Setting Up Secure Device Provisioning (SDP) for Enrollment in a PKI
First Published: May 2, 2005Last Updated: March 20, 2008RSF Note - Update 12.5(1st)T Release number - global
This module describes how to use Secure Device Provisioning (SDP) in a public key infrastructure (PKI). SDP is a web-based certificate enrollment interface that can be used to easily deploy PKI between two end devices, such as a Cisco IOS client and a Cisco IOS certificate server. The end devices may or may not be directly connected to the network at the time of deployment or provisioning. SDP provides a solution for users deploying a large number of peer devices (including certificates and configurations).
Finding Feature Information in This Module
Your Cisco IOS software release may not support all of the features documented in this module. To reach links to specific feature documentation in this module and to see a list of the releases in which each feature is supported, use the "Feature Information for SDP in a PKI" section.
Finding Support Information for Platforms and Cisco IOS and Catalyst OS Software Images
Use Cisco Feature Navigator to find information about platform support and Cisco IOS and Catalyst OS software image support. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Contents
•
Prerequisites for Setting Up SDP
•
•
•
Prerequisites for Setting Up SDP
Setting Up SDP for Enrollment in a PKI
Before you set up SDP, your environment should meet the following requirements:
•
•
•
•
Setting Up SDP for Enrollment in a PKI Using USB Tokens
To leverage USB tokens to provision devices with SDP, your environment should meet the following requirements:
•
•
•
•
•
•
Note
Using SDP To Configure a Device for an Internet Connection Through a Service Provider
To leverage SDP to configure a device that is not connected to the Internet, your environment should meet the following requirements:
•
•
•
•
Information About Setting Up SDP for Enrollment in a PKI
Before using SDP for certificate enrollment, you should understand the following concepts:
•
•
SDP Overview
SDP (also referred to as Trusted Transitive Introduction [TTI]) is a communication protocol that provides a bidirectional introduction between two end entities, such as a new network device and a Virtual Private Network (VPN). SDP involves the following three entities (see Figure 1):
•
–
•
•
Figure 1 Post-Introduction Secure Communication
As of Cisco IOS Release 12.5(1st)T or a later release, the introducer can start the SDP process without the petitioner having prior Internet connectivity established. The use of the prep-connect phase and the connect phase provides the ability to configure a petitioner for Internet connectivity through a service provider. For more information on the prep-connect phase and the connect phase, see the section "How SDP Works."
The registrar communicates directly with an external authentication, authorization, and accounting (AAA) server to verify petitioner credentials, permit or deny enrollment, and retrieve specific petitioner configuration information. The petitioner and registrar server web pages to the introducer, the end user. The petitioner receives the bootstrap configuration from a remote management system via the introducer's web browser.
SDP is implemented over a web browser with six possible phases—prep-connect (optional), connect, start (optional), welcome, introduction, and completion. Each phase is shown to the user via a web page. For more information on each phase, see the section "How SDP Works."
How SDP Works
The following sections describe how SDP deploys PKI between two devices:
The SDP process starts with one of three entry pages being loaded into the web browser by the introducer: the SDP prep-connect phase received from the administrator; the start phase loaded from the registrar; or the welcome phase loaded from the petitioner.
The sample figures show how to introduce the local device (the petitioner) to the secure domain of the registrar. The "introducer" is referred to as the end user.
SDP Prep-Connect Phase
The prep-connect page is optional. Without the prep-connect page, the petitioner must have IP connectivity established.
The administrator must configure the prep-connect template and send the prep-connect page to the introducer. For more information on configuring the prep-connect template, see the section "Default Prep-Connect Template."
The administrator must also obtain and communicate the username and password for the secure network to the introducer by a telephone call, an email, a secure email, a CD, or a USB token. The registrar may be configured to authenticate the introducer using an existing AAA infrastructure for example, an existing username and password database that is part of the existing corporate domain. The SDP prep-connect phase supports a one time password mechanism as is used by common AAA infrastructures. For more information on SDP and AAA, see the section "How SDP Uses an External AAA Database."
After receiving the prep-connect page, the introducer must load the page onto the computer where the HTTP browser will run. The introducer then loads the prep-connect page into the HTTP browser as a local file and then the prep-connect page is displayed (see Figure 2).
Figure 2 Sample SDP Prep-Connect Page
After the introducer selects the "Log onto Cisco Device" button, the login dialog box is displayed (see Figure 3). The introducer enters the factory default username (cisco) and password (cisco) of the Cisco device.
Figure 3 Sample Petitioner Login Dialog Box
The introducer authenticates with the petitioner and then Internet connectivity is tested by attempting to access a known URL. Access to www.cisco.com (198.133.219.25) is tested by default. The administrator can modify the URL to be used for testing connectivity by modifying the default prep-connect template. For more information about modifying the default test URL and other fields that the administrator may configure for the prep-connect page, see the section "Default Prep-Connect Template."
Note
If Internet connectivity is established the start page or welcome page is displayed, depending on the prep-connect template setting as defined by the administrator. If Internet connectivity is not established, the connect page is displayed.
SDP Connect Phase
The connect page is displayed only if the prep-connect page is used and there is no IP connectivity for the petitioner at the completion of the prep-connect phase. The connect page has three IP address assignment methods to allow flexibility for your Cisco IOS platform: Dynamic Host Configuration Protocol (DHCP), Point to Point Protocol over Ethernet (PPPoE), or static IP address assignment.
Note
DHCP IP Address Assignment Method
If the introducer selects DHCP, the default method, for the IP address assignment method option (see Figure 4), pressing the Connect button causes petitioner to be configured for Internet connectivity.
Figure 4 Sample Connect Page for DHCP IP Address Assignment Method
PPPoE IP Address Assignment Method
If the introducer selects PPPoE, input fields for PPPoE username and password are displayed (seeFigure 5). The introducer must enter a the username and password as supplied by the Internet service provider then press the Connect button, which causes petitioner to be configured for Internet connectivity.
Figure 5 Sample Connect Page for PPPoE IP Address Assignment Method
Static IP Address Assignment Method
If the introducer selects static, input fields for the IP address, netmask, and the default gateway are displayed (see Figure 6). The introducer must enter the configuration values as supplied by the Internet service provider then press the Connect button, which causes petitioner to be configured for Internet connectivity.
Figure 6 Connect Page for Static IP Address Assignment Method
Connect Page IP Address Configuration
After IP address configuration, Internet connectivity is tested again by attempting to access a known URL configured by the administrator in the prep-connect template (www.cisco.com by default). If Internet connectivity is now established the start page or welcome page is displayed, depending on the prep-connect template setting as defined by the administrator. If Internet connectivity is not established, the introducer should verify the settings entered or contact their administrator.
SDP Start Phase
The start page is optional. Without the start page, during the SDP exchange, the user clicks the Next button on the welcome page and is sent to the registrar's introduction page. Because the user has not previously connected to the registrar, the user is required to log in to the registrar using available credentials (per the registrar configuration). Some browsers fail to reconnect to the registrar after the user credentials are requested (after the user has entered the login data). As of Cisco IOS Release 12.4(4)T, users may configure their browsers to begin the SDP exchange by contacting the registrar's introduction URL via a start page. Thereafter, the registrar can direct the user to the welcome page, which is on the petitioner device. The SDP transaction will then continue through the welcome, introduction, and completion phases as described in this document.
To begin the SDP transaction from the registrar, the user must configure the browser via the template http start command; otherwise, the SDP transaction must begin from the welcome page on the petitioner. For more information on how to configure a custom template, see the section "How Custom Templates Work with SDP."
Before the welcome page is displayed, the user must direct his or her browser to the start page via the URL "http://registrar/ezsdd/intro". A login dialog box is then displayed and the end user can log into the registrar via a username and password supplied by the administrator to access the secure network (see Figure 7).
Figure 7 Registrar Remote Login Dialog Box
After entering a valid user name and password, the start page is displayed (see Figure 8).
Figure 8 Sample SDP Start Page
After entering the URL of the petitioner's welcome page (for example, http://10.10.10.1/ezsdd/welcome) and clicking the Next button on the start web page, the end user enters the SDP welcome phase and logs into his or her petitioner as shown in Figure 9.
SDP Welcome Phase
The welcome phase begins when the user clicks the Next button on the start page. Before the welcome page is displayed, the user must log into the petitioner via the URL "http://10.10.10.1/ezsdd/welcome." The local login dialog box is then displayed (see Figure 9). The end user can then log into the local device via the factory default username (cisco) and password (cisco).
Figure 9 Petitioner Local Login Dialog Box
After the password is successfully entered, the welcome web page is displayed (see Figure 10), which is served by the petitioner.
Figure 10 Sample SDP Welcome Page
After entering the URL of the registrar (for example, http://192.0.2.155/ezsdd/intro) and clicking the Next button on the welcome web page, the SDP introduction phase begins and the introduction page is displayed, which is served by the registrar.
SDP Introduction Phase
Before the introduction page is displayed, the end user must log into the registrar if the user has not already done so from the start page (see "SDP Start Phase"), which utilizes the external AAA database.
With an external AAA database, the introducer can use an account on the database to perform the introduction without requiring knowledge of the enable password of the registrar. Without an external AAA database, the introducer may use the enable password of the registrar for authentication.
Note
The administrative introducer is identified by the HTTP authentication for the introduction page (or the start page), with the AAA database query returning administrative privilege for the user. If the introducer has administrator privilege, the device name is that which was entered in the administrative introduction page. If the introducer does not have administrative privileges, the device name is the introducer name. The existing device certificate is the current certificate on the petitioner, which may be the manufacturing identification certificate (MIC). This certificate may or may not exist. For more information on the function of the external AAA database, see the section "How SDP Uses an External AAA Database."
After the end user successfully enters his or her password, the introduction web page is displayed (see Figure 11).
Figure 11 Sample SDP Introduction Page
At this point, the registrar passes device information to the external management system to obtain a bootstrap configuration file. For more information on options available to identify a customized bootstrap configuration file, see the section "Custom HTML Template Expansion Rules."
After the end user clicks the Next button on the introduction page, the end user enters the completion phase and automatically returns to his or her local device.
SDP Completion Phase
Now that the end user has enrolled the petitioner with the registrar, the petitioner will serve the completion page (see Figure 12).
Figure 12 Sample SDP Completion Page
The SDP exchange is now complete. The petitioner has received configuration information from the registrar and should received a certificate from the registrar shortly.
SDP Leveraging USB Tokens
SDP provides for highly scalable deployments and streamlines the deployment of an individual device or multiple devices. USB tokens provide for secure storage and configuration distribution.
As of Cisco IOS Release 12.4(15)T or a later release, USB tokens may be utilized to transfer PKI credentials using SDP to a remote device, and SDP may be used to configure the USB token. The USB token may then be used to provision a device at the same location, or the USB token may be transported to another location where it may be used to provision a remote device. For more information about configuring and using USB tokens, see the "Related Documents" section.
An example SDP deployment using a USB token to transfer PKI credentials is shown in Figure 13. The required devices include the USB token and the SDP entities required to provision a device. These SDP entities are the introducer, the registrar, a petitioner at the local location, Petitioner A, and a petitioner at the remote location, Petitioner B. Optionally, a management server may be used.
Note
Figure 13
Example SDP Environment Using USB Tokens to Transfer Credentials
Use of SDP to Configure the USB Token
Prior to initiating an SDP introduction a USB token is inserted into the petitioner device. In the example configuration shown in Figure 13, the USB token would be inserted into Petitioner A. The petitioner may be configured to ignore any existing information on the USB token. As in regular SDP operations, for a scalable configuration of USB tokens, an initial template configuration has to be prepared and placed onto each SDP device with appropriate target configuration information.
Files used to provision a device are moved in the following sequence, shown by the numbered arrows in Figure 13.
1.
The URL for the binary file location is expanded on the registrar. Binary files are not processed through the template expansion functions. The template expansion occurs on the registrar for both the source URL and destination URL.
By default, binary files and template files will be retrieved from and stored to NVRAM on the registrar and petitioner respectively. The binary file location on the registrar and the destination binary file location on Petitioner A may be specified with the binary file command. The template file location on the registrar and the destination template file location on Petitioner A may be specified with the template file command.
2.
3.
4.
SDP Phases with a USB Token
The same SDP phase concepts introduced in the "SDP Overview" section are used, with the following distinctions in the SDP welcome phase, the SDP introduction phase, and the SDP completion phase.
SDP Welcome Phase with a USB Token
The SDP welcome phase begins as usual, when an introduction is initiated by connecting to the welcome user interface. If there is an existing certificate on the USB token, it will be used for signing the SDP exchange. Instead of a local RSA key pair, a new RSA key pair on the token is used.
Note
The new key pair generated by Petitioner A is added to the USB token without removing any existing RSA key pairs. SDP AV pairs indicate both that a token is being used and if there is any token secondary configuration information. If an optional management server is in use, the AV pair information is used to determine if any special configuration commands are needed.
SDP Introduction Phase with a USB Token
The SDP Introduction phase begins with AV pairs being transferred to the registrar. When the registrar detects USB token related AV pairs, the registrar, if previously configured, may prepare configuration information destined for the USB token. Currently configuration commands are sent as a specific configuration files that are subsequently merged with the running configuration.
The administrator can leverage normal SDP configuration commands to configure the USB token. USB token information that should be configured includes the certificate, the bootstrap configuration, and the PIN number configuration.
SDP Completion Phase with a USB Token
At the beginning of the completion phase, the introduction proceeds with AV pairs being transferred to the petitioner (in Figure 13, this would be Petitioner A). The various files are stored in the specified file system locations and then the existing configuration file processing proceeds. This ordering allows the configuration to take advantage of the new files that have been transferred.
Use of the Configured USB Token
After the USB token is configured by Petitioner A, it is transported from its current location to the remote location, where the second petitioner, Petitioner B is located. The USB token is inserted into the target device, Petitioner B, which then inherits the USB token configuration and cryptographic material from the USB token. The end user at the remote location must have the PIN number on the USB token. The PIN number is either the default factory PIN or the PIN number the administrator configured during the introduction phase.
How SDP Uses an External AAA Database
The external AAA database is accessed twice during the SDP exchange. The first time the AAA database is accessed the introducer is authenticated; that is, when the registrar receives an introduction request via the secure HTTP (HTTPS) server, the registrar does an AAA lookup based on the introducer's username and password to authorize the request. The second time the AAA database is accessed authorization information is obtained and applied to the configuration and certificates that are issued to the petitioner device; that is, the registrar checks the integrity of the request by verifying the request signature using the petitioner-signing certificate. The certificate subject name may be specified in the AAA database, and up to nine configuration template variables may be specified and expanded into the template configuration.
Use of a Self-Signed Certificate Versus a Certificate Issued by Another CA Server
By default, the SDP exchange results in only one certificate being issued to the petitioner device. Although just one certificate is issued, the introducer is not restricted from introducing multiple devices and thus obtaining multiple certificates. By specifying the subject name in the certificate that is issued, you can be assured that all certificates that are issued in this way are associated with the introducer. You can use PKI AAA integration to further restrict the use of these certificates. Additionally, the AAA database can be configured to accept only one authentication and authorization request per user.
Because the petitioner certificate is self-signed, it is just used to convey the public key of the petitioner. No verification or authorization check is performed on the certificate; thus, authorization is per-user based and no per-device information is used.
There are some scenarios when per-device authorization is preferred. Therefore, if the petitioner is able to use certificates issued by other certification authority (CA) servers for SDP transactions, the existing PKI can be used and authorization can be achieved over the certificate attributes.
Configuring the petitioner and the registrar for certificate-based authorization provides authorization of the specific device being deployed. Previously, introducer-to-petitioner device communication was secured only using physical security between the introducer and the petitioner device. SDP certificate-based authorization gives the registrar an opportunity to validate the current device identity before accepting the introduction.
Authentication and Authorization Lists for SDP
When you are configuring your SDP registrar, if you specify an authentication list and an authorization list, the registrar uses the specified lists for all introducer requests. The authentication list is used when authenticating the introducer (the AAA server checks for a valid account by looking at the username and password). The authorization list is used to receive the appropriate authorized fields for the certificate subject name and a list of template variables to be expanded into the Cisco IOS command-line interface (CLI) snippet that is sent back to the petitioner. The authentication and authorization lists will usually point to the same AAA server list, but it is possible to use a different database for authentication and authorization. (Storing files on different databases is not recommended.)
When a petitioner makes an introduction request, multiple queries are sent to the AAA list database on the RADIUS or TACACS+ server. The queries search for entries of the following form:
user Password <userpassword>cisco-avpair="ttti:subjectname=<<DN subjectname>>"cisco-avpair="tti:iosconfig#<<value>>"cisco-avpair="tti:iosconfig#<<value>>"cisco-avpair="tti:iosconfig#=<<value>>"
Note
If a subject name was received in the authorization response, the SDP registrar stores it in the enrollment database, and that "subjectname" overrides the subject name that is supplied in the subsequent certificate request (PKCS10) from the petitioner device.
The numbered "tti:iosconfig" values are expanded into the SDP Cisco IOS snippet that is sent to the petitioner. The configurations replace any numbered ($1 through $9) template variable. Because the default Cisco IOS snippet template does not include the variables $1 through $9, these variables are ignored unless you configure an external Cisco IOS snippet template. To specify an external configuration, use the template config command. For more information on external configurations, see the section "Custom Configuration and File Template Variable Expansion Rules at the Petitioner."
Note
Authentication and Authorization Lists for an Administrative Introducer
The SDP mechanisms assume a permanent relationship between the introducer and the device. As a result, the introducer username is used to define the device name.
In some SDP deployment scenarios, the introducer is an administrator doing the introduction for many devices. However, using the introducer (the administrator) name to define the device name results in multiple devices being incorrectly deployed with the same device name. Instead, an administrative introducer allows the administrator to specify the correct device name during the introduction.
More generally stated, the introducer username is used as the database record locator to determine all other information about the device including the Cisco IOS configuration template, various template variables (pulled from an AAA database and expanded into the template), and the appropriate subject name for PKI certificates issued to the device. For simplicity, this database record locator is called the user/device name.
The administrative introducer provides a device name. In that way, an administrator can provide the appropriate record locator when doing an introduction. For example, if an administrator is trying to introduce a device for username "user1," the administrator introduces the device into the PKI network and provides user1 as the record locator after logging into the registrar using the administrator's own credentials. The record locator, user1, becomes the device name. All other template and PKI certificate subject name information specific to the introduction is then provided by the user1 username records instead of by the administrator's record.
The registrar device uses the supplied username information with a user introducer name. The username allows the existing mechanisms for determining a user's authorization, template, and PKI certificate information to be supported without modification.
How Custom Templates Work with SDP
You may use custom templates to streamline the SDP process.
•
•
An easy way to define a custom template is to modify the default template. Without custom templates, the introducer must contact the registrar for information to begin the SDP transaction. For a list of the default templates, see the section "Default Templates for SDP Transaction Web Pages."
Note
Custom Template Variable Expansion
There are expansion variables in the templates that are replaced by the Cisco IOS SDP registrar or petitioner. These variables are expanded as follows:
•
•
•
•
•
•
•
•
•
•
•
•
Custom Template Variable Expansion Rules
Configuration and templates are used during an SDP exchange. Prior to use and after distribution, these templates are expanded using the following rules based in the SDP communication stage.
Custom HTML Template Expansion Rules
HTML templates are expanded immediately before being served to the HTTP client. The HTTP templates are expanded as follows:
•
•
•
•
•
<INPUT type=hidden NAME="attribute string here"
value="variable string here"><BR>
all HTML templates should have this!
$d = dump all av pairs in: attribute = value<BR>
URL Template Expansion Rules
There are URLs for the configuration template source, the file template source, and the file destination. These variables are expanded when the registrar prepares the URL, just before retrieving the configuration or file. For the file destination, these variables are expanded just before the petitioner copies the file to the file destination.
•
•
Custom Configuration and File Template Variable Expansion Rules
Custom configuration and file template variables are expanded both when the registrar prepares the configuration or file template and when the petitioner receives the configuration or file template.
Custom Configuration and File Template Variable Expansion Rules at the Registrar
When the registrar expands the configuration or file template, the following variables are used by the Cisco IOS CA. These variables are expanded before being sent through the SDP wizard.
•
•
•
•
Custom Configuration and File Template Variable Expansion Rules at the Petitioner
When the petitioner expands the configuration or file template, the following variables are expanded:
•
•
•
•
•
•
•
Custom Configuration HTTP Template Variable Expansion Rules
Custom configuration HTTP templates provide flexibility for backend Common Gateway Interface (CGI) scripts and integration with external management systems. Template URLs run through the HTTP template expansions before registrar retrieves the bootstrap configuration from the external management system. The device name ($n) is expanded into the URL and passed to the external management system so that a specific bootstrap configuration file can be located based on the device information.
Note
The HTTP template expansion and template config command allow you to specify either of the following file types to obtain a customized bootstrap configuration file:
•
•
As of Cisco IOS Release 12.4(6)T, the CGI support has been expanded so that the bootstrap configuration can be identified by not only the device name, but also the type, current Cisco IOS version information, and current configuration. This functionality expands the template config command with the post keyword, which tells the registrar to send this additional device information to the external management system via a CGI script with the HTTP or HTTPS protocol only.
The registrar passes the device information via AV pairs ($a) to the external management system. Using the AV pair information, the management system identifies the appropriate bootstrap configuration files and sends it back to the registrar. The additional AV pairs that are sent with the expanded CGI support for identification of customized bootstrap configuration file are shown in .
Note
Default Templates for SDP Transaction Web Pages
The following default templates exist for each SDP transaction web page:
•
•
•
•
•
Default Prep-Connect Template
The prep-connect template may be modified by the administrator to contain values that are appropriate for their environment. The format of the prep-connect page may also be modified by the settings contained in the template.
Except for the registrar IP address, which the administrator must customize, the prep-connect template may be used as shown below.
<html><head><title>SDP: Test Internet Connection</title></head><noscript><b>If you see this message, your browser is not running JavaScript,<br>which is required by Cisco Secure Device Provisioning.<br>If you cannot enable JavaScript, please contact your system administrator.<br><br></b></noscript><body style="background-color: rgb(204, 255, 255);"><div style="text-align: center;"><big><big>Secure Device Provisioning</big><br>Test Internet Connection</big><br><br><form action="http://10.10.10.1/ezsdd/connect" method="post"><input type="submit" value="Log onto Cisco Device"><br><br>Default username/password is cisco/cisco.<input type="hidden" name="TTIAfterConnectURL"value="http://10.10.10.1/ezsdd/welcome"><!-- Note, that for the below, 198.133.219.25 = www.cisco.com. --><input type="hidden" name="TTIConnectTestURL" value="http://198.133.219.25"><input type="hidden" name="TTIInsideAddr" value="10.10.10.1"><input type="hidden" name="TTIlanport" value="Vlan1"><input type="hidden" name="TTIwanport" value="FastEthernet4"></form></div></body></html>Hidden HTML Form Fields
The hidden HTML form fields communicate initial configuration information to the browser as set by the administrator and are not signed.
Note
The administrator can set the following hidden HTML form fields in the prep-connect template.
Table 2 Administrator Defined AV Pairs Sent During Prep-Connect Phase
Note
Default Start Page Template
<html><head><title>EZ-Secure Device Deployment Start page on $h</title></head><NOSCRIPT><B>If you see this message, your browser is not running JavaScript.<BR>Cisco Secure Device Deployment requires JavaScript.<BR> Please contactyour system adminstrator.<BR><BR></B></NOSCRIPT><SCRIPT LANGUAGE="JavaScript">function submit_to_url(form){form.action=form.TTIWelcomeURL.value;return true;}</SCRIPT><B>Welcome to Cisco Secure Device Deployment Server $h</B> <FORMaction="" method="post" onSubmit="return submit_to_url(this)"> Yourdevice:<BR> <INPUT type="text" name="TTIWelcomeURL" size=80value=\"\"><BR><BR> <INPUT type="submit" value="Next>"><BR>$a</FORM></html>Default Welcome Page Template
<html><head><title>EZ-Secure Device Deployment WELCOME to $h</title></head><NOSCRIPT><B>If you see this message, your browser is not running JavaScript.<BR>Cisco Secure Device Deployment requires JavaScript.<BR> Please contactyour system adminstrator.<BR><BR></B></NOSCRIPT><SCRIPT LANGUAGE=\"JavaScript\">function submit_to_url(form){natURL=location.href.split(\"/\");localURL=form.TTICompletionURL.value.split(\"/\");if(natURL[2]!=localURL[2]){form.TTICompletionURL.value=localURL[0]+\"//\"+natURL[2]+\"/\"+localURL[3]+\"/\"+localURL[4];}form.action=form.vpnserviceurl.value;return true;}</SCRIPT><B>Welcome to Cisco Secure Device Deployment for $h</B> <FORMaction=\"\" method=\"post\" onSubmit=\"return submit_to_url (this)\">To join a Virtual Private Network (VPN) enter the web<BR> site URLprovided by your network administrator:<BR> <INPUT type=\"text\"name=\"vpnserviceurl\" size=80 value=\"\"><BR><BR><INPUTtype=\"submit\" value=\"Next>\"><BR> $a</FORM></html>Default Introduction Page Template
<html><head><title>EZ-Secure Device Deployment INTRODUCTION to $h</title></head><B>Welcome to the VPN network gateway on $h</B> <FORMaction=\"$u\" method=\"post\"> Your 'username' and 'password' enteredhave been accepted.<BR> Your device will now be allowed toautomatically join the VPN network.<BR> <BR>Press Next to completeautomatic configuration of your VPN Device.<BR> <BR><INPUTtype=\"submit\" value=\"Next>\"><BR> $a</P></FORM></html>Default Admin-Introduction Page Template
<html><head><title>EZ-Secure Device Deployment ADMINISTRATIVEINTRODUCTION to $h</title></head> <NOSCRIPT><B> If you see thismessage, your browser is not running JavaScript.<BR> Cisco SecureDevice Deployment requires JavaScript.<BR> Please contact your systemadminstrator.<BR><BR></B></NOSCRIPT><SCRIPT LANGUAGE=\"JavaScript\">function submit_to_url(form){form.introadminurl.value=location.href+\"/admin\";form.action=form.introadminurl.value;return true;}</SCRIPT><B>Welcome to the VPN network gateway on $h</B> <FORM action=\"\"method=\"post\" onSubmit=\"return submit_to_url (this)\"> Youradministrator 'username' and 'password' entered have beenaccepted.<BR> Please provide the name to be associated with thisdevice:<BR> <INPUT type=\"text\" name=\"userdevicename\" size=64value=\"\"><BR><BR> <INPUT type=\"submit\" value=\"Next>\"><BR> <INPUTtype=\"hidden\" name=\"introadminurl\" value=\"\"><BR>$a</FORM></html>Default Completion Page Template
<html><head><title>EZ-Secure Device Deployment COMPLETE on $h</title></head><B>Now enrolling $h with the VPN network...</B><BR> Full network VPNaccess should be available in a moment.<BR><BR> $d<BR></html>Default Template for the Configuration File
The default configuration template is shown below. This default configuration file is used if a configuration template is not specified or if the template config command is issued without the post keyword. For more information on using the default configuration template, see the section "Using a Configuration Template File: Example."
$t!$c!endHow to Set Up SDP for a PKI
This section contains the following procedures that should be followed when setting up SDP for your PKI. You can configure the registrar according to only one of the registrar configuration tasks.
•
•
•
Enabling the SDP Petitioner
Perform this task to enable or disable the petitioner and associate a trustpoint with the SDP exchange.
You can also use this task to configure the petitioner to use a certificate and the Rivest, Shamir, and Adelman (RSA) keys associated with a specific trustpoint.
Note
Note
Prerequisites
•
•
SUMMARY STEPS
1.
2.
3.
4.
or
trustpoint signing trustpoint-label
5.
DETAILED STEPS
Troubleshooting Tips
After the SDP exchange is complete, a new trustpoint-label named "tti" will exist. The trustpoint will be automatically enrolled with the certificate server (the registrar). To verify that the trustpoint is really there, use the show running-config command.
What to Do Next
If you set up the petitioner to use a certificate and the RSA keys associated with the specified trustpoint, you should configure the registrar as shown in the task "Enabling the SDP Registrar for Certificate-Based Authorization."
Enabling the SDP Registrar and Adding AAA Lists to the Server
Perform this task to enable the registrar and associate a certificate server with the SDP exchange.
You can also use this task if you want to add an authentication list and an authorization list to the RADIUS or TACACS+ server.
Prerequisites
Before configuring an registrar, ensure the following tasks are complete:
•
Note
•
If you are configuring AAA lists, you should complete the prerequisites required for the registrar in addition to completing the following tasks:
•
•
Restrictions
Cisco IOS CA Device Requirement
During the SDP process, a Cisco IOS CA certificate is automatically issued to the peer device. If an SDP registrar is configured on a third-party vendor's CA device, the SDP process will not work.
The template config Command
There are nine Cisco IOS configuration variables. If you require more configuration flexibility, the template config command can be used to reference a configuration template that is specific to the introducer. For more information on configuration flexibility, see the "Custom Configuration and File Template Variable Expansion Rules" section.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
DETAILED STEPS
Examples
To help troubleshoot the SDP transaction, you can issue the debug crypto provisioning command, which displays output from the petitioner and registrar devices.
The following is output for the debug crypto provisioning command. The output from the petitioner and registrar devices are shown below.
Petitioner device! The user starts the Welcome phase.Nov 7 03:15:48.171: CRYPTO_PROVISIONING: received welcome get request.! The router generates a Rivest, Shamir, and Adelman (RSA) keypair for future enrollment.Nov 7 03:15:48.279: CRYPTO_PROVISIONING: keyhash 'A506BE3B83C6F4B4A6EFCEB3D584AACA'! The TTI transaction is completed.Nov 7 03:16:10.607: CRYPTO_PROVISIONING: received completion post request.Registrar device!. During the introduction phase, the browser prompts for login information.06:39:18: CRYPTO_PROVISIONING: received introduction post request.06:39:18: CRYPTO_PROVISIONING: checking AAA authentication (ipsecca_script_aaalist, ttiuser)! This happens if the user types in the wrong username or password.06:39:19: CRYPTO_PROVISIONING: authentication declined by AAA, or AAA server not found - 0x306:39:19: CRYPTO_PROVISIONING: aaa query fails!! The user re-enters login information.06:39:19: CRYPTO_PROVISIONING: received introduction post request.06:39:19: CRYPTO_PROVISIONING: checking AAA authentication (ipsecca_script_aaalist, ttiuser)06:39:20: CRYPTO_PROVISIONING: checking AAA authorization (ipsecca_script_aaalist, ttiuser)! The login attempt succeeds and authorization information is retrieved from the AAA database.06:39:21: CRYPTO_PROVISIONING: aaa query ok!! These attributes are inserted into the configuration template.06:39:21: CRYPTO_PROVISIONING: building TTI av pairs from AAA attributes06:39:21: CRYPTO_PROVISIONING: "subjectname" = "CN=user1, O=company, C=US"06:39:21: CRYPTO_PROVISIONING: "$1" = "ntp server 10.3.0.1"06:39:21: CRYPTO_PROVISIONING: "$2" = "hostname user1-vpn"! The registrar stores this subject name and overrides the subject name in the subsequent enrollment request.06:39:21: CRYPTO_PROVISIONING: subjectname=CN=user1, O=company, C=US! The registrar stores this key information so that it may be used to automatically grant the subsequent enrollment request.06:39:21: CRYPTO_PROVISIONING: key_hash=A506BE3B83C6F4B4A6EFCEB3D584AACAEnabling the SDP Registrar for Certificate-Based Authorization
Perform this task to enable the SDP registrar to perform the following functions:
•
•
Prerequisites
You must also configure the SDP petitioner to use a certificate and RSA keys associated with a specific trustpoint. To complete this task, use the trustpoint signing command as shown in the task "Enabling the SDP Petitioner."
Restrictions
Because RADIUS does not differentiate between authentication and authorization, you need to use the default password, cisco, for certificate authorization.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
DETAILED STEPS
Configuring an Administrative Introducer
Perform the following task to configure an administrative introducer using administrator authentication and authorization lists.
Prerequisites
The administrative introducer must have enable privileges on the client device and administrator privileges on the server.
Restrictions
When using RADIUS, a user/device that needs to be introduced by the administrative introducer must always use cisco as its own password. TACACS+ does not have this limitation; a user/device can have any password and be introduced by the administrative introducer.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
DETAILED STEPS
Examples
The following example from the show running-config command allows you to verify that an administrative introducer using administrator authentication and authorization lists have been created:
Router# show running-configBuilding configuration...Current configuration : 2700 bytes!! Last configuration change at 01:22:26 GMT Fri Feb 4 2005!version 12.4no service padservice timestamps debug datetime msecservice timestamps log datetime msecno service password-encryption!hostname router!boot-start-markerboot-end-marker!memory-size iomem 5enable secret 5 $1$tpBS$PXnBDTIDXfX5pWa//1JX20enable password lab!aaa new-model!!!aaa session-id common!resource manager!clock timezone GMT 0ip subnet-zerono ip routing!!no ip dhcp use vrf connected!!no ip cefno ip domain lookupip domain name company.comip host router 10.3.0.6ip host router.company.com 10.3.0.6no ip ips deny-action ips-interface!no ftp-server write-enable!crypto pki server mycs!crypto pki trustpoint mycsrevocation-check crlrsakeypair mycs!crypto pki trustpoint ttirevocation-check crlrsakeypair tti!crypto pki trustpoint micenrollment url http://router:80revocation-check crl!crypto pki trustpoint catrevocation-check crl!!!crypto pki certificate map cat 10!crypto pki certificate chain mycscertificate ca 01crypto pki certificate chain tticrypto pki certificate chain miccertificate 02certificate ca 01crypto pki certificate chain cat!crypto provisioning registrar <---------- !SDP registrar device parameters!administrator authentication list authen-tacadministrator authorization list author-tac!no crypto engine onboard 0username qa privilege 15 password 0 labConfiguring Custom Templates
Perform this task to create and configure custom templates.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
DETAILED STEPS
Examples
The following example shows the use of custom start, introduction, and completion templates:
template http start tftp://registrar.company.com/start.html
template http introduction tftp://registrar.company.com/intro.html
template http completion tftp://registrar.company.com/completion.html
Configuration Examples for Setting Up a PKI via SDP
This section contains the following configuration examples:
•
•
•
•
•
•
Verifying the SDP Registrar: Example
The following sample output from the show running-config command verifies that the certificate server "cs1" was configured and associated with the SDP exchange between the registrar and petitioner:
Router# show running-configBuilding configuration...Current configuration : 5902 bytes!! Last configuration change at 09:34:44 GMT Sat Jan 31 2004!version 12.3service timestamps debug datetime msecservice timestamps log datetime msecno service password-encryption!hostname pki-36a!boot-start-markerboot-end-marker!logging buffered 32768 debuggingno logging consoleenable secret 5 $1$b3jz$CKquLGjFIE3AdXA2/Rl9./enable password lab!clock timezone GMT 0no aaa new-modelip subnet-zero!!ip cefip domain name company.comip host msca-rootip host yni-u10ip host pki-36a 10.23.2.131ip host pki-36a.company.com 10.23.2.131!!crypto pki server cs1issuer-name CN=company,L=city,C=USlifetime crl 336lifetime certificate 730!crypto pki trustpoint pki-36aenrollment url http://pki-36a:80ip-address FastEthernet0/0revocation-check none!crypto pki trustpoint cs1revocation-check crlrsakeypair cs1!!crypto pki certificate chain pki-36acertificate 03308201D0 30820139 A0030201 02020103 300D0609 2A864886 F70D0101 0405003034310B30 09060355 04061302 55533114 30120603 55040713 0B205361 6E7461204372757A 310F300D 06035504 03130620 696F7363 73301E17 0D303430 3133313039333334 345A170D 30363031 33303039 33333434 5A303A31 38301606 092A864886F70D01 09081309 31302E32 332E322E 32301E06 092A8648 86F70D01 09021611706B692D 3336612E 63697363 6F2E636F 6D305C30 0D06092A 864886F7 0D0101010500034B 00304802 4100AFFA 8F429618 112FAB9D 01F3352E 59DD3D2D AE67E31D370AC4DA 619735DF 9CF4EA13 64E4B563 C239C5F0 1578B773 07BED641 A18CA629191884B5 61B66ECF 4D110203 010001A3 30302E30 0B060355 1D0F0404 030205A0301F0603 551D2304 18301680 141DA8B1 71652961 3F7D69F0 02903AC3 2BADB137C6300D06 092A8648 86F70D01 01040500 03818100 67BAE186 327CED31 D642CB39AD585731 95868683 B950DF14 3BCB155A 2B63CFAD B34B579C 79128AD9 296922E94DEDFCAF A7B5A412 AB1FC081 09951CE3 08BFFDD9 9FB1B9DA E9AA42C8 D1049268C524E58F 11C6BA7F C750320C 03DFB6D4 CBB3E739 C8C76359 CE939A97 B51B3F7F3FF;A9D82 9CFDB6CF E2503A14 36D0A236 A1CCFEAEquitcertificate ca 0130820241 308201AA A0030201 02020101 300D0609 2A864886 F70D0101 0405003034310B30 09060355 04061302 55533114 30120603 55040713 0B205361 6E7461204372757A 310F300D 06035504 03130620 696F7363 73301E17 0D303430 3133313039333132 315A170D 30373031 33303039 33313231 5A303431 0B300906 0355040613025553 31143012 06035504 07130B20 53616E74 61204372 757A310F 300D060355040313 0620696F 73637330 819F300D 06092A86 4886F70D 01010105 0003818D00308189 02818100 FC0695AF 181CE90A 1B34B348 BA957178 680C8B51 07802AC3BF77B9C6 CB45092E 3C22292D C7D5FFC1 899185A1 FD8F37D5 C44FC206 6D1FA581E2264C83 1CC7453E 548C89C6 F3CD25BC 9BFFE7C5 E6653A06 62133950 78BED51B49128428 AB237F80 83A530EA 6F896193 F2134B54 D181F059 348AA84B 21EE6D80727BF668 EB004341 02030100 01A36330 61300F06 03551D13 0101FF04 0530030101FF300E 0603551D 0F0101FF 04040302 0186301D 0603551D 0E041604 141DA8B171652961 3F7D69F0 02903AC3 2BADB137 C6301F06 03551D23 04183016 80141DA8B1716529 613F7D69 F002903A C32BADB1 37C6300D 06092A86 4886F70D 0101040500038181 00885895 A0141169 3D754EB2 E6FEC293 5BF0A80B E424AA2F A3F597653463AAD1 55E71F0F B5D1A35B 9EA79DAC DDB40721 1344C01E 015BAB73 1E148E039DD01431 A5E2887B 4AEC8EF4 48ACDB66 A6F9401E 8F7CA588 8A4199BB F8A437A0F25064E7 112805D3 074A154F 650D09B9 8FA19347 ED359EAD 4181D9ED 0C667C108A7BCFB0 FBquitcrypto pki certificate chain cs1certificate ca 0130820241 308201AA A0030201 02020101 300D0609 2A864886 F70D0101 0405003034310B30 09060355 04061302 55533114 30120603 55040713 0B205361 6E7461204372757A 310F300D 06035504 03130620 696F7363 73301E17 0D303430 3133313039333132 315A170D 30373031 33303039 33313231 5A303431 0B300906 0355040613025553 31143012 06035504 07130B20 53616E74 61204372 757A310F 300D060355040313 0620696F 73637330 819F300D 06092A86 4886F70D 01010105 0003818D00308189 02818100 FC0695AF 181CE90A 1B34B348 BA957178 680C8B51 07802AC3BF77B9C6 CB45092E 3C22292D C7D5FFC1 899185A1 FD8F37D5 C44FC206 6D1FA581E2264C83 1CC7453E 548C89C6 F3CD25BC 9BFFE7C5 E6653A06 62133950 78BED51B49128428 AB237F80 83A530EA 6F896193 F2134B54 D181F059 348AA84B 21EE6D80727BF668 EB004341 02030100 01A36330 61300F06 03551D13 0101FF04 0530030101FF300E 0603551D 0F0101FF 04040302 0186301D 0603551D 0E041604 141DA8B171652961 3F7D69F0 02903AC3 2BADB137 C6301F06 03551D23 04183016 80141DA8B1716529 613F7D69 F002903A C32BADB1 37C6300D 06092A86 4886F70D 0101040500038181 00885895 A0141169 3D754EB2 E6FEC293 5BF0A80B E424AA2F A3F597653463AAD1 55E71F0F B5D1A35B 9EA79DAC DDB40721 1344C01E 015BAB73 1E148E039DD01431 A5E2887B 4AEC8EF4 48ACDB66 A6F9401E 8F7CA588 8A4199BB F8A437A02;F25064E7 112805D3 074A154F 650D09B9 8FA19347 ED359EAD 4181D9ED 0C667C108A7BCFB0 FBquit!crypto provisioning registrarpki-server cs1!!!crypto isakmp policy 1hash md5!!crypto ipsec transform-set test_transformset esp-3des!crypto map test_cryptomap 10 ipsec-isakmpset peer 10.23.1.10set security-association lifetime seconds 1800set transform-set test_transformsetmatch address 170!!interface Loopback0ip address 10.23.2.131 255.255.255.255no ip route-cache cefno ip route-cacheno ip mroute-cache!interface FastEthernet0/0ip address 10.23.2.2 255.255.255.192no ip route-cache cefno ip route-cacheno ip mroute-cacheduplex autospeed autocrypto map test_cryptomap!interface FastEthernet1/0no ip addressshutdownduplex autospeed auto!ip default-gateway 10.23.2.62ip http serverno ip http secure-serverip classlessip route 0.0.0.0 0.0.0.0 10.23.2.62!!access-list 170 permit ip host 10.23.2.2 host 10.23.1.10dialer-list 1 protocol ip permit!!control-plane!!line con 0exec-timeout 0 0speed 115200line aux 0line vty 0 4password lablogin!!endVerifying the SDP Petitioner: Example
After the SDP exchange is complete, the petitioner will automatically enroll with the registrar and obtain a certificate. The following sample output via the show running-config command shows the automatically generated configuration, which verifies that the trustpoint is really there:
Router# show running-configBuilding configuration...Current configuration : 4650 bytes!! Last configuration change at 09:34:53 GMT Sat Jan 31 2004!version 12.3service timestamps debug datetime msecservice timestamps log datetime msecno service password-encryption!hostname pki-36b!boot-start-markerboot-end-marker!logging buffered 32768 debuggingno logging consoleenable secret 5 $1$JYgw$060JKXgl6dERLZpU9J3gb.enable password lab!clock timezone GMT 0no aaa new-modelip subnet-zero!!ip cefip domain name company.comip host msca-rootip host yni-u10ip host pki-36a 10.23.2.131ip host pki-36a.company.com 10.23.2.131!!crypto pki trustpoint ttienrollment url http://pki-36a.company.com:80revocation-check crlrsakeypair tti 1024auto-enroll 70!!crypto pki certificate chain tticertificate 02308201FC 30820165 A00302012;02020102 300D0609 2A864886 F70D0101 0405003034310B30 09060355 04061302 55533114 30120603 55040713 0B205361 6E7461204372757A 310F300D 06035504 03130620 696F7363 73301E17 0D303430 3133313039333333 385A170D 30363031 33303039 33333338 5A302231 20301E06 092A864886F70D01 09021611 706B692D 3336622E 63697363 6F2E636F 6D30819F 300D06092A864886 F70D0101 01050003 818D0030 81890281 8100E383 35584B6C 24751E2CF4088F06 C00BFECE 84CFF8EB 50D52044 03D14A2B 91E5A260 7D07ED24 DB599D27432065D9 0E459248 D7CDC15D 654E2AF6 BA27D79C 23850306 3E96C508 F311D33376FDDC9C A810F75C FCD10F1B 9A142F0C 338B6DB3 346D3F24 97A4B15D 0A9504E71F6CB769 85E9F52B FE907AAF 63D54D66 1A715A20 D7DB0203 010001A3 30302E300B060355 1D0F0404 030205A0 301F0603 551D2304 18301680 141DA8B1 716529613F7D69F0 02903AC3 2BADB137 C6300D06 092A8648 86F70D01 01040500 03818100C5E2DA0E 4312BCF8 0396014F E18B3EE9 6C970BB7 B8FAFC61 EF849568 D546F73F67D2A73C 156202DC 7404A394 D6124DAF 6BACB8CF 96C3141D 109C5B0E 46F4F827022474ED 8B59D654 F04E31A2 C9AA1152 75A0C455 FD7EEEF5 A505A648 863EE9E6C361D9BD E12BBB36 16B729DF 823AD5CC 404CCE48 A4379CDC 67FF6362 0601B950quitcertificate ca 0130820241 308201AA A0030201 02020101 300D0609 2A864886 F70D0101 0405003034310B30 09060355 04061302 55533114 30120603 55040713 0B205361 6E7461204372757A 310F300D 06035504 03130620 696F7363 73301E17 0D303430 3133313039333132 315A170D 30373031 33303039 33313231 5A303431 0B300906 0355040613025553 31143012 06035504 07130B20 53616E74 61204372 757A310F 300D060355040313 0620696F 73637330 819F300D 06092A86 4886F70D 01010105 0003818D00308189 02818100 FC0695AF 181CE90A 1B34B348 BA957178 680C8B51 07802AC3BF77B9C6 CB45092E 3C22292D C7D5FFC1 899185A1 FD8F37D5 C44FC206 6D1FA581E2264C83 1CC7453E 548C89C6 F3CD25BC 9BFFE7C5 E6653A06 62133950 78BED51B49128428 AB237F80 83A530EA 6F896193 F2134B54 D181F059 348AA84B 21EE6D80727BF668 EB004341 02030100 01A36330 61300F06 03551D13 0101FF04 0530030101FF300E 0603551D 0F0101FF 04040302 0186301D 0603551D 0E041604 141DA8B171652961 3F7D69F0 02903AC3 2BADB137 C6301F06 03551D23 04183016 80141DA8B1716529 613F7D69 F002903A C32BADB1 37C6300D 06092A86 4886F70D 0101040500038181 00885895 A0141169 3D754EB2 E6FEC293 5BF0A80B E424AA2F A3F597653463AAD1 55E71F0F B5D1A35B 9EA79DAC DDB40721 1344C01E 015BAB73 1E148E039DD01431 A5E2887B 4AEC8EF4 48ACDB66 A6F9401E 8F7CA588 8A4199BB F8A437A0F25064E7 112805D3 074A154F 650D09B9 8FA19347 ED359EAD 4181D9ED 0C667C108A7BCFB0 FBquit!no crypto engine accelerator!!crypto isakmp policy 1hash md5!!crypto ipsec transform-set test_transformset esp-3des!crypto map test_cryptomap 10 ipsec-isakmpset peer 10.23.2.2set security-association lifetime seconds 1800set transform-set test_transformsetmatch address 170!!interface Ethernet0/0ip address 10.23.1.10 255.255.255.192no ip route-cache cefno ip route-cacheno ip mroute-cachehalf-duplexcrypto map test_cryptomap!interface Ethernet0/1no ip addressshutdownhalf-duplex!interface Ethernet0/2no ip addressshutdownhalf-duplex!interface Ethernet0/3no ip addressshutdownhalf-duplex!interface Serial1/0no ip addressshutdownserial restart-delay 0!interface Serial1/1no ip addressshutdownserial restart-delay 0!interface Serial1/2no ip addressshutdownserial restart-delay 0!interface Serial1/3no ip addressshutdownserial restart-delay 0!ip default-gateway 10.23.1.62ip http serverno ip http secure-serverip classlessip route 0.0.0.0 0.0.0.0 10.23.1.62!!access-list 170 permit ip host 10.23.1.10 host 10.23.2.2dialer-list 1 protocol ip permit!!control-plane!!line con 0exec-timeout 0 0speed 115200line aux 0line vty 0 4password lablogin!!endAdding AAA Lists to a RADIUS or TACACS+ Server: Examples
This section contains the following configuration examples:
•
•
•
TACACS+ AAA Server Database: Example
In the following example, user information has been added to a TACACS+ AAA database. The username is "user1." The password is "cisco." Two Cisco IOS configuration template variables are configured for "user1": iosconfig1 and iosconfig2. The variables will replace $1 and $2 in the configuration template file. The subject name "CN=user1, O=company, C=US" is also configured. This subject name will replace the subject name field in the subsequent enrollment request (PKCS10) that is received from the petitioner device.
user = user1password = clear "pswd"service=tti! The certificate server inserts the following subject name to the certificate.set subjectname="CN=user1, O=company, C=US"! Up to nine template variables may be added.set iosconfig1="ntp server 10.3.0.1"set iosconfig2="hostname user1-vpn"RADIUS AAA Server Database: Example
User information has been added to the RADIUS AAA server database in the following example. The username is "user1." The password is "cisco." Two Cisco IOS configuration template variables are configured for "user1": iosconfig1 and iosconfig2. The variables will replace $1 and $2 in the configuration template file. The subject name "CN=user1, O=company, C=US" is also configured. This subject name will replace the subject name field in the subsequent enrollment request (PKCS10) that is received from the petitioner device.
user = user1password = clear "pswd"radius=companyreply_attributes=9,1="tti:subjectname=CN=user1, O=company, C=US"! Up to nine template variables may be added.9,1="tti:iosconfig1=ntp server 10.3.0.5"9,1="tti:iosconfig2=hostname user1-vpn"AAA List on a TACACS+ and a RADIUS AAA Server: Example
The following is a configuration example showing that AAA authentication has been configured on a TACACS+ server and that AAA authorization has been configured on a RADIUS server.
Note
Router(config)# tacacs-server host 10.0.0.48 key ciscoRouter(config)# aaa authentication login authen-tac group tacacs+Router(config)# radius-server host 10.0.1.49 key ciscoRouter(config)# aaa authorization network author-rad group radiusUsing a Configuration Template File: Example
You can use a different configuration template file on the basis of the introducer name. For example, if you have multiple template files for different users, each with the username in the filename, configure the following under the registrar:
Router(config)# crypto provisioning registrarRouter (tti-registrar)# pki-server cs1Router (tti-registrar)# template config tftp://server/config-$n.txtIn this example, the default configuration file shown in the section "Default Template for the Configuration File" will be used because the template config command does not reference a CGI script.
CGI Script: Example
The following example would execute a CGI script named "mysdpcgi":
Router(config)# crypto provisioning registrarRouter (tti-registrar)# pki-server cs1Router (tti-registrar)# template config tftp://server/cgi-bin/mysdpcgi postThe following is an example CGI script, named "mysdpcgi", that would be executed with the example template config command above:
#!/usr/bin/perl -w# for debugging use the -debug form# use CGI (-debug);use CGI;# base64 decoding is being used.use MIME::Base64;# The following has been commented out, but left for your information.## Reading everything that has been received from stdin and writing it to the debug log to #see what has been sent from the registrar.## Remember to reset the STDIN pointer so that the normal CGI processing can get the input.## print STDERR "mysdpcgi.cgi dump of stdin:\n";# if($ENV{'REQUEST_METHOD'} eq "GET"){# $input_data = $ENV{'QUERY_STRING'};# }# else {# $data_length = $ENV{'CONTENT_LENGTH'};# $bytes_read = read(STDIN, $input_data, $data_length);# }# print STDERR $input_data,"\n";# exit;$query = new CGI;my %av_table;# A basic configuration file is being sent back, therefore it is being indicated as plain # text in the command below.print $query->header ("text/plain");print "\n";# For testing, parameters can be passed in so that the test applications can# see what has been received.## print STDERR "The following are the raw AV pairs mysdpcgi.cgi received:\n";# for each $key ($query->param) {# print STDERR "! $key is: \n";# $value = $query->param($key);# print STDERR "! ",$value;# print STDERR "! \n";#}# The post process AV pairs are identical to those in Cisco IOS and may be used to produce # AV pair specific configurations as needed.%av_table = &postprocessavpairs($query->param);# Decoded values may be written out.# WARNING: Some error_logs cannot handle the amount of data and will freeze.# print STDERR "The following are the decoded AV pairs mysdpcgi.cgi received:\n";# now write the values out# while ( ($a, $v) = each(%av_table) ) {# print STDERR "$a = $v\n";# }# Identifying the AV pairs and specifying them in the config.while ( ($a, $v) = each(%av_table) ) {if ($a eq "TTIIosRunningConfig") {$search = "hostname ";$begin = index($v, $search) + length($search);$end = index($v, "\n", $begin);$hostname = substr($v, $begin, $end - $begin);}if ($a eq "TTIIosVersion") {$search = "Version ";$begin = index($v, $search) + length($search);$end = index($v, "(", $begin);$version = substr($v, $begin, $end - $begin);}}print <<END_CONFIG;!! Config auto-generated by sdp.cgi! This is for SDP testing only and is not a real config!!\$t!\$c!cry pki trust Version-$version-$hostname! NOTE: The last line of the config must be 'end' with a blank line after the end# statement.END_CONFIG;# Emulate IOS tti_postprocessavpairs functionalitysub postprocessavpairs {@attributes = @_;# Combine any AV pairs that were split apart$n = 0; #element index counterwhile ($attributes[$n]) {# see if we are at the start of a setif ($attributes[$n] =~ m/_0/) {# determine base attribute name$a = (split /_0/, $attributes[$n])[0];# set initial (partial) value$v = $query->param($attributes[$n]);# loop and pull the rest of the matching# attributes's values into v (would be# faster if we stop at first non-match)$c = $n+1;while ($attributes[$c]) {if ($attributes[$c] =~ m/$a/) {$v = $v.$query->param($attributes[$c]);}$c++;}# store in the av hash table$av_table{$a} = $v;} else {# store in hash table if not part of a setif ($attributes[$n] !~ m/_\d/) {$av_table{$attributes[$n]} = $query->param($attributes[$n]);}}$n++;}# de-base64 decode all AV pairs except userdevicenamewhile ( ($a, $v) = each(%av_table) ) {if ($a ne "userdevicename") {$av_table{$a} = decode_base64($av_table{$a});}}return %av_table;}
Note
Configuring the Petitioner and Registrar for Certificate-Based Authentication: Example
The following examples shows how to configure a petitioner to use the certificate issued by the trustpoint named mytrust:
Router# configure terminalEnter configuration commands, one per line. End with CNTL/Z.Router(config)# crypto provisioning petitionerRouter(tti-petitioner)# trustpoint signing mytrust
Router(tti-petitioner)# end
The following example shows how to configure a registrar to verify the petitioner-signing certificate and to perform authorization lookups:
Router# configure terminalEnter configuration commands, one per line. End with CNTL/Z.Router(config)# crypto provisioning registrarRouter(tti-registrar)# authentication trustpoint mytrust
Router(tti-registrar)# authorization login certificate
Router(tti-registrar)# authorization username subjectname all
Router(tti-registrar)# endConfiguring an Administrative Introducer Using Authentication and Authorization Lists: Example
The following example shows how to configure an administrative introducer with the authentication list "authen-tac" and the authorization list "author-tac":
Router# configure terminalEnter configuration commands, one per line. End with CNTL/Z.Router(config)# crypto provisioning registrarRouter(tti-registrar)# administrator authentication list authen-tacRouter(tti-registrar)# administrator authorization list author-tacRouter(tti-registrar)# endAdditional References
The following sections provide references related to SDP.
Related Documents
Technical Assistance
Feature Information for SDP in a PKI
Table 3 lists the features in this module and provides links to specific configuration information. Only features that were introduced or modified in Cisco IOS Release 12.2(1) or a later release appear in the table.
For information on a feature in this technology that is not documented here, see the "Implementing and Managing PKI Features Roadmap."
Not all commands may be available in your Cisco IOS software release. For release information about a specific command, see the command reference documentation.
Use Cisco Feature Navigator to find information about platform support and software image support. Cisco Feature Navigator enables you to determine which Cisco IOS and Catalyst OS software images support a specific software release, feature set, or platform. To access Cisco Feature Navigator, go to http://www.cisco.com/go/cfn. An account on Cisco.com is not required.
Note
Table 3 Feature Information for SDP in a PKI
Secure Device Provisioning (SDP) Connect Template
12.5(1st)T
This feature provides the ability to configure a device for Internet connectivity through a service provider.
The following sections provide information about this feature:
•
USB Token and Secure Device Provisioning (SDP) Integration
12.4(15)T
This feature provides the ability to provision remote devices using a USB token as a mechanism to transfer credentials from one network device to a remote device via SDP.
The following sections provide information about this feature:
•
•
The following commands were introduced by this feature: binary file, crypto key move rsa, template file.
Note
SDP Expanded Template CGI Support
12.4(6)T
This feature allows users to configure the SDP registrar to send a bootstrap configuration to the SDP petitioner based on not only the device name, but also its current Cisco IOS version and current configuration.
The following sections provide information about this feature:
•
•
•
The following command was modified by this feature: template config
Secure Device Provisioning (SDP) Start Page
12.4(4)T
This feature allows users to configure their browsers to begin the TTI transaction by contacting the registrar's introduction URL via a start page. Thus, users no longer have to begin the TTI transaction from the welcome page on the petitioner.
The following sections provide information about this feature:
•
The following commands were introduced by this feature: template http admin-introduction, template http completion, template http error, template http introduction, template http start, template http welcome
Administrative Secure Device Provisioning Introducer
12.3(14)T
This feature allows you to act as an administrative introducer to introduce a device into a PKI network and then provide a username as the device name for the record locator in the AAA database.
The following sections provide information about this feature:
•
•
The following commands were introduced by this feature: administrator authentication list, administrator authorization list
Easy Secure Device Deployment
12.3(8)T
This feature introduces support for SDP, which offers a web-based enrollment interface that enables network administrators to deploy new devices in large networks.
The following sections provide information about this feature:
•
•
The following commands were introduced or modified by this feature: crypto wui tti petitioner, crypto wui tti registrar, pki-server, template config, template username, trustpoint (tti-petitioner)
Easy Secure Device Deployment AAA Integration
12.3(8)T
This feature integrates an external AAA database, allowing the SDP introducer to be authenticated against a AAA database instead of having to use the enable password of the local Cisco certificate server.
The following sections provide information about this feature:
•
•
The following commands were introduced or modified by this feature: authentication list (tti-registrar), authorization list (tti-registrar), debug crypto wui template config, template username
Secure Device Provisioning (SDP) Certificate-Based Authorization
12.3(14)T
This feature allows certificates issued by other authority (CA) servers to be used for SDP introductions.
The following sections provide information about this feature:
•
•
The following commands were introduced by this feature: administrator authentication list, administrator authorization list
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2005-2008 Cisco Systems, Inc. All rights reserved.
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211049.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211950.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211951.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211952.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211953.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211954.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211955.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211956.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211957.jpg)
/Features/12.5(1st)T/FTS-8004-1%20(SDP)/Images/211958.jpg)
