Release Notes for Cisco 7000 Family for Cisco IOS Release 12.3 YQ
August 8, 2007
Cisco IOS Release 12.3(14)YQ8
OL-7519-09
These release notes for the Cisco 7000 family describe the enhancements provided in Cisco IOS Release 12.3(14)YQ8. These release notes are updated as needed.
For a list of the software caveats that apply to Cisco IOS Release 12.3(14)YQ8, see the "Caveats for Cisco IOS Release 12.3 YQ" section and Caveats for Cisco IOS Release 12.3. The caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.3 located on Cisco.com and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
MIBs
•
•
System Requirements
This section describes the system requirements for Cisco IOS Release 12.3(14)YQ8 and includes the following sections:
•
•
Memory Recommendations
Supported Hardware
Cisco IOS Release 12.3(14)YQ8 supports the following Cisco 7000 platforms:
•
For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco 7000 family router, log in to the Cisco 7000 family router and enter the show version EXEC command. The following sample show version command output is from a router running a Cisco 7200 series software image with Cisco IOS Release 12.3(14)YQ8:
Router> show versionCisco IOS Software, 7301 Software (c7200-g8ik8s-mz), Version 12.3(14)YQ7, RELEASE SOFTWARE (fc1)Upgrading to a New Software Release
For information about selecting a new Cisco IOS software release, please refer to How to Choose a Cisco IOS Software Release at:
http://www.cisco.com/warp/public/130/choosing_ios.shtml
For information about upgrading to a new software release, refer to the appropriate platform-specific document:
•
http://www.cisco.com/en/US/products/hw/routers/ps133/products_tech_note09186a0080094c07.shtml
For Cisco IOS Upgrade Ordering Instructions, refer to the document at the following location:
http://www.cisco.com/warp/public/cc/pd/iosw/prodlit/957_pp.htm
To choose a new Cisco IOS software release by comparing feature support or memory requirements, use Cisco Feature Navigator. Cisco Feature Navigator is a web-based tool that enables you to determine which Cisco IOS and Catalyst OS software images support a specific set of features and which features are supported in a specific Cisco IOS image. You can search by feature or by feature set (software image). Under the release section, you can compare Cisco IOS software releases side by side to display both the features unique to each software release and the features that the releases have in common.
Cisco Feature Navigator is updated regularly when major Cisco IOS software releases and technology releases occur. For the most current information, go to the Cisco Feature Navigator home page at the following URL:
To choose a new Cisco IOS software release based on information about defects that affect that software, use Bug Toolkit at:
http://www.cisco.com/pcgi-bin/Support/Bugtool/launch_bugtool.pl.
Feature Support
Cisco IOS software is packaged in feature sets that consist of software images that support specific platforms. The feature sets available for a specific platform depend on which Cisco IOS software images are included in a release. Each feature set contains a specific set of Cisco IOS features.
Caution
The feature set tables have been removed from the Cisco IOS Release 12.3 release notes to improve the usability of the release notes documentation. The feature-to-image mapping that was provided by the feature set tables is available through Cisco Feature Navigator.
Cisco Feature Navigator is a web-based tool that enables you to determine which Cisco IOS software images support a specific set of features and which features are supported in a specific Cisco IOS image. You can search by feature or by feature set (software image). Under the release section, you can compare Cisco IOS software releases side by side to display both the features unique to each software release and the features that the releases have in common.
To access Cisco Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, send a blank e-mail to cco-locksmith@cisco.com. An automatic check will verify that your e-mail address is registered with Cisco.com. If the check is successful, account details with a new random password will be e-mailed to you. Qualified users can establish an account on Cisco.com by following the directions found at this URL:
Cisco Feature Navigator is updated regularly when major Cisco IOS software releases and technology releases occur. For the most current information, go to the Cisco Feature Navigator home page at the following URL:
For frequently asked questions about Cisco Feature Navigator, see the FAQs at the following URL:
http://www.cisco.com/support/FeatureNav/FNFAQ.html
Determining Which Software Images (Feature Sets) Support a Specific Feature
To determine which software images (feature sets) in Cisco IOS Release 12.3 support a specific feature, go to the Cisco Feature Navigator home page, enter your Cisco.com login, and perform the following steps:
Step 1
Step 2
Step 3
Note
Repeat this step to add additional features. A maximum of 20 features can be chosen for a single search.
Step 4
Step 5
Step 6
Step 7
Determining Which Features Are Supported in a Specific Software Image (Feature Set)
To determine which features are supported in a specific software image (feature set) in Cisco IOS Release 12.3, go to the Cisco Feature Navigator home page, enter your Cisco.com login, and perform the following steps:
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 7000 family of routers for Cisco IOS Release 12.3 YQ:
New Hardware Features in Cisco IOS Release 12.3(14)YQ8
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ8.
New Software Features in Cisco IOS Release 12.3(14)YQ8
There are no new software features supported in Cisco IOS Release 12.3(14)YQ8.
New Hardware Features in Cisco IOS Release 12.3(14)YQ7
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ7.
New Software Features in Cisco IOS Release 12.3(14)YQ7
There are no new software features supported in Cisco IOS Release 12.3(14)YQ7.
New Hardware Features in Cisco IOS Release 12.3(14)YQ6
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ6.
New Software Features in Cisco IOS Release 12.3(14)YQ6
There are no new software features supported in Cisco IOS Release 12.3(14)YQ6.
New Hardware Features in Cisco IOS Release 12.3(14)YQ5
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ5.
New Software Features in Cisco IOS Release 12.3(14)YQ5
There are no new software features supported in Cisco IOS Release 12.3(14)YQ5.
New Hardware Features in Cisco IOS Release 12.3(14)YQ4
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ4.
New Software Features in Cisco IOS Release 12.3(14)YQ4
There are no new software features supported in Cisco IOS Release 12.3(14)YQ4.
New Hardware Features in Cisco IOS Release 12.3(14)YQ3
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ3.
New Software Features in Cisco IOS Release 12.3(14)YQ3
There are no new software features supported in Cisco IOS Release 12.3(14)YQ3.
New Hardware Features in Cisco IOS Release 12.3(14)YQ2
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ2.
New Software Features in Cisco IOS Release 12.3(14)YQ2
There are no new software features supported in Cisco IOS Release 12.3(14)YQ2.
New Hardware Features in Cisco IOS Release 12.3(14)YQ1
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ1.
New Software Features in Cisco IOS Release 12.3(14)YQ1
There are no new software features supported in Cisco IOS Release 12.3(14)YQ1.
New Hardware Features in Cisco IOS Release 12.3(14)YQ
There are no new hardware features supported in Cisco IOS Release 12.3(14)YQ.
New Software Features in Cisco IOS Release 12.3(14)YQ
There are no new software features supported in Cisco IOS Release 12.3(14)YQ.
MIBs
To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL:
http://tools.cisco.com/ITDIT/MIBS/servlet/index
If Cisco MIB Locator does not support the MIB information that you need, you can also obtain a list of supported MIBs and download MIBs from the Cisco MIBs page at the following URL:
http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml
To access Cisco MIB Locator, you must have an account on Cisco.com. If you have forgotten or lost your account information, send a blank e-mail to cco-locksmith@cisco.com. An automatic check will verify that your e-mail address is registered with Cisco.com. If the check is successful, account details with a new random password will be e-mailed to you. Qualified users can establish an account on Cisco.com by following the directions found at this URL:
http://tools.cisco.com/RPF/register/register.do
Important Notes
The following sections contain important notes about Cisco IOS Release 12.3(14)YQ5 that can apply to the Cisco 7000 family.
Deferrals
Cisco IOS software images are subject to deferral. Cisco recommends that you view the deferral notices at the following location to determine if your software release is affected:
http://www.cisco.com/public/sw-center/sw-ios-advisories.shtml
Field Notices and Bulletins
For general information about the types of documents listed in this section, refer to the following document:
http://www.cisco.com/warp/public/cc/general/bulletin/software/general/1654_pp.htm
•
•
•
•
Caveats for Cisco IOS Release 12.3 YQ
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
This section contains only open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Cisco IOS Release 12.3 and Cisco IOS Release 12.3 T are also in Cisco IOS Release 12.3(14)YQ8.
For information on caveats in Cisco IOS Release 12.3, see Caveats for Cisco IOS Release 12.3.
For information on caveats in Cisco IOS Release 12.3 T, see Caveats for Cisco IOS Release 12.3 T, which lists severity 1 and 2 caveats and select severity 3 caveats and is located on Cisco.com and the Documentation CD-ROM.
Note
Open Caveats—Cisco IOS Release 12.3(14)YQ8
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ8 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) with an encrypted image may reload when having a heavy load.
This issue occurs only when the CPU is consistently over 96% for a long timeframe and is sending bi-directional data over all the IPSec tunnels at the same time, causing the IPSec card to reset.
Workaround: Configure Policing such that high unchecked data is not sent for long periods of time.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ8
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ8. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Symptoms: A router may crash if it receives a packet with a specific crafted IP option as detailed in Cisco Security Advisory: Crafted IP Option Vulnerability:
http://www.cisco.com/warp/public/707/cisco-sa-20070124-crafted-ip-option.shtml
Conditions: This DDTS resolves a symptom of CSCec71950. Cisco IOS with this specific DDTS are not at risk of crash if CSCec71950 has been resolved in the software.
Workaround: Cisco IOS versions with the fix for CSCec71950 are not at risk for this issue and no workaround is required. If CSCec71950 is not resolved, see the following Cisco Security Advisory: Crafted IP Option Vulnerability for workaround information:
http://www.cisco.com/warp/public/707/cisco-sa-20070124-crafted-ip-option.shtml
•
The Cisco IOS Transmission Control Protocol (TCP) listener in certain versions of Cisco IOS software is vulnerable to a remotely-exploitable memory leak that may lead to a denial of service condition.
This vulnerability only applies to traffic destined to the Cisco IOS device. Traffic transiting the Cisco IOS device will not trigger this vulnerability.
Cisco has made free software available to address this vulnerability for affected customers.
This issue is documented as Cisco bug ID CSCek37177.
There are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20070124-crafted-tcp.shtml
•
A Cisco Gateway GPRS Serving Node (GGSN) crashes while executing the show gprs gtp pdp tid command.
This issue occurs during multiple PDP creates and deletes.
Workaround: Avoid using the show gprs gtp pdp tid command.
•
The Intrusion Prevention System (IPS) feature set of Cisco IOS contains several vulnerabilities. These include:
–
–
There are mitigations and workarounds for these vulnerabilities. Cisco has made free software available to address these vulnerabilities for affected customers.
This advisory is posted at:
http://www.cisco.com/warp/public/707/cisco-sa-20070213-iosips.shtml.
•
A vulnerability exists in certain Cisco IOS software release trains running on the Cisco IAD2400 series, Cisco 1900 series Mobile Wireless Edge Routers and Cisco VG224 Analog Phone Gateways. Vulnerable versions may contain a default hard-coded Simple Network Management Protocol (SNMP) community string when SNMP is enabled on the device. The default community string is a result of inadvertently identifying these devices as supporting Data Over Cable Service Interface Specification (DOCSIS) compliant interfaces. The consequence of this error is that an additional read-write community string may be enabled if the device is configured for SNMP management, allowing a knowledgeable attacker the potential to gain privileged access to the device.
Cisco is making free software available to address this vulnerability for affected customers. There are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20060920-docsis.shtml.
•
A Cisco Gateway GPRS Serving Node (GGSN) reloads when certain rare passwords are used.
This issue occurs only when the create request is using the Virtual Access Point Name (APN) feature and the password contains the "@"character.
Workaround: Do not use the Virtual APN feature to get the real APN name if the username contains the "@" character; instead use the pre-authenticate Virtual APN feature.
•
A Cisco Gateway GPRS Serving Node (GGSN) running the R5.x/R6.0 image reloads when a secondary create PDP context request includes a traffic flow template (TFT) information element (IE) that contains the TFT code "No TFT operation" and the packet has a filter in it.
This issue occurs only when debug gprs gtp parsing is enabled.
There are no known workarounds.
Open Caveats—Cisco IOS Release 12.3(14)YQ7
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ7 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) with an encrypted image may reload when having a heavy load.
This issue occurs only when the CPU is consistently over 96% for a long timeframe and is sending bi-directional data over all the IPSec tunnels at the same time, causing the IPSec card to reset.
Workaround: Configure Policing such that high unchecked data is not sent for long periods of time.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ7
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ7. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
A router may crash when you shut down the Frame Relay interface of a peer.
This issue occurs only on a Cisco router that connects to the peer using a serial interface that has Frame Relay encapsulation and encryption enabled.
There are no known workarounds.
Open Caveats—Cisco IOS Release 12.3(14)YQ6
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ6 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) with an encrypted image may reload when having a heavy load.
This issue occurs only when the CPU is consistently over 96% for a long timeframe and is sending bi-directional data over all the IPSec tunnels at the same time, causing the IPSec card to reset.
Workaround: Configure Policing such that high unchecked data is not sent for long periods of time.
•
A MWAM Processor running IOS Release 12.3(14)YQ2 may experience an input queue high problem. If the input queue is kept in high level for a long time, new input packets may be dropped. If the image is without the CSCej48454 fix, input queue wedge could occur after arp entrees are aged.
This issue occurs under the following conditions:
–
–
–
The root cause of this issue is that the process is blocked in TCP write and can not take care of the queued data packets in a timely fashion. These packets pile up in the input queue and block new input packets.
Workaround: Load an image with the CSCej48454 fix (Cisco IOS Release 12.3(14)YQ4 or later).
Resolved Caveats—Cisco IOS Release 12.3(14)YQ6
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ6. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
A Cisco Gateway GPRS Serving Node (GGSN) may reload when executing the show aaa attribute protocol radius command.
This issue only occurs if the show aaa attribute protocol radius command is executed from the Command Line Interface.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) may reload under control and data traffic stress conditions.
This issue occurs when consecutive actions of create and delete requests for a large number PDP Contexts occur at a very high rate, especially when not enough time is allowed for all the contexts to be established or cleaned up properly.
There are no known workarounds.
•
In Cisco GGSN, when Interim Accounting is not configured, the updated values of SGSN address and QOS Negotiated do not appear in the Accounting-Stop message.
This issue occurs under the following conditions:
–
–
–
–
–
Workaround: Enable Interim Accounting under the APN.
•
A Cisco Gateway GPRS Serving Node (GGSN) is sending a wrong Message-length value for PAP Authenticate-Ack frames inside Create PDP Context Response messages. The Data field inside the Authenticate-Ack frame contains a one-byte Msg-Length subfield that specifies the length of the Message subfield that follows it. The Message subfield contains an arbitrary string of data whose use is implementation dependent. It may be used to provide an indication of authentication success or failure to the user. If not used, the Msg-Length field is still included, but its value is set to zero.
When looking into a sniffer trace you can see that Msg-Length subfield has not been included in the frame, and the incorrect value of Msg-Length equal to 65 (0x41) is the first letter (letter "A") in the message "Authentication successful".
This issue occurs when setting a message in the Message Field of PPP PAP. This does not have an operational impact as PAP authentication passes successfully, but it causes monitoring issues.
Workaround: Configure the command gprs gtp response-message pco ipcp message-length at global scope. This will cause the message length subfield to be included in the PAP Authenticate-Acl frame.
Open Caveats—Cisco IOS Release 12.3(14)YQ5
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ5 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) with an encrypted image may reload when having a heavy load.
This issue occurs only when the CPU is consistently over 96% for a long timeframe and is sending bi-directional data over all the IPSec tunnels at the same time, causing the IPSec card to reset.
Workaround: Configure Policing such that high unchecked data is not sent for long periods of time.
•
A Cisco Gateway GPRS Serving Node (GGSN) may reload when executing the show aaa attribute protocol radius command.
This issue occurs only if the show aaa attribute protocol radius command is executed from the Command Line Interface.
There are no known workarounds.
•
A MWAM Processor running IOS Release 12.3(14)YQ2 may experience an input queue high problem. If the input queue is kept in high level for a long time, new input packets may be dropped. If the image is without the CSCej48454 fix, input queue wedge could occur after arp entrees are aged.
This issue occurs under the following conditions:
–
–
–
The root cause of this issue is that the process is blocked in TCP write and can not take care of the queued data packets in a timely fashion. These packets pile up in the input queue and block new input packets.
Workaround: Load an image with the CSCej48454 fix (Cisco IOS Release 12.3(14)YQ4 or later).
•
A Cisco Gateway GPRS Serving Node (GGSN) may reload under control and data traffic stress conditions.
This issue occurs when consecutive actions of create and delete requests for a large number PDP Contexts occur at a very high rate, especially when not enough time is allowed for all the contexts to be established or cleaned up properly.
There are no known workarounds.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ5
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ5. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
There are no known resolved caveats for Cisco IOS Release 12.3(14)YQ5.
Open Caveats—Cisco IOS Release 12.3(14)YQ4
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ4 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
A Cisco Gateway GPRS Serving Node (GGSN) does not function properly when wait-accounting and AAA Broadcast Accounting are configured on an APN. When the first RADIUS server responds to an Accounting Start message, the GGSN establishes the PDP context without waiting for responses from all other RADIUS servers. Under a stress condition, the GGSN may reload.
This issue occurs on a Cisco platform that runs Cisco IOS Release 12.4 and GGSN Release 5.2 and occurs only when both wait-accounting and AAA Broadcast Accounting are configured together on an APN.
There are no known workarounds.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ4
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ4. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An unexpected bus error reload (that is, an illegal access to a low address) may occur in the RADIUS process.
This issue occurs on a Cisco 7200 series that is configured with an NPE-G1 and that runs Cisco IOS Release 12.3(9). However, this issue does not occur in Release 12.3(3).
There are no known workarounds.
•
When the GGSN receives a PDP context with non-real time traffic classes and the SSD value is not 1 (that is, speech), the PDP is rejected.
This issue occurs as a result of not being CR-830 compliant. To be compliant with CR-830, accept PDP context with non-real time classes for any value of SSD.
There are no known workarounds.
•
The GGSN interface inputq may lose communication
This issue occurs under the following conditions:
–
–
–
–
Workaround: Use config APN ACL to deny any user payload traffic that is addressed to an internal loopback address.
•
The TCP path between the charging gateway and Cisco GGSN flapping may drop some packets under the following conditions:
–
–
–
This issue occurs because while the GGSN can send 128 charging msg simultaneously, the TCP send window is only 20K bytes; so many of the packet are dropped before getting out of GGSN. After max retry and no response, GGSN will mark the charging gateway down.
Workaround: Reduce the number of msg that send simultaneously to less than 20 if TCP is used. This will make charging msg send slower but more reliable.
•
The Cisco IOS Stack Group Bidding Protocol (SGBP) feature in certain versions of Cisco IOS software is vulnerable to a remotely-exploitable denial of service condition. Devices that do not support or have not enabled the SGBP protocol are not affected by this vulnerability.
Cisco has made free software available to address this vulnerability for affected customers. There are workarounds available to mitigate the effects of the vulnerability.
Cisco has published a Security Advisory on this issue; it is available at http://www.cisco.com/warp/public/707/cisco-sa-20060118-sgbp.shtml
•
A Cisco Gateway GPRS Serving Node (GGSN) that functions under stress may reload unexpectedly.
This issue occurs when the call rate is high (200 calls per second), when there are two Dynamic Host Configuration Protocol (DHCP) servers that respond very slowly, and when the GGSN is configured for session redundancy.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) may unexpectedly reload if the following condition persists for a long time:
–
–
–
In some stress error conditions, GGSN enqueue an already free element into queue.
Workaround: Use a faster DHCP server or config the DHCP lease time longer in the DHCP server.
•
In Cisco IOS Release 12.3(14)YQ3 (Cisco GGSN Release 5.2), a PLMN and QoS change at the same time will cause a duplicated volume report. The same byte counts are reported in successive containers, one added due record closure due to PLMN change, and the other due to QoS Change.
No charging profile was configured under the APN because it is not service-aware (GGSN functionality testing). SGSN did not send any Charging-characteristics value.
Workaround: Use an APN specific charging profile.
•
In Cisco IOS GGSN Release 5.0 and 6.0, the router reloads when 3000 create requests are sent under the following conditions:
–
–
–
After about 3000 create requests, the router unexpectedly reloads.
There are no known workarounds.
Open Caveats—Cisco IOS Release 12.3(14)YQ3
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ3 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) running R5.2 shows incorrect behavior when wait-accounting is configured in an APN along with AAA broadcast accounting. When the first Radius server responds to Accounting Start, GGSN establishes the PDP context without waiting for responses from all other Radius servers. Sometimes under stress conditions, GGSN may reload.
This issue occurs only when both wait-accounting and AAA broadcast accounting are used together for an APN.
There are no known workarounds.
•
A Cisco Gateway GPRS Serving Node (GGSN) that functions under stress may reload unexpectedly.
This issue occurs when the call rate is high (200 calls per second), when there are two DHCP servers that respond very slowly, and when the GGSN is configured for session redundancy.
There are no known workarounds.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ3
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ3. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco GGSN does not clear the TCP socket from the GGSN to the charging gateway. This makes the GGSN unresponsive to Nodealive requests from the charging gateway if the Charging Functionality is under a lot stress, and the charging gateway is going up and down frequently, resulting in a lot of charging data records being queued.
Workaround: Execute the show tcp brief command to display the tcb value. Then enter the clear tcp tcb command to clear the tcb using the tcb value from the show tcp brief command command. Then send Nodealive from the charging gateway.
•
Cisco IOS may permit arbitrary code execution after exploitation of a heap-based buffer overflow vulnerability. Cisco has included additional integrity checks in its software, as further described below, that are intended to reduce the likelihood of arbitrary code execution.
Cisco has made free software available that includes the additional integrity checks for affected customers.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20051102-timers.shtml.
•
Cisco GGSN does not negotiate the Qos values properly when an wrong Qos profile of all 0's is sent in as a request in the R98 format.
There are no known workarounds.
•
In a Cisco Gateway GPRS Support Node (GGSN) running release 5.2 and 6.0 software, the CAUSE IE in PDP update-context-response from GGSN shall be set to 201 (Mandatory IE incorrect) upon receiving a PDP update-context-request with Max Bit-Rate (MBR) set to 0 KBPS.
This occurs when SGSN sends PDP update-context-request to GGSN with Uplink/Downlink Max Bit Rate (MBR) set to zero KBPS.
There are no known workarounds.
Open Caveats—Cisco IOS Release 12.3(14)YQ2
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ2 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco GGSN does not clear the TCP socket from the GGSN to the charging gateway. This makes the GGSN unresponsive to Nodealive requests from the charging gateway if the Charging Functionality is under a lot stress, and the charging gateway is going up and down frequently, resulting in a lot of charging data records being queued.
Workaround: Execute the show tcp brief command to display the tcb value. Then enter the clear tcp tcb command to clear the tcb using the tcb value from the show tcp brief command command. Then send Nodealive from the charging gateway.
•
CEF may not work over different tunnels.
This issue occurs when both GRE and IPIP tunnels are configured, and the packet traverses both.
There are no known workarounds.
•
A Cisco GGSN running R5.2 shows incorrect behavior when wait-accounting is configured in an APN along with AAA broadcast accounting. When the first Radius server responds to Accounting Start, GGSN establishes the PDP context without waiting for responses from all other Radius servers. Sometimes under stress conditions, GGSN may reload.
This issue occurs only when both wait-accounting and AAA broadcast accounting are used together for an APN.
There are no known workarounds.
•
The cgprsCgProfileVolumeLimit object accepts invalid values from SNMP.
This issue occurs when the value for cgprsCgProfileVolumeLimit is written using the setany command
There are no known workarounds.
•
Multiple voice-related vulnerabilities are identified in Cisco IOS software, one of which is also shared with Cisco Unified Communications Manager. These vulnerabilities pertain to the following protocols or features:
–
–
–
–
–
Cisco has made free software available to address these vulnerabilities for affected customers. Fixed Cisco IOS software listed in the Software Versions and Fixes section contains fixes for all vulnerabilities mentioned in this advisory.
There are no workarounds available to mitigate the effects of any of the vulnerabilities apart from disabling the protocol or feature itself.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20070808-IOS-voice.shtml
•
The Gateway GPRS support node (GGSN) may cause some packet looping with two GRE headers.
This issue is observed under the following conditions:
–
–
–
Workaround: Turn off cef or not use VRF. However, this is not recommended.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ2
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ2. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Charging characteristics selection mode is set to roaming default for a roaming user when there is no default profile on GGSN.
This issue occurs when there is no default profile in GGSN.
There are no known workarounds.
•
Radius accounting request packet from GGSN to Radius does not have CLASS attribute.
This issue occurs in pdp type PPP for both gtp v0 and gp v1.
There are no known workarounds.
•
Adding a secondary/tertiary gateway does not work.
This issue occurs only when non default port is used for gprs charging.
Workaround: Unconfigure all CGs followed by configure all the CGs.
Open Caveats—Cisco IOS Release 12.3(14)YQ1
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ1 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco GGSN does not clear the TCP socket from the GGSN to the charging gateway and hence does not respond to the Nodealive requests from the charging gateway, under the condition that the Charging Functionality is under a lot stress and the charging gateway is going up and down frequently resulting in a lot of charging data records being queued.
Workaround: Execute the show tcp brief command to display the tcb value. Then enter the clear tcp tcb command to clear the tcb using the tcb value from the show tcp brief command command. Then send Nodealive from the charging gateway.
•
Charging characteristics selection mode is set to roaming default for a roaming user when there is no default profile on GGSN.
This issue occurs when there is no default profile in GGSN.
There are no known workarounds.
•
Radius accounting request packet from GGSN to Radius does not have CLASS attribute.
This issue occurs in pdp type PPP for both gtp v0 and gp v1.
There are no known workarounds.
•
Adding a secondary/tertiary gateway does not work.
This issue occurs only when non default port is used for gprs charging.
Workaround: Unconfigure all CGs followed by configure all the CGs.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ1
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ1. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
There are no known resolved caveats for Cisco IOS Release 12.3(14)YQ1.
Open Caveats—Cisco IOS Release 12.3(14)YQ
This section documents possible unexpected behavior by Cisco IOS Release 12.3(14)YQ and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco GGSN does not clear the TCP socket from the GGSN to the charging gateway and hence does not respond to the Nodealive requests from the charging gateway, under the condition that the Charging Functionality is under a lot stress and the charging gateway is going up and down frequently resulting in a lot of charging data records being queued.
Workaround: Execute the show tcp brief command to display the tcb value. Then enter the clear tcp tcb command to clear the tcb using the tcb value from the show tcp brief command command. Then send Nodealive from the charging gateway.
Resolved Caveats—Cisco IOS Release 12.3(14)YQ
All the caveats listed in this section are resolved in Cisco IOS Release 12.3(14)YQ. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco GGSN Deletes and create the PDP context again under the condition that the new create request for an already existing context is coming for GTPv0 and that it is coming from a different SGSN than the earlier one and this new SGSN already is having a few active contexts with the same GGSN and the Restart count value in this new create request is different.
There are no known workarounds.
•
A document that describes how the Internet Control Message Protocol (ICMP) could be used to perform a number of Denial of Service (DoS) attacks against the Transmission Control Protocol (TCP) has been made publicly available. This document has been published through the Internet Engineering Task Force (IETF) Internet Draft process, and is entitled "ICMP Attacks Against TCP" (draft-gont-tcpm-icmp-attacks-03.txt).
These attacks, which only affect sessions terminating or originating on a device itself, can be of three types:
1. Attacks that use ICMP "hard" error messages
2. Attacks that use ICMP "fragmentation needed and Don't Fragment (DF) bit set" messages, also known as Path Maximum Transmission Unit Discovery (PMTUD) attacks
3. Attacks that use ICMP "source quench" messagesSuccessful attacks may cause connection resets or reduction of throughput in existing connections, depending on the attack type.
Multiple Cisco products are affected by the attacks described in this Internet draft.
Cisco has made free software available to address these vulnerabilities. In some cases there are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20050412-icmp.shtml.
The disclosure of these vulnerabilities is being coordinated by the National Infrastructure Security Coordination Centre (NISCC), based in the United Kingdom. NISCC is working with multiple vendors whose products are potentially affected. Its posting can be found at:
http://www.cpni.gov.uk/docs/re-20050412-00303.pdf
•
GGSN will continue duration limit trigger for CDRs which belong to PDPs, which are in the process of deletion.
This issue occurs when the charging profile, which is selected by PDP, has duration limit in it and PDP context is in "to be deleted" state.
There are no known workarounds.
•
When a PDP context of type PPP is established on the GGSN without the use of L2TP, the GGSN tries to set up a AAA authentication group list for this context, even when AAA new-model is not configured. This results in a failure in establishing this context with the following debug message printed out:
GTP-PPP: Fail to install aaa-group listsThis issue occurs on GGSN Release 5.0 when the involved APN for this PDP context is in non-transparent access-mode.
Workaround: Do not configure the aaa-group under the APN when AAA new-model is not used.
•
With very high rate of IP PDP signaling and very high rate of viable length packets over all open contexts for a long period of time, GGSN may show wrong "available BW" in the output of command show gprs bandwidth status <>.
There are no known workarounds.
•
GGSN does spurious memory access while creating pdp context in maintenance-mode.
This issue occurs when GGSN is in maintenance mode.
There are no known workarounds.
•
GGSN will not reject pdp update request. It will return cause value 128, and it will not increment the mandatory IE incorrect counter.
This issue occurs when SGSN sends an update request with incorrect length QOS.
There are no known workarounds.
•
A Cisco router running gateway GPRS support node software (GGSN) does not send tunnel end-point identifier (TEID) control in the update response if TEID-C is previously confirmed by the SGSN.
This is not a problem. However, to help interoperation with SGSNs, which only talk GTPv0 with each other but can talk GTPv1 with GGSN, the new SGSN needs to know the TEID-C of the PDP context.
There are no known workarounds.
•
After enough number of mobiles fail to establish contexts due to username errors, domain name errors, or internal memory allocation problems, the GGSN fails to accept any further Create Requests to establish such contexts. This is caused by the count for the max number of pending PPP-Regen contexts reaching the max without recovering back to zero, which is shown in the output of the command show gprs gtp statistic behind the entry "ppp_regen_pending".
This issue occurs in Cisco GGSN of release R4.0 or later which has some APNs configured to use PPP-Regeneration to handle IP PDP contexts.
Workaround: Configure a larger max using the global config command gprs gtp ppp-regeneration max-pending command. However, this may introduce a consequence that when the activation rate of such PPP-Regen PDP contexts is high, high PPP and L2TP traffic will be resulted between the GGSN and other LNSes/PDNs.
•
A document that describes how the Internet Control Message Protocol (ICMP) could be used to perform a number of Denial of Service (DoS) attacks against the Transmission Control Protocol (TCP) has been made publicly available. This document has been published through the Internet Engineering Task Force (IETF) Internet Draft process, and is entitled "ICMP Attacks Against TCP" (draft-gont-tcpm-icmp-attacks-03.txt).
These attacks, which only affect sessions terminating or originating on a device itself, can be of three types:
1. Attacks that use ICMP "hard" error messages
2. Attacks that use ICMP "fragmentation needed and Don't Fragment (DF) bit set" messages, also known as Path Maximum Transmission Unit Discovery (PMTUD) attacks
3. Attacks that use ICMP "source quench" messagesSuccessful attacks may cause connection resets or reduction of throughput in existing connections, depending on the attack type.
Multiple Cisco products are affected by the attacks described in this Internet draft.
Cisco has made free software available to address these vulnerabilities. In some cases there are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20050412-icmp.shtml.
The disclosure of these vulnerabilities is being coordinated by the National Infrastructure Security Coordination Centre (NISCC), based in the United Kingdom. NISCC is working with multiple vendors whose products are potentially affected. Its posting can be found at:
http://www.cpni.gov.uk/docs/re-20050412-00303.pdf
•
SYSLOG message returns NULL in the APN field.
This issue occurs when GTP authentication fails:
%GPRSFLTMG-4-GTPv1AAAFAIL_PDPACTIVATIONFAIL: GSN: <snip> APN: NULL, <snip>There are no known workarounds.
•
A document that describes how the Internet Control Message Protocol (ICMP) could be used to perform a number of Denial of Service (DoS) attacks against the Transmission Control Protocol (TCP) has been made publicly available. This document has been published through the Internet Engineering Task Force (IETF) Internet Draft process, and is entitled "ICMP Attacks Against TCP" (draft-gont-tcpm-icmp-attacks-03.txt).
These attacks, which only affect sessions terminating or originating on a device itself, can be of three types:
1. Attacks that use ICMP "hard" error messages
2. Attacks that use ICMP "fragmentation needed and Don't Fragment (DF) bit set" messages, also known as Path Maximum Transmission Unit Discovery (PMTUD) attacks
3. Attacks that use ICMP "source quench" messagesSuccessful attacks may cause connection resets or reduction of throughput in existing connections, depending on the attack type.
Multiple Cisco products are affected by the attacks described in this Internet draft.
Cisco has made free software available to address these vulnerabilities. In some cases there are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20050412-icmp.shtml.
The disclosure of these vulnerabilities is being coordinated by the National Infrastructure Security Coordination Centre (NISCC), based in the United Kingdom. NISCC is working with multiple vendors whose products are potentially affected. Its posting can be found at:
http://www.cpni.gov.uk/docs/re-20050412-00303.pdf
•
A document that describes how the Internet Control Message Protocol (ICMP) could be used to perform a number of Denial of Service (DoS) attacks against the Transmission Control Protocol (TCP) has been made publicly available. This document has been published through the Internet Engineering Task Force (IETF) Internet Draft process, and is entitled "ICMP Attacks Against TCP" (draft-gont-tcpm-icmp-attacks-03.txt).
These attacks, which only affect sessions terminating or originating on a device itself, can be of three types:
1. Attacks that use ICMP "hard" error messages
2. Attacks that use ICMP "fragmentation needed and Don't Fragment (DF) bit set" messages, also known as Path Maximum Transmission Unit Discovery (PMTUD) attacks
3. Attacks that use ICMP "source quench" messagesSuccessful attacks may cause connection resets or reduction of throughput in existing connections, depending on the attack type.
Multiple Cisco products are affected by the attacks described in this Internet draft.
Cisco has made free software available to address these vulnerabilities. In some cases there are workarounds available to mitigate the effects of the vulnerability.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20050412-icmp.shtml.
The disclosure of these vulnerabilities is being coordinated by the National Infrastructure Security Coordination Centre (NISCC), based in the United Kingdom. NISCC is working with multiple vendors whose products are potentially affected. Its posting can be found at:
http://www.cpni.gov.uk/docs/re-20050412-00303.pdf
•
Packets may be stuck in the input queue of a Cisco 7200 series.
This issue occurs on a Cisco 7200 series running a Cisco IOS interim Release 12.3(12.10) and configured with an NPE-G1.
Workaround: Reload the router to clear the input queue or increase the input queue beyond the default limit of 75 via the hold-queue length command.
Related Documentation
The following sections describe the documentation available for the Cisco 7000 family of routers. These documents consist of hardware and software installation guides, Cisco IOS configuration guides and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.3 and are located on Cisco.com and the Documentation CD-ROM:
•
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.3: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.3: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
As a supplement to the caveats listed in "Caveats for Cisco IOS Release 12.3 YQ" in these release notes, see Caveats for Cisco IOS Release 12.3 and Caveats for Cisco IOS Release 12.3 T, which contains caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.3 and Cisco IOS Release 12.3 T.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.3: Release Notes: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.3: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco 7000 family of routers on Cisco.com and the Documentation CD-ROM:
•
•
On Cisco.com at:
Technical Documents: All Product Documentation: Core/High-End Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: All Product Documentation: Core/High-End Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.3(14)YQ and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.3: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.3: New Feature Documentation
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.
Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.3: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.3: Configuration Guides and Command References
Cisco IOS Release 12.3 Documentation Set Contents
Table 3 lists the contents of the Cisco IOS Release 12.3 software documentation set, which is available in electronic form and in printed form if ordered.
Note
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.3
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.3
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
The most current Cisco documentation is available on the World Wide Web at
Translated documentation can be accessed at
http://www.cisco.com/public/countries_languages.shtml.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/public/ordsum.html
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco products documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
For your convenience, many documents contain a response card behind the front cover for submitting your comments by mail. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
The following sections provide sources for obtaining technical assistance from Cisco Systems.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
Cisco.com registered users who cannot resolve a technical issue by using the TAC online resource can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
Guest
