EoS for Cisco Catalyst 8510/8540 MSR Switch & Cisco Lightstream 1010 ATM Switch [Cisco Lightstream ATM Switches]

End-of-Life Notice, No. 2833

Cisco Systems® announces the end-of-sale and end-of-life dates for the Cisco® Catalyst® 8510 MSR Switch, Catalyst 8540 MSR Switch, and Cisco LightStream 1010 ATM Switch. The last day to order the affected products is April 29, 2006. Customers with active service contracts will continue to receive support from the Cisco Technical Assistance Center (TAC) until April 29, 2011. Table 1 describes the end-of-life milestones, definitions, and dates for the affected product. Table 2 lists the product part numbers affected by this announcement.

Customers are encouraged to migrate to the products listed in the Product Migration Options section of this announcement.

Table 1. End-of-Life Milestones and Dates for the Cisco Catalyst 8510 MSR, Catalyst 8540 MSR, and Cisco LightStream 1010

Milestone	Definition	Date
End-of-Life Announcement Date	The date the document that announces the end of sale and end of life of a product is distributed to the general public.	July 28, 2005
End-of-Sale Date	The last date to order the product through Cisco point-of-sale mechanisms. The product is no longer for sale after this date.	April 29, 2006
Last Ship Date	The last-possible ship date that can be requested of Cisco and/or its contract manufacturers. Actual ship date is dependent on lead time.	June 30, 2006
End of SW Maintenance Releases Date	The last date that Cisco Engineering may release any final software maintenance releases or bug fixes. After this date, Cisco Engineering will no longer develop, repair, maintain, or test the product software.	April 29, 2007
End of Routine Failure Analysis Date	The last-possible date a routine failure analysis may be performed to determine the cause of product failure or defect.	April 29, 2007
End of New Service Attachment Date	For equipment and software that is not covered by a service-and-support contract, this is the last date to order a new service-and-support contract or add the equipment and/or software to an existing service-and-support contract.	April 29, 2007
End of Service Contract Renewal Date	The last date to extend or renew a service contract for the product.	April 29, 2010
Last Date of Support	The last date to receive service and support for the product. After this date, all support services for the product are unavailable, and the product becomes obsolete.	April 29, 2011

Table 2. Product Part Numbers Affected by This Announcement

End-of-Sale Product Part Number	Product Description
Cisco Catalyst 8510 MSR Products
C8510-CHAS5	Catalyst 8510 Chassis
C8510-CHAS5=	Catalyst 8510 Chassis (spare)
C8510-PWR-AC	Catalyst 8510 AC Power Supply
C8510-PWR-AC=	Catalyst 8510 AC Power Supply (spare)
C8510-PWR-AC/2	Catalyst 8510 Redundant AC Power Supply
C8510-PWR-DC	Catalyst 8510 DC Power Supply
C8510-PWR-DC=	Catalyst 8510 DC Power Supply (spare)
C8510-PWR-DC/2	Catalyst 8510 Redundant DC Power Supply
C8510MSR-SKIT-AC	Catalyst 8510 MSR Starter Kit with AC Power
C8510MSR-SKIT-DC	Catalyst 8510 MSR Starter Kit with DC Power
C8515-MSRP	Catalyst 8510 MSR Switch Route Processor
C8515-MSRP=	Catalyst 8510 MSR Switch Route Processor (spare)
MEM-ASP-32M=	LightStream 1010 32 MB DRAM (spare)
MEM-ASP-64M	LightStream 1010 64 MB DRAM
MEM-ASP-64M=	LightStream 1010 64 MB DRAM (spare)
MEM-ASP-FLC16M=	Catalyst 8500/LightStream 1010 PCMCIA Flash Memory Card 16 MB (spare)
MEM-ASP-FLC20M=	Catalyst 8500/LightStream 1010 PCMCIA Flash Memory Card 20 MB (spare)
MEM-ASP-FLD48M=	Catalyst 8540 PC Flash Disk, 48 MB (spare)
C85GE-1X-16K	Catalyst 8510 1-Port Gigabit Ethernet (GE) 16K
C85GE-1X-16K=	Catalyst 8510 1-Port GE 16K (spare)
C85GE-1X-64K	Catalyst 8510 1-Port GE 64K
C85GE-1X-64K=	Catalyst 8510 1-Port GE 64K (spare)
C8510-ACL=	Catalyst 8510 Access Control List (ACL) (spare)
C85FE-8T-64K	Catalyst 8510 8-Port 10/100 RJ-45 64K
C85FE-8T-64K=	Catalyst 8510 8-Port 10/100 RJ-45 64K (spare)
C8510-ARM-64K	Catalyst 8510 ATM Router Module 64K
C8510-ARM-64K=	Catalyst 8510 ATM Router Module 64K (spare)
C8510-TSCAM-2P	Catalyst 8510/LightStream 1010 Traffic Shaping Carrier Access Module (CAM)
C8510-TSCAM-2P=	Catalyst 8510/LightStream 1010 Traffic Shaping CAM (spare)
WATM-CAM-2P	Catalyst 5500/LightStream 1010 CAM (installed)
WATM-CAM-2P=	Catalyst 5500/LightStream 1010 CAM (spare)
WATM-CAM-CVR=	Catalyst 5500/LightStream 1010 CAM Slot Cover (spare)
WAI-CVR=	Catalyst 8500/LightStream 1010 Port Adapter Module (PAM) Slot Cover (spare)
WAI-T1C-4RJ48	4-Port T1 (circuit emulation) RJ-48 PAM
WAI-T1C-4RJ48=	4-Port T1 (circuit emulation) RJ-48 PAM (spare)
WAI-E1C-4BNC	4-Port E1 (circuit emulation) BNC PAM
WAI-E1C-4BNC=	4-Port E1 (circuit emulation) BNC PAM (spare)
WAI-E1C-4RJ48	4-Port E1 (circuit emulation) RJ-48 PAM
WAI-E1C-4RJ48=	4-Port E1 (circuit emulation) RJ-48 PAM (spare)
C85MS-4E1-FRRJ48	Catalyst 8500 4-Port E1 Frame Relay PAM
C85MS-4E1-FRRJ48=	Catalyst 8500 4-Port E1 Frame Relay PAM (spare)
WAI-OC12-1SSLR	1-Port OC-12c/STM-4c single-mode fiber (SMF) long reach (LR) PAM
WAI-OC12-1SSLR=	1-Port OC-12c/STM-4c SMF LR PAM (spare)
WAI-OC12-1SS	1-Port OC-12c/STM-4c SMF intermediate reach (IR) PAM
WAI-OC12-1SS=	1-Port OC-12c/STM-4c SMF IR PAM (spare)
WAI-OC12-1MM	1-Port OC-12c/STM-4c multimode fiber (MMF) PAM
WAI-OC12-1MM=	1-Port OC-12c/STM-4c MMF PAM (spare)
WAI-OC3-4SSLR	4-Port OC-3c/STM-1 SMF LR PAM
WAI-OC3-4SSLR=	4-Port OC-3c/STM-1 SMF LR PAM (spare)
WAI-OC3-4SS	4-Port OC-3c/STM-1 SMF IR PAM
WAI-OC3-4SS=	4-Port OC-3c/STM-1 SMF IR PAM (spare)
WAI-OC3-1S3M	OC-3c/STM-1 Mix PAM, 1-Port SMF IR + 3-Port MMF
WAI-OC3-1S3M=	OC-3c/STM-1 Mix PAM, 1-Port SMF IR + 3-Port MMF (spare)
WAI-OC3-4MM	4-Port OC-3c/STM-1 MMF PAM
WAI-OC3-4MM=	4-Port OC-3c/STM-1 MMF PAM (spare)
WAI-T3-4BNC	4-Port DS-3 PAM
WAI-T3-4BNC=	4-Port DS-3 PAM (spare)
WAI-E3-4BNC	4-Port E3 BNC PAM
WAI-E3-4BNC=	4-Port E3 BNC PAM (spare)
C85MS-ATM25-4P	4-Port ATM 25 PAM - Catalyst 8510/LightStream 1010 only
C85MS-ATM25-4P=	4-Port ATM 25 PAM - Catalyst 8510/LightStream 1010 only (spare)
C85MS-8T1-IMA	Catalyst 8500 MSR/LightStream 1010 8-Port TI Inverse Multiplexing for ATM (IMA) PAM
C85MS-8T1-IMA=	Catalyst 8500 MSR/LightStream 1010 8-Port TI IMA PAM (spare)
C85MS-8E1-IMA-120	Catalyst 8500 MSR/LightStream 1010 8-Port E1 120 ohm IMA PAM
C85MS-8E1-IMA-120=	Catalyst 8500 MSR/LightStream 1010 8-Port E1 120 ohm IMA PAM (spare)
WAI-T1-4RJ48	4-Port T1 (ATM) RJ-48 PAM
WAI-T1-4RJ48=	4-Port T1 (ATM) RJ-48 PAM (spare)
WAI-E1-4RJ48	4-Port E1 (ATM) RJ-48 PAM
WAI-E1-4RJ48=	4-Port E1 (ATM) RJ-48 PAM (spare)
WAI-E1-4BNC	4-Port E1 (ATM) BNC PAM
WAI-E1-4BNC=	4-Port E1 (ATM) BNC PAM (spare)
C85-SLOT-CVR=	Catalyst 8500/LightStream 1010 Blank Line Card Slot Cover (spare)
Cisco Catalyst 8540 MSR Products
C8540-CHAS13	Catalyst 8540 Chassis
C8540-CHAS13=	Catalyst 8540 Chassis (spare)
C8540-PWR-AC	Catalyst 8540 AC Power Supply
C8540-PWR-AC=	Catalyst 8540 AC Power Supply (spare)
C8540-PWR-AC/2	Catalyst 8540 Redundant AC Power Supply
C8540-PWR-DC	Catalyst 8540 DC Power Supply
C8540-PWR-DC=	Catalyst 8540 DC Power Supply (spare)
C8540-PWR-DC/2	Catalyst 8540 Redundant DC Power Supply
C8540-FANTRAY=	Catalyst 8540 Fan Tray (spare)
C8540MSR-SKIT-AC	Catalyst 8540 MSR Starter Kit with Stratum 4 Clock Module - AC Power
C8540MSR-SKIT-DC	Catalyst 8540 MSR Starter Kit with Stratum 4 Clock Module - DC Power
C8545MSR-MRP4CLK	Catalyst 8540 MSR Multiservice Route Processor
C8545MSR-MRP4CLK=	Catalyst 8540 MSR Multiservice Route Processor (spare)
C8545MSR-MRP4CLK/2	Catalyst 8540 MSR Redundant Multiservice Route Processor (MRP)
C8545MSR-MRP3CLK	Catalyst 8540 MSR MRP Stratum 3
C8545MSR-MRP3CLK=	Catalyst 8540 MSR MRP Stratum 3 (spare)
C8545MSR-MRP3CLK/2	Catalyst 8540 Redundant MSR MRP Stratum 3
UPG-MSR-MRP-3CLK	Catalyst 8540 MSR - MRP Stratum 3 Clock Upgrade (starter kit only)
C8540-3CLK=	Catalyst 8540 Stratum 3 Clock Module (spare)
C8546MSR-MSP-FCL	Catalyst 8540 MSR Switch Processor with ATM FC
C8546MSR-MSP-FCL=	Catalyst 8540 MSR Switch Processor with ATM FC (spare)
C8546MSR-MSP-FCL/2	Catalyst 8540 Redundant MSR Switch Processor with ATM FC
C85-SIMM-16MB=	8- to 16-MB Flash Upgrade for the Catalyst 8500 Series (spare)
C85EGE-2X-64K	Catalyst 8540 2-Port Enhanced GE 64K
C85EGE-2X-64K=	Catalyst 8540 2-Port Enhanced GE 64K (spare)
C85EGE-2X-256K	Catalyst 8540 2-Port Enhanced GE 256K
C85EGE-2X-256K=	Catalyst 8540 2-Port Enhanced GE 256K (spare)
C85GE-8X-64K	Catalyst 8540 8-Port GE Module 64K
C85GE-8X-64K=	Catalyst 8540 8-Port GE Module 64K (spare)
C85FE-16TACL-64K	Catalyst 8540 16-port 10/100 RJ-45 with ACL 64K
C85FE-16TACL-64K=	Catalyst 8540 16-port 10/100 RJ-45 with ACL 64K (spare)
C8540-ACL=	Catalyst 8540 ACL Daughter Card (spare)
C8540-ARM2	Catalyst 8540 Enhanced ATM Router Module
C8540-ARM2=	Catalyst 8540 Enhanced ATM Router Module (spare)
C8540-ARM-64K	Catalyst 8540 ATM Router Module 64K
C8540-ARM-64K=	Catalyst 8540 ATM Router Module 64K (spare)
C85MS-2F-OC48SS	Catalyst 8540 2-Port OC-48c SMF IR
C85MS-2F-OC48SS=	Catalyst 8540 2-Port OC-48c SMF IR (spare)
C85MS-4F-OC12MM	Catalyst 8540 4-Port OC-12 MMF
C85MS-4F-OC12MM=	Catalyst 8540 4-Port OC-12 MMF (spare)
C85MS-4F-OC12SS	Catalyst 8540 MSR 4-Port OC-12 SMF IR (installed)
C85MS-4F-OC12SS=	Catalyst 8540 MSR 4-Port OC-12 SMF IR (spare)
C85MS-16F-OC3MM	Catalyst 8540 MSR 16-Port OC-3 MMF (installed)
C85MS-16F-OC3MM=	Catalyst 8540 MSR 16-Port OC-3 MMF (spare)
C85MS-16F-OC3SM	Catalyst 8540 MSR 16-Port OC-3 SMF LR
C85MS-16F-OC3SM=	Catalyst 8540 16-Port OC-3 SMF LR (spare)
C85MS-SCAM-2P	Catalyst 8540 SuperCAM for PAMs
C85MS-SCAM-2P=	Catalyst 8540 SuperCAM for PAMs (spare)
Cisco LightStream 1010 Products
L1010-CHAS5	LightStream 1010 Chassis
L1010-CHAS5=	LightStream 1010 Chassis (spare)
L1010-PWR-AC	LightStream 1010 AC Power Supply
L1010-PWR-AC=	LightStream 1010 AC Power Supply (spare)
L1010-PWR-AC/2	LightStream 1010 Redundant AC Power Supply
L1010-PWR-DC	LightStream 1010 DC Power Supply
L1010-PWR-DC=	LightStream 1010 DC Power Supply (spare)
L1010-PWR-DC/2	LightStream 1010 Redundant DC Power Supply
L1010-SKIT-AC	LightStream 1010 Starter Kit with AC Power
L1010-SKIT-DC	LightStream 1010 Starter Kit with DC Power
L1010-ASP-C-FC1	ATM Switch Processor with FC Per-Class Queuing (no memory)
L1010-ASP-C-FC1=	ATM Switch Processor with FC Per-Class Queuing (spare)
L1010-ASP-C-FCPFQ	ATM Switch Processor with FC Per-Flow Queuing (64K memory)
L1010-ASP-C-FCPFQ=	ATM Switch Processor with FC Per-Flow Queuing (spare)

Product Migration Options

For pure ATM switches and applications and for Circuit Emulation over ATM, customers are encouraged to migrate to the Cisco MGX® 8800 Series switches: http://www.cisco.com/en/US/products/hw/switches/ps1938/index.html.

For ATM and Ethernet switching, customers are encouraged to migrate to the Cisco Catalyst 4500 or Catalyst 6500 series switches:
http://www.cisco.com/en/US/products/hw/switches/ps4324/index.html or
http://www.cisco.com/en/US/products/hw/switches/ps708/index.html

For Circuit Emulation over IP, customers are encouraged to migrate to the Cisco 2600, 3600, or 3700 series routers:
http://www.cisco.com/en/US/products/hw/routers/ps259/index.html
http://www.cisco.com/en/US/products/hw/routers/ps274/index.html
http://www.cisco.com/en/US/products/hw/routers/ps282/index.html

Customers can use the Cisco Technology Migration Plan (TMP) to trade in products and receive credit toward the purchase of new Cisco equipment. For more information about Cisco TMP, go to: http://www.cisco.com/go/tradein/. The Cisco TMP application requires all users to have a Cisco.com user ID.

Customers may be able to continue to purchase the end-of-sale products through the Cisco Authorized Refurbished Equipment program. Refurbished units of the end-of-sale product are available in limited supply for sale in certain countries on a first-come, first-served basis. For information about the refurbished equipment program, go to: http://www.cisco.com/en/US/ordering/or6/or17/order_refurbished_equipment_program_description.html.

For More Information

For more information about the Cisco Catalyst 8510 MSR, Catalyst 8540 MSR, and Cisco LightStream 1010, visit: http://www.cisco.com/en/US/products/hw/switches/ps718/index.html or contact your local account representative or http://www.cisco.com.

For more information about the Cisco End-of-Life Policy, go to: http://www.cisco.com/en/US/products/prod_end_of_life.html.

To subscribe to receive end-of-life/end-of-sale information, go to: http://www.cisco.com/cgi-bin/Support/FieldNoticeTool/field-notice.
