Release Notes for Cisco Unity Express 2.3

February 20, 2007

Cisco Unity Express 2.3.4

Text Part Number OL-10392-04

These release notes support Cisco Unity Express 2.3 up to and including Cisco Unity Express 2.3.4. These release notes are updated as needed.

We recommend that you read the field notices for this release to see if your software or hardware platforms are affected. If you have an account on Cisco.com, you can find field notices at http://www.cisco.com/warp/customer/tech_tips/index/fn.html. If you do not have a Cisco.com login account, you can find field notices at http://www.cisco.com/warp/public/tech_tips/index/fn.html.

Table 1 describes the history of this Cisco Unity Express release.

Table 1 Cisco Unity Express 2.3 History

Cisco Unity Express Version
Released

2.3.1

May 1, 2006

2.3.2

July 28, 2006

2.3.3

December 22, 2006

2.3.4

February 20, 2007


Note The user documentation for Cisco Unity Express refers to this version as 2.3. The 2.3.4 release is the fourth released version for Cisco Unity Express 2.3.

Contents

These release notes contain the following sections:

•System Requirements

•New Features and Enhancements

•Important Notes

•Caveats

•Additional References

System Requirements

Hardware and software requirements for Cisco Unity Express 2.3 are in the following sections:

•Hardware Supported

•Files Included in Cisco Unity Express 2.3

•Software Licenses and Factory-Set Limits

•Software Upgrade Overview

•Software Compatibility

•Determining the Software Version and License

•Cisco Unity Express Language Support

Hardware Supported

Table 2 lists supported platforms and the minimum Cisco IOS release required to support Cisco Unity Express Network Modules (NM) and Advanced Integration Modules (AIM).

Table 2 Supported Platforms and Minimum Cisco IOS Release

Cisco Platform
Cisco Unity Express Network Module (NM-CUE)
Cisco Unity Express Network Module Extended Capacity (NM-CUE-EC)
Cisco Unity Express AIM-CUE 1

Cisco 2600XM

12.3(4)T

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(7)T

Cisco 2650XM,
Cisco 2651XM

12.3(4)T

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(7)T

Cisco 2691

12.3(4)T

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(7)T

Cisco 2801

Not Supported

Not Supported

12.3(8)T4

Cisco 2811, Cisco 2821, Cisco 2851

12.3(8)T4

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(8)T4

Cisco 3725, Cisco 3745

12.3(4)T

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(7)T

Cisco 3825, Cisco 3845

12.3(11)T

12.3(11)T5, 12.3(14)T1, 12.4(1)

12.3(11)T

1 Only the 1 GB AIM module is supported in release 2.3.


Files Included in Cisco Unity Express 2.3

Table 3 lists the files available in the Cisco Unity Express 2.3 release.

Table 3 Files Included in Cisco Unity Express Release 2.3

Filename
Description

cue-vm.2.3.4.pkg1

The main software package file

cue-installer.2.3.4

Helper installer

cue-vm-installer.2.3.4.prt1

Installer payload file

cue-vm-full.2.3.4.prt1

VoiceMail application

CUEEditor2.3.4.exe

Installer for the Script Editor

Language Packages

cue-vm-lang-pack.2.3.4.pkg1

Language package file

cue-vm-upgrade.2.2.2_2.3.4.prt1

Language prompts upgrade package file from release 2.2.2

cue-vm-en_US-lang-pack.2.3.4.prt1

English (US) language prompts

cue-vm-en_US-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-zh_CN-lang-pack.2.3.4.prt1

Chinese language prompts

cue-vm-zh_CN-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-da_DK-lang-pack.2.3.4.prt1

Danish language prompts

cue-vm-da_DK-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-en_GB-lang-pack.2.3.4.prt1

British English (UK) language prompts

cue-vm-en_GB-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-fr_FR-lang-pack.2.3.4.prt1

French (European) language prompts

cue-vm-fr_FR-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-fr_CA-upg-lang-pack.2.3.4

French (Canada) language prompts

cue-vm-fr_CA-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-de_DE-lang-pack.2.3.4.prt1

German (European) language prompts

cue-vm-de_DE-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-it_IT-lang-pack.2.3.4.prt1

Italian language prompts

cue-vm-it_IT-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-ja_JP-lang-pack.2.3.4.prt1

Japanese language prompts

cue-vm-ja_JP-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-ko_KR-lang-pack.2.3.4.prt1

Korean language prompts

cue-vm-ko_KR-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-pt_BR-lang-pack.2.3.4.prt1

Portuguese (Brazilian) language prompts

cue-vm-pt_BR-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-es_ES-lang-pack.2.3.4.prt1

Spanish (European) language prompts

cue-vm-es_ES-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-es_CO-lang-pack.2.3.4.prt1

Spanish (Latin American) language prompts

cue-vm-es_CO-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

cue-vm-es_MX-lang-pack.2.3.4.prt1

Spanish (Mexico) language prompts

cue-vm-es_MX-upg-lang-pack.2.2.2_2.3.4.prt1

Upgrade package from release 2.2.2

License Packages for Cisco Unified CallManager

cue-vm-license_12mbx_ccm_2.3.4.pkg

License 12 mailbox

cue-vm-license_25mbx_ccm_2.3.4.pkg

License 25 mailbox

cue-vm-license_50mbx_ccm_2.3.4.pkg

License 50 mailbox

cue-vm-license_100mbx_ccm_2.3.4.pkg

License 100 mailbox

cue-vm-license_150mbx_ccm_2.3.4.pkg

License 150 mailbox

cue-vm-license_200mbx_ccm_2.3.4.pkg

License 200 mailbox

cue-vm-license_250mbx_ccm_2.3.4.pkg

License 250 mailbox

License Packages for Cisco Unified CallManager Express

cue-vm-license_12mbx_cme_2.3.4.pkg

License 12 mailbox

cue-vm-license_25mbx_cme_2.3.4.pkg

License 25 mailbox

cue-vm-license_50mbx_cme_2.3.4.pkg

License 50 mailbox

cue-vm-license_100mbx_cme_2.3.4.pkg

License 100 mailbox

cue-vm-license_150mbx_cme_2.3.4.pkg

License 150 mailbox

cue-vm-license_200mbx_cme_2.3.4.pkg

License 200 mailbox

cue-vm-license_250mbx_cme_2.3.4.pkg

License 250 mailbox

1 Required to upgrade the software using the online installer.


Software Licenses and Factory-Set Limits

Different license levels are available for Cisco Unity Express software for the network module or the AIM and for Cisco Unified CallManager or Cisco Unified CallManager Express. To download Cisco Unity Express software licenses, you must have an account on Cisco.com. In Cisco.com, go to the Software Center for Cisco Unity Express at:

http://www.cisco.com/cgi-bin/tablebuild.pl?topic=278535672

The following Cisco Unity Express licenses are available for Cisco Unity Express 2.3:

Table 4 Cisco Unity Express Network Module

Cisco Unity Express Network Module

Cisco Unified CallManager:

•SCUE-LIC-200CCM-2.3.x

•SCUE-LIC-250CCM-2.3.x

•SCUE-LIC-25CCM-2.3.x

•SCUE-LIC-100CCM-2.3.x

•SCUE-LIC-12CCM-2.3.x

•SCUE-LIC-50CCM-2.3.x

•SCUE-LIC-150CCM-2.3.x

Cisco Unified CallManager Express

•SCUE-LIC-12CME-2.3.x

•SCUE-LIC-25CME-2.3.x

•SCUE-LIC-50CME-2.3.x

•SCUE-LIC-100CME-2.3.x

•SCUE-LIC-150CME-2.3.x

•SCUE-LIC-200CME-2.3.x

•SCUE-LIC-250CME-2.3.x

Cisco Unity Express AIM

Cisco Unified CallManager

•SCUE-LIC-12CCM-2.3.x

•SCUE-LIC-25CCM-2.3.x

•SCUE-LIC-50CCM-2.3.x

Cisco Unified CallManager Express

•SCUE-LIC-12CME-2.3.x

•SCUE-LIC-25CME-2.3.x

•SCUE-LIC-50CME-2.3.x


Note Before release 4.0, Cisco Unified CallManager was known as Cisco CallManager.

Factory-set system limits are determined by the ordered license. Limits for the NM-CUE-EC are shown in Table 5 and Table 6. Limits for the NM-CUE are shown in Table 7 and Table 8. Limits for the 1 GB AIM-CUE are shown in Table 9 and Table 10.

Table 5 NM-CUE-EC System Capacities for Mailboxes, Storage Hours, Ports, Scripts, and Prompts

Cisco Unity Express License/Software SKU
Total Mailbox Storage (Hours)
Default Mailbox Size (Sec)1
No. of Concurrent Voice Mail and
Auto Attendant Ports/Sessions
No.of Scripts
No.of Prompts
No. of Public Distribution Lists
No. of Triggers

SCUE-LIC-12CCM
SCUE-LIC-12CME

300

63529

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-25CCM
SCUE-LIC-25CME

300

36000

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-50CCM
SCUE-LIC-50CME

300

16115

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-100CCM
SCUE-LIC-100CME

300

9600

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-150CCM
SCUE-LIC-150CME

300

6171

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-200CCM
SCUE-LIC-200CME

300

4800

16

8

120

25

8 SIP
8 JTAPI

SCUE-LIC-250CCM
SCUE-LIC-250CME

300

3297

16

8

120

25

8 SIP
8 JTAPI

1 The default mailbox size calculation includes the allocation for the General Delivery Mailboxes (GDMs).


Table 6 NM-CUE-EC Maximum Number of Mailboxes, Users, Groups, Owners, and Members

Cisco Unity Express License/Software SKU
Default Number of Personal Mailboxes
Default Number of General Delivery Mailboxes
Total
Number of
Mailboxes
Number of Users
Number of Groups
Number of Owners
Number of Members

SCUE-LIC-12CCM
SCUE-LIC-12CME

12

5

17

24

20

400

880

SCUE-LIC-25CCM
SCUE-LIC-25CME

25

10

35

50

20

400

1000

SCUE-LIC-50CCM
SCUE-LIC-50CME

50

15

65

100

30

400

1000

SCUE-LIC-100CCM
SCUE-LIC-100CME

100

20

120

200

40

400

1000

SCUE-LIC-150CCM
SCUE-LIC-150CME

150

25

175

300

40

400

1000

SCUE-LIC-200CCM
SCUE-LIC-200CME

200

25

225

300

40

400

1000

SCUE-LIC-250CCM
SCUE-LIC-250CME

250

25

275

300

40

400

1000


Table 7 NM-CUE System Capacities for Mailboxes, Storage Hours, Ports, Scripts, and Prompts

Cisco Unity Express License/Software SKU
Total Mailbox Storage (Hours)
Default Mailbox Size (Sec)1
No. of Concurrent Voice Mail and
Auto Attendant Ports/Sessions
No. of Scripts
No. of Prompts
No. of Public Distribution Lists
No. of Triggers

SCUE-LIC-12CCM
SCUE-LIC-12CME

100

21120

8

8

120

15

8 SIP
8 JTAPI

SCUE-LIC-25CCM
SCUE-LIC-25CME

100

10260

8

8

120

15

8 SIP
8 JTAPI

SCUE-LIC-50CCM
SCUE-LIC-50CME

100

5520

8

8

120

15

8 SIP
8 JTAPI

SCUE-LIC-100CCM
SCUE-LIC-100CME

100

3000

8

8

120

15

8 SIP
8 JTAPI

1 The default mailbox size calculation includes the allocation for the General Delivery Mailboxes (GDMs).


Table 8 NM-CUE Maximum Number of Mailboxes, Users, Groups, Owners, and Members

Cisco Unity Express License/Software SKU
Default Number of Personal Mailboxes
Default Number of General Delivery Mailboxes
Total
Number of
Mailboxes
Number of Users
Number of Groups
Number of Owners
Number of Members

SCUE-LIC-12CCM
SCUE-LIC-12CME

12

5

17

24

20

400

880

SCUE-LIC-25CCM
SCUE-LIC-25CME

25

10

35

50

20

400

1000

SCUE-LIC-50CCM
SCUE-LIC-50CME

50

15

65

100

30

400

1000

SCUE-LIC-100CCM
SCUE-LIC-100CME

100

20

120

200

40

400

1000


Table 9 1-GB AIM-CUE System Capacities for Mailboxes, Storage Hours, Ports, Scripts, and Prompts

Cisco Unity Express License/Software SKU
Total Mailbox Storage (Hours)1
Default Mailbox Size (Sec)2
No. of Concurrent Voice Mail and
Auto Attendant Ports/Sessions
No. of Scripts
No. of Prompts
No. of Public Distribution Lists
No. of Triggers

SCUE-LIC-12CCM
SCUE-LIC-12CME

14

2700

4 (Cisco 2600XM, Cisco 2691)
6 (Cisco 2800 series, Cisco 3700 series,
   Cisco 3800 series)

4

25

15

8 SIP
8 JTAPI

SCUE-LIC-25CCM
SCUE-LIC-25CME

14

1320

4 (Cisco 2600XM, Cisco 2691)
6 (Cisco 2800 series, Cisco 3700 series,
   Cisco 3800 series)

4

25

15

8 SIP
8 JTAPI

SCUE-LIC-50CCM
SCUE-LIC-50CME

14

720

4 (Cisco 2600XM, Cisco 2691)
6 (Cisco 2800 series, Cisco 3700 series,
   Cisco 3800 series)

4

25

15

8 SIP
8 JTAPI

1 Cisco Unity Express 2.3 does not support the 512-MB AIM.

2 The default mailbox size calculation includes the allocation for the General Delivery Mailboxes (GDMs).


Table 10 1-GB AIM-CUE Maximum Number of Mailboxes, Groups, Owners, and Members

Cisco Unity Express License/Software SKU
Default Number of Personal Mailboxes
Default Number of General Delivery Mailboxes
Total Number of Mailboxes
Number of Users
Number of Groups
Number of Owners
Number of Members

SCUE-LIC-12CCM
SCUE-LIC-12CME

12

5

17

24

20

100

200

SCUE-LIC-25CCM
SCUE-LIC-25CME

25

10

35

50

20

100

200

SCUE-LIC-50CCM
SCUE-LIC-50CME

50

15

65

100

20

100

200


Software Upgrade Overview

Depending on the Cisco Unity Express version you are upgrading from, different software upgrade methods are available. The following methods are supported to upgrade to Cisco Unity Express 2.3:

•Upgrade using the online installer with the software install upgrade command. For specific procedures, see the Upgrading an Existing Software Image section in the Cisco Unity Express 2.3 Installation and Upgrade Guide.

This method is designated as Process "A" in Table 11.

•A "clean" installation process upgrade using the online installer with the software install clean command. For specific procedures, see the Upgrading an Existing Software Image section in the Cisco Unity Express 2.3 Installation and Upgrade Guide.

This method is designated as Process "B" in Table 11.

•A "clean" installation process upgrade using the boot helper. For specific procedures, see the Upgrading an Existing Software Image section in the Cisco Unity Express 2.3 Installation and Upgrade Guide.

This method is designated as Process "C" in Table 11.

Table 11 provides a matrix of the upgrade processes available for the different software releases using the following conventions:

•A = Upgrade Using Online Installer

•B = "Clean" Installation Upgrade Using Online Installer

•C = "Clean" Installation Upgrade Using Boot Helper. For software upgrades where other upgrade options are available, Cisco recommends using this upgrade process only if the other methods are unsuccessful.

Caution If you upgrade using either of the "clean" installation processes, the existing configuration files on the system are not preserved. Any voice mail, greetings or passwords configured on the system are lost.

To preserve your configuration, you must first back up the existing configuration files and restore them after performing the upgrade. If the configuration files are not backed up before performing the upgrade, then Cisco Unity Express must be reconfigured.

Table 11 Cisco Unity Express Software Upgrade Process Matrix

Upgrade From:
To:
2.3.4
2.3.3
2.3.2
2.3.1
2.2.2
2.2.1
2.1.3
2.1.2
2.1.1
2.0.2
2.0.1

2.3.3

B, C



2.3.2

B, C

B, C

—

—

—

—

—

—

—

—

—

2.3.1

B, C

B, C

B, C

—

—

—

—

—

—

—

—

2.2.2

A, B, C

A, B, C

A, B, C

B, C

—

—

—

—

—

—

—

2.2.1

B, C

B, C

B, C

B, C

B, C

—

—

—

—

—

—

2.1.3

B, C

B, C

B, C

B, C

B, C

A, B, C

—

—

—

—

—

2.1.2

B, C

B, C

B, C

B, C

B, C

B, C

A, B, C

—

—

—

—

2.1.1

B, C

B, C

B, C

B, C

B, C

B, C

B, C

A, B, C

—

—

—

2.0.2

B, C

B, C

B, C

B, C

B, C

B, C

B, C

B, C

B, C

—

—

2.0.1

B, C

B, C

B, C

B, C

B, C

B, C

B, C

B, C

B, C

B, C

—

1.1.2

B, C

B, C

B, C

B, C

B, C

B, C

C

C

C

C

C


When planning your software upgrade, consider the following:

•If you upgrade the software using the online installer, downgrading to an earlier software version is currently not supported.

•If a non-2.3.x license is installed, several null node name error messages are shown on the console display after Populating internal database.... during the bootup sequence. This can be resolved by installing a 2.3.2 version license. This is benign and can be safely ignored. The new licenses only fix the display error. Also, 2.3.x licenses are backward compatible with 2.1.3.

•When you upgrade, make sure to upgrade to the same type of license. For example, if you are running the license SCUE-LIC-50CME, make sure to upgrade to another SCUE-LIC-xxCME license. You can upgrade to a license that offers support for more personal mailboxes. To increase your mailbox license, you must purchase a new license.

•If your system is using an AIM-CUE module with 512 MB compact flash, you must upgrade to the AIM-CUE module with 1 GB compact flash before upgrading the software to
Cisco Unity Express 2.3.

•The online installer is not available on the AIM-CUE module with 512 MB compact flash.

•Downgrading to a license with support for fewer personal mailboxes is not supported. If you want to change the system to support fewer mailboxes, and you cannot restore any previous backups on the larger system, then you must purchase a new license and perform a new installation.

•If you are upgrading from a previous release with non-U.S. English audio prompts installed, you cannot upgrade to Cisco Unity Express 2.3.1, since these languages were not supported in that release. However, you can upgrade to Cisco Unity Express 2.3.2 or 2.3.3 and the languages will be supported.

Software Compatibility

Cisco Unity Express compatibility with other software application versions is described in the following sections:

•Cisco Unity Express Compatibility with Cisco Unified CallManager

•Cisco Unity Express Compatibility with Cisco Unified CallManager Express

•Voice Messaging Networking between Systems

Cisco Unity Express Compatibility with Cisco Unified CallManager

Table 12 lists the Cisco Unified CallManager software versions that are compatible with supported versions of Cisco Unity Express for Cisco Unity Express software licenses with the format SCUE-LIC-xxCCM.

Note Beginning with Release 5.0, Cisco Unified CallManager is known as Cisco Unified Communications Manager.

Table 12

Cisco Unity Express Supported Releases
Compatible Cisco Unified CallManager Releases1

2.3.3
2.3.4

4.1(2)
4.1(3)
4.2(1)
4.2(3)
5.0(1)
5.0(2)
5.0(3)
5.0(4)
5.1(1)
5.1(2)

2.3.1
2.3.2

4.1(2)
4.1(3)
4.2(1)
4.2(3)
5.0(1)
5.0(2)
5.0(3)
5.0(4)

2.2.1
2.2.2

3.3(3)
3.3(4)
4.0(1)
4.0(2)
4.1(2)
4.1(3)

2.1.3
2.1.2
2.1.1

3.3(3)
3.3(4)
4.1(3)
4.0(1)
4.0(2)
4.1(3)
4.1(2)
4.1(3)

2.0.2
2.0.1

3.3(3)
3.3(4)
4.0(1),
4.0(2)

1.1.2

3.3(3)
3.3(4)

1 Before Release 4.0, Cisco Unified CallManager was known as Cisco CallManager.


Cisco Unity Express Compatibility with Cisco Unified CallManager

Caution Cisco Unity Express 2.3.x does not support versions of Cisco Unified CallManager prior to release 4.1(2). If you are using an earlier version of Cisco Unified CallManager, then you must upgrade to release 4.1(2) or higher to interoperate with Cisco Unity Express 2.3.x.

Cisco Unity Express Compatibility with Cisco Unified CallManager Express

Table 13 lists the Cisco Unity Express releases that are compatible with different versions of Cisco Unified CallManager Express for Cisco Unity Express software licenses with the format SCUE-LIC-xxCME.

Note Beginning with Release 4.1, Cisco Unified CallManager Express is known as Cisco Unified Communications Manager Express.

Table 13

Cisco Unity Express Supported Version
Compatible
Cisco Unified CallManager Express Versions1
Minimum Cisco IOS Release Required for
Cisco Unified CallManager Express Version

2.3.1
2.3.2
2.3.3
2.3.4

3.2

12.3(11)T

3.2.1

12.3(11)XL

3.2.2

12.3(11)XL1

3.3

12.3(14)T

3.4

12.4(4)T

4.0

12.4(4)XC and 12.4(9)T

4.0.1

12.4(4)XC1

4.0.2

12.4(4)XC2

4.0.3

12.4(6)XE and 12.4(11)T

4.1

12.4(11)XJ , 12.4(15)T



4.2

12.4(11)XW2

2.2.1
2.2.2

3.0

12.3(4)T

3.1

12.3(7)T

3.2

12.3(11)T

3.2.1

12.3(11)XL

3.2.2

12.3(11)XL1

3.3

12.3(14)T

4.0

12.4(4)XC and 12.4(9)T

2.1.3
2.1.2
2.1.1

3.0

12.3(4)T

3.1

12.3(7)T

3.2

12.3(11)T

3.2.1

12.3(11)XL

3.2.2

12.3(11)XL1

2.0.2
2.0.1

3.0

12.3(4)T

3.1

12.3(7)T

3.2

12.3(11)T

3.2.1

12.3(11)XL

3.2.2

12.3(11)XL1

1.1.2

3.0

12.3(4)T

3.1

12.3(7)T

3.2

12.3(11)T

3.2.1

12.3(11)XL

3.2.2

12.3(11)XL1

1 Before Release 4.0, Cisco Unified CallManager Express was known as Cisco CallManager Express.


Cisco Unity Express Compatibility with Cisco CallManager Express

Voice Messaging Networking between Systems

Cisco Unity Express can be deployed in a networked environment with other Cisco Unity Express or Cisco Unity systems. Table 14 identifies the software version requirements for this functionality.

Table 14

Cisco Unity Express Version
Compatible Cisco Unity Versions1

2.3.1
2.3.2
2.3.3
2.3.4

4.0(5) and higher

2.2.1
2.2.2

4.0(4) and higher

2.1.3
2.1.2
2.1.1

4.0(4) and higher

2.0.2
2.0.1

4.0(3), 4.0(4)

1.1.2

--

1 Cisco Unity versions shown in bold indicate releases that provide Cisco Unity Voice Profile for Internet Messaging (VPIM) message interoperability with the corresponding Cisco Unity Express release.


Cisco Unity Express Compatibility

Determining the Software Version and License

Note Bootloader is reported as 2.0.0 on the bootloader screen, but the show software versions command reports it as 2.1.2.

To determine the software version of Cisco Unity Express and the license being used, perform the following steps.

Step 1 Open a Telnet session.

Step 2 Telnet to the router by entering telnet ip-address.

Step 3 Enter the user ID and password of the router.

Step 4 Enter the following command to enter the Cisco Unity Express command environment:

enable

<router password>

service-module service-engine slot/port session

Step 5 Enter Cisco Unity Express EXEC mode by entering the following command:

enable

Step 6 Enter the following command to display the Cisco Unity Express software version:

show software versions

Step 7 Enter the following command to display the Cisco Unity Express software license:

show software licenses

Cisco Unity Express Language Support

Cisco Unity Express 2.3 supports different languages for the telephony user interface and the VoiceView Express user interface. The GUI pages, CLI commands and the IMAP interface are only available in English.

One language can be installed on the system at one time. Table 15 lists the languages that are supported, and the minimum Cisco Unity Express release required.

Note In Cisco Unity Express release 2.3.1, only United States English was supported.

Table 15 Cisco Unity Express 2.3 Language Support

Language
Minimum Cisco Unity Express
Release Required

English (United States)

1.0.0

Chinese (Mandarin)

2.3.3

Danish

2.1.3

English (United Kingdom)

2.1.3

French (Europe)

2.0.1

French (Canada)

2.3.2

German

2.0.1

Italian

2.1.3

Japanese

2.3.3

Korean

2.3.3

Portuguese (Brazil)

2.1.3

Spanish (Europe)

2.0.1

Spanish (Latin America)

2.1.3

Spanish (Mexico)

2.3.2


New Features and Enhancements

The following sections describe new features and enhancements:

•New Features and Enhancements in Cisco Unity Express 2.3.4

•New Features and Enhancements in Cisco Unity Express 2.3.3

•New Features and Enhancements in Cisco Unity Express 2.3.2

•New Features and Enhancements in Cisco Unity Express 2.3.1

New Features and Enhancements in Cisco Unity Express 2.3.4

Cisco Unity Express 2.3.4 introduces support for the following enhancement:

•The Cisco Unity Express voicemail system has been updated to support the date changes in United States timezone Daylight Saving Time that take effect in March, 2007. These timezone changes were mandated by the U.S. Energy Policy Act of 2005.

New Features and Enhancements in Cisco Unity Express 2.3.3

Cisco Unity Express 2.3.3 introduces support for the following enhancements:

•New language support:

Chinese (Mandarin)

Korean

Japanese

New Features and Enhancements in Cisco Unity Express 2.3.2

Cisco Unity Express 2.3.2 introduces support for the following enhancements:

•New language support:

French (Canada)

Spanish (Mexico)

Note Cisco Unity Express 2.3.2 also provides support for languages that were not available in version 2.3.1.

New Features and Enhancements in Cisco Unity Express 2.3.1

Cisco Unity Express 2.3.1 introduces support for the following enhancements:

•Increased system capacity on the NM-CUE-EC—The NM-CUE-EC supports custom prompts, increased number of mailboxes, increased number of remote and cached users, larger storage capacity, and an increased number of public distribution lists.

•Integrated Messaging—Cisco Unity Express end-users can access and manage their voice messages and e-mail using an e-mail client. This feature is only supported on the NM-CUE and NM-CUE-EC.

•Message Notification—Cisco Unity Express can notify end-users of new voice messages on their cell phone, home phone, work phone, numeric pager, text pager, and/or e-mail.

•VoiceView Express—Cisco Unity Express end users can browse, listen, manage, and create their voice messages and manage their mailbox options from their Cisco IP phone. Only Cisco IP phones 7940, 7941, 7960, 7961, 7970, and 7971 support VoiceView Express. This feature is only supported on the NM-CUE and NM-CUE-EC.

VoiceView Express does not support Korean and Chinese when the CUE is working with CME.

•Future message delivery—End-users can schedule messages to be delivered at a future time to users on local or remote systems.

•Local broadcast privilege—End-users with this privilege can send broadcast messages only to other end-users on the local system.

•Mailbox selection—This configurable option specifies the mailbox to be used in case of call forward. SIP phones are not supported.

•Voice mailbox mask—Cisco Unity Express supports Voice Mailbox Mask when integrated with
Cisco Unified CallManager 4.2(x). The feature must be configured on Cisco Unified CallManager.

•Consulting call transfers—Cisco Unity Express permits attended and semi-attended call transfer modes in addition to blind transfers.

•DTMF signal transfers—This feature handles incoming and outgoing DTMF signals for SIP calls from
Cisco Unified CallManager Express, Cisco Unified CallManager, and Cisco SRST mode.

•MWI Notifications in SRST mode—Cisco Unity Express includes the MWI status update capability to Cisco Unified CallManager and SRST mode.

•Mandatory message expiry—This feature forces the subscriber to delete messages when they expire.

•Cisco Unity Express Script Editor enhancements—Enhanced debugging procedures and two new steps are available.

•Cisco Unity Express GUI enhancements—New configuration screens and options are available through the Cisco Unity Express GUI. These new options parallel most of the new CLI commands.

•AvT enhancements—Capability to rerecord existing prompts and status of the alternate greeting are new capabilities for the AvT.

•Cisco Unified CallManager Support—Cisco Unity Express supports Cisco Unified CallManager 4.2, Cisco Unified CallManager 5.0, and the new JTAPI introduced in the 5.0 release.

New CLI Commands

The following sections describe new CLI commands:

•New CLI Commands in Cisco Unity Express 2.3.3

•New CLI Commands in Cisco Unity Express 2.3.3

•New CLI Commands in Cisco Unity Express 2.3.1

For more information on CLI commands, see the Cisco Unity Express 2.3 Command Reference.

New CLI Commands in Cisco Unity Express 2.3.4

No new CLI commands have been added in Cisco Unity Express 2.3.4.

New CLI Commands in Cisco Unity Express 2.3.3

No new CLI commands have been added in Cisco Unity Express 2.3.3.

New CLI Commands in Cisco Unity Express 2.3.2

The following CLI commands have been added in Cisco Unity Express 2.3.2:

•show voicemail configuration

•voicemail configuration outgoing-email from-address

New CLI Commands in Cisco Unity Express 2.3.1

The following CLI commands have been added in Cisco Unity Express 2.3.1:

•crypto key default

•crypto key delete

•crypto key generate

•crypto key import

•dtmf-relay

•enable (IMAP)

•enable (VoiceView Express)

•fallback-url

•groupname profile cell-phone

•groupname profile email

•groupname profile home-phone

•groupname profile num-pager

•groupname profile text-pager

•groupname profile work-phone

•maxsessions (IMAP)

•mwi sip

•protocol

•restriction msg-notification dial-string

•restriction msg-notification max-digits

•restriction msg-notification min-digits

•service imap

•service phone-authentication

•service voiceview

•service voiceview session terminate

•session idletimeout (IMAP)

•session idletimeout (VoiceView Express)

•session security

•show ccn sip subscription mwi

•show crypto key

•show group profiles

•show imap configuration

•show imap sessions

•show phone-authentication configuration

•show smtp server

•show user profiles

•show voicemail configuration
