Release Notes for the Cisco 1700 Series Routers for Cisco IOS Release 12.3(2)XC
September 29, 2003
These release notes describe new features and significant software components for the Cisco 1700 series routers that support the Cisco IOS Release 12.3(2)T, up to and including Release 12.3(2)XC. These release notes are updated as needed to describe new memory requirements, new features, new hardware support, software platform deferrals, microcode or modem code changes, related document changes, and any other important changes. Use these release notes with the Cross-Platform Release Notes for Cisco IOS Release 12.3(2)T located on Cisco.com and the Documentation CD.
For a list of the software caveats that apply to Release 12.3(2)XC, see the "Caveats" section and Caveats for Cisco IOS Release 12.3(2)T. The online caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD.
Contents
These release notes include the following topics:
•
Obtaining Technical Assistance
•
System Requirements
This section describes the system requirements for Release 12.3(2)XC and includes the following sections:
•
•
Memory Requirements
Table 1 describes the memory requirements for the Cisco IOS feature sets supported by the Cisco IOS Release 12.3(2)XC on the Cisco 1700 series routers.
Table 1 Recommended Memory for the Cisco 1700 Series Routers1 —Legacy Images
Cisco 17102
Cisco 1710 IOS IP/IPX/AT/IBM/ FW/IDS PLUS IPSEC 3DES
IP/IPX/AT/IBM/
FW/IDS PLUS IPSEC 3DESc1710-bk9no3r2sy-mz
16 MB
64 MB
Cisco 1710 IOS IP/FW/IDS PLUS IPSEC 3DES
IP/FW/IDS PLUS IPSEC 3DES
c1710-k9o3sy-mz
16 MB
64 MB
Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL/VOX PLUS
IP/ADSL/VOX PLUS
c1700-sv8y7-mz
32 MB
96 MB
Cisco 1700 IOS IP/ADSL/VOX/ FW/IDS PLUS IPSEC 3DES
IP/ADSL/VOX/FW/
IDS PLUS IPSEC 3DESc1700-k9o3sv8y7-mz
32 MB
96 MB
Cisco 1700 IOS IP/ADSL/IPX/AT/ IBM/VOX/FW/ IDS PLUS IPSEC 3DES
IP/ADSL/IPX/AT/
IBM/VOX/FW/IDS PLUS IPSEC 3DESc1700-bk9no3r2sv8y7-mz
32 MB
96 MB
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL PLUS
IP/ADSL PLUS
c1700-sy7-mz
16 MB
64 MB
Cisco 1720,Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP
IP
c1700-y-mz
16 MB
48 MB
Cisco 1701,Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL/IPX/AT/ IBM PLUS
IP/ADSL/IPX/AT/
IBM PLUSc1700-bnr2sy7-mz
16 MB
64 MB
Cisco 1701, Cisco 1711, Cisco 1712,Cisco 1721, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL/IPX/AT/ IBM/FW/IDS PLUS IPSEC 3DES
IP/ADSL/IPX/AT/
IBM/FW/IDS PLUS IPSEC 3DESc1700-bk9no3r2sy7-mz
32 MB
96 MB
Cisco 1701, Cisco 1720, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL
IP/ADSL
c1700-y7-mz
16 MB
48 MB
Cisco 1701, Cisco 1711,Cisco 1712,Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP/ADSL/FW/IDS PLUS IPSEC 3DES
IP/ADSL/FW/IDS PLUS IPSEC 3DES
c1700-k9o3sy7-mz
16 MB
64 MB
1 The WIC-4ESW is supported only on the Cisco 1721, 1751, 1751-V, and 1760 routers.
2 The Cisco 1710 router does not support Security Device Manager (SDM).
Table 2 Recommended Memory for the Cisco 1700 Series Routers1 —Cross-Platform Images
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP BASE
IP BASE
c1700-ipbase-mz
16 MB
64 MB
Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS IP VOICE
IP VOICE
c1700-ipvoice-mz
32 MB
96 MB
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS ENTERPRISE BASE
ENTERPRISE BASE
c1700-entbase-mz
16 MB
64 MB
Cisco 1701, Cisco 1711, Cisco 1712, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS ADVANCED SECURITY
ADVANCED SECURITY
c1700-advsecurityk9-mz
16 MB
64 MB
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS SP SERVICES
SP SERVICES
c1700-spservicesk9-mz
32 MB
96 MB
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS ENTERPRISE SERVICES
ENTERPRISE SERVICES
c1700-entservicesk9-mz
32 MB
96 MB
Cisco 1701, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS ADVANCED IP SERVICES
ADVANCED IP SERVICES
c1700-advipservicesk9-mz
32 MB
96 MB
Cisco 1701, Cisco 1711, Cisco 1712, Cisco 1721, Cisco 1751, Cisco 1751-V, and Cisco 1760
Cisco 1700 IOS ADVANCED ENTERPRISE SERVICES
ADVANCED ENTERPRISE SERVICES
c1700-adventerprisek9-mz
32 MB
96 MB
1 The WIC-4ESW is supported only on the Cisco 1721, 1751, 1751-V, and 1760 routers.
2 Refer to the product bulletin "Cisco IOS Software Release 12.3 Mainline and 12.3T Feature Sets for Cisco 1700 Series Routers.
Hardware Supported
Cisco IOS Release 12.3(2)XC supports the following Cisco 1700 series routers:
•
•
•
•
•
•
•
•
The Cisco 1701, Cisco 1710, Cisco 1711, Cisco 1712, Cisco 1720, and Cisco 1721routers run data images only. The Cisco 1751, Cisco 1751-V, and Cisco 1760 routers run data or data-and-voice images, providing digital and analog voice support. The Cisco 1711 and Cisco 1712 routers run select IPSec Triple Data Encryption Standard (3DES) images only (the Cisco 1700 IOS IP/ADSL/IPX/AT/IBM/FW/IDS PLUS IPSEC 3DES, the Cisco 1700 IOS IP/ADSL/FW/IDS PLUS IPSEC 3DES, the Cisco 1700 Advanced Security, and the Cisco 1700 Advanced Enterprise Services images).
For descriptions of existing hardware features and supported modules, see the hardware installation guides, configuration and command reference guides, and additional documents specific to the Cisco 1700 series routers, which are available on Cisco.com and the Documentation CD at the following location:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1700/index.htm
This URL is subject to change without notice. If it changes, point your web browser to Cisco.com, and click the following path:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 1700 Series Routers: <platform_name>
Determining the Software Version
To determine which version of Cisco IOS software is currently running on your Cisco 1700 series router, log in to the router and enter the show version EXEC command. The following sample output from the show version command indicates the version number.
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) C1700 Software (C1700-NY-MZ), Version 12.3(2)XC, EARLY DEPLOYMENT RELEASE SOFTWARE (fc1)Synched to technology version 12.3(1.6)TUpgrading to a New Software Release
For general information about upgrading to a new software release, refer to the Software Installation and Upgrade Procedures located at http://www.cisco.com/warp/public/130/upgrade_index.shtml.
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images, depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.3(2)XC supports the same feature sets as Releases 12.3 and 12.3(2)T, but Release 12.3(2)XC includes new features supported by the Cisco 1700 series routers.
Caution
Table 3 through Table 6 lists the feature and feature sets supported in the Cisco IOS Release 12.3(2)XC.
The tables use the following conventions:
•
•
•
Note
Table 5 Feature List by Cross-Platform Feature Set for Cisco 1751, 1751-V, and 1760 Routers
WIC-4ESW (4-Port Ethernet Switch WIC)
12.3(2)XC
Yes
New and Changed Information
The following sections list the new hardware features supported by the Cisco 1700 series routers for Release 12.3(2)XC.
New Hardware Features in Release 12.3(2)XC
The following sections describe the new hardware features supported by the Cisco 1700 series routers for Release 12.3(2)XC.
WIC-4ESW (4-Port Ethernet Switch WIC)
The WIC-4ESW (4-Port Ethernet Switch WAN interface card [WIC]) is a new four-port managed 10/100 Base-T Layer 2 switch in a WIC form factor. The switch supports IEEE 802.1D spanning tree algorithm and can be used to connect upto four LANs or up to 16 IEEE 802.1Q based virtual LANs.
New Software Features in Release 12.3(2)T
For information regarding the features supported in the Cisco IOS Release 12.3(2)T, refer to the Cross-Platform Release Notes and New Feature Documentation links at the following location on Cisco.com:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios123/123relnt/xprn123/index.htm
This URL is subject to change without notice. If it changes, point your web browser to Cisco.com, and click the following path:
Service & Support: Technical Documents: Cisco IOS Software: Release 12.3: Release Notes: Cross-Platform Release Notes (Cisco IOS Release 12.3(2)T)
Limitations
The following sections describe limitations concerning the new hardware and software features supported by the Cisco 1700 series routers for Release 12.3(2)XC.
WIC-4ESW (4-Port Ethernet Switch WIC)
The following features are not supported on WIC-4ESW card:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Caveats
Caveats describe unexpected behavior or defects in the Cisco IOS software releases. Severity 1 caveats are the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious of these three severity levels.
Caveats in Cisco IOS Release 12.3(2)T are also in Release 12.3(2)XC. For information on caveats in Cisco IOS Release 12.3(2)T, refer to the Caveats for Cisco IOS Release 12.3(2)T document. This document lists severity 1 and 2 caveats; the documents are located on Cisco.com and the Documentation CD.
Note
Resolved Caveats - Release 12.3(2)XC
This section documents possible unexpected behavior by Cisco IOS Release 12.3(2)XC and describes only severity 1 and 2 caveats and selected severity 3 caveats.
•
TCP checks should verify ack sequence number.
A vulnerability in the Transmission Control Protocol (TCP) specification (RFC793) has been discovered by an external researcher. The successful exploitation enables an adversary to reset any established TCP connection in a much shorter time than was previously discussed publicly. Depending on the application, the connection may get automatically re-established. In other cases, a user will have to repeat the action (for example, open a new Telnet or SSH session). Depending upon the attacked protocol, a successful attack may have additional consequences beyond terminated connection which must be considered. This attack vector is only applicable to the sessions which are terminating on a device (such as a router, switch, or computer) and not to the sessions that are only passing through the device (for example, transit traffic that is being routed by a router). In addition, this attack vector does not directly compromise data integrity or confidentiality.
All Cisco products which contain TCP stack are susceptible to this vulnerability.
This advisory is available at http://www.cisco.com/warp/public/707/cisco-sa-20040420-tcp-ios.shtml, and it describes this vulnerability as it applies to Cisco products that run Cisco IOS® software.
A companion advisory that describes this vulnerability for products that do not run Cisco IOS software is available at http://www.cisco.com/warp/public/707/cisco-sa-20040420-tcp-nonios.shtml.
•
TCP checks should verify ack sequence number.
A vulnerability in the Transmission Control Protocol (TCP) specification (RFC793) has been discovered by an external researcher. The successful exploitation enables an adversary to reset any established TCP connection in a much shorter time than was previously discussed publicly. Depending on the application, the connection may get automatically re-established. In other cases, a user will have to repeat the action (for example, open a new Telnet or SSH session). Depending upon the attacked protocol, a successful attack may have additional consequences beyond terminated connection which must be considered. This attack vector is only applicable to the sessions which are terminating on a device (such as a router, switch, or computer) and not to the sessions that are only passing through the device (for example, transit traffic that is being routed by a router). In addition, this attack vector does not directly compromise data integrity or confidentiality.
All Cisco products which contain TCP stack are susceptible to this vulnerability.
This advisory is available at http://www.cisco.com/warp/public/707/cisco-sa-20040420-tcp-ios.shtml, and it describes this vulnerability as it applies to Cisco products that run Cisco IOS® software.
A companion advisory that describes this vulnerability for products that do not run Cisco IOS software is available at http://www.cisco.com/warp/public/707/cisco-sa-20040420-tcp-nonios.shtml.
Open Caveats for Release 12.3(2)XC
•
•
•
•
"00:00:05 PQUICC-1-UNKNOWN_WIC:PQUICC(0), WIC card has an unknown ID of 0xFF."
•
•
•
•
•
Related Documentation
The following sections describe the documentation available for the Cisco 1700 series routers. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents. Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD.
Use these release notes with the documents listed in the following sections:
Release-Specific Documents
The following documents are specific to Release 12.3 and apply to Release 12.3(2)XC. They are located on Cisco.com and the Documentation CD (under the heading Service & Support):
•
Technical Documents: Cisco IOS Software: Release 12.3: Release Notes: Cisco IOS Release 12.3(2)T
•
Technical Documents: Product Bulletins
•
Technical Documents: Cisco IOS Software: Release 12.3: Caveats
Note
Platform-Specific Documents
Hardware installation guides, configuration and command reference guides, and additional documents specific to the Cisco 1700 series routers are available on Cisco.com and the Documentation CD at the following location:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1700/index.htm
This URL is subject to change without notice. If it changes, point your web browser to Cisco.com, and click the following path:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 1700 Series Routers: <platform_name>
Obtaining Documentation
These sections explain how to obtain documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at this URL:
Translated documentation is available at this URL:
http://www.cisco.com/public/countries_languages.shtml
Documentation CD-ROM
Cisco documentation and additional literature are available in a Cisco Documentation CD-ROM package, which is shipped with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or through an annual subscription.
Ordering Documentation
You can order Cisco documentation in these ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
You can submit comments electronically on Cisco.com. In the Cisco Documentation home page, click the Fax or Email option in the "Leave Feedback" section at the bottom of the page.
You can e-mail your comments to bug-doc@cisco.com.
You can submit your comments by mail by using the response card behind the front cover of your document or by writing to the following address:
Cisco Systems
Attn: Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain online documentation, troubleshooting tips, and sample configurations from online tools by using the Cisco Technical Assistance Center (TAC) Web Site. Cisco.com registered users have complete access to the technical support resources on the Cisco TAC Web Site.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information, networking solutions, services, programs, and resources at any time, from anywhere in the world.
Cisco.com is a highly integrated Internet application and a powerful, easy-to-use tool that provides a broad range of features and services to help you with these tasks:
•
•
•
•
•
If you want to obtain customized information and service, you can self-register on Cisco.com. To access Cisco.com, go to this URL:
Technical Assistance Center
The Cisco Technical Assistance Center (TAC) is available to all customers who need technical assistance with a Cisco product, technology, or solution. Two levels of support are available: the Cisco TAC Web Site and the Cisco TAC Escalation Center.
Cisco TAC inquiries are categorized according to the urgency of the issue:
•
•
•
•
The Cisco TAC resource that you choose is based on the priority of the problem and the conditions of service contracts, when applicable.
Cisco TAC Web Site
You can use the Cisco TAC Web Site to resolve P3 and P4 issues yourself, saving both cost and time. The site provides around-the-clock access to online tools, knowledge bases, and software. To access the Cisco TAC Web Site, go to this URL:
All customers, partners, and resellers who have a valid Cisco service contract have complete access to the technical support resources on the Cisco TAC Web Site. The Cisco TAC Web Site requires a Cisco.com login ID and password. If you have a valid service contract but do not have a login ID or password, go to this URL to register:
http://www.cisco.com/register/
If you are a Cisco.com registered user, and you cannot resolve your technical issues by using the Cisco TAC Web Site, you can open a case online by using the TAC Case Open tool at this URL:
http://www.cisco.com/tac/caseopen
If you have Internet access, we recommend that you open P3 and P4 cases through the Cisco TAC Web Site.
Cisco TAC Escalation Center
The Cisco TAC Escalation Center addresses priority level 1 or priority level 2 issues. These classifications are assigned when severe network degradation significantly impacts business operations. When you contact the TAC Escalation Center with a P1 or P2 problem, a Cisco TAC engineer automatically opens a case.
To obtain a directory of toll-free Cisco TAC telephone numbers for your country, go to this URL:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
Before calling, please check with your network operations center to determine the level of Cisco support services to which your company is entitled: for example, SMARTnet, SMARTnet Onsite, or Network Supported Accounts (NSA). When you call the center, please have available your service agreement number and your product serial number.
Obtaining Additional Publications and Information
Information about Cisco products, technologies, and network solutions is available from various online and printed sources.
•
http://www.cisco.com/en/US/products/products_catalog_links_launch.html
•
•
http://www.cisco.com/go/packet
•
http://www.cisco.com/go/iqmagazine
•
http://www.cisco.com/en/US/about/ac123/ac147/about_cisco_the_internet_protocol_journal.html
•
http://www.cisco.com/en/US/learning/le31/learning_recommended_training_list.html
This document is to be used in conjunction with the documents listed in the "Related Documentation" section.
