Release Notes for the Packet Data Serving Node Service Manager, Release 4.1.1
OL-11462-01
January 2007
The Cisco Packet Data Serving Node Service Manager (PDSN SM) facilitates service-activation or deactivation in Cisco PDSN devices in Cisco Mobile Exchange networks.
These release notes contain important information for Release 4.1.1 of the PDSN SM. These notes include the installation procedure and information on resolved and open caveats.
Contents
This document covers the following topics:
•
Prerequisites for Installing the PDSN Service Manager
•
•
•
•
•
•
Introduction
A Cisco Packet Data Serving Node (PDSN) provides access to the Internet, intranets, and Wireless Application Protocol (WAP) servers for mobile stations that use a CDMA2000 radio access network (RAN).
The PDSN SM is an application that provides an easy and intuitive way to provision service activation or deactivation in Cisco PDSN devices in Cisco Mobile Exchange networks. You can also use the PDSN SM to troubleshoot and debug by using show and debug commands.
The PDSN SM includes:
•
•
•
The User Guide for Cisco Packet Data Serving Node Service Manager provides complete information on the PDSN SM. See Product Documentation, for information on accessing the electronic version of this document on the Cisco website.
The PDSN SM is part of the Mobile Wireless Center (MWC) for Cisco Mobile Exchange, a suite of element-management applications that provide configuration and fault-monitoring capabilities to mobile wireless operators. The MWC for Cisco Mobile Exchange applications complement the CiscoWorks LAN Management Solution (LMS) to manage the Cisco Mobile Exchange. The LMS is prerequisite to the MWC for Cisco Mobile Exchange.
The LMS 2.6 includes:
•
•
•
Note
Refer to the Release Notes for Mobile Wireless Center for Cisco Mobile Exchange Release for this release, http://www.cisco.com/en/US/products/ps6401/prod_release_notes_list.html, for information on the MWC for Cisco Mobile Exchange and the LMS requirement.
Prerequisites for Installing the PDSN Service Manager
Refer to the Release Notes for Mobile Wireless Center for Cisco Mobile Exchange for this release, http://www.cisco.com/en/US/products/ps6401/prod_release_notes_list.html, for information on MWC for Cisco Mobile Exchange hardware and software requirements, including information on Sun patches and package requirements.
Installing the PDSN Service Manager
This section contains information on:
•
•
•
Installation Order
The PDSN SM requires that the CiscoWorks Common Services application be bundled with the Release 2.6 of the LMS. The LMS is prerequisite to the MWC for Cisco Mobile Exchange.
For new installations, always install in this order:
1.
2.
3.
Note
cmxinstall.log.12012006_14:04:INFO: Package CSCO<pkgnam> - Installed. Verifying - Failed. Modifying - Done.
Ignore this message.The Release Notes for Mobile Wireless Center for Cisco Mobile Exchange for this release, http://www.cisco.com/en/US/products/ps6401/prod_release_notes_list.html, contains instructions for installing the LMS bundle and the CMX core. This section provides information on installing the PDSN SM.
Installation Procedure
To install the PDSN SM for the first time:
Step 1
Step 2
Step 3
Step 4
Step 5
./setup.shA confirmation message appears after a successful installation. If errors occur during installation, check the installation log file /var/tmp/pdsninstall.log.
Backing Up and Restoring Data
You can use the PDSN SM to back up and restore:
•
•
•
•
Use the Common Services (CS) back-up tool to back up and restore information. This tool backs up and restores CS and all applications registered with it.
Refer to the Release Notes for Mobile Wireless Center for Cisco Mobile Exchange Release at http://www.cisco.com/en/US/products/ps6401/prod_release_notes_list.html for information on this procedure.
Reinstalling the PDSN Service Manager
To reinstall the PDSN SM after an interrupted or failed installation attempt:
Step 1
Step 2
Step 3
prod_release_notes_list.html for information on this procedure.Step 4
Step 5
./setup.shA confirmation message appears after a successful installation. If errors occur during installation, check the installation log file: /var/tmp/pdsninstall.log.
Uninstalling the PDSN Service Manager
To uninstall PDSN SM:
Step 1
Step 2
cd /opt/CSCOpx/binStep 3
./uninstall.shThe script prompts you with a list of software that is installed in the host machine.
Step 4
A confirmation message appears after a successful uninstallation.
What's New in PDSN SM 4.1.1
In previous releases, you used the Service Activation and Batch Mode features to deploy batch configurations to devices on demand. In patch release 4.1.1, you can use a new feature, Batch Mode Scheduling, to schedule deployment of batch configurations at a future time. You can also monitor the configurations that you have scheduled.
You launch the Batch Mode Scheduling feature by clicking the:
•
•
Refer to the Release Notes for Mobile Wireless Center for Cisco Mobile Exchange Release 4.1.1 at http://www.cisco.com/en/US/products/ps6401/prod_release_notes_list.html for information on this procedure.
Caveats Resolved With This Release
Table 1 lists the ID number and a summary of each caveat closed with this release.
Table 1 Caveats Resolved With This Release
CSCsb3280
The Service Managers now control the size of the cmxTe.log file by adding that file to the Common Services logrot utility during installation of the Service Manager Core module. The cmxTe.log can increase rapidly if you have enabled devices for debugging and viewing Syslogs. If this file becomes larger than 10 MB, the logrot utility rotates the log file. If the rotation occurs while you are viewing the Debug window, you should close and reopen the window to observe the most recent log messages.
Find more information about the logrot utility at http://www.cisco.com/en/US/
products/sw/cscowork/ps3996/
products_user_guide_chapter
09186a008022f958.html#wp271846.CSCsb87801
You cannot use PDSN SM to select a suboption for show commands.
This bug has been resolved.
CSCsc17290
The AAA password configured user session parameters is visible when you click List.
When you click List to view the current user session configuration or Execute to configure the user session parameters (Service Manager > Service Activation > User Session Parameters), you can see the AAA password.
Workaround: None.
CSCsc19877
In User Session Parameters, when you configure the maximum mobile sessions as 20,000 (the default value), the field is blank. The corresponding command is generated and downloaded to the device, even though the value does not appear in the GUI.
This bug has been resolved.
CSCsd43594
The install script claims to be installing the Gateway GPRS Support Node Service Manager rather than the PDSN Service Manager.
This bug has been resolved.
CSCsb67002
When running more than one Service Manager simultaneously, log messages were being written to the log file of the Service Manager that was instantiated first.
This bug has been resolved.
CSCsd39538
The Restore function claims to be restoring the HA Service Manager rather than the PDSN Service Manager.
This bug has been resolved.
Open Caveats and Workarounds
Table 2 lists the ID number, summary, and any available workaround for each open caveat in this release.
Note
Supported Device Versions
Table 3 lists the devices that the PDSN SM supports.
You can find further information about all supported devices on Cisco.com at: http://www.cisco.com/univercd/cc/td/doc/product/rtrmgmt/cw2000/mgt_pix/fwmc_1_3/px_sd_13.htm
Prerequisites for Configuring PDSN Devices for Mobile IP
Before you configure a PDSN device by using the PDSN SM:
1.
2.
3.
4.
5.
6.
7.
For more information on the RME inventory function, see the "Adding and Troubleshooting Devices Using Device Management" section in the User Guide for Resource Manager Essentials 4.0.5 (With LMS 2.6) at http://www.cisco.com/en/US/products/sw/cscowork/ps2073/
products_installation_guide_book09186a008073d5dc.html. The specific section is here.8.
PDSN Configurations For Service Activation
You must configure the PDSN devices with the following configurations as a prerequisite to managing and configuring some service-activation commands by using PDSN SM:
Step 1
service cdma pdsnStep 2
router mobileip mobile foreign-agent care-of <Interface Name>ip mobile routerStep 3
aaa new-modelStep 4
If you do not require user login:
aaa authentication login default enableIf you do not require username and password:
aaa authentication login default localusername <login name> privilege <user privelege level> password <user password>Step 5
aaa authorization configuration default group radiusStep 6
Configure read-only (RO) community string:
snmp-server community <read community> ROConfigure read-write (RW) community string:
snmp-server community <write community> RWStep 7
Documentation Support
This section provides information on:
•
•
Note
Product Documentation and Related Documentation
This section provides information on:
Product Documentation
Table 4 lists the available product documentation.
Table 4 Product Documentation
User Guide for Cisco Packet Data Serving Node Service Manager
http://www.cisco.com/en/US/products/ps6696/
products_user_guide_list.htmRelease Notes for Cisco Packet Data Serving Node Service Manager (this document)
http://www.cisco.com/en/US/products/ps6696/
prod_release_notes_list.htmlContext-sensitive online help
•
•
Related Documentation
Table 5 lists available related documentation for the Cisco PDSN SM.
Table 5 Related Documentation
The Cisco Content Services Gateway documentation set
http://www.cisco.com/en/US/products/sw/wirelssw/ps779/
index.htmlRelease Notes for Mobile Wireless Center for Cisco Mobile Exchange for this release
http://www.cisco.com/en/US/products/ps6401/
prod_release_notes_list.htmlUser Guide for CiscoWorks Common Services 3.0.5 (With LMS 2.6)
http://www.cisco.com/en/US/products/sw/cscowork/ps3996/
products_user_guide_book09186a00806feda7.htmlUser Guide for Resource Manager Essentials 4.0.5 (With LMS 2.6)
http://www.cisco.com/en/US/products/sw/cscowork/ps2073/
products_user_guide_book09186a00806a52cb.html
Additional Information Online
Your application might support incremental device updates (IDUs). An IDU is a software package that enables an application to support new devices. An IDU might also contain bug fixes. You can download IDUs and their Readme files by logging into Cisco.com at http://www.cisco.com/kobayashi/sw-center/cw2000/lan-planner.shtml.
To determine which packages are installed on your CiscoWorks Server, go to your CiscoWorks page and choose Common Services > Software Center > Software Update.
You can also obtain any published patches from the download site.
You can find information about all supported devices on Cisco.com at http://www.cisco.com/univercd/cc/td/doc/product/rtrmgmt/cw2000/mgt_pix/fwmc_1_3/px_sd_13.htm.
