Release Notes for Catalyst 6000 Family Module ROMMON Release 6.3(1)

---

Current Release: 6.3(1)—July 31, 2001

ROMMON release 6.3(1) is supported on Catalyst 6000 family modules installed in systems using Supervisor Engine 2.

The Supervisor Engine 2 houses two separate CPUs. One CPU applies to the supervisor engine and the other applies to the modules. ROMMON release 6.3(1) applies to the CPU that is housed on the Catalyst 6000 family modules and to the CPU housed on the Supervisor Engine 2 that applies to the modules.

This publication provides the procedure for downloading the new ROMMON image from Cisco.com and upgrading the ROMMON on your Catalyst 6000 family modules.

---

Note Upgrading the ROMMON on a Catalyst 6000 family module requires supervisor engine software release 6.3(1) or later. Earlier supervisor engine software releases do not support this method of upgrading the ROMMON version on a Catalyst 6000 module.

---

Contents

This publication consists of these sections:

•ROMMON Images

•Upgrading the Catalyst 6000 Family Module ROMMON

•Additional Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

ROMMON Images

Table 1 lists the versions for the Catalyst 6000 family module ROMMON images.

Table 1 Upgradeable ROMMON Images

Module ROMMON Software Version	Filename
6.3(1) Upgradeable module ROMMON image	cat6000-CPBOOT.6-3-1.ubin

Upgrading the Catalyst 6000 Family Module ROMMON

To upgrade the ROMMON version on your Catalyst 6000 family module, perform these steps:

---

Step 1 Check the current ROMMON version by entering a show version command. In this example the ROMMON version for the module in slot 8 will be upgraded:

Console> (enable) show version

WS-C6509 Software, Version NmpSW:7.1(0.12-Eng)TAM

Copyright (c) 1995-2001 by Cisco Systems

NMP S/W compiled on Jul 26 2001, 16:00:45

System Bootstrap Version:6.1(2)

Hardware Version:1.0  Model:WS-C6509  Serial #:SCA032500X1

PS1  Module:WS-CAC-1300W    Serial #:ACP03240218

Mod Port Model               Serial #    Versions

--- ---- ------------------- ----------- --------------------------------------

2   2    WS-X6K-SUP2-2GE     SAD044409SD Hw :1.1

                                         Fw :6.1(2)

                                         Fw1:6.3(1)

                                         Sw :7.1(0.12-Eng)TAM

                                         Sw1:7.1(0.12)TAM

         WS-F6K-PFC2         SAD044302JM Hw :1.0

5   16   WS-X6316-GE-TX      JAB040804WB Hw :0.201

                                         Fw :5.3(1)

                                         Sw :7.1(0.12)TAM

6   0    ws-c6500-sfm        sad040600uf Hw :0.111

                                         Fw :6.1(0.133)ORL

                                         Sw :7.1(0.9)FW4

8   16   WS-X6516-GE-TX      SAD044706E8 Hw :0.102

                                         Fw :6.1(2)

                                         Sw :7.1(0.9-Eng)TAM

9   48   WS-X6248-RJ-45      SAD03040219 Hw :0.406

                                         Fw :5.1(1)CSX

                                         Sw :7.1(0.12)TAM

16  1    WS-F6K-MSFC2        SAD04430J22 Hw :1.1

                                         Fw :12.1(3a)E4

                                         Sw :12.1(3a)E4

       DRAM                    FLASH                   NVRAM

Module Total   Used    Free    Total   Used    Free    Total Used  Free

------ ------- ------- ------- ------- ------- ------- ----- ----- -----

2      130944K  64030K  66914K  16384K   9976K   6408K  512K  112K  400K

Uptime is 6 days, 2 hours, 38 minutes

Console> (enable)

Step 2 Download the new ROMMON image from the TFTP server:

Console> (enable) copy tftp bootflash:

IP address or name of remote host []? 10.7.1.9

Name of file to copy from []? /users/image/cat6000-CPBOOT.6-3-1.ubin

3464060 bytes available on device bootflash, proceed (y/n) [n]? y

CCC

File has been copied successfully.

Step 3 Download the ROMMON image to the module you want to upgrade:

Console> (enable) download bootflash:cat6000-CPBOOT.6-3-1.ubin 8 boot

Warning!! This command replaces the existing boot code on Module 8.

Please verify with TAC that the file specified is appropriate for WS-X6516-GE-TX.

Use this command with caution.

Do you want to continue (y/n) [n]? y

Download boot image start...

Download boot code completed.

Console> (enable) 2001 Jul 25 14:55:47 %SYS-5-MOD_OK:Module 8 is online

2001 Jul 25 14:55:48 %SYS-3-MOD_PORTINTFINSYNC:Port Interface in sync for Module 8

Step 4 Enter the show version command to verify the new ROMMON version for the module in slot 8:

Console> (enable) show version

WS-C6509 Software, Version NmpSW:7.1(0.12-Eng)TAM

Copyright (c) 1995-2001 by Cisco Systems

NMP S/W compiled on Jul 26 2001, 16:00:45

System Bootstrap Version:6.1(2)

Hardware Version:1.0  Model:WS-C6509  Serial #:SCA032500X1

PS1  Module:WS-CAC-1300W    Serial #:ACP03240218

Mod Port Model               Serial #    Versions

--- ---- ------------------- ----------- --------------------------------------

2   2    WS-X6K-SUP2-2GE     SAD044409SD Hw :1.1

                                         Fw :6.1(2)

                                         Fw1:6.3(1)

                                         Sw :7.1(0.12-Eng)TAM

                                         Sw1:7.1(0.12)TAM

         WS-F6K-PFC2         SAD044302JM Hw :1.0

5   16   WS-X6316-GE-TX      JAB040804WB Hw :0.201

                                         Fw :5.3(1)

                                         Sw :7.1(0.12)TAM

6   0    ws-c6500-sfm        sad040600uf Hw :0.111

                                         Fw :6.1(0.133)ORL

                                         Sw :7.1(0.9)FW4

8   16   WS-X6516-GE-TX      SAD044706E8 Hw :0.102

                                         Fw :6.3(1)

                                         Sw :7.1(0.9-Eng)TAM

9   48   WS-X6248-RJ-45      SAD03040219 Hw :0.406

                                         Fw :5.1(1)CSX

                                         Sw :7.1(0.12)TAM

16  1    WS-F6K-MSFC2        SAD04430J22 Hw :1.1

                                         Fw :12.1(3a)E4

                                         Sw :12.1(3a)E4

       DRAM                    FLASH                   NVRAM

Module Total   Used    Free    Total   Used    Free    Total Used  Free

------ ------- ------- ------- ------- ------- ------- ----- ----- -----

2      130944K  64030K  66914K  16384K   9976K   6408K  512K  112K  400K

Uptime is 6 days, 2 hours, 38 minutes

Console> (enable)

---
