Release Notes for Cisco SIP IP Phone 7940/7960 Release 4.2
June 22, 2004
Contents
This document lists the known problems in Cisco Session Initiation Protocol (SIP) IP Phone 7940/7960 Release 4.2 and contains information about the Cisco SIP IP Phone 7940/7960 (hereafter referred to as the Cisco SIP IP phone) that is not included in the most recent release of the phone documentation.
This document includes the following sections:
•
Obtaining Technical Assistance
New and Changed Information
New Software Features in Release 4.2
The following new software features are supported in Cisco IP Phone 7940/7960 Release 4.2.
UDP Fragmentation Support
The Cisco SIP IP phone supports User Datagram Protocol (UDP) fragmentation, which allows the phone to transmit and receive fragmented UDP packets up to 1932 bytes for use in conjunction with SIP messages.
Backup Proxy Registration to Support SIP-SRST
The SIP phone can register with a backup proxy to support Survivable Remote Site Telephony (SRST). If the main proxy goes down, the backup proxy has the registration information required to route calls successfully.
DNS SRV Support for Outbound Proxy
The SIP phone supports DNS SRV for outbound proxy configuration.
Locking Configuration Mode / Unlocking Configuration Mode
The method for locking and unlocking the configuration changes with Release 4.2 from previous releases.
For more information on the new procedure, refer to the section "Modifying the Network Settings" in the document, Managing Cisco SIP IP Phones.
Multiple Product Vulnerabilities Found by PROTOS SIP Test Suite
Multiple Cisco products contain vulnerabilities in the processing of Session Initiation Protocol (SIP) INVITE messages. These vulnerabilities were identified by the University of Oulu Secure Programming Group (OUSPG) "PROTOS" Test Suite for SIP and can be repeatedly exploited to produce a denial of service.
This vulnerability is repaired in Cisco IP Phone SIP Images P0S3-04-2-00 and later.
For more information, refer to the document at the following URL:
http://www.cisco.com/warp/public/707/cisco-sa-20030221-protos.shtml
Installation Notes
For Cisco SIP IP phones, follow the instructions in the "Upgrading the Cisco SIP IP Phone Firmware" section at the following URL:
http://www.cisco.com/univercd/cc/td/doc/product/voice/c_ipphon/sip7960/sadmin31/sipmntn.htm
For these instructions, use P0S3-04-2-00.bin as the image name for Release 4.2.
Caveats
Open Caveats—Release 4.2
This section documents possible unexpected behavior by Cisco IP Phone 7940/7960 Release 4.2 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
•
•
Resolved Caveats—Release 4.2
All the caveats listed in this section are resolved in Cisco IP Phone 7940/7960 Release 4.2. This section lists only severity 1 and 2 caveats and select severity 3 caveats.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
