Compatibility Matrixes for Cisco AS5x00, Cisco 3600, and Cisco 3700 Platforms with Cisco MICA 6-Port and 12-Port Modem Module Portware
August 1, 2003
This document contains software compatibility matrixes for Cisco MICA 6-port and 12-port modem modules and includes the following sections:
•
Portware Feature Descriptions
•
•
•
•
•
Portware Feature Descriptions
Table 1 contains descriptions of released portware versions. Each new release has fixes on top of the code base of the previous release in addition to the new features listed in Table 1.
Table 1 Cisco AS5x00 Portware Feature Descriptions
8.2.3.0
Maintenance release for Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS). Support for PIAFS Version 2.1.
Note
8.2.1.11
Maintenance release for Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS). Support for PIAFS Version 2.0.
8.2.1.01
Support for Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS). Support for PIAFS Version 2.0.
2.9.4.0 2
V.92 maintenance release. Adds features to existing 2.9.2.0 features.
A new general purpose bit mapped S-register (S82), similar to S54, has been added as a part of the resolution of CSCdy17030. See CSCdy17030—Do not mark DSP OOS for checksum error.
Changes have been made to the call setup code of the S54 GENERAL_PURPOSE_MAP s-register. See the CSCdw05174— Improvement for shorter Call Setup time needed for Cisco MICA.
2.9.2.03
V.92 maintenance release. Adds features to existing 2.9.1.0 features. Adds backward compatibility for support of pre-V.92 Cisco IOS Software versions.
Capabilities exchange enhancements added to address CSCdu43488---Capabilities exchange needs to be fully implemented. Refer to the Release Notes for Cisco MICA Portware Version 2.9.2.0 on Cisco AS5300 and Cisco AS5800 Universal Access Servers for more information.
2.9.1.04
Feature release. New features added to existing 2.7.3.0 features. Supports Cisco IOS Software Release 12.2(2)XA, 12.2(2)XB, 12.2(11)T5 , and higher.
•
•
•
2.7.4.0
Maintenance release. New features added to existing 2.7.3.0 features. Cisco IOS Software Release 12.2 support.
•
S74 allows you to optimize the overall time to connect for V.90 calls. S74 replaces S62.
2.7.3.0
Maintenance release. New features added to existing 2.7.2.0 features. Cisco IOS Software Release 12.1(5) support.
•
•
–
S64, finer granularity in modulation selection (CSCdm94337)
Note
2.7.2.0
Maintenance release. New features added to existing 2.7.1.0 features. Cisco IOS Software Release 12.1(5) support.
•
•
•
•
•
•
•
•
•
•
•
2.7.1.0
V.110 terminal adapter support
2.6.2.0
Resource Pool Management (RPM) support
2.6.1.0
Introduce SS7 support
2.5.1.0
V.90 and RFC-2217 dialout support for fax/data
Note
2.3.1.0
R1 support and K56flex maintenance
2.2.3.0
K56flex
2.0.1.7
Initial V.34 release
1 Cisco MICA Portware Version 8.2.x.x is a special release for PIAFS support only. PIAFS is an error-correcting link layer protocol used in Japan over PHS digital server networks. PIAFS is supported on Cisco AS5300 universal access servers. Cisco MICA Portware Version 8.2.x.x only supports PIAFS and does not support other modem modulations or standards. Contact your account representative for information about obtaining Cisco MICA portware for PIAFS.
2 If you are using V.92 and V.44, Cisco MICA Portware Version 2.9.2.0 is supported with Cisco IOS Releases 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher. If you are using V.90 or below, Cisco MICA Portware Version 2.9.2.0 is supported with Cisco IOS Releases 11.2(16+)P, 11.3(5)T/NA/AA, 12.0 (all), 12.1 (all), and 12.2 (all).
3 On all Cisco IOS software platforms that support Cisco MICA portware but that do not support V.92 and V.44, Cisco MICA portware 2.9.2.0 and follow on releases are supported as long as V.92 and V.44 are disabled in the configuration.
4 Cisco MICA Version 2.9.1.0 is compatible only with Cisco IOS Versions that support V.92.
5 Support for V.92 and V.44 on the Cisco 36x0 and Cisco 37x0 has been added with Cisco IOS Release 12.2(11)YT. Cisco MICA Version 2.9.1.0 is the bundled portware with the Cisco IOS software. The Cisco 3600 series and Cisco 3700 series are supported in Cisco MICA Portware Version 2.9.1.0 through Version 2.9.4.0, but only Version 2.9.1.0 contains the bundled firmware for the Cisco 3600 and Cisco 3700 series.
6 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Cisco AS5200 Compatibility Information
The following sections contain compatibility information for the Cisco AS5200 universal access server listed by portware version.
Note
Table 2 Cisco AS5200 Portware Feature-to-Cisco IOS Software Compatibility Matrix
V.90
•
•
•
•
•
•
•
•
11.3(6)T1, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI15, 12.1(1), 12.1(1)AA
V.34
•
•
•
•
•
•
•
•
•
•
•
11.3(2)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI15, 12.0(5)T5, 12.1(1), 12.1(1)AA
K56flex
•
•
•
•
•
•
•
•
•
•
11.3(2)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI15, 12.0(5)T5, 12.1(1), 12.1(1)AA
V.110 terminal adapter
•
•
•
•
•
12.0(5)T5 , 12.1(1), 12.1(1)AA
SS7 support when used with Cisco SC2200
•
•
•
•
•
•
•
11.3(7)AA2, 12.0(3)T, 12.0(4)XJ, 12.0(4)XI13, 12.1(1), 12.1(1)AA
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
•
•
•
RFC-2217 dialout support for fax/data
Note
•
•
•
•
•
•
•
•
11.3(6)T1, 11.3(6)AA1, 12.0(2), 12.0(2)T, 12.0(4)XJ, 12.0(4)XI15, 12.0(5)T5, 12.1(1), 12.1(1)AA
R1 support
•
•
•
•
•
•
•
•
•
11.3(3)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI15, 12.0(5)T5, 12.1(1), 12.1(1)AA
1 See Table 3 for recommended portware-to-Cisco IOS software combinations.
2 V.92 and V.44 are not supported on the Cisco AS5200 platform.
3 Cisco MICA Portware Version 2.7.2.0 is backward compatible with Cisco IOS software releases prior to 12.(3)T, but some features are only available with the specific Cisco IOS software releases listed.
4 Cisco MICA Portware Version 2.7.1.0 requires minimum Cisco IOS Software Release 12.0(4)XI1, 12.0(5)T, or 12.1(1)
5 You can use the spe configuration command to download portware for Cisco IOS Software Releases 12.0(4)XI1, 12.0(5)T, and higher
6 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Table 3 Recommended Cisco AS5200 Portware Features/Cisco IOS Software Combinations
V.90
•
•
•
12.0, 12.1, 12.1AA
V.34
•
•
•
12.0, 12.1, 12.1AA
K56flex
•
•
•
12.0, 12.1, 12.1AA
V.110 terminal adapter
•
•
•
12.1, 12.1 AA
SS7 support when used with Cisco SC2200
•
•
•
12.1, 12.1 AA
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
12.1, 12.1 AA
R1 support
•
•
•
12.0, 12.1, 12.1AA
RFC-2217 dialout support for fax/data
Note
•
•
•
12.0, 12.1, 12.1AA
1 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Note
Cisco AS5300 Compatibility Information
The following sections contain compatibility information for the Cisco AS5300 universal access server listed by portware version. Use the following tables to match portware versions to the tested minimum Cisco IOS Software Release.
Note
Note
Table 5 Cisco AS5300 Portware Feature-to-Cisco IOS Software Matrix
V.92
•
•
•
•
•
12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T2 , 12.2, 12.2T, 12.3, and 12.3T
V.44
•
•
•
12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T2, 12.2, 12.2T, 12.3, and 12.3T
V.90
•
•
•
•
•
•
•
•
•
•
11.2P, 11.3(6)T1, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI1, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
V.34
•
•
•
•
•
•
•
•
•
•
•
•
•
11.2P, 11.3(2)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI1, 12.0(5)T, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
K56flex
•
•
•
•
•
•
•
•
•
•
•
•
11.2P, 11.3(2)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI1, 12.0(5)T, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
V.110 terminal adapter
•
•
•
•
•
•
•
11.2P, 12.0(5)T5 , 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T. and higher
SS7 support when used with Cisco SC2200
•
•
•
•
•
•
•
•
•
11.2P, 11.3(7)AA2, 12.0(3)T, 12.0(4)XJ, 12.0(4)XI1, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
•
•
•
•
•
11.2P, 12.0(4)XI1, 12.0(5)T, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
R1 support
•
•
•
•
•
•
•
•
•
•
•
11.2P, 11.3(3)T, 11.3(6)AA1, 12.0(1), 12.0(1)T, 12.0(4)XJ, 12.0(4)XI1, 12.0(5)T, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
RFC-2217 dialout support for fax/data
Note
•
•
•
•
•
•
•
•
•
•
11.2P, 11.3(6)T1, 11.3(6)AA1, 12.0(2), 12.0(2)T, 12.0(4)XJ, 12.0(4)XI1, 12.0(5)T, 12.1(1), 12.1(1)T, 12.1(1)AA, 12.1(5)T, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS)7
Support for Version 2.1.
•
12.2(2)XA, 12.2(2)XB
Note
Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS)7
Support for Version 2.0
•
12.1(5)T
Personal Handyphone (PHS) Internet Access Forum Standard (PIAFS)7
Support for Version 2.0
•
12.1(2a)XH
1 For V.92 and V.44, the capabilities exchange is only supported in 12.2(2)XB6 and higher releases. If you are using Cisco IOS Release 12.2(2)XA, 12.2(2)XB5, or earlier releases, you must modify S54 in a modemcap to enable V.92 and V.44 operation as described in the capabilities exchange enhancements documented in the
Release Notes for Cisco MICA Portware Version 2.9.2.0 on Cisco AS5300 and Cisco AS5800 Universal Access Servers.2 The Cisco 3600 and Cisco 3700 support V.92 and V.44 in Cisco IOS Release 12.2(11)YT and 12.2(15)T. Cisco AS5x00 platforms support V.92 and V.44 in 12.2(11)T.
3 Cisco MICA Portware Version 2.7.2.0 is backward compatible with Cisco IOS software releases prior to 12.(3)T, but some features are only available with the specific Cisco IOS software releases listed.
4 Cisco MICA Portware Version 2.7.1.0 requires minimum Cisco IOS Software Release 12.0(4)XI1, 12.0(5)T, or 12.1(1)
5 You can use the spe configuration command to download portware for Cisco IOS Software Releases 12.0(4)XI1, 12.0(5)T, and higher
6 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.7 Cisco MICA Portware Version 8.2.x.x is a special release for PIAFS support only. PIAFS is an error-correcting link layer protocol used in Japan over PHS digital server networks. PIAFS is supported on Cisco AS5300 universal access servers. Cisco MICA Portware Version 8.2.x.x only supports PIAFS and does not support other modem modulations or standards. Contact your account representative for information about obtaining Cisco MICA portware for PIAFS.
Note
Table 6 Recommended Cisco AS5300 Portware Features/Cisco IOS Software Combinations
V.92
•
•
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T2 , 12.2, 12.2T, 12.3, 12.3T
V.44
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T2, 12.2, 12.2T, 12.3, 12.3T
V.90
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB6, 12.2(1)T, and higher
V.34
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
K56flex
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
V.110 terminal adapter
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
SS7 support when used with Cisco SC2200
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
R1 support
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
RFC-2217 dialout support for fax/data
Note
•
•
•
12.1 mainline, 12.2 mainline, 12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, and higher
PIAFS4
•
•
•
12.2 mainline
1 For V.92 and V.44, the capabilities exchange is only supported in 12.2(2)XB6 and higher releases. If you are using Cisco IOS Release 12.2(2)XA, 12.2(2)XB5, or earlier releases, you must modify S54 in a modemcap to enable V.92 and V.44 operation as described in the capabilities exchange enhancements documented in the
Release Notes for Cisco MICA Portware Version 2.9.2.0 on Cisco AS5300 and Cisco AS5800 Universal Access Servers.2 The Cisco 3600 and Cisco 3700 support V.92 and V.44 in Cisco IOS Release 12.2(11)YT and 12.2(15)T. Cisco AS5x00 platforms support V.92 and V.44 in 12.2(11)T.
3 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.4 Cisco MICA Portware Version 8.2.x.x is a special release for PIAFS support only. PIAFS is an error-correcting link layer protocol used in Japan over PHS digital server networks. PIAFS is supported on Cisco AS5300 universal access servers. Cisco MICA Portware Version 8.2.x.x only supports PIAFS and does not support other modem modulations or standards. Contact your account representative for information about obtaining Cisco MICA portware for PIAFS.
Table 7 Cisco AS5300 Cisco IOS Software Bundled Portware
2.9.4.0
12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, 12.2(11)T, 12.2(15)T, 12.2, 12.2T, 12.3, 12.3T
2.9.2.01
12.2(2)XA, 12.2(2)XB, 12.2(2)XB, 12.2(2)XB6, and higher
2.9.1.01
12.2(2)XA, 12.2(2)XB, 12.2(11)T, 12.2(15)T, and higher
2.7.4.0
12.2T
2.7.3.0
12.2(2)XA, 12.2(2)XB
2.7.2.0
12.0(5)T, 12.1(1), 12.1(1)T, 12.1(5)T
2.7.1.0
12.1(1), 12.1(1)T
2.6.2.0
11.3(11)AA, 12.0(4)XJ, 12.0(5)T, 12.0(4)XI
2.5.1.0
11.2(18)P, 11.3(8)T, 11.3(8)AA, 12.0(3), 12.0(3)T
2.3.1.0
11.2(16)P, 11.3(5)T, 11.3(5)AA, 12.0(1), 12.0(1)T
2.0.1.7
11.2(9)XA1, 11.2(9)P1, 11.3(2)T, 11.3(4)AA
1 Support for V.92 and V.44 on the Cisco 3600 series and Cisco 3700 series has been added with Cisco IOS Release 12.2(11)YT and Cisco IOS Release 12.2(15)T. Cisco MICA Version 2.9.1.0 is the bundled portware with the Cisco IOS software.
Cisco AS5800 Compatibility Information
The following sections contain compatibility information for the Cisco AS5800 universal access server listed by portware version. Use the following tables to match portware versions to the tested minimum Cisco IOS Software Release.
Note
Table 8 Cisco AS5800 Portware Feature-to-Cisco IOS Software Matrix
V.92
•
•
•
•
•
12.2(2)XB1, 12.2(2)XB6, 12.2(11)T1 , 12.2, 12.2T, 12.3, 12.3T
V.44
•
•
•
12.2(2)XB1, 12.2(2)XB6, 12.2(11)T1, 12.2, 12.2T, 12.3, 12.3T
V.90
•
•
•
•
•
•
•
•
•
11.3(6)AA1, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
V.34
•
•
•
•
•
•
•
•
•
•
•
•
11.3(6)AA1, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
K56flex
•
•
•
•
•
•
•
•
•
•
•
11.3(6)AA1, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
V.110 terminal adapter
•
•
•
•
•
•
12.0(5)T13 , 12.1(1),12.1(1)T, 12.1(5)T
SS7 support when used with Cisco SC2200
•
•
•
•
•
•
•
•
11.3(7)AA2, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
•
•
•
•
12.0(5)T13, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
R1 support
•
•
•
•
•
•
•
•
•
•
11.3(6)AA1, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
RFC-2217 dialout support for fax/data
Note
•
•
•
•
•
•
•
•
•
11.3(6)AA1, 12.0(5)T1, 12.0(4)XJ, 12.1(1),12.1(1)T, 12.1(5)T
1 The Cisco 3600 and Cisco 3700 support V.92 and V.44 in Cisco IOS Release 12.2(11)YT and 12.2(15)T. Cisco AS5x00 platforms support V.92 and V.44 in 12.2(11)T.
2 Cisco MICA Portware Version 2.7.2.0 is backward compatible with Cisco IOS software releases prior to 12.(3)T, but some features are only available with the specific Cisco IOS software releases listed.
3 You can use the spe configuration command to download portware for Cisco IOS Software Releases 12.0(4)XI1, 12.0(5)T, and higher.
4 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Table 9 Recommended Cisco AS5800 Portware Features/Cisco IOS Software Combinations
V.92
•
•
•
•
•
12.2(2)XB1, 12.2(2)XB6, 12.2(11)T1 , 12.2, 12.2T, 12.3, 12.3T
V.44
•
•
•
12.2(2)XB1, 12.2(2)XB6, 12.2(11)T1, 12.2, 12.2T, 12.3, 12.3T
V.90
•
•
•
12.1 mainline, 12.2 mainline
V.34
•
•
•
12.1 mainline, 12.2 mainline
K56flex
•
•
•
12.1 mainline, 12.2 mainline
V.110 terminal adapter
•
•
•
12.1 mainline, 12.2 mainline
SS7 support when used with Cisco SC2200
•
•
•
12.1 mainline, 12.2 mainline
Resource Pool Management (RPM) and RPM Server (RPMS)
•
•
•
12.1 mainline, 12.2 mainline
RFC-2217 dialout support for fax/data
Note
•
•
•
12.1 mainline, 12.2 mainline
R1 support
•
•
•
12.1 mainline, 12.2 mainline
1 The Cisco 3600 and Cisco 3700 support V.92 and V.44 in Cisco IOS Release 12.2(11)YT and 12.2(15)T. Cisco AS5x00 platforms support V.92 and V.44 in 12.2(11)T.
2 See the following CDU replacement information:
The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
Note
Product Numbers and Spares for Cisco AS5200, AS5300, and AS5800
Table 11 Cisco AS5x00 Portware/DSP Product Numbers
2.9.4.0
DM-SW-2.9.4.0
DM-SW-2.9.4.0=
mica-modem-pw.2.9.4.0
2.9.2.0
DM-SW-2.9.2.0
DM-SW-2.9.2.0=
mica-modem-pw.2.9.2.0
2.9.1.0
DM-SW-2.9.1.0
DM-SW-2.9.1.0=
mica-modem-pw.2.9.1.0
2.7.4.0
DM-SW-2.7.4.0
DM-SW-2.7.4.0=
mica-modem-pw.2.7.4.0
2.7.3.0
DM-SW-2.7.3.0
DM-SW-2.7.3.0=
mica-modem-pw.2.7.3.0
2.7.2.01
DM-SW-2.7.2.0
DM-SW-2.7.2.0=
mica-modem-pw.2.7.2.0
2.7.1.0
DM-SW-2.7.1.0
DM-SW-2.7.1.0=
mica-modem-pw.2.7.1.0
2.6.1.0
DM-SW-2.6.1.0
DM-SW-2.6.1.0=
mica-modem-pw.2.6.1.0
2.6.2.0
DM-SW-2.6.2.0
DM-SW-2.6.2.0=
mica-modem-pw.2.6.2.0
2.5.1.0
DM-SW-2.5.1.0
DM-SW-2.5.1.0=
mica-modem-portware.2.5.1.0
2.3.1.0
DM-SW-2.3.1.0
DM-SW-2.3.1.0=
mica-modem-pw.2.3.1.0
2.2.3.0
DM-SW-2.2.3.0
DM-SW-2.2.3.0=
mica-modem-portware.2.2.3.0
2.0.1.7
DM-SW-2.0.1.7
DM-SW-2.0.1.7=
mica-modem-portware.2.0.1.7
1 Cisco MICA Portware Version 2.7.2.0 is orderable with Cisco IOS Software Release 12.1(1)T only.
Cisco 3600 and Cisco 3700 Compatibility Information
Table 12 Minimum Cisco 3600 and Cisco 3700 Series Cisco IOS Software Versions Supporting Cisco MICA Portware
Cisco 3620, Cisco 3640, Cisco 3660, Cisco 3725, and Cisco 3745 with Cisco IOS Release 12.2, 12.2T, 12.3, and 12.3T.
2.9.10 or 2.9.4.0
Note
The Cisco 3600 series and Cisco 3700 series is supported in Cisco MICA Portware Version 2.9.1.0 through Version 2.9.4.0.All Cisco 3600 series and Cisco 3700 series; all supported Cisco IOS Software versions including 12.2, 12.2T, 12.3, and 12.3T
2.9.2.01 and 2.7.4.0
Note
Note
Cisco 3600 series with Cisco IOS Software V.110 support—12.1(5+)T, 12.2, 12.2T, 12.3, and 12.3T
2.9.2.0, 2.7.x.0 (V.110).
Cisco 3600 series with Cisco IOS Software V.90 support—11.2(16+)P, 12.0(1+)T, 12.1(5+)T, 12.3(1), and 12.3(2)T
2.9.2.0, 2.9.4.0 (V.90)
3620 with NM-*CT1/CE1—11.2(16+)P
2.5.1.0 through 2.7.4.0, and 2.9.2.0.
3640 only—11.3(5+)T, 12.0(1+), and 12.0(1+)T
3640 with NM-*BRI—12.0(3+)T
3640 with NM-*CT1/CE1—11.2(16+)P
3660: 12.0(7)XK, 12.2, 12.2T, 12.3, and 12.3T
1 On all Cisco IOS software platforms that support Cisco MICA portware but that do not support V.92 and V.44, Cisco MICA portware 2.9.2.0 and follow on releases are supported as long as V.92 and V.44 are disabled in the configuration.
Related Links
For more portware/firmware information, see the following URLs:
•
•
•
•
•
•
•
•
•
•
•
Note
•
•
•
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:
Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
Guest
