Release Notes for Cisco SIP IP Phone 7940/7960 Release 7.0

---

June 22, 2004

Contents

This document lists the known problems in Cisco Session Initiation Protocol (SIP) IP Phone 7940/7960 Release 7.0 and contains information about the Cisco SIP IP Phone 7940/7960 (hereafter referred to as the Cisco SIP IP phone) that is not included in the most recent release of the phone documentation.

This document includes the following sections:

•Contents

•New and Changed Information

•Installation Notes

•Caveats

•Related Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

New and Changed Information

New Software Features in Release 7.0

The following new software features are supported in Cisco IP Phone 7940/7960 Release 7.0.

Memory Storage

A new design approach is used to store the existing software base in the Cisco 7940 and Cisco 7960 telephones. The new approach utilizes a "run from flash" design to use the Flash and RAM memory available more efficiently.

Installation Notes

For Cisco SIP IP phones, follow the instructions in the "Upgrading the Cisco SIP IP Phone Firmware" section at the following URL:

http://www.cisco.com/univercd/cc/td/doc/product/voice/c_ipphon/english/ipp7960/addprot/mgcp/frmwrup.htm

For these instructions, use P0S3-07-0-00.sbn as the image name for Release 7.0. You can find the current images at the following URL:

http://www.cisco.com/cgi-bin/tablebuild.pl/sip-ip-phone7960

Caveats

Open Caveats—Release 7.0

No open caveats are in Cisco IP Phone 7940/7960 Release 7.0 that require documentation in these release notes.

Resolved Caveats—Release 7.0

All caveats listed in this section are resolved in Cisco IP Phone 7940/7960 Release 7.0. This section lists only severity 1 and 2 caveats and select severity 3 caveats.

•CSCea72385: Timer registration prior to expiration

•CSCea88169: Headset is active when call is made from handset

•CSCeb18853: SIPPhone:Ringer should have 32 volume setting and is loud

•CSCeb50035: Phone loses sidetone with g711ulaw codec during call hold

•CSCeb58123: SIPPhone: Multiple Hold/Resumes cause no media and display issues

•CSCeb62783: SipPhone: Phone does not handle non-std Alert-Info headers from BTS

•CSCeb67452: Multiple calls with different codecs cause crash

•CSCeb70854: Phone loses voice path with g711ulaw

•CSCeb71065: Stress crash from MGCP

•CSCeb73808: Crash after multiple X-fer during basic call

•CSCeb75975: SIPPhone: Phone crashes upon any menu exit (Settings, Services, etc)

•CSCeb78620: SIPPhone: Fast digit dial causes digits to not be processed

•CSCeb86102: SIPPhone: Alternate TFTP gets overwritten from Yes to No

•CSCec04268: Customer complaints about digits sounding bad

•CSCec04676: SIP Phone crashes when the command Reg 0 1 is used

•CSCec25740: Rx path is going away when making a basic call

•CSCec45286: SIPPhone: ICMP Unreachable infinite loop

•CSCec59953: SIPPhone: DNS SRV memory leak

•CSCec65603: Changing network config causes memory leak

•CSCec65624: Phone crashes after bugtrap 0x18

•CSCec72091: SIPPhone: DOS attack crashes phone

•CSCed13693: Add GARP Disable Option

•CSCed69788: SIPPhone: INVITE w/o media line in SDP causes phone hang/reboot

•CSCed81406: SIPPhone: G729 calls send RFC2833 packets and voice packets at 10ms

•CSCed87306: Wrong SDP message for a G711 codec negotiation

•CSCed88935: SIP: Issues with IP UDP Fragmentation of Larger SIP Messages

Related Documentation

•Cisco SIP IP Phone Administrator Guide, Release 7.0

•Cisco IP Phone 7960/7940 Series - Quick Reference

•Regulatory Compliance and Safety Information for the Cisco IP Phone 7960, 7940, and 7910 Series

•Installing the Wall Mount Kit for the Cisco IP Phone
