RADIUS Attribute 5 (NAS-Port) Format
Specified on a Per-Server Group Level

Contents

Prerequisites for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

Information About RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

RADIUS Attribute 5 Format Customization

How to Configure RADIUS Attribute 5 (NAS-Port)
Format Specified on a Per-Server Group Level

Configuring the RADIUS Attribute 5 Format on a Per-Server Group Level

Prerequisites

Monitoring and Maintaining RADIUS Attribute 5 Format on a Per-Server Group Level

Configuration Examples for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

RADIUS Attribute 5 Format Specified on a Per-Server Level: Example

Additional References

Related Documents

Standards

MIBs

RFCs

Technical Assistance

Command Reference

attribute nas-port format

RADIUS Attribute 5 (NAS-Port) Format
Specified on a Per-Server Group Level

---

First Published: March 28, 2005

Last Updated: March 20, 2006

The RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level feature allows you to customize configurations for different RADIUS server groups. This flexibility allows customized network access server- (NAS-) port formats to be used instead of global formats.

History for the RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level Feature

Release	Modification
12.3(14)T	This feature was introduced.
12.2(28)SB	This feature was integrated into Cisco IOS Release 12.2(28)SB.

Finding Support Information for Platforms and Cisco IOS Software Images

Use Cisco Feature Navigator to find information about platform support and Cisco IOS software image support. Access Cisco Feature Navigator at http://www.cisco.com/go/fn. You must have an account on Cisco.com. If you do not have an account or have forgotten your username or password, click Cancel at the login dialog box and follow the instructions that appear.

Contents

•Prerequisites for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

•Information About RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

•How to Configure RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

•Configuration Examples for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

•Additional References

•Command Reference

Prerequisites for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

•You must be running a Cisco IOS image that contains the authentication, authorization, and accounting (AAA) components.

Information About RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

To configure the RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level feature, you must understand the following concept:

•RADIUS Attribute 5 Format Customization

RADIUS Attribute 5 Format Customization

Prior to Cisco IOS Release 12.3(14)T, Cisco IOS software allowed RADIUS attributes that were sent in access requests or accounting requests to be customized on a global basis. You could customize how each configurable attribute should function when communicating with a RADIUS server. Since the implementation of server groups, global attribute configurations were not flexible enough to address the different customizations that were required to support the various RADIUS servers with which a router might be interacting. For example, if you configured the global radius-server attribute nas-port format command option, every service on the router that interacted with a RADIUS server was used in the same way.

Effective with Cisco IOS Release 12.3(14)T, you can configure your router to support override flexibility for per-server groups. You can configure services to use specific named methods for different service types on a RADIUS server. The service types can be set to use their own respective service groups. This flexibility allows customized NAS-port formats to be used instead of the global formats.

How to Configure RADIUS Attribute 5 (NAS-Port)
Format Specified on a Per-Server Group Level

This section contains the following procedures:

•Configuring the RADIUS Attribute 5 Format on a Per-Server Group Level

•Monitoring and Maintaining RADIUS Attribute 5 Format on a Per-Server Group Level

Configuring the RADIUS Attribute 5 Format on a Per-Server Group Level

To configure your router to support the RADIUS Attribute 5 format on a per-server group level, perform the following steps.

---

Note To use this per-server group capability, you must actively use a named method list within your services. You can configure one client to use a specific named method while other clients use the default format.

---

Prerequisites

Before performing these steps, you should first configure method lists for AAA as is applicable for your situation.

SUMMARY STEPS

1. enable

2. configure terminal

3. aaa group server radius group-name

4. server ip-address [auth-port port-number] [acct-port port-number]

5. attribute nas-port format format-type [string]

DETAILED STEPS

	Command or Action	Purpose
Step 1	enable Example: Router> enable	Enables privileged EXEC mode. •Enter your password if prompted.
Step 2	configure terminal Example: Router# configure terminal	Enters global configuration mode.
Step 3	aaa group server radius group-name Example: Router (config)# aaa group server radius radius1	Groups different RADIUS server hosts into distinct lists and distinct methods and enters server-group configuration mode.
Step 4	server ip-address [auth-port port-number] [acct-port port-number] Example: Router (server-group)# server 172.101.159.172 auth-port 1645 acct-port 1646	Configures the IP address of the RADIUS server for the group server.
Step 5	attribute nas-port format format-type [string] Example: Router (server-group)# attribute nas-port format d	Configures a service to use specific named methods for different service types. •The service types can be set to use their own respective server groups.

Monitoring and Maintaining RADIUS Attribute 5 Format on a Per-Server Group Level

To monitor and maintain RADIUS Attribute 5 Format on a Per-Server Group Level, perform the following steps (the debug commands may be used separately):

SUMMARY STEPS

1. enable

2. debug aaa sg-server selection

3. debug radius

DETAILED STEPS

	Command or Action	Purpose
Step 1	enable Example: Router> enable	Enables privileged EXEC mode. •Enter your password if prompted.
Step 2	debug aaa sg-server selection Example: Router# debug aaa sg-server selection	Displays information about why the RADIUS and TACACS+ server group system in a router is choosing a particular server.
Step 3	debug radius Example: Router# debug radius	Displays information showing that a server group has been selected for a particular request.

Configuration Examples for RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level

This section provides the following configuration example:

•RADIUS Attribute 5 Format Specified on a Per-Server Level: Example

RADIUS Attribute 5 Format Specified on a Per-Server Level: Example

The following configuration example shows a leased-line PPP client that has chosen to send no RADIUS Attribute 5 while the default is to use format d:

interface Serial2/0

 no ip address

 encapsulation ppp

 ppp accounting SerialAccounting

 ppp authentication pap

aaa accounting network default start-stop group radius

aaa accounting network SerialAccounting start-stop group group1

aaa group server radius group1

 server 10.101.159.172 auth-port 1645 acct-port 1646

 attribute nas-port none

radius-server host 10.101.159.172 auth-port 1645 acct-port 1646

radius-server attribute nas-port format d

Additional References

The following sections provide references related to RADIUS Attribute 5 (NAS-Port) Format Specified on a Per-Server Group Level.

Related Documents

Related Topic	Document Title
Cisco IOS commands	Cisco IOS Security Command Reference, Release 12.4
Configuring AAA and AAA method lists	"Authentication, Authorization, and Accounting (AAA)" section of Cisco IOS Security Configuration Guide, Release 12.3.

Standards

Standards	Title
None.	—

MIBs

MIBs	MIBs Link
None	To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs

RFCs

RFCs	Title
None	—

Technical Assistance

Description	Link
The Cisco Technical Support & Documentation website contains thousands of pages of searchable technical content, including links to products, technologies, solutions, technical tips, and tools. Registered Cisco.com users can log in from this page to access even more content.	http://www.cisco.com/techsupport

Command Reference

This section documents the following new command only.

•attribute nas-port format

attribute nas-port format

To configure services to use specific named methods for different service types, which can be set to use their own respective RADIUS server groups, use the attribute nas-port format command in server-group configuration mode. To remove the override, which is to use specific named methods for different service types, use the no form of this command.

attribute nas-port format format-type [string]

no attribute nas-port format format-type [string]

Syntax Description

format-type	Type of format (see Table 1).
string	(Optional) Pattern of the data format (see Table 2).

Defaults

Default format type is used for all services.

Command Modes

Server-group configuration

Command History

Release	Modification
12.3(14)T	This command was introduced.
12.2(28)SB	This command was integrated into Cisco IOS Release 12.2(28)SB.

Usage Guidelines

The following format types may be configured.

Table 1 Format Types

a	Format is type, channel, or port.
b	Either interface(16), isdn(16), or async(16).
c	Data format (bits): shelf(2), slot(4), port(5), or channel(5).
d	Data format (bits): slot(4), module(1), port(3), vpi(8), or vci(16).
e	Configurable data format (see Table 2).

The following characters may be used in the string pattern of the data format.

Table 2 Characters Supported by Format-Type e

0	Zero
1	One
f	DS0 shelf
s	DS0 slot
a	DS0 adapter
P	DS0 port
i	DS0 subinterface
c	DS0 channel
F	Async shelf
S	Async slot
P	Async port
L	Async line
S	PPPoX slot (includes PPP over ATM [PPPoA], PPP over Ethernet over ATM [PPPoEoA], PPP over Ethernet over Ethernet [PPPoEoE], PPP over Ethernet over VLAN [PPPoEoVLAN], and PPP over Ethernet over Queue in Queue [PPPoEoQinQ]).
A	PPPoX adapter
P	PPPoX port
V	PPPoX VLAN ID
I	PPPoX virtual path identifier (VPI)
C	PPPoX virtual channel indicator (VCI)
U	Session ID

Examples

The following example shows that a leased-line PPP client has chosen to send no RADIUS Attribute 5 while the default is set for format d:

interface Serial2/0

 no ip address

 encapsulation ppp

 ppp accounting SerialAccounting

 ppp authentication pap

aaa accounting network default start-stop group radius

aaa accounting network SerialAccounting start-stop group group1

aaa group server radius group1

 server 10.101.159.172 auth-port 1645 acct-port 1646

 attribute nas-port none

radius-server host 10.101.159.172 auth-port 1645 acct-port 1646

radius-server attribute nas-port format d

Related Commands

Command	Description
aaa group server radius	Groups different RADIUS server hosts into distinct lists and distinct methods.
ip radius source-interface	Forces RADIUS to use the IP adressing of a specified interface for all outgoing RADIUS packets.
radius-server host	Specifies a RADIUS server host.
