRSM8-C Modules

Release 1.1.31

Stratum-3 Clocking

Field Trial Only with Release 1.1.31. Support is not available in Release 1.1.34.

VBR-rt on AUSM

Release 1.1.31

VISM 1.5.05 on MGX 8250/8850

Release 1.1.31

VISM 2.0.0 on MGX 8230/8250/8850

Release 1.1.31


Feature Descriptions in Releaes 1.1.31

For descriptions of the features introduced in Release 1.1.31, see the following sections:

CoS Map for FRSM-8.

DS3 Loopback on PXM-T3.

Stratum-3 Clocking

ForeSight and Standard ABR Coexistence Guidelines.

Independent Service Rate on FRSM-HS1/B.

Online Diagnostics for PXM.

SRM in MGX 8230.

Standard ABR on AUSM.

Standard ABR on FRSM-8 and FRSM8-C Modules.

VBR-rt on AUSM.

VISM 1.5.05 on MGX 8250/8850.

Features Introduced in Release 1.1.25.

CoS Map for FRSM-8

This feature implements the ATM Class of Service (CoS) on the FRSM-8 Module. This feature maps the connection with ATM Class of Service parameters to the appropriate queue in the ingress side of the FRSM-8 and PXM.

Previous versions do not support any CoS type of connections; only ForeSight and non-ForeSight type connections are supported. By mapping the CoS parameters, the connections can then be scheduled in the appropriate queue on the PXM.

The following service types are added to the existing service types: UBR, VBR, VBR-RT, VBR-nRT, and STD-ABR. The current limit on connection count is to be retained as far as possible. This feature is supported by CWM 10.3 (which is not targeted for General Availability).

DS3 Loopback on PXM-T3

This feature enables the active PXM to initiate the DS3 loopback code (program the T3 framers to generate the sequence of 16 bit FEAC codes, or Far End Alarm and Control codes). The main functions are:

Send alarm or status information from the far-end terminal back to the near-end terminal.

Initiate DS3 loopbacks at the far-end terminal from the near-end terminal.

The active PXM will initiate this code, which will also run on the standby PXM. This feature has CLI support and is supported by CWM 10.3 (which is not targeted for General Availability).

Stratum-3 Clocking

Standard clocking in the MGX is supported with a built-in Stratum-4 clock source. For network applications that require a higher clock accuracy, the PXM-UI back card used with the Stratum-4 can be replaced with an optional PXM-UI-S3 back card that carries a Stratum-3 clock. This clock reference conforms to AT&T T1.5 and ITU G.824 specifications. A provision is also made for a Service Provider to connect an external clock source, if necessary.

Both holdover and fail-over modes are supported by the PXM-UI-S3. That is, if all clock sources fail, the Stratum-3 clock will hold the last best-known clocking frequency.

The default clock is the internal Stratum-4. Pertinent CLI and MIB support are provided for Stratum-3 configuration. The PXM-UI-S3 back card is also recognized by the Cisco WAN Manager.

Hardware Changes

A new PXM-UI-S3 back card replaces existing PXM-UI-B cards.

The new PXM-UI-S3 supports both T1 and E1 interfaces through an RJ-45/48 connector.

CLI

A new CLI cnfclklevel permits the user to set the STRATUM level desired.

Default Settings

The default clock source is set to be the Internal Oscillator. Subsequently, an External/Inband/SM clock can be configured to be the primary/secondary clock driving the node.

Limitations

There are two physical ports on the PXM-UI-S3 back card for providing External clock. However, only "Ext Clk 1" is currently supported. There are 2 physical LAN ports on the PXM-UI-S3 back card. However, only "LAN port 1" is currently supported.


Warning If an External clock was configured to drive the node in Stratum-4 clocking with the old UI back card, and this UI card is replaced with the new PXM-UI-S3 back card, the Stratum-3 clocking must be explicitly configured on the node to continue using the External clock source. The following CLI's must be executed:

* cnfclklevel 3

* cnfextclk (with T1/E1 option)


ForeSight and Standard ABR Coexistence Guidelines

With Release 1.1.31, both ABR TM4.0 and ForeSight congestion control are supported on the FRSM and AUSM modules. This document contains the following:

Description of the major differences between the TM 4.0-compliant standard ABR and ForeSight ABR.

Guidelines for coexistence of ForeSight with standard ABR connections on the same network.

Example configuration of the two different connection types to have similar characteristics.

Independent Service Rate on FRSM-HS1/B

This feature provides the capability to configure a connection service rate in the ingress direction. Users can also specify EIR if connection is "0" of CIR. This feature is already implemented in FRSM-8 and FRSM-VHS.

This functionality is the same as that provided in FRSM-8 and FRSM-VHS. This feature is not supported by CWM 10.3 (which is not targeted for General Availability).

Online Diagnostics for PXM

This feature provides hardware tests to check the health of the SRM and PXM modules (both active and standby). This test is non-intrusive and operates with minimum overhead while the shelf is running. Connections, states and tasks are not affected.

The Online Diagnostics are optional tests operated through CLI and SNMP interfaces. The test is invoked from the active PXM. If a standby PXM exists and is in standby state, it also will be tested. When the test is executed, each component is checked and the results are presented on the screen. The results of the diagnostics are written to a log file so they can be viewed and analyzed offline.

Initially, intelligence is not provided, but built-in intelligence may be considered as a future enhancement. The hardware and software components selected for running the diagnostics will be selected from field experience. The targets are hard disk and memory components. Although the intent is to check the health of the hardware, a switchover should not occur except under severe circumstances.

SRM in MGX 8230

This feature provides SRM support in the MGX 8230. Only the newest version of the SRM, MGX-SRM-3T3/C, is supported in the 8230 chassis. This feature is not supported by CWM 10.3 (which is not targeted for General Availability), but is planned for a future release.

Standard ABR on AUSM

This feature involves implementing the standards-based TM 4.0 ABR congestion control loop. The current AUSM-8 card only supports ForeSight, which is pre-standards-based. Standard ABR is required on AUSM cards in order for them to interoperate with third-party devices that support standard ABR and AXSM cards.

Support for standard ABR calls for implementing the RM cells to perform the flow control. All three modes are considered: EFCI, ER, and RR. Only modes that can be supported on the existing hardware are implemented. In addition, all appropriate behaviors are implemented. These behaviors include Source, Destination, and Switch. Connections with the standard ABR parameter are mapped to the appropriate queue. This feature includes new CLI and MIB support. Also expected for the CWM support is the appropriate formula. Due to current hardware limitation, VS/VD is not considered. This feature is supported by CWM 10.3 (which is not targeted for General Availability).

Standard ABR on FRSM-8 and FRSM8-C Modules

The feature implements TM 4.0 ABR service on the FRSM card. The current FRSM supports ForeSight, a pre-standard version of congestion control. This feature provides standards-compliant ABR congestion mechanism in addition to ForeSight. The module will generate RM cells to dynamically increase or decrease bandwidth rate. This includes all applicable modes of behavior: Source, Destination, and Switch. Only relevant modes need be considered. Connections with the standard ABR parameter will be mapped to the appropriate queues and will co-exist with ForeSight connection types.

This feature is implemented via appropriate MIBS and CLI. This feature is supported by CWM 10.3 (which is not targeted for General Availability). ABR license (similar to ForeSight license) is created and is a billable feature. One common license is available for either ForeSight or standard ABR on FRSM. Standard ABR fulfils the standards-compliance part of TM 4.0.

VBR-rt on AUSM

This feature involves implementing the standard Class of Service on the AUSM-8 Module. VBR-rT CoS is required for video and real time voice applications. In terms of conformance definition it is same as VBR-nRT, which is already supported. The connection parameters will be bounded by Peak Cell rate (PCR), Sustainable Cell Rate (SCR) and Maximum Burst Size (MBS). Cell Delay Variation Tolerance (CDVT) will be parameter to characterize the PCR.

This new CoS requires scheduling the appropriate queue in both the ingress and egress direction. It has lower priority than CBR but higher than VBR-nRT.

Appropriate CLI commands to configure the parameters are implemented. This feature is supported by CWM 10.3 (which is not targeted for General Availability).

VISM 2.0.0 on MGX 8230/8250/8850

VISM 2.0.0 supports all of the VISM 1.5.05 features listed above. VISM 2.0.0 is supported on MGX 8230/8250/8850. CWM 10.3 (which is not targeted for General Availability) supports VISM 2.0.0. VISM is not targeted for General Availability.

PRI Backhaul to the Softswitch Using RUDP

The PRI backhaul capability provides PRI termination on the VISM with the Softswitch providing call control. ISDN Layer 2 is terminated on the VISM and the layer 3 messages are transported to the Softswitch using RUDP.

Latency Reduction (<60 ms round-trip)

Significant improvements have been made to bring the round-trip delay to less than 60 ms.

Codecs Preference

VISM provides the capability to have the codecs negotiated between the two end-points of the call. The VISM can be configured, for a given end-point, to have a prioritized list of codecs. Codec negotiation could be directly between the end-points or could be controlled by a Softswitch

31 DS0 for E1 with 240 Channels Only

While all 31 DS0s on a E1 port can be used, there is a limitation of 240 channels per card.

VISM 1.5.05 on MGX 8250/8850

VISM 1.5.05 is supported on MGX 8250/8850. For VISM on MGX 8230, please use VISM 2.0.0 listed below. CWM 10.3 (which is not targeted for General Availability) supports VISM 1.5.05. VISM is not targeted for General Availability.

VoIP using RTP (RFC 1889)

VISMR1.5 supports standards-based VoIP using RTP (RFC1889) and RTCP protocols. This allows VISM to interwork with other VoIP Gateways.

VoAAL2 (With sub-cell multiplexing) PVC

The VISM supports standards-compliant AAL2 adaptation for the transport of voice over an ATM infrastructure. AAL2 trunking mode is supported.

Codec Support

G.711 PCM (A-law, Mu-law), G.726, G.729a/b

8 T1/E1 Interfaces

The VISM supports 8 T1 or 8 E1 interfaces when G.711 PCM coding is used. For higher complexity coders such as G.726-32K and G.729a-8K, the density drops to 6 T1 or 5 E1 interfaces (max 145 channels).

1:N redundancy using SRM.

T3 Interfaces (via SRM Bulk Distribution)

T3 interfaces are supported using the SRM's bulk distribution capability. In this case, the T3 interfaces are physically terminated at the SRM module. The SRM module breaks out the individual T1s and distributes the T1s via the TDM backplane bus to the individual VISM cards for processing.

Echo Cancellation

The VISM provides on-board echo cancellation on a per-connection basis. Up to 128 msec. user-configurable near-end delay can be canceled. The echo cancellation is compliant with ITU G.165 and G.168 specifications.

Voice Activity Detection (VAD)

VISM uses VAD to distinguish between silence and voice on an active connection. VAD reduces the bandwidth requirements of a voice connection by not generating traffic during periods of silence in an active voice connection. At the far-end, comfort noise is generated.

Fax/Modem Detection for ECAN and VAD Control

The VISM continually monitors and detects fax and modem carrier tones. When carrier tone from a fax or modem is detected, the connection is upgraded to full PCM to ensure transparent connectivity. Fax and modem tone detection ensures compatibility with all voice-grade data connections.

CAS Tunneling via AAL2 (For AAL2 Trunking Mode)

The VISM in AAL2 mode facilitates transport of CAS signaling information. CAS signaling information is carried transparently across the AAL2 connection using type 3 packets. In this mode, VISM does not interpret any of the signaling information.

PRI Tunneling via AAL5 (For AAL2 Trunking Mode)

VISM supports transport of D-ch signaling information over an AAL5 VC. The signaling channel is transparently carried over the AAL5 VC and delivered to the far-end. In this mode, VISM does not interpret any of the signaling messages.

Voice CAC

VISM can be configured to administer Connection Admission Control (CAC) so that the bandwidth distribution between voice and data can be controlled in AAL2 mode.

Type 3 Packet for DTMF

The VISM in AAL2 mode facilitates transport of DTMF signaling information. DTMF information is carried transparently across the AAL2 connection using type 3 packets.

Dual (Redundant) PVCs for Bearer/Control

The VISM provides the capability to configure two PVCs for bearer/signaling traffic terminating on two external routers (dual-homing). VISM continually monitors the status of the active PVC by using OAM loopback cells. Upon detection of failure, the traffic is automatically switched over to the backup PVC.

64 K Clear Channel Transport

The VISM supports 64 Kbps clear channel support. In this mode, all codecs are disabled and the data is transparently transported through the VISM.

DTMF Relay for G.729

In VoIP mode, DTMF signaling information is transported across the connection using RTP NSE (Named Signaling Event) packets

MGCP 0.1 for VoIP with Softswitch Control

VISM supports Media Gateway Control Protocol (MGCP) Version 0.1. This open protocol allows any Softswitch to interwork with the VISM module.

Resource Coordination via SRCP

Simple Resource Control Protocol (SRCP) provides a heartbeat mechanism between the VISM and the Softswitch. In addition, SRCP also provides the Softswitch with gateway auditing capabilities.

Full COT Functions

VISM provides the capability to initiate continuity test as well as provide loopbacks to facilitate continuity tests when originated from the far-end.

Courtesy Down

This feature provides a mechanism for graceful upgrades. By enabling this feature, no new calls are allowed on the VISM while not disrupting the existing calls. Eventually, when there are no more active calls, the card is ready for a upgrade and/or service interruption.

Features Introduced in Release 1.1.25

None.

Features Introduced in Release 1.1.24

While no new features are incorporated into Software Release 1.1.24, this software release does provide support to two new wide area switches, the MGX 8230 and the MGX 8250, as well as continued support for the MGX 8850 switch.

MGX 8230

The MGX 8230 functions as a feeder to the IGX, BPX, or MGX 8850 switches, or can be used for bringing in service. It has a seven slot (double-height) chassis, and the slots are oriented in the following manner:

Two slots are reserved for PXMs.

Two single-height (which equals one double-height) slots are reserved for SRM.

The remaining slots can be configured with four double-height or eight single-height slots, supporting service modules.

Figure 1 shows the MGX 8230 with its door attached. Note that there are light pipes in the door that display the status of the processor models (PXMs). Figure 2 is a conceptual drawing of an MGX 8230 showing the dimensions and the slot numbering. The slot numbering is as it appears from the front of the MGX 8230; slots 8 and 9 refer to back card slots only.

Note that the following features are not supported in 1.2xx baseline:

Service Resource Module (SRM)

Route processor module (RPM)

Voice Interface Service Module (VISM)

PNNI (some CLI commands may show options for PNNI, but this feature is not supported)


Note In Release 1.1.31 and later, SRM, RPM, and VISM are all supported.


Figure 1 MGX 8230 with Door Attached

Figure 2 MGX 8230 Dimensions


Note Even though the card slots in an MGX 8230 are horizontal and would more appropriately be called single-width and double-width, this manual still refers to the card slots, and the processor and service modules, as single-height and double-height. This is for consistency because the PXM and service module cards are a subset of the MGX 8850 cards that are installed vertically in an MGX 8850 chassis.


Main Features

Release 1.0 of MGX 8230 includes:

PXM1 with 4-port OC3-C/STM-1.

MMF, SMFLR, and SMFIR back cards are supported.

PXM1 ports are used as ATN UNI or feeder trunks.

Core redundancy for PXM1.

Environmental monitoring.

PXM-1 with one OC-12 port.

PXM1-2-T3E3 provides interfaces for up to two T3 (each at 44.736 Mbps) or two E3 lines (each at 34.368 Mbps).

ATM, Frame Relay, and Circuit Emulation service modules.

AUSM-8T1/E1/B with RJ48-T1/E1 and SMB E1 back card with UNI and IMA support.

FRSM-8T1/E1 with RJ48-T1/E1 and SMB E1 back cards.

FRSM-2T3E3 with BNC-2T3/E3 back cards.

FRSM-HS2 with 2-port HSSI back card.

FRSM-2CT3 with BNC-2T3 back card.

CESM-8T1/E1 with RJ48-T1/E1 and SMB E1 back cards.

CESM-T3E3

1:1 redundancy for T3/E3 cards.

1:N redundancy for T1/E1 service modules.

Graceful upgrade.

1000 connections per card, 4000 connections per shelf (T1 service modules).

The MGX 8230 backplane supports a minimum of 1.2 Gbps of non-blocking switching and has a high-end limit of 21 Gbps with the PXM1. Individual line rates can range from DS0 through OC-3.

The MGX 8230 can also support a wide range of services over narrowband and mid-band user interfaces. It maps all the service traffic to and from ATM circuits based on standardized interworking methods.

The MGX 8230 supports up to 64 channelized or non-channelized T1 and E1 interfaces on a single IP + TM multiservice gateway. These interfaces support:

Frame Relay UNI and NNI

ATM UNI, NNI, and FUNI

Frame Relay-to-ATM network interworking

Frame Relay-to-ATM service interworking

Circuit emulation services

Frame-based services on T3 and E3 high-speed lines are also supported.

The MGX 8230 also supports Inverse Multiplexing for ATM (IMA) to provide ATM connectivity below T3 or E3 rates via the AUSM-8T1/E1 (AUSM/B).

The modular, software-based system architecture enables it to support new features through downloadable software upgrades or new hardware modules.

The Service Resource Module-3T3 (MGX-SRM-3T3/B), when supported in a future release, will be able to support up to 64 T1 interfaces over its three T2 lines and provide 1:N redundancy for the T1 and E1 cards. This feature is described in the MGX 8230 switch documentation, but is currently not supported by the hardware.

Standards-Based Conversion to ATM

The MGX 8230 converts all user-information into 53-byte ATM cells by using the appropriate ATM Adaptation Layer (AAL) for transport over the ATM backbone network. The individual service modules segment and reassemble (SAR) cells to eliminate system bottlenecks. The following list shows the applicable AAL for each service:

Circuit emulation services uses AAL1.

Frame Relay-to-ATM network interworking uses AAL5 and Frame Relay Service Specific Convergence Sub-layer (FR-SSCS).

Frame Relay-to-ATM service interworking uses both transparent and translation modes to map Frame Relay to native ATM AAL5.

Frame forwarding uses AAL5.

Refer to the Cisco MGX 8230 Installation and Configuration Guide for further installation and physical descriptions for the MGX 8230 switch.

MGX 8230 Cards

MGX 8230 Processor Switch Module (PXM1)

The MGX 8230 Processor Switch Module (PXM1) performs shelf control and shared-memory switching functions. It also serves as a data processing and ATM interface card. The PXM1 processor module for the MGX 8230 is identical to the PXM1 for the MGX 8250.

Primarily, the MGX 8230 PXM1 controls the switch and provides 1.2 Gbps of non-blocking, shared memory ATM switching and ATM trunking up to OC-12 speed. In addition, the PXM features:

A 4.0-Gigabyte hard disk drive that holds software, firmware for all the cards, and a substantial amount of other information.

Environmental monitoring (cabinet temperature, fan speed, and power supply voltages).

Hot swappable, 1:1 redundancy.

The PXM1 and its two types of back cards make up the required control card set. The following are model numbers of cards supported by the MGX 8230 for this release:

The following are model numbers of cards supported by the MGX 8230 for this release:

PXM1-4-155, PXM1-1-622, and PXM1-2-T3E3

PXM-UI (user interface back card)

MGX-MMF-4-155 (uplink back card)

MGX-SMFIR-4-155 (uplink back card)

MGX-SMFLR-4-155 (uplink back card)

MGX-BNC-2-T3 (uplink back card)

MGX-BNC-2-E3 (uplink back card)

MGX-SMFIR-2R-1-622 (uplink back card)

MGX-SMFLR-1-622 (uplink back card)

PXM1 User Interface Back Card

The PXM1 User Interface card (PXM-UI) provides the MGX 8230 with the several user- interface ports. It mates with an PXM1 through the backplane and is installed in a back card slot (slot 8 or 9). As seen from the back of the MGX 8230, the PXM-UI will plug into the slot that is on the right side of its corresponding PXM1. The user-interface ports provide the following functions:

User and management interface to an ASCII terminal or workstation

Network synchronization for the shelf

Central office-compatible major/minor alarm interface

The PXM UI has the following physical connectors and interfaces:

RJ-45 T1 clock input—BITS clock source

RJ-45 Maintenance port—RJ-45 connector, EIA/TIA 232, DTE mode, asynchronous interface, 19200 bits per second, 1 start bit, 1 stop bit, no parity bits.

RJ-45 Control port— EIA/TIA 232, DTE mode, asynchronous interface, 9600 bits per second, 1 start, 1 stop, no parity.

RJ-45 LAN port—10BaseT, 802.3 Ethernet

SMB connector E1 clock input—BITS clock source

DB-15 female connector for alarm outputs

MGX 8230 OC-3 Uplink Back Card

The MGX 8230 Uplink back card, which mates with a corresponding PXM1 through the backplane, provides the feeder trunk to the MGX switch. This uplink back card can provide either a multi-mode or single-mode fiber OC-3 interface:

MGX-MMF-4-155 (multi-mode fiber uplink back card)

MGX-SMFIR-4-155 (single-mode fiber intermediate reach uplink back card)

MGX-SMFLR-4-155 (single-mode fiber long reach uplink back card)

FRSM Cards

The primary function of the FRSM is to convert between the Frame Relay-formatted data and ATM/AAL5 cell-formatted data. It converts the header format and translates the address for Frame Relay port/DLCIs, ATM-Frame UNI (FUNI) port/frame address, or frame forwarding port, and the ATM virtual connection identifiers (VPI/VCIs).

The MGX 8230 supports the following FRSM models:

Frame Service Module for T1 (FRSM-8T1)
The FRSM-8T1 card provides interfaces for up to eight T1 lines, each of which can support one
56 Kbps or one Nx64 Kbps FR-UNI, FR-NNI port, ATM-FUNI, or a frame forwarding port.
Note that this unchannelized card cannot be configured to support sub-T rates.

Frame Service Module for T1, channelized (FRSM-8T1-C)
The FRSM-8T1-C card provides interfaces for up to eight T1 lines, each of which can support up to twenty-four 56 Kbps or Nx64 Kbps FR-UNI, FR-NNI, ATM-FUNI, or frame forwarding ports.

Frame Service Module for E1 (FRSM-8E1)
The FRSM-8E1 card provides interfaces for up to eight E1 lines, each of which can support one
56 Kbps or one Nx64 Kbps FR-UNI, FR-NNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for E1, channelized (FRSM-8E1-C)
The FRSM-8E1-C card provides interfaces for up to eight E1 channelized Frame Relay lines, each of which can support multiple (up to thirty-one) 56 Kbps or Nx64 Kbps FR-UNI, FR-NNI, ATM-FUNI, or frame forwarding ports.

Frame Service Module for T3 and E3 (FRSM-2E3T3)
The FRSM-2E3/T3 card provides interfaces for up to two T3 or E3 Frame Relay lines, each of which can support either two T3 lines (each at 44.736 Mbps) or two E3 lines (each at 34.368 Mbps) FR-UNI, FR-NNI, ATM-FUNI, or frame forwarding ports.

Frame Service Module for channelized T3 (FRSM-2CT3)
The FRSM-2CT3 card supports interfaces for up to two T3 channelized Fame Relay lines, each of which supports 56 Kbps, 64 Kbps, Nx56 Kbps, Nx64 Kbps, T1 ports for a total of 256 ports that can be freely distributed across the two T3 lines.

FRSM-HS2
The FRSM-HS2 provides unchannelized Frame Relay service for up to 1000 user-connections over two HSSI lines on the SCSI2-2HSSI back card. The maximum rate for the card is 104 Mbps. Each port can operate in either DTE or DCE mode with incremental rates of N x T1 or N x E1 up to
52 Mbps.

OC-12 Uplink Back Card

For Automatic Protection Switching (APS) requires the "B" model—an SMFLR-1-622/B.

SMFIR-1-622 Back Card

For Automatic Protection Switching (APS) requires the "B" model—an SMFIR-1-622/B.

BNC-2T3 Back Card

BNC-2E3 Back Card

Two versions of the BNC-2E3 card are available. The BNC-2E3A applies to Australia only, and the BNC-2E3 applies to all other sites that require E3 lines on the PXM uplink card.

ATM Universal Service Module

AUSM/B Front Card

AUSM/B Back Cards

The MGX-AUSM/B-8T1 and MGX-AUSM/B-8E1 use the generic 8-port T1 or E1 line modules that operate with the 8-port service modules. The standard T1 version of the back card has eight RJ-48 connectors. The standard versions of the E1 back card have either eight RJ-48 connectors or eight pairs of SMB connectors. The following back cards are compatible with the AUSM/B:

RJ48-8T1 back card for T1

RJ48-8E1 back card for E1

SMB-8E1 back card for E1

Circuit Emulation Service Module 8T1E1

CESM Models

The MGX 8230 supports the following CESM models:

Circuit Emulation Service Module for T1 (CESM-8T1)
The CESM-8T1 card provides interfaces for up to eight T1 lines, each of which is a 1.544 Mbps structured or unstructured synchronous data stream.

Circuit Emulation Service Module for E1 (CESM-8E1)
The CESM-8E1 card provides interfaces for up to eight E1 lines, each of which is a 2.048 Mbps structured or unstructured synchronous data stream.

Circuit Emulation Service Module for T3/E3 (CESM-T3E3)

The CESM-8T1E1 card set consists of the CESM-8T1E1 front card and one of the following back cards:

RJ48-8T1-LM

RJ48-8E1-LM

SMB-8E1-LM

Redundancy Architecture

Since the MGX 8230 chassis is a smaller form factor MGX 8850, most of the redundancy features available in MGX 8850 are available in MGX 8230 chassis. The following is a list of available redundancy features on the MGX 8230 chassis.

Dual PXM

Y-cable redundancy on PXM uplink ports

1:N redundancy for T1/E1 service modules

Eight cell buses per PXM

N+1 cooling fan redundancy

N+1 AC or DC power redundancy (optional)

1:1 Y-cable redundancy for T3/E3 interfaces

MGX 8230 Management

To give you access for control purposes, the MGX 8230 switch supports high- and low-level user interfaces. You can use the Cisco WAN Manager application (formerly StrataView Plus) for connection management, the CiscoView application for hardware configuration, and a command line interface for low-level control of hardware functionality and connection control. An assortment of ports and protocols supports these user-interfaces. For communicating with the MGX 8230 switch, the control port (SLIP protocol only), the LAN (Ethernet) port, and the in-band ATM connection (feeder application only) all support access by the command line interface (CLI) via Telnet, TFTP, and SNMP protocols.

The downloadable firmware on each card determines the functionality, and you can upgrade functionality by downloading new firmware through a TFTP application on a workstation or a PC.

The current status and configuration parameters of the MGX 8230 modules reside in a Management Information Base (MIB). The firmware on each card updates the MIB as changes in status and configuration occur.

MGX 8250

The Cisco MGX 8250 wide-area edge switch supports:

Integrated IP+ATM services

Frame Relay

IP-based virtual private network

Video

Circuit emulation services for private line replacement

It does not support PNNI, despite the fact that some CLI commands may show options for PNNI.

This chapter contains a brief outline of the features of the Cisco MGX 8250 switch. An illustration of the AC-powered version of the switch appears in Figure 3.

Figure 3 MGX 8250 Switch

The Applications of the MGX 8250 Switch

The MGX 8250 switch operates in two operational applications:

As a feeder, the MGX 8250 switch concentrates narrow-band and medium-band ATM, Frame Relay, and voice into a single, wide-band ATM feeder trunk to an BPX 8600 series switch.

As a stand-alone node, the MGX 8250 switch concentrates narrow-band and medium-band ATM, Frame Relay, and voice into a single ATM line to at third-party switch. The MGX 8250 interface in this application is a UNI or an NNI.

For a description of how to configure the switches for a particular application, see the MGX 8250 Switch Installation and Configuration Guide.

The switch is also capable of supporting Cisco Multiprotocol Label Switching (MPLS).

Universal Edge Architecture

The MGX 8250 switch can support a wide range of services over narrowband and mid-band user interfaces. It maps all the service traffic to and from ATM by using standardized interworking methods.

The supported interfaces for user-traffic are:

Frame Relay UNI on T3, E3, HSSI, T1, and E1 lines

ATM UNI and FUNI and optional inverse multiplexing for ATM (IMA)

Frame Relay to ATM network interworking and service interworking

Circuit emulation services (T1/E1 and T3/E3)

The optional Service Resource Module-3T3 (MGX-SRM-3T3/B) can support up to 80 T1 interfaces over its three T3 lines and provide 1:N redundancy for the T1 and E1 cards.

The modular, software-based system architecture enables the switch to support new features through downloadable software upgrades or new hardware modules.

The MGX 8250 backplane supports a minimum of 1.2 Gbps of non-blocking switching. Individual line rates range from DS0 through OC-12.

Standards-Based Conversion to ATM

The MGX 8250 switch converts all user information into 53-byte ATM cells by using the appropriate ATM Adaptation Layer (AAL) for transport over the ATM backbone network. The individual service modules segment and reassemble (SAR) cells to eliminate system bottlenecks. The following list shows the applicable AAL for each service:

Circuit emulation services uses AAL1.

Frame Relay-to-ATM network interworking uses AAL5 and Frame Relay Service Specific Convergence Sub-layer (FR-SSCS).

Frame Relay-to-ATM service interworking uses both transparent and translation modes to map Frame Relay to native ATM AAL5.

Frame forwarding uses AAL5.

MGX 8250 Cards

The MGX 8250 switch supports core cards and service modules. The Processor Switching Module (PXM) and optional Service Resource Module (SRM) are core cards. In addition to the PXM being a core card, it is also part of a a card set. A card set consists of a front card, a back card, and a daughter card. Service modules are not combined in this manner and are never part of a card set. Instead, service modules provide the interface to the transport technologies of the CPE—Frame Relay, ATM, and so on. The MGX 8250 enclosure contains up to 24 service modules (I/O cards) and 4 optional Service Redundancy Modules (SRMs) provide redundancy. A card set consists of a front card with its attached daughter card and a back card (or line module). The front card contains the processing intelligence and, on the daughter card, the firmware that distinguishes the interface (OC-3, T3, E3, and so on). The back card is a simple card that provides the electrical interface for one or more lines of a particular type. The MGX 8250 front and back cards are the:

Processor Switching Module (PXM1)
This front card controls the switch and supports external interfaces for user-access and trunking or UNI ports. The back cards consist of a user interface card (PXM-UI) and a broadband network module (see subsequent list items).

Processor Switch Module User Interface (PXM1-UI)
The PXM1-UI is the user interface card that has various types of ports to let you access and control the switch.

Broadband Network Module (MGX-SMFIR-1-622 and MGX-SMFLR-1-622)
The SMFIR-1-622 is a broadband network module for the PXM and provides a SONET OC12/STM4 ATM interface at 622 Mbps.

Broadband Network Module (MGX-MMF-4-155)
The MMF-4-155 is a broadband network module for the PXM and provides four SONET OC3/STM1 ATM interfaces at 155 Mbps.

Broadband Network Module (MGX-BNC-2T3)
The MGX-BNC-2T3 is a broadband network module for the PXM and provides two T3 ATM interfaces.

Broadband Network Module (MGX-BNC-2E3)
The MGX-BNC-2E3 is a broadband network module for the PXM and provides two E3 ATM interfaces. A version for Australia, New Zealand, and elsewhere is available (MGX-BNC-2E3A).

Frame Service Module for T3 and E3 (MGX-FRSM-2E3T3)
The MGX-FRSM-2E3/T3 provides interfaces for up to two T3 or E3 Frame Relay lines, each of which can support either two T3 lines (each at 44.736 Mbps) or two E3 lines (each at 34.368Mbps) FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for channelized T3 (MGX-FRSM-2CT3)
The MGX-FRSM-2CT3 supports interfaces for up to two T3 channelized Frame Relay lines, each of which supports 56 Kbps, 64 Kbps, Nx56 Kbps, Nx64 Kbps, T1 ports for a total of 256 ports that can be freely distributed across the two T3 lines.

Frame Service Module for unchannelized HSSI (MGX-HS2/B)
The MGX-HS2/B supports interfaces for 2 unchannelized HSSI lines, each of which supports approximately 51 Mbps. With both lines operating, maximum throughput is 70 Mbps.

Frame Service Module for T1 (AX-FRSM-8T1)
The AX-FRSM-8T1 provides interfaces for up to eight T1 lines, each of which can support one
56 Kbps or one Nx64 Kbps FR-UNI, ATM-FUNI, or a frame forwarding port. Note that this unchannelized card cannot be configured to support sub-T rates.

Frame Service Module for T1, channelized (AX-FRSM-8T1c)
The AX-FRSM-8T1c provides interfaces for up to eight T1 lines, each of which can support up to 24 56 Kbps or N x 64 Kbps FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for E1 (AX-FRSM-8E1)
The AX-FRSM-8E1 provides interfaces for up to eight E1 lines, each of which can support one
56 Kbps or one N x 64 Kbps FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for E1, channelized (AX-FRSM-8E1c)
The AX-FRSM-8E1c provides interfaces for up to 8 E1 channelized Frame Relay lines Each line can support N x 64-Kbps or (up to 31) 56-Kbps FR-UNI, ATM-FUNI, or frame forwarding ports.

ATM UNI Service Module for T1 (MGX-AUSM/B-8T1)
The MGX-AUSM/B-8T1 provides interfaces for up to eight T1 lines. You can group N x T1 lines to form a single, logical interface (IMA).

ATM UNI Service Module for E1 (MGX-AUSM/B-8E1)
The MGX-AUSM/B-8E1 provides interfaces for up to eight E1 lines. You can group N x E1 lines to form a single, logical interface (IMA).

Circuit Emulation Service Module for T1 (AX-CESM-8T1)
The AX-CESM-8T1 provides interfaces for up to eight T1 lines, each of which is a 1.544 Mbps structured or unstructured synchronous data stream.

Circuit Emulation Service Module for E1 (AX-CESM-8E1)
The AX-CESM-8E1 provides interfaces for up to eight E1 lines, each of which is a 2.048 Mbps structured or unstructured synchronous data stream.

Route Processor Module (RPM)
The RPM is a Cisco 7200 series router redesigned as a double-height card. Each RPM uses two single-height back cards. The back-card types are single-port Fast Ethernet, four-port Ethernet, and single-port (FDDI).

Service Resource Module (MGX-SRM-3T3/B)
The optional MGX-SRM-3T3/B provides bit error rate testing (BERT), 1:N redundancy for T1 and E1 service modules, and a demultiplexing function for T1 service called bulk mode.

Smart Serial Interface FRSM-HS1/B 12IN1
A multipersonality back card that supports either X.21 or V.35 interface.

MGX 8250 Management

To give you access for control purposes, the MGX 8250 switch supports high- and low-level user interfaces. You can use the Cisco WAN Manager application (formerly StrataView Plus) for connection management, the CiscoView application for hardware configuration, and a command line interface for low-level control of hardware functionality and connection control. An assortment of ports and protocols supports these user-interfaces. For communicating with the MGX 8250 switch, the control port (SLIP protocol only), the LAN (Ethernet) port, and the in-band ATM connection (feeder application only) all support access by the command line interface (CLI) via Telnet, TFTP, and SNMP protocols.

The downloadable firmware on each card determines the functionality, and you can upgrade functionality by downloading new firmware through a TFTP application on a workstation or a PC.

The current status and configuration parameters of the MGX 8250 modules reside in a Management Information Base (MIB). The firmware on each card updates the MIB as changes in status and configuration occur.

Continued Support for the MGX 8850

The Cisco MGX 8850 wide area edge switch supports:

Integrated IP+ATM services

Frame Relay

IP-based virtual private network

Video

Circuit emulation services for private line replacement

It does not support PNNI, despite the fact that some CLI commands may show options for PNNI.

An illustration of the AC-powered version of the switch appears in Figure 4.

Figure 4 MGX 8850 Switch

The Applications of the MGX 8850 Switch

The MGX 8850 switch operates in two operational applications:

As a feeder, the MGX 8850 switch concentrates narrow-band and medium-band ATM, Frame Relay, and voice into a single, wide-band ATM feeder trunk to an BPX 8600 series switch.

As a stand-alone node, the MGX 8850 switch concentrates narrow-band and medium-band ATM, Frame Relay, and voice into a single ATM line to at third-party switch. The MGX 8850 interface in this application is a UNI or an NNI.

For a description of how to configure the switches for a particular application, see the MGX 8250 Switch Installation and Configuration Guide.

The switch is also capable of supporting Cisco Multiprotocol Label Switching (MPLS).

Universal Edge Architecture

The MGX 8850 switch can support a wide range of services over narrowband and mid-band user interfaces. It maps all the service traffic to and from ATM by using standardized interworking methods. When the MGX 8850 switch operates as a feeder, it uses a single port to communicate the aggregated traffic over an ATM interface with an MGX 8850 or BPX 8600 series switch.

The supported interfaces for user-traffic are:

Frame Relay UNI on T3, E3, HSSI, T1, and E1 lines

ATM UNI and FUNI and optional inverse multiplexing for ATM (IMA)

Frame Relay to ATM network interworking and service interworking

Circuit emulation services

The optional Service Resource Module-3T3 (MGX-SRM-3T3/B) can support up to 80 T1 interfaces over its 3 T3 lines and provide 1:N redundancy for the T1 and E1 cards.

The modular, software-based system architecture enables the switch to support new features through downloadable software upgrades or new hardware modules.

The MGX 8850 backplane supports a minimum of 1.2 Gbps of non-blocking switching up to
45 Gbps. Individual line rates range from DS0 through OC-12.

Standards-Based Conversion to ATM

The MGX 8850 switch converts all user-information into 53-byte ATM cells by using the appropriate ATM Adaptation Layer (AAL) for transport over the ATM backbone network. The individual service modules segment and reassemble (SAR) cells to eliminate system bottlenecks. The following list shows the applicable AAL for each service:

Circuit emulation services uses AAL1.

Frame Relay-to-ATM network interworking uses AAL5 and Frame Relay Service Specific Convergence Sub-layer (FR-SSCS).

Frame Relay-to-ATM service interworking uses both transparent and translation modes to map Frame Relay to native ATM AAL5.

Frame forwarding uses AAL5.

MGX 8850 Cards

The MGX 8850 switch supports two types of card sets: the core cards (or core modules) and service modules. The Processor Switching Module (PXM) and optional Service Resource Module (SRM) are core cards. The service modules provide the interface to the transport technologies of the CPE—Frame Relay, ATM, and so on. The MGX 8850 enclosure contains up to 24 service modules (I/O cards) and 4 optional Service Redundancy Modules (SRMs) provide redundancy. A card set consists of a front card with its attached daughter card and a back card (or line module). The front card contains the processing intelligence and, on the daughter card, the firmware that distinguishes the interface (OC-3, T3, E3, and so on). The back card is a simple card that provides the electrical interface for one or more lines of a particular type. The MGX 8850 front and back cards are the:

Processor Switching Module (PXM1)
This front card controls the switch and supports external interfaces for user-access and trunking or UNI ports. The back cards consist of a user interface card (PXM-UI) and a broadband network module (see subsequent list items).

Processor Switch Module User Interface (PXM1-UI)
The PXM1-UI is the user interface card that has various types of ports to let you access and control the switch.

Broadband Network Module (MGX-SMFIR-1-622 and MGX-SMFLR-1-622)
The SMFIR-1-622 is a broadband network module for the PXM and provides a SONET OC12/STM4 ATM interface at 622 Mbps.

Broadband Network Module (MGX-MMF-4-155)
The MMF-4-155 is a broadband network module for the PXM and provides four SONET OC3/STM1 ATM interfaces at 155 Mbps.

Broadband Network Module (MGX-BNC-2T3)
The MGX-BNC-2T3 is a broadband network module for the PXM and provides two T3 ATM interfaces.

Broadband Network Module (MGX-BNC-2E3)
The MGX-BNC-2E3 is a broadband network module for the PXM and provides two E3 ATM interfaces. A version for Australia, New Zealand, and elsewhere is available (MGX-BNC-2E3A).

Frame Service Module for T3 and E3 (MGX-FRSM-2E3T3)
The MGX-FRSM-2E3/T3 provides interfaces for up to two T3 or E3 Frame Relay lines, each of which can support either two T3 lines (each at 44.736 Mbps) or two E3 lines (each at 34.368Mbps) FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for channelized T3 (MGX-FRSM-2CT3)
The MGX-FRSM-2CT3 supports interfaces for up to two T3 channelized Frame Relay lines, each of which supports 56 Kbps, 64 Kbps, Nx56 Kbps, Nx64 Kbps, T1 ports for a total of 256 ports that can be freely distributed across the two T3 lines.

Frame Service Module for unchannelized HSSI (MGX-HS2/B)
The MGX-HS2/B supports interfaces for two unchannelized HSSI lines, each of which supports approximately 51 Mbps. With both lines operating, maximum throughput is 70 Mbps.

Frame Service Module for T1 (AX-FRSM-8T1)
The AX-FRSM-8T1 provides interfaces for up to eight T1 lines, each of which can support one
56 Kbps or one Nx64 Kbps FR-UNI, ATM-FUNI, or a frame forwarding port.

Frame Service Module for T1, channelized (AX-FRSM-8T1c)
The AX-FRSM-8T1c provides interfaces for up to eight T1 lines, each of which can support up to 24 56 Kbps or N x 64 Kbps FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for E1 (AX-FRSM-8E1)
The AX-FRSM-8E1 provides interfaces for up to eight E1 lines, each of which can support one
56 Kbps or one N x 64 Kbps FR-UNI, ATM-FUNI, or frame forwarding port.

Frame Service Module for E1, channelized (AX-FRSM-8E1c)
The AX-FRSM-8E1c provides interfaces for up to eight E1 channelized Frame Relay lines Each line can support N x 64-Kbps or (up to 31) 56-Kbps FR-UNI, ATM-FUNI, or frame forwarding ports.

ATM UNI Service Module for T1 (MGX-AUSM/B-8T1)
The MGX-AUSM/B-8T1 provides interfaces for up to eight T1 lines. You can group N x T1 lines to form a single, logical interface (IMA).

ATM UNI Service Module for E1 (MGX-AUSM/B-8E1)
The MGX-AUSM/B-8E1 provides interfaces for up to eight E1 lines. You can group N x E1 lines to form a single, logical interface (IMA).

Circuit Emulation Service Module for T1 (AX-CESM-8T1)
The AX-CESM-8T1 provides interfaces for up to eight T1 lines, each of which is a 1.544 Mbps structured or unstructured synchronous data stream.

Circuit Emulation Service Module for E1 (AX-CESM-8E1)
The AX-CESM-8E1 provides interfaces for up to eight E1 lines, each of which is a 2.048 Mbps structured or unstructured synchronous data stream.

Route Processor Module (RPM)
The RPM is a Cisco 7200 series router redesigned as a double-height card. Each RPM uses two single-height back cards. The back-card types are: single port Fast Ethernet, four port Ethernet, and single-port (FDDI).

Service Resource Module (MGX-SRM-3T3/B)
The optional MGX-SRM-3T3/B provides bit error rate testing (BERT), 1:N redundancy for T1 and E1 service modules, and a demultiplexing function for T1 service called bulk mode.

Smart Serial Interface FRSM-HS1/B 12IN1
A multi-personality back card that supports either X.21 or V.35 interface.

MGX 8850 Management

To give you access for control purposes, the MGX 8850 switch supports high- and low-level user interfaces. You can use the Cisco WAN Manager application (formerly StrataView Plus) for connection management, the CiscoView application for hardware configuration, and a command line interface for low-level control of hardware functionality and connection control. An assortment of ports and protocols supports these user-interfaces. For communicating with the MGX 8850 switch, the control port (SLIP protocol only), the LAN (Ethernet) port, and the in-band ATM connection (feeder application only) all support access by the command line interface (CLI) via Telnet, TFTP, and SNMP protocols.

The downloadable firmware on each card determines the functionality, and you can upgrade functionality by downloading new firmware through a TFTP application on a workstation or a PC.

The current status and configuration parameters of the MGX 8850 modules reside in a Management Information Base (MIB). The firmware on each card updates the MIB as changes in status and configuration occur.

Features Introduced in Release 1.1.23

MGX 8850 Release 1.1.23 is a maintenance release of Release 1.1.22. In addition, it introduces the following new features:

Dynamic subrate FRSM-T3E3.

Clrsmcnf/savesmcnf/restoresmcnf feature support for VISM.

Switchcc and Softswitch performance enhancement (See Problems Fixed).

New database integrity check commands.

Model # recognition for MGX 8230 and MGX 8250.

Release 1.1.32 MGX 8850, MGX 8230, and MGX 8250 Hardware

MGX 8850 is a 45 Gbps backplane with 1.2 Gbps switching fabric for Release 1.1.32. The same backplane is used with different switching fabric cards (1.2, 45 Gbps) to achieve scalability. MGX 8850 Release 1.1.21 hardware components and their revisions that are supported are as follows:

Front Card Model #
Rev #
Back Card Model #
Rev #

MGX 8850 Chassis

A



MGX 8230 Chassis

A



MGX 8250 Chassis

A



MGX-DC power supply

MGX-AC1 power supply

MGX-AC2-2 power supply

PS-1200-AC power supply

A

A

A

A



MGX-SRM-3T3/B

B

MGX-BNC-3T3-M

A

PXM1

H

PXM-UI

A

PXM 1-2-T3E3

H

PXM-UI

MGX-BNC-2E3

MGX-BNC-2E3A

MGX-BNC-2T3

A

A

A

A

PXM 1-4-155

J

PXM-UI

MGX-MMF-4-155

MGX-SMFIR-4-155

MGX-SMFLR-4-155

A

A

A

A

PXM 1-1-622

H

PXM-UI

MGX-SMFIR-1-622

MGX-SMFLR-1-622

A

A

A

MGX-RPM 64M/B

A

MGX-RJ45-FE

MGX-MMF-FE

MGX-RJ45-4E

MGX-MMF-FDDI

MGX-SMF-FDDI

MGX-MMF-FDDI/FD

MGX-SMF-FDDI/FD

A

A

A

A

A

A

A

MGX RPM-128M/B

A

MGX-RJ45-FE

MGX-MMF-FE

MGX-RJ45-4E

MGX-MMF-FDDI

MGX-SMF-FDDI

MGX-MMF-FDDI/FD

MGX-SMF-FDDI/FD

A

A

A

A

A

A

A

AX-CESM-8E1

B

AX-SMB-8E1

AX-RJ48-8E1

AX-R-SMB-8E1

AX-R-RJ48-8E1

B

C

B

B

AX-CESM-8T1

B

AX-RJ48-8T1

AX-R-RJ48-8T1

B

B

MGX-AUSM-8E1/B

A

AX-SMB-8E1

AX-RJ48-8E1

AX-R-SMB-8E1

AX-R-RJ48-8E1

B

C

B

B

MGX-AUSM-8T1/B

A

AX-RJ48-8T1

AX-R-RJ48-8T1

B

B

AX-FRSM-8E1

B

AX-SMB-8E1

AX-RJ48-8E1

AX-R-SMB-8E1

AX-R-RJ48-8E1

B

C

B

B

MGX-VISM-8T1

B

AX-RJ48-8T1

AX-R-RJ48-8T1

B

B

MGX-VISM-8E1

B

AX-SMB-8E1

AX-RJ48-8E1

AX-R-SMB-8E1

AX-R-RJ48-8E1

B

C

B

B

AX-FRSM-8E1-C

B

AX-SMB-8E1

AX-RJ48-8E1

AX-R-SMB-8E1

AX-R-RJ48-8E1

B

C

B

B

AX-FRSM-8T1

B

AX-RJ48-8T1

AX-R-RJ48-8T1

B

B

AX-FRSM-8T1-C

B

AX-RJ48-8T1

AX-R-RJ48-8T1

B

B

MGX-FRSM-HS2/B

B

MGX-SCSCI2-2HSSI/B

A

MGX-FRSM-2CT3

C

MGX-BNC-2T3

A

MGX-FRSM-2T3E3

C

MGX-BNC-2E3

MGX-BNC-2E3A

A

A

MGX-FRSM-HS1/B

A

MGX-12IN1-4S

A

MGX-CESM-T3E3

C

MGX-BNC-2T3

MGX-BNC-2E3

MGX-BNC-2E3A

A

A

A


Support for embedded Cisco IOS router (Router Processor Module - [RPM])

The RPM is an embedded Cisco IOS router with integrated ATM Deluxe Port Adapter and cell bus controller ASIC for internal connections to the backplane cell bus. A number of port adapters (back cards) can be configured with the RPM front card (FDDI, Ethernet, Fast Ethernet).

4E Adapter

FE Adapter (UTP, MMF)

FDDI Adapter (full duplex, half duplex, SMF, MMF)

MGX 8220 Hardware Not Supported on Release 1.1.32 of the MGX 8850

The following cards are not supported in Release 1.1.32:

AX-SRM-T1E1

AX-SMB-8E1

AX-R-SMD-8E1

AX-RJ48-8E1

AX-R-RJ48-8E1

MGX 8220 Hardware That Has Been Superseded on the MGX 8850 by MGX 8850-Specific Hardware

AX-SRM-3T3-A and AX-BNC-3T3 card set

The MGX-SRM-3T3-C front card replaces the original AX-SRM-3T3-A front card and the MGX-BNC-3T3 back card replaces the original AX-BNC-3T3 back card. This change allows the use of slots 9, 10, 25, and 26 for 1:N redundancy and BERT in the MGX 8850 chassis. Both the AX-SRM-3T3-A/AX-BNC-3T3 card set and the MGX-SRM-3T3-C/MGX-BNC-3T3 card set are supported on the MGX 8220.

New card should have enabled use of bulk distribution in slots 9 and 10. 1:N redundancy should have been supported in those slots with the model A card.

AX-SCSI2-2HSSI

Superseded by the MGX-SCSCI2-2HSSI/B, which works with the MGX-FRSM-HS2 front card. A V.35 interface is supported on the MGX-FRSM-HS1/B in this release.

AX-IMATM

Superseded by MGX-AUSM-8T1/B and MGX-AUSM-8E1/B.

AX-IMATM-B

Superseded by MGX-AUSM-8T1/B and MGX-AUSM-8E1/B.

MGX 8220 Hardware Not Supported on the MGX 8850

AX-FRASM-8T1

All four-port MGX 8220 cards

AX-AUSM-8T1

AX-AUSM-8E1

Software Platform Features

MGX 8850 provides high-speed native ATM interfaces, which can be configured as ATM UNI ports or trunks. Table 2 contains redundancy support information for service modules.

Table 2

Front Card Model #
Redundancy Supported

MGX-RPM-64M/B

No redundancy

MGX-RPM-128M/B

No redundancy

MGX-AUSM-8E1/B

1:N redundancy

MGX-AUSM-8T1/B

1:N redundancy

AX-CESM-8E1

1:N redundancy

AX-CESM-8T1

1:N redundancy

MGX-CESM-2T3E3

1:1 redundancy

AX-FRSM-8E1

1:N redundancy

AX-FRSM-8E1-C

1:N redundancy

AX-FRSM-8T1

1:N redundancy

AX-FRSM-8T1-C

1:N redundancy

MGX-FRSM-HS2

1:1 redundancy

MGX-FRSM-2CT3

1:1 redundancy

MGX-FRSM-2T3E3

1:1 redundancy

MGX-FRSM-HS1/B

No redundancy

MGX-T3E3

1:1 redundancy

MGX-VISM-8T1

1:N redundancy (bulk mode support for T1 lines only)

MGX-VISM-8E1

1:N redundancy (bulk mode support for T1 lines only)


Support for Bulk Distribution using SRM-3T3-C card.

Service module and PXM upgrades.

Features Not Supported in This Release

RPM 1:1 and 1:N redundancy

RPM statistics

S3 clocking

Layer 2 support as an AutoRoute routing node

SRM T1E1

IPX end-points with the MGX 8850

E1 users circuits

T1/CAS backhaul

Interworking with SGCP 1.1+ compliant call agent (Bellcore CA SM1.5)

Interworking with Cisco 3810

G.726 and G.729 voice compression

G729b voice activity detection

Voice Circuit Admission Control (CAC)

Bearer continuity testing

Ring back tone on Ground Start

Separate PVCs for signaling and bearer channels


Note Code for the above features may be included in the VISM code image. However, no specific mechanism has been included to prevent the use of these unsupported features. If the user attempts to use these unsupported features, there is no guarantee that the features will operate correctly.


Major Network Management Features

CWM Connection Management

CiscoView support for equipment management

CLI support

Service MIB support

Connection Management for connections to RPM with associated CM GUI support

Topology subsystem enhancements to support the MGX 8850 as a stand-alone switch

Statistics

For more details refer to the CWM Release 9.2.07 release notes part number 78-6659-07.

Connection Limits

Up to 4000 connections per VHS card, except for FRSM-HS2 and FRSM-2T3/E3, which support up to 2000 connections.

Up to 1000 connections per eight-port card (up to 898 per port with LMI enabled), except the CESM-8T1, which supports 192 connections, and the CESM-8E1, which supports 248 connections.

Up to 192 connections per HS1 card.

Up to 12000 connections per shelf.

SNMP MIB

The SNMP MGX Release 1 MIB are provided with the delivery of Release 1.1.35. The MIB is in standard ASN.1 format and is located in the same directory within the 1.1.35 bundle on CCO. These files may be compiled with most standards-based MIB compilers. For changes in this MIB from the previous release, please refer to the MIB release notes.

Their are two formats contained in the bundle:

old_mibFormat

new_mibFormat

The old_mibFormat is released and maintained for Legacy and backward compatibility. These files can be used by NMS, only if the NMS is not using any standard MIBs for DS1, DS3 and SONET.

The NMS should not be managing MGX Release 2 as that product uses the standard DS3, SONET and DS1 MIBs. This rule applies to any other Cisco or third-party product that supports these MIBs.

For those who are using both MGX Release 1 and MGX Release 2 in the same network and managing the two products by the same NMS, use the new_mibFormat.

Notes and Cautions

The following notes and cautions should be reviewed before using Release 1.1.35.

Stratum-3 Clocking

The PXM-UI-S3 back card used in previous releases to support Stratum-3 level clocking, is not supported in Release 1.1.35.

UPC Connection Parameters

In Release 1.1.35, the default UPC connection parameters on the PXM have changed. The default PCR is 50 cps, and the default for policing is "enabled." These settings are insufficient for running RPM ISIS protocol over the connection, and with such settings, the ISIS protocol will fail. The PCR value needs to be increased, depending upon the number of interfaces configured for ISIS on the RPM. CLI modification and changes in this release.

Depending upon your connection type, you can use the following CLIs to modify the PCR parameter.

cnfupccbr

cnfupcvbr

cnfupcabr

cnfupcubr

ForeSight and Standard ABR Coexistence Guidelines

ForeSight is similar to the rate-based ABR control system in TM 4.0 in that they both use Rate up and Rate down messages sent to the source of the connection to control the rate a connection runs at, based on congestion within the switches along that connections path. Both systems use Resource Management (RM) cells to pass these messages. There are differences between the two systems that need to be considered.

RM Cell Generation

ForeSight is a destination-driven congestion notification mechanism. The destination switch is responsible for generating the RM cells, which defaults to every 100 ms. This means that any rate modifications at the source end happen approximately every 100 ms, and the time delay between the actual congestion at the destination and the source getting to know about it could be 100 ms.

In standard ABR a source generates FRM cells every (nRM) cell intervals, where n is configurable. These are used to pass congestion information along to the destination switch, which then uses this information to generate BRM (Backward RM cells) back to the source A further consideration is that the actual user data flow will be lower for an equivalent rate due to the additional RM cells. Therefore, the more traffic being generated on a connection at any one time, the faster the feedback will be to the source.

There is also a TRM parameter which states that if no RM cells have been generated after this time has passed then one will automatically be sent. Depending upon the speed it is running at, an ABR connection may therefore react faster or slower to congestion than the equivalent ForeSight connection. (for example, if an ABR connection runs at 100 cells per second, and nRM is 32, then approximately three RM cells will be generated per second, or once every 300 msecs. If it runs at 1000 cps then an RM cell would be generated approximately every 30 msecs. In both cases, the equivalent ForeSight connection would generate an RM cell every 100 msec.)

Reaction to Feedback Messages - Rate Up

In ForeSight, in response to a Rate Up cell from the destination, the source increases its rate by a percentage of the MIR for that connection. If we call this percentage the rate increase percentage (RIP), then RIP is configurable at the card level (the default is 10 percent). In the case where MIR is low, the ForeSight rate increase will be slow as it has to increase as a percentage of MIR (rather than CIR).

On a standard ABR connection, in the event of available bandwidth (no congestion) the source increases its rate by a factor of (RIF*PCR). This means the rate increase step sizes are much bigger than for ForeSight for larger values of RIF (RIF has a range of 1/2, 1/4,....,1/32768). If RIF is not configured properly then standard ABR will ramp up its rate much faster and to a higher value. This is aided by the fact that the step sizes are bigger and the step frequency is higher in comparison with ForeSight.

Reaction to feedback messages - Rate Down

In ForeSight on receiving a Rate Down cell from the remote end, the source reduces its current rate (actual cell rate) by 13 percent. The rate decrease percentage (RDP). RDP is configurable at the card level.

In standard ABR, rate decrease is by an amount (RDF*ACR). Currently, the default value of RDF is 1/16 (6.25 percent). This means when this connection co-exists with ForeSight connections, in the event of congestion ForeSight connection reduces its rate by 13 percent whereas standard ABR connection reduces its rate by only 6.25 percent. Therefore, in the case of co-existence, if we need to approximate the same behavior across the two connection types, then RDF should be changed to 1/8, so that both connections ramp down by the same amount (13 percent).

Fast-Down

In ForeSight if the destination egress port drops any data due to congestion then the destination sends a Fast Rate Down cell. Also, if a frame cannot be reassembled at the egress due to a lost cell somewhere in the network, a Fast-down will be generated. On reception of Fast Rate Down the source reduces its current rate by 50 percent (this is again a card-level configurable parameter).

Standard ABR does not distinguish between drops and the ECN/EFCI threshold being exceeded. This means that, in case of drops in the egress port queue, a standard ABR connection rate reduces by only (RDF*ACR) but the ForeSight connection rate reduces by (ACR*0.5). Therefore, in the case of co-existence, if we need to approximate the same behavior across the two connection types then Fast Down could be effectively disabled by configuring the reaction to be 13 percent rate down instead of 50 percent.

Guidelines

The two systems will work together within the network, but as the above description suggests, if the differences between the two systems are not taken into consideration, then a ForeSight connection and an ABR connection with the same configuration parameters will not behave the same way within the network.

ABR and ForeSight provide a mechanism for distributing excess bandwidth between connections over and above the minimum rate, therefore if these guidelines are not taken into consideration then the allocation of this excess bandwidth may be biased toward connections running one of these algorithms over connections running the other.

If this is a requirement, the following guidelines may be useful, assuming ForeSight is set to defaults except for Fast Rate Down which is set for 13 percent.

1. Nrm: Nrm needs to be set at a value whereby the approximate RM cell generation is
100 milliseconds, to match that of ForeSight. This calculation is based on the expected average, or sustained, cell rate of the connection. However, if the (potential) fast-down messages from ForeSight are left to equate to 50 percent rate down, then an estimate of how often this may occur needs to be made and factored into the equation. If the connection receives Fast-down messages, then this would make the ForeSight connection react faster than the equivalent ABR connection to congestion. To compensate for this, Nrm needs to be set at a value of less than 100 msecs, a suggested value to aim for is between 60-70 msecs (this would be approximate as n is configurable in steps of 2**n). This would mean that, in the event of congestion, the ABR connection would start to react faster.

2. RIF: Rate increase factor is a factor of PCR in ABR and MCR in ForeSight. The default RIF for ForeSight is MCR*.10. Therefore, RIF should be configured so that (PCR*RIF) approximates MCR*0.1. If Fast-Down is still effectively enabled, then PCR*RIF should approximate MCR*0.62 to compensate.

3. RDF: (Rate Decrease Factor) RDF should be 1/8. This approximates to 13 percent that ForeSight uses.

The following worked examples may help explain this further

Assume a network is currently running ForeSight with default parameters, and supports the following four connection type, where CIR = MIR, PIR = port speed, and QIR = PIR:

T1 Port Speed 64K CIR

Example:

CIR = MIR = 64K
PIR = QIR = port speed = 1544
Fastdown = 13%

(The calculation used to convert between frame based parameters (CIR, PIR, and so on.) and their equivalent cell-based parameters is FR_param *3/800. This allows for cell overheads, and so on. based on frame sizes of 100 octets.)

CIR = MIR = (64000*3/800) = 240 cps
PIR = QIR = (1544 *3/800) = 5790 cps

ForeSight ABR
Rate-up equals (240*.1) = 24 cps RIF equals x where (1590/x) = 24 cps
X needs to be approx 200
RIF equals 256 (nearest factor of 2)

RDF equals 13% RDF = 1/8
Nrm equals 100 msecs Nrm equals 32

RM cells will be generated somewhere between 6 (5790 cps approx equal to 32 cells per 6 msecs) and 133 msecs (240 cps approx equal to 32 cells every 133 msecs) depending on ACR.

CLI Modifications in 1.1.35 and Prior Releases

dspfail <slotno>

shows all failed connections per slot basis

dspfabit <slotno>

shows all A-bit failed connections per slot basis

dsplmiloop

shows if LMI loop is present

chkslotcon <slotno>

checks database consistency per slot basis

chkportcon <slotno> <portno>

checks database consistency per slot basis

Chkcon <slot.port.vpi.vci>

checks database consistency per connection basis

dspbecnt

displays bit error count

CLI modification and changes in previous releases:

A few modifications have been made to the IP configuration commands. (cnfifip and bootChange) See CLI Change section:

the cnfifip command has an additional option to up/down one of the IP interfaces (Ethernet, SLIP, ATM) dynamically. No reboot is required to up/down interface. Turned-down interfaces are persistent across resets.

cnfifip is now an active only command.

dspifip will now display the state of each interface and indicate if it is up or down.

bootChange now checks the IP values set and will complain if it detects incorrect values.

bootChange values are sent and updated on standby card automatically. Both bootlines are kept in sync.

bootChange command is now an active-only command from CLI.

cnfenetgw command has been added to establish the Ethernet gateway route permanently (command is active only).

dspenetgw command will display Ethernet gateway address set.

A shelf can now either have one or two IP addresses for Ethernet. The shelf IP address set using cnfifip will always be the active card IP address. The bootChange IP address will be used for the standby card and backup boot if it is different than the shelf IP address. If the bootChange IP address is same as the shelf IP address, then the Ethernet interface on the standby card or in backup boot will be left in the down state.

If the "255.255.255.252" netmask is used for the SLIP interface, the PXM will automatically add host route for its peer whenever the interface is turned ON

If the FW fails to reach the CLI prompt or comes up in backup boot, the Ethernet interface could be down if the shelf IP address and boot change address are the same. In this case the bootChange command could be used from the shell to set another IP address and then usrEnetEnable should be called to activate that address (see example).

Commands and Examples

cnfifip:

Syntax:

cnfifip "Interface IPaddr [NetMask [BroadcastAddr]]"

or cnfifip "Interface Flag"

Interface -- 26/28/37 (26:Ethernet 28:SLIP 37:ATM)

or Ethernet/SLIP/ATM

IP_Addr -- <n>.<n>.<n>.<n> (<n>: integer 0..255)

Net_Mask -- <n>.<n>.<n>.<n> (<n>: integer 0..255)

BroadcastAddr -- <n>.<n>.<n>.<n>

(<n>: integer 0..255)

Flag -- a string "UP" or "DOWN"

Example:

> cnfifip atm 192.9.200.1 255.255.255.128

This configures the ATM interface and brings it UP.

> cnfifip atm up

This will bring up the ATM interface with current information in the database.

> cnfifip atm down

This will bring down the ATM interface and preserve the information in the database.

delifip

Syntax:

delifip Interface

Interface -- 26/28/37 (26:Ethernet 28:SLIP 37:ATM) or Ethernet/SLIP/ATM

Example:

> delifip 37

This will bring down the ATM interface and delete the information in the database.

dspifip:

Example:

    > dspifip
Interface        Flag  IP Address       Subnetmask       Broadcast Addr
---------------  ----  ---------------  ---------------  ---------------
Ethernet/lnPci0  UP    172.29.37.77     255.255.255.0    172.29.37.255
SLIP/sl0         DOWN  172.29.36.253    255.255.255.252  (N/A)
ATM/atm0         UP    192.9.200.1      255.255.255.128  0.0.0.0

This command shows the current condition of all three interfaces. The data shown for the SLIP interface will apply when it is turned UP with, for example, cnfifip slip on.

cnfenetgw

Syntax:

cnfenetgw IPAddr

Example:

    > cnfenetgw 172.29.37.1

This command will set the default gateway and add the appropriate routes necessary to it.

dspenetgw

Example:

    > dspenetgw
      Enet Gateway:  172.29.37.1

bootChange:

Several lines are essential for the network to function:

- boot device : lnPci

(The only Ethernet interface)

- inet on ethernet (e) : 172.29.37.40:ffffff00

(IP address and subnetmask)

- gateway inet (g) : 172.29.37.1

(Default Ethernet gateway)

The PXM will try to correct bad entries when it boots up. This information will be copied to the standby card and if different than the shelf IP address it will up the interface on the standby with the bootChange IP address. The shellconn version of this command only updates the local bootline values and is not copied to the other card.

usrEnetEnable:

Used to bring up the Ethernet interface when CLI prompt is not there or in backup boot if it's not enabled.

The following commands are related to FRSM-2CT3 line-level loopbacks.

Remote Loopback at DS3:

This loopback can be configured in FRSM-2CT3 using the following commands:

addds3rmtloop <lineno>

xcnfln -ds3 <lineno> -e 3 -lpb 2

Local Loopback at DS3:

This loopback can be configured in FRSM-2CT3 using the following commands:

addds3loop <lineno>

xcnfln -ds3 <lineno> -e 3 -lpb 3

DS3 Loopback status will be displayed with following commands:

dspds3ln <lineno>

dspalm -ds3 <lineno>

dspalms -ds3

FEAC codes monitoring and Inband loopbacks for DS3 are not supported in FRSM-2CT3

Remote Loopback at DS1:

This loopback can be configured in FRSM-2CT3 using the following commands:

cnfbert (from PXM)

addrmtloop <lineno>

xcnfln -ds1 <lineno> -e 3 -lpb 2

Local Loopback at DS1:

This loopback can be configured in FRSM-2CT3 using the following commands:

cnfbert (from PXM)

addlnloop <lineno>

xcnfln -ds1 <lineno> -e 3 -lpb 3

DS1 Loopback status will be displayed with following commands:

dspln <lineno>

dspalm -ds1 <lineno>

dspalms -ds1

Inband loopback for DS1 are supported only using BERT diagnostics. The status of inband loopbacks are displayed with dspalm and dspalms commands. It is not displayed with dspln command. Before configuring the DS1 line in Inband loopback from BERT diagnostics, user should use the following command to enable code detection on FRSM-2CT3:

xcnfln -ds1 <lineno> -e 3 -detect 2

Ctrl-X has been disabled from resetting PXM on the firmware.

This release has the fix to meet the Bellcore jitter specs. The way to fix the jitter problem is to have FW disable the force_signal_detect_enable register and let the optical receiver to control the signal-detect input. The OC-3 transmit data jitter now measures below 0.10UI.

Due to the concerns about the too frequent message exchanging between the two PXM cards, the current command dspbecnt is limited by following:

dspbecnt displays only the bit error counts after the last APS switch. In other words, every APS switch will clear the counts for both working and protection line.

dspbecnt displays the active line bit error counts correctly. The bit error counts for non-active line is inaccurate and requires a state change (since the last state) in the protection line for display of any bit error counts.

A state change indicates a change of line status, such as from SD to SF.

Node Related

A maximum of one BERT test can be performed per shelf at any point in time. BERT can be activated only through the CLI.

Do not execute the restoreallcnf command in the middle of the installation process. If you follow the steps below, the dsplns command will display a line as disabled, but you cannot run an addln command. Do not execute the restoreallcnf command until the install and newrev commands have completed

The correct order for the restore procedure is:


Step 1 saveallcnf

Step 2 install

Step 3 newrev

Step 4 restoreallcnf



Note For more information, refer to CSCdm57683.


Addln should be issued before issuing addapsln.

The following line and alarm-related commands have been modified to allow slots 8, 16, and 32 as valid arguments if PXM at slot 8 is active:

addln

delln

cnfln

dspln

dsplns

addlnloop

dellnloop

cnfsrmclksrc

dspsrmclksrc

dspalm

dspalms

dspalmcnt

clralmcnt

clralm

dspalmcnf

Full SRM redundancy requires redundant SRMs. There must be SRMs in BOTH slot 15 and 16 to ensure service module redundancy for the upper shelf and SRMs in BOTH slot 31 and 32 to ensure service module redundancy for the lower shelf. Lack of the second SRM in either shelf may result in mismatch conditions.

For service module redundancy support, if the active service module is physically removed from the slot then a switchcc would cause the now active service module to be inaccessible. The workaround is to make sure that both the active and standby cards are physically present in their slots. If the active card does need to be removed, then at shellconn type: pmmStartScmPolling(slotnumber) after the switchcc.

If you are moving service modules from an existing MGX 8220 platform to the MGX 8850, the MGX 8220 service modules (AX-FRSM-8T1/E1, and AX-CESM-8T1/E1) need to have the boot flash upgraded to MGX 8220 Release 5.0.00 common boot code (1.0.01 version) before they can be plugged in to the MGX 8850 chassis. All MGX 8220 service module versions that use Release 4.0.xx of boot code and earlier are not supported in the MGX 8850.

If loading of the correct common boot code image is required then it will have to be performed on an MGX 8220 chassis, and cannot be performed on an MGX 8850 chassis. Please refer to the procedure below, which is also outlined in the Cisco MGX 8850 Installation and Configuration publication on the documentation CD.


Step 1 Use ftp to port the Axis 5 common boot image for the service module to a workstation.

Step 2 Plug in the card into the MGX 8220 shelf.

Step 3 Download the proper MGX 8220 shelf Release 5.0 boot image using the following commands from the workstation:


tftp <ip address of the MGX 8220 shelf >
bin
put <boot filename> AXIS_SM_1_<slot#>.BOOT

Insure that TFTP downloaded the appropriate boot code by verifying the flash checksums.


Step 1 Log into the shelf.

cc <slot #>'

Step 2 Verify that the two checksums are the same.


chkflash'

If not, repeat the process until they are the same. If they are the same, then you can safely remove the card. At this point the service module can be used in the MGX 8850 shelf.


Caution If the checksums are not the same when you remove the service module, then the service module will not boot when it is plugged in and the service module will have to be returned using the Cisco Returned Material Authorization process.

Whenever an MGX 8850 is added as a feeder to a BPX 8600, SWSW automatically programs a channel with a VPI.VCI of 3.8 for use as the IP Relay channel. IP Relay is used to send IP data between nodes via the network handler, allowing every node in the domain to be directly addressable via IP addressing and CWM workstations to communicate with every node (especially feeders) using TELNET, SNMP and CWM protocols. If the user tries to add a channel with a VPI.VCI of 3.8, the BPX 8600 does not prevent the user channel from being added, but the MGX 8850 rejects it. To delete the added channel on the BPX 8600, and to get IP relay working you need to reset the BXM card.

In addition to clearing the entire configuration, clrallcnf clears the network IP addresses. IP addresses and netmasks stay the same (dspifip). However, it's recommended by engineering to reconfigure them using the cnfifip command. Network IP is gone (dspnwip), and must be reconfigured using the cnfifip command. Refer to the entry on cnfifip in the Cisco MGX 8850 Command Reference publication on the documentation CD for syntax.

The copychan command does not work on the MGX 8850.

A minimum of two and up to four IP addresses are needed to be configured for MGX 8850 (one or more of the following: Ethernet, ATM, SLIP) and the boot IP address. The user should use bootChange to set up IP gateway when the PXM card is just installed. The IP default gateway should be on the same subnet as the PXM board. Use the bootChange command to set correct IP address, netmask, and default gateway.

Do not install a Y-cable on the UIA CP port for PXMs. If you do, both serial ports will be enabled and you will not be able to communicate with the shelf through the console ports. If after switchcc the standby PXM loses the down-level port, it is most likely due to a downlevel Beta version of UIA back card that was shipped during field-trial only. Upgrading the UIA back card to the latest version should fix this problem.

To configure the external clock source, use the interface label 7.35. Do not use 0.33 or 7.33.

There are also routeShow/routeAdd/routeDelete commands for modifying routing tables.

You must reboot your PXM after each modification with "bootChange" for it to take effect. Also make sure the subnet mask is 255.255.0.2

 . bootChange
   - Only enter the ethernet IP address, netmask and default gateway.
   - Type "." to erase incorrect entries.
     tigers.1.7.PXM.a > bootChange
     '.' = clear field;  '-' = go to previous field;  ^D = quit
     boot device          :lnPci
     processor number     :0
     host name            :C             <-- Please put "C".
     file name            :
     inet on ethernet (e) :172.29.37.40:ffff00  <-- Ethernet IP Addr/Netmask
     inet on backplane (b):
     host inet (h)        :
     gateway inet (g)     :172.29.37.1   <-- Default Gateway
     user (u)             :
     ftp password (pw) (blank = use rsh):
     flags (f)            :0x0
     target name (tn)     :
     startup script (s)   :
     other (o)            :
   - Type in reboot, after this the command "" will work:
     tigers.1.7.PXM.a >  171.71.54.53 1
     171.71.54.53 is alive

Configuration save-and-restore is supported only through the CLI (CWM does not support configuration save-and-restore). Service module upgrades error handling is not provided. If the user skips any of the steps during upgrade or if a power failure happens in the middle of the upgrade, results will be unpredictable. See the Special Installation and Upgrade requirements section for service module upgrades. To recover from procedural errors contact your TAC support personnel.

The MGX 8850 supports 15 simultaneous Telnet sessions and 10 TFTP sessions.

You must use the following Y-cables for FRSM-HS2 and FRSM-CT3 redundancy as specified in the Product Orderability Matrix (Straight Cable: 72-0710-01, Crossover Cable: 72-1265-01, Straight Y-cable: FRSM-HS2: CAB-SCSI2-Y, FRSM-CT3: CAB-T3E3-Y). Other cables are not supported.

Y-cable redundancy for FRSM-HS2, FRSM-2CT3, FRSM-2T3, FRSM-2E3 is supported only for adjacent slots.

Statistics are not supported for the RPM.

There is no need to issue the syncdisk and shutdisk commands before removing the PXMs. The system quiesces the disk by detecting the removal of the PXM board and flushes the write buffers to the disk and puts the PXM in sleep mode. This disables any further hard disk access since it locks the actuator. When the card is reinserted the PXM automatically comes out of sleep mode.

Syntax of addlink command has changed as follows:

New Syntax:

Syntax: addlink <T3LineNum> <T1Slot> <NumberOfT1s> <TargetSlotNum>

<TargetSlotLineNum>

<T3LineNum> where = Slot.Line

Slot = 15,31

Line = 1 - 3

<T1Slot> where T1Slot = 1 - 28

<NumberOfT1s> where NumberOfT1s = 1-8

<TargetSlotNum> where TargetSlotNum = 1-6|11-14|17-22|27-30

<TargetSlotLineNum> where TargetSlotLineNum = 1-8

PAR command cnfnwip has been disabled in this release, please use cnfifip instead.

If you lose power, or remove the online PXM you lose the broadcast address. Use the "cnfifip" command to configure the broadcast address. To redefine your ATM address and IP address that are in the same subnet, you have to change the ATM address to a temporary address not in the same subnet, then add back your IP address with the original Broadcast address, then go back and correct your ATM address.

Cooling and Power limitations: Customer should be aware of the need for extra power supplies and fans beyond certain limitations. A single fan tray will support all configurations that draw between 1200 and 1400 watts. For power requirements, the MGX 8850 requires a minimum of one power supply per line cord to support the power requirement for five cards.


0-5 Cards
6-10 Cards
11 and Above

Single Line Cord (N+1):

2

3

4

Dual Line Cord (2N):

2

4

6


This is based on an estimated worst-case power requirement of 190W plus margin per card slot.

Connection Management Related

The name of the node cannot be changed if there are PVCs. The node name must be changed from the default value before adding connections, since it cannot be changed later. Use the cnfname command to change the node name.

Only one feeder trunk can be configured. No BNI trunk to MGX 8850 as a feeder is supported.

The slave end of a connection must be added first.

The slave end cannot be deleted and re-added back by itself. If you delete the slave end, the entire connection must be completely torn down and re-added back. If the slave end of the connection is deleted and re-added back by itself, then unpredictable results will happen.

For user connections, VCI 3 and VCI 4 on every VPI are reserved for VPC OAMs.

The actual number of feeder connections you can provision on the PXM is always two less than you have configured. The dsprscprtns command shows max connections as 32767, but you can only use 32767 - 2 = 32765. One connection is used for LMI and another one for IP relay.

There is no error handling detection while provisioning through the CLI. Invalid endpoints and unsupported connection types (such as connections between FRSM-CESM ports or connections between structured and unstructured connections) are permitted using the CLI. The user should not configure these connections.

The sum of CIR of all channels of a port can be greater than port speed as long as CAC is disabled. However, it is not acceptable for one channel's CIR to be greater then port speed even if CAC is disabled. Two channels added up can exceed port speed. This means you cannot oversubscribe a port if only one channel is configured.

When trying to add a port on DS0 slot 32 of a CESM-8E1 line using an SNMP set or the CiscoView Equipment Manager, the SNMP agent in CESM will time out, without adding the port. The SNMP libraries treat the 32 bit DS0 slotmap (cesPortDs0ConfigBitMap) as an integer. The value for the last DS0 is treated as the sign value. This causes a corruption in the packet coming to the agent. As the agent does not receive a complete SNMP packet, it does not respond and times out. Use the command line interface to add a port on DS0 slot 32 of a CESM-8E1 line.

The cnfport command does not allow VPI ranges to be reduced. The cnfport command only allows the VPI range to expand. The correct sequence is to delete all connections on the partitions, delete the partitions, delete the port, and add the port with new VPI range.

On an FRSM-2CT3, one can add 128 ports on a group of 14 T1 lines as indicated below.

lines 1 to 14: 128 ports (A)

lines 15 to 28: 128 ports (B)

lines 29 to 42: 128 ports (C)

lines 43 to 56: 128 ports (D)

So, to add 256 ports on one T3: add 128 ports on the first 14 T1 lines and the remaining 128 on the next 14 T1 lines.

Note that (A) and (D) are connected to first FREEDM and (B) and (C) are connected to the second FREEDM. Each FREEDM supports only 128 ports. If 128 ports are added on one T3 as in (A), then there cannot be any more ports as in (D). The 129th port should be on lines 15 to 42 (as in B or C).

If the user adds a connection between an RPM and a PXM and then deletes the connection, the RPM shows no connection but the PXM still has the connection. The MGX was designed and implemented in such a way that only the connections that have the master end show up on PXM (by dspcons command). Consider these three connections:

c1: has only slave end

c2: has only master end

c3: has both master and slave end

When using the dspcons command, c2 and c3 will be displayed, not c1. The connection will not show up once the master end (PXM) is deleted. Recommendation: When adding a connection, if one end of the connection is PXM, always configure the PXM side to be the slave. Thus when deleting the RPM side, which is the master, the connection will not show up on the PXM. However, keep in mind that the slave end (PXM) still exists. This also provides a side benefit. When a connection exists with only the slave side, no bandwidth is occupied. The bandwidth is reserved only if the master end exists (with or without the slave).

The MGX-FRSM-HS1/B is capable of supporting a total throughput (card-level) of 16 Mbps. However, it is possible to configure four lines each supporting up to 8 Mbps, thus oversubscribing the card. This has been raised in bug #CSCdm71476 and a restriction/warning will be added in a future release.

Addlnloop on an FRSM-HS1/B line works only when there is a (valid) cable plugged in to the back card on that line. This is a hardware limitation on the back card and has been mentioned in the Release Notes in bug# CSCdm44993.

RPM Related

The RPM/PR and RPM/B operate under the following IOS and Release 1 software.

MGX SW version
1.1.24
1.1.31
1.1.32
1.1.34 and 1.1.35

"Bundled" IOS SW version

12.1(3)T

12.1(3)T

12.1(5.3)T_XT

12.2(2)T2

IOS Version for RPM-PR

not supported

not supported

12.1(5.3)T_XT*

12.2(2)T2

IOS for RPM/B in MGX 8230

not supported

not supported

12.1(5.3)T_XT

12.2(2)T2

CWM

9.2.08

10.3

10.4.01

10.4.01 Patch 1

Note *Support for RPM-PR is FCS with Release 1.1.32. General Availability of RPM-PR is with Release 1.1.34.



With MGX Release 1.1.32, two Route Processor Modules (RPMs) are supported; the RPM/B and the RPM-PR.

The RPM/B is a NPE-150 based router card capable of sustaining 150,000 pps. The RPM-PR is an NPE-400 based router capable of sustaining over 350,000 pps. The RPM-PR will only operate with IOS 12.1(5.3)T_XT or later. For the following section "RPM" will refer to both the RPM/B and the RPM-PR, (unless specifically called out) even though some software versions and limitations are not applicable to the RPM-PR because it doesn't support IOS versions before 12.1(5.3)T_XT.

With RPM/B versions earlier than 12.O.7T1, some limitations in Inter-Process Communication when the RPM/B is at high loads can cause the PXM to declare that the RPM/B has Failed. To avoid this with RPM/B, software releases earlier than 12.0.7T1, throughput is limited to 62,000 pps, and it is recommended that MPLS configurations are limited to 100 interfaces. With RPM software releases from 12.0.7T1, those limitations are removed. In a separate limitation, the number of directly connected OSPF networks supported by an RPM is currently limited to 27. This means that any or all of the subinterfaces supported by the RPM can run OSPF, but the number of distinct OSPF networks supported is limited to 27. (A work around is available and is discussed below.) The limit of 27 arises because of the overheads of supporting separate link-state databases for separate networks.

In an application where the RPM is a Provider Edge Router in an MPLS Virtual Private Network service, a much better solution in any case is to use a distance-vector routing protocol between the customer routers and the RPM. A distance-vector routing protocol provides exactly the information required for this application: reachability information, and not link-state information. The distance-vector routing protocols supported by the RPM are BGP, RIP v1 and RIP v2, as well as static routing. With RPM software releases from 12.0.7T1, distance-vector routing protocols can be used with as many different networks as subinterfaces.

Note that if the RPM is acting as a Provider Edge Router in an MPLS Virtual Private Network service, and even if OSPF is running in a customer network, it is not necessary to run OSPF between the customer router and the RPM. If the customer edge devices run Cisco IOS, they can redistribute OSPF routing information into RIP using the IOS commands, redistribute RIP in the OSPF configuration, and redistribute OSPF in the RIP configuration. Similar configurations are possible for BGP. (For more information on readvertisement, see the "Configuring IP Routing Protocol-Independent Features" chapter in the Cisco IOS Release 12.0 Network Protocols Configuration Guide, Part 1). Redistribution is not unique to Cisco CPE, and other vendors' equipment also supports redistribution.

RPM Front Card Resets on an MGX 8250 Switch

The RPM front card resets on an MGX 8250 switch when the ethernet back card is removed. While this problem is observed on the MGX 8250 switch, it does not occur on an MGX 8230 switch.

This reset problem can be easily avoided if "shut" interface is executed before the removal of the back card.

RPM-PR Back Ethernet Card Support

For Ethernet connectivity with the RPM-PR, the model "/B" four-port Ethernet back card is required (order number: MGX-RJ45-4E/B).

RPM/B Ethernet Back Card Support

The model "/B" four-port Ethernet back card can be used with the RPM/B module only in combination with IOS 12.2(2)T2 or higher. The model "/B" back card will not work on the RPM/B with earlier versions of the IOS.

The order number is order number: MGX-RJ45-4E/B.

Older back cards can be used with any version of the IOS.

4-port Ethernet back card used with RPM/B
Required IOS

model "/B" back card

12.2(2)T2

earlier back card models

Min. IOS for RPM/B on MGX 8250 is 12.0(7)T


Refer to Route Processor Module (RPM) Addendum for more specific information about the RPM.

Limitations

CWM Recognition of RPM/PR and RPM/B Back Cards

CWM does not distinguish between the Ethernet back card versions installed with the RPM/B or RPM-PR. There is no functionality difference. The ability for CWM to distinguish between the Ethernet back card revisions is planned, but there is no targeted release at this time.

restoreallcnf

Do not execute the restoreallcnf command in the middle of the installation process. If you do, the dsplns command will display a line as disabled, but you cannot run an addln command. Do not execute the restoreallcnf command until the install and newrev commands have completed.

The correct order for the restore procedure is:


Step 1 Execute the saveallcnf command.

Step 2 Execute the install command.

Step 3 Execute the newrev command.

Step 4 Execute the restoreallcnf command


Note For more information, refer to CSCdm57683.



Please also note the following:

The Service MIB does not support resource partitions.

LIP is supported on the maintenance port, but there is no PPP support on the maintenance port.

BIS messages are constantly being sent from BPX to various nodes. This affects the frequency of TFTP updates, which may affect CWM performance and/or CWM database consistency.

Unable to provision virtual trunks in SWSW 9.1.10.

clrsmcnf

As a speedy way to wipe out all configuration on an SM, you can use clrsmcnf. This command works in the following scenarios:

1.1 SM not in slot

1.2 SM in slot and in active (good) state

1.3 SM in slot but in failed state, boot state or another state.

To be able to use an SM of a different type from the current one in a slot you can also use clrsmcnf for example, if there is a FRSM8T1/E1 in the slot with some configuration and the customer wants to use this slot for an AUSM8T1/E1 card.

The clrsmcnf cannot delete a port or channel due to corruption or error locally on the SM. It is able to delete the port/channel from within the PXM, but it cannot delete a port or channel due to corruption/error on the PXM itself. You can save an SM configuration and restore it back to the same slot on the same node. If the SM configuration is corrupted on disk, but the run-time image is okay and the file contented is corrupted, this is supported.

The following are NOT supported on the MGX 8850:

Saving a configuration of an SM from one shelf and restoring it to the same slot on another shelf.

Saving a configuration of an SM in a slot and restoring it to another slot of the same card type.

If the SM configuration is corrupted on disk, but the run-time image is okay and the FAT is corrupted.

If you have more than 500 connections on a service module, before issuing clrsmcnf you need to change the session timeout default value.

Use CLI command timeout 0 (no timeout)

clrsmcnf

After it is done, use the CLI command timeout 600 (to set the timeout value back to the default).


Note The clrsmcnf does not work with the VISM card.


Problems Fixed in Release 1.1.35

Bug ID
Description

CSCdw56886

An error can occur with management protocol processing. Please use the following URL for further information:

http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903


Problems Fixed in Release 1.1.34

Bug ID
Description

CSCds67533

Symptom:

You might see bit errors on the BERT tester when CESME1 line is configured as CLEAR.

Conditions:

This problem can occur on a E1CLEAR line, depending upon the bit pattern being sent on the line.

Workaround:

None.

CSCds87925

Symptoms:

Buffer overflow on the card causes one way traffic.

Conditions:

Occurs on a MGX-FRSM-HS1, with 4.0.16.

Workaround:

Execute resetcd.

CSCdt22219

Symptom:

The channel remains in alarm after the line/port alarm is cleared.

Conditions:

When a channel is added on a port in alarm, it remains in alarm even after the port alarm clears.

Workaround:

A switchcc clears this problem.

Further Problem Description:

The AIS sent on the channel is not stopped after the line/port alarm clears.

CSCdt33066

Symptom:

The RPM card remains in "Not Responding" state for ever.

Conditions:

This problem is observed when a lot of traffic is running on RPM.

Workaround:

By design, RPM can go into "Not Responding'" state momentarily, and recover later. However, if the card is really dead, then also it'll show the state as "Not Responding."

If the card seems to be stuck in "Not Responding" for long, the workaround is to reset the card.

Further Problem Description:

This is a baseline issue. In the forthcoming release, "Failed'" state will be defined for RPM card; hence, the two states will then be distinguishable.

CSCdt36828

Symptom:

A PXM switchover occurs.

Workaround:

None.

Further Problem Description:

The problem happens if a combination of 10.4.xx CWM release is used with PXM 1.1.3x or 1.1.2x release.

This problemis avoided if the connection is added or modified through the CLI.

CSCdt37479

Symptom:

The RPM continuously shows errors at 5 minute intervals on bulk updates of the subinterfaces.

Conditions:

This problem occurs during an upgrade from 1.1.24 to 1.1.31 upwards.

Workaround:

None.

CSCdt41897

Symptom:

The dspcon command on the PXM shows mcrBwd different from mcrFwd, pcrFwd and pcrBwd.

Conditions:

This problem has been observed with MGX-FRSM-VHS to PXM connections.

Workaround:

None.

CSCdt47663

Symptom:

The PXM trunk back card becomes inaccessible.

Condition:

This problem is observed after a power cycle.

Any subsequent commands (dspchans, dspalms, dsplns) show that the table is empty.

Workaround:

Execute a switchcc.

CSCdt49644

Symptom:

The dspcd command returns a checksum error and a data item not found prompt.

Condition:

This problem is seen when trying to execute the dspcd command on the PXM that shows in mismatch.

Workaround:

None.

CSCdt50606

Symptom:

APS l:N shows active on the MGX switch, but on the BPX switch, the interface shows as failed.

Condition:

Unknown.

Workaround:

None.

Further problem description:

This problem could be caused by a switchcc or backcard removal.

CSCdt50905

Symptom:

The command dspapsln 1 is not showing the right interface.

Condition:

This problem is observed when the backcard is removed from the active PXM.

Workaround:

None.

CSCdt51645

Symptom:

The cardis stuck in CardInit state.

Condition:

This problem was observed during testing, by invoking a switchcc approximately every 5 minutes.

Workaround:

None.

CSCdt56636

Symptom:

Exception while using dspnovram on SRM cards.

Conditions

When issuing the command dspnovram on an MGX release 1 shelf that has SRM configured on either 15+16 or 31+32 only, a "Tlb Load Exception" will take place and the novram information will not be displayed.

Workaround:

None. The bug has been fixed in PXM version 1.1.34.

CSCdt60892

Symptom:

Core shows a Device Driver Error on the shelf.

Condition:

Not known at the present time.

Workaround:

None.

CSCdt60998

Symptom:

Software error occurs on a shelf running 1.1.33Ac.

Condition:

Unknown.

Workaround:

None.

CSCdt61771

Symptoms:

A message is printed during clrsmcnf on all the telnet sessions; this causes any running expect script to fail.

Conditions:

This problem occurs all the time.

Workaround:

None.

CSCdt61936

Symptom:

Under certain low memory conditions , the PXM can get Watchdog timeouts. This problem has not been seen in the field. It was seen in the lab when the memory on the PXM was reduced intentionally for testing purposes.

Conditions:

This problem is observed when the PXM is low on memory and there are lots of traps or connection addition/deletion activities occurring on the node.

Workaround:

None.

CSCdt65310

Symptom:

CiscoView won't show the card state for a card.

Conditions:

RPM card goes into "Not Responding" state, which happens when the IPC polling fails.

Workaround:

Once the card goes back to active state, do the node resynchronization again from CWM, and refresh CiscoView.

CSCdt66754

Symptom:

The command dspcds does not display the SRM card in slot 14 on an MGX 8230 switch.

Condition:

This problem was observed when the RPM card is in slot 6.

Workaround:

None. This is a display issue only.

CSCdt67137

Symptom:

When the RPM is in boot mode, cc is not allowed.

Conditions:

RPM is in boot mode and dspcds shows it in Boot.

Workaround:

None.

CSCdt67556

Symptom:

The RPM goes into a failed state after switchcc. RPM on the console shows fine.

Condition:

Switchcc message is missed by the RPM when swithcc is done.

Workaround:

Reset the RPM card.

CSCdt67767

Symptom:

The PXM resets due to software error.

Conditions:

This problem is found during memory corruption.

Workaround:

None.

CSCdt68144

Symptom:

Telnet to a shelf does not go through.

Conditions:

This problem was observed when PXMs are swapped between shelves.

Workaround:

On the shellConn of both the active and standby PXMs, do sysDownNetwork and only on the shellConn of the active PXM, do sysUpNetwork (after doing sysDownNetwork).

Further Problem Description:

This problem is caused by Gratuitous ARP done by the standby PXM.

CSCdt69590

Symptom:

The card resets twice while coming up

Condition:

Reset both the primary and secondary card

Workaround:

None.

CSCdt70311

Symptom:

The RPM is stuck in Reserved state after back-to-back softswich.

Condition:

This is possible when a script is executed which will do back-to-back softswich between RPMs when they are a part of Redundant group. After 15 or more softswiches, the problem was observed

Cause:

Found that the PEM2 daughter card isn't tightly connected with NCB2 daughter card, possibly due to the number of manual upgrades pccurring on this board. The card never exhibited this problem again after carefully reassembled.

Workaround:

Reset the RPM card that is in reserved state.

CSCdt70488

Symptom:

If the RPM boots using the bootimage, it will be in Boot state.

Conditions:

If the RPM cannot load the IOS image, it will load the first Boot image in the flash. Under this condition, the RPM will be not be configurable via cc from the PX M.

Workaround:

Access the RPM only through the console if it is in a Boot state.

CSCdt70786

Symptom:

The command clrsmcnf doesn't clear the RPM configuration.

Condition:

This problem was observed when clrsmcnf is done on an RPM in slots 1 to 9.

Workaround:

Add the command in the format "boot config c:auto_config_slot01" in the configuration and do a write before doing clrsmcnf for RPM's in slots 1 to 9. (Slot 1 is used in the command string above for example purposes only).

CSCdt71121

Symptom:

Customer shelf experienced a software error during routine check of the core.

Conditions:

Normal.

Workaround:

None.

CSCdt71524

Symptom:

Switchover message is not transmitted.

Condition:

This problem occurs during a softswitch, followed by a switchcc.

Workaround:

1. Resetcd on the card.

2. Wait for primary to come up, then do a switchcc.

CSCdt75765

Symptom:

The auto_config_slotXX file is cleared.

Condition:

This problem can occur when the command clrsmcnf is executed while RPM is engaged with redundancy.

Workaround:

None.

CSCdt78616

Symptom:

The command delport on the FRSM in not working properly.

Condition:

Normal.

Workaround:

Issue the command delport twice.

CSCdt88238

Symptom:

If there are two CC sessions open on a particular service module, and if the active PXM card is reset or removed, no more CC sessions can be opened on the same service module.

Conditions:

As stated above.

Workaround:

Softswitch or resetcd on a service module experiencing a problem.

CSCdt93357

Symptom:

When a reset of an active card of a hotstandby pair is done, the command dspcds shows both cards in standby.

Conditions:

This problem was seen in version 1.1.33Ahm VHS version 10.0.13, with about 200 feeder trunk connections.

Workaround:

None.

CSCdt93367

Symptom:

After a PXM goes into a HOLD state, the SRM state change is not updated. Also, the PXM in hold state does not go to mismatch.

Condition:

This problem is observed during a graceful upgrade, after the install or newrev command.

Workaround:

Reset the PXM in HOLD state after the SRM is removed from the shelf or after the SRM is put back in the shelf.

CSCdt94118

Symptom:

Traffic is not flowing on the even numbered ports on an AUSM.

Conditions:

This problem occurs after a power cycle.

Workaround:

Issue the following command in shellConn:

SarSetCellFormat 2

CSCdt97663

Symptom:

Unable to disable statistics for a PXM1 node.

Conditions:

Unknown.

Workaround:

Execute a switchcc.

Further Problem Description:

None.

CSCdu07281

Symptom:

Cannot do a reset; flash memory write message appears.

Condition:

This problem occurs after a second resetsys was done on the shelf.

Workaround:

None.

CSCdu12023

Symptom:

With a 120 ohms E1 clock source plugged into a PXM-UI= card (via RJ45 port), configuring the external clock type via the cnfextclk command to an incorrect value does not impair the clock source attached. The MGX switch still reflects the presence of the E1 external clock source when executing a dspcurclk command.

For example, configuring the external clock source type as T1 does not disturb the presence of the external E1 clock source physically plugged into the PXM-UI. dspcurclk continues to accept the external E1 clock source as the current clock irrespective of what is configured using the command cnfextclk.

Conditions:

This problem occurs when an external clock source is used.

Workaround:

None.

CSCdu12917

Symptom:

Sometimes the AUSM-8T1E1 card gets stuck in CardInit state after reset.

Conditions:

Normal conditions

Workaround:

Reset the card again.

CSCdu17286

Symptom:

All the lines on AUSM and channels are in alarm.

Condition:

When upgrading from 1.1.33Aj to 1.1.33Ak

Workarounds:

None

Further Problem Description:

None.

CSCdu30080

Symptom:

Can not cc to the Active AUSM after 10 minutes.

Condition:

After doing a softswitch on the ausm SM's in slot 29 and 30.

Workaround:

Reset the active slot.

Further Problem Description:

None.

CSCdu31239

Symptom:

Card gets stuck in 'CardInit' state. Even a reset of card doesn't help.

Conditions:

This problem is the result of repeated softswitches.

Workaround:

Perform a switchcc.

CSCdu32432

Symptom:

No alarms are present.

Condition:

This problem occurs when the SRM Tx and Rx cables are removed from the SRM.

Workaround:

None.

CSCdu45583

Symptom:

Slot #30 that was covering for Slot #28 rebooted.

Conditions:

This problem is observed after a switchcc on the PXM card while the secondary card is covering primary card. Need to have two IMA ports on this card connected with a Cisco 3660 router.

Workaround:

Softswitch back to primary before switchcc.

Further Problem Description:

The problem only happens with IMA configuration.

CSCdu54665

Symptom:

The service module FRSM-8T1E1 doesn't display a service type.

Condition:

This problem occurs for connections created in the 1.1.2x baseline, then upgraded to Release 1.1.34.

The channel service type was not initialized to default during the upgrade.

Workaround:

None.

CSCdu54875

Symptom:

After upgrading to Release 1.1.34, the command xcnfchan doesn't change the service rate.

Condition:

This problem occurs for connections created in baseline 1.1.2x, and because the ChanServiceRateOverride and the ChanServiceRate were not initialized after the upgrade. This caused the mir,qir,pir to be calculated based on the ChanServiceRate(which was 0).

Workaround:

Configure the ChanServiceRateOverride to the default value(disabled) using either:

cnfchansrvrate <channel no> 2 <chan service rate>

or

xcnfchan -chn <chan no.> -en 3 -srvovrd 2

CSCdu61035

Symptom:

FE backcards on an RPM card go into promiscuous mode after prolonged traffic.

Condition:

On pumping traffic through an FE backcard on RPM for 6-8 hours, the backcard would not respond; however, the RPM card indicates operations are fine.

Workaround:

None. Fixed with IOS 12.2(3.1)T.


Problems Fixed in Release 1.1.32

Bug ID
Description

CSCdp38293

Symptom:

dspcd on the SRM will show the 800 number from the back card in the front card FabNumber field.

Workaround:

Added a new field to show the SRM front card's fab number. Renamed the old field to be the fab number for the SRM back card.

CSCds09448

Symptom:

The CWM does not display the correct values of:

Ingress Percentage Utilization

Egress Percentage Utilization

Connection Percentage Utilization

Connection Remote Percentage Utilization

Conditions:

These MIB objects are not included in the TFTP config upload file.

Workaround:

None.

CSCds24381

Symptom:

PXM7 switched to PXM8.

Condition:

Memory corruption.

Workaround:

None.

CSCds25261

Symptom:

SNMP trap to indicate ILMI failure on AUSM card causes HP OpenView to crash.

Conditions:

When ILMI is disabled or fails, (after being enabled), an SNMP trap #50915 is sent to CWM. This trap causes HP OpenView to crash with the following message:

"xnmevents lost contact with pmd.
No new events will be received.
Lost connection with pmd/ovEvent process (application disconnected)"

Workaround:

None.

CSCds31371

Symptom:

Active card automatically switches to standby card.

Condition:

Unknown.

Workaround:

None.

CSCds37482

Symptom:

BERT for a port/line on CESM-8 fails intermittently with a general error. A resetcd is required to make the port/line operational.

Conditions:

This happens when BERT is configured on the CESM-8 port/line. The bug is applicable to all CESM-8 releases up to and including 10.0.21.

Workaround:

Depending on which phase of the BERT configuration the error occured, it might be possible to recover the port/line state with a delbert.

CSCds38566

Symptom:

The SCM queue reports an overflow error log message for the slots containing RPM card.

Conditions:

The problem occurred when the customer was running the script to add a connection.

Workaround:

The log message should be simply ignored for RPM cards. The build-up in the SCM queue does not impact service.

Further Description:

Messages put into the queue are not supposed to be sent to the RPM card. When a connection is added to a Service Module, a task sends some information to the Service Module related to those connections. This information is not applicable for the RPM card.

CSCds43238

Symptom:

The dsploads CLI command does not display load from rt-vbr connections.

Conditions:

This occurs when the dsploads CLI command is executed.

Workaround

None.

CSCds43415

Symptom:

Telnet session lost after clrsmcnf CLI, several SMs in Boot states.

Condition:

Unknown

Workaround:

None.

CSCds48811

Symptom:

If a manual refresh is performed from CiscoView on the MGX 8230 chassis after a switchcc, the Standby PXM removes itself and resets.

Conditions:

This occurs when CiscoView is started or a manually refreshed.

Workaround:

None.

CSCds52286

Symptom:

Infinite loop on the Telnet input task, causing PXM switchovers.

Conditions:

The customer was using a shareware software for Telnet to the node.

Workaround:

Use Solaris machines for Telnet to the node.

Further Problem Description:

Telnet through the shareware software and leave that window untouched for approximately 13 minutes. To ensure that the session doesn't timeout, use the command sesntimeout 0 after you login. This will reproduce the problem.

CSCds55580

Symptom:

"dir c": shows no files in the directory when running PXM 1.1.32 and an earlier image with the RPM 12.1(5.X)T image.

Conditions:

PXM 1.1.32 and an earlier image with the RPM 12.1(5.X)T image causes this problem.

Workaround:

When running the RPM 12.1(5.X)T image, the PXM image containing the fix for this problem should be run hand-in-hand with the new RPM image.

CSCds60208

Symptom:

Shelf sometimes reboots on switchcc.

Conditions:

During redundancy testing in the lab, back cards were pulled out to check if core card switchover occured. When switchcc was entered, the shelf rebooted.

Workaround:

None.

CSCds65330

Symptom:

After PXM was upgraded from 1.1.24 to 1.1.31Aa, some of the RPMs went into Failed state and some went into Not Responding state.

Conditions:

Some RPMs were running very old images, some RPMs were running a later boot image and an older IOS image. Officially only the last two RPM releases are supported with any PXM release.

Workaround:

Reset the RPM card where the cc is failing.

Further Problem Description:

In the node on which the upgrade was tried, some of the RPMs were running very old IOS images. With any PXM release only the last two IOS releases are supported. Documented upgrade procedures should be followed for upgrading the RPM nodes.

CSCds66048

Symptom:

Bit errors occur on the CESM during BERT testing.

Conditions:

Bit errors occured when testing the CESM in an MGX 8850:

using synchronous clocking on the CESM channel

with the BERT tester set for internal clocking

Workaround:

There are no problems passing data and getting a pattern sync without bit loss when using a simple pattern (2^11-1 and lower ). Use of Adaptive clocking and SRTS also improves the results.

CSCds66176

Symptom:

Cannot utilize entire FRDM buffers after Softswitch ports deleted for db.

Conditions:

FRSM-CT3 connection within maximum limit window.

Workaround:

Configure up to 105 ports.

CSCds67365

Symptom:

PREFIX : Resolve warnings reported by prefix tool.

Workaround:

None.

CSCds71795

Symptom:

Routine check of core dump showed several errors on standby PXM. Standby is in Minor alarm. Errors caused reset of standby card.

Conditions:

PXM-0C3 1.1.31

DSPERR -EN 1149

Core dump shows error 1149: 1149 software error reset.

Workaround:

None.

CSCds72478

Symptom:

Routine check of core dump showed several errors on standby PXM. Standby is in Minor alarm. Errors caused reset of standby card. This problem seems to be similar to CSCds71795 (above), although a different node.

Conditions:

PXM-0C3 1.1.31

DSPERR -EN 121

Core dump shows error 121: 121 software error reset.

Workaround:

None.

CSCds72620

Symptom:

During upgrade of SMs, Softswitch from secondary to primary puts the card to failed state.

Conditions:

Occurs with 1.1.31

Workaround:

Resetcd the primary card.

CSCds73092

Symptom:

RPMs show the message "PXM does not support RSRCPRTN resynch" while booting up.

Condition:

A PXM rebuild occurs during a PXM switchover or when an RPM is reset.

Workaround:

None.

CSCds73935

Symptom:

FRSM VHS cards OAM-receive buffer overflows. This causes the received OAM buffers to be dropped.

Conditions:

This problem occurs when OAM is enabled for the connections.

Workaround:

Softswitch to the hot standby, or disable the OAM.

Further Problem Description:

In the FRSM VHS cards, the OAM receive buffers overflow causing the received OAM cells to be droped. The free buffer list is being corrupted. This corruption is triggered by the incorrect CRC in the OAM cells received. Softswitch temporarily solves the problem. A second solution is to disable the OAM.

CSCds75559

Symptom:

ABR connection with SrcDstBehavior on AUSM card stops forwarding traffic when the queue depth becomes equal to the number of RM cells sent across.

Condition:

Every time an ABR connection is configured to SrcDstBehavior.

Workaround:

None.

Further Problem Description:

The ICSE-SAR interface is enhanced so that the ICSE can generate another service decision for every RM cell that was sent instead of the data cell. This way, the data cell (which was not sent due to the RM cell) is sent out and there is no problem in the data flow.

CSCds76985

Symptom:

After an upgrade from 1.1.24 to 1.1.31, the chassis model number is automatically changed to 8250. This causes the sync up with CWM to stop.

Conditions:

This occurs when a node connected to CWM is upgraded from 1.1.24 to 1.1.31.

Workaround:

Delete the node from the CWM configurator and re-add it.

CSCds81247

Symptom:

dspclkinfo shows current ClockSetReq to be primary while current ClockHwStat is secondary. The node is not synced up to the valid primary clock.

Conditions:

Inband from PXM line is configured to be the primary clock source. When the inband line fails and recovers the node, it does not sync up to the primary clock source. This problem was seen in 1.1.31 but not in 1.1.25.

Workaround:

None.

CSCds82530

Symptom:

RPM gets stuck in Go Active/Go Standby on doing resetsys/resetcd.

Condition:

The problem happens when five or more RPM cards in a shelf come up at the same time. This problem is typically seen:

after a resetsys

when resetcd has either been issued to all cards simultaneously or to one after the other.

Workaround:

Reset each stuck RPM card twice. Wait for each card to come up to a stable state before resetting the next card. Follow this proceedure one stuck card at a time

Example: If two cards are stuck, reset one of the cards. It will gets stuck while waiting for bootack state. Then, reset the same card a second time until it comes up OK. Once the first card is up, repeat the proceedure for the second card.

CSCdt00463

Symptom:

Card type of -32600 is sent for RPM-PR instead of 2001.

Condition:

After upgrading an RPM/B with an RPM-PR, the PR card does not sync up with CWM. That happens because the PXM is sending the wrong card type to CWM and CWM cannot recogonize the card.

Workaround:

Perform a node resync from CWM to clear the problem.


Problems Fixed in Release 1.1.31

Bug ID
Description

CSCdk82484

Symptom:

The RPM incorrectly identifies the physical slot position when it is placed in an MGX 8230 node. This causes communication with the PXM to fail.

Conditions:

PXM and/or RPM software is running on an 8230 or other Sweet Pea node.

Workaround:

PXM and RPM software should be upgraded to versions that support the 8230 slot numbering scheme. The minimum level of software should be 1.1.31 on the PXM and Cisco IOS Release 121-4.1(T).

CSCdk94100

Symptom:

When ILMI signaling and polling is enabled at one port and not enabled at the other end the port on which signaling was configured does not go into the failed state.

Condition:

This happens when address registration is also configured along with the ILMI signaling and polling at one end and the other end is not configured for any signaling.

Workaround:

Do not configure address registration along with ILMI signaling and polling only at one end.

CSCdm06097

Symptom:

While SM is in a mismatch state, and switchcc occurs, the log file gets cluttered.

Condition:

When switchcc occurs and SM goes in mismatch state, SM logs same message more than once to PXM. Message that gets logged is like this:

02/01/1999-14:28:42 12 cmm        FRSM-6-4167 ASC sent slot number to
SM : Old S.N.= 12 New S.N.=12
02/01/1999-14:28:41 11 cmm        FRSM-6-4167 ASC sent slot number to
SM : Old S.N.= 11 New S.N.=11
02/01/1999-14:28:41 12 cmm        FRSM-6-4167 ASC sent slot number to
SM : Old S.N.= 12 New S.N.=12

Workaround:

This log file is not going to affect the functionality of the card or any performance of the card. This log message simply can be ignored because this is useful for debug purposes only.

CSCdm20583

Symptom:

When the dspcd command gets executed on the active PXM, with standby SRM card number or vice versa, the error message is confusing.

Conditions:

When the dspcd command is executed with the other SRM slot numbers.

Workaround:

No work around is available. This is just an unclear error message problem. No logical errors.

Further Problem Description:

When the dspcd command gets executed on the active PXM and when the argument for the command is the standby SRMs slot number, the above error message is displayed. That is because from slot 7 PXM only slot 15 and 31 SRMs are accessible. Similarly for slot 8 PXM only 16 and 32 are accessible.

CSCdm31793

Symptom:

When you configure a BERT on any line, all the channels on the local as well as remote are going into alarm. But connections on the PXM on both end does not indicate any alarm.

Conditions:

Configure BERT on any line which is having some connections.

Workaround:

No workaround for this.

CSCdm41079

Symptom:

When you configure CESM T1 D4/AMI Lingcod and framing, the line will not come up. The card is not generating a T1 signal.

Conditions

When configuring CESM T1 D4/AMI line.

Workaround:

None other than use ESF/B8ZS.

CSCdm55480

Symptom:

While "downloadflash" is executing on the PXM or while the TFTP of the flash image to SM is in progress, if the PXM or the respective SM is reset, it leaves the flash in an unknown state. The card that was reset will not bootup the next time.

Conditions:

The problem will happen when the PXM or the respective SM is reset using the resetcd or switchcc commands, while the flash is being written.

Workaround:

No workaround. Make sure that the flash is intact before executing the resetcd or switchcc commands or any other command which will result in the reset of the card.

Further Problem Description:

If the card is reset when the flash is being written, it leaves the flash in the corrupted state and the card does not boot up. All the soft reset commands like switchcc, resetcd, or addred do not check if any flash write is going on before resetting the card.

CSCdm69318

Symptom:

If a switchcc is performed at the same time that an FRSM-2CT3 is going through a reboot, the FRSM gets stuck in boot state.

Conditions:

If a switchcc is performed at the same time that an FRSM-2CT3 is going through a reboot, the FRSM gets stuck in boot state.

Workaround:

Do switchcc only after FRSM-CT3 is comes up.

CSCdm84982

Symptom:

The CLI tstdelay displays time in micro seconds in stead of milliseconds.

Condition:

CLI shows delay in microseconds and GUI shows in milliseconds but the values are almost same.

Workaround:

Convert the displayed time using this formula:
Time in milliseconds = (time displayed + 1000 - 1) / 1000.
The above formula converts the time in milliseconds with a round off. After converting the time, consider the time in milliseconds.

CSCdp03640

Symptom:

The dspshelfalm command displays power supplies and fans for MGX 8830 that are non-existent. Also, the fan unit numbers 1 to 8 are displayed as 10 to 17 in the fan traps.

Conditions:

This occurs when the dspshelfalm command is executed. When the fan traps occur, the unit numbers are displayed as 10 to 17 instead of 1 to 8.

Workaround:

None.

CSCdp11502

Symptom:

In case of any failure in modifying the channel parameters, such as when a modify fails due to over-subscription, the backoff fails with "Wrong Egress Service rate Value" as the error.

Conditions:

When there are AUSM UBR-1 connections through Proxy.

Workaround:

None.

CSCdp15496

Symptom:

Doesn't ask for the password to protect platform feature (CLI: dspfeature).

Description:

This is a CLI enhancement, not a bug.

Condition:

Not applicable.

Work around:

Currently not available.

CSCdp17122

Symptom:

Softswitch and switchback commands accept invalid slot numbers

Workaround:

None. Before executing the Softswitch or switchback commands make sure that the slot numbers are valid by executing the dspred command and verifying the slot numbers and their states.

Further Problem Description:

The Softswitch and switchback commands do not check for valid slot numbers before executing the command. Therefore, the slot might get reset even though the slot is not the primary of the redundancy group or the secondary of the redundancy group for the switchback command.

CSCdp23328

Symptom:

Inconsistency in the syntax used for dsplns vs addln/delln/dspln conditions:

The commands that are used to configure the PXM physical interfaces have inconsistency in their syntax. Some commands require a "-" sign before the line type parameter. The others do not.

Workaround:

Check the help text for the commands or refer to the command help in the manual before using the command.

Further Problem Description:

Some commands expect the '-' sign before the line type parameter; other commands do not. After the fix, all commands will have a consistent parameter syntax.

CSCdp30538

Symptom:

When memShow command is displaying the detailed memory statistics on all partitions, the PXM hangs when <ctrl>C is pressed in the middle of the display.

Conditions:

When executing memShow with a non-zero argument from the CLI prompt (for example, memShow 1), memShow without any argument works fine. But that will display only the summary information on the memory blocks. The detailed display can be executed only with a non-zero argument.

Also, while recreating the problem, it was observed that when the pagemode is OFF, the user has more chances of hitting the problem.

Workaround:

Do not execute memShow with arguments from the CLI prompt. From the VxWorks shell the command works fine. Also, do not execute the command with arguments when the PAGEMODE is OFF.

Further Problem Description:

When memShow with arguments is issued, either the process that is handling the output or the memShow routine infinitely waits. The reason for this infinite wait is currently unknown. After the problem occurs, the shelf cannot be telneted into or pinged. The active PXM has to be rebooted by pulling out the card.

CSCdp31043

Symptom:

dspalm on the FRSM-HSSI card needs the x21 as the interface type for HSSI interface.

Condition:

The alarms for the FRSM-HSSI card for the line require x.21 instead of HSSI as the interface type for dspalm command.

The CLI dspalm should except option -hssi on the card FRSM-HSSI but it accepts x.21 option.

Workaround:

-x.21 option can be used for HSSI interface. Be sure to use the appropriate MIB object to display the required info for the CLI dspalm.

CSCdp35123

Symptom:

When adding a fiftieth user to a single node, the last user becomes a "Not a valid user" after a short time (and/or before that user gets a chance to login into that node).

Workaround:

None

Description:

Array that keep all valid users' password (userPassword[ ]) was overflowing because of coding error. Since the password was not getting saved, the newly added user ID was also getting dropped from the valid user list. Fixing the bounds of the array fixed this problem.

CSCdp37528

Symptom:

At Softswitch for FRSM-VHS cards (hotSatndby case) two traps are seen—primary to secondary trap number is 50045, secondary to primary trap number is 50046. Duplicate 50045 traps sent when Softswitch executed on FRSM-2CT3

Conditions:

Softswitch "from" "to"

Workaround:

None.

Further Problem Description:

If switchover occurs due to fault condition, there is only one trap sent out, which is correct functionality. Only when Softswitch is done manually through CLI or SNMP will traps 50045 or 50046 be sent twice.

CSCdp38293

Symptom:

The dspcd on SRM will show the 800 number from the back card in the FrontCard FabNumber field.

Workaround:

None.

Further Problem Description:

In CLI session, if a user issues a dspcd command on any SRM slot, besides getting other useful information it used to list 800 fabnumber of the back card as the fabnumber of the SRM front card.

Fix:

Added a new field that will show the SRM front card's fab number. Renamed the old field to be the fab number for the SRM back card.

CSCdp41488

Symptom:

The secLineModuleMismatchTrap is not generated.

Conditions:

When two half- height back cards are inserted that the full-height front card doesn't support, such as when PXM (full-height) card is inserted with 2 FRSM-8T1 back cards (half height).

Workaround:

This does not have any workaround. This needs further investigation and currently does not have any impact on the functionality. This is a negative test condition.

CSCdp42525

Symptom:

The dspfwrevs command does not display boot code versions.

Conditions:

Happens always.

Workaround:

Currently no workaround.

CSCdp43643

Symptom:

Under the condition given below you cannot add any configuration, but the PXM does not show any the card or even slot to be present through dspcds.

Conditions:

After pulling out PRM slot and then if a half-height card (SM) is inserted in the bottom half of that slot it comes up.

Workaround:

Currently not available. Has been fixed in 1.1.31

CSCdp45431

The dspcurclk does not update from external clock to internal OSC when the external clock fails.

CSCdp46345

Symptom:

When the active PXM back card is pulled out, the active PXM does not switchover to the standby.

Conditions:

When the active PXM back card is pulled out.

Workaround:

None.

Further Problem Description:

Intelligence needs to be put in, so that for T3/E3 back cards, or if there is no APS protection, we cause a switchover on back card removal.

CSCdp51956

Symptom:

No online diagnostics are available to check the health of PXMs and SRMs in the system.

Conditions:

Any.

Workaround:

None.

CSCdp57090

This needs further investigation and currently does not have any impact on the functionality.

CSCdp57673

Symptom:

RPM removal trap will show incorrect functionModuleState (ACTIVE).

Conditions:

RPM removal.

Workaround:

None.

CSCdp60418

This needs further investigation and currently does not have any impact on the functionality. There is no known workaround for this.

CSCdp66005

Symptom:

PXM UNI connections added on a port that is in alarm remain in alarm even after the port alarm is cleared.

Conditions:

This problem is reproducible. If connections already existing on a clear port are put in alarm by causing a port alarm, the alarms get cleared on clearing the port alarm. Only connections added on a port in alarm remain in alarm state even after clearing the port alarm. This problem was first seen in image 1.1.21Lc.

Workaround:

Before adding UNI connections originating from any SM, make sure that the ports at the two endpoints are clear of any alarms. Alarms on a connection can also be cleared by doing an SM reset.

CSCdp69136

Access Violation errors reported during TFTP of ComMat.dat file.

CSCdp69188

Symptom:

SNMP query "get" on "mibVersionNumber" returns incorrect value. Invalid response issued when an SNMP query is performed on an 8850.

Conditions:

SNMP query "get" on "mibVersionNumber" returns incorrect value. Invalid response issued when an SNMP query is performed on 8850.

Workaround:

Get MIB version number from platform firmware version by CLI command version. Cisco CCO has details of which MIB version goes with which firmware version number.

CSCdp70729

Symptom:

None.

Conditions:

A new feature to provide SNMP set switchCoreCard. This feature was added to the (POP1PRET5) 1.1.31 release.

Workaround:

None.

CSCdp71073

Symptom:

Customer has performed a Softswitch with redundancy setup between slot 22 and slot 30. After reviewing the logs, they noticed that the wrong slot numbers are referenced in the log. They believe that axis slots are being referenced rather then PXM1 slots.

Conditions:

This bug can be reproduced after doing a Softswitch or a normal reset of the card.

Workaround:

There is no workaround for this bug.

Further Problem Description:

The desplog shows the wrong slot number for some of the log messages, this is because the slot number has not been updated from the PXM at this point.

CSCdp77492

Inconsistency in behavior of port status reporting when local loops put up on line. In one case, the port came out of alarm, and stayed that way even when loop removed. In another, port stayed in alarm when loop put up.

CSCdp91401

Symptom:

Customer cannot execute a BERT test on an AUSM card that has an IMA port defined on it. Only after the port is deleted can a BERT test take place. There are physical T3 loopbacks placed on the SRM cards and all links are defined.

Conditions:

Configure BERT test on any line with IMA port defined on it.

Workaround:

No workaround.

CSCdp97387

When the dspegrqs command was issued to display the egress ports of the FRSM-2T3 slot on popfnj46 MGX node, the system displayed. This command is valid only when egress service type is Weighted Fair Queueing.

CSCdp99436

Symptom:

On the FRSM-VHS2T3 shows dspportstats as command but there is no such command.

Condition:

Happens always.

Workaround:

Do not use the CLI dspportstats for FRSM-VHS2T3 and FRSM-VHSHS2 cards.

CSCdr05045

Symptom:

Trap varbinds missing in ChanOAMLpbkStatus Trap 50311. As per the MIB trap, 50311 is defined with 16 varbinds but received trap shows only 14 varbinds. The two varbinds functionModuleType and genericTimeStamp are missing.

Conditions:

Configure the RasOam loopback, status change will generate the trap.

Workaround:

No workaround for this.

CSCdr07250

Symptom:

APS lower priority external request asserted after higher priority req clears.

Workaround:

None

CSCdr08987

This problem is observed when no line is added on the BPX side and APS is added on the MGX side. Also the sigD threshold has to be of the order of 8 or 9. SigD levels of 7 or under do not result in this problem. No known workarounds.

CSCdr09138

Symptom and Problem description:

Whenever a yellow alarm is sent on the line side—whenever a line is alarm because of RcvRAI—the port remains in Active state. The port is expected to go in alarm.

Fix and Unit test: When the line is in alarm in RcvRAI state, the port is now put in alarm.

To test this, Unit Test:

1) a) Bring a line to RCV_RAIS state. (Connect a CERJAC or HP tester to the line and generate RAI). b) Add a port to that line. On dspport, this port should be in "Line alarm" state and not in active state.

2) a) Add a line such that it is active. b) Add a port on that line and check if its active. c) Bring a line to RCV_RAIS state (same method as in 1). On dspport, this port should be in "Line alarm" state and not in active state.

CSCdr09927

Symptom:

AUSM configured with an IMA port sends the trap 50231 on Softswitch. The trap contains the varbind imaPortState.0 (Integer): failedDueToImaSigFailure. The description for 50231 says "Indicates that IMA group is active" that contradicts with the value of the varbind imaPortState seen in the trap.

Conditions:

AUSM is in 1:N redundancy and it has an IMA port configured.

Workaround:

No workaround.

Further Problem Description:

50231 is sent when an IMA port is added. But the description for 50231 "Indicates that IMA group is active" leads to misinterpretation by the user. On Softswitch, secondary AUSM downloads the configuration and adds the lines, ports, IMA groups, and so on. Hence, this trap is sent.

CSCdr12555

Symptom:

Required Support for ZERO CIR connections on FRSM-HS1.

Condition:

Present HS1 SM does not support Zero CIR connections and does not provide to configure Service rate and EIR of the zero CIR connections.

Workaround:

None.

CSCdr15892

The addlnloop on the PXM causes SONET line alarms, which sometimes do not clear when the loop is removed.

CSCdr17560

Symptom:

Shelf reset while executing a switchcc command or if executing an SNMP get. This was due to (the creation of) a null pointer in the SNMP system data structure.

Conditions:

You will run into this problem only if you are running the PXM image from the 1.1.22Ll or 1.1.22Lo (internal) Releases.

Resolution:

A fix for CSCdr17560 was checked in to both 1.1.23 and 1.1.31 Releases. This fix provides the check of the return code of the function querying the shelf model number and thus allows the correct data to be registered for use later on. The SNMP system data structure is then initialized based on the model number found. The defaults are provided just in case an error occurs during the query of the system model number.

CSCdr18819

Symptom:

PXM prompt gets misaligned after adding a connection.

Fixed-in: 1.1.24

Workaround:

None

CSCdr19336

Symptom:

Unable to configure service rate after reducing the line rate using cnflnsubrate.

Conditions:

Reduce PortSpeed (which is same as LineSpeed for unchannelized cards) using cnflnsubrate. Unable to modify the service rate after a line subrate modification. This applies only to Zero CIR connections.

Workaround:

Per -connection policing parameters are not adjusted when the port speed is reduced dynamically. For correct policing parameter, the s card has to be rebooted and then modify using cnfchaneir.

CSCdr21154

Symptom:

The time on the FRSM-8 card shows day as 00.

Conditions:

In the year 2000, on the last day of every month, the day will show up as 0.

Workaround:

There is no workaround, the date will get corrected the next day.

CSCdr22345

Symptom:

Voice call gets dropped, line alarm is seen on SM after a PXM switchover.

Conditions:

Happens only when the SRM has link to the SM, the secondary SM is Active and there is an SRM/PXM switchover.

Workaround:

Switch back the SM so that the Primary SM is Active before doing the PXM switchover.

Further Problem Description:

HotStandby SRM's link points to the Primary SM until the new SRM becomes Active.

CSCdr22910

Customer is concerned that the dspfst text does not match the cnffst text exactly. The dspfst output is missing the word "interval" after RTD.

CSCdr23908

Connection failures are not indicated in the system event log.

CSCdr33265

Symptoms:

After copying the new bootflash to the bootflash directory, the command "dir bootflash:" is used to find out whether the new bootflash is loaded correctly. The date is incorrectly shown as the old date, which may lead to confusion for the user. Also, if show clock is used on the RPM, then the wrong date and time is displayed.

Description:

Currently there is no real-time synchronization between the RPM and the PXM card. Because of this, the RPM always sets to some default time whenever it resets and the same time is reported as the time of modification for the File. The solution to this bug required sending the current date and time from PXM as a part of HELLO_BOOT_ACK message. RPM, upon receiving the date and time from PXM will set its own date and time to that of PXM and hence it gets synchronized to PXM's date and time.

Workaround:

Set the date and time at RPM using clock set hh:mm:ss command.

CSCdr35833

Symptom:

Both active and standby AUSM cards in a 1:N red config reset after a Softswitch

Conditions:

Statistics collection should be enabled.

Workaround:

This problem doesn't occur always, user has to try Softswitch once again, if it fails again disable stats and do Softswitch.

CSCdr36153

Creating an LOS condition on APS line caused multiple event log entries and traps.

CSCdr38808

Available as a part of 1.1.31. No workarounds.

CSCdr41646

Symptom:

No traps indicating SRM in Standby state is sent.

Conditions:

This occurs when PXM comes to Standby state after reset.

Workaround:

No workaround.

Further Problem Description:

After the Standby PXM card is reset and comes back up, traps are generated to indicate that the PXM card is back in Standby. However, no traps are received for the associated SRM cards to indicate status.

CSCdr42000

Symptom:

Many error messages showing on the screen after clrsmcnf command.

Conditions:

If you have an SM with many connections on the MGX 8850 shelf, then after the clrsmcnf command, this problem will happen.

Workaround:

None. However, those error messages are harmless; user should simply ignore them.

CSCdr43004

Symptom:

The IMA group goes down as soon as a local loop is initiated.

Conditions:

This happens when one of the lines on the side that is configured for loop timing is put into local loop.

Workarounds:

Resetting the card.

Further Problem Description:

This is because the loopback programming for the LIU was not being done in case of BERT.

CSCdr43525

Symptom:

Error Messages: CAN'T decrement portLcnUsed[cntrlType], already 0, slot 7, port 0 CAN'T decrement port lcnUsed, already 0, slot 7, port 0 appear after delchan of a management conn.

Conditions:

Seen in 1.1.24.

Workaround:

None.

CSCdr45284

Symptom:

While executing the command clrsrmcnf, there is no check before prompting user confirmation. The error checking is done at a later stage.

Conditions:

When the command clrsrmcn is executed with wrong SRM slot number.

Workaround:

Should enter valid SRM slot number. It has been fixed in 1.1.31.

CSCdr46692

Symptom:

Queue Engine on PXM1 hardware supports programmable values for minimum rate and maximum rate for the virtual interface (VI is mapped to a port) .

Currently, maximum rate is default to 100 percent of line bandwidth.

Conditions:

This is always the case, A new parameter has to be added in CLI/MIB to make this configurable.

Workaround:

None.

CSCdr46699

Symptom:

PXM1 has T3 interface. one conn. is added from VHS card at full T3 rate to PXM1 Line1. Another conn. is added from FRSM8t1 card at full T1 rate to PXM1 Line1 when data was sent at full rate on both connections, since PXM1 Line1 is congested, cells are dropped. But cells were dropped only for T3 full-rate connection; all cells for T1 rate connection went through. To be fair, a proportional amount of cells should get dropped from both connections.

Conditions:

This is always the case for the above setup.

Workaround:

None.

Further Problem Description:

By modifying the VI, Qbin, VC thresholds, some amount of fairness can be achieved.

CSCdr47445

Symptom:

Ethernet netmask reverts back to 255.255.255.0 after switchcc

Conditions:

Happens whenever the netmask in bootChange and cnfifip are different

Workaround:

Set the bootChange IP address to have same netmask by adding a colon followed by a hex netmask. Example: '172.29.36.99:ffffff80' The default netmask in the boot line is 'ffffff00' which is equivalent to 255.255.255.0

CSCdr48918

Symptom:

The PXM will not be able to clock from the T1s in the IMA group.

Conditions:

When configuring clock using cnfclksrc on the PXM from a line in an IMA group in AUSM, you must select the line with the same number as the label of the IMA group. If the IMA group label is not the same as one of the lines in the group, then the PXM will not be able to clock from the T1s in the IMA group.

Workaround:

Configure the IMA group such that its label is the same as one of the lines being used (example, IMA group 1 with lines 1, 2, 3, and 4). Then configure the PXM to clock from line 1.

CSCdr50184

Description:

The clrsmcnf on RPM resets RPM.

Condition:

Not applicable.

Workaround:

Clearing RPM config. can be done in two steps.

1. Erase NVRAM config. on RPM.

2. Use clrsmcnf for RPM.

CSCdr56159

Symptom:

CWM EM may show a physical line on PXM, even if the line is deleted.

Description:

No physical line delete trap is sent to CWM when the line is manually deleted by CLI or SNMP.

Workaround:

Currently not available.

CSCdr58168

Symptom:

Some of the lines in IMA group become unavailable.

Conditions:

This happens when the AUSM card was in bulk mode.

Workaround:

None.

Further Problem Description:

After a switchcc on PXM, the AUSM-8T1 card started displaying Minor Alarm. On further investigation, it was found that some of the lines configured as a part of the IMA group became unavailable. The respective AUSM-8T1 card was in bulk mode.

CSCdr58663

Symptom:

The CLI command restoresmcnf will not work after SM redundancy is deleted (in bulk mode).

Description:

When the SM is in bulk mode, restoresmcnf won't go through.

Conditions:

Same as the above description.

Workaround:

Currently not available. This bug has been fixed in 1.1.31

CSCdr59398

Symptom:

PVCs get deleted after the CLI cnfportrscprtn.

Conditions:

This condition results on use of the CLI cnfportrscprtn if the new VPI range specified is shrinked beyond the existing values of the resource partition and existing PVCs use VPI values that lie between the old range and the new range. Seen in 1.1.23

Workaround:

No workaround. Care should be taken to provide a "proper" VPI range so that all PVCs lie within.

CSCdr59813

Symptom:

The FRSM T1/E1 module has an egress HDLC queue scheduler that scheduled frames onto the logical egress queue. The rate at which this runs is not aligned with the logical port speed.

Workaround:

Further Problem Description:

Suggested fix is to have the queue scheduler schedule traffic out onto the HDLC framer queue at a rate aligned with the logical port speed.

CSCdr61374

Symptom:

1. The idle flag in dspchans seems to constantly toggle from Yes to No (even though Detection and suppression is disabled).

2. The on/offhook indicator seems to toggle when dspchancnt is viewed.

3. The throughput of the channels go down.

Conditions:

The situation is triggered when idle suppression related cells are received by CESM under the erroneous behavior of the network.

Workaround:

Deleting the erroneous connection and re-adding should solve the problem.

CSCdr61803

Symptom:

While clrsmcnf is in progress, entering control-c to stop the CLI will cause subsequent clrsmcnf on that same slot being aborted.

Description:

While clrsmcnf is in progress, entering control-c to stop the CLI will abort the clrsmcnf process and leave the slot in reserved state. After resetting the SM in the slot and card comes back to active, clrsmcnf cannot be resumed (aborted).

Workaround:

Wait until the clrsmcnf to complete and do not issue control-c to stop.

CSCdr63304

Symptom:

On the reception of segment loopback OAM cells on the AUSM port the counter gets incremented (PortXmtSgmtLpbkCells). On clearing the port counters this counter does not clear.

Conditions:

When segment loopback OAM cells are received on the AUSM port.

Workaround:

None.

Further Problem Description:

This counter was not being cleared. This has been fixed in the fix.

CSCdr63533

Symptom:

When a line is configured in remote loopback, dspcd does not indicate remote loopback.

Condition:

Happens every time remote loopback is configured.

Workaround:

No workaround.

CSCdr69994

Problem:

ForeSight parameters do not get modified on the standby card.

Symptom:

Standby card MIR/PIR/QIR do not get changed when they are changed on the active card.

Workaround:

Do a Softswitch and switch back

CSCdr70797

Symptom:

When a line is put in remote loopback the port is put into alarm and hence the connections, in which case AIS as well as data traffic, are sent to the CPE.

Conditions:

This happens when the line is put into remote loopback.

Workaround:

No workaround.

Further Problem Description:

Due to a hardware limitation the data traffic cannot be stopped from going to the CPE, hence the AIS transmission will be stopped in case the line is put into remote loopback. We will not put the port and connection into alarm just like local loopback.

CSCdr70820

Symptom:

In 1.1.24 PXM, chassis came up as MGX 8830 and as a routing node.

Description:

This has been fixed, so that it comes up as MGX 8230 and the default configuration is changed to be feeder node.

Workaround:

If dspswfunc shows the node to be routing node it can be configured to feeder using cnfswfunc.

CSCdr72963

Symptom:

When PSU fails, alarm event does not appear in dsplog. It appears on Eventlog of CWM.

Conditions:

This occurs when there is a power supply failure.

Workaround:

Get the PSU failure information from NMS, CWM. Also CLI command dspshelfalm gives status of PSU.

Further Problem Description:

Only trap is sent to CWM, the event is not logged.

CSCdr74393

Symptom:

APS bidirection non-revertive mode interoperability with Sentient does not work.

Condition:

APS interoperability with the Sentient.

Workaround:

None.

CSCdr76747

Symptom:

When using CNFBERT local loop or no loop due to having a hardware loop on the physical ports of a FRSM 8E1, it is observed that the BERT test does not run error free. Tests show that the local loop BERT test errors when using 1.1.23 but in previous 1.1.12 has zero bit error count. Test was reperformed using AUSM in 1.1.23 and zero bit errors were recorded.

Conditions:

Lab environments of both heavily loaded nodes or nodes with only PXM, FRSM, SRM.

Workaround:

None.

CSCdr76819

No known workaround. Fixed in 1.1.31.

CSCdr77088

Symptom:

Node hangs due to the back card going bad.

Conditions:

Sometimes when the back card is going bad, the line oscillate between OK and LOS condition. When this happen, there are flood of messages between the active and standby PXM.

Workaround:

Remove the bad back card.

CSCdr80198

Symptom:

The oldiags fails the framer test when run on a PXM1 with an OC-3 daughter card and debug level 3 is used.

Conditions:

PXM1 with OC-3 daughter card and oldiags is invoked with debug level 3.

Workaround:

Do not run oldiags with debug level 3. Use debug level 0-2.

CSCdr81334

Symptom:

VxWorks heap may have some leaks and some allocations of memory will fail.

Conditions:

This problem occurs only when there is a memory corruption or the memory partitions are full (or nearly full).

Workaround:

Reset the PXM.

CSCdr83869

Symptom:

There is no command to display trunk utilization.

Condition:

Applies to PXM release prior to 1.1.31.

Workaround:

None.

Further Info:

The command that has been introduced is dspportutil <port#>. The output of the command looks like this:

mgx524.1.7.PXM.a > dspportutil 1 Avg CPS Rcv to XmtQ = 1 Utilization = 0% Avg CPS Xmt to Port = 1 Utilization = 0%

Note that due the h/w limitations, the CPS and %util are only available for the egress direction. The first line is for the egress cells coming to the switch fabric and the second is for the egress cells leaving the switch fabric toward the physical ports. For a description of the h/w limitation refer to bug CSCdp03385.

The %util is with respect to the physical line cell rate.

To clear the counts use the existing commands: clrportcnt or clrportcnts.

There is no MIB support to access the counters. The counters are displayed only via the CLI command.

CSCdr86099

Symptom:

The clrportcnt does not clear the counter EgressPortQFullDiscardCells.

Condition:

When there is EgressPortQFullDiscardCells in the rt-vbr connection.

Workaround:

No workaround.

Further Problem Description:

This counter was not being cleared, this has been cleared in the fix.

CSCdr86885

Symptom:

Frames get DE Tagged even though DE Tagging is disabled.

Conditions:

When user pumps traffic greater than CIR, and Bc bucket becomes full, frames get DE tagged even though DE tagging is disabled.

Workaround:

There is no workaround.

CSCdr87800

Problem Description:

PVCs could be added on reserved VCCs, for example, with VPI = 0 and VCI between 0 and 31, without an appropriate warning message.

Fix:

A warning message is displayed now whenever a PVC is added on a reserved VCC.

Unit test:

Add a connection with VPI = 0 and VCI between 0 and 31. See that appropriate warning message is displayed, but channel addition goes through.

CSCdr88653

Symptom:

The chanDEtoCLPmap resets to default value whenever channel configuration is changed.

Conditions:

This will occur when ever user modifies the channel configuration after configuring chanDEtoCLPmap to the required value.

Workaround:

Whenever user wants to modify the channel configuration, chaneDEtoCLPmap has to be included in the channel configuration.

Further Problem Description:

This occurs because whenever the user modifies the channel configuration, chanDEtoCLPmap is reset to default values when user does not provide value to this object. So whenever user modifies other channel configuration, this object also has to be set to required value.

CSCdr89017

Symptom:

The oldiags will eventually use up all file descriptors on the system when run in a loop.

Conditions:

Run oldiags in a continuous loop.

Workaround:

None.

CSCdr90273

Symptom:

Connection gets added even though DLCI for the remote FR Port is not specified. This connections gets added with remote end's DLCI taken as 0.

Conditions:

This occurs when addcon command is executed without specifying the remote end's DLCI.

Workaround:

User has to enter the remote end's DLCI while adding the connection.

CSCdr90635

The xcnfcon displays the range of VPI/VCI as VPI 1-4095 (sometimes 0-255) and VCI 1-65536. Sometimes the display is Hex based as 0xff and 0xffff. The info needs to be correct and made consistent throughout.

CSCdr90909

Symptom:

The oldiags running on an MGX 8230 refers to slots 7 and 8 as PXM slots. Should be slots 1 and 2.

Conditions:

Issue oldclralm and the usage message is: USAGE: oldsplog <slot_number (7, 8)

Workaround:

None.

CSCdr95869

Symptom:

Programming the new Novram fails.

Condition:

The new Novram(AT93C66) required a different programming sequence.

Workaround:

None.

CSCdr98433

Symptom:

The PXM log is required for addition and deletion of SM redundancy.

Condition:

No logs while adding and deletion redundancy for SM.

Workaround:

Made changes to the code so that the logging will take place whenever addition or deletion of SM redundancy happens (files changed redUI.c and cliRedundancy.c in POP1PRET5 branch).

CSCdr98519

Symptom:

Login, logout, and all user commands must be logged.

Condition:

Rate limit was there for all the commands, so login, logout, and all user commands were not logged everytime.

Workaround:

The login, logout, and all user commands will be logged from now on. Files changed to cli_msgs.h in pop1pret5 branch.

CSCds00987

Symptom:

The display format for CLI dspchans was misaligned.

Condition:

Happens when the CLI dspchans executes in the presence of rt-VBR connections.

Workaround:

None.

CSCds01023

Symptom:

The xcnfportq with the option qa=0 disables the corresponding egress port Q.

Condition:

This display inconsistency exists in all firmware releases prior to 1.1.31.

Workaround:

Use cnfportq instead of xcnfportq.

Further Problem Description:

Even though an option of 0 is not displayed for the "-qa" option in xcnfportq, a value of 0 if specified is taken and the specified port queue is disabled. This seems to be conflicting with the range specified in the help. The help has now been fixed in 1.1.31 to display the extra option of setting qa to 0 to disable the queue.

CSCds01417

Symptom:

There is no range checking for port and queue numbers in case of CLI dspportq.

Condition:

When executing the CLI dspportq.

Workaround:

No workaround. The fix is taking care of range checking for port and queue numbers in CLI dspportq.

CSCds01472

Symptom:

The help string shows that the MaxLcn parameter for the CLI's cnfrscprtn, cnfportrscprtn, and xcnfrscprtn has a range of 1 to 1000, but 0 is accepted.

Conditions:

This happens whenever cnfrscprtn, cnfportrscprtn, and xcnfrscprtn are configured with MaxLcn as 0.

Workaround:

Do not use MaxLcn as 0 while configuring cnfrscprtn, cnfportrscprtn, and xcnfrscprtn.

CSCds03756

Symptom:

The object chanServType is missing in the TFTP config upload file.

Conditions:

When user uploads the TFTP config file, chanServType object is missing.

Workaround:

There is no workaround.

CSCds03905

Symptom:

Prior to the 1.1.31 release the default display for the shelf banner upon booting up is as following:

SES for SES-IGX product
MGX 8830 for MGX 8230 or MGX 8830
MGX 8850 for MGX 8250 or MGX 8850

Conditions:

With the 1.1.31 release onward, the default display for the shelf banner upon booting up is as following:

SES for SES-IGX product
MGX 8230 for MGX 8230 or MGX 8830
MGX 8250 for MGX 8250 or MGX 8850

The reason for changing the default banners from MGX 8830/MGX 8850 to MGX 8230/MGX 8250 in the 1.1.31 release is because the PNNI is required to be available in the 1.X release in order for the MGX 8250 and MGX 8850 products to be available. The PNNI is not currently available in the 1.X release, so it makes sense to default the shelf banner to the currently existing products (hence using 1.X image).

Workaround:

None.

CSCds04145

Symptom:

FRF.5 NIW frames may get dropped in the egress direction, because incoming DLCI is not set to 1022.

Condition:

When the FRF.5 NIW Interworking function switch looks for incoming DLCI and if it is not 1022, then it may drop the NIW frame.

Workaround:

None.

Problem Description:

While sending the FRF.5 NIW frame to the network, the DLCI is not set to 1022 as per the standard. So when the frame reaches the other end, NIW Interworking function may look for incoming DLCI, and it may drop if it is not set to 1022.

CSCds04697

Trap couldn't see beyond 700 connections because PXM allowed only up to 700 table entries. The size of this table now allows 2000 entries.

CSCds05006

Symptom:

If an SRM line with loopback is deleted, next time when this line is added again, the loopback value will not have the default "noloop". It will be the previous loopback value.

Condition:

Delete an SRM line and add it back again. The loopback value will be the previous value instead of default value.

Workaround:

Configure the desirable loopback value after adding a line.

CSCds05374

Symptom:

When user adds PVC on MGX service module to feeder trunk and leaves out the remote VPI.VCI in the syntax, the system accepts the command and adds a PVC with a remote VPI.VCI of 0.0.

The system should not accept this command and make the user add it again with correct syntax of: remote node.slot.port.VPI.VCI.

CSCds06755

Problem Description:

The AUSM xcnfilmi CLI command options do not match the "usage" message—the "mei" and "-ar" options are not displayed as available command line options. Also, option "-pti" is shown as usage option "-pt".

CSCds07411

Symptom:

FEAC DS3 OOF are seen at the far-end of a FRSM-2T3

Workaround:

Call the TAC. The workaround requires very experienced personnel.

CSCds09808

The rpmChanMidLow and rpmChanMidHigh are referred as to message ID for PVC connections. They are read-only numbers and are generated by addconn command. This is why you ca not change its content after it has been assigned by PXM.

0 is an invalid number, which is due to the connection unsuccessfully made across from one PXM to another PXM via a BPX. When you do dspconn, ABIT ALARM shown next to a connection is an indication that the connection was not made across.

CSCds11325

Symptom and Problem Description:

There were cases reported where the AUSM-8 card reset on its own mostly when SNMP sets were being done on the card. The AUSM-8 card used to report a "WatchDog Timeout Reset" to the PXM in these cases, which could be seen using the command dsplog on the PXM.

Conditions:

It was noted that in most cases, the WatchDog Timeout reset happened when SNMP scripts doing snmpsets were being run on the card. For example, when an SNMP script was continuously adding connections on the card using snmpsets.

Workaround:

None.

Detailed Problem Description and Attempted Fix:

The "WatchDog Timeout resets" were intermittent and did not happen very often. Though it could not be recreated in the lab premises, some potential causes were identified and were fixed accordingly. With these fixes, the problem is not expected to happen. Apart from these fixes, some additional logging utility has been added to the image so as to log additional information about the WatchDog reset if the reset happens again.

CSCds11410

Symptom:

The xcnfalmcnt command accepts any parameters and does not display any error messages.

Conditions:

When xcnfalmcnt command is executed with invalid parameters.

Workaround:

There is no workaround.

Problem Description:

The xcnfalmcnt command does nothing with the input parameters as this is feature is not implemented.

CSCds13806

Symptom:

Whenever an SM card is reset and the card remains stuck in boot state, even though the firmware versions of the SM are on disk.

Conditions:

This happens everytime a dspsmcnf command is issued on the PXM just before resetting an SM card.

Workaround:

Do not use the dspsmcnf command at any time. If it has to be used, then the shelf will have to be reset for the condition not to occur.

CSCds18765

The cnfupcabr on the AUSM-8 currently does policing on PCR(0+1) as the first leaky bucket and on SCR as the second leaky bucket. The second leaky bucket has to be changed to MCR, with an option of choosing the type of policing needed (already available).

Typically Standard ABR connections need to be policed only on one bucket i.e. the PCR(0+1) bucket. Currently VBR, rt-VBR and ForeSight ABR connections have two buckets each for policing - PCR(0+1) and SCR. Standard ABR policing needs to be done on PCR(0+1) only. But for consistency with the PXM (cnfupcabr), Std ABR policing will be done on PCR(0+1) as the first bucket and with ABR-MCR as the second bucket, with an option in cnfupcabr to turn second bucket policing off (as is with SCR for ForeSight ABR).

But it is important to note that during firmware Upgrade, especially for existing abr.1 connections (Transparent ABR connections with ForeSight disabled), policing will still be done based on SCR value immediately after Upgrade. This is to avoid sudden traffic pattern changes during Upgrade. The user should know that for all commands executed here after (after Upgrade) whenever the ABR MCR value is changed, the policing function will get affected since policing for Standard ABR connections will be done on MCR.

The command help for cnfupcabr has been modified. The new cnfupcabr has changes in the SCR parameter description.

CSCds22296

Symptom and Problem Description:

The atmfAtmLayerMaxVciBits object returns a value of 12 when queried from the CPE via ILMI. Because of this VCIs greater that 4095 cannot be added to interoperate with the CPE.

Workaround:

None.

Fix made:

Changed atmfAtmLayerMaxVciBits to 16 from 12.

Test setup:

1. Do an SNMP query on atmfAtmLayerMaxVciBits and check if it returns 16.

2. There should be no problems in adding a PVC on the router with VCI greater than 4095.

CSCds22476

Symptom:

The port takes a long time to come out of failure even though ILMI Keepalive polling is enabled on both ends.

Condition:

The incoming PDUs ID is not checked against the ILMI request ID.

Workaround:

No workaround.

CSCds22479

Symptom:

The port will not change state even though the Keepalive ILMI polling is enabled/disabled.

Condition:

When the ILMI Keepalive polling is enabled/disabled the port status does not change accordingly (it does not go into ILMI signaling failure/ come out of ILMI signaling failure).

Workaround:

No workaround.

CSCds22483

Symptom:

The address registration is not disabled when ILMI signaling is disabled.

Condition:

When disabling ILMI on a port using the cnfilmi CLI the address registration option is enabled (cnfilmi <portno> 2 0 16 2 1 2 2).

Workaround:

While disabling ILMI on a port also disable address registration (cnfilmi <portno> 2 0 16 1 1 1 1).

CSCds22489

Symptom:

If a port, down due to ILMI failure is deleted and added again, the ILMI failure on the port does not clear.

Condition:

The port alarm is not cleared when the ILMI is cleared.

Workaround:

The ILMI port alarm should be clear by enabling ILMI keepalive polling and then the port is to be deleted.

CSCds23602

Symptom:

The BERT pattern test for FRSM-8T1 and CESM-8T1 cards reports a high Bit Error Rate.

Conditions:

No specific conditions. Problem happens every time a BERT test is run on FRSM-8T1 and CESM-8T1 cards.

Workaround:

On Active PXM, inside shellConn set the flag newPxmWithOldSmPre1130 to 1.

CSCds23604

Symptom:

In AUSM, the xcnfilmi command has two display errors.

1. VPI <VirtualPathId> where VirtualPathId = 1 - 255. The VPI range should be 0-255.

2. PTI <PortNum> where PortNum = 1 - 8. The actual option should be -pt and -pti which is not accepted.

Condition:

This display error is present in all firmware releases prior to 1.1.31.

Workaround:

None.

CSCds24045

Symptom:

RPM connections are lost after an upgrade from 1.1.24 to 1.1.30(1.1.24Or)

Conditions:

It happens under all conditions.

Workaround:

None.

Further Description:

The customer upgraded a single PXM shelf from 1.1.24 to 1.1.24Or. After the upgrade dspcons shows connections but on RPM it shows that the connections exist only in RPM. Now a resetsys after this point causes all the connections to disappear.

CSCds24602

Symptom:

Data loss after an AUSM E1 card reset.

Condition:

This problem happens on all AUSM E1 cards with firmware version prior to 1.1.31.

Workaround:

Execute the cnfplpp command and disable the scramble option. Note that though dspplpp shows no scrambling, the actual framer programming is not done. The cnfplpp command takes care of that problem.

Unit test after fix:

One test that can be done is to have an IMA group active on the card with the lines in the IMA group configured in the "No Scramble" mode. Have connections on this IMA group with traffic flowing. Do a resetcd and confirm that the IMA group is not down, and traffic continues to flow on the connections.

CSCds25992

The command cnfplpp configures a line even when the line has not been added/enabled.

CSCds26096

Symptoms:

The dspplpp command asks the user to enter the "port_num" instead of "phy_port_num" as in xcnfportq. This can be confusing since the physical port number corresponds to the line number, and port number corresponds to the logical port number (which can be different from physical port number).

Conditions:

This is a display error, and is present in all firmware releases except prior to 1.1.31.

Workaround:

None.

Further Problem Description:

Since the dspplpp command prompts the user to enter port_num, it is possible that the user enters the logical port number, and does not get the expected display. This has been corrected now to display "phys_port_num".

CSCds27682

Symptom:

The dspalmcnt on an AUSM/B on an 8250 does not seem to register code errors on the physical line.

Conditions:

Happens on 1.1.25 AUSM firmware.

Workaround:

None.

CSCds32838

Information on this anomaly is unavailable at this time.

CSCds35958

O/p drivers are getting disabled when rd_bcE2prom is invoked.

CSCds38406

Symptom:

After a switchcc the prompt still shows "s" (for standby), when the card is actually active.

Conditions:

When using the console port for accessing the node.

Workaround:

Cc to any other card and cc back.

Further Problem Description

This problem does not occur when the node is accessed during Telnet sessions.

CSCds49185

The dspcds commands occasionally hang, causing access to the Telnet and maintenance ports to be blocked. This bug was resolved in Release 1.1.31.


Problems Fixed in Release 1.1.25

Bug ID
Description

CSCdr19456

Symptom:

The CLI of the AUSM card hangs and then the AUSM card reboots when a number of ILMI (atmfVpcVpi) requests are received by the card.

Condition:

The time gap between two ILMI (atmfVpcVpi) requests arriving at the card is too small (the rate at which the ILMI requests arriving is high).

Workaround:

The rate at which the ILMI (atmfVpcVpi) requests to be received by the card should be less than two requests per second.

CSCdr42989

Symptom:

The AUSM card generates excessive traps.

Condition:

PLPP, port, and IMA link traps are generated in excess for small bit errors on the line.

Workaround:

None.

CSCdr45128

If the primary clock is configured as inband, the dspclkinfo hardware status may shows the clock as internal even though it is inband.

CSCdr61335

Symptom:

The card gets reset.

Conditions:

The card gets reset when a continuous getnext operation on the atmfVccEntry MIB group is done via the ILMI protocol from the CPE side.

Workaround:

None.

Further Problem Description:

This is happening because one of the semaphores was not being released. Another thing was that the maxilmicells was changed from 100 to 6. This was done in order to prevent the ILMI task from hogging the CPU.

CSCdr63753

Symptom:

The Stratacom Axis Shelf correctly translates Q.933 PDUs from ATM to FR. The Axis shelf correctly translates an X.25 PDU ATM to FR to pass. X.25 PDUs with I Frame values of 0x03 0x08 FR to ATM are incorrectly translated to Q.933 PDUs. The Axis Shelf discards all X.25 1490 PDUs with and I-Frame not equal to 0x03 0x08. When PDUs are discarded, Stratacom View (9.0.03.SOL.Patch1) does show PDUs were received/transmitted but fails to show that they were discarded. Using the CLI command dspchancnt, the statistics Frames Discarded: and RcvFramesUnknownProtocols/XmtFramesUnknownProtocols were pegged on the Axis Shelf.

Conditions:

Workaround:

CSCdr72788

Symptom:

When an ATM port is added with different line and port numbers, the ATM cell delineation alarm never clears.

Condition:

This occurs when the ATM port is added with different line and port numbers.

Workaround:

Use the same number for both the line and port numbers. This has been corrected in the fix.

CSCdr82101

Symptoms:

On an ABR.1 connection (ABR with ForeSight disabled), the PCR(0+1) was changed (after adding the connection to something lower than the value it currently holds), further operations on this channel (via CLI or snmpset) fail.

Conditions:

On an ABR.1 connection (ABR with ForeSight disabled), the PCR(0+1) was changed after adding the connection to something lower than the value it currently holds, further operations on this channel (via CLI or snmpset) would fail. This is because the PCR(0+1) change would change the values of ForeSightPIR and ForeSightQIR, but leave the value of ForeSightMIR unchanged. ForeSightMIR used to have a higher value than ForeSightPIR and ForeSightQIR (after the snmpset) thereby causing further commands on this channel to fail.

Workaround:

This problem has been corrected. When PCR(0+1) is changed, it will be reflected in all three values (ForeSightPIR, ForeSightQIR, and ForeSightMIR).

CSCdr82560

Symptom:

When FRSM-2CT3 and FRSM-8 are connected on the line side and CLLM is enabled between them, FRSM-8 drops the CLLM messages sent by FRSM-CT3. Also FRSM-2CT3 cannot support CLLM timers as low as 40 ms.

Conditions:

The CLLM messages FRSM-8 drops do not carry congestion information. Hence it does not affect anything. But if the FRSM-8 is sending in CLLM messages at 100 ms then FRSM-2CT3 starts drop LMI/CLLM messages as the queue for both is common. This may lead to port alarm transitions.

Workaround:

For the first issue of FRSM-8 drop the CLLM messages there is no workaround but this problem is fixed in 1.30. For the case where FRSM-2CT3 cannot handle CLLM messages at 100 ms, the CLLM timer has to be set at least 250 ms as 2CT3 cannot support anything less.

CSCdr86692

Symptom:

The PXM is stuck in the initialized state due to a bad back card and a PXM7 cold solder problem.

Workaround:

None.

CSCdr89759

Symptom:

Traps are sent with reversed VPI and VCI values.

Conditions:

This occurs when a VCC is setup or deleted.

Workaround:

None. This has been fixed.

CSCdr89898

Symptom:

Card gets reset during connection provisioning using SNMP.

Conditions:

Back-to-back SNMP connection ADD requests will cause a reset to the FRSM-2CT3.

Workaround:

There is no concrete workaround. Introduce enough delay in the SNMP connection provisioning script.

CSCdr90170

This happens only when data flow is required between RPM and PXM over IPC channels, such as dir c: file transfer type of activities. This error message posts a warning due to IPC master and slave but does not impact IPC operations. The message appears on the console but not on the PXM syslog.

CSCdr92751

Symptom:

The card gets reset.

Conditions:

In case of Softswitch.

Workaround:

None.

Further Problem Description:

We are ignoring the config change trap when the card is not active. Also, the addimagrp trap is not sent during any card rest/Softswitch. Note that statistic requests are processed only after the card is active.

CSCds01770

Symptom:

During a manual switchCC, as the standby PXM is active, a few nonreentrant APIs are called by tasks that were waiting to go ACTIVE on standby PXM. SnmpFeRx is an example. This task calls system_initialize(). During this period, if an SNMP request is made by NMS for the MIB-2 SYstem group, the request calls the same API. As the API is nonreenterant, it causes an exception and the snmpAgent task is suspended, which causes PXM to reset.

Workaround:

None.

CSCds02301

Symptom:

None

Workaround:

A new feature to provide SNMP set switchCoreCard. This feature was backported from the 1.1.31 release to the 1.1.25 so that the PXM image can be built successfully.

CSCds16745

Symptom:

GR253 standards are not adhered to in APS unidirection mode mismatch conditions.

Workaround:

None

CSCds24088

Symptom:

Memory leaks on the hot standby card leads to the resetting of the standby.

Conditions:

Channel row status is CHAN_ADD and a connection resync starts on active.

Workaround:

1. Before you run out of memory, use a channel modify to change the chanRowStatus from CHAN_ADD to CHAN_MOD. This should be done immediately after adding the connection.

2. If you are already out of memory or have very low memory, then do a Softswitch and switchback.


Problems Fixed in Release 1.1.24

Bug ID
Description

CSCdp55281

Symptom:

Missing RPM resource partition (rpmrscprtn) line in configuration file.

Conditions:

When trying to add PVCs to an RPM module, you may be prevented from doing so. This is caused by a missing rpmrscprtn line in the configuration file running the configuration. This problem can occur if the PXM is busy when it receives an rpmrscprtn command update from the PXM. If the RPM times out after a request to the PXM, the rpmrscprtn configuration line will be missing from the running configuration file. This problem does not affect traffic or the addition of new connections.

Workaround:

Ensure that the rpmrscprtn configuration line is present in the running configuration file before resetting the RPM card, then save the running configuration file to the startup configuration. This will avoid the confusion of this line not being present in the running configuration. This command can be reexecuted on the RPM if it is missing. Please ensure that the parameters match with the PXM side. This can be checked by displaying the resource partition view on the PAR.

CSCdr05630

Symptom:

MGX 8850 Switch shelf resets with an TlbLoadException error from tDispatch as follows:

Tlb Load Exception
Exception Program Counter: 0x80127fac
Status Register: 0x3000ff01
Cause Register: 0x00000008
Access Address : 0xc8787854
Task: 0x82a485b0 "tDispatch"

Conditions:

The shelf resets when the RPM is stressed; specifically, 3000-byte UDP packets loaded at -9.8 MB on e1/4 and approximately 170 kbps worth of s on e1/1.

Workaround:

None.

CSCdr19633

Symptom:

On an AUSM-8T1/E1, the IMA group name matched to an individual line forces the group to go down.

Conditions:

When a line is configured with the IMA group name, then the entire IMA group goes down if the line goes down.

Workaround:

Do not use the same name for the IMA group as the name given to the lines used.

Evaluation:

For AUSM card, when a line goes down, if there is a port(s) within the line, AUSM always send a porttrap to PXM. If the line is one of the links in an IMA GROUP, there is no porttrap except if the available number of links is less than the configured minimum.

This means that when PXM receives linetrap, for AUSM card, it does not need to generate porttrap, which will fix the problem.

CSCdr34252

Symptom:

Management PVC between the MGX 8850 and remote equipment fails after Softswitch of AUSM cards.

Conditions:

After Softswitch is performed the PVC that passes management traffic between devices stops passing through the PXM.

Workaround:

None.

Further Problem Description:

Management IP connections added from service modules to 7.34 fail to pass data after a switch over occurs from the primary to the secondary.

CSCdr35117

Symptom:

The PXM shelf resets when the RPM is under stress.

Condition:

This problem occurs when the RPM is loaded with an enclosed configuration and traffic is generated toward CARed interfaces with CBWFQ.

Workaround:

None.

Further Problem Description:

The IOS IPC code on PXM was not handling NAK messages from RPM correctly. The code was not checking to see if the port (polling port) the NAK is received for still exists or not (checking for NULL pointer). This cause access to invalid address and eventually shelf reset.

CSCdr38391

Symptom:

Running the clrsmcnf command on a CESM and resetting the standby PXM causes the card to come up in cardinit state.

Workaround:

None. The code has been modified to pass LCN index zero instead of firstdatalcn.

CSCdr42987

Symptom:

End-to-end OAM cells are dropped by the AUSM-8T1/E1 card.

Conditions:

As of Release 5.0.11, AUSM-8T1/E1 dropped end-to-end loopback cells other than AIS, RDI, and Loopback function types in Fault Management OAM cell type. This problem is now corrected so that the end-to-end OAM cells pass through the AUSM-8T1/E1 card though the card does not monitor all of them.

Workaround:

None.

CSCdr49478

Symptom:

After a sequence of adding and deleting service module redundancy and issuing the clrsmcnf command, and connection deletion/addition, the command tstcon does not pass on certain connections.

Conditions:

This problem occurs when a 1:1 redundancy is configured between VHS cards in
slot 1 and slot 2. Card 1 is active, and card 2 is standby. Connections are added from 1 to 5. Then, redundancy deleted and connections deleted both on slot 1 and on slot 5 using the clrsmcnf command. Redundancy was then added between slots 1 and 5, and subsequently deleted.

Note that the connection addition was done in an environment wherein no connections existed either on slot 5, slot 1, or slot 2.

Workaround:

1. Use CWM or the CLI to delete connections on both slots when a service module is configured with redundancy.

2. Then issue the command clrsmcnf to clear the port/line configuration.

CSCdr51248

Symptom:

A mismatch is reported due to a MIB corruption since the new versions of VISMs need larger allocation of memory for the MIB.

Workaround:

None.

CSCdr55023

Symptom:

ARP translation doesn't work on FRSM-2CT3. Both the destination and the source IP addresses get corrupted in the ARP reply.

Conditions:

This problem occurs when ARP request is initiated from the ATM side. This problem does not occur if ARP request is initiated from the FR CPE side.

Workaround:

One of the following:

1. Use a static IP address instead of ARP.

2. Initiate ARP request from FR CPE.

CSCdr61548

Symptom:

The card resets/fails when more than 600 connections are added when LMI is configured on the port.

Condition:

LMI packets gets corrupted after 600 connections, and subsequently leads to problems during the ESE-SAR handshake. This causes ESE to stop.

Workaround:

No workaround for more than 600 connections.

CSCdr62285

Symptom:

The CESM module generates a general error.

Conditions:

When the command cnfbert is issued, the causes the CESM module to generate the error.

Workaround:

None.


Problems Fixed in Release 1.1.23

Bug ID
Description

CSCdp80130

The dspapsln shows both APS lines to be OK when alarm exists.

CSCdp88046

Slow TFTP GET and corrupted CF file checksum for SM with 3920 active chans.

CSCdm12468

PXM CLI cannot read NVRAM data for UI back card and trunk back card.

CSCdm73868

New IMA link failure trap 50251 is generated.

CSCdm82756

The MGX 8850 stores user passwords in clear text. Any person with IP connectivity to the MGX 8850 can TFTP the userPassword.dat file from the MGX 8850 and view all the passwords. Password are encrypted before saving in the database.

CSCdm83076

IMA Group failure status is Ne start up, whereas Ne is operational.

CSCdp12290

When deleting port, no trap should be sent if RSC partition diskupdate fails. Return value for resource partition deletion diskupdate message, as part of port deletion, is not checked before sending out the subsequent resource partition config change trap. Also, when one of the resource partition diskupdate fails, the port deletion process should stop.

CSCdp14073

A dspabit type command.

CSCdp20616

Cell-loss on PXM-UNI conn on switchover caused by SRM back card removal.

CSCdp43334

The BERT on the FRSM-VHS require the xcnfln, which has misleading parameters for the FRSM-T3 and FRSM-E3 service module. Although some parameters like -ds3enb (dsx3LineBERTEnable) also appear under the xcnfln for the FRSM-E3 card, but BERT could not be started with this parameter and it requires a different parameter -ds3ben (dsx3LineBERTEnable).

Some other times when BERT is enabled on one line, you could not delete the BERT from this line using deldsx3bert and hence forth BERT cannot be enabled on any other line.

CSCdp46146

Cannot delete RPM-RPM connection from the PXM.

CSCdp47079

Policing defaulted to off on certain PXM connection (VBR and ABR).

CSCdp50541

PXM-trunk-clocking goes bad on PXM-switchover. Periodic cell loss on FDR-conns.

CSCdp51846

INCS1.5: Slot failure on SRM brings down voice services CSCdp52180 MGX SRM fail/switchover outage time is unacceptable. CSCdp53887 Feeder connections could not be added via SNMP on AUSM.

CSCdp54765

Cannot add a port to a slot until card reset on FRSM-8T1/E1.

CSCdp57974

Need varbind for Configured Links in certain IMA traps.

CSCdp58707

The dspbecnt command does not work correctly for the non-active line currently.

CSCdp62456

Database integrity commands do not catch incomplete master conns.

CSCdp62652

No updated information about IMA Rx grp ID on AUSM.

CSCdp63757

FunctionModuleFailed Trap 50006 keeps repeating twice.

CSCdp65370

The port on the CESM-T3/E3 is in active state but the line is in RcvLOS alarm. When a T3 or E3 line indicates an alarm condition, the corresponding port state is not updated correctly. Port state is still displayed as active instead of failed due to line.

CSCdp65557/

CSCdp75117

Softswitch on AUSM causes 29 sec. channel outage. When you perform a Softswitch from Primary AUSM to Secondary AUSM in non-bulk mode, if system is very busy, the remote equipment may notice LOF or LOS. It is intermittent.

CSCdp65651

Need to support a new VSI force Del passthru to handle connection timeout. During the connection addition, if the timeout occurs in VSI slave, SPM will clean up all the resources allocated for the connection. It then sends HD Update Fail message to the SM. Both SM & SPM do not have the connection anymore but PAR still has the connection in its database. If the user try to read the connection, PAR will reject the request. The user can not delete the connection either since there is none in the SM.

CSCdp69367

Need to disable CLI session timeout when issuing clrsmcnf. The fix involves disabling the session timeout before clrsmcnf or restoresmcnf commands are carried out and re-enabling the session timeout period when complete.

CSCdp69416

Removal of back card on active APS line causes trunk and conn failure.

CSCdp70976

Arbitrary number of voice calls are dropped due to switchcc on PXM.

CSCdp75827

Values specified via cnflmitimer not preserved after switchcc/resetsy.

CSCdp75844

LMI timeout values specified via the cnflmitimer value not correct. Prior to this fix LMI timers had to be configured (using cnflmitimer command) to double the desired value of LMI timeout.

CSCdp75879

Signaling bits toggle in case of voltage disturbance on T1 input lea.

CSCdp76372

FRSM-2CT3 dspchancnt does not have KbpsAIR field.

CSCdp77244

Support port rate modification without deleting connections.

CSCdp80104

The dspapsln shows both lines in R_AM after alarm on one line was cleared.

CSCdp80154

The dspapsln shows one line in R_AM when both are.

CSCdp81205

When Protection Line was unplugged, it went into P_B state.

CSCdp81859

Introduce dspfail command to display failed connections.

CSCdp82888

PXM reset/switchcc causes the AUSM port to fail.

CSCdp84676

When the service module tries to do graceful upgrade PXM crashes.

CSCdp84773

Symptom:

The resource partition does not get registered on the PXM card.

Conditions:

The resource partitioning of the AUSM card on the PXM is registered as zero instead of a value of three. This process takes place automatically with the AUSM card. On the VISM, it is done by issuing the command addrscprtn.

CSCdp87088

CESM-8T1/E1 clock change to async mode on line causes bit errors on another line.

CSCdp88526

FRSM-2CT3 cards fail when script run to add 4000 conns.

CSCdp91587

The dsx3LineXmtClockSrc cannot be set to localClk on PXM T3.

CSCdp92627

Cannot add redundancy from primary AUSM slot 19 to 30.

CSCdp96495

FRSM-2E3 does not support G.751 clearchannel format.

CSCdp99561

Cannot disable policing on the FRSM-2CT3 if Bc & Be set to max.

CSCdp99581

FRSM-CT3 egress queue build up causing the ingress VCQ to start discard even though traffic was being generated at PIR, with no other VCs active.

CSCdp99795

The k:dspservrate does not show correct values.

CSCdr07429

The restoresmcnf not completely working.

CSCdr07460

The addlnloop on the PXM causes a bidirectional loop.

CSCdr08552

Not able to delete connections from SM after switchcc. In case of UNI connections, able to delete connections but dspcons still shows the connections.

CSCdr09310

VxWorks Ping hangs on receiving ICMP unreachable message from NMS.

CSCdr11405

PVC alarms on FRSM-2CT3 cleared by Softswitch.

CSCdr12167

Pulling active SRM causes IMA PVC to lose traffic w/o alarm.

CSCdr15904

Frames drop on FR-ATM PVCs.

CSCdr15904

Frames are getting dropped on FR-ATM PVC, reason is not shown.

CSCdr25595

/vob/psm/switchmgm/rmeptsm.c

In func rmRebindLcnEpt(), modified the code not to init the pEptBlk->state, pEptBlk->lmiStatus, pEptBlk->lmiChangeFlag if EptBlk already exists.


Compatibility Notes

MGX 8230/8250/8850 Software Interoperability with Other Products

Platform Software:

PXM 1.1.34

MGX 8220 Firmware:

Rev: 4.1.09 or 5.0.15 (Refer to the MGX 8220 Release Notes)

Compatible Switch Software:

Switch Software 9.2.33 release or higher for BPX and BXM firmware—MFF (Refer to the Switch Software Release Notes)

Network Management Software:

10.4.01 patch 1. Refer to the CWM 10.4.01 Release Notes.

The MGX 1x feeder to MGX 2x:

MGX 2.0.14.


Boot File Names and Sizes

The following table displays the boot file names and sizes for the Release 1.1.34.

File Name
File Size (in bytes)

ausm_8t1e1_AU8_BT_1.0.02.fw

377836

cesm_8t1e1_CE8_BT_1.0.02.fw

264592

cesm_t3e3_CE8_BT_1.0.02.fw

303936

frsm_8t1e1_FR8_BT_1.0.02.fw

297988

frsm_hs1_HS1_BT_1.0.02.fw

293052

frsm_vhs_VHS_BT_1.0.02.fw

467156

rpm-boot-mz.122-2.T2

2507264

vism_8t1e1_VI8_BT_2.0.03.fw

245232


MGX 8250/8850 Firmware Compatibility

The following firmware compatibility matrix is for System Release 1.1.34.

PCB Description
CW2000 Name
Latest F/W
Min F/W
File Name
File Size
(in bytes)

PXM1

PXM-1

1.1.34

1.1.34

pxm_1.1.34.fw

2290084

PXM1-2-T3E3

PXM1-2T3E3

1.1.34

1.1.34

pxm_1.1.34.fw

2290084

PXM1-4-155

PXM1-4OC3

1.1.34

1.1.34

pxm_1.1.34.fw

2290084

PXM1-1-622

PXM1-OC12

1.1.34

1.1.34

pxm_1.1.34.fw

2290084

MGX-SRM-3T3/B

SRM-3T3

n/a

n/a

n/a

n/a

AX-CESM-8E1

CESM-8E1

10.0.22

10.0.22

cesm_8t1e1_10.0.22.fw

677872

AX-CESM-8T1

CESM-8T1

10.0.22

10.0.22

cesm_8t1e1_10.0.22.fw

677872

MGX-AUSM-8E1/B

AUSMB-8E1

10.0.22

10.0.22

ausm_8t1e1_10.0.22.fw

1194784

MGX-AUSM-8T1/B

AUSMB-8T1

10.0.22

10.0.22

ausm_8t1e1_10.0.22.fw

1194784

MGX-CESM-T3

CESM-T3

10.0.22

10.0.22

cesm_t3e3_10.0.22.fw

606768

MGX-CESM-E3

CESM-E3

10.0.22

10.0.22

cesm_t3e3_10.0.22.fw

606768

AX-FRSM-8E1/E1-C

FRSM-8E1

10.0.22

10.0.22

frsm_8t1e1_10.0.22.fw

831008

AX-FRSM-8T1/T1-C

FRSM-8T1

10.0.22

10.0.22

frsm_8t1e1_10.0.22.fw

831008

MGX-FRSM-HS2

FRSM-HS2

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2CT3

FRSM-2CT3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2T3E3

FRSM-2T3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2T3E3

FRSM-2E3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-HS1/B

FRSM-HS1/B

10.0.22

10.0.22

frsm_hs1_10.0.22.fw

761040

MGX-VISM-8T1

VISM-8T1

2.1(0)

2.1(0)

vism_8t1e1_002.001.000.000.fw

2281512

MGX-VISM-8E1

VISM-8E1

2.1(0)

2.1(0)

vism_8t1e1_002.001.000.000.fw

2281512

MGX-RPM-128M/B

RPM

12.2(2)T2

12.2(2)T2

rpm-js-mz.122-2.T2 (IOS)

8202580

MGX-RPM-PR

RPM-PR

12.2(2)T2

12.2(2)T2

rpm-js-mz.122-2.T2 (IOS)

8202580


MGX 8230 Firmware Compatibility

The following firmware compatibility matrix is for System Release 1.1.34.

PCB Description
CW2000 Name
Latest F/W
Min F/W
File Name
File Size
(in bytes)

PXM1

PXM-1

1.1.34

1.1.34

pxm_sc_1.1.34.fw

2288416

PXM1-2-T3E3

PXM1-2T3E3

1.1.34

1.1.34

pxm_sc_1.1.34.fw

2288416

PXM1-4-155

PXM1-4OC3

1.1.34

1.1.34

pxm_sc_1.1.34.fw

2288416

PXM1-1-622

PXM1-OC12

1.1.34

1.1.34

pxm_sc_1.1.34.fw

2288416

MGX-SRM-3T3/B

SRM-3T3

n/a

n/a

n/a

n/a

MGX-SRM-3T3/C

SRM-3T3

n/a

n/a

n/a

n/a

AX-CESM-8E1

CESM-8E1

10.0.22

10.0.22

cesm_8t1e1_10.0.22.fw

677872

AX-CESM-8T1

CESM-8T1

10.0.22

10.0.22

cesm_8t1e1_10.0.22.fw

677872

MGX-AUSM-8E1/B

AUSMB-8E1

10.0.22

10.0.22

ausm_8t1e1_10.0.22.fw

1194784

MGX-AUSM-8T1/B

AUSMB-8T1

10.0.22

10.0.22

ausm_8t1e1_10.0.22.fw

1194784

MGX-CESM-T3

CESM-T3

10.0.22

10.0.22

cesm_t3e3_10.0.22.fw

606768

MGX-CESM-E3

CESM-E3

10.0.22

10.0.22

cesm_t3e3_10.0.22.fw

606768

AX-FRSM-8E1/E1-C

FRSM-8E1

10.0.22

10.0.22

frsm_8t1e1_10.0.22.fw

831008

AX-FRSM-8T1/T1-C

FRSM-8T1

10.0.22

10.0.22

frsm_8t1e1_10.0.22.fw

831008

MGX-FRSM-HS2

FRSM-HS2

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2CT3

FRSM-2CT3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2T3E3

FRSM-2T3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-2T3E3

FRSM-2E3

10.0.23

10.0.23

frsm_vhs_10.0.23.fw

939540

MGX-FRSM-HS1/B

FRSM-HS1/B

10.0.22

10.0.22

frsm_hs1_10.0.22.fw

761040

MGX-VISM-8T1

VISM-8T1

2.1(0)

2.1(0)

vism_8t1e1_002.001.000.000.fw

2281512

MGX-VISM-8E1

VISM-8E1

2.1(0)

2.1(0)

vism_8t1e1_002.001.000.000.fw

2281512

MGX-RPM-128M/B

RPM

12.2(2)T2

12.2(2)T2

rpm-js-mz.122-2.T2 (IOS)

8202580

MGX-RPM-PR

RPM-PR

12.2(2)T2

12.2(2)T2

rpm-js-mz.122-2.T2 (IOS)

8202580


Compatibility Matrix

This multiservice gateway comparison matrix is designed to identify capabilities supported in the MGX 8220, 8230, 8250, and 8850 platforms.

Feature
MGX 8220
MGX 8230
MGX 8250
MGX 8850, PXM1
Slot Capacity


Total Number of Slots

16 single-height

14 single-height/
7 double-height, or combination

32 single-height/
16 double-height, or combination

32 single-height/
16 double-height, or combination

Slots for Processor cards (PXM1s)

2 single-height (plus 2 slots reserved for BNM)


2 double-height


2 double-height


2 double-height

Slots for Service Modules (SMs)

10 single-height

8 single-height/
4 double-height or combination

24 single-height/ 12 double-height, or combination

24 single-height/
12 double-height combination

Slots for SRM Cards

(Service Resource Modules)


2 single-height


2 single-height


4 single-height


4 single-height


Physical Attributes
8220
8230
8250
8850

Height (in inches)

8.75

12.25

26.25 to 29.75

26.25 to 29.75

Width (in inches)

17.45

17.72

17.72

17.72

Depth

20.0

23.5

21.5

21.5


Services
8220
8230
8250
8850

MPLS (IP +ATM)

No

Yes

Yes

Yes

Voice

No

Yes

Yes

Yes

ATM

Yes

Yes

Yes

Yes

Frame Relay

Yes

Yes

Yes

Yes

Frame Relay-to-ATM network interworking

Yes

Yes

Yes

Yes

Frame Relay-to-ATM service interworking

Yes

Yes

Yes

Yes

Circuit Emulation

Yes

Yes

Yes

Yes


Local Switching
8220
8230
8250
8850


No

Yes

Yes

Yes


PNNI Routing
8220
8230
8250
8850


No

Future—will require upgrade

Future—will require upgrade

Future on PXM1


BPX Feeder
8220
8230
8250
8850

Feeder to BPX 8600

Yes

Yes

Yes

Yes

Feeder to MGX 8850 PXM-45

No

Yes

Yes

Yes

Feeder to IGX

No

Yes

No

No


Automatic Protection Switching
(APS 1+1)
8220
8230
8250
8850


No

Yes

Yes

Yes


Switching Capacity
8220
8230
8250
8850


320 Mbps

1.2 Gbps

1.2 Gbps

1.2 Gbps


Trunk/Port Interfaces
8220
8230
8250
8850

T3/E3

1

2
(one feeder trunk)

2
(one feeder trunk)

2

OC-3c/STM-1

1

4
(one feeder trunk)

4
(one feeder trunk)

4

OC-12c/STM-4

No

1

1

1

OC-48c/STM-16

No

No

No

No

n x T1/E1

Yes

Yes

Yes

Yes


Service Module Front Cards
8220
8230
8250
8850

AX-FRSM-8T1

Yes

Yes

Yes

Yes

AX-FRSM-8E1

Yes

Yes

Yes

Yes

AX-FRSM-8T1-C

Yes

Yes

Yes

Yes

AX-FRSM-8E1-C

Yes

Yes

Yes

Yes

MGX-FRSM-HS2

Yes

Yes

Yes

Yes

AX-FRSM-HS1

Yes

No

No

No

MGX-FRSM-HS1/B

Yes

Yes

Yes

Yes

MGX-FRSM-2T3/E3

No

Yes

Yes

Yes

MGX-FRSM-2CT3

No

Yes

Yes

Yes

AX-AUSM-8T1

Yes

No

No

No

MGX-AUSM-8T1/B

Yes

Yes

Yes

Yes

AX-AUSM-8E1

Yes

No

No

No

MGX-AUSM-8E1/B

Yes

Yes

Yes

Yes

AX-IMATM-8T1/B

Yes

No

No

No

AX-IMATM-8E1/B

Yes

No

No

No

AX-CESM-8T1

Yes

Yes

Yes

Yes

AX-CESM-8E1

Yes

Yes

Yes

Yes

MGX-CESM-T3E3

No

Yes

Yes

Yes

AX-SRM-T1E1/B

Yes

No

No

No

AX-SRM-3T3

Yes

No

No

No

MGX-SRM-3T3/B

Yes

No

Yes

Yes

MGX-SRM-3T3/C

Future

Yes

Yes

Yes

MGX-VISM-8T1

No

Yes

Yes

Yes

MGX-VISM-8E1

No

Yes

Yes

Yes

MGX-RPM-128/B

No

Yes

Yes

Yes

MGX-RPM-PR

No

Yes

Yes

Yes

PXM1

No

8230PXM1

8250PXM1

PXM1

PXM1-2T3E3

No

8230PXM1-2T3
8230PXM1-2E3

8250PXM1-2T3
8250PXM1-2E3

PXM1-2T3E3

PXM1-4-155

No

8230PXM1OC3-SIR

8230PXM1OC3-SLR

8230PXM1OC3-MMF

8250PXM1OC3-SIR

8250PXM1OC3-SLR

8250PXM1OC3-MMF

PXM1-4-155

PXM1-1-622

No

8230PXM1OC12-SIR

8230PXM1OC12-SLR

8250PXM1OC12-SIR

8250PXM1OC12-SLR

PXM1-1-622

PXM45

No

No

No

No


Back Cards
8220
8230
8250
8850

AX-SMB-8E1

Yes

Yes

Yes

Yes

AX-RJ48-8E1

Yes

Yes

Yes

Yes

AX-RJ48-8T1

Yes

Yes

Yes

Yes

AX-R-SMB-8E1

Yes

Yes

Yes

Yes

AX-R-RJ48-8E1

Yes

Yes

Yes

Yes

AX-R-RJ48-8T1

Yes

Yes

Yes

Yes

MGX-SCSI2-2HSSI/B

Yes

Yes

Yes

Yes

MGX-12IN1-4S

Yes

Yes

Yes

Yes

MGX-BNC-2T3

No

Yes

Yes

Yes

MGX-BNC-2E3

No

Yes

Yes

Yes

MGX-BNC-2E3A

No

Yes

Yes

Yes

MGX-BNC-3T3-M

Future

Yes

Yes

Yes

PXM1-UI

No

Yes

Yes

Yes

MGX-MMF-4-155/B

No

Yes

Yes

Yes

MGX-SMFIR-4-155/B

No

Yes

Yes

Yes

MGX-SMFLR-4-155/B

No

Yes

Yes

Yes

MGX-SMFIR-1-622/B

No

Yes

Yes

Yes

MGX-SMFLR-1-622/B

No

Yes

Yes

Yes

MGX-RJ45-FE

No

Yes

Yes

Yes

MGX-MMF-FE

No

Yes

Yes

Yes

MGX-RJ45-4E

No

Yes

Yes

Yes

SMB-8-T3

No

No

No

No

SMB-8-E3

No

No

No

No

MMF-8-155-MT

No

No

No

No

SMFIR-8-155-LC

No

No

No

No

SMFLR-8-155-LC

No

No

No

No

SMFIR-2-622

No

No

No

No

SMFLR-2-622

No

No

No

No

SMFLR-1-2488

No

No

No

No

SMFXLR-1-2488

No

No

No

No


Special Installation and Upgrade Requirements

Existing customers should use the upgrade procedure Service Module Upgrades to upgrade. A graceful upgrade from any release previous to 1.1.34 is supported. For new customers, the image will be pre-installed as 1.1.34 and should use the PXM installation procedure to upgrade to future maintenance releases.

A graceful upgrade from any release previous to 1.1.34 is supported, but a graceful downgrade is not supported. Abort or fallback to the previous release is supported at any stage during the upgrade. For abort instructions, refer to Instructions to Abort Upgrade.

Special Instructions for Networks Containing FRSM 2 CT3

Under certain conditions with the FRSM 2 CT3, a script must be ran in order to properly upgrade from previous releases to Release 1.1.34. The script resolves the FREEDM buffer issue described inanomally CSCds66176; namely, that ports are lost sometimes after softswitch or resetcd. The algorithm to allocate FREEDM buffers was changed in order to fix this anomally. Because of the algorithm change, ports might be lost when upgrading from a release (FRSM version < 10.0.22) with the older algorithm. The script identifies cards which will lose ports if the card is upgraded to Release 1.1.32 or greater.

A README file contained in the Release 1.1.34 TAR file located on CCO describes how to run the script and shows an example of the script output.

Executing the Script

Execute the script:

On all shelves with FRSM-2CT3 prior to an upgrade from any version to Release 1.1.32 ( FRSM VHS version 10.0.22) or higher.

For upgrades from releases prior to Release 1.1.32 for the MGX 8250, MGX 8230, or MGX 8850. To fix this issue, an algorithm change was made in Release 1.1.32 (10.0.22 version of FRSM 2 CT3).

Script Functionality

The script applies the new algorithm for buffer allocation to existing ports to determine if all the ports will remain intact during the upgrade process. After application of the new algorithm, a log file is created for each FREEDM chip on all the FRSM 2CT3 cards on the shelf. The log file contains confirmation that the buffer allocations are OK or NOTOK. If the log file contains NOTOK for a card, then upgrading the card to the new release will cause the card to lose ports. Therefore, ports must be moved to another card before upgrading this card.

Single PXM Installation Procedure


Step 1 Save your current configuration.

saveallcnf

Step 2 Get the filename by listing the CNF directory:

        node-prompt> ll "C:/CNF"
          size          date       time       name
        --------       ------     ------    --------
             512    APR-08-1999  08:16:18   .                 <DIR>
             512    APR-08-1999  08:16:18   ..                <DIR>
             512    APR-09-1999  05:26:42   TMP               <DIR>
           45433    APR-09-1999  05:28:42   NODENAME_0409990528.zip
           45433    APR-09-1999  05:28:42   NODENAME.zip
        In the file system :
            total space :  819200 K bytes
            free  space :  787787 K bytes

Step 3 On the workstation, upload the saved configuration to the workstation:

        unix-prompt> tftp shelf.ip.address
        tftp> bin
        tftp> get CNF/NODENAME_0409990528.zip
        Received 45433 bytes in 0.4 seconds

Step 4 Download the 1.1.34 PXM Backup boot image to the PXM .

tftp <node_name or IP address>
bin
put pxm_bkup_1.1.34.fw @PXM.BT
quit

Step 5 Download the 1.1.34 PXM runtime image to the PXM.

tftp <node_name or IP address>
bin
put pxm_1.1.34fw @PXM.FW
quit

Step 6 Download the ComMat.dat file to the C:/fw directory of the Active PXM. Use the TFTP put command:

tftp <node_name or IP address>
bin
put ComMat.dat
quit

Step 7 On the PXM type the following when the transfer is done:

copy ComMat.dat /FW/ComMat.dat

Step 8 Execute the install bt 1.1.34.

Step 9 Execute install 1.1.34 command.

Step 10 Answer Yes to the question the install command will ask.

PXM.a> install 1.1.34
redundancy is not available
the other card is not available
you are not in redundant mode,
do you want to try an ungraceful upgrade
(yes or no)?yes


Installation Procedure for Redundant PXMs

This section applies to upgrades from 1.1.23, 1.1.25, or 1.1.32.


Caution Do not remove old firmware until the upgrade is done.

During the graceful upgrade procedure, if after the newrev command the non-active card enters the "MISMATCH" state, do the normal commit command. You will get a warning message:

other card not found,

do you still want to complete the commit operation

Answer yes and then reset the non-active card.

If you get the MISMATCH during the upgrade process, after you finish, you will also get the MISMATCH. To correct the mismatch, you must check your back cards; they must be identical.


Note First you must ensure that the shelf IP address and the PXM IP address are set. The PXM must have its own unique IP address and there must be a another unique IP address for the shelf.


To set the PXM address, use the bootChange command:

        node-prompt> bootChange
        '.' = clear field;  '-' = go to previous field;  ^D = quit
        boot device          : lnPci
        processor number     : 0
        host name            :
        file name            :
        inet on ethernet (e) : 172.29.37.220:ffff00
        inet on backplane (b):
        host inet (h)        :
        gateway inet (g)     : 172.29.37.1
        user (u)             :
        ftp password (pw) (blank = use rsh):
        flags (f)            : 0x0
        target name (tn)     :
        startup script (s)   :
        other (o)            :

Set the "inet on ethernet (e) :" field with the first part of the entry (before the :) as the IP address, and the second part as the subnet mask.

Set the "gateway inet (g) :" with the gateway address.

This must be done on both PXMs. This can also be done in backup boot from the VxWorks prompt "->".

To set the shelf IP address:

node-prompt> cnfifip 26 shelf.ip.address subnet.mask broadcast.address

The second argument is the shelf IP address.

The third argument is the subnet mask.

The fourth argument is the broadcast address.


Step 1 Save your current configuration.

saveallcnf

Step 2 Get the filename by listing the CNF directory:

        node-prompt> ll "C:/CNF"
          size          date       time       name
        --------       ------     ------    --------
             512    APR-08-1999  08:16:18   .                 <DIR>
             512    APR-08-1999  08:16:18   ..                <DIR>
             512    APR-09-1999  05:26:42   TMP               <DIR>
           45433    APR-09-1999  05:28:42   NODENAME_0409990528.zip
           45433    APR-09-1999  05:28:42   NODENAME.zip
        In the file system :
            total space :  819200 K bytes
            free  space :  787787 K bytes

Step 3 On the workstation, upload the saved configuration to the workstation:

unix-prompt> tftp shelf.ip.address
tftp> bin
tftp> get CNF/NODENAME_0409990528.zip
Received 45433 bytes in 0.4 seconds

Step 4 Verify that one PXM is Active and the other Standby.

Step 5 From the workstation, download the PXM Backup boot image.

unix-prompt> tftp pxm.ip.address
tftp> bin
tftp> put pxm_bkup_1.1.34.fw POPEYE@PXM.BT
tftp> quit

Step 6 From the workstation, download the PXM FW.

unix-prompt> tftp pxm.ip.address
tftp> bin
tftp> put pxm_1.1.34.fw @PXM.FW
Sent 1982672 bytes in 18.3 seconds

Make sure that the transfer is successful by looking at the message displayed on the PXM console after the transfer:

Program length = 1982672
Calculated checksum = 0xd9779bc6 stored checksum = 0xd9779bc6
Fw checksum passed

Step 7 Download the ComMat.dat file to the C:/fw directory of the Active PXM. Use the TFTP put command:

tftp <node_name or IP address>
bin
cd fw
put ComMat.dat
copy ComMat.dat to FW directory on the PXM.
quit

Step 8 After the transfer is done, type the following on the PXM:

copy ComMat.dat /FW/ComMat.dat

Step 9 Execute the command install bt <newrev>.

Step 10 Exeucte the command install <newrev>.

Step 11 After the Standby card is reset and successfully enters the hold state, on the Active PXM, execute the command newrev 1.1.34.

The Active card will be reset and go to hold state.

After the newrev the firmware should now show the new revision on dspcd.


Caution If at this stage (after newrev) the upgrade needs to be aborted, follow the instructions under "Instructions to Abort Upgrade"

Step 12 After the Active PXM is reset and successfully enters the hold state, on the new Active PXM, execute commit 1.1.34.

Instructions to Abort Upgrade

A graceful downgrade is not supported. However, abort or fallback to the previous release is supported at any stage during the upgrade. The following procedure should be used to abort to a previous release.

Upgrade to 1.1.34 from 1.1.3x

If the upgrade needs to be aborted for any reason during the upgrade process, follow these instructions.


Step 1 Execute abort <release no>

PXM.a> abort 1.1.32

Upgrade to 1.1.34 from 1.1.2x

If the upgrade needs to be aborted for any reason during the upgrade process, follow these instructions


Step 1 If the abort is required before the newrev command is executed skip to Step 3.

a. Execute the following commands if the upgrade process is past the newrev stage.

b. On the Active PXM, execute shellConn.

c. Execute smCardMibVer = 21.

d. Execute saveDBToArchive <PXM SlotNo>, 0.

e. Execute uploadBram <PXM SlotNo>, <PXM SlotNo>.

f. The <PXM SlotNo> should be 7 for the MGX8850 Switch and for the MGX 8250 Switch (even if the Active PXM is in slot 8, use 7).

g. The <PXM SlotNo> should be 1 for the MGX8230 Switch (even if the Active PXM is in slot 2 use 1). The example that follows is for the MGX8850.

PXM.a > shellConn
-> smCardMibVer=21
-> saveDBToArchive 7, 7
-> uploadBram 7, 7

Step 2 Execute abort <release no>.


Service Module Firmware Download Procedure


Step 1 Download the selected revision of service module firmware into the service module in the selected slot.

tftp <node_name or IP address>
bin
put <backup boot> POPEYE@SM_1_0.BT
quit
tftp <node_name or IP address>
put <FW file> POPEYE@SM_1_0.FW
quit

You cannot do two puts in the same TFTP session.

Step 2 Install bt SM <slot> <version> then do install SM <slot> <version>

Step 3 Answer Yes to the question the install command will ask.

Step 4 Reset the card.


Note To upgrade all the SM, load all the firmwares and BTs to the node then do resetsys. Make sure that the configuration is saved.




Note Please consult your Support Representative before performing any software upgrade.


Manual Configuration of Chassis Identification

MGX as a Standalone Node

If any MGX box is to be used as a standalone node for testing, the intended model number from the PXM firmware configuration should be matched MANUALLY by running the "runConfigurator" utility.

Example: ipfrnj40 was running 1.1.24 as a 8850 node:

If the node's model number is set to 8250 by default after a 1.1.32 firmware upgrade, but the ipfrnj40 is still configured as a 8850 standalone node on the CWM side, then CWM will reject the node on discovery, and the node will remain undiscovered.

Solution: On every standalone node, manually verify that the runConfigurator settings match the switch.

Chassis Identification During a Firmware Upgrade

On the CWM side, the emd.conf must be modified to a one second wait time so it can help clean up the emc process's internal cache and CWM database (regarding any slot that has sent the functional removal trap). This ensures that CWM will sync up whatever is current with the switch after the upgrade.

Before a firmware upgrade is begun, complete the following steps:


Step 1 Change the following line in emd.conf:

"Hold for 300 secs before deleting the card after a func module trap is received".

to

"Hold for 1 secs before deleting the card after a func module trap is received".


Note This prevents race conditions in updating the database table from the firmware version upgrade.


Step 2 After emd.conf is changed, send HUP signals to all EMC processes.

Step 3 Revert the changes after the firmware upgrade is complete.

Step 4 Send HUP signals to EMC processes to confirm the changeback.


Service Module Installation/Upgrade and Flash Download Requirements.


Caution Service Module downgrade from 1.1.34 to any down level version is not supported.

If you are moving service modules from an existing MGX 8220 platform to the MGX 8850, the MGX 8220 service modules (AX-FRSM-8T1/E1, and AX-CESM-8T1/E1) need to have the boot flash upgraded to MGX 8220 Release 5.0.00 common boot code (1.0.01 version) before they can be plugged in the MGX 8850 chassis. All MGX 8220 service module versions that use Release 4.0.xx of boot code and earlier are not supported in the MGX 8850.

SPARE DEPOT: Customers receiving a replacement service module via the TAC (through the RMA process) will have the common boot code image that works for MGX 8220 Release 4.x, 5,x, and MGX 8850 installed on legacy service modules. (Spare service modules received directly from manufacturing through the normal ordering process will have the correct boot code image already loaded.)

If loading of the correct common boot code image is required then it will have to be performed on an MGX 8220 chassis, and cannot be performed on an MGX 8850 chassis. Please refer to the procedure below, which is also outlined in the Cisco MGX 8850 Installation and Configuration Guide on the documentation CD.

Use ftp to port the Axis 5 common boot image for the service module to a workstation.

Plug in the card into the MGX 8220 shelf.

Download the proper MGX 8220 shelf Release 5.0 boot image using the following commands from the workstation:

tftp <ip address of the MGX 8220 shelf >
bin
put <boot filename> AXIS_SM_1_<slot#>.BOOT

Now you must insure that TFTP downloaded the appropriate boot code by verifying the flash checksums.

Login to the shelf.

cc <slot #>'
chkflash'

Verify that the two checksums are the same.

If NOT, repeat the process until they are the same. If they are the same, then you can safely remove the card. At this point the service module can be used in the MGX 8850 shelf.

Service Module Upgrades

The following steps need to be followed for service module upgrades. Service module firmware images cannot be downloaded as specific versions in MGX 8850 Release 1.1.32 because only one image can be present on the disk at one instance. Hence the user cannot revert back during the installation process.


Step 1 Download the service module firmware to the shelf:

        unix-prompt> tftp shelf.ip.address
        tftp> bin
        tptp>put frsm_8t1e1_10.0.01.fw POPEYE@SM_1_0.FW
        Sent 1982672 bytes in 18.3 seconds

Make sure that the transfer is successful by looking at the message displayed on the PXM console after the transfer:

        Program length = 1982672
        Calculated checksum = 0xd9779bc6 stored checksum = 0xd9779bc6
        Fw checksum passed

Repeat for each service module type and for each slot-independent firmware.

For a slot-specific image (in this example the service module is tied to slot 1),

tftp <ip address of the MGX 8850 shelf >
bin
put frsm_<version>.fw POPEYE@SM_1_1.fw

for a slot-dependent image,


Note If the checksums are not the same when you remove the service module then the service module will not boot when it is plugged in and the service module will have to be RMA'ed.


MGX 8850 MGX-FRSM-HS2, MGX-FRSM-2CT3, MGX-FRSM-2T3E3 need to have Release 10.0.01 firmware for the runtime image and Release 10.0.01 firmware for the backup boot image.

If you need to upgrade both flash and runtime image of MGX 8220 Release 4.0.xx service modules to Release 10.0.01 to operate within the MGX 8850 chassis please follow the procedure below, which is also outlined in the Cisco MGX 8850 Installation and Configuration publication on the documentation CD.

Step 2 For non-graceful upgrades, just reset the card and the service module will come up with the new image.

Step 3 For graceful upgrades, a secondary card should be backing up the service module that needs to be upgraded. Configure the redundancy and issue the command:

install sm <slot> <version>

where <slot> is the service module that is being upgraded

and <version> is the service module image on the disk.


Note The concept of version is redundant here, since there is only one service module image on the disk. However we do check that the version given by the user matches the image on the disk to make it consistent with PXM upgrade/downgrade.


newrev sm <slot> <version>

where <slot> is the service module that is being upgraded

and <version> is the service module image on the disk.

commit sm <slot> <version>

where <slot> is the service module that is being upgraded

and <version> is the service module image on the disk.


Note There is no abort command for service module upgrade.


Known Anomalies for Platform Software Release 1.1.34 and Service Module Firmware

The following is the list of known anomalies in the service module firmware and the Release 1.1.34 software. Included with each is a brief discussion of the problem. A more in-depth discussion is available in the Release Note enclosure of the problem record in Bug Navigator.

Bug ID
Description

CSCdr71479

Symptom:

If slot 9 or 25 are configured in the 1:N group, upon transitioning to or from slot 9 or 25, line alarms are generated. The alarms observed have been RcvLOS (Receive Loss of Signal). Upon returning to the original service module, the alarm clears.

Conditions:

This problem occurs when using 1:N redundancy on the MGX8250 or MGX 8850 switch (PXM1).

1:N redundancy must be configured with slot 9 and/or 25 as either the redundant card (1) or in the working group (N).

Upon a transition to or from slot 9 or 25, the physical lines go into alarm(Loss of Signal). This has been seen in 1.1.21, 1.1.23, 1.1.31, and 1.1.32. This has been confirmed with CESM and AUSM, but is not service module specific.

Workaround:

Do not use slot 9 or slot 25 in the 1:N redundancy group.

CSCds58040

Symptom:

Cannot login into an MGX 8250 switch using a newly created userid.

Conditions:

This problem occurs in Releases 1.1.30 to 1.1.32 in instanceds when a new user account is created with the command adduser and the subsequent command xcnfuser.

Workaround:

Create the new user account with the adduser command. Login using the new account from another terminal and logout. After this, you can use the xcnfuser command without problem.

CSCds81767

Symptom:

During upgrade, the message ldrv_send_sm_message().... is displayed on the standby PXM.

Conditions:

Occurs sometimes during an upgrade from 1.1.24 to 1.1.31.

Workaround:

None.

CSCds82759

Symptom:

After running copy start running-config, the console port to the RPM is sometimes frozen.

Conditions:

When you copy startup config to a running config from a console port.

Workaround:

None. However, you can open another telnet session when this problem occurs, and there is no impact to traffic.

CSCds83090

Symptom:

The command clrsmcnf times out, deleting a non-existent port on the FRSM-8E1.

Conditions:

Occurs on an MGX8850 switch running Release 1.1.3Ae.

Workaround:

None.

CSCds83554

Symptom:

When doing a graceful upgrade, a system error is sometimes displayed.

Conditions:

Occurs during an upgrade to Release 1.1.32.

Workaround:

None.

CSCds86720

Symptoms:

One end of a frame forwarding connection is in alarm.

Conditions:

This problem occurs when a frame forwarding connection is added using a DLCI value other than 1000.

Workaround:

Delete the connection; add it again using a DLCI value of 1000.

CSCds86780

Symptom:

The following commands do not prompt after multiple, three-segment connections are added.

dspcd

dspln

dsplns

dspport,

dspports

dspcon.

dspcons

Conditions:

This problem occurs on an MGX 8850 switch after multiple, three-segment connections are added using script.

Workaround:

None.

CSCds90056

Symptoms:

DAX connections on FRSM-HS1B are alarms-free after removing one of the two cards used to establish those connections.

Conditions:

Remove one FRSM-HS1B, then check the connections status on the remaining side.

Workaround:

None.

CSCdt03252

Symptom:

The commands tstcon and tstdelay fail for three-segment connections on the CESM-T3 to CESM-T3 3.

Condition:

This problem occurs on a three-segment connection configured on the CESM-T3 card.

Workaround:

None.

CSCdt03580

Symptom:

Sometimes during an ungraceful upgrade, the cofiguration for the service module is lost, causing an AUSM-8E1 to fail.

Conditions:

This problem occurs occasionally during an upgrade from Release 1.1.25 to Release 1.1.32

Workaround:

Save all configuration before starting the upgrade. If there is a loss of configuration, restore the configuration.

CSCdt05474

Symptoms:

An ABIT alarm on a three-segments connection is not propagated from the PXM to the FRSM2T3.

Conditions:

The problem occurs when a three-segments connection is added using the wrong remote DLCI value on the BPX 8600 switch.

Workaround:

Use the correct DLCI value on the BPX 8600 switch.

CSCdt12990

Symptom:

CAC does not work properly on a PXM feeder trunk.

Conditions:

CAC doesn't work on a port in alarm status, but does operate on a port not in alarm.

Work Around:

None.

CSCdt21978

Symptom:

A popup message appears when executing commands.

Conditions:

This problem occurs after a the command resetsys and dspprfhist are executed.

Workaround:

None.

CSCdt27067

Symptom:

The command tstconseg fails intermittently when executed from the PXM.

Conditions:

Normal conditions.

Workaround:

None.

CSCdt28249

Symptom:

When configuring an exec-timeout under the line vty configuration on the RPM, the configured value isn't taken. Instead, the line timeout shown by the sh line output always defaults to 11 minutes.

Conditions:

This bug is written for primarily two issues:

1) The exec-timeout configured under the vty isn't used.

2) The idle timer in the output of sh users is not accurate and constantly increments, regardless of whether the user is idle or not.

Workaround:

None.

CSCdt28566

Symptom:

Frames are getting dropped due to port queue overflow without any frames being tagged on the egress direction.The command dspchanct for the channel shows increasing values for FramesDiscarded count and FramesByteDiscarded in the transmit direction.

The command dspportcnt for the port shows increasing values for the counters XmtFramesDiscXceedQDepth and XmtBytesDiscXceedQDepth in transmit direction.

Conditions:

This problem occurs when the queue threshold for the port is configured very low.

Workaround:

Use the command cnfegrq to configure the queue threshold accordingly. Note that in case of Ratio Based Servicing, the queue number of high priority is 1 and for low priority, it is 2. In case of weighted fair queuing, use the class of service index to refer to the queue number.

Verify that the values are set properly using the shellConn command "eseQueInfoShow." This command takes two parameters, the port number and the queue number. After setting the threshold to proper values, reset the card to implement the changes.

Further Problem Description:

The command cnfegrq doesn't update the cached copy of the port queue thresholds. Hence, the reset is necessary to get the configuration into effect. More over, the command dspegrq should be unblocked to make it available, irrespective of the type of servicing algorithm used in the card. Also, the command cnfegrq should be fixed to update the cached datastructure and display proper queue numbers to use during different servicing algorithms.

CSCdt33218

Symptom:

CWM is receiving too many traps from the MGX switch.

Conditions:

This problem occurs when an APS Line Failure occurs and a message logged on the MGX switch.

Workaround:

None.

CSCdt38056

Symptom:

The PXM displays VISM cards as failed while traffic continuity exists.

Condition:

This problem occurs on the PXM for Release 1.1.32, on the MGX 8250 switch for the CESM and VISM, and on the BPX 8600 switch with SRM.

Workaround:

Reseat the VISM card.

CSCdt42041

Symptom:

The standby card does not come up after the upgrade. The PXM is fine by itself.

Conditions:

This problem occurs during an upgrade.

Workaround:

None.

CSCdt42778

Symptoms:

The commands dspegrq and cnfegrq display the same information for ratio queue versus weighted fair queuing.

Workarounds:

None.

CSCdt44373

Symptom:

The AUSM and VISM cards remain in the state "cardinit."

Conditions:

The problem is observed on MGX switches running Release 1.1.32, AUSM 10.0.21, and VISM:2.0.0.1.

Workaround:

Under investigation.

CSCdt44475

Symptom:

The card crashes after being removed and then reseated.

Conditions:

After multiple switchccs on the node, removing the secondary card (in a redundant group) then reseating it causes the card to crash. It is unable to load the IOS image after that point, and remains in boot mode.

Workaround:

None.

CSCdt45706

Symptoms:

The standby PXM displays a state of "mismatch."

Conditions:

This problem occurs after the command clrallcnf is executed.

Workaround:

Execute clrallcnf repeatedly until the standby PXM is reported as "active."

CSCdt47766

Symptom:

The RPM directory files are not synchronized between the sactive and standby PXMs after TFTP.

Condition:

This problem occurs when TFTPing back to back files to PXM RPM directory.

Workaround:

Unknown.

CSCdt49909

Symptom:

When a PVC is in alarm, it is incorrectly reported as OK on the PXM.

Conditions:

Occurs occasionally when a PVC is in alarm.

Workaround:

None.

CSCdt50211

Symptom:

PSU failure is not indicated in either the command dsplog or dspshelfalm displays.

Conditions:

Occurs when there is a PSU failure.

Workaround:

None.

CSCdt53527

Symptom:

After altering the clock source using the command cnfclksrc, the hardware status of Clock remains Internal.

Condition:

This problem was noticed in Release 1.1.32, running with VISM Firmware is 002.001.000.126I . The PXM was configured to get the Primary clock from Sonet 7.1 line by the command "cnfclksrc 7.1 P" but the Hardware status of Clock remained on Internal Oscillator

Workaround:

Go inside shellConn on Active PXM:

-> m &lDrvClk+7,1

m &lDrvClk+7,1

81131d06: 03-01

01

81131d07: 03-.

Execute the command dspclkinfo to show the currentClockHwStat as "Primary."

CSCdt58037

Symptom:

After doing a back-to-back switchcc, the standby PXM state becomes and remains CardInit. The clock timing of PXM also is changed, and some RPMs are shown as RPM instead of RPM-PR.

Conditions:

The problem occurs during back-to-back switchcc test.

Workaround:

None.

CSCdt63497

Symptom:

Cannot check the memory of the MGX shelf.

Condition:

This problem occurs due to the memShow command causing unreachability. It has been removed from the CLI.

Workaround:

None.

CSCdt67828

Symptom:

A channel on an AUSM was deleted from both the PXM and the service module; however, the segment still exists on the BPX switch.

Conditions:

This problem may occur due to a resynchronization.

Workaround:

None.

CSCdt70642

Symptom:

On a PXM switchover, a PXM line hooked up to Adtech receives LOS momentarily.

Condition:

A PXM port is connected to Adtech. On a switchcc, the Adtech port receives a momentary LOS. Switchcc should be graceful; getting an LOS on switchcc is unacceptable.

Workaround:

Unknown.

CSCdt71179

Symptom:

Cannot modify the stat reserve parameter for the MGX trunks. The command executes, but doesn't hold the value of the changed parameter.

Condition:

This problem was observed on a network with a BPX 8600 running SWSW 9.3.11 and an MGX switch running Release 1.1.32.

Workaround:

Under investigation.

CSCdt71240

Symptom:

In a slot where a card does not reside, a connection is shown to exist and is auto-deleted continuously.

Conditions:

This condition was observed after a resetsys was done, and the auto delete was seen in the log.

Workaround:

None.

CSCdt74149

Symptom:

The GUI for the FRSM-8T1/E1 and AUSM 8T1/E1 is missing the parameters:

Line Module Description

Line Module Serial Number

Card Integrated Alarm BitMap

However, this information is present on a FRSM 2CT3 card. Incomplete information in the GUI forces operators to revert to the CLI.

Condition:

Occurs under CWM 10.4FCS with Patch 2, 8850 1.1.32, FRSM-8T1 10.0.22

Workaround:

None.

CSCdt75500

Symptoms:

Sometimes sub-interfaces are not shown in running configuration but the "show ip int br" command displays sub-interfaces.

Condition:

Thisproblem occurs when the user creates an interface without link type. In this case, even though the command is not completed, sub-interface structures are created. However, since the command is not complete, it is not show as part of the running configuration.

Workaround:

Delete the sub-interface by using the command "no int sw1.<if#>;" add it again with the proper link type.

CSCdt76729

Symptom:

The remote Loopback operation is not blocked by CiscoView on an AUSM 8T1 line.

Conditions:

Add a remote loopback on AUSM8T1 and remove it. Data continuity is lost.

Workaround:

In order to restore traffic continuity, after adding and removing the remote loopback on the AUSM line, add and remove a local loop on that line again through CiscoView.

CSCdt79407

Symptom:

After successively pulling out the backcard of Active PXMs, the GCRA1 and GCRA2 cell counters increase profusely.

Conditions:

This problem was observed on a PXM running Release 1.1.32Af with UNI connections between the PXM and the service module. The following events occurred prior to the problem:

1. The backcard of the active was pulled out.

2. The standby took over and the active card booted to mismatch state.

3. When the backcard was inserted; the mismatch PXM went into standby state.

4. When the backcard was removed from the active PXM, the standby took over before the active card rebooted.

5. The command dspchancnt) was used to check counters, and the GCRA1 & GCRA2 counters were incrementing at a very fast rate

This problem did not occur with a PXM having a T3E3 backcard.

Workaround:

Reset the standby PXM after event 3.

CSCdt84598

Symptom:

When the PXM1-4-155 is configured for UNI and configured for either VPC or VCC, non-zero GFC values arriving at the ingress port are not encoded to "0'"at egress.

Conditions:

This problem occurs when the PXM1-4-155 is configured for UNI, VP or VC service, and a non-zero GFC value is present at the ingress port.

Workaround:

None.

CSCdt85583

Symptom:

When the PXM1 receives an F4 or F5 loopback cell with reserved bits set to values other than '0', the PXM1 forwards the loopback cell rather than discarding the cell.

Conditions:

When the PXM1 receives an F4 or F5 loopback cell with reserved bits set to a non-zero value.

Workaround:

None.

CSCdt90915

Symptom:

The addlnloop command is not working properly. Although a remote line loop is specified, the software instead puts the line in local line loop.

Condition:

This problem occurs when an attempt is made to add a remote loopback using the addlnloop command on a PXM card.

Workaround:

Use the cnfln command to put the line in remote/local loopback.

CSCdt95937

Symptom:

Shellcon freezes and no new shellcon commands can be executed.

Condition:

Accessing the PXM via telnet and entering to Shellcon mode and closing the telnet session causes the PXM not to execute any further shellcon commands on the new telnet session.

Workaround:

Ececute a switchcc.

CSCdt96671

Symptom:

The RPM port is always shown as active, even when the subinterface is shut down on a switch.

Condition:

Create a subinterface on the RPM-PR card on the switch. Check the status field in rpm_port table. It will be 1(active). Do a "shutdown"on the interface. Check the status. It still shows 1(active). According to the DBSchema, it should be shown as 2(down).

Workaround:

Unknown.

CSCdu00165

Symptom:

For an RPM connection, the connection status is not propagated to CWM from PROXY.

Condition:

This problem occurs whenever a connection is added between the RPM and any other card. It will show as failed on the RPM side.

Workaround:

Unknown.

CSCdu02695

Symptom:

When an MGX switch is running on external clock, and the service module lines are set to local timing, intermittent slips are observed on the attached device interface. This occurs despite the fact that both the attached device and the MGX switch show they are both taking the clock value from the same external source.

Workaround:

If the external clock is disconnected and reconnected from the Active PXM UI card, the clock slips then stop and all is OK.

CSCdu03185

Symptom:

Allowing more than expected CLP1 cells into the network by the policing function on VBR.2 (rt/nrt) connections on AUSM 8T1.

Condition:

This could potentially lead to network congestion.

Workaround:

Unknown.

CSCdu06781

Symptom:

Back-to-back forced/manual (W->P followed by P->W) switch was permitted when the latter external user request is initiated from the remote end.

Condition:

Check to see if remote request of equal priority is not in place.

Workaround:

None.

CSCdu07060

Symptom:

After upgrading from Release 1.1.32Ag to 1.1.33, it was noticed that a LOS on an OC3 line did not get summarized in the dspcd or dspcds command.

dspalm -sonet 7.3 shown the line to be in LOS

dspcd 7 did not shown major alarm

dspcds did not shown major alarm

The OC3 line was not configured for APS (as it was attached to a testset).

Conditions:

This problem occurred with pxm_bkup_1.1.33.fw, pxm_1.1.33.fw, rpm-boot-mz.121-5.T5_XT, rpm-js-mz.121-5.T5_XT .

Workaround:

Execute a switchcc.

Further Problem Description:

This problem was not observed on nodes upgraded from 1.1.23 to 1.1.33 or 1.1.24 to 1.1.33. Note that Release 1.1.34 has a new firmware file, rpm-js-mz.122-3.3.T.

CSCdu07122

Symptom:

The dspcons and dspchans output does not list the particular vpi, vci pairs in question. When trying to add the connection via the CLI, the PXM output the following error:

ipfrtx40.1.8.PXM.a > addcon 4 2 12 401 3 2 2

ERR !: IfNum.Vpi.Vci already in Use

Set failed due to illegal option value(s)


Conditions:

This problem occurred under the following conditions:

Light traffic load

Number of connections - 1288 (entire node)

Number of connections - 180 (slot 11)

No alarms

Problem reported by a user running a home grown Perl script from a CWM 10.4 interface. Cannot be reproduced on demand. Occurs infrequently.

Workaround:

Connections were restored by running the following:

-> GetRpVcTbl 12,402,3

-> rpDumpSram 35

-> qeDispVcRam 0,0x07d5

-> rpDeleteCon 12,402,3

CSCdu11046

Symptom:

The FRSM service module comes up in card init state and reserved state.

Conditions:

This problem occurs when the active service module is physically reset and the standby becomes active. The service module in the standby slot comes up in the reserved state.The command dspcds shows reserved, but running the command dsplog does not show the card insertion.

Workaround:

Unknown.

Further problem description:

Additionally, another FRSM was removed and reinserted 30 minutes later, and it got stuck in the init state.

CSCdu11132

Symptoms:

The shelf reset by itself.

Conditions:

Observed when swapping a PXM with 1.1.23 into a shelf with 1.1.33Aj.

Workarounds:

None.

CSCdu12272

Symptom:

The nodename is not being updated.

Conditions:

This problem occurred when a standby PXM with a Release 1.1.23 was placed in a shelf with Release 1.1.33.

Workaround:

None.

CSCdu17838

Symptom:

Alarms do not show.

Condition:

Problem observed after resetting the card.

Workaround:

Up the other side of the lines, then delete it.

CSCdu18583

Symptom:

The AUSM is not returning to the proper state.

Conditions:

Problem is observed after a softswitch is executed from slot 30 to slot 22.

Workaround:

Reset the service modules.

Further Problem Description:

Service modules become unreachable at times. SM is slot #30 gets stuck in the boot state, and the service module in slot 22 becomes active but you can't change cards to it.

CSCdu21136

Symptom:

Channels do not come up to the active state.

Conditions:

This problem is observed after a softswitch was done between slots 22 and 30, then a switchcc executed.

Workarounds:

Do a second switchcc, and the channels come up to the active state.

CSCdu21155

Symptom:

Cannot add more than 47 users. However, the maximum number of user IDs should be 67.

Conditions:

Occurs under Release 1.1.32 software. Occurs always.

Workaround:

None.

CSCdu21988

Symptom:

The standby PXM Card freezes in the card init state, and a software error is logged.

Conditions:

Unknown.

Workarounds:

None.

CSCdu22398

Symptom:

The PXM gets stuck in the empty state.

Conditions:

Observed after issuing the install command during an upgrade from from 1.1.33Aj to 1.1.33Ak.

Workaround:

Reset this card once more; the card will come up to hold state.

CSCdu23948

Symptom:

There is mismatch between the commands dspcds and dspred output.

Conditions:

This problem is observed when there is redundancy and you perform a softswitch.

Workaround:

None.

CSCdu25295

Symptom:

When using the script executed add/softswitch/delete 1:N redundancy, the primary RPM-PR card lost all the informations in "show switch connection."

Condition:

Cyclic add/softswich/delete 1:N redundancy led to this problem.

Workaround:

Unknown.

CSCdu26221

Symptom:

Release 1 group for MGX switch needs to address improvements to MIB contents. Duplicate of CSCdu16882 for CWM.

Conditions:

Customers experiencing problems with MIB contents and or matrix input identifying network element pertinence per MIB to/with CWM team.

Workaround:

None

CSCdu26869

Symptom:

The state of a connection stays in "OK'" state for about a minute before changing to the correct "AIS FAIL" state.

Condition:

This problem is observed when the UPC value of the connection is modified.

Workaround:

This is a transient problem, lasting for about a minute.

CSCdu27251

Symptom:

The CESM card sometimes gets stuck in the failed state if a resetcd is executed. The CESM also may go into the failed state if a cc is done to the card or the addcon command is executed on it.

Conditions:

This happens if the PXM has a UI-S3 back card and a switchcc is done. The problem is observed on a shelf running on Stratum-3 level internal oscillator.

Workaround:

If the shelf is running on Stratum-3 level internal oscillator and there is a switchcc, re-execute the following command on the new active card: cnfclklevel 3

Further problem description:

Please contact cisco TAC for a workaround referencing this bug id. Note that the PXM-UI-S3 backcard is not supported in Release 1.1.34.

CSCdu27272

Symptom:

The alarm indication signal state is incorrect on the hybrid three-segment connections from the AUSM-8T1/B.

Condition:

When three-segment connections are added on AUSM-SES and SES-AUSM acombinations, the connections slip into AIS state.

Workaround:

Unknown.

CSCdu27733

Symptom:

The shelf resest and a software error is logged, creating a core dump.

Conditions:

This problem occurred whenthe command dspcons was issued.

Workaround:

None.

CSCdu31686

Symptoms:

The policing for a VBR1 connection originating at an MGX switch and and AUSM-8T1/E1 remains active when the UPC is disabled.

Condition:

Observed when a 5-segment xpvc connection was set up across an AR/PNNI hybrid network. Then, the traffic rose above the PCR rate, and the traffic is dropped to the PCR level.

Workaround:

None.

CSCdu35704

Symptom:

The RPM front card resets on an MGX 8250 switch, when the ethernet back card is removed.

Conditions:

Observed on the MGX 8250 switch, but the problem does not occur on an MGX 8230 switch. The problem occurs when the back card is removed.

Workaround:

This issue can be easily avoided if "shut" interface is executed before the removal.

Forther problem description:

During testing, it was observed that the IOS looses the running configuration of this interface. If this occurs, the configuration could be loaded from the saved config by "copy startup running."

CSCdu36455

Symptom:

After creating login accounts with adduser command of differing privilege levels, some of the accounts work, while others experience problems related to account usage. Problems include nonrecognition of login, and an inability to change the password. Also, deleting accounts sometimes does not work.

Conditions:

Occurs under Release 1.1.32.

Workaround:

None.

CSCdu36970

Symptom:

The command addcon fails.

Condition:

Occurs with connections on the RPM.

Workaround:

Add a connection with a different VCI on the RPM and same VPI/VCI on PXM. Delete it, then readd the original connection.

CSCdu36978

Symptom:

An LOS alarm is triggered after adding a soft loop on the FRSM-2E3.

Condition:

Occurs always.

Workaround:

None.

CSCdu38240

Symptoms:

AIS is seen at all interface points (BPX feeders and ENNI interfaces at nodes). No traffic is possible.

Condition:

Observed when VBR3 xpvc is added across Release 1-1/RPM to Release 1-2/RPM across the AR/PNNI hybrid network.

Workaround:

None.

CSCdu38711

Symptom:

All PSU is showing "missing."

Condition:

Unknown.

Workaround:

None.

CSCdu38845

Symptom:

Sometimes current clock controller hardware status is not correctly displayed.

Conditions:

The problem is observed under normal condtions.

Workaround:

None.

CSCdu39150

Symptom:

The command dspchancnt 2000 triggers an error message onthe FRSM-2CT3.

Condition:

Problem is observed on an MGX 8230 switch with a FRSM-VHS.

Workaround:

Under investigation.

CSCdu39325

Symptom:

The switch interface does not come up.

Condition:

Occurs when OAM manage is enabled.

Workaround:

Disable OAM manage.

CSCdu39799

Symptom:

The PXM is reset after going to active state.

Condition:

Unknown.

Workaround:

Unknown.

CSCdu40067

Symptom:

Connections do not show up when executing the command dspcons -slot 21 from the PXM.

Conditions:

This problem occured after the SRM in slot #31 was removed and reinserted.

Workaround:

After a switchcc, the connections are active and passing data, but they still do not show up in the conn_table.

CSCdu40820

Symptom:

The primary and secondary AUSM rebooted simultaneously.

Conditions:

This problem was observed while doing a switchcc.

Workaround:

None.

CSCdu40885

Symptom:

AUSM channels are showing in alarm.

Conditions:

Observed when the active SRM card was removed.

Workaround:

None.

CSCdu40171

Symptom:

Sometimes the primary clock reference is not selected initially after a switchcc.

Conditions:

After a switchcc.

Workaround:

None.

CSCdu40524

Duplicate anomaly. Please refer to CSCdu35704 for a description of the problem.

CSCdu41961

Symptom:

Data transfer stopped for approximately 1min, 25 secs.

Conditions:

Observed when the active SRM back card is removed.

Workaround:

None.

CSCdu41352

Symptom:

The message PAR-4-SWERROR is logged by system. System error message keeps appearing on the user interface.

Conditions:

Observed when the year is onfigured beyond 2020 using the command cnfdate.

Workaround:

System functions fine if year is not configured higher than 2019.

CSCdu42177

Symptom:

After an upgrade, a load exception occurred, in turn triggering the node to reset.

Condition:

The problem was observed periodically after upgrading the node from Release 1.1.32 to 1.1.34 .

Workaround:

Unknown.

CSCdu44076

Symptom:

Connections remain out of alarm.

Condition:

The problem was observed on an MGX 8250 switch running Release 1.1.34.

Workaround:

Under investigation.

CSCdu44086

Symptom:

The alarm state does not change on the PXM Trunk

Condition:

The problem is observed on the MGX 8250 Switch running Release 1.1.34.

Workaround:

Reset the system.

CSCdu45324

Symptom:

During a traffic test, discards ona FRSM are displayed due to CRC and assembly errors. This mainly occurs on the last 5 ports of the FRSM.

Conditions:

GN Netester inputting 60cps across 500 SIW connections built from a BPX 8600 network running Switch Software 9.2.37 and passing through two ATM NNI gateways, then terminating on a MGX switch running Release 1.1.32, configured as a feeder and a vFRSM card. Occurs when the FRSM is heavily loaded.

Workaround:

None.

CSCdu45565

Symptom:

Both the primary and secondary AUSM reboot and channels remain in alarm.

Conditions:

The problem is observed when softswitching from the primary to the secondary slots via a script.

Workaround:

None.

CSCdu45583

Symptom:

Slot #30, covering for Slot #28, rebooted.

Conditions:

This problem is observed after a switchcc on the PXM.

Workaround:

None.

CSCdu45874

Symptom:

The FRSM-2CT3 in slot #5 failed.

Conditions:

The problem is observed during an upgrade from 1.1.33Al to 1.1.33An.

Workaround:

Switchcc cleared the failure, and the FRSM then went active.

CSCdu46419

Symptom:

GCRA2 NonConforming cells are observed without Policing on the Ingress channel.

Conditions:

This problem is observed when UBR is configured on the PXM to RPM, and no policing is enabled. Even with OC3 rate, there are GCRA2 cells on the ingress.

Workaround:

None.

CSCdu47264

Symptom:

Traffic discontinuity is experienced on the RPM-PR card.

Condition:

This problem occurs during traffic bursts on the FA card.

Workaround:

Reseat the FA back card.

CSCdu48231

Symptom:

ILMI failure occurs on ports while traffic continuity

Condition:

The problem occurs on the MGX8250 running Release 1.1.34.

Workaround:

Under investigation.

CSCdu49424

Symptom:

All service module's setup for redundancy show as active.

Conditions:

Problem observed while running a softswitch script on slots 19, 28,and 30.

Workaround:

None.

CSCdu49464

Symptom:

The FRSM-2CT3 card in slot 11 is stuck in reserved state.

Conditions:

The problem is observed after a resetsys.

Workarounds:

None.

CSCdu49667

Symptom:

Sometimes the Stratum-3 clock from UI-S3 is not selected properly.

Conditions:

Problem occurs when the UI-S3 backcard is used.

Workaround:

None.

CSCdu51152

Symptom:

The CESM card sometimes gets stuck in the failed state if a resetcd is done on it. The CESM may also go in the failed state if a chance card is done to the card or the addcon command is executed.

Conditions:

This happens if the PXM has a UI-S3 back card and a switchcc is done. The shelf needs to be running on Stratum-3 level internal oscillator for this problem to occur.

Workaround:

If the shelf is running on Stratum-3 level internal oscillator and there is a switchcc, re-execute the following command on the new active card:

cnfclklevel 3

CSCdu51610

Symptom:

A switchover occurred on an MGX8250 switch, but the log and the output from dsperr does not provide a clear indication of the cause.

Conditions:

This problem is observed on an MGX8250 switch running 1.1.32 and populated with AUSM and FRSM cards with a light traffic load.

Workaround:

None.

Further problem description:

The switchover functionality is not in question, as this worked perfectly. However, errors logged do require further explanation in respect to a one off occurrence or a hardware/firmware issue.

CSCdu51707

Symptom:

An MGX 8820 looses a default route pointing to the ATM network.

Conditions:

To recreate:

1. Add a default route to the PXM card using the routeAdd command

2. Display the route using the routeShow command

3. Do a switchcc command

When PXM comes back up do a routeShow. The default route you added will be gone.

Workaround:

Unknown.

CSCdu52789

Symptom:

The port alarm is present on the AUSM card.

Conditions:

Even after an upgrade, and there are no port alarms, or line alarms.

Workaround:

Wait a while, and the alarm finally clears itself.

CSCdu52855

Symptom:

The command output for chkslotcon is not representing the correct connection information.

Conditions:

This problem is observed directly after a switchcc on the shelf.

Workaround:

None.

CSCdu53799

Symptom:

Even if there is a MGX log even, the switch doesn't send a trap when the command switchapsln clear is executed. There is one trap for other switchapsln.

Workaround:

Manual, forced and lockout.

CSCdu53814

Symptom:

Inserting 1E-03 errors into the working APS line of the feeder trunk in the MGX switch receive direction results in an APS switch to protection due to signal failure (as expected).

The errors were then removed from the working APS line. However, despite the fact that the APS line was clear, the it did not switch back to the working line when a manual switch was attempted using the switchapsln command.

A Second attempt at switching the APS line is successful. This is reproducible i.e. following an APS line failure due to Sig Failure and resultant clear, the APS line will not switch back to Working on first attempt. Is okay following a failure due to Sig Degrade. MGX8250 feeder configured for APS 1+1, Unidirectional, Non revertive.

Workaround:

Enter the switchapsln command a second time and providing the line is clear of errors it will now successfully switch.

CSCdu71151

Problem Description:

Customers upgrading to 12.2(2)T2 image with RPMs might see some e-BGP sessions not coming up when the CE router is running an older version of IOS (12.0, 12.0.xT). This issue was first encountered with CE running 12.0(7)T image. In such case, the CEs running old IOS versions were not able to create BGP sessions to PEs with the newer image (12.2(2)T2).

The issue is fixed in 12.2(2)T3. Customers who face the problems described with the 12.2(2)T2 image, may upgrade to 12.2(2)T3 image. The IOS 12.2(2)T3 can be downloaded from the following CCO URL:

http://www.cisco.com/kobayashi/sw-center/index.shtml

Symptom

MPLS PE doesn't advertise BGP network to CE router running an older IOS image.

Conditions

A Cisco router that is running Cisco IOS Release 12.2(3.1)T or 12.2(2)T and is configured as a provider edge (PE) router may not support Label Distribution Protocol (LDP). This defect might cause the PE router not to advertise any Border

Gateway Protocol (BGP) routes to a Cisco 2600 series customer edge (CE) router that is running Cisco IOS Release 12.0(18). However, the CE router will advertise routes to the PE router. Entering the neighbor ce-ipaddress don-capability-negotiate command on the PE router does not correct this defect.

Workaround

Upgrade the CE router from Cisco IOS Release 12.0(18) to Cisco IOS Release 12.2(2)T3.

CSCdu72190

Symptom:

The active PXM resets due to "Software Error Reset". The standby PXM takes over. There is no service impact.

Conditions:

This problem occurs when CiscoView is running and SRM T3 lines are enabled. The time it takes for the PXM to reset depends upon the number of instances of CiscoView running.

The PXM reset happens approximately every 4 hours when running more than 80 instances of CiscoView.

Workaround:

None.

CSCdv02276

Symptom:

Primary card is in a failed state after softswitch.

Conditions:

The problem is seen in the following instance:

PXM is running 1.1.34

Chassis contains 2 AUSMs in 1:N Redundancy & running 10.0.11 version

An upgrade on the AUSM from 10.0.11 to 10.0.22 occurs by doing softswitch twice.

Workaround:

Reset the secondary card before the first softswitch.

Further Problem Description:

While doing the softswitch from the secondary to the primary, and the command dspred is executed, we can see that the primary gets stuck in failed state.


Known Anomalies for Platform Software Release 1.1.32 and Service Module Firmware

The following is the list of known anomalies in the service module firmware and the Release 1.1.32 software. Refer to Bug Navigator for a current description of these problems, or to the 1.1.32 Version Software Release Notes Cisco WAN MGX 8850, 8230, and 8250 Software.

Bug ID
Description

CSCdk54268

When sending cells of VPI=0, VCI=0, and CLP=1 from a UNI port, dspportcnt reports the cells as being discarded due to VpiVciErr and the cell rate also gets updated.

CSCdk71643

End-to-end connectivity with full recovery in cases of error does not fully function with current design.

CSCdk86638

When using CWM to add connections, if the connection addition request times out, subsequent addition of the same connection may fail as well, complaining that the connection already exists (even though it timed out).

CSCdm05358

When modifying a particular protected memory address on CESM8p, which causes CESM HW watchdog reset, PXM got reset or lost SAR functionality.

CSCdm10722

SM upgrade should be done with the following commands in this order: install, newrev and commit .

CSCdm11410

When listing a directory, some file names contain either illegal characters or a timestamp for the name instead of a standard DOS file name.

CSCdm22510

Connection traps are not sent out when receiving A-bit update from CPE. Related to CSCdm22510.

CSCdm31437

SV+ needs a trap when a line is added or deleted.

CSCdm33351

An Endpoint Added Trap message and an Endpoint is Active message are sent to the manager from VISM.

CSCdm33605

When a switchover to a redundant VISM card takes place due to a reset/failure of the active VISM card, the display on CWM is not correct.

CSCdm33638

When a switchover to a redundant VISM card takes place, the display of active lines is not consistent between the shelf and CiscoView.

CSCdm42849

An execution of the dlmi command to display LMI messages results in a system reboot.

CSCdm43053

Connection addition fails.

CSCdm48639

Better error checking needs to be provided for SM boot and firmware download. It's possible to download the boot image as firmware and vice versa.

CSCdm53758

Channel alarms do not get propagated to the middle segment if NNI signaling is enabled.

CSCdm56094

The far-end device cannot be put into a loopback using the "Far End Inband Loopback" or the "Far End ESF Loopback" options under the "DEVICE TO LOOP" menu in the cnfbert command.

CSCdm85931

There are display errors for FRSM-HS1 card for dspchancnt 17.

CSCdm91930

LED status in CWM is different for lines in same status in Active card/hot standby.

CSCdm92345

The VHS SM have either DAX or FEEDER connections on the logical port, which is simulated with some kind of signaling.

CSCdp00912

Core redundancy should be allowed in mismatch state

CSCdp11859

The ABCD bits that are produced on the egress of a CCS-to-CAS connection seem to have a random/unpredictable pattern.

CSCdp32043

SV+ node sync always failed because of timeout, due to TFTP very low.

CSCdp34543

Install backup boot fails when it tries to program the flash on the standby card.

CSCdp35772

This should not affect the normal running of the system as the background memory check checks for memory corruption and leaks.

CSCdp36477

The switchcc on 8850 causes a Sig_F APS line switch on BPX.

CSCdp39894

The software error is logged as a result of an attempt to refer to a transaction that is already complete.

CSCdp39900

The software error is logged when trying to allocate a msg buffer to send VSI commit for a connection.

CSCdp42349

A PXM1-155 alarm is issued.

CSCdp44837

When deleting a large number of connections using a script, it was found that for some connections, the resources were not properly freed.

CSCdp46927

VISM card in alarm after addcid.

CSCdp48790

This problem has not been reproducible.

CSCdp50045

During boot time, VC-create failed message will be displayed.

CSCdp50317

Information displayed using the dsphotstandby command is not consistent.

CSCdp51707

Removing a Service Module, then inserting an RPM in the same slot causes the RPM to go to Active State instead of Mismatch.

CSCdp52549

This software error has been a one-time occurrence when deleting a connection.

CSCdp52776

New CLI command to delportrscprtn for the AUSM and the FRSM.

CSCdp53342

Information on this anomaly is unavailable at this time.

CSCdp53347

If two different HS1 SM have too many master and slave connections, delete about 15 slaves first.

CSCdp59851

Per the log messages, PAR failed, followed by PVC deletion.

CSCdp60443

A data outage occurs on the FRSM-2CT3, up to 15 seconds in length.

CSCdp63530

FRSM-2T3 fails after upgrading causing switchover to secondary.

CSCdp63922

Connections could not be added successfully from a SM, with a particular port/DLCI combo that did not seem to be used.

CSCdp63924

SYSTEM ERROR 20102 (PV_DB_RMV_ERR) is reported when we try to refer a completed transaction. Duplicate of the bug CSCdp39894.

CSCdp65639

Existence of any such problem that can lead to time-out scenario described in the bug report would be the one to be addressed as the root cause.

CSCdp65652

The ImaGroupRxImaId is not updating properly on the AUSM when the TxImaGroupId parameter is manually changed via the Kentrox CPE.

CSCdp71408

No information is available about this anomaly at this time.

CSCdp75846

In the AAL1 cells generated by CESM for a Structured T1 CAS connection, the AAL1 pointer may not be pointing to the first 125 us frame of the multiframe.

CSCdp77451

Inserting standby PXM can cause the Telnet to be lost on the active PXM.

CSCdp81287

The clrsmcnf says unsupported SM for CESM-8E1.

CSCdp84145

When adding a connection from CWM using local and remote nodename, which is different from the one configured on the node (because CWM is not synced), the addcon request erroneously passes and the connection gets added.

CSCdp84773

It has been found that the Resource Partitioning of an AUSM card on the PXM is registered as zero instead of a value of three.

CSCdp86479

PVCs shown as UP on RPM even when they are deleted remotely.

CSCdp89717

In some cases, when RPM fails, it is not declared as failed on PXM, and any attempt to cc to this FAILED card fails, even though it is showing ACTIVE on PXM.

CSCdp92736

The line, port, channel counters are reset to zero, and start counting from 0 after a switchcc.

CSCdp93004

When a connection fails, the A-bit status displayed on the connection manager for the particular connection always stays as "ok".

CSCdp94060

Receiving user connection modification traps 25015 for no reason.

CSCdp96632

The table rpm_port parameter will have -1 value, even if the port is in the active state.

CSCdp99496

When FRSM-VHS2T3? is ran, the return display shows that dspportstats is a command. However, no such command exists.

CSCdr00016

This problem was encountered sometimes when deleting more than 500 connections using a single delchans command.

CSCdr01410

PXM resets if holding down the return key while cc'ed to a service module.

CSCdr01426

Error logs overwritten and no core dump. Information is not retained on reset.

CSCdr02667

When IMA ports are configured on AUSM via SRM (BULK distribution), execution of switchcc causes IMA port failure.

CSCdr04154

Customer has come upon a failed PXM in their shelf and would like to have EFA done on it to determine the root cause of the failure.

CSCdr05471

Softswitch caused FRSM-CT3 cards to go to failed state, and ed map in the PXM had the same slot number for both the entries.

CSCdr06052

The dspcd in PXM would show the FAB number as 800-XXX, which is actually the PCB number.

CSCdr10332

Upon switchcc, AUSM in bulk mode receives wrong VPI-VCI cells.

CSCdr11454

PVC alarm status was not reported correctly after a Softswitch was executed on FRSM-2CT3.

CSCdr14672

Standby FRSM shows not available under redundancy and hot standby table.

CSCdr15892

The addlnloop on the PXM causes SONET line alarms, which sometimes do not clear when the loop is removed.

CSCdr16499

RPM sends Trap 50600 after resetcd.

CSCdr16720

Softswitch caused the standby FRSM-VHS to Failed state. (Though Softswitch succeeded according to the CLI it really didn't occur.)

CSCdr17959

AUSM card hangs if 2 to 3 ILMI requests are sent on a port. It reboots if 5 ILMI requests are sent.

CSCdr19456

Sending five ILMI requests to an AUSM card makes the directly connected AUSM card reboot.

CSCdr20239

When the command tstcon is issued, it clears the alarm status of connection when connection is failed due to remote A-bit failure.

CSCdr21393

The AUSM-AUSM loopback connections go into alarm.

CSCdr22375

The added between SMs fails to report a feature mismatch but dspsmcnf shows identical feature bitmaps for the two SMs.

CSCdr23964

The 50012 trap is sent twice.

CSCdr25038

There are times when we are not able to send the cc frame to the RPM card and as such not able to do a cc.

CSCdr25083

Mod Conn fails with error "Wrong OID or problem with Varbind" for FRSM-VHS endpoint connections. Both DAX/NONDAX.

CSCdr25163

Details on this anomaly are not available at this time.

CSCdr26529

Able to restoresmcnf on a different slot.

CSCdr28177

During a switchcc, VISM lines go into yellow alarm for a very short interval.

CSCdr36469

CLI commands are required to display the NOVRAM contents of all the MGX 8850 cards.

CSCdr41616

Unable to Telnet to the active FRSM card even when there only one cc session initiated to that SM.

CSCdr43216

The stand-by PXM and all service modules go into a failed stated after 64-byte packet transmitted from RPM.

CSCdr44024

The MGX and BPX defaults are consistent. The solution is to explicitly configure the framing. AXSM needs to be changed.

CSCdr44337

The aveallcnf creates 2 identical files.

CSCdr44487

System error is printed onscreen.

CSCdr49478

One-time occurrence. After a sequence combination of adding and deleting SM redundancy and clrsmcnf, and connection deletion/addition, tstcon is not passing on certain connections

CSCdr53807

The LED on a card is green even though the card failed.

CSCdr57422

Channel Active or Channel Added trap was not received by CWM.

CSCdr58123

The card gets reset.

CSCdr58189

Alarm status is inconsistent for standby PXM card.

CSCdr60198

The Arbiter PLD on the existing 4E back cards is not compatible with the PCI rev2.1 Port Adapter bridges that are used on the RPM-PR.

CSCdr61309

MGX log fills up when the Frame Relay port is in alarm.

CSCdr61335

The card gets reset.

CSCdr61360

When the AUSM card is receiving AIS from the network side as well the A-bit alarm from PXM, duplicate AIS on the port side orrurs.

CSCdr61544

No information is available about this anomaly at this time.

CSCdr62285

When running BERT tests on CESM lines or ports, the PXM might report a general error.

CSCdr62322

Some of the BERT test patterns, for example, QRSS, fail to synchronize with the new CESM-8T1 card.

CSCdr62361

Able to configure line parameters on an FRSM when BERT port tests are running.

CSCdr62370

BERT pattern tests on the SRM-3T3-C are intermittently not synchronized with the FRSM-8E1 module.

CSCdr66666

Some of the lines in IMA group become unavailable. Duplicate of CSCdr58168.

CSCdr68155

Sometimes the disk update messages for the simulated delete connection/delete port done when the clrsmcnf command is issued occurs after the database is removed.

CSCdr71479

Lines on AUSM/B in slot 9 of MGX 8850 are failed upon switchover to redundant AUSM/B.

CSCdr71982

CESM addred displays incorrect error message when the card is in Reserved State.

CSCdr73483

Information on this anomaly is unavailable at this time.

CSCdr82396

The srvovrd option is not functioning in cnfchansrvrate command.

CSCdr90512

Not able to collect statistics from the MGX 8850 Release 1 shelf.

CSCdr90658

Even though xaddcon/xcnfcon displays 38328 cps as the maximum value if calculated, do not configure it to a maximum of 38328 cps.

CSCdr90871

Customer is requesting additional information be provided in the log file when a PVC is deleted.

CSCdr90987

The cnfclklevel command succeeds for level 3 even if the old PXM UI back card is used.

CSCdr91331

Configurations, like bulk mode SRM configurations, seen in unused slots of the shelf.

CSCdr91665

The displayShelfBanner on Standby PXM does not display the right banner.

CSCdr92373

PUBLIC community string should be "READ-ONLY", on MGX "PUBLIC" can be used to write by SNMP.

CSCdr93342

Details on this anomaly are not available at this time.

CSCdr93376

Details on this anomaly are not available at this time.

CSCdr93664

Unused slots on 8250 show up as "reserved" even after a clrallcnf.

CSCdr96138

Configure the transmit FEAC code to be dsx3SendPayloadCode on DS1s, which should be rejected since DS3 application on PXM is unchannelized.

CSCdr98578

Parameter fields for command dspalms is not preceded with an -example: dspalms ds3 | e3 | SONET instead of dspalms -ds3 | -e3 | -SONET

CSCds03072

The soft reset path on the RPM-PR rommon is not re-initializing the TLB correctly.

CSCds04372

Initial Burst Size behavior (IBS) is not functioning correctly for the ABR connections.

CSCds05040

The major alarm LED on the active and the standby PXM on MGX 8850 are on, while the CLI commands do not show any indication of alarm.

CSCds05580

On doing a dspcon on a PXM connection, the remote end LCN is displayed as 0.

CSCds05593

Issue a clralm on the SRM and the AlarmState clears. Issue a clralm on any SM (AUSM, FRSM, CESM) and the AlarmState does not clear.

CSCds05978

On trying to use option "*" for VCI in the cnfilmi command as specified in the CLI help, the command returns an error.

CSCds07944

The clralmcnt -ds3 does not clear the counters.

CSCds08528

The ports do not go into signaling failure even after the two ports have a signaling mismatch.

CSCds09036

The version displays StrataCom instead of displaying Cisco.

CSCds09448

At present CWM is setting %util values(lper_util, rper_util) to -1. CWM will get these values from * TFTP config UpLoad File * SNMP UpLoad file.

CSCds10270

When a OC-12 feeder trunk is configured as 1+1 unidirectional mode, the PXM-622 OC-12 line had no option to specify "working" or "protection" line would be applied upon an external request .

CSCds10279

Request for user-friendly APS status information.

CSCds10286

The PXM displays the incorrect error message when trying to switch APS line using switchapsln CLI.

CSCds10287

An APS protection switch has occurred because of line alarm. When the status of dsptrks and dspalms are checked, they indicate that the lines are clear.

CSCds10377

When one of the OC-12/OC-3 lines are in alarm, the CLI dspapsln shows the line status as "ALM" instead of specifically indicating LOS/LOF.

CSCds10765

Software error 20304 was observed during resetsys/switchcc.

CSCds11679

No known workaround. To be fixed in later releases.

CSCds12647

From Cisco WAN Manager, v9.2.07, Connection Manager, customer tries to create a new NRTVBR3 connection on MGX 8850. There are three passwords: login, password, and RPM enable password.

CSCds13629

Issue clrallcnf on PXM, RPM-PR failed to erase the connection setup in NVRAM.

CSCds14812

During a switchcc, the AUSM Secondary active card LEDS show LOS for a while.

CSCds15610

PXM takes long time (10+ mins) to reprogram the connections after power recycle.

CSCds15835

When a user configures a CESM-T3 or E3 line in a local loopback, the dspalm display does not indicate that the loopback is configured on the line.

CSCds16990

When issuing clrsmcnf, an "auto:upLoadBram, Read file failure" can be seen on screen.

CSCds17001

Log file cannot be found for a particular slot.

CSCds18374

Reset of an FRSM-HS2 card corrupted the PXM card type matrix and it started displaying improper card types.

CSCds18459

The help string shows an incorrect value for the line rate.

CSCds18513

Error message while configuring the line rate gave a misleading reason for failure.

CSCds18524

Addcon help for CIR shows a range greater than the possible line rate.

CSCds18760

Local Connection ID returns wrong VPI on the slave side of addcon.

CSCds19141

The card goes into mismatched after the CLI cnfbctype.

CSCds19155

The tstcon passes for a deleted side of connection.

CSCds19333

The port loopbacks trap are not generated when the loopback is initiated using BERT.

CSCds19363

Details on this anomaly is not available at this time.

CSCds19477

Details on this anomaly is not available at this time.

CSCds19934

Port is generating a large number of async updates when the connection is made up/down.

CSCds20497

An alarm is not raised by the slave end when the corresponding master end is deleted.

CSCds25261

SNMP trap to indicate ILMI failure on AUSM card causes HP OpenView to crash.

CSCds25992

The command cnfplpp configures a line even when the line has not been added/enabled.

CSCds28525

The alarm status for the connection shown at CESM and PXM do not match. The CLIs tstcon and tstdelay fails for these connections.

CSCds38687

FRSM-8T1/E1 takes Invalid (lesser) no. of parameters in the addcon CLI and does not display any error message.

CSCds47676

When the clock level is configured to be STRATUM-3, the PXM trunk card does not receive the STRATUM-3 clock signal. The trunk card still gets the STRATUM-4 clock.

CSCds47699

The cnfupcvbr setting incorrect default ingress %util when parm=0.

CSCds47719

The xdspconstdabr and xdspcon displayed the contents of the first channel, when the channel number was given without the "-chn" prefix.

CSCds48610

Neither the VBR connections are getting higher bandwidth even when it has higher Maxbwinc values than CBR and ABR VCC's.

CSCds48615

The VBR connections are not getting a higher bandwidth even though their CLP-high and CLP-Low values are changed to Q-Max.

CSCds51198

RPM-PR crashes in boot mode when in dir c:

CSCds52875

The value of Maxbwinc is reset to 0 after this action and hence traffic is stopped.

CSCds52894

Maxbwinc in all queues can total up to more than 512; however, if the rtVBR queue set to Algorithm 3, the Minbwinc in nrtVBR, ABR, and UBR were set to 0; the rtVBR Minbwinc= 447.

CSCds53841

There are six type options available to set the CoS. No ConnServiceType option for rtVBR.

CSCds56829

After switchcc the Standby PXM back card still displays on.

CSCds59688

CESM/T3 & CESM/E3 failed to upgrade to 10.0.20 version.

CSCds60827

The FRSM 2CT3 VCCs were configured with CBR and CIR=4240.

CSCds63641

FRSM/T1 in an MGX1 Feeder node, added 470 CBR VCCs on port 1 with script.

CSCds64800

The FRSM/2T3 card was in Active, with 200 VCCs.

CSCds65754

Both PXM modules stuck in boot mode.

CSCds78615

Redundant PXM goes into failed state when restoring SM configuration.

CSCds81277

Adding a slave connection on FRSM-HS1/B returns a wrong Local Connection ID.

CSCds81743

A system error 21205 is sometimes seen after invoking a switchcc.

CSCds82088

The clrsmcnf gives wrong error message when the card is not present.

CSCds82667

Ports are Alarms Free when line and channels are on Alarms.

CSCds82670

delchans causes Telnet session to freeze.

CSCds83090

The clrsmcnf times out when deleting a non-existent port on FRSM-8E1.

CSCds83131

The clrsmcnf fails after a Service Module is replaced with an RPM.

CSCds83554

When doing a graceful upgrade, a system error is sometimes seen.

CSCds83584

The savesmcnf/restoresmcnf are not blocked for RPM cards even though the commands are not supported.

CSCds84695

Display for slot 14 disappears in MGX 8230.

CSCds85934

Restoring the SMs configuration takes a long time (8 to 20 mins) using CLI restoresmcnf <slot #>.

CSCds86720

One end of Frame Forwarding connection is permanently on Alarm.

CSCds86780

The dspcd, dspln, dsplns, dspport, dspports, dspcon, dspcons commands never prompt after adding multiple 3 segment connections.

CSCds87189

The RcvLOS count toggles between 0 and 252.

CSCds89200

SYSTEM ERROR 20301 logged after deleting a frame forwarding port.

CSCds89508

Able to configure the port N393 timer values less than N392.

CSCds89838

The delchans command causes SYSTEM ERROR 20404.

CSCds90056

DAX connections on FRSM-HS1/B are free of alarms after removing one of the two cards used to establish those connections.

CSCds91080

The addport command with wrong port type causes Data Bus Error.

CSCds92204

System Error 20617 caused by delchans command.

CSCdt00596

The dspcons command display is not aligned on FRSM-HS2

CSCdt00613

The dlecon or delchans commands when deleting connections cause System Error 20300.

CSCdt03252

The tstcon and tstdelay fail for the CESM-T3 to CESM-T3 three-segment connection.

CSCdt03580

Ungraceful upgrades of AUSM-8E1 sometimes fail when the configuration for the SM is lost. This problem occurred once.

CSCdt05474

A bit alarm on a three-segment connection is not propagated from PXM to FRSM-2T3

CSCdt05984

The xcnfchan command does not display the setup options correctly.

CSCdt07206

On a PXM to PXM feeder connection, when doing a dspchancnt on the ATM port side of the connection, "Discard Cells to Port" shows that cells have been discarded.


.

CSCdm22510

The NNI part of the connection is working correctly. A=0 is being sent from the tester to the local port of the FRSM and the remote port of the FRSM is sending A=0 to the remote port of the tester. However, Test Suite 16 of Bellcore's Frame Relay Protocol Conformance Certification Test Suites states "Since the active/inactive indication is independent of direction, the IUT(FRSM) Local port (DLCI 16) should transmit STATUS messages with ACTIVE status to the local test equipment." In other words port 1(Local port) of the FRSM should also transmit A=1 back to port 1(Local port) of the tester. This is stated in Frame Relay Forum Document No. FRF 2.1 Frame Relay Network-to-Network Interface Implementation Agreement. This was verified by Bellcore Engineers.

The last sentence of the expected results statement: "Since the active/inactive indication is independent of direction, the IUT Local port (DLCI 16) should transmit STATUS messages with ACTIVE status to the local test equipment." is correct as stated. This statement actually reflects a requirement from FRF 2.1 Section 4.2:

"PVC status information from full status reports and optionally from single PVC asynchronous status reports shall be propagated toward the user-to-network interface (UNI) of the multi-network PVC. The PVC status information element active bit state signaled at the NNI is independent of the PVC status information element active bit state signaled in the other direction at the same NNI."

Bidirectional status signaling requires that a user-side process and a network-side process execute concurrently. Nowhere in the requirements, Annex A, Annex D, FRF 2.1 does it state that these processes share information. They are totally independent. PVC status is signaled to the local user based on the service affecting conditions or PVC status signaled from the remote user side.

Polling Requirements of Network-to-network Interfaces

Two sets of sequence numbers and local in-channel signaling parameters are administered for the network-to-network interface as shown below; see the table for parameter ranges and default values.

User-side procedures: T391, N391, N392, and N393

Network-side procedures: T392, N392, and N393

The table below summarizes the acceptable values when using bidirectional procedures at the NNI. The default values should be used as the actual system parameter values. Parameter values other than the default values are a subscription time option. Procedures for starting and stop T391 and T392 are described in Q.933 Annex A.

Table 3 NNI System Parameters

Name
Range
Default
Units
Definition

N391

1-255

6

Polling Cycles

Full status (status of all PVCs) polling cycles.

N392

1-10

3

Errors

Number of errors during N393 monitored events which cause the channel/user side procedures to be declared inactive. This number may also be used by the user side procedures as the number of errors during N393 monitored events which cause the network side procedures to be declared inactive.

N393

1-10

4

Events

Monitored events count.

T391

5-30

10

Seconds

Link integrity verification polling timer.

T392

5-30

15

Seconds

Timer for verification of polling cycle.


Both networks are required to initiate status enquiry messages based on T391. A full status report is requested each N391 (default 6) polling cycles. Both networks shall have the same values for T391, T392, N392, and N393 for both user side procedures and network side procedures; N391 is not required to have the same value in both networks.

PVC status information from full status reports and optionally from single PVC asynchronous status reports shall be propagated towards the user-to-network interface (UNI) of the multi-network PVC. The PVC status information element active bit state signaled at the NNI is independent of the PVC status information element active bit state signaled in the other direction at the same NNI.


Note In addition, when a PVC segment's active/inactive status has changed, or a PVC segment has been newly added or deleted, the network should respond to any poll (i.e., status enquiry) with a full status report. Alternatively, the network may generate a single PVC asynchronous status report to convey the PVC segment's status change.


Known Anomalies for RPM release 12.1(1)T

1. The show rscprtn command on RPM will always display the state as "out of sync". This does not necessarily mean that the config on the PXM and RPM are out of sync. The PXM software 1.1.23 does not fully recognize a particular message from RPM and hence assumes that it is out of sync.

The user will still be able to add the connections. The only side effect is that there will be a syslog entry (and a message on the console, if not under Telnet) every five minutes.

2. WRED feature on the PA-A3 RPM is not functionally working.

Known Anomalies for RPM Release 12.0(5)T1

These RPM anomalies are tied to its function with the MGX 8850. For generic IOS issues, refer to the 12.0.5T1 release notes.

Under heavy load conditions from multiple sources, RPM performance may degrade (CSCdk91818)

Some RPMs may not boot when more than 8 RPMs are booting simultaneously from the PXM hard disk (CSCdm14987)

UBR connection for RPM is not supported from CWM, even though the CLI can support it


Note For more details refer to the CWM Release 9.2.05 release notes part number 78-6659-05


The ABR service type is not supported in 12.0.5T1/120.5.T1 release of MGX/RPM but the CLI does not restrict the provisioning.

Under heavy load conditions the counter (input queue size, packet output byte size) values reported may be incorrect particularly with Tag VP configuration.

It is required to allow OSPF and MPLS to converge while adding connections continuously. Otherwise, it will load the CPU and cause CPUHOG condition. Under such condition the IPC channel is not serviced which in turn will cause PXM to declare RPM in Failed state.

This problem will not occur when either enough time is given to the protocols to converge or the newly added connections are just added without enabling these protocols, and later these protocols are enabled on them.

To avoid this condition, you may limit the tag PVP connections to 75 or fewer. Above this, the TDP updates may create a CPUHOG condition (with CPU utilization very high). This in turn will break the IPC channel between PXM and RPM, and PXM will declare the RPM as Failed.

It is not recommended to shut the switch interface. Doing so will remove the connection to the MGX cell-bus and all connections will go down. It also generates some trace back error messages, which are benign. The 120-5.T image does not provide any caution or warning when the command is entered.

In some instances you may see RPM_VIRTUAL_PORT-3-IPCERR indicating that RPM was not able to convey the existing virtual port information to PXM. This situation is more likely to happen after clrallcnf is executed or the card is reset. At this point the connection database gets out of sync between RPM and PXM, and RPM experienced a problem in connection resync. However the connection eventually comes up successfully.

If not, the saved config needs to be copied to running config by "copy" command.

In multi-point configuration with inverse ARP, it is recommended to decrease the frequency from the default value of 15 min to 1 min.

If you are unable to overwrite on an existing config file on PXM disk and are getting the:

%error opening c: filename (bad file number)

message then delete:

(rm <filename>)

the existing file and then copy the new file.

In 120-5.T release when RPM re-loads, the "Status" column in the output of the "show switch connections" command show "MISMATCH" for all the connections or for a few connections even though the connections are fine and traffic passes through them without any problem.

If the PVC leg of the connections is added using the pvc command, then the "VCD" is chosen automatically for those PVCs. If the RPM is reloaded, then these VCD values might change. If they do change, then those connections will appear in the mismatched state.

This condition does not affect traffic. The problem can be avoided by using the atm pvc command which requires the user to specify the VCD value explicitly in the command. The "show switch connections nextvcd" command can be used to determine a VCD value that can be used with the atm pvc command.

In the event that the pvc commands were used and the connections go into the mismatched state, they can be cleaned up by re-adding the affected connections or if all the connections are affected and all of them are in the mismatched state, they can all be re-added using the "copy startup-config running-config" command.

This problem is fixed in the 120-5.T1 release.

RPM Configuration Examples for MPLS-based Virtual Private Networks

The following are MPLS VPN examples with MGX/RPM. These examples will be included in the online version of the Cisco RPM Installation and Configuration publication.

One PE - Two CE Configuration

The following is a one PE and two CE VPN configuration.


Note Both RPMs are in the same shelf or chassis.



                        e10/1/2
     +---------+e0/1          +---------+    PVC       +----------+ e14/1/2
     |  CE1    |--------------|  PE1    |--------------|  PE2     |------+
     | sys-2-1 |      +-------|         |sw1.1    sw1.1|          |      |
     +---------+      |       +---------+              +----------+      |
         | e0/3       | e10/1/3                                          |
         |            |                                                  |
         | e0/2       |                                                  |
     +---------+      |                                +----------+ e0/1 |
     |  CE3    |------+                                |  CE2     |------+
     | sys-2-2 |e0/1          PE1 ==> RPM-18-110       | sys-2-4  |
     +---------+              PE2 ==> RPM-18-114       +----------+

One PE - Two CE Configuration - OSPF & IBPG Between PEs & EBGP between PE-CE

CE1 Configuration:


sys-2-1#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-1
!
boot system tftp mpls/12.0/c3620-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 12.12.12.12 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.1 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 50.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 ip address 52.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 redistribute bgp 101
 passive-interface Ethernet0/1
 network 12.0.0.0 0.255.255.255 area 100
 network 52.0.0.0 0.255.255.255 area 100
!
router bgp 101
 no synchronization
 network 12.0.0.0
 network 13.0.0.0
 network 50.0.0.0
 network 51.0.0.0
 network 52.0.0.0
 neighbor 50.0.0.2 remote-as 100
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-1#
sys-2-1#


CE2 Configuration


sys-2-4#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-4
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 14.14.14.14 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.4 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 53.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 redistribute bgp 102
 passive-interface Ethernet0/1
 network 14.0.0.0 0.255.255.255 area 100
!
router bgp 102
 no synchronization
 network 14.0.0.0
 network 53.0.0.0
 neighbor 53.0.0.1 remote-as 100
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-4#
sys-2-4#


CE3 Configuration:


sys-2-2#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-2
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 13.13.13.13 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.2 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 51.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 ip address 52.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 redistribute bgp 101
 passive-interface Ethernet0/1
 network 13.0.0.0 0.255.255.255 area 100
 network 52.0.0.0 0.255.255.255 area 100
!
router bgp 101
 no synchronization
 network 12.0.0.0
 network 13.0.0.0
 network 50.0.0.0
 network 51.0.0.0
 network 52.0.0.0
 neighbor 51.0.0.1 remote-as 100
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-2#
sys-2-2#


PE1 Configuration:


rpm-18-110#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-110
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 11.11.11.11 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.110 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 ip vrf forwarding vpn1
 ip address 50.0.0.2 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
 tag-switching ip
!
interface Ethernet1/3
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 51.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 tag-switching ip
 no fair-queue
!
interface Ethernet1/4
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface FastEthernet2/1
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Switch1
 no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 30 30 0 aal5snap
 tag-switching atm vp-tunnel 30
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 60 60 0 aal5snap
 tag-switching atm vp-tunnel 60
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 passive-interface Ethernet1/3
 network 11.0.0.0 0.255.255.255 area 100
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 10.10.10.10 remote-as 100
 neighbor 10.10.10.10 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 neighbor 50.0.0.1 remote-as 101
 neighbor 50.0.0.1 activate
 neighbor 51.0.0.2 remote-as 101
 neighbor 51.0.0.2 activate
 no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 10.10.10.10 activate
 neighbor 10.10.10.10 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
x25 host shorun
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-110.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.2 30 rslot 0 3 30 master local
addcon vpc switch 1.1 50 rslot 14 1 50
addcon vpc switch 1.3 60 rslot 0 4 60 master local
end
rpm-18-110#
rpm-18-110#
rpm-18-110#


PE2 Configuration:


rpm-18-114#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-114
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 10.10.10.10 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.114 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 53.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 tag-switching ip
 no fair-queue
!
interface Ethernet1/3
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Ethernet1/4
 bandwidth 100
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no fair-queue
!
interface Switch1
 no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 40 40 0 aal5snap
 tag-switching atm vp-tunnel 40
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 20 20 0 aal5snap
 tag-switching atm vp-tunnel 20
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 network 10.0.0.0 0.255.255.255 area 100
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 11.11.11.11 remote-as 100
 neighbor 11.11.11.11 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 neighbor 53.0.0.2 remote-as 102
 neighbor 53.0.0.2 activate
 no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 11.11.11.11 activate
 neighbor 11.11.11.11 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-114.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.3 20 rslot 0 2 20 master local
addcon vpc switch 1.2 40 rslot 0 1 40
addcon vpc switch 1.1 50 rslot 10 1 50 master local
end
rpm-18-114#

One PE - Two CE Configuration - OSPF & IBPG Between PEs & RIP between PE-CE

CE1 Configuration


sys-2-1#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-1
!
boot system tftp mpls/12.0/c3620-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 12.12.12.12 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.1 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 50.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 ip address 52.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router rip
 version 2
 network 12.0.0.0
 network 50.0.0.0
 network 52.0.0.0
 no auto-summary
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-1#
sys-2-1#


CE2 Configuration


sys-2-4#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-4
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 14.14.14.14 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.4 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 53.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router rip
 version 2
 network 14.0.0.0
 network 53.0.0.0
 no auto-summary
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-4#
sys-2-4#
sys-2-4#


CE3 Configuration


sys-2-2#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-2
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 13.13.13.13 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.2 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 51.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 ip address 52.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router rip
 version 2
 network 13.0.0.0
 network 51.0.0.0
 network 52.0.0.0
 no auto-summary
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
!
x25 host shorun
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-2#
sys-2-2#


PE1 Configuration


rpm-18-110#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-110
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 11.11.11.11 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.110 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 ip vrf forwarding vpn1
 ip address 50.0.0.2 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
 tag-switching ip
!
interface Ethernet1/3
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 51.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 tag-switching ip
 no fair-queue
!
interface Ethernet1/4
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface FastEthernet2/1
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Switch1
 no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 30 30 0 aal5snap
 tag-switching atm vp-tunnel 30
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 60 60 0 aal5snap
 tag-switching atm vp-tunnel 60
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 passive-interface Ethernet1/3
 network 11.0.0.0 0.255.255.255 area 100
 network 50.0.0.0 0.255.255.255 area 100
 network 51.0.0.0 0.255.255.255 area 100
!
router rip
 version 2
 !
 address-family ipv4 vrf vpn1
 version 2
 redistribute bgp 100 metric 2
 network 50.0.0.0
 network 51.0.0.0
 no auto-summary
 exit-address-family
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 10.10.10.10 remote-as 100
 neighbor 10.10.10.10 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 redistribute rip
no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 10.10.10.10 activate
 neighbor 10.10.10.10 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-110.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.2 30 rslot 0 3 30 master local
addcon vpc switch 1.1 50 rslot 14 1 50
addcon vpc switch 1.3 60 rslot 0 4 60 master local
end
rpm-18-110#
rpm-18-110#


PE2 Configuration


rpm-18-114#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-114
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 10.10.10.10 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.114 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 53.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 tag-switching ip
 no fair-queue
!
interface Ethernet1/3
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Ethernet1/4
 bandwidth 100
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no fair-queue
!
interface Switch1
no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 40 40 0 aal5snap
 tag-switching atm vp-tunnel 40
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 20 20 0 aal5snap
 tag-switching atm vp-tunnel 20
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 network 10.0.0.0 0.255.255.255 area 100
 network 53.0.0.0 0.255.255.255 area 100
!
router rip
 version 2
 !
 address-family ipv4 vrf vpn1
 version 2
 redistribute bgp 100 metric 2
 network 53.0.0.0
 no auto-summary
 exit-address-family
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 11.11.11.11 remote-as 100
 neighbor 11.11.11.11 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 redistribute rip
 no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 11.11.11.11 activate
 neighbor 11.11.11.11 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-114.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.3 20 rslot 0 2 20 master local
addcon vpc switch 1.2 40 rslot 0 1 40
addcon vpc switch 1.1 50 rslot 10 1 50 master local
end
rpm-18-114#
rpm-18-114#
rpm-18-114#


One PE - Two CE Configuration - OSPF & IBPG Between PEs & STATIC ROUTES between PE-CE

CE1 Configuration


sys-2-1#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-1
!
boot system tftp mpls/12.0/c3620-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 12.12.12.12 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.1 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 50.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 ip address 52.0.0.1 255.0.0.0
 no ip directed-broadcast
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 passive-interface Ethernet0/1
 network 12.0.0.0 0.255.255.255 area 100
 network 50.0.0.0 0.255.255.255 area 100
 network 52.0.0.0 0.255.255.255 area 100
!
ip default-gateway 3.3.0.1
no ip classless
ip route 0.0.0.0 0.0.0.0 Ethernet0/1 50.0.0.2
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-1#
sys-2-1#


CE2 Configuration


sys-2-4#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-4
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 14.14.14.14 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
 ip address 3.3.30.4 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 53.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 passive-interface Ethernet0/1
 network 14.0.0.0 0.255.255.255 area 100
 network 53.0.0.0 0.255.255.255 area 100
!
ip default-gateway 3.3.0.1
no ip classless
ip route 0.0.0.0 0.0.0.0 Ethernet0/1 53.0.0.1
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-4#



CE3 Configuration


sys-2-2#sho run
Building configuration...

Current configuration:
!
version 12.0
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname sys-2-2
!
boot system tftp mpls/12.0/c3640-js-mz.120-5.0.2.T2 3.3.0.1
logging buffered 4096 debugging
no logging console
!
!
!
!
!
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
ip cef
cns event-service server
!
!
!
process-max-time 200
!
interface Loopback0
 ip address 13.13.13.13 255.255.255.255
 no ip directed-broadcast
!
interface Ethernet0/0
ip address 3.3.30.2 255.255.0.0
 no ip directed-broadcast
 shutdown
!
interface Ethernet0/1
 ip address 51.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/2
 ip address 52.0.0.2 255.0.0.0
 no ip directed-broadcast
!
interface Ethernet0/3
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/0
 no ip address
 no ip directed-broadcast
 shutdown
 no fair-queue
!
interface Serial1/1
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/2
 no ip address
 no ip directed-broadcast
 shutdown
!
interface Serial1/3
 no ip address
 no ip directed-broadcast
 shutdown
!
router ospf 100
 passive-interface Ethernet0/1
 network 13.0.0.0 0.255.255.255 area 100
 network 51.0.0.0 0.255.255.255 area 100
 network 52.0.0.0 0.255.255.255 area 100
!
ip default-gateway 3.3.0.1
no ip classless
ip route 0.0.0.0 0.0.0.0 Ethernet0/1 51.0.0.1
no ip http server
!
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
!
end
sys-2-2#
sys-2-2#
sys-2-2#


PE1 Configuration


rpm-18-110#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-110
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 11.11.11.11 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.110 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 ip vrf forwarding vpn1
 ip address 50.0.0.2 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
 tag-switching ip
!
interface Ethernet1/3
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 51.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 shutdown
 tag-switching ip
 no fair-queue
!
interface Ethernet1/4
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface FastEthernet2/1
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Switch1
 no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 30 30 0 aal5snap
 tag-switching atm vp-tunnel 30
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 60 60 0 aal5snap
 tag-switching atm vp-tunnel 60
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 passive-interface Ethernet1/3
 network 11.0.0.0 0.255.255.255 area 100
 network 50.0.0.0 0.255.255.255 area 100
 network 51.0.0.0 0.255.255.255 area 100
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 10.10.10.10 remote-as 100
 neighbor 10.10.10.10 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 redistribute connected
 redistribute static
 no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 10.10.10.10 activate
 neighbor 10.10.10.10 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
ip route vrf vpn1 12.0.0.0 255.0.0.0 Ethernet1/2 50.0.0.1
ip route vrf vpn1 13.0.0.0 255.0.0.0 Ethernet1/3 51.0.0.2
ip route vrf vpn1 50.0.0.0 255.0.0.0 Ethernet1/2 50.0.0.1
ip route vrf vpn1 51.0.0.0 255.0.0.0 Ethernet1/3 51.0.0.2
ip route vrf vpn1 52.0.0.0 255.0.0.0 Ethernet1/2 50.0.0.1
ip route vrf vpn1 52.0.0.0 255.0.0.0 Ethernet1/3 51.0.0.2
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-110.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.2 30 rslot 0 3 30 master local
addcon vpc switch 1.1 50 rslot 14 1 50
addcon vpc switch 1.3 60 rslot 0 4 60 master local
end
rpm-18-110#
rpm-18-110#
rpm-18-110#



PE2 Configuration


rpm-18-114#sho run
Building configuration...

Current configuration:
!
version 12.0
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname rpm-18-114
!
boot system tftp mpls/12.0/rpm-js-mz.120-5.T.bin 3.3.0.1
no logging console
!
!
!
!
!
clock timezone EST -5
clock summer-time EDT recurring
ip subnet-zero
no ip domain-lookup
ip host ios-lab-fw 3.3.0.1
!
!
ip vrf vpn1
 rd 100:1
 route-target export 100:1
 route-target import 100:1
ip cef
cns event-service server
!
!
process-max-time 200
!
interface Loopback0
 ip address 10.10.10.10 255.255.255.255
 no ip directed-broadcast
!
interface Loopback1
 no ip address
 no ip directed-broadcast
!
interface Ethernet1/1
 ip address 3.3.18.114 255.255.0.0
 no ip directed-broadcast
 no ip mroute-cache
 no keepalive
!
interface Ethernet1/2
 bandwidth 100
 ip vrf forwarding vpn1
 ip address 53.0.0.1 255.0.0.0
 no ip directed-broadcast
 no ip mroute-cache
 tag-switching ip
 no fair-queue
!
interface Ethernet1/3
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
!
interface Ethernet1/4
 bandwidth 100
 no ip address
 no ip directed-broadcast
 no ip mroute-cache
 no fair-queue
!
interface Switch1
 no ip address
 no ip directed-broadcast
 no atm ilmi-keepalive
!
interface Switch1.1 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 50 50 0 aal5snap
 tag-switching atm vp-tunnel 50
 tag-switching ip
!
interface Switch1.2 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 40 40 0 aal5snap
 tag-switching atm vp-tunnel 40
 tag-switching ip
!
interface Switch1.3 tag-switching
 ip unnumbered Loopback0
 no ip directed-broadcast
 atm pvc 20 20 0 aal5snap
 tag-switching atm vp-tunnel 20
 tag-switching ip
!
router ospf 100
 passive-interface Ethernet1/2
 network 10.0.0.0 0.255.255.255 area 100
 network 53.0.0.0 0.255.255.255 area 100
!
router bgp 100
 no synchronization
 no bgp default ipv4-unicast
 neighbor 11.11.11.11 remote-as 100
 neighbor 11.11.11.11 update-source Loopback0
 !
 address-family ipv4 vrf vpn1
 redistribute connected
 redistribute static
 no auto-summary
 no synchronization
 exit-address-family
 !
 address-family vpnv4
 neighbor 11.11.11.11 activate
 neighbor 11.11.11.11 send-community extended
 exit-address-family
!
ip default-gateway 3.3.0.1
no ip classless
ip route vrf vpn1 14.0.0.0 255.0.0.0 Ethernet1/2 53.0.0.2
ip route vrf vpn1 53.0.0.0 255.0.0.0 Ethernet1/2 53.0.0.2
no ip http server
!
dialer-list 1 protocol ip permit
dialer-list 1 protocol ipx permit
!
!
line con 0
 exec-timeout 0 0
 transport input none
line aux 0
line vty 0 4
 password lab
 login
!
exception core-file mpls/mgx/dumps/rpm-18-114.core
rpmrscprtn PAR 100 100 0 255 0 3840 4047
addcon vpc switch 1.3 20 rslot 0 2 20 master local
addcon vpc switch 1.2 40 rslot 0 1 40
addcon vpc switch 1.1 50 rslot 10 1 50 master local
end
rpm-18-114#

Route Processor Module (RPM) Addendum

This section describes the installation requirements and guidelines for RPM modules installed with Release 1.1.34.

About the Cisco IOS 12.1(5.3)T_XT Release

The Cisco IOS 12.1(5.3)T_XT or higher is used with MGX Release 1.1.32 and provides support for:

RPM-PR in any MGX chassis
(Note: RPM-PR is FCS with Release 1.1.32; and General Availability with Release 1.1.34.)

RPM/Bs in an MGX 8230 chassis

Multiple RPM card types

IOS 12.1(5.3)T_XT offers no other software features for the RPM.


Note To locate IOS-related anomalies or problems fixed, please refer to IOS release notes.


About the Cisco IOS 12.2(2)T2 Release

The Cisco IOS 12.2(2)T2 or higher is used with MGX Release 1.1.34. This IOS release does not support new RPM features, but has been tested with 1.1.34 and continues to support existing features on the RPM/PR and RPM/B cards.

RPM Compatibility Matrix

MGX SW version
1.1.24
1.1.31
1.1.32
1.1.34

"Bundled" IOS SW version

12.1(3)T

12.1(3)T

12.1(5.3)T_XT

12.2(2)T2

IOS Version for RPM-PR

not supported

not supported

12.1(5.3)T_XT*

12.2(2)T2

IOS for RPM/B in MGX 8230

not supported

not supported

12.1(5.3)T_XT

12.2(2)T2

CWM

9.2.08

10.3

10.4.01

10.4.01 Patch 1

Note *Support for RPM-PR is FCS with Release 1.1.32. General Availability of RPM-PR occurs with Release 1.1.34.



Special Upgrade Requirements for RPM

This section describes procedures for graceful firmware/hardware upgrades and downgrades in nodes.

Recommendations for Booting

You can boot the RPM/B or RPM/PR from any of the following sources:

From PXM Disk

NetBoot (TFTP server)

Booting from PXM Disk is faster than NetBoot

Recommendations for saving RPM configuration

The current implementation provides the following options:

Save on flash/boot-flash.

Save on PXM disk.

Save on network (TFTP server)

Save on RPM NVRAM (comes up faster; only for limited configuration size)

It is recommended to save the configuration on flash and on the PXM Disk, as well as on the network server. This ensures that the configuration can be restored, even in the case of multiple failures.

For example, if an RPM card has problems, you can copy the configuration from either the PXM disk or from the network to new RPM card. In case of multiple hardware failures (both RPM and PXM cards have problems) you can copy the configuration from the network server.

Replacing the existing RPM with a new card or a card with old configuration in flash

The existing configuration (of the old card) can be restored on the newly inserted card by following the instructions given below:


Step 1 Insert the new card into an unreserved empty slot. A previously used slot can be unreserved by giving the clrsmcnf command.

Step 2 Copy the old RPM's configuration (from the PXM disk or the network server) to the new card's bootflash. For example, copying from PXM disk: "copy c: <image name> bootflash:".

Step 3 Configure the new card to use the configuration in its bootflash using the boot config bootflash: <config-file-name> command.

Step 4 Save the changes using write mem command.

Step 5 Insert the new card into the old slot.


Please note that in RPM context the "config save/restore" feature of the PXM restores only the PXM part of the RPM configuration/connections. The RPM part of the configuration should also be saved from RPM CLI through copy command. For example, copy run c: <config-filename> for saving to PXM Disk for future restoration.

RPM Connection Resynchronization

The RPM Connection Resync process is supported in the 12.04T and higher releases. This feature checks for consistency between the RPM and PXM connection databases.

General Upgrade/Downgrade Guidelines

To perform an upgrade, the PXM should be upgraded first.

To perform a downgrade, the RPM should be downgraded first.

With any PXM release, only the last two IOS releases are supported

The following upgrade instructions are included in this section:

Upgrade the RPM Firmware

Upgrade a RPM/B Module to RPM-PR

Install an RPM-PR Module in a Fresh Slot

Operate an RPM/B or RPM-PR in an MGX 8230 Chassis

Upgrade the RPM Firmware


Step 1 Verify that any RPM modules are running one of the prior two IOS releases on the running PXM image. If not, the RPMs must first be upgraded to one of the last two releases.

Example: if the PXM is running a 1.1.24 image, then the RPM(s) should be running with the boot image and either the 12.1(2)XT or 12.1(3)T IOS release.

Step 2 TFTP the PXM new firmware image and RPM new boot image, IOS image to PXM disk.

Step 3 Follow the PXM graceful upgrade procedure to upgrade the PXM.

Step 4 Burn the latest RPM boot image in the RPM's flash.

a. Use of the format command to erase the flash is NOT recommended.

b. First copy the new RPM boot image to its flash.

c. Verify that the boot image is the first file in the flash.

d. Use the command dir bootflash: and delete all the files one by one till the new boot image file is shown as the first file.


Note Note that the copy command may return an error reporting a lack of space on the bootflash. If this occurs, delete some files from the bootflash and perform squeeze bootflash: to free that space. Then, try the copy command again.


Step 5 Modify the configuration file on the RPM(s) to point to the desired RPM IOS image. Use write memory to write it to the NVRAM. This will also write it to the C: drive if boot config C:auto_config_slotxx has been specified.

Step 6 Reset the RPM card so it can come up with the configured IOS image.

Step 7 Once the RPM successfully comes up, issue a squeeze bootflash: command to permanently erase the flash files deleted in Step 4.


Upgrade a RPM/B Module to RPM-PR

RPM-PR requires IOS Release 12.2(2)T2 or higher.


Caution Graceful hardware downgrades are not supported. Once a RPM/B card is replaced with a RPM-PR card, the RPM/B card can not be re-installed. If an attempt is made to re-install the RPM/B, the module will be put into 'Mismatch'.


Step 1 Insert the RPM-PR in a test node.

Step 2 Copy the new RPM boot image to the flash. Verify that boot image is the first file in the flash.

Step 3 Modify the configuration file to:

a. point to the latest RPM IOS image.

b. Verify that the RPM/B is configured to pick the configuration file from the C: drive. This is done using 'show bootvar' and checking for the 'CONFIG_FILE' variable. If the variable is set, add 'boot config C:auto_config_slotxx' to the configuration of RPM-PR.

c. Use "write memory" to write this configuration file to the NVRAM.

Step 4 Verify the following before inserting the RPM-PR in the node:

The PXM must be running a minimum firmware release of 1.1.34.

If replacing a RPM/B card when the PXM is running 1.1.34, verify that the RPM is a standalone card.


Install an RPM-PR Module in a Fresh Slot

This section contains instructions to insert an RPM-PR card in a fresh slot. RPM-PR requires IOS Release 12.2(2)T2 or higher.


Step 1 Insert the RPM-PR in a test node.

Step 2 Copy the new RPM boot image to the flash. Verify that boot image is the first file in the flash.

Step 3 Modify the configuration file to point to the latest RPM IOS image. Use write memory to write the configuration file to the NVRAM.

Step 4 Verify the PXM is running a minimum firmware release of 1.1.34 before inserting the RPM-PR.


Operate an RPM/B or RPM-PR in an MGX 8230 Chassis


Step 1 Verify that MGX 1.1.34 is loaded on the PXM.

Step 2 Load IOS 12.2(2)T2 or higher onto the MGX 8230 C: drive.


Note A copy of IOS 12.2(2)T2 may be obtained at the Cisco Software Center
http://www.cisco.com/public/sw-center/

The filename is: rpm-js-mz.122-2.T2

A laptop or workstation with an IP stack will be required to access this FTP location.


Step 3 Boot the RPM/B and copy the IOS 12.2(2)T2 image to the RPM/B flash.

Step 4 Reboot the RPM/B with the IOS 12.2(2)T2 image.


New CLI Commands for RPM

The new CLI commands for the Route Processor Module are:

atm (ping command)

privilege exec level 0 ping ip

atm pvp <vpi> (for configuring a VPC connection on RPM)

debug rpm ecc

debug rpm ecc [number]


Note For configuration information on the Route Processor Module (RPM), see the Cisco Route Processor Module Installation and Configuration Guide.


ATM ping command for the RPM

This command provides a single point of reference from which troubleshooting can be performed along with the round-trip transit time information. The command syntax is:

atm <switch interface> <vpi> <vci> {seg-loopback | end-loopback} [<repeat>] [<timeout>]

For example, issuing the command "atm sw1.200 0 300 end-loopback" would give 53 byte OAM echoes to the connection end-point over VPI 0, VCI 300 and provide a reliability and round-trip time measurement. The command can be extended so that the default repeat and timeout values can be modified. The command can be issued even when the OAM management is configured to run periodic background test on the same VC. The user can abort the command by the escape sequence before the command finishes.

Due to the inclusion of the new ATM ping command, the command privilege exec level 0 ping provides only standard pings. To have extended ping capability, the following, use the command privilege exec level 0 ping ip.

ATM pvp <vpi> command for configuring a VPC connection on RPM

This command is not new, but is necessary in order to configure an OAM-managed PVC for a VPC connection. When configuring a VPC connection on RPM, you must configure PVP parameters under the main interface, SW1. If these configurations are not performed first, the OAM-managed PVCs, which are part of this VPI will not function.

Before configuring the PVC, configure the PVP under the SW1 interface by entering the following interface configuration command:

atm pvp <vpi> <pcr>

or

pvp <vpi> <pcr>

Parameter
Description

<vpi>

The VPI number to be used.

<pcr>

The bandwidth to be allocated (default OC3).


debug rpm ecc

This new CLI command displays the number of ECC errors since the system was booted.

debug rpm ecc [number]

This new CLI command allows an administrator to determine the number of ECC errors (since the system was booted) that will result in a switch over.

Problems Fixed with IOS 12.1(5.3)T_XT

Please refer to the IOS 12.1 Release Notes at:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121relnt/index.htm

Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at the following sites:

http://www.cisco.com

http://www-china.cisco.com

http://www-europe.cisco.com

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:

Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
