Release Notes for Cisco MICA Portware Version 184.108.40.206 on Cisco AS5300, Cisco AS5800, Cisco 3600, and Cisco 3700 Series
These release notes describe Cisco MICA Portware Version 220.127.116.11 on Cisco AS5300 and Cisco AS5800 universal access servers and Cisco 3600 and Cisco 3700 series routers supporting V.92 and V.44 with Cisco IOS Software Releases 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher. This is a V.92 maintenance release.
Cisco MICA Portware Release 18.104.22.168 is based on the V.92 Cisco MICA Portware maintenance release 22.214.171.124, and it includes the caveats listed in the "Caveats for Cisco MICA Version 126.96.36.199" section. Cisco MICA Portware Release 188.8.131.52 contains all of the fixes and caveats listed in the following Cisco MICA Portware releases:
•184.108.40.206, and earlier versions (220.127.116.11, 18.104.22.168, and so on)
See the Cisco MICA portware release notes for Cisco AS5300 index page to find all earlier version release notes.
This document includes the following sections:
New Features for Version 22.214.171.124
•The S54 register (General Purpose Bit Mapped Register #1) defaults to S54=200 in Cisco MICA release 126.96.36.199 and above. This enables the following features:
–Power control (CSCdk11008)
–SQ value increment set to 0.5 (CSCdp40871)
–UART functionality and EC parity bit (CSCds35369).
•The general purpose bit mapped S-register (S82) has been changed as part of the resolution of CSCdy17030 and CSCea13007. See CSCea13007—Block outbound calls from Cisco MICA.
•The call setup code of the S54 GENERAL_PURPOSE_MAP s-register has been changed as part of the resolution of SCSdw05174. See CSCdw05174— Improvement for shorter Call Setup time needed for Cisco MICA.
V.40, V.90, and V.92
If you are using V.92 and V.44, Cisco MICA Portware Version 188.8.131.52 is supported with Cisco IOS Releases 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher. If you are using V.90 or below, Cisco MICA Portware Version 184.108.40.206 is supported with Cisco IOS Releases 11.2(16+)P, 11.3(5)T/NA/AA, 12.0 (all), 12.1 (all), and 12.2 (all).
On all Cisco IOS software platforms that support Cisco MICA portware but that do not support V.92 and V.44 (all Cisco IOS software releases prior to 12.2(2)XA, 12.2(2)XB, and 12.2(11)T and all Cisco IOS software that supports the Cisco 3600), Cisco MICA portware 220.127.116.11 and follow on releases are supported as long as V.92 and V.44 are disabled in the configuration.
Bundled firmware support
The Cisco 3600 and Cisco 3700 series are supported in Cisco MICA Portware Version 18.104.22.168 through Version 22.214.171.124, but only Version 126.96.36.199 contains the bundled firmware for these platforms.
Refer to the Compatibility Matrixes for Cisco AS5x00, Cisco 3600, and Cisco 3700 Platforms with Cisco MICA 6-Port and 12-Port Modem Module Portware.
For platform-specific information, refer to the Cisco AS5300 Universal Access Servers Release Notes.
Note Many client modems used in Europe are known to have problems with the Modem on Hold (MOH) feature. The vendors are aware of the issue and are working to correct it. If you are having trouble with the Modem on Hold feature in Europe, it is suggested that the customer contact the client modem vendor to verify that the modem complies with the telephony signaling for call waiting, caller ID, and 3-way calling in their particular country. For more information, refer to the Configuring and Troubleshooting V.92 Modems document.
For a list of modems tested with Cisco MICA portware, refer to the Modem Interoperability List for V.34 and V.90 Modems document.
Note The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Cisco MICA Portware Version 188.8.131.52 is supported on the following platforms:
•Cisco 3600 series
•Cisco 3700 series
Cisco MICA Portware Features
Table 1 Feature Content by Modem Version
Portware Version Feature Content
V.92 maintenance release.
•S82 has been updated.
•S54 has been updated.
•Includes caveats and caveat fixes from Cisco MICA Portware Releases 184.108.40.206, 220.127.116.11, 18.104.22.168, 22.214.171.124, and earlier releases.
V.92 maintenance release.
•New s-register (S82) added as part of the resolution to CSCdy17030.
•Changes made to the call setup code of S54, GENERAL_PURPOSE_MAP s-register as part of the resolution to CSCdw05174.
•Includes caveats and caveat fixes from Cisco MICA Portware Releases 126.96.36.199, 188.8.131.52, 184.108.40.206, and earlier releases.
V.92 maintenance release. Capabilities exchange enhancements added to address CSCdu43488—Capabilities exchange needs to be fully implemented.
Feature release. New features added to existing 220.127.116.11 features. Supports Cisco IOS Release 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher1 .
•V.92 Quick Connect
•V.92 Modem on Hold
•V.44 LZJH Data Compression
Non-V.92 maintenance release. New features added to existing 18.104.22.168 features:
•S74—Minimum duration of TRN1d signal in milliseconds (CSCdv46797).
Maintenance release. New features added to existing 22.214.171.124 features. Cisco IOS Release 12.1(5) support.
•V.110 blind connect feature for compatibility with nonstandard clients (CSCdr39887), which is enabled by bit 9 in S-register S54.
–S71 and S72 (decouple maximum symbol rates for V.90 and V.34)
–S64, finer granularity in modulation selection (CSCdm94337)
Maintenance release. New features added to existing 126.96.36.199 features. Cisco IOS Software Release 12.1(5) support.
•W, X, and (,) dial modifiers
•Support for IPDC protocol for call control signaling
•Additional V.110 speeds (CSCdm43898): 38,400, 28,800, 24,000, 12,000 bps
•Additional dial modifiers (CSCdk10292)
•Decoupled V.90 power levels for S-registers S39 and S59 (CSCdm52396)
•New values for S54 general capabilities register
•Signal quality threshold changes
•Parity for error controlled connections (CSCdj92333)
•Added client modems for V.90 Digital Impariment Learning (DIL) sequence detection
Feature release. New features added to existing Version 188.8.131.52 features.
•V.110 ISDN rate specification
•spe download command
•Cisco AS5800 supported on Cisco IOS Release 12.0(5)T onlyModulation
•ITU-T Recommendation Q.931 V.110 Bearer Rates:
1200 bps, 2400 bps, 4800 bps, 7200 bps, 9600 bps, 14,400 bps, 19,200 bps, 38,400 bps.
•ITU-T Recommendation Q.931 Intermediate Rates:
8k, 16k, 32k, and 64k bps.
Maintenance release. New features added to existing Version 184.108.40.206 features.Signaling
•Resource Pool Management (RPM):
–Ring-back tone generation.Port Management
•Improved port management interfacing for acquiring modem/port data for AAA records.
SS7 support added to Version 220.127.116.11 features.Signaling
•Continuity Testing (COT) of DSO channels in SS7 networks.
V.90 and RFC-2217 dialout support for fax/data.
Note The Cisco DialOut Utility (CDU) is no longer supported. Refer to the
Cisco DialOut Utility End of Sale/Shipping bulletin and the
Sample NAS Configurations for Cisco DialOut Utility document for information.Modulation
•V.90 standard supporting rates of 56,000 to 28,000 in 1333.3-bps increments.
•Fax out (transmission) Group 3, standards EIA 2388 Class 2 and EIA 592 Class 2.0, at modulations V.33, V.29, V.27ter, V.21, and V.17.
R1 support plus K56flex maintenance.Signaling
•R1 noncompelled and semicompelled.
•Rockwell K56flex at 56,000 to 32,000 in 2000 bps increments.
Initial V.34+ release.Modulation
•ITU-T V.34 Annex 12 at 33600 and 31200 bps.
•ITU-T V.34 at 26,400, 24,000, 21,600, 19,200, 16,800, 14,400, 12,000, 9600, 7200, 4800, or 2400 bps.
•V.32bis = 14400, 12000, 9600, 7200, 4800; V.32 = 9600, 4800; V.22bis = 2400, 1200; V.21 = 300; Bell212A = 1200, Bell103 = 300; V.22 = 1200; V.23 = 1200/75.Signaling
•R2 compelled, noncompelled, and semicompelled.Protocols
•ITU-T V.42 (including MNP 2-4 and LAPM) Error Correction.
•ITU-T V.42bis (1K nodes) and MNP 5 Data Compression.Modem Standard
•ITU-T V. 25—Automatic calling or answering equipment on dialup lines. This standard includes the procedures for disabling echo control devices for calls that are established manually and automatically.
1 Support for V.92 and V.44 on the Cisco 36x0 and Cisco 37x0 has been added with Cisco IOS Release 12.2(11)YT. Cisco MICA Version 18.104.22.168 is the bundled portware with the Cisco IOS software.
Caveats for Cisco MICA Version 22.214.171.124
This section describes known problems with portware Version 126.96.36.199. If a workaround is not provided, a solution is being developed.
Note The capabilities exchange feature for V.92 and V.44 is supported only in Cisco IOS Release 12.2(2)XB6 and higher. If you are using Cisco IOS Release 12.2(2)XA, 12.2(2)XB5, or earlier releases, you must modify S54 in a modem cap to enable V.92 and V.44 operation. See the Release Notes for Cisco MICA Portware Version 188.8.131.52 on Cisco AS5300 and Cisco AS5800 Universal Access Servers for details on enabling V.92 using S54 for Cisco IOS software versions that do not contain this caveat (CSCdu81035).
Resolved Version 184.108.40.206 Caveats
•CSCdy09524—Number of tx_underruns is reported wrong in general portware info
•CSCdy05081—atDEBUGTHISMODEMD3 needs to turn off all CP-generated out-of-service (OOS) events
•CSCdx63339—Cisco MICA fails to respond to a MHreq sequence from the client modem
•CSCdt56162—%MICA-3-UNKNINBAND: Unknown inband message from modem
•CSCdy57585—New hmm_trace has problems with SP_DEBUG messages
•CSCdy82264—Round error causes a wrong length of TRN1D sequence
This section provides specific caveat details from the "Resolved Version 220.127.116.11 Caveats" section.
S54 and S82 Notes
Table 2 S54  General Purpose Bit Mapped Register #1
All general options are disabled
Reserved for engineering use
Enables aggressive client capping
Forces 4-point training (see the "4-Point Training (S54=4) Debug Tool" section)
Enables power control
Enables EC quality checking
Caps Rx rate to 26400 when detecting PC-Tel modem (see CSCdm45403)
Enables UART functionality (see CSCdj92333)
Enables 0.5 increment for SQ value with S32 (see CSCdp40871)
Enables DSP reset (see CSCdp94025)
Enables V.110 S&X option to be the same as Cisco AS5200 (see CSCdr39887)
Enables enhanced S detector (see CSCdr65889)
Enables V.92 and V.44 (see CSCdu43488 and CSCdu81035)
Disables 400 ms silence loop before ANSback tone (see CSCdw05174)
CSCea13007—Block outbound calls from Cisco MICA
In order to suppress outbound calls from being placed from Cisco MICA, the S82 bit 4 must be set in their modemcap. The default setting of S82 does not change the outbound call behavior of Cisco MICA.
Note To avoid decreasing your call success rate (CSR) with a ring no answer, do not enable the SP checksum OOS functionality for the Cisco AS5300 or Cisco AS5800 with Cisco IOS releases prior to 12.2(2)XB7. CSCds09499 and CSCdy00812 need to be integrated in your Cisco IOS software version before enabling the OOS functionality. Otherwise, Cisco IOS continues to allocate calls to the out-of-service modem, which results in a Ring No Answer, which decreases your CSR.
CSCds09499 —Cisco AS5300:CSM should not allocate calls to busy or bad modems
CSCdy00812—Cisco AS5800:%MICA-3-NAK:NAK from modem 21 in state 50—payload 0x20 seen
CSCdw05174— Improvement for shorter Call Setup time needed for Cisco MICA
According to the V.8 specifications, Cisco MICA sends 400 ms of silence before the ANSback tone. It was observed that there is no longer a need for staying in a 400 ms loop in the SP, because this silence is inherently already there, due to the time spent elsewhere in the code.
The last bit of the GENERAL_PURPOSE_MAP (S54) has been allocated to give the you flexibility whether to stay in this 400 ms loop or not. S54=32768 disables the 400 ms silence loop before the ANSback tone. The default value of S54 (200) was not changed, so by default, the 400 ms silence loop in Cisco MICA is still enabled.
CSCdv46797—Capability needed to reduce EC training time
This caveat was brought over from the 272x branch to the 291x branch. This change makes the length of the TRN1d signal variable. As part of V.92, this signal is minimized to its shortest length while allowing for the best connection. So if V.92 is enabled in Cisco MICA Portware Version 18.104.22.168, the code added as part of CSCdv46797 is not used, regardless of the S74 setting. If V.92 is not enabled in 22.214.171.124, the value of S74 can be used to shorten the TRN1d sequence.
See the Release Notes for Cisco MICA Portware Version 126.96.36.199 on Cisco AS5300 and AS5800 Universal Access Servers and Cisco 3600 Series for further details regarding S74.
4-Point Training (S54=4) Debug Tool
There are two types of training, 4-point and 16-point. This information is provided by signal J in phase 3 of a modem connection. These size denotations tell the modems which constellation size is used when the modems are training up (in phase 4). 6-point is used the most, but if you do not have a very clean line, and you are having problems syncing up, you can set the constellation size to 4-point to see if you are having problems during training. With 4-point, there are less detection errors (the points are spread further away, so the detection is more lenient) than 16-point which has to be more precise.
Additionally, 4-point training is a more robust way of completing the full duplex train in V.34, V.90, and K56Flex. The regular train uses an 8-point constellation. When the line is noisy, the standard allows you to switch down to a 4-point constellation, which allows you to operate reliably in a lower SNR environment and complete training. We have broken this out into an S-register (S54=4) as a debug tool for customer use.
See the Release Notes for Cisco MICA Portware Version 188.8.131.52 on Cisco AS5300 and Cisco AS5800 Universal Access Servers for more information about S54.
Unresolved Caveats for Version 184.108.40.206
•CSCdp42990—Modem log shows false outgoing calls
If you have an account on Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in to Cisco.com and click Service & Support: Software Center: Cisco IOS Software: BUG TOOLKIT.
Downloading Portware Modem Code
Download new portware by going to the following link:
SPE Download Tasks
Cisco supports portware configuration using service processing element (SPE) configuration commands and modem-pool commands. The spe command allows portware to be downloaded to the SPE.
To download modem portware using the spe command, enter the spe command, one configuration command per line.
Step 1 Enter the spe command and subcommands, one configuration command per line:Router# configure terminalRouter(config)# spe <slot>/<spe_begin> <slot>/<spe_end>Router(config-spe)# firmware location system:/ucode/mica_port_firmwareRouter(config-spe)# ^Z
For example, the following display shows a Cisco AS5300 SPE download to all modems in Slot 1 (that is, all modems on a feature card containing ten 6-port modem modules). The modem code resides in the Flash memory, and the modem code filename is mica-modem-portware.220.127.116.11.bin.Router(config)# spe 1/0 1/9Router(config-spe)# firmware location flash:mica-modem-portware.18.104.22.168.bin
Step 2 Copy the configuration from NVRAM into running RAM:Router# copy running-config startup-config
Download occurs when the modems become available and shows the SPE firmware upgrade option defined (default: busyout). The spe command generates NVRAM modem download and configuration file entries.
Note If the configuration is not saved as described above, download of the portware specified with the spe command will not occur after the next reboot.
For detailed information on the spe command, go to the following link:
Modem-Pool Download Tasks
If you have an account on Cisco.com, you can download modem portware/firmware using FTP if you are using Cisco IOS Software Release 12.0(5)T or earlier at the following link:
For further information about Cisco MICA portware and Cisco IOS software, see the following related sources:
•Cisco AS5x00 Cisco MICA 6-Port and 12-Port Modem Module Portware/Cisco IOS Software Compatibility Matrixes
•Cisco MICA Modem Dial Modifiers for Cisco AS5300, Cisco AS5400, and AS5800 Universal Access Servers
•Cisco IOS Release 12.2 Configuration Guides and Command References
•Cisco IOS Release 12.2 Master Indexes
•Cisco IOS Dial Services Command Reference for Cisco IOS Software Release 12.2
•AT Command Set and Register Summary for Cisco MICA 6-Port Modules
•Modem Management Operations
•SPE and Firmware Download Enhancements
•Cisco AS5300 access servers, Appendix A, "Managing Modems," and Appendix B, "Rom Monitor," in the Cisco AS5300 Universal Access Server Software Configuration Guide
•Modem Management Commands
•V.90 and RFC-2217 dialout support for fax/data
