SOAP Web Services
The following client programs use SOAP web services in Cisco DCNM.
Java Client
This section provides an example of the Java client that uses the SOAP web services.
Example A-1 Zone Manager Web Services API
package com.cisco.dcbu.smis.jaxws.test; import static com.cisco.dcbu.smis.jaxws.test.ZoneWsUtil.*; import java.io.BufferedReader; import java.io.InputStreamReader; import com.cisco.dcbu.smis.jaxws.ep.Fabric; import com.cisco.dcbu.smis.jaxws.ep.OperationStatus; import com.cisco.dcbu.smis.jaxws.ep.Vsan; import com.cisco.dcbu.smis.jaxws.ep.WwnKey; import com.cisco.dcbu.smis.jaxws.ep.Zone; import com.cisco.dcbu.smis.jaxws.ep.ZoneMember; import com.cisco.dcbu.smis.jaxws.ep.ZoneSet; import com.cisco.dcbu.smis.jaxws.ep._switch; public class ZoneWsClient { input_ = new BufferedReader(new InputStreamReader(System.in)); * Main method is the starting point of execution. public static void main(String[] args) throws Exception { * This method show all available zone webservice as user menu. public static void menu() throws Exception { ZoneWsClient zwsClient = new ZoneWsClient(); header("=================================Zone WS Client============================================="); System.out.println("Available Zone services:\n\n " + "\t1:Discover Zones in fabric\n " + "\t2:Discover Zonesets in fabric\n " + "\t3:Discover Zonemenbers in fabric\n " + "\t4:Create new Zone in fabric\n " + "\t5:Create new ZoneSet in fabric\n " + "\t6:Add Zonemember to existing Zone in fabric\n " + "\t7:Add existing Zone to existing Zoneset in fabric\n " + "\t8:Activate/Deactivate a ZoneSet in fabric\n " + "\t9:Manual Zone Cache Invalidation\n " + "\t10:Exit "); System.out.println("\n\tPlease enter your Choice: "); choice = Integer.parseInt(input_.readLine()); } catch (NumberFormatException e) { System.out.println("Enter Integer choices only..."); zwsClient.displayZonesets(); zwsClient.displayZonemembers(); zwsClient.createZoneSet(); zwsClient.addZoneMember(); zwsClient.activateAndDeactivateZoneSet(); trailer("ACTIVATE/DEACTIVATE ZONESET"); zwsClient.zoneCacheInvalidation(); System.out.println("Exiting ZoneWSClient.."); trailer("Zone WS CLIENT"); System.out.println("Wrong Choice entered."); * This method invalidates zonedata cache by making use of * ZoneManagerWS: invalidateZoneDataCache() public void zoneCacheInvalidation() { System.out.println("Invalidation of Zone data cache started"); zoneManager.invalidateZoneDataCache(); System.out.println("Succesfully Invalidated Zone data cache"); trailer("Zone Cache Invalidation"); * This method takes promts user to enter already existing zoneset name to * ZoneManagerWS: ActivateZoneset() * ZoneManagerWS: deActivateZoneset() public void activateAndDeactivateZoneSet() throws Exception { System.out.println("Enter your choice\n 1:Activate a ZoneSet\n 2:Deactivate a ZoneSet\n 3:Main menu"); choice = Integer.parseInt(input_.readLine()); OperationStatus oper = null; if (choice != 1 && choice != 2 && choice !=3) { System.out.println("Enter right Choice: 1 or 2 or 3"); oper = activation(choice); System.out.println("Zoneset activation/deactivation is done successfully.\n Please wait for 1-5 minutes to get reflected."); System.out.println("Zoneset activation/deactivation is not successfull"); } catch(NumberFormatException ne){ System.out.println("NumberFormatException: Integer type expected."); }while(choice !=3||flag==0); private OperationStatus activation(int choice) throws Exception { OperationStatus oper = null; System.out.println("Enter the ZoneSet name to be activated/deactivated "); String zName = input_.readLine(); Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { ZoneSet enfZoneset = zoneManager.getEnfZoneSetDO(vsan.getKey()); ZoneSet[] zoneSets = zoneManager.getZoneSets(vsan.getKey(),new WwnKey(sw.getWwn())); System.out.println("Zoneset is null for VSan "+vsan.getKey().getVsanID()); for (ZoneSet zs : zoneSets) { if (enfZoneset != null) { if (enfZoneset.getName().equals(zName) && choice == 1 && enfZoneset.isActive()) { System.out.println("Selected ZoneSet is already activated"); else if (!enfZoneset.getName().equals(zName) && choice == 2 && zs.getName().equals(zName)) { System.out.println("Selected ZoneSet is already deactivated"); } else if (enfZoneset == null && choice == 2) { System.out.println("No ZoneSet is active to deactivate"); } else if (zs.getName().equals(zName) && choice == 2 && !zs.isActive()) { System.out.println("Selected ZoneSet is already deactivated"); if (zs.getName().equals(zName)) { oper = zoneManager.activateZoneset(vsan.getKey(), new WwnKey(sw.getWwn()), zs.getName()); oper = zoneManager.deActivateZoneset(vsan.getKey(), new WwnKey(sw.getWwn()), zs.getName()); System.out.println("Invalid Zoneset is selected"); * This method promts user to enter a unique zone name and creates the * ZoneManagerWS:createZone() public void createZone() { System.out.println("Enter the new Zone name"); zName= input_.readLine(); }while(zName.length()<1); Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { boolean readOnly = false; boolean broadcast = false; Zone zone1 = zoneManager.createZone(vsan.getKey(),new WwnKey(sw.getWwn()), zName, readOnly, broadcast, qos, qosPriority); System.out.println("Failed to create Zone: " + zName); System.out.println("Zone " + zName + " created successfuly in Vsan:" + vsan.getKey().getVsanID() + ",Switch: " + sw.getName()); * This method promts user to enter an existing zone,zonememberid and zonemembertype and creates a zonemember in zone provided. * ZoneManagerWS:addZoneMemberToZone public void addZoneMember() { System.out.println("\nEnter existing zonename to which member has to be added\n"); String zoneName = input_.readLine(); Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { Zone existingzones[] = zoneManager.getZones(vsan.getKey(), new WwnKey(sw.getWwn())); for (Zone zs : existingzones) { if (zs.getName().equals(zoneName)) { System.out.println("Enter zonemember type which is in number format. \n 1. For WWN "); int zonememtype = Integer.parseInt(input_.readLine()); byte[] zonememberid = null; System.out.println("Enter zonemember id which is in hexa format Eg: 1122334455667788 or 11:22:33:44:55:66:77:88"); hexstr=input_.readLine(); if (hexstr.contains(":")) zonememberid = ZoneWsUtil.fromHexString(hexstr, true); zonememberid = ZoneWsUtil.fromHexString(hexstr, false); System.out.println("Demo ZoneWsClient do not support other member types\n"); ZoneMember zoneMemberAdded = zoneManager.addZoneMemberToZone(vsan.getKey(),new WwnKey(sw.getWwn()),zoneName, zonememtype, -1,-1, -1, zonememberid, null); if (zoneMemberAdded == null) System.out.println("Failed to add Zonemember to specified zone"); System.out.println("ZoneMember added succesfully to zone "+ zoneName); System.out.println("Zone " + zoneName + " not found. Please enter an existing zone"); } catch(NumberFormatException ne){ System.out.println("NumberFormatException: Please check the input type/format"); * This method promts user to enter existing zoneset, existing zone * and adds zone to zoneset. * ZoneManagerWS:addZoneToZoneset() System.out.println("Enter already existing zoneset to which the zone has to be added: "); String zonesetName = input_.readLine(); Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { ZoneSet existingzonesets[] = zoneManager.getZoneSets(vsan.getKey(), new WwnKey(sw.getWwn())); for (ZoneSet zset : existingzonesets) { if (zset.getName().equals(zonesetName)) { System.out.println("Enter existing zone to be added to zoneset: "); String zonename = input_.readLine(); Zone existingzones[] = zoneManager.getZones(vsan.getKey(),new WwnKey(sw.getWwn())); for (Zone zone : existingzones) { if (zone.getName().equals(zonename)) { ZoneSet znst = zoneManager.addZoneToZoneset(vsan.getKey(),new WwnKey(sw.getWwn()),zset, zone); System.out.println("Failed to add Zone to specified Zoneset"); System.out.println("Zone "+ zonename+ " added succesfully to zoneset "+ zonesetName); System.out.println("Zone "+ zonename+ " not found. Please enter an existing zone"); System.out.println("ZoneSet " + zonesetName+ " not found. Please enter an existing zoneset"); * This method promts user to enter zoneset name which will be created * ZoneManagerWS:createZoneSet() public void createZoneSet() { System.out.println("Enter the new unique Zoneset name"); String zonsetName =input_.readLine(); Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { ZoneSet newzoneset = zoneManager.createZoneSet(vsan.getKey(), new WwnKey(sw.getWwn()), zonsetName); System.out.println("Failed to create Zoneset: "+ zonsetName); System.out.println("ZoneSet " + zonsetName+ " created in Vsan:"+ vsan.getKey().getVsanID() + ",Switch: "+ sw.getName()); trailer("CREATE ZONESET"); * This method displays the Zone member setting data in the fabric. * ZoneManagerWS:getZoneMembers() public void displayZonemembers() { Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { Zone[] enfZones = getEnfZones(vsan); for (Zone ezone : enfZones) { ZoneMember[] zms = getZoneMembers(ezone); for (ZoneMember zm : zms) System.out.println("vsan id:"+ vsan.getKey().getVsanID()+ ",vsan wwn:"+ vsan.getKey().getPWwn().getValue()+ ",Zone Name:" + ezone.getName() + ", ZoneMemberType: " + zm.getType()+ ", ZoneMemberId: "+ ZoneWsUtil.toHexString(zm.getId())+ ",Status:" + ezone.isActive()); for (Vsan vsan : vsans) { Zone[] zones = getZones(vsan, sw); for (Zone zone : zones) { ZoneMember[] zms = getZoneMembers(zone); for (ZoneMember zm : zms) System.out.println("vsan id:"+ vsan.getKey().getVsanID()+ ",vsan wwn:"+ vsan.getKey().getPWwn().getValue()+ ",Zone Name:" + zone.getName() + ", ZoneMemberType: " + zm.getType()+ ", ZoneMemberId: "+ ZoneWsUtil.toHexString(zm.getId())+ ",Status:" + zone.isActive()); private ZoneMember[] getZoneMembers(Zone zone) { header("Now getting ZoneMembers for Zone " + zone.getName()); ZoneMember[] zoneMemz = null; zoneMemz = zone.getMembers(); System.out.println(zoneMemz.length+ " ZoneMembers found for the Zone " + zone.getName()); System.out.println("No ZoneMembers found for the Zone "+ zone.getName()); * This method displays the active and local zonesets in the fabric. * ZoneManagerWS:getZoneSets() public void displayZonesets() { Fabric[] fabrics = getFabrics(); for (Fabric fab : fabrics) { _switch[] sws = getSwitchesByFabric(fab); Vsan[] vsans = getVsans(fab); for (Vsan vsan : vsans) { for (Vsan vsan : vsans) { ZoneSet[] zoneSets = zoneManager.getZoneSets(vsan.getKey(), new WwnKey(sw.getWwn())); header("Now getting local ZoneSets for Vsan "+ vsan.getKey().getVsanID()); System.out.println("No Zoneset found for switch"+ sw.getName() + " Vsan "+ vsan.getKey().getVsanID()); System.out.println(zoneSets.length+ " Zonesets found for the switch "+ sw.getName() + " Vsan "+ vsan.getKey().getVsanID()); for (ZoneSet zoneset : zoneSets) { System.out.println("VsanId:"+ vsan.getKey().getVsanID() + ",Vsan WWN:"+ vsan.getKey().getPWwn().getValue()+ ",ZonesetName:" + zoneset.getName()+ ",Status:" + zoneset.isActive()); private static Fabric[] getFabrics() { Fabric[] fabrics = san.getFabrics(); System.out.println("fabrics is null" + fabrics.length); trailer("No Fabric - Return to Main Menu"); private static _switch[] getSwitchesByFabric(Fabric fabric) { _switch[] sws = san.getSwitchesByFabric(fabric.getFabricKey()); System.out.println("No switches found for fabric"); header(sws.length + " switch(es) found for fabric"); System.out.println("Name:" + sw.getName() + ",IP:"+ sw.getIpAddress() + ",WWN:"+ sw.getWwn().getValue()); private static Vsan[] getVsans(Fabric fabric) { Vsan[] vsans = san.getVsans(fabric.getFabricKey()); System.out.println("No vsans found for fabric"); header(vsans.length + " vsan(s) found for fabric"); for (Vsan vsan : vsans) { System.out.println("VanID:" + vsan.getKey().getVsanID()+ ",VsanWWN:" + vsan.getKey().getPWwn().getValue()); * This method displays all the active and local zones in the fabric. * ZoneManagerWS:getEnfZones() * ZoneManagerWS:getZones() public void displayZone() throws Exception { Fabric[] fabrics=getFabrics(); for (Fabric fabric : fabrics) { System.out.println("Discovered the Fabric with WWN:" + fabric.getSeedSwWwn().getValue()); _switch[] sws = getSwitchesByFabric(fabric); Vsan[] vsans = getVsans(fabric); for (Vsan vsan : vsans) { Zone[] enfZones = getEnfZones(vsan); for (Zone ezone : enfZones) { System.out.println("vsan id:"+ vsan.getKey().getVsanID() + ",vsan wwn:"+ vsan.getKey().getPWwn().getValue()+ ",Zone Name:" + ezone.getName() + ",Status:"+ ezone.isActive()); for (Vsan vsan : vsans) { Zone[] zones = getZones(vsan, sw); if (zones == null) continue; for (Zone zone : zones) { System.out.println("vsan id:"+ vsan.getKey().getVsanID() + ",vsan wwn:"+ vsan.getKey().getPWwn().getValue()+ ",Zone Name:" + zone.getName() + ",Status:"+ zone.isActive()); private Zone[] getEnfZones(Vsan vsan) throws Exception { header(" Getting active zones for Vsan " + vsan.getKey().getVsanID()); enfZones = zoneManager.getEnfZoneSet(vsan.getKey()); System.out.println(enfZones.length+ " Active zones found for the Vsan "+ vsan.getKey().getVsanID()); System.out.println("No Active zones found"); private ZoneSet getEnfZonesets(Vsan vsan) throws Exception { header("Now getting active ZoneSets for Vsan " + vsan.getKey().getVsanID()); ZoneSet enfZoneset = null; enfZoneset = zoneManager.getEnfZoneSetDO(vsan.getKey()); System.out.println("Active zoneset for the VsanId: "+ vsan.getKey().getVsanID() + ", Pwwn: "+ vsan.getKey().getPWwn().getValue() + ", ZonesetName: " + enfZoneset.getName()+ ", Status " + enfZoneset.isActive()); System.out.println("Active zoneset is null"); private static Zone[] getZones(Vsan vsan, _switch sw) { header("Now getting Local Zones for switch " + sw.getName() + " vsan "+ vsan.getKey().getVsanID()); Zone[] zones = zoneManager.getZones(vsan.getKey(), new WwnKey(sw.getWwn())); System.out.println("Found " + zones.length + " zones"); System.out.println("No zones found "); public class ZoneWsUtil { public static String url = null; public static String username = null; public static String password = null; public static String token = null; public static Logon logon = null; public static San san = null; public static ZoneManager zoneManager = null; static BufferedReader input_ = null; static byte[] fromHexString(String hexStr, boolean hasColon) throws NumberFormatException { hexStr = hexStr.toLowerCase(); int len = hexStr.length(); byte bytes[] = new byte[hasColon ? ((len / 3) + 1) : (len / 2)]; int sPos = 0; // position in hexStr int bPos = 0; // position in bytes char a = hexStr.charAt(sPos); char b = hexStr.charAt(sPos + 1); if (hasColon && (a == ':' || b == ':')) throw new NumberFormatException("bad Hex format"); int v1 = Character.digit(a, 16); int v2 = Character.digit(b, 16); throw new NumberFormatException("bad Hex format"); int v3 = (int) (v1 * 16 + v2); sPos += hasColon ? 3 : 2; throw new NumberFormatException("bad Hex format"); throw new NumberFormatException("bad Hex format"); static String toHexString(byte[] inputByte) { char[] HEX_DIGIT = { '0', '1', '2', '3', '4', '5', '6', '7', '8', '9', 'a', 'b', 'c', 'd', 'e', 'f' }; if (inputByte == null || inputByte.length == 0) StringBuffer outputstr = new StringBuffer(inputByte.length * 3); for (int i = 0; i < inputByte.length; i++) { int n = (int) (inputByte[i] & 0xFF); outputstr.append(HEX_DIGIT[(n >> 4) & 0x0F]); outputstr.append(HEX_DIGIT[n & 0x0F]); if (i + 1 < inputByte.length) return outputstr.toString(); static void header(String text) { System.out.println(text); static void trailer(String string) { System.out.println("\n******************************** END OF " + string + " ******************************** "); * This static method is used read the login credentials from the properties * file named "configuration.properties" public static void getCredentials() { Properties props = new Properties(); System.out.println("Reading credentials from the 'configuration.properties' file"); props.load(new FileInputStream("configuration.properties")); url = props.getProperty("FMServer-ipadress"); username = props.getProperty("UserName"); password = props.getProperty("Password"); catch (FileNotFoundException fe) { System.out.println("ZoneWsClient: 'configuration.properties' File Not found!!"); * This method is to check LogonWSService is available or not. If available public static void getLoginService() { String loginServiceAddr = "http://" + url + "/LogonWSService/LogonWS"; LogonServiceLocator logonService = new LogonServiceLocator(); logonService.setEndpointAddress("LogonPort", loginServiceAddr); logon = logonService.getLogonPort(); System.out.println("login service not available" + logon); System.out.println("Logon success."); * This method is to get login token. public static void getLogin() { token = logon.requestToken(username, password, 1000000000L); System.out.println("Token not found" + token); System.out.println("Token found for configured user. "); * This method is to check SanWSService is available or not. If available public static void getZoneManagerService() { String zmServiceAddr = "http://" + url + "/ZoneManagerWSService/ZoneManagerWS"; ZoneManagerServiceLocator zmService = new ZoneManagerServiceLocator(); zmService.setEndpointAddress("ZoneManagerPort", zmServiceAddr); zoneManager = zmService.getZoneManagerPort(); if (zoneManager == null) { System.out.println("zonemanager service not available"); SOAPHeaderElement hdrElement = setSoapHeader(token); ZoneManagerBindingStub zmStub = (ZoneManagerBindingStub) zoneManager; zmStub.setHeader(hdrElement); * This method is to check ZoneManagerWSService is available or not. If * available bind to the stub. public static void getSanService() { String sanServiceAddr = "http://" + url + "/SanWSService/SanWS"; SanServiceLocator sanService = new SanServiceLocator(); sanService.setEndpointAddress("SanPort", sanServiceAddr); san = sanService.getSanPort(); System.out.println("service not available"); SOAPHeaderElement hdrElement = setSoapHeader(token); SanBindingStub sStub = (SanBindingStub) san; sStub.setHeader(hdrElement); private static SOAPHeaderElement setSoapHeader(String token) { SOAPHeaderElement hdrElement = new SOAPHeaderElement( "http://ep.cisco.dcbu.cisco.com", "token"); hdrElement.setPrefix("m"); hdrElement.setMustUnderstand(false); hdrElement.setValue(token); static void exception(Exception e){ header("ZonwWsWclient: Some exception occurred!! \n"+e.toString()+"\nEnter [y] to view the stack trace or any key to continue..."); String view=input_.readLine(); if(view.equalsIgnoreCase("y")){ } catch (IOException e1) {
Perl Client
This section describes the Perl client that use the SOAP web services, installing ActiveState Perl, and the SOAP:Lite package. Also, this section provides information about installing ActiveState Perl, the SOAP:Lite package and the Perl client to consume the exposed SOAP web services along with the sample code.
This section contains the following sections:
Before executing the Perl script, install ActiveState Perl and the SOAP:Lite package.
Installing Perl
Step 1 Download Perl from http://www.perl.org/get.html
Note Choose and download the appropriate Perl version for your operating system.
Step 2 Run the downloaded executable file to install Perl.
Step 3 To verify whether Perl has been installed properly, use the perl -v CLI command in the command prompt.
If the installation is proper, the details of the installed version of Perl are displayed.
Running the Perl Clients
Note To run a Perl client, the client file and its module file need to be in the same Perl folder.
From the Perl folder where the source files exist, enter the following command:
perl Client-File-Name FM-Server-IP Username password
Figure A-1 Running a Perl Client
Running the Zone Client
To run the zone client, the files zoneClient.plx and zoneModule.plx need to be in same directory.
From the Perl folder where the source files exist, enter the following command:
perl zoneClient.plx FM-Server-IP Username password
Running the Statistics Client
To run the statistics client, the files statistics.plx and statisticsModule.plx need to be in same directory.
From the Perl folder where the source files exist, enter the following command:
perl statistics.plx FM-Server-IP Username password
Sample Code for Perl Client
Note • The sample code provided here works only with DCNM release 6.1(x) and later. For prior DCNM versions, you need to make changes to the namespace base on the WSDL.
-
To collect statistics related data, you need to turn on the PM.
Example A-2 ZoneClient.plx
# Description: zoneClient my $vsan_wwn = '20:01:00:0d:ec:19:6a:81'; my $wwn = '20:00:00:0d:ec:19:6a:80'; my $zoneMemberFormat = 1; my $zoneMemberIvrFabricIndex = -1; my $zoneMemberIvrVsanIndex = -1; my $zoneMemberId = 'b1a2334455667788'; my $zoneMemberLunId = ''; my $zoneSetName = 'ZoneSet5'; require 'zoneModule.plx'; ($url,$username,$password) = @ARGV; my $token = getToken($url,$username,$password); print "\nError in getToken call \n"; my $zoneIndex = createZone($token,$vsanId,$vsan_wwn,$wwn,$zoneName,$readOnly,$broadcast,$qos,$qosPriority); print "\nError in createZone call \n"; my $status = addZoneMemberToZone($token,$vsanId,$vsan_wwn,$wwn,$zoneName,$zoneMemberType,$zoneMemberFormat,$zoneMemberIvrFabricIndex,$zoneMemberIvrVsanIndex,$zoneMemberId,$zoneMemberLunId); print "\nError in addZoneMemberToZone call \n"; my $zoneSetIndex = createZoneSet($token,$vsanId,$vsan_wwn,$wwn,$zoneSetName); print "\nError in createZoneSet call \n"; my $status = addZoneToZoneset($token,$vsanId,$vsan_wwn,$wwn,$zoneIndex,$zoneName,$readOnly,$broadcast,$qos,$qosPriority,$zoneMemberDbId,$zoneMemberType,$zoneLastModtime,$zoneMemberLunId,$zoneisIvr,$zoneSetIndex,$zoneSetName,$active); print "\nError in addZoneToZoneset call \n"; $status = activateZoneset($token,$vsanId,$vsan_wwn,$wwn,$zoneSetName); print "\nError in activateZoneset call \n";
Example A-3 ZoneModule.plx
($url,$username,$password) = @_; #->uri('http://ep.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/LogonWSService/LogonWS?wsdl') ->ns('http://ep.jaxws.dcbu.cisco.com/','namesp1'); my $username = SOAP::Data->type('string')->name('username')->value($username); my $password = SOAP::Data->type('string')->name('password')->value($password); my $expiration = SOAP::Data->type('long')->name('expiration')->value(100000000); # Calling requestToken method my $result = $client->requestToken($username,$password,$expiration); unless ($result->fault) { my $token = $result->result(); ($token,$arg_vsanId,$arg_vsanwwn,$arg_wwn,$arg_zoneName,$arg_readOnly,$arg_broadcast,$arg_qos,$arg_qosPriority) = @_; my $VsanKey = SOAP::Data->name("vsanKey" => \SOAP::Data->value( SOAP::Data->name("vsanID" => $arg_vsanId), SOAP::Data->name("pWwn" => \SOAP::Data->value(SOAP::Data->name("value" => $arg_vsanwwn)))->type("Wwn")))->type("VsanKey"); my $Wwn = SOAP::Data->name("switchKey" => \SOAP::Data->value( SOAP::Data->name("wwn" => \SOAP::Data->value(SOAP::Data->name("value"=>$arg_wwn)))->type("Wwn")))->type("WwnKey"); my $zName = SOAP::Data->name("zoneName"=>$arg_zoneName); my $readOnly = SOAP::Data->name("readOnly")->value($arg_readOnly); my $broadcast = SOAP::Data->name("broadcast")->value($arg_broadcast); my $qos = SOAP::Data->type('boolean')->name("qos")->value($arg_qos); my $qosPriority = SOAP::Data->type('int')->name("qosPriority")->value($arg_qosPriority); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/ZoneManagerWSService/ZoneManagerWS?wsdl') ->ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp2'); # Calling createZone method my $result = $client->createZone($header,$VsanKey,$Wwn,$zName,$readOnly,$broadcast,$qos,$qosPriority); unless ($result->fault) { return $result->valueof('//index'); # Adding Zone Member To Zone sub addZoneMemberToZone { my $arg_zoneMemberFormat; my $arg_zoneMemberIvrFabricIndex; my $arg_zoneMemberIvrVsanIndex; ($token,$arg_vsanId,$arg_vsanwwn,$arg_wwn,$arg_zoneName,$arg_zoneMemberType,$arg_zoneMemberFormat,$arg_zoneMemberIvrFabricIndex,$arg_zoneMemberIvrVsanIndex,$arg_zoneMemberId,$arg_zoneMemberLunId) = @_; my @hex = ($arg_zoneMemberId =~ /(..)/g); my @dec = map { hex($_) } @hex; my @zoneMemberId = map { pack('C',$_) } @dec; my $arg_zoneMemberId = join("",@zoneMemberId); #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/ZoneManagerWSService/ZoneManagerWS?wsdl') ->ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp3'); my $VsanKey = SOAP::Data->name("vsanKey" => \SOAP::Data->value( SOAP::Data->name("vsanID" => $arg_vsanId), SOAP::Data->name("pWwn" => \SOAP::Data->value(SOAP::Data->name("value" => $arg_vsanwwn)))->type("Wwn")))->type("VsanKey"); my $Wwn = SOAP::Data->name("switchKey" => \SOAP::Data->value( SOAP::Data->name("wwn" => \SOAP::Data->value(SOAP::Data->name("value"=>$arg_wwn)))->type("Wwn")))->type("WwnKey"); my $zName = SOAP::Data->name("zoneName"=>$arg_zoneName); my $zMemberType = SOAP::Data->name("zoneMemberType")->value($arg_zoneMemberType); my $zMemberFormat = SOAP::Data->name("zoneMemberFormat")->value($arg_zoneMemberFormat); my $zMemberIvrFabricIndex = SOAP::Data->name('zoneMemberIvrFabricIndex')->value($arg_zoneMemberIvrFabricIndex); my $zMemberIvrVsanIndex = SOAP::Data->type('int')->name("zoneMemberIvrVsanIndex")->value($arg_zoneMemberIvrVsanIndex); my $zMemberId = SOAP::Data->name("zoneMemberId")->value($arg_zoneMemberId); my $zMemberLunId = SOAP::Data->name("zoneMemberLunId")->value(arg_zoneMemberLunId); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); my $result = $client->addZoneMemberToZone($header,$VsanKey,$Wwn,$zName,$zMemberType,$zMemberFormat,$zMemberIvrFabricIndex,$zMemberIvrVsanIndex,$zMemberId,$zMemberLunId); unless ($result->fault) { ($token,$arg_vsanId,$arg_vsanwwn,$arg_wwn,$arg_zoneSetName) = @_; #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/ZoneManagerWSService/ZoneManagerWS?wsdl') ->ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp4'); # Creating complex data type my $VsanKey = SOAP::Data->name("vsanKey" => \SOAP::Data->value( SOAP::Data->name("vsanID" => $arg_vsanId), SOAP::Data->name("pWwn" => \SOAP::Data->value(SOAP::Data->name("value" => $arg_vsanwwn)))->type("Wwn")))->type("VsanKey"); my $Wwn = SOAP::Data->name("switchKey" => \SOAP::Data->value( SOAP::Data->name("wwn" => \SOAP::Data->value(SOAP::Data->name("value"=>$arg_wwn)))->type("Wwn")))->type("WwnKey"); my $zSetName = SOAP::Data->name("zoneSetName"=>$arg_zoneSetName); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); # Calling createZone method my $result = $client->createZoneSet($header,$VsanKey,$Wwn,$zSetName); unless ($result->fault) { return $result->valueof('//index')."\n"; ($token,$arg_vsanId,$arg_vsanwwn,$arg_wwn,$arg_index,$arg_zoneName,$arg_readOnly,$arg_broadcast,$arg_qos,$arg_qosPriority,$arg_zoneMemberDbId,$arg_memberType,$arg_zoneLastModtime,$arg_zoneMemberLunId,$arg_isIvr,$arg_zoneSetindex,$arg_zoneSetName,$active) = @_; #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/ZoneManagerWSService/ZoneManagerWS?wsdl') ->ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp5'); # Creating complex data type my $VsanKey = SOAP::Data->name("vsanKey" => \SOAP::Data->value( SOAP::Data->name("vsanID" => $arg_vsanId), SOAP::Data->name("pWwn" => \SOAP::Data->value(SOAP::Data->name("value" => $arg_vsanwwn)))->type("Wwn")))->type("VsanKey"); my $Wwn = SOAP::Data->name("switchKey" => \SOAP::Data->value( SOAP::Data->name("wwn" => \SOAP::Data->value(SOAP::Data->name("value"=>$arg_wwn)))->type("Wwn")))->type("WwnKey"); my $zoneDO = SOAP::Data->name("zoneDo"=> \SOAP::Data->value( SOAP::Data->name("index"=>$arg_index), SOAP::Data->name("name"=>$arg_zoneName), SOAP::Data->name("readonly"=>$arg_readonly), SOAP::Data->name("qos"=>$arg_qos), SOAP::Data->name("qosPriority"=>arg_qosPriority), SOAP::Data->name("broadcast"=>$arg_broadcast), SOAP::Data->name("active"=>$active), SOAP::Data->name("zoneLastModtime"=>arg_zoneLastModtime), SOAP::Data->name("zoneMemberDbId"=>$arg_zoneMemberDbId), SOAP::Data->name("vsanId"=>$arg_vsanId), SOAP::Data->name("isIvr"=>$arg_isIvr), SOAP::Data->name("memberType"=>$arg_memberType), SOAP::Data->name("lunId"=>$arg_zoneMemberLunId)))->type("zone"); my $zoneSetDO = SOAP::Data->name("zoneSetDo"=> \SOAP::Data->value( SOAP::Data->name("index"=>$arg_zoneSetindex), SOAP::Data->name("name"=>$arg_zoneSetName), SOAP::Data->name("active"=>$active), SOAP::Data->name("zoneLastModified"=>$arg_zoneLastModtime)))->type("ZoneSet"); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); # Calling addZonetoZoneSet method my $result = $client->addZoneToZoneset($header,$VsanKey,$Wwn,$zoneDO,$zoneSetDO); unless ($result->fault) { ($token,$arg_vsanId,$arg_vsanwwn,$arg_wwn,$arg_zoneSetName) = @_; #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/ZoneManagerWSService/ZoneManagerWS?wsdl') ->ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp6'); # Creating complex data type my $VsanKey = SOAP::Data->name("vsanKey" => \SOAP::Data->value( SOAP::Data->name("vsanID" => $arg_vsanId), SOAP::Data->name("pWwn" => \SOAP::Data->value(SOAP::Data->name("value" => $arg_vsanwwn)))->type("Wwn")))->type("VsanKey"); my $Wwn = SOAP::Data->name("switchKey" => \SOAP::Data->value( SOAP::Data->name("wwn" => \SOAP::Data->value(SOAP::Data->name("value"=>$arg_wwn)))->type("Wwn")))->type("WwnKey"); my $zSetName = SOAP::Data->name("zoneSetName"=>$arg_zoneSetName); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); # Calling activateZoneset method my $result = $client->activateZoneset($header,$VsanKey,$Wwn,$zSetName); unless ($result->fault) {
Example A-4 StatisticsClient.plx
# File: StatisticsClient.plx # Description: Statistics Client my $sortField = 'rxTxStr'; require 'statisticsModule.plx'; ($url,$username,$password) = @ARGV; my $token = getToken($url,$username,$password); ($rrdFile,$fid,$pmType) = getIslStatList($token,$fabricDbId,$switchDbId,$vsanDbId,$sortField,$sortType,$limit,$groupId,$isGroup,$networkType,$filterStr,$temp,$startIdx,$recordSize); for (my $i=0;$i<1;$i++) { getPmChartData($token,@$rrdFile[$i],@$pmType[$i],@$fid[$i],$interval) . "\n";
Example A-5 StatisticsModule.plx
($url,$username,$password) = @_; #->uri('http://ep.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/LogonWSService/LogonWS?wsdl') -> ns('http://ep.jaxws.dcbu.cisco.com/','namesp1'); my $username = SOAP::Data->type('string')->name('username')->value($username); my $password = SOAP::Data->type('string')->name('password')->value($password); my $expiration = SOAP::Data->type('long')->name('expiration')->value(100000000); # Calling requestToken method my $result = $client->requestToken($username,$password,$expiration); unless ($result->fault) { my $token = $result->result(); ($token,$arg_fabricDbId,$arg_switchDbId,$arg_vsanDbId,$arg_sortField,$arg_sortType,$arg_limit,$arg_groupId,$arg_isGroup,$arg_networkType,$arg_filterStr,$arg_interval,$arg_startIdx,$arg_recordSize) = @_; my $DbFilter= SOAP::Data->name("arg0" => \SOAP::Data->value( SOAP::Data->name("fabricDbId" => $arg_fabricDbId), SOAP::Data->name("switchDbId" => $arg_switchDbId), SOAP::Data->name("vsanDbId" => $arg_vsanDbId), SOAP::Data->name("sortField" => $arg_sortField), SOAP::Data->name("sortType" => $arg_sortType), SOAP::Data->name("limit" => $arg_limit), SOAP::Data->name("groupId" => $arg_groupId), SOAP::Data->name("isGroup" => $arg_isGroup)->type("boolean"), SOAP::Data->name("networkType" => $arg_networkType), SOAP::Data->name("filterStr" => $arg_filterStr)))->type("DbFilter"); my $interval = SOAP::Data->type("string")->name("arg1")->value($arg_interval); my $data_startIdx = SOAP::Data->name("arg2"=>$arg_startIdx); my $data_recordSize = SOAP::Data->name("arg3"=>$arg_recordSize); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); #my $header = SOAP::Header->name('token')->prefix('m')->value($token)->type('string'); #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/StatisticsWSService/StatisticsWS?wsdl') -> ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp2'); # Calling getIslStatDataLength method my $result = $client->getIslStatList($header,$DbFilter,$interval,$data_startIdx,$data_recordSize); unless ($result->fault) { print "\ngetIslStatList\n\n"; my @fabric = $result->valueof('//item/fabric'); my @title = $result->valueof('//item/title'); my @maxTxStr = $result->valueof('//item/maxTxStr'); my @maxRxStr = $result->valueof('//item/rxTxStr'); my @rxTx = $result->valueof('//item/rxTx'); print "---------------------------------------------------------\n"; print "Fabric -> " . $fabric[$i] . "\n"; print "Title -> " . $title[$i] . "\n"; print "maxTxStr -> " . $maxTxStr[$i] . "\n"; print "maxRxStr -> " . $maxRxStr[$i] . "\n"; print "rxTx -> " . $rxTx[$i] . "\n"; print "---------------------------------------------------------\n"; my @rrdFile = $result->valueof('//item/rrdFile'); my @fid = $result->valueof('//item/fid'); my @pmType = $result->valueof('//item/pmtype'); return (\@rrdFile,\@fid,\@pmType); ($token,$arg_rrd,$arg_pmType,$arg_fid,$arg_interval) = @_; my $data_rrd = SOAP::Data->type("string")->name("arg0")->value($arg_rrd); my $data_pmType = SOAP::Data->name("arg1")->value($arg_pmType); my $data_fid = SOAP::Data->name("arg2"=>$arg_fid); my $data_interval = SOAP::Data->name("arg3"=>$arg_interval); my $header = SOAP::Header->name('token')->prefix('m')->value($token)->uri('http://ep.cisco.dcbu.cisco.com')->type('string'); #->uri('http://ep.san.jaxws.dcbu.cisco.com/') ->proxy('https://'.$url.'/StatisticsWSService/StatisticsWS?wsdl') -> ns('http://ep.san.jaxws.dcbu.cisco.com/','namesp3'); # Calling getPmChartData method my $result = $client->getPmChartData($header,$data_rrd,$data_pmType,$data_fid,$data_interval); unless ($result->fault) { print "\n\nGetPmChartData\n\n"; my @item = $result->valueof('//item/item'); for(my $i=2;$i<30;$i=$i+3) { print "---------------------------------------------------------\n"; print "Rx -> ".$item[$i-2]."\n"; print "Tx -> ".$item[$i-1]."\n"; print "Time -> ".scalar localtime($item[$i]) . "\n"; print "---------------------------------------------------------\n";
REST Web Services
The following client programs use REST web services in Cisco DCNM.
This section contains the following sections:
Python Client
This section provides information about installing Python, and using the python client to consume the exposed REST web services along with the sample code.
This section contains the following sections:
Running Python Client Using IDE
Step 1 Using Pycharm (Python IDE), set the interpreter to the location where python is installed. For example, C:\Users\ Local\Programs\Python\Python36-32\python.exe.
Note In the MyClient.py file, set the queryKey, zone name, zoneset name, fabricDBID accordingly.
Step 2 Go to
Run > Edit Configurations
. In the Script parameters tab provide the arguments such as FMServerIP, UserName, Password that need to be separated by blank spaces. For example, FMServerIP username password)
Step 3 Right-click on the file, and select “Run FileName”.
Running Python Client Using Command Prompt
Step 1 Using the command prompt, go to the location where python is installed.
Note In the MyClient.py file, set the queryKey, zone name, zoneset name, fabricDBID accordingly.
C:\users\exampleuser\AppData\Local\Programs\Python\Python36>python.exe C:\Users\exampleuser\PycharmProjects\PythonRestClient\MyClient.py FMServerIP username password
Step 2 Execute “
python.exe
<complete path for MyClient.py file> FMServerIP username password
”. For example:
C:\Python\Python36-32>python.exe C:\Users\PycharmProjects\PythonRestClient\MyClient.py FMServerIP username password
Sample Code for Python Client
Example A-6 MyClient.py
from restfactory import RestFactory rf = RestFactory(fmserver, user, password) i_rest = rf.get_webzonemanager_rest(); zonesetName = "PythonZoneSetTest" switchName = "sw-9148-248" fabricName = "Fabric_sw-9250i-244" cacheBust = i_rest.getCacheBust() fabricDBID = i_rest.get_fabrics(cacheBust, navId,fabricName) print("fabricDBID "+str(fabricDBID)) vsanDBID = i_rest.get_vsanDBID(fabricDBID,cacheBust,navId,vsanID,switchName) print("VSANDBID "+str(vsanDBID)) swwn = i_rest.get_switchesForVsan(fabricDBID,vsanDBID,cacheBust,navId,vsanID,switchName) #queryKey is the combination of <FDBID>,<VSANIndex>,<SWWWN>,<client ID>,<otherclient data> queryKey = i_rest.generate_queryKey(fabricDBID,vsanID,swwn,"-1","-1") createZoneSetResponse = i_rest.createZoneSet(queryKey, zonesetName, fabricDBID) createZoneResponse = i_rest.create_zone(queryKey, zoneName, fabricDBID) addZoneResponse = i_rest.addZoneToZoneSet(queryKey, zoneName, zonesetName, fabricDBID) # # deletingZoneFromZoneSet removeZoneFromZoneSet = i_rest.removeZoneToZoneSet(queryKey, zoneName, zonesetName, fabricDBID) deleteZoneResponse = i_rest.deleteZone(queryKey, zoneName, fabricDBID) deleteZoneSet = i_rest.deleteZoneset(queryKey, zonesetName, fabricDBID)
Example A-7 restfactory.py
from san_rest_api import RestApi from webzonemanagerrest import WebZoneManager class RestFactory(object): _expiration_time = "9999999" def __init__(self, dcnm_url , username = None, password = None): self._username = username self._password = password dcnm_url = "https://" + dcnm_url + "/" self._rest_api = RestApi(dcnm_url, dcnm_token = self._rest_api.dcnm_token['Dcnm-Token'] raise Exception("Failed to instantiate RestFactory as Dcnm-Token is :" + dcnm_token) self._rest_api.headers['Dcnm-Token'] = dcnm_token print("headers with token") print(self._rest_api.headers) self._dcnm_url = dcnm_url def get_webzonemanager_rest(self): return WebZoneManager(self._dcnm_url, self._rest_api)
Example A-8 san_rest_api.py
"""This class handles all the REQUEST modules required for DCNM""" """This handles all the request modules""" def __init__(self, *args): self.headers = {'Content-Type': 'application/json; charset=utf8'} self.logon_url = self.dcnm_url + LOGON_URL self.expiration_time = args[3] self.credentials = self.generate_encoded_credentials( self.username, self.password) self.dcnm_token = self.generate_dcnmtoken(self.credentials) def generate_encoded_credentials(self, username, password): """This generates the credentials""" data = {'Content-Type': 'application/json; charset=utf8'} credentials = username + ':' + password encoded = base64.b64encode(credentials.encode()) print(encoded.decode('ascii')) data.update({"Authorization": 'Basic ' + encoded.decode('ascii')}) """This generates valid DCNM-Token for the encoded credentials""" payload = {'expirationTime': self.expiration_time} print("//////////Header///////") response = requests.post( data=json.dumps(payload), if response.status_code == 200: # Successful token generation dcnm_token = ast.literal_eval(response.text)
Example A-9 webzonemanagerrest.py
class WebZoneManager(object): ZONE_REST_PATH = "fm/fmrest/WebZoneManager/" CREATE_ZONE = "createZoneMod" CREATE_ZONESET = "createZoneSetMod" ADD_ZONE_TO_ZONESET = "addZonesToZonesetMod" REGISTER_AND_POPULATE = "registerAndPopulateLocalZoneDBGet" DELETE_ZONE_FROM_ZONESET = "deleteZonesFromZonesetMod" DELETE_ZONESET = "deleteZonesetsMod" DELETE_ZONE = "deleteZonesMod" GET_FABRICS_URL = 'fm/fmrest/dcnm/fabrics' GET_VSANS_MOD_URL = "getVsansMod" GET_SWITCHES_IN_VSAN = "getSwitchesInVSANMod" def __init__(self, dcnm_url, restapi): self._dcnm_url = dcnm_url + self.ZONE_REST_PATH self.get_fabrics_url = dcnm_url + self.GET_FABRICS_URL self.headers = {'Content-Type': 'application/json; charset=utf8'} def createZoneSet(self, queryKey, zonesetName, fabricDBID): print("creating zoneset") zoneset_url = self._dcnm_url+self.CREATE_ZONESET; self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneSetName'] = zonesetName payload['fabricDBID'] = fabricDBID response = requests.post(url=zoneset_url, data=payload, headers=self._rest_api.headers, verify=self.verify) def create_zone(self, queryKey, zoneName, fabricDBID): zone_url = self._dcnm_url + self.CREATE_ZONE self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneName'] = zoneName payload['fabricDBID'] = fabricDBID response = requests.post(zone_url, data=payload, headers=self._rest_api.headers, verify=self.verify) print("printing response") def addZoneToZoneSet(self, queryKey, zoneNames, zonesetName, fabricDBID): print("adding zone to zoneset") addzoneurl = self._dcnm_url + self.ADD_ZONE_TO_ZONESET self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneNames'] = zoneNames payload['zonesetName'] = zonesetName payload['fabricDBID'] = fabricDBID response = requests.post(addzoneurl, data=payload, headers=self._rest_api.headers, verify=self.verify) print("printing response") def removeZoneToZoneSet(self, queryKey, zoneNames, zonesetName, fabricDBID): print("deleting zone from zoneset") removezoneurl = self._dcnm_url + self.DELETE_ZONE_FROM_ZONESET self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneName'] = zoneNames payload['zonesetName'] = zonesetName payload['fabricDBID'] = fabricDBID response = requests.post(url=removezoneurl, data=payload, headers=self._rest_api.headers, verify=self.verify) print("printing response") def deleteZone(self, queryKey, zoneName, fabricDBID): deletezoneurl = self._dcnm_url + self.DELETE_ZONE self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneName'] = zoneName payload['fabricDBID'] = fabricDBID response = requests.post(url=deletezoneurl, data=payload, headers=self._rest_api.headers, verify=self.verify) print("printing response") def deleteZoneset(self, queryKey, zonesetName, fabricDBID): print("deleting zoneset") delete_ZoneSet_url = self._dcnm_url+self.DELETE_ZONESET print(delete_ZoneSet_url) self._rest_api.headers['Content-Type'] = 'application/x-www-form-urlencoded' payload['queryKey'] = queryKey payload['zoneSetName'] = zonesetName payload['fabricDBID'] = fabricDBID response = requests.post(url=delete_ZoneSet_url, data=payload, headers=self._rest_api.headers, verify=self.verify) def registerAndPopulate(self,queryKey,fabricDBID,clientRequestID,navId): registerAndPopulate_url = self._dcnm_url+self.REGISTER_AND_POPULATE registerAndPopulate_url += '/?queryKey=' + queryKey + '&fabricDBID=' + fabricDBID + '&clientRequestID=' + clientRequestID + \ '&cacheBust=' + self.getCacheBust() + '&navId=' + navId response = requests.get(registerAndPopulate_url, params=None, headers=self._rest_api.headers, verify=self.verify) resp_dict = json.loads(response.text) req_key = resp_dict['requestKey'] return str(int(time.time() * 1000)) def get_fabrics(self, cachebust, navId, fabricName): print("fetching fabrics") get_fabric_url = self.get_fabrics_url+"/?"+'&cacheBust=' + cachebust + '&navId=' + navId self.headers['Content-Type'] = 'application/x-www-form-urlencoded' response = requests.get(url=get_fabric_url, params=None, headers=self._rest_api.headers, verify=self.verify) resp = json.loads(response.text) if res['name'] == fabricName: def get_vsanDBID(self, fabricid, cachebust, navId, vsanID, switchName): get_vsans_url = self._dcnm_url+self.GET_VSANS_MOD_URL+"/?"+'&fabricDBID=' + str(fabricid) +'&cacheBust=' + cachebust + '&navId=' + navId self.headers['Content-Type'] = 'application/x-www-form-urlencoded' response = requests.get(url=get_vsans_url, params=None, headers=self._rest_api.headers, verify=self.verify) resp = json.loads(response.text) if res['vsanIndex'] == vsanID: if res['prinswName'] == switchName: self.vsan_dbid = (res['DBID']) def get_switchesForVsan(self, fabricid, vsanid, cachebust, navId, vsanID, switchName): print("fetching switches") get_switches_for_vsans_url = self._dcnm_url+self.GET_SWITCHES_IN_VSAN + "/?" + '&fabricDBID=' + str( fabricid) + '&vsanDBID=' + str(vsanid) +'&cacheBust=' + cachebust + '&navId=' + navId print(get_switches_for_vsans_url) self.headers['Content-Type'] = 'application/x-www-form-urlencoded' response = requests.get(url=get_switches_for_vsans_url, params=None, headers=self._rest_api.headers, verify=self.verify) resp = json.loads(response.text) if res['sys_name'] == switchName: self.switchWWN = res['swWWN'] def generate_queryKey(self,fDBID,vsanIndex,SWWN,clientID,otherClientData): key = str(fDBID)+","+str(vsanIndex)+","+SWWN+","+clientID+","+otherClientData; self.queryKey = self.registerAndPopulate(key,str(fDBID),clientID,"-1") print("query key "+self.queryKey)
JavaScript Client
This section provides information about using the JavaScript client to access REST Web Services along with sample code and configuring the CORS plugin.
This section contains the following sections:
Downloading and Configuring the CORS Toggle Plug-in
Step 1 Download the CORS Toggle plugin from Chrome web store using the following URL:
https://chrome.google.com/webstore/search/CORSToggle?hl=en-US
Step 2 Add the Access control Allow-Headers in the space provided and save. (For example, Content-Type, Authorization, Dcnm-Token).
Step 3 Ensure CORS status is ‘ON’.
Step 4 Click on the plug-in to change the status.
Running JavaScript REST Client
Step 1 Double-click on
JavaScript_Client.html, which
will show the below UI in web browser.
Step 2 Fill the above fields, and click the
Submit
button. Cisco DCNM performs the supported zone-related operations and displays the status message.
Step 3 After you get a success message, you can verify this in Cisco DCNM GUI (/SAN/Zoning).
Sample Code for JavaScript Client
Example A-10 JavaScript_Client.html
src="https://ajax.aspnetcdn.com/ajax/jQuery/jquery-3.2.1.min.js"></script> <script type="text/javascript"> var user = document.getElementById("un").value; var password = document.getElementById("pw").value; var serverIP = document.getElementById("ip").value; var fabricName = document.getElementById("fabricName").value; var switchName = document.getElementById("switchName").value; var zoneSetName = document.getElementById("zoneSetName").value; var zoneName = document.getElementById("zoneName").value; var vsanID = document.getElementById("vsanID").value; var cacheBust = new Date().getTime() * 1000; var encodeUP = btoa(user + ':' + password); var authorization='Basic ' + encodeUP; // Below ajax is for Getting Dcnm-token from serverIP "Authorization" : authorization, url : "https://" + serverIP + "/rest/logon", expirationTime : '9999999' methods : "GET,PUT,POST,DELETE" error : function(xhr, status, error) { document.getElementById("result").innerHTML = data.statusMessage success : function(msg, status, xhr) { var dcnmToken = xhr.responseText; dcnm_Token = dcnmToken.substring(15, url : 'https://' + serverIP + "/fm/fmrest/dcnm/fabrics/?&cacheBust=" + cacheBust + "&navId=" + navID, "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { console.log("data= " + fabrics); var fab = JSON.stringify(data); var fabrics = JSON.parse(fab); for (var i = 0; i < fabrics.length; i++) { if (fabricName == fabrics[i].name) { fabricDBID = fabrics[i].id; error : function(xhr, textStatus, errorThrown) { document.getElementById("result").innerHTML = " " //getting the VsanDBID from the vsanID (vsanID is provided as the input) function getVsanDbId(fabricDBID) { + '/fm/fmrest/WebZoneManager/getVsansMod/?&fabricDBID=' + fabricDBID + '&cacheBust=' + cacheBust "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { console.log("data= " + data); var vsanSwitches = JSON.stringify(data); var vsanSwitch = JSON.parse(vsanSwitches); for (var i = 0; i < vsanSwitch.length; i++) { if (vsanID == vsanSwitch[i].vsanIndex) { if (switchName == vsanSwitch[i].prinswName) { vsanDbId = vsanSwitch[i].DBID; getSwitchesInVSANMod(vsanDbId); error : function(xhr, textStatus, errorThrown) { document.getElementById("result").innerHTML = data.statusMessage function getSwitchesInVSANMod(vsanDbId) { + '/fm/fmrest/WebZoneManager/getSwitchesInVSANMod/?&fabricDBID=' + fabricDBID + '&vsanDBID=' + vsanDbId + '&cacheBust=' + cacheBust + '&navId=' "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { console.log("data " + data); var sw_wwn = JSON.stringify(data); var sw_WWN = JSON.parse(sw_wwn); for (var i = 0; i < sw_WWN[1].length; i++) { if (switchName == sw_WWN[1][i].sys_name) { swWWN = sw_WWN[1][i].swWWN; generateQueryKey(fabricDBID, vsanID, swWWN, -1, error : function(xhr, textStatus, errorThrown) { document.getElementById("result").innerHTML = " " function generateQueryKey(fabricId, vsanID, SWWN, clientRequestID, var key = fabricId + ',' + vsanID + ',' + SWWN + ',' + clientRequestID + ',' + otherClientData; + '/fm/fmrest/WebZoneManager/registerAndPopulateLocalZoneDBGet/?queryKey=' + key + '&fabricDBID=' + fabricDBID + '&clientRequestID=' + clientRequestID + '&cacheBust=' + cacheBust + '&navId=' "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { console.log("data " + data); var query_Key = JSON.stringify(data); var query = JSON.parse(query_Key); queryKey = query.requestKey; createZoneset(queryKey, zoneSetName, fabricDBID) error : function(xhr, textStatus, errorThrown) { document.getElementById("result").innerHTML = " " function createZoneset(queryKey, zoneSetName, fabricDBID) { payload['queryKey'] = queryKey; payload['zoneSetName'] = zoneSetName; payload['fabricDBID'] = fabricDBID; + '/fm/fmrest/WebZoneManager/createZoneSetMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result").innerHTML = data.status createZone(queryKey, zoneName, fabricDBID); error : function(xhr, textStatus, errorThrown) { document.getElementById("result").innerHTML = " " function createZone(queryKey, zoneName, fabricDBID) { payload['queryKey'] = queryKey; payload['zoneName'] = zoneName; payload['fabricDBID'] = fabricDBID; url : 'https://' + serverIP + '/fm/fmrest/WebZoneManager/createZoneMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result1").innerHTML = data.status addZonesToZoneset(queryKey, zoneName, zoneSetName, fabricDBID); error : function(xhr, textStatus, errorThrown) { document.getElementById("result1").innerHTML = " " // 3. Adding Zones to Zoneset function addZonesToZoneset(queryKey, zoneNames, zonesetName, payload['queryKey'] = queryKey; payload['zoneNames'] = zoneNames; payload['zonesetName'] = zoneSetName; payload['fabricDBID'] = fabricDBID; + '/fm/fmrest/WebZoneManager/addZonesToZonesetMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result2").innerHTML = data.status + "- Adding Zones to Zoneset "; deleteZonesFromZoneset(queryKey, zoneName, zoneSetName, fabricDBID); error : function(xhr, textStatus, errorThrown) { document.getElementById("result2").innerHTML = " " // 4. Deleting Zones from zoneset function deleteZonesFromZoneset(queryKey, zoneNames, zonesetName, payload['queryKey'] = queryKey; payload['zoneName'] = zoneNames; payload['zonesetName'] = zonesetName; payload['fabricDBID'] = fabricDBID; + '/fm/fmrest/WebZoneManager/deleteZonesFromZonesetMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result3").innerHTML = data.status + "- Deleting Zones from Zoneset "; deleteZones(queryKey, zoneName, fabricDBID); error : function(xhr, textStatus, errorThrown) { document.getElementById("result3").innerHTML = " " function deleteZones(queryKey, zoneName, fabricDBID) { payload['queryKey'] = queryKey; payload['zoneName'] = zoneName; payload['fabricDBID'] = fabricDBID; + '/fm/fmrest/WebZoneManager/deleteZonesMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result4").innerHTML = data.status deleteZoneset(queryKey, zoneSetName, fabricDBID); error : function(xhr, textStatus, errorThrown) { document.getElementById("result4").innerHTML = " " function deleteZoneset(queryKey, zonesetName, fabricDBID) { payload['queryKey'] = queryKey; payload['zonesetName'] = zonesetName; payload['fabricDBID'] = fabricDBID; + '/fm/fmrest/WebZoneManager/deleteZonesetsMod', "Content-Type" : "application/x-www-form-urlencoded", "Authorization" : authorization, "Dcnm-Token" : dcnm_Token success : function(data, textStatus, xhr) { document.getElementById("result5").innerHTML = data.status error : function(xhr, textStatus, errorThrown) { document.getElementById("result5").innerHTML = " " <td><input id="ip" type="text" value=""></td> <td><input id="un" type="text" value=""></td> <td><input id="pw" type="password" value=""></td> <td><input id="fabricName" type="text" <td><input id="switchName" type="text" value=""></td> <td><input id="vsanID" type="text" value=""></td> <td><input id="zoneSetName" type="text" name="zoneSetName" <td><input id="zoneName" type="text" name="zoneName" value="" /></td> <button type="button" onclick="loadDoc()">Submit</button> <!-- below divs for displaying status messages -->
