Release Notes for Cisco Signaling Link Terminal for Cisco IOS Release 12.0 XR
February 27, 2002
These release notes describe Cisco Signaling Link Terminal (SLT), which is designed to perform SS7 signal pre-processing for a Cisco Media Gateway Controller. The Cisco SLT consists of a customized Cisco IOS Release 12.0(7)XR4 image running on a Cisco 2611 router. These release notes are updated as needed to describe new features, memory requirements, hardware support, and related document changes.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
The Cisco Signaling Link Terminal (SLT) enables service providers to reliably transport Signaling System 7 (SS7) protocols across an IP network. The Cisco SLT uses the Cisco IOS SS7 Signaling Link Terminal feature set, providing reliable interoperability with the Cisco Media Gateway Controller. The Cisco SLT is responsible for terminating the Message Transfer Part (MTP) 1 and MTP 2 layers of the SS7 protocol stack. Using Cisco's Reliable User Datagram Protocol (RUDP), the Cisco SLT backhauls, or transports, upper-layer SS7 protocols across an IP network to the Cisco SC or Cisco VSC.
In combination with this application-specific version of the Cisco IOS software, the Cisco SLT hardware component leverages the widely deployed Cisco 2600 multiservice access router. The Cisco 2600 series, driven by a powerful RISC processor, provides the high performance required in complex networking infrastructures.
When used for Signal Link Terminal applications, the modular Cisco 2611 dual-Ethernet port router can be configured with dual serial as well as the multiflex interface cards. The E1 multiflex interface cards offer integrated DSUs while the T1 multiflex interface cards offer integrated CSU/DSUs. For additional flexibility, the multiflex interface cards can also be ordered with a dual-port drop-and-insert capability. All of these interface cards are Field Replaceable Units (FRUs).
The Cisco SLT supports only the SS7 MTP 2 serial protocol. Therefore, the serial interfaces cannot be configured for other protocols such as HDLC, PPP, X.25, LAPB, and Frame Relay.
The Cisco SLT functions as a component of several solutions currently under development. Participants in lab trials can obtain solution documentation from their Cisco representative. See the "Service and Support" section for more information.
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0(7)XR4:
•
Determining Your Software Release
Memory Requirements
Enter
Table 1 Memory Requirements for the Cisco 2611 with Cisco SLT
DRAM
Memory
FromIP/SS7
c2600-ipss7-mz
16 MB
48 MB
RAM
Hardware Supported
Cisco IOS Release 12.0(7)XR4 supports the Cisco 2611 series routers exclusively. The Cisco SLT feature is not supported with any other Cisco 2600 series chassis.
Table 2 Supported Interfaces for the Cisco SLT Solution Data Rate
2-port Ethernet (10BaseT)
Cisco 2611
1-Port T1 multiflex trunk interface (VWIC-1MFT-T1)
All Cisco 2600 series platforms
1-Port E1 multiflex trunk interface (VWIC-1MFT-E1)
All Cisco 2600 series platforms
2-Port T1 multiflex trunk interface (VWIC-2MFT-T1)
All Cisco 2600 series platforms
2-Port E1 multiflex trunk interface (VWIC-2MFT-E1)
All Cisco 2600 series platforms
2-Port T1 multiflex trunk interface with drop-and-insert (VWIC-2MFT-T1-DI)
All Cisco 2600 series platforms
2-Port E1 multiflex trunk interface with drop-and-insert (VWIC-2MFT-E1-DI)
All Cisco 2600 series platforms
1-port High-Speed Serial (up to 2.048 Mbps)
All Cisco 2600 series platforms
2-port Dual High-Speed Serial (up to 2.048 Mbps; Asynchronous/ Synchronous support)
All Cisco 2600 series platforms
1 See E1/T1 Multiflex Voice/WAN Interface Cards in this table.
Determining Your Software Release
To determine the version of Cisco IOS software running on the Cisco SLT or any Cisco 2600 series router, log in to the router and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 2600 Software (c2600-ipss7-mz), Version 12.0(7)XR4, RELEASE SOFTWAREUpgrading to a New Release
For information on upgrading to Cisco IOS Release 12.0 T, see Cisco IOS Software Release 12.0T Upgrade Paths and Packaging Simplification product bulletin located on CCO at:
Service & Support: Software Center: Cisco IOS Software: Product Bulletins: Software.
Under Cisco IOS 12.0, click Cisco IOS Software Release 12.0T Upgrade (#819: 1/99).
This product bulletin does not contain information specific to Cisco IOS Release 12.0(7)XR4 but provides general upgrade information that may apply to Cisco IOS Release 12.0(7)XR4.
Feature Set Table
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Table 3 Feature Sets Supported by the Cisco SLT
Signaling Link Terminal
Basic with SS7
c2600-ipss7-mz
Cisco 2611 only
lists the features and feature sets supported by the Cisco IOS Release 12.0(7)XR for the Cisco 2611 with Cisco SLT.
The table uses the following conventions to identify features:
•
•
Note
Note
New and Changed Information
New Features
The following sections list the new features supported by the Cisco 2611 with Cisco SLT for Cisco IOS Release 12.0(7)XR4:
•
•
•
Important Notes
This section contains important information about use of your Cisco IOS Release 12.0(7)XR software.
Deprecated MIBs
Older Cisco Management Information Bases (MIBs) will be replaced in a future release. OLD-CISCO-* MIBS are currently migrated into more scalable MIBs, without affecting existing Cisco IOS products or NMS applications. Application developers should update from deprecated MIBs to the replacement MIBs as shown in the following table.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 and Release 12.0 T are also in Release 12.0 T.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0.
For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T, which lists severity 1 and 2 caveats and is located on CCO and the Documentation CD-ROM.
Note
Open Caveats—Cisco IOS Release 12.0(7) XR4
There are no open caveats specific to Cisco IOS Release 12.0(7) XR4 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.0(7) XR4
All the caveats listed in this section are resolved in Cisco IOS Release 12.0(7) XR4. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/pcgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Related Documentation
The following sections describe the documentation available for the Cisco 2600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with these documents:
•
Cisco SLT-Specific Documents
The following documents are specific to configuration of Cisco SLT on the Cisco 2611:
•
Solution-Specific Documents
Cisco SLT functions as a component of several solutions currently under development. Participants in lab trials can obtain solution documentation from their Cisco representative.
Release-Specific Documents
The following documents are specific to Cisco IOS Releases 12.0 T and 12.0, on which Release 12.0(7)XR is based. These documents are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see Caveats for Cisco IOS Release 12.0 T which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T. Caveats for Release 12.0(5)T apply to Release 12.0(7)XR.
On CCO:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Platform-Specific Documents
These documents are available for the Cisco 2600 series on CCO and on the Documentation CD-ROM:
•
•
•
•
•
•
•
•
•
•
•
•
•
On CCO:
Technical Documents: Documentation Home Page: Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers
On the Documentation CD-ROM:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.0 T and 12.0(7)XR, and updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
On CCO:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Cisco IOS Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set. The document set is available in electronic form and also in printed form upon request.
Note
On CCO:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References.
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet that shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on Cisco's Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/public/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
