Cisco ASA 5500 Series Release Notes Version 7.0(4)

Contents

Introduction

System Requirements

Memory Requirements

Determining the Software Version

Upgrading to a New Software Release

New Features

4GE SSM

WebVPN Capture Feature

Auto Update Over a VPN Tunnel

Crashinfo Enhancement

Modular Policy Framework Enhancement

Support GTP Load Balancing Across GSNs

Downloadable ACL Enhancements

Converting Wildcards to Network Mask in Downloadable ACL

HTTP proxy applet

IPSec VPN: Add support for cascading ACLs

Rate limiting of Syslog messages

Important Notes

Important Notes in Release 7.0

Common Criteria EAL4+

FIPS 140-2

Hostname and Domain Name Limitation

WebVPN ACLS and DNS Hostname

Proxy Server and ASA

Mismatch PFS

ACS Radius Authorization Server

Readme Document for the Conduits and Outbound List Conversion Tool 1.2

User Upgrade Guide

Features not Supported in Version 7.0

MIB Supported

Downgrade to Previous Version

Caveats

Open Caveats - Release 7.0(4)

Resolved Caveats - Release 7.0(4)

Related Documentation

Software Configuration Tips on the Cisco TAC Home Page

Obtaining Documentation

Cisco.com

Documentation DVD

Ordering Documentation

Documentation Feedback

Cisco Product Security Overview

Reporting Security Problems in Cisco Products

Obtaining Technical Assistance

Cisco Technical Support Website

Submitting a Service Request

Obtaining Additional Publications and Information


Cisco ASA 5500 Series Release Notes Version 7.0(4)

October 2005

Contents

This document includes the following sections:

•Introduction

•System Requirements

•New Features

•Important Notes

•Caveats

•Related Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

•Obtaining Additional Publications and Information

Introduction

The Cisco ASA 5500 series security appliance delivers unprecedented levels of defense against threats to the network with deeper web inspection and flow specific analysis, improved secure connectivity through end-point security posture validation and voice and video over VPN support. It also provides enhanced support for intelligent information networks through improved network integration, resiliency, and scalability. This release introduces significant enhancements to all major functional areas, including: firewalling and inspection services, VPN services, network integration, high-availability services, and management/monitoring.

For more information on all the new features, see New Features.

Additionally, the Cisco ASA 5500 series security appliance software supports Adaptive Security Device Manager. ASDM is a browser-based, Java applet used to configure and monitor the software on the security appliances. ASDM is loaded from the security appliance, then used to configure, monitor, and manage the device.

System Requirements

The sections that follow list the system requirements for operating a Cisco ASA 5500 series security appliance. This section includes the following topics:

•Memory Requirements

•Determining the Software Version

•Upgrading to a New Software Release

Memory Requirements

Table 1 lists the DRAM memory requirements for the Cisco ASA 5500 series security appliance.

Table 1 DRAM Memory Requirements

ASA Model
DRAM Memory

ASA 5510

256 MB

ASA 5520

512 MB

ASA 5540

1 GB


All Cisco ASA 5500 series security appliances require a minimum of 64 MB of internal CompactFlash.

Determining the Software Version

Use the show version command to verify the software version of your Cisco ASA 5500 series security appliance.

Upgrading to a New Software Release

If you have a Cisco.com (CDC) login, you can obtain software from the following website:

http://www.cisco.com/kobayashi/sw-center/products.shtml

New Features

This section describes the new features in this release. This section includes the following topics:

•4GE SSM

•WebVPN Capture Feature

•Auto Update Over a VPN Tunnel

•Crashinfo Enhancement

•Modular Policy Framework Enhancement

•Support GTP Load Balancing Across GSNs

•Downloadable ACL Enhancements

•Converting Wildcards to Network Mask in Downloadable ACL

•HTTP proxy applet

•IPSec VPN: Add support for cascading ACLs

•Rate limiting of Syslog messages

4GE SSM

The 4GE Security Services Module (SSM) is an optional I/O card for the adaptive security appliance. The 4GE SSM expands the total number of ports available on the security appliance, providing four additional ports with Ethernet (RJ-45) or SFP (fiber optic) connections.

WebVPN Capture Feature

The WebVPN capture feature lets you log information about websites that do not display properly over a WebVPN connection. You can enable the WebVPN capture feature with the capture command, but note that it has an adverse affect on the performance of the security appliance. So, be sure to disable this feature after you have captured the information that you need for troubleshooting.

For more information, see the "Capturing WebVPN Data" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Auto Update Over a VPN Tunnel

With this release, the auto-update server command has a new source interface argument that lets you specify an interface, such as a VPN tunnel used for management access and specified by the management-access command:

auto-update server url [source interface] [verify-certificate]

no auto-update server url [source interface] [verify-certificate]

For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Crashinfo Enhancement

Output from the crashinfo command might contain sensitive information that is inppropriate for viewing by all users connected to the security appliance. The new crashinfo console disable command lets you suppress the output from displaying on the console.

For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Modular Policy Framework Enhancement

The new set connection timeout command lets you configure the timeout period, after which an idle TCP connection is disconnected.

For more information, see the "Using Modular Policy Framework" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Support GTP Load Balancing Across GSNs

If the security appliance performs GTP inspection, by default the security appliance drops GTP responses from GSNs that were not specified in the GTP request. This situation occurs when you use load-balancing among a pool of GSNs to provide efficiency and scalability of GPRS. You can enable support for GSN pooling by using the permit response command. This command configures the security appliance to allow responses from any of a designated set of GSNs, regardless of the GSN to which a GTP request was sent.

For more information, see the "Enabling and Configuring GTP Inspection" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Downloadable ACL Enhancements

A new feature has been added to ensure that downloadable ACL requests sent to a RADIUS server come from a valid source through the Message-Authenticator attribute.

Upon receipt of a RADIUS authentication request that has a username attribute containing the name of a downloadable ACL, Cisco Secure ACS authenticates the request by checking the Message-Authenticator attribute. The presence of the Message-Authenticator attribute prevents malicious use of a downloadable ACL name to gain unauthorized network access. The Message-Authenticator attribute and its use are defined in RFC 2869, RADIUS Extensions, available at http://www.ietf.org.

For more information, see the "Configuring Any RADIUS Server for Downloadable ACLs" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Converting Wildcards to Network Mask in Downloadable ACL

Some Cisco products, such as the VPN 3000 concentrator and Cisco IOS routers, require you to configure dowloadable ACLs with wildcards instead of network masks. The Cisco ASA 5500 adaptive security appliance, on the other hand, requires you to configure downloadable ACLs with network masks. This new feature allows the security appliance to convert a wildcard to a netmask internally. Translation of wildcard netmask expressions means that downloadable ACLs written for Cisco VPN 3000 series concentrators can be used by the security appliance without altering the configuration of the downloadable ACLs on the RADIUS server.

You can configure ACL netmask conversion on a per-server basis, using the acl-netmask-convert command, available in the AAA-server configuration mode. For more information about configuring a RADIUS server, see the"Identifying AAA Server Groups and Servers" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

HTTP proxy applet

The HTTP proxy is an Internet Proxy, that supports both HTTP and HTTPS connections. The HTTP proxy code modifies the browser proxy configuration dynamically to redirect all browser HTTP/S requests to the new proxy configuration. This allows the Java Applet to take over as the proxy for the browser.

HTTP Proxy can be used in conjunction with the Port Forwarding (Application Access) feature or by itself.

Note The HTTP proxy feature only works when using Internet Explorer.

On some of the older computers, running Windows XP, the RunOnce Reg-Key is not available, causing the Port Forwarding HTTP-Proxy feature to fail when attempting to modify Proxy settings on Internet Explorer.

You can mannually change the registry. Complete the following steps to change the registry manually:

a. Click Start | Run.

b. Type regedit in the open text box, and click OK.

c. Open this folder: HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\

d. Right click inside the CurrentVersion and select New | Key.

e. Name the new key RunOnce.

f. Click OK.

To configure file access and file browsing, MAPI Proxy, HTTP Proxy, and URL entry over WebVPN for this user or group policy, use the functions command in WebVPN mode.

For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

IPSec VPN: Add support for cascading ACLs

Cascading ACLs involves the insertion of deny ACEs to bypass evaluation against an ACL and resume evaluation against a subsequent ACL in the crypto map set. Because you can associate each crypto map with different IPSec settings, you can use deny ACEs to exclude special traffic from further evaluation in the corresponding crypto map, and match the special traffic to permit statements in another crypto map to provide or require different security. The sequence number assigned to the crypto ACL determines its position in the evaluation sequence within the crypto map set.

For more information, see the "Defining Crypto Maps" section in the Cisco Security Appliance Command Line Configuration Guide. For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Rate limiting of Syslog messages

The logging rate limit enables you to limit the rate at which system log messages are generated. You can limit the number of system messages that are generated during a specified time interval.

You can limit the message generation rate for all messages, a single message ID, a range of message IDs, or all messages with a particular severity level. To limit the rate at which system log messages are generated, use the logging rate-limit command.

For a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Important Notes

Important Notes in Release 7.0

This section lists important notes related to release 7.0(4).

Common Criteria EAL4+

For information on common criteria EAL4+, see the Installation and Configuration for Common Criteria EAL4+ Evaluated Cisco Adaptive Security Appliance, Version 7.0(4) document.

FIPS 140-2

The Cisco ASA 5500 series security appliance is on the FIPS 140-2 Pre-Validation List.

Hostname and Domain Name Limitation

When using ASDM, the hostname and domain names combined should not be more than 63 characters long. If the hostname and domain names combined is more than 63 characters, you will get an error message.

WebVPN ACLS and DNS Hostname

When a deny webtype URL ACL (DNS-based) is defined, but the DNS-based URL is not reachable, a "DNS Error" popup is displayed on the browser. The ACL hitcounter is also not incremented.

If the URL ACL is defined by an IP instead of DNS name, then the traffic flow hitting the ACL will be recorded in the hitcounter and a "Connection Error" is displayed on the browser.

Proxy Server and ASA

If WebVPN is configured to use an HTTP(S)-proxy server to service all requests for browsing HTTP and/or HTTPS sites, the client/browser may expect the following behavior:

1. If the ASA cannot communicate with the HTTPS or HTTPS proxy server, a "connection error" is displayed on the client browser.

2. If the HTTP(S) proxy cannot resolve or reach the requested URL, it should send an appropriate error to the ASA, which in turn will display it to the client browser.

Only when the HTTP(S) proxy server notifies the ASA of the inaccessible URL, can the ASA notify the error to the client browser.

Mismatch PFS

The PFS setting on the VPN client and the security appliance must match.

ACS Radius Authorization Server

When certificate authentication is used in conjuction with Radius authorization, the ACS server sends a bogus Group=CISCOACS:0003b9c6/5a940131/username and is displayed in the vpn-session database.

Readme Document for the Conduits and Outbound List Conversion Tool 1.2

The Cisco ASA 5500 series security appliance Outbound/Conduit Conversion tool assists in converting configurations with outbound or conduit commands to similar configurations using ACLs. ACL-based configurations provide uniformity and leverage the powerful ACL feature set. ACL based configurations provide the following benefit:

•ACE Insertion capability - System configuration and management is greatly simplified by the ACE insertion capability that allows users to add, delete or modify individual ACEs.

User Upgrade Guide

•For a list of deprecated features, and user upgrade information, go to the following URL:

http://www.cisco.com/univercd/cc/td/doc/product/multisec/asa_sw/v_70/migr_vpn/index.htm

Features not Supported in Version 7.0

The following features are not supported in Version 7.0(4):

•PPPoE

•L2TP over IPSec

•PPTP

MIB Supported

For information on MIB Support, go to:

http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml

Downgrade to Previous Version

To downgrade to a previous version of the operating system software (software image), use the downgrade command in privileged EXEC mode. For more information and a complete description of the command syntax, see the Cisco Security Appliance Command Reference.

Caveats

The following sections describe the caveats for the 7.0(4) release.

For your convenience in locating caveats in Cisco's Bug Toolkit, the caveat titles listed in this section are drawn directly from the Bug Toolkit database. These caveat titles are not intended to be read as complete sentences because the title field length is limited. In the caveat titles, some truncation of wording or punctuation may be necessary to provide the most complete and concise description. The only modifications made to these titles are as follows:

•Commands are in boldface type.

•Product names and acronyms may be standardized.

•Spelling errors and typos may be corrected.

Note If you are a registered cisco.com user, view Bug Toolkit on cisco.com at the following website:

http://www.cisco.com/support/bugtools

To become a registered cisco.com user, go to the following website:

http://tools.cisco.com/RPF/register/register.do

Open Caveats - Release 7.0(4)

Table 2 Open Caveats

ID Number
Software Release 7.0(4)
Corrected
Caveat Title

CSCeg57001

No

Packet does not come to inspect after no inspect and inspect

CSCeh15557

No

Assertion in tmatch_compile_proc, all memory is not freed.

CSCeh18115

No

Authentication not triggered sometimes when URL filtering enabled.

CSCeh32087

No

PIM sends Register with untranslated IP when NAT pool exhausted.

CSCeh43554

No

Device may reload if showing and removing config at the same time

CSCeh46345

No

Dynamic L2L could pass clear text traffic when tunnel terminates

CSCeh51949

No

Can no longer connect to ASA via WebVPN or ASDM->exhausted 8K blocks

CSCeh60845

No

Logginig queue incorrectly registers 8192 256-byte blocks

CSCeh84006

No

Wrong http version number should not be allowed

CSCeh90617

No

Recompiling ACLs can cause packet drops on low-end platforms

CSCeh93834

No

RSA SecurID replica list is lost after reboot

CSCei02273

No

1st log message is not sent by mail in transparent firewall

CSCei43588

No

traceback when trying to match a packet to acl with deny

CSCej04099

No

static xlate breaks management-access inside

CSCsb28708

No

Console traceback using show route command

CSCsb40188

No

SCEP fails if RA cert has 4096 bit key

CSCsb41742

No

P2P/IM/tunneling traffic is only dropped if strict-http action is drop

CSCsb51038

No

Traceback: _snp_sp_create_flow+1937 with outbound ACL and Policy Statics

CSCsb80170

No

Address-pools needed in group-policy - missing functionality from VPN3K

CSCsb81593

No

removing sunrpc-server cli doesnt stop sunrpc traffic from getting thru

CSCsb90046

No

GTP context creation might fail w/ Tunnel Limit xxx exceeded error

CSCsb99385

No

strict-http: with a space before http ver should generate a tcp reset

CSCsc00176

No

clear xlate take 4.5+ mins to clear 60K PAT xlat

CSCsc01017

No

ASA to VPN3K L2L fails rekey w/ main mode, 3des, sha, rsa, pfs-2, dh-2

CSCsc02485

No

Session Cmd: sendind \036x\r to exit session to ssm causes Traceback

CSCsc07421

No

Traceback in Dispatch Unit - decoding h323 ras message

CSCsc07614

No

Minimum unit poll time causes trouble for failover with 4GE card

CSCsc10617

No

GTP: memory leakage after <clear config all> at gtp_init

CSCsc11724

No

Logging: Wrong behaivor if syslog is sent to a nonfunctioning tcp server

CSCsc12094

No

AAA fallback authentication does not work with reactivation-mode timed

CSCsc14591

No

xlate and xlate perfmon print graph are all zeros

CSCsc15434

No

Assertion violation w/icmp traffic and icmp inspection

CSCsc16041

No

'clear local host' results in memory leak

CSCsc16503

No

Transparent firewall ASR UDP out traffic got errors and inbound failed

CSCsc16607

No

fixup pptp fails with static pat server configuration

CSCsc17051

No

VPNFO: VPN Failover fails to parse P2 SA when IPCOMP is used

CSCsc17409

No

dhcprelay: ASA blocks RELEASE packets

CSCsc17428

No

Tracebacks with ci/console with 'clear config all'

CSCsc18444

No

Tunnel-group for specific peer not created upgrading to 7.0 w/ certs

CSCsc18911

No

ASA does not remove OSPF route for global PAT entry after deleting


Resolved Caveats - Release 7.0(4)

Table 3 Resolved Caveats

ID Number
Software Release 7.0(4)
Corrected
Caveat Title

CSCeg67989

Yes

WebVPN: Logo file is not working correctly

CSCeh81062

Yes

wrong ip addr on outgoing packets when PAT and static port are used

CSCeh90309

Yes

Checkheaps process crashes while dumping corrupted memory blocks

CSCeh90617

Yes

Recompiling ACLs can cause packet drops on low-end platforms

CSCeh97228

Yes

cTCP: cTCP connection are dropped sporadically when connected F1 Bet

CSCei00497

Yes

PIX/ASA 7.0 doesnt encrypt packets if next hop is PIX interface.

CSCei20466

Yes

Increase in CPU utilization when OSPF is enabled

CSCei20682

Yes

FWSM uptime stops at 49 days 17 hours

CSCei23290

Yes

DHCP Relay fails when static specified

CSCei24062

Yes

Some hosts in the network connects to inside intf cannot be reached

CSCei33166

Yes

Crash while pinging through a L2L tunnel w/ 10,000 byte pings

CSCei33782

Yes

Simultaneous TFTP connections are not closed properly

CSCei38012

Yes

DHCP Server should check for correct network upon REQUEST for rebind

CSCei38640

Yes

AAA: radius /w expiry does not work when using funk radius server

CSCei38644

Yes

VPN3000 does not properly handle State Attribute

CSCei38647

Yes

IKE SA stuck in MM_DONE state

CSCei38651

Yes

NT auth for VPN clients do not work with domainuser or user@domain

CSCei38657

Yes

P1 rekey may fail when P1/P2 rekeying and retransmit required

CSCei38667

Yes

Can't differentiate between root CA certs that have been re-keyed

CSCei38669

Yes

IPSec rekey causes tunnel to drop

CSCei41326

Yes

AAA: fallback to LOCAL authentication does not work for SSH

CSCei43065

Yes

Traceback - 0x004a21b0 ojb-f1/c_crypto_map:_crypto_map_remove_np+80

CSCei43133

Yes

traceback eip 0x006026a4 obj-f1/snp_ha_db in ci/console af cleconfal

CSCei44143

Yes

Crash in malloc.c if removing ACE from ACL

CSCei50190

Yes

ASA not accepting 2 ISAKMP policies with different AES types

CSCei50691

Yes

traceback with ASR enabled for session with 2ndary conn in TFW mode

CSCei51783

Yes

Group enumeration possible on Benetton platform

CSCei51867

Yes

Usability - crypto config should be grouped together in CLI output

CSCei52413

Yes

ASA fails to import cert if CA issuer has 4096 bits cert

CSCei52906

Yes

Routes assoc. w/ net ext tunnels fail to get removed after tun drop

CSCei54438

Yes

Inspects that use TCP proxy must enable dual TCP normalizer mode

CSCei56278

Yes

All access-lists removed when removing one

CSCei57279

Yes

Cascading ACL: Deny rules not working after tunnel established

CSCei62347

Yes

acl interval default value not show when inactive parameter used

CSCei64608

Yes

GTP: box reloads when Create Response has 3rd party GSN addr

CSCei67952

Yes

GTP: PDP Context expires even when data is present in the tunnel

CSCei68679

Yes

Traceback on telnet TACACS+ authentication through the firewall.

CSCei68679

Yes

Traceback on telnet TACACS+ authentication through the firewall.

CSCei70172

Yes

TCP dynamic proxy doesnt fast retransmit lost packet

CSCei70785

Yes

TCP proxy must send data from retransmit queue when ACK is received

CSCei71868

Yes

Deny message for inbound traffic with no access-list changed

CSCei75013

Yes

confg doesnt get copied to admin ctx when changing mode SRM->MRM

CSCei78667

Yes

URL filtering: misc issues related to request exhaustion and cleanup

CSCei81803

Yes

Assert in validate_chunk() during startup

CSCei83304

Yes

clear conf sec doesnt clear igmp and ospf param in ifx submode

CSCei84925

Yes

traceback obj-f1/snp_tfw:_snpi_tfw_update_l2_entry+75 af apply conf

CSCei87390

Yes

Removing failover group causes traceback with 4GE installed

CSCei87785

Yes

MGCP: Call cannot be placed with IP phone using BTS CA & version 1.0

CSCei92828

Yes

Authentication failing for virtual telnet/http in transperent mode

CSCei93112

Yes

Existing connections not replicated to standby after failover

CSCei93790

Yes

Clear configure all in single transparent mode causes traceback

CSCej08898

Yes

tcpintercept caused trcback.embconn=0,maxconn!=0,eip:0x00c32dbc

CSCej12123

Yes

OSPF external routes preferred over internal with multiple processes

CSCej24446

Yes

error in processing IKE

CSCsb32565

Yes

Device reboots unexpectedly with traceback

CSCsb36441

Yes

Traceback eip _snp_fp_inspect_ip_options with IP Frag and 10 KB ping

CSCsb37531

Yes

Traceback after failover if TCP Intercept is triggered.

CSCsb45373

Yes

Traceback tcp_slow after vpn system test script strtd snd cfg setupUUT

CSCsb45584

Yes

Traceback eip _snp_ids_cleanup_cb with ips promiscuous and 100 byte ping

CSCsb46603

Yes

GTP: Responses that reject Create Requests are dropped

CSCsb46862

Yes

Assertion in ctm_sw_rng_x931.c:update_key

CSCsb47027

Yes

ASA crashed eip 0x00b8773c (image 7.0.2.1)

CSCsb47825

Yes

F1 fails to establish TCP remote access sessions with 3002 HW client

CSCsb49125

Yes

F1 crashes at <show debug> command

CSCsb49744

Yes

WebVPN: New crash behavior w buffer capture

CSCsb50946

Yes

High cpu due to shun command

CSCsb52950

Yes

With banner exec command and # as delimiter replication not correct

CSCsb53407

Yes

MFIB: tracebacks when bouncing multicast-routing

CSCsb54403

Yes

mcast: asa crashes after inside router pings 226.1.1.1

CSCsb54545

Yes

Traceback eip _keyword_option_flex_action with show ip local pool

CSCsb55282

Yes

sh inventory does not show 4GE module

CSCsb55550

Yes

traceback in pki_ctm:_pki_ctm_verify_signature+164 - 8192 bit certs conn

CSCsb56247

Yes

traceback in crypto_pki:_crypto_pki_poll_crl+52 - with crl opt PKI

CSCsb56367

Yes

webvpn: assertion in thread emweb/https when max webvpn sessions reached

CSCsb58364

Yes

VPNFO: tunnels get dropped when fover occurs

CSCsb58364

Yes

VPNFO: tunnels get dropped when fover occurs

CSCsb60861

Yes

WebVPN session attempt with proto=webvpn off, causes emweb crash

CSCsb61027

Yes

mcast: secondary crashes shortly after sync'd with primary

CSCsb61544

Yes

WebVPN: Traceback within obj-f1/http_ewa:_ewaNetHTTPSend+162

CSCsb61644

Yes

ASA crashes when acessing ASDM over IPSec/TCP-10000 tunnel

CSCsb61832

Yes

HTTP-Proxy functionality (Port Forwarding) not working on Windows ME

CSCsb62617

Yes

VPN: assertion 0 failed: file malloc.c, line 4570 RA dial/hang test

CSCsb62908

Yes

Closing the Port Forwarding Applet removes existing Proxy configuration

CSCsb63920

Yes

CLI: no ssl trust-point cmmd causes traceback, ssl_chain:_ssl_trustpoint

CSCsb64159

Yes

VPNLB: need ability to assign a trustpoint to the vcpip address

CSCsb64985

Yes

4ge module interface stops passing traffic after using QoS and L2L tunn

CSCsb67119

Yes

Inspect ESMTP incorrectly rewrites smtp reply containing 220 in text

CSCsb67166

Yes

Time based ACLs not working properly if object groups are used

CSCsb70268

Yes

'hw-module module 1 reload reloads 4GE module

CSCsb71198

Yes

incorrectly formatted DL ACL causes traceback in IKE daemon

CSCsb72604

Yes

crash in snmp thread after nmap UDP scan of port 161

CSCsb72665

Yes

IX 7 may drop valid TCP segments that carry data in final segment

CSCsb72803

Yes

rash triggered when system is out of memory

CSCsb74050

Yes

F1 crashed when sweep-ping (G-PDU) thru GTP tunnel v0

CSCsb74836

Yes

MFW-R: ASA crash on SSM reboot from IDM

CSCsb75857

Yes

F1 hit memory corrution crash @ clear conf gtp then clear conf all

CSCsb76268

Yes

Immediately after upgrade to 7.0(1) - interfaces stuck in waitingstate

CSCsb77332

Yes

traceback in fover_parse on standby unit if config contains webtype acl

CSCsb77397

Yes

Traceback: eip 0x00c3426c strcpy:_strcpy+12, using deb menu ike commands

CSCsb78230

Yes

hw-module module 1 shut and reset do not bring up the 4ge module

CSCsb79742

Yes

incorrectly formatted downloadable acl causes traceback in emweb/https

CSCsb80196

Yes

DHCP ID String is limited to 50 characters, should be 128

CSCsb81575

Yes

key gen causes an assert if ASA has DES only license

CSCsb82663

Yes

Out of order TCP packets degrade HTTP inspection performance

CSCsb83962

Yes

F1 OSPF regression scripts hang with removal of router config

CSCsb85767

Yes

URL Filtering with long URLs could cause memory corruption

CSCsb85780

Yes

Malformed HTTP GET request causes URL filtering module to cause a crash.

CSCsb88557

Yes

Traceback at snap:_snap_mini_dump+26 with acl Logging: thread-arp_timer

CSCsb89147

Yes

certificate-to-username mapping broken for some DN attributes

CSCsb91835

Yes

ASA reload in smtp/esmtp inspection {insp_process_smtp_data}

CSCsb91837

Yes

vpn-filter incorrectly blocking traffic with echo, echo-response keyword

CSCsb93659

Yes

Local IP doesn't get translated with NAT Exemption

CSCsb94651

Yes

Overlapping static statements should be allowed

CSCsb94689

Yes

4GE card firmware accessing incorrect PHY address

CSCsb95027

Yes

Stadby Betabox rebooted while upgrading to 7.0.3.19

CSCsb95259

Yes

No hits shown on access-list associated to a group-policy vpn-filter

CSCsb97680

Yes

traceback in radpact:_RADPBldHWClientReauth+260 during 3002 New Pin Mode

CSCsb99192

Yes

Show access-list | inc xxx causes traffic through device to be delayed

CSCsb99360

Yes

Logging queue 0 is wrongly shown as being unlimited queue

CSCsc00709

Yes

ASA enable authentication issue

CSCsc02230

Yes

nat entry with outside keyword : ERROR: unable to download policy

CSCsc02485

Yes

Session Cmd: sendind 036xr to exit session to ssm causes Traceback

CSCsc02574

Yes

pki: ID cert signature validation failure allows successful connection

CSCsc06282

Yes

fover: ip local pool fails to replicate after issuing from grp submode

CSCsc06477

Yes

unable to manage running config with err msg: configuration in progress

CSCsc06702

Yes

VPN: Interface counters are incorrectly incremented on decrypted packets

CSCsc08843

Yes

DHCP-Relay drops packets when source address is non-zero

CSCsc09527

Yes

VPNFO: cannot establish a vpn tunnel "session limit reached" sa cnt -1

CSCsc09932

Yes

Assertion in file "vf_api.c", line 264, traceback in strdup:_int3+4

CSCsc14837

Yes

ARP fails on the 4GE interfaces in routed firewall mode


Related Documentation

For additional information on the Cisco ASA 5500 series security appliance, refer to the following documentation found on Cisco.com:

•Cisco ASA 5500 Hardware Installation Guide

•Cisco ASA 5500 Quick Start Guide

•Cisco Security Appliance Command Line Configuration Guide

•Cisco Security Appliance Command Reference

•Migrating to ASA for VPN 3000 Series Concentrator Administrators

Software Configuration Tips on the Cisco TAC Home Page

The Cisco Technical Assistance Center has many helpful pages. If you have a CDC account you can visit the following websites for assistance:

TAC Troubleshooting, Sample Configurations, Hardware Info, Software Installations and more:

http://www.cisco.com/en/US/products/hw/vpndevc/ps2030/tsd_products_support_series_home.html

Obtaining Documentation

Cisco documentation and additional literature are available on Cisco.com. Cisco also provides several ways to obtain technical assistance and other technical resources. These sections explain how to obtain technical information from Cisco Systems.

Cisco.com

You can access the most current Cisco documentation at this URL:

http://www.cisco.com/univercd/home/home.htm

You can access the Cisco website at this URL:

http://www.cisco.com

You can access international Cisco websites at this URL:

http://www.cisco.com/public/countries_languages.shtml

Documentation DVD

Cisco documentation and additional literature are available in a Documentation DVD package, which may have shipped with your product. The Documentation DVD is updated regularly and may be more current than printed documentation. The Documentation DVD package is available as a single unit.

Registered Cisco.com users (Cisco direct customers) can order a Cisco Documentation DVD (product number DOC-DOCDVD=) from the Ordering tool or Cisco Marketplace.

Cisco Ordering tool:

http://www.cisco.com/en/US/partner/ordering/

Cisco Marketplace:

http://www.cisco.com/go/marketplace/

Ordering Documentation

You can find instructions for ordering documentation at this URL:

http://www.cisco.com/univercd/cc/td/doc/es_inpck/pdi.htm

You can order Cisco documentation in these ways:

•Registered Cisco.com users (Cisco direct customers) can order Cisco product documentation from the Ordering tool:

http://www.cisco.com/en/US/partner/ordering/

•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco Systems Corporate Headquarters (California, USA) at 408 526-7208 or, elsewhere in North America, by calling 1 800 553-NETS (6387).

Documentation Feedback

You can send comments about technical documentation to bug-doc@cisco.com.

You can submit comments by using the response card (if present) behind the front cover of your document or by writing to the following address:

Cisco Systems
Attn: Customer Document Ordering
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Cisco Product Security Overview

Cisco provides a free online Security Vulnerability Policy portal at this URL:

http://www.cisco.com/en/US/products/products_security_vulnerability_policy.html

From this site, you can perform these tasks:

•Report security vulnerabilities in Cisco products.

•Obtain assistance with security incidents that involve Cisco products.

•Register to receive security information from Cisco.

A current list of security advisories and notices for Cisco products is available at this URL:

http://www.cisco.com/go/psirt

If you prefer to see advisories and notices as they are updated in real time, you can access a Product Security Incident Response Team Really Simple Syndication (PSIRT RSS) feed from this URL:

http://www.cisco.com/en/US/products/products_psirt_rss_feed.html

Reporting Security Problems in Cisco Products

Cisco is committed to delivering secure products. We test our products internally before we release them, and we strive to correct all vulnerabilities quickly. If you think that you might have identified a vulnerability in a Cisco product, contact PSIRT:

•Emergencies — security-alert@cisco.com

•Nonemergencies — psirt@cisco.com

Tip We encourage you to use Pretty Good Privacy (PGP) or a compatible product to encrypt any sensitive information that you send to Cisco. PSIRT can work from encrypted information that is compatible with PGP versions 2.x through 8.x.

Never use a revoked or an expired encryption key. The correct public key to use in your correspondence with PSIRT is the one that has the most recent creation date in this public key server list:

http://pgp.mit.edu:11371/pks/lookup?search=psirt%40cisco.com&op=index&exact=on

In an emergency, you can also reach PSIRT by telephone:

•1 877 228-7302

•1 408 525-6532

Obtaining Technical Assistance

For all customers, partners, resellers, and distributors who hold valid Cisco service contracts, Cisco Technical Support provides 24-hour-a-day, award-winning technical assistance. The Cisco Technical Support Website on Cisco.com features extensive online support resources. In addition, Cisco Technical Assistance Center (TAC) engineers provide telephone support. If you do not hold a valid Cisco service contract, contact your reseller.

Cisco Technical Support Website

The Cisco Technical Support Website provides online documents and tools for troubleshooting and resolving technical issues with Cisco products and technologies. The website is available 24 hours a day, 365 days a year, at this URL:

http://www.cisco.com/techsupport

Access to all tools on the Cisco Technical Support Website requires a Cisco.com user ID and password. If you have a valid service contract but do not have a user ID or password, you can register at this URL:

http://tools.cisco.com/RPF/register/register.do

Note Use the Cisco Product Identification (CPI) tool to locate your product serial number before submitting a web or phone request for service. You can access the CPI tool from the Cisco Technical Support Website by clicking the Tools & Resources link under Documentation & Tools. Choose Cisco Product Identification Tool from the Alphabetical Index drop-down list, or click the Cisco Product Identification Tool link under Alerts & RMAs. The CPI tool offers three search options: by product ID or model name; by tree view; or for certain products, by copying and pasting show command output. Search results show an illustration of your product with the serial number label location highlighted. Locate the serial number label on your product and record the information before placing a service call.

Submitting a Service Request

Using the online TAC Service Request Tool is the fastest way to open S3 and S4 service requests. (S3 and S4 service requests are those in which your network is minimally impaired or for which you require product information.) After you describe your situation, the TAC Service Request Tool provides recommended solutions. If your issue is not resolved using the recommended resources, your service request is assigned to a Cisco TAC engineer. The TAC Service Request Tool is located at this URL:

http://www.cisco.com/techsupport/servicerequest

For S1 or S2 service requests or if you do not have Internet access, contact the Cisco TAC by telephone. (S1 or S2 service requests are those in which your production network is down or severely degraded.) Cisco TAC engineers are assigned immediately to S1 and S2 service requests to help keep your business operations running smoothly.

To open a service request by telephone, use one of the following numbers:

Asia-Pacific: +61 2 8446 7411 (Australia: 1 800 805 227)
EMEA: +32 2 704 55 55
USA: 1 800 553-2447

For a complete list of Cisco TAC contacts, go to this URL:

http://www.cisco.com/techsupport/contacts

•World-class networking training is available from Cisco. You can view current offerings at this URL:

http://www.cisco.com/en/US/learning/index.html

Obtaining Additional Publications and Information

Information about Cisco products, technologies, and network solutions is available from various online and printed sources.

•Cisco Marketplace provides a variety of Cisco books, reference guides, and logo merchandise. Visit Cisco Marketplace, the company store, at this URL:

http://www.cisco.com/go/marketplace/

•Cisco Press publishes a wide range of general networking, training and certification titles. Both new and experienced users will benefit from these publications. For current Cisco Press titles and other information, go to Cisco Press at this URL:

http://www.ciscopress.com

•Packet magazine is the Cisco Systems technical user magazine for maximizing Internet and networking investments. Each quarter, Packet delivers coverage of the latest industry trends, technology breakthroughs, and Cisco products and solutions, as well as network deployment and troubleshooting tips, configuration examples, customer case studies, certification and training information, and links to scores of in-depth online resources. You can access Packet magazine at this URL:

http://www.cisco.com/packet

•iQ Magazine is the quarterly publication from Cisco Systems designed to help growing companies learn how they can use technology to increase revenue, streamline their business, and expand services. The publication identifies the challenges facing these companies and the technologies to help solve them, using real-world case studies and business strategies to help readers make sound technology investment decisions. You can access iQ Magazine at this URL:

http://www.cisco.com/go/iqmagazine

•Internet Protocol Journal is a quarterly journal published by Cisco Systems for engineering professionals involved in designing, developing, and operating public and private internets and intranets. You can access the Internet Protocol Journal at this URL:

http://www.cisco.com/ipj

•World-class networking training is available from Cisco. You can view current offerings at this URL:

http://www.cisco.com/en/US/learning/index.html
