Release Notes for Cisco 827 Routers
This document describes new and changed information for the Cisco 827 Routers Hardware Installation Guide and the Cisco 827 Routers Software Configuration Guide.
For last-minute updates to this release note, refer to the Cisco 827 routers documentation Web site at http://www.cisco.com/univercd/cc/td/doc/product/access/acs_fix/index.htm.
ADSL Cable Requirements
The ADSL cable that you connect to the Cisco 827 router must be 10BaseT Category 5, unshielded twisted-pair (UTP) cable. Using regular telephone cable can introduce line errors.
DHCP Client Support
Follow these steps to configure the router for DHCP client support:
Step 1
Configure the BVI interface by entering the ip address dhcp client-id Ethernet 0 command.
Specifying the value client-id ethernet0 means that the MAC address of the Ethernet interface is used as the client ID when the DHCP request is sent. Otherwise, the MAC address of the BVI interface is used as the client ID.
Step 2
a.
b.
c.
d.
ip nat inside source list 1 interface BVI 1 overload command.Step 3
a.
b.
Configuration Example
The following example shows a configuration of the DHCP client.
Current configuration:!version 12.0no service padservice timestamps debug uptimeservice timestamps log uptimeno service password-encryption!hostname c827!!ip subnet-zeroip dhcp excluded-address 10.10.10.1!ip dhcp pool SERVERnetwork 10.10.10.0 255.255.255.0default-router 10.10.10.1import all!bridge irbinterface Ethernet0ip address 10.10.10.1 255.255.255.0no ip directed-broadcastip nat inside!interface ATM0no ip addressno ip directed-broadcastno atm ilmi-keepalivebundle-enablehold-queue 208 in!interface ATM0.1 point-to-pointno ip directed-broadcastpvc 1/100encapsulation aal5snap!bridge-group 1!interface ATM0.2 point-to-pointip address 5.0.0.2 255.0.0.0no ip directed-broadcastpvc 1/101protocol ip 5.0.0.1 broadcastprotocol ip 5.0.0.5 broadcastencapsulation aal5snap!!interface BVI1ip address dhcp client-id Ethernet0no ip directed-broadcastip nat outside!ip nat inside source list 1 interface BVI1 overloadip classlessip route 0.0.0.0 0.0.0.0 BVI1no ip http server!access-list 1 permit 10.10.10.0 0.0.0.255bridge 1 protocol ieeebridge 1 route ip!voice-port 1timing hookflash-in 0!voice-port 2timing hookflash-in 0!voice-port 3timing hookflash-in 0!voice-port 4timing hookflash-in 0!!line con 0exec-timeout 0 0transport input nonestopbits 1line vty 0 4password lablogin!scheduler max-task-time 5000endDialer Interface Configuration
The "Configuring the Dialer Interface" section in Chapter 3, "Feature-By-Feature Router Configurations," of the Cisco 827 Routers Software Configuration Guide has an incorrect router prompt in Step 4. The prompt should be Router(config-if).
Easy IP (Phase 1) Configuration
The "Configuring Easy IP (Phase 1)" section in Chapter 3, "Feature-By-Feature Router Configurations," of the Cisco 827 Routers Software Configuration Guide has an incorrect reference in Step 2. The task should refer to the access list defined in Step 1 rather than in Step 2.
MMI Support
The Modem Management Interface (MMI) is software that enables auto-provisioning for the Cisco 827 routers. The MMI uses a fixed PVC to communicate with the Proxy Element (PE) residing on the digital subscriber line access multiplexer (DSLAM). Using MMI, the Cisco 827 router updates the running image and downloads the prescribed configuration using a configuration file or configuration values in a provisioning information database.
Configuring MMI for Auto-Provisioning
The customer premise equipment (CPE) can be automatically configured using the Cisco DSL CPE download, but it can be configured only with the image provisioning feature. The following provisioning configuration files are not supported in this release:
•
•
•
Follow these steps to configure the router for MMI support in configure-terminal mode:
Step 1
mmi auto-configure
no mmi auto-configure
If this parameter is enabled, the router is provisioned by the PE. By default, this parameter is enabled.
If this parameter is disabled, the router is configured by the start up configuration file.
Step 2
mmi polling-interval time
where time is the number of seconds. The polling-interval range is from 1 to 65535, with the default set to 60 seconds.
Step 3
mmi pvc vpi/vci
where vpi/vci is the virtual path identifier/virtual channel identifier. The default PVC for MMI is 0/16 ilmi, but if it is not available, you must set the specific PVC for the router to communicate with the PE.
Step 4
mmi snmp-timeout time
where time is 1 to 1800 seconds, which is the allowed interval to download any two consecutive blocks. If you enter the no mmi snmp-timeout command, the default time is set to 180 seconds.
Step 5
dsl operating-mode auto
If the DSLAM is using a Cisco 4xDMT ADI-based card, enter the following command:
dsl operating-mode ansi-dmt
Step 6
debug mmi
Step 7
MMI Configuration Example
The following example shows an MMI configuration:
820-voice1#sh runBuilding configuration...Current configuration :947 bytes!version 12.1no service single-slot-reload-enableno service padservice timestamps debug uptimeservice timestamps log uptimeno service password-encryption!hostname 820-voice1!no logging bufferedno logging bufferedlogging rate-limit console 10 except errors!mmi polling-interval 1000no mmi auto-configuremmi pvc 0/16debug mmiip subnet-zerono ip finger!!!interface Ethernet0no ip addressshutdown!interface Virtual-Template1no ip address!interface ATM0no ip addresspvc 0/101!bundle-enabledsl operating-mode auto!ip classlessno ip http server!snmp-server manager!voice-port 1!voice-port 2!voice-port 3!voice-port 4>line con 0transport input nonestopbits 1line vty 0 4login!scheduler max-task-time 5000endNotes for the DSL Provider
To use the Cisco automated configuration solution with the Cisco 827 CPEs, follow these steps:
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
For more information on the Cisco DSL CPE image provisioning, refer to the following documents:
•
•
Multilink PPP and Interleaving
Multilink PPP fragments large data packets so that small voice packets can be interleaved within them. However, apart from first-in-first-out (FIFO) queuing, no other kind of output queuing mechanisms are currently supported with PPP over ATM. Consequently, when multilink PPP is configured on the Cisco 827 routers, the big packets are fragmented, but interleaving of small voice packets within them does not occur.
NAT Support for H.323 Signaling
Currently, NAT does not support alerting H.225 messages. Therefore, NAT communication cannot be established between the router end points.
NAT support for H.323 signaling is limited to the Netmeeting application.
PPP over AAL5SNAP Encapsulation Support
PPP over AAL5SNAP encapsulation is currently not supported, although the context-sensitive help mentions that it can be configured.
PPP over Ethernet Support
This feature supports the PPP over Ethernet (PPPoE) client on an ATM permanent virtual circuit (PVC). Only one PPPoE client on a single ATM PVC is supported. The PPPoE client over an ATM interface is supported for all 820 platforms.
The following figure depicts a typical deployment scenario for PPPoE support:
Figure 1 PPPoE Deployment Scenarios
A PPPoE session is initiated on the client side by the network described above. If the session has a timeout or is disconnected, the PPPoE client immediately attempts to reestablish the session.
Follow these steps to configure the router for PPPoE client support:
Step 1
Note
a.
b.
c.
d.
Step 2
a.
b.
c.
Step 3
a.
b.
c.
d.
e.
Note
If you enter the clear vpdn tunnel pppoe command with a PPPoE client session already established, the PPPoE client session terminates and the PPPoE client immediately tries to reestablish the session.
Configuration Example
The following example shows a configuration of a PPPoE client on a router running a Cisco IOS release prior to Cisco IOS release 12.2(13)T.
vpdn enablevpdn-group 1request-dialinprotocol pppoeint atm0pvc 1/100pppoe-client dial-pool-number 1int dialer 1ip address negotiatedppp authentication chapdialer pool 1dialer-group 1The following example shows a configuration of a PPPoE client on a router running Cisco IOS release 12.2(13)T or higher.
int atm0pvc 1/100pppoe-client dial-pool-number 1int dialer 1ip address negotiatedppp authentication chapdialer pool 1dialer-group 1Obtaining Documentation
