Release Notes for Cisco SIP IP Phone 7940/7960 Release 4.0
June 22, 2004
Contents
This document lists the known problems in the Cisco Session Initiation Protocol (SIP) IP Phone 7940/7960 Release 4.0 and contains information about the Cisco SIP IP Phone 7940/7960 (hereafter referred to as the Cisco SIP IP phone) that was not included in the most recent release of the phone documentation.
This document includes the following sections:
•Obtaining Technical Assistance
New and Changed Information
New Software Features in Release 4.0
ISO 8859-1 Latin1 Character Support
The Cisco SIP IP Phone supports the ISO 8859-1 Latin1 character set, which covers most of Western Europe, the entire American continent, Australia, and much of Africa.
Supported Languages
Languages supported as part of the ISO 8859-1 Latin1 character set include French (fr), Spanish (es), Catalan (ca), Basque (eu), Portuguese (pt), Italian (it), Albanian (sq), Rhaeto-Romanic (rm), Dutch (nl), German (de), Danish (da), Swedish (sv), Norwegian (no), Finnish (fi), Faroese (fo), Icelandic (is), Irish (ga), Scottish (gd), English (en), Afrikaans (af), and Swahili (sw).
The lack of the ligatures (Dutch IJ, French OE, and, German`` quotation marks) is considered tolerable.
Unsupported Languages
The most notable unsupported languages are Zulu (zu) and other Bantu languages that use Latin Extended-B letters. Also not supported are Arabic in North Africa and Guarani (gn), which are missing GEIUY with tilde (~).
SIP Support
The phone can support the ISO 8859-1 Latin1 characters. However, the XML cards, information text, and menus are all in English. These items are built into the phone image and cannot be changed.
The customer can use the ISO 8859-1 Latin1 characters in the following three areas:
•Caller id information—When a SIP message is received with ISO 8859-1 Latin1 characters in the caller ID strings, those caller ID strings are displayed on the LCD screen of the phone with the correct ISO 8859-1 Latin1 characters.
•Services menu applications written in CMXML—The customer can develop language-specific applications for a particular region. For example, the customer can write an application that displays the current weather in Sweden using Swedish language characters. The Swedish characters would be displayed on the phone. If the customer were to develop the same application for a Spanish town, the application could easily be translated into Spanish.
•Line key labels—The line keys can also be configured to have the Latin1 characters in them. Simply specify the name in the configuration file, and it is displayed correctly. The Latin1 characters cannot be used in the lineX_name parameter, but can be used in the lineX_shortname and lineX_displayname parameters. If a proxy supports Latin1 characters in the To/From headers, they can be used in the lineX_name parameter as well.
HTTP Proxy Support
This feature allows requests for Call Manager eXtensible Markup Language (XML) services to be routed through an HTTP proxy.
ARP Changes
Changes to the application allow the Cisco SIP IP phone to receive broadcast Address Resolution Protocol (ARP) updates. Previously, this was unavailable. When a hot standby proxy system is used, the phone can receive unsolicited updates from the backup proxy, such as when the backup proxy tells all devices to use its IP address when the primary proxy fails. Previously, the phone would ignore such messages and continue to use the MAC address for the primary proxy.
DNS/TFTP Server in Configuration Files
This feature allows the service provider to specify a DNS server and/or a TFTP server in the configuration files (either the default configuration file or the <mac-addr> configuration file). The phone will go to the default TFTP server to get the default and mac-addr configuration files. Then it will parse them completely. When it is done, it will look to see if a new DNS server or TFTP server was specified in those files. If a new DNS server was specified, it will be used for any further DNS requests. If a TFTP server was specified, the phone will rerequest the default and mac-addr configuration files from the new TFTP server.
i Button Support
Currently, the i button serves no purpose as a help menu on the SIP versions of the Cisco SIP IP phone. Support has been added to enable the i button to display a descriptor of the key pressed in a direct sequence after pressing the i button.
Example: <i> then <up/down toggle> displays the following screen:
"I - Information - To scroll up on the LCD press the scroll up button. A small arrow displays when there is text for you to scroll through."
Remote Party ID Header
The Remote Party ID header supports network verification and screening of a call participant's identity (name, number) as well as provide a call participant's privacy. Details are contained in the privacy draft draft-ietf-sip-privacy-04.txt. The ability to use this new header is controlled with the configuration parameter remote_party_id.
Multiple 18x Responses
This feature introduces support for multiple 18x responses, which enables Find-Me/Follow-Me/Forwarding services.
Multiple Contact Headers in 3xx Responses
When multiple contacts are provided in a 3xx response, the phone previously ignored all but the first entry. The ability to walk a list of contacts has been added. The phone will attempt to use the information provided in each contact.
XML Support
Support for eXtensible Markup Language (XML) has been added in Cisco IP Phone 7940/7960 Release 4.0 as described in the following sections. For more information, refer to the "Product Overview" section of Cisco SIP IP Phone 7940/7960 Administrator Guide, Version 4.0.
BTXML Support
Basic Telephony eXtensible Markup Language (BTXML) is supported on the Cisco SIP IP phone. BTXML defines XML elements for controlling the user interface of an IP telephone. BTXML describes what information is displayed on the screen and how the user provides input using soft keys and hard keys.
Cisco CallManager XML Support
The Cisco SIP IP phone supports customer-written Cisco CallManager XML cards that can be accessed using buttons or soft keys on the phone. These cards can provide data such as stock quotes, calendars, and directory lookups.
Installation Notes
For Cisco SIP IP phones, follow the instructions in the "Upgrading the Cisco SIP IP Phone Firmware" section at the following URL:
http://www.cisco.com/univercd/cc/td/doc/product/voice/c_ipphon/sip7960/sadmin31/sipmntn.htm
For these instructions, use P0S3-04-0-00 as the image name for Release 4.0.
Caveats
Open Caveats—Release 4.0
This section documents possible unexpected behavior by Cisco IP Phone 7940/7960 Release 4.0 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•CSCdu68091: No support for configurable action tag in REGISTER Contact.
Problem Description: When the phone sends a REGISTER message, it does not attach an action= tag to the Contact header. This can lead to mismatched registrations when another client registers with the same user ID because the 7960/7940 is always treated as action=none.
Recommended Action: Configure the other client to have action=none to avoid mismatched registrations.
•CSCdy25289: 79x0 does not support UDP fragmentation
Problem Description: Phone does not support User Datagram Protocol (UDP) fragmentation. Packets get dropped.
Recommended Action: Make sure that any packets the phone receives are less than 1300 bytes in length.
•CSCdy39019: Headset w/ Cisco phone causes humming sound
Problem Description: When using a headset that is on the preferred headset list, the Cisco phone has a background noise. This is especially evident when calling to a PBX phone. When VAD is enabled the background noise is worse. The background noise is described as a humming sound.
Recommended Action: None.
•CSCdy39222: Phone does not check RURI for call leg identification
Problem Description: The phone does not check RURI for call leg identification.
Recommended Action: Do not fork a SIP call to two separate lines of a single phone.
Resolved Caveats—Release 4.0
All the caveats listed in this section are resolved in Cisco IP Phone 7940/7960 Release 4.0. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•CSCds35841: When in overview mode, the Cisco SIP IP phone soft keys do not work.
•CSCdv90788: MWI/Ringer lamp lights briefly when answering call waiting call.
•CSCdw40309: Multiple hookflashes cause speaker pops.
•CSCdu02920: Address Resolution Protocol (ARP) cache does not update correctly.
•CSCdx8913: REFER retransmitted when 4xx,5xx,or 6xx received (not 405 or 501).
Related Documentation
•Cisco SIP IP Phone 7940/7960 Administrator Guide Version 4.0
•Cisco IP Phone 7960/7940 Series - Quick Reference
•Regulatory Compliance and Safety Information for the Cisco IP Phone 7960, 7940, and 7910 Series
•Installing the Wall Mount Kit for the Cisco IP Phone
