Release Notes for Cisco IOS Release 12.1(5) T Feature Packs for the Cisco 7200 Series Router
June 18, 2001
Note
You can find the most current Cisco IOS documentation on Cisco.com. This set of electronic documents may contain updates and modifications made after CD documents are created.
Contents
These release notes describe the following topics:
•Introduction
•System Requirements
•Related Documentation
•Obtaining Documentation
•Obtaining Technical Assistance
Introduction
List of Terms
The following terms are used throughout this document:
Feature—Networking functionality that supports network technology and hardware. For example: Double Authentication, IP Multicast over Token Ring, Voice Over IP, PPP over ATM, and so forth.
Feature Set—A group of features. For example: IP, IP Plus, Enterprise Plus, IP IPSec 56, and so forth.
Image—Software code containing a Cisco IOS feature set. The image file nomenclature, such as c800-y6-mw, c1000-bnsy40-mz, and c2500-g-l, specifies a platform, feature set, and file compression method. For example, c4500-is56i-mz indicates:
•Cisco 4500 platform: c4500.
•IP Plus IPSec 56 feature set: is56i.
•RAM compression method: mz.
Feature Pack—A folder containing installation documentation and CDs that contain software images, applications, and electronic documentation. Feature packs provide software upgrades for many of the Cisco hardware platforms.
Feature Pack Contents
Your feature pack contains:
•A Software Feature Pack CD-ROM with the following software:
–Cisco IOS feature set software images that can include bundled modem firmware
–Trivial File Transfer Protocol (TFTP) server application (for Windows 95 only)
–These release notes
•Documentation CD-ROM that contains all Cisco documentation
•Getting Started Fast
•Loading the Software Feature Pack instruction booklet
•Cisco Connection Online wallet card and sticker with service contact information
•Software license for using Cisco software in object code form on a single access server or router.
How to Use These Release Notes
The tables in these release notes contain details about the Cisco feature packs. Use these tables to perform the following tasks before loading a software image onto a router:
1. Use Table 1, "7200 Series Router Default Memory and Upgrade Options,"page 3 for the feature set memory requirements, factory-default memory, and available memory upgrades for your 7200 series router.
2. Use Table 2, "7200 Series Router Feature Packs," page 4 to identify your feature pack and the memory required for your feature set, based on the image you load.
3. Use the tables in the "Feature Set Tables" section to identify which features are supported in a feature set image.
System Requirements
This section describes the system requirements for Cisco IOS Release 12.1(5) T:
•Memory Defaults and Upgrade Options
•Hardware Supported
•Software Compatibility
•Determining the Software Version
•Upgrading to a New Software Release
•Feature Pack Overview Table
•Feature Set Tables
Memory Defaults and Upgrade Options
Table 1 lists the 7200 series router default memory and upgrade options.
Table 1 7200 Series Router Default Memory and Upgrade Options
Memory Type
|
Cisco 7200 Series Router Defaults
|
Upgrade Options
|
Flash memory
|
48 MB
|
MEM-I/O-FLD-128MB
|
Process memory
|
128 MB
|
MEM-SD-NPE-256MB
MEM-SD-NSE-256MB
MEM-NPE-400-256MB
MEM-NPE-400-512MB
|
Hardware Supported
Cisco IOS Release 12.1(5) T supports the Cisco 7200 series routers (Cisco 7204 VXR and Cisco 7206 VXR).
Note A Hardware-Software Compatibility Matrix is available on Cisco.com for users with Cisco.com login accounts. Using this matrix, you can search for supported hardware components by entering a Cisco platform and IOS Release. The Hardware-Software Compatibility Matrix tool is also available at the following URL:
http://www.cisco.com/cgi-bin/front.x/Support/HWSWmatrix/hwswmatrix.cgi
Software Compatibility
The feature packs described in these release notes contain Cisco IOS Release 12.1(5) T software images and some images from previous software releases.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco 7200 family router, log in to the router and enter the show version EXEC command:
Cisco Internetwork Operating System Software
IOS (tm) 12.1 T Software (C7200-JS-MZ), Version 12.1(5) T, RELEASE SOFTWARE
Upgrading to a New Software Release
For general information about upgrading to a new software release, see Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:
http://www.cisco.com/warp/public/620/6.html
Feature Pack Overview Table
Table 2 7200 Series Router Feature Packs
Product Number
|
CD-ROM Title
|
Image Name(s)
|
Recommended Memory
|
UNIX
|
DOS
|
Flash
|
Main
|
CD72-C-12.1.5T=
|
Cisco 7200 Series IP Feature Pack Release 12.1(5) T
|
c7200-is-mz.121-5.T8
|
aaa1358
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-is-mz.121-6.E
|
aaa1360
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-is-mz.121-7
|
aaa1362
|
16MB
|
64MB
|
c7200-is-mz.120-16
|
aaa1364
|
16MB
|
64MB
|
c7200-boot-mz.120-16
|
aaa1365
|
16MB
|
64MB
|
CD72-CL-12.1.5T=
|
Cisco 7200 Series IP IPSEC 56 Feature Pack Release 12.1(5) T
|
c7200-is56i-mz.121-5.T8
|
aaa1366
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-is56i-mz.121-6.E2
|
aaa1367
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-is56i-mz.121-7
|
aaa1368
|
16MB
|
64MB
|
c7200-is56i-mz.120-16
|
aaa1369
|
16MB
|
64MB
|
c7200-boot-mz.120-16
|
aaa1365
|
16MB
|
64MB
|
CD72-CK2-12.1.5T=
|
Cisco 7200 Series IP IPSEC 3DES Feature Pack Release 12.1(5) T
|
c7200-ik2s-mz.121-5.T8
|
aaa1370
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-ik2s-mz.121-6.E
|
aaa1371
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-ik2s-mz.121-7
|
aaa1372
|
16MB
|
64MB
|
CD72-CH-12.1.5T=
|
Cisco 7200 Series IP/FW/IDS Feature Pack Release 12.1(5) T
|
c7200-io3s-mz.121-5.T8
|
aaa1373
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-io3s-mz.121-6.E
|
aaa1374
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-io3s-mz.121-7
|
aaa1375
|
16MB
|
64MB
|
CD72-CHL-12.1.5T=
|
Cisco 7200 Series IP/FW/IDS IPSEC 56 Feature Pack Release 12.1(5) T
|
c7200-io3s56i-mz.121-5.T8
|
aaa1376
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-io3s56i-mz.121-6.E
|
aaa1377
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-io3s56i-mz.121-7
|
aaa1378
|
16MB
|
64MB
|
CD72-CHK2-12.1.5T=
|
Cisco 7200 Series IP/FW/IDS IPSEC 3DES Feature Pack Release 12.1(5) T
|
c7200-ik2o3s-mz.121-5.T8
|
aaa1379
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-ik2o3s-mz.121-6.E
|
aaa1380
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-ik2o3s-mz.121-7
|
aaa1381
|
16MB
|
64MB
|
CD72-BS-12.1.5T=
|
Cisco 7200 Series Desktop/IBM Feature Pack Release 12.1(5) T
|
c7200-ds-mz.121-5.T8
|
aaa1382
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-ds-mz.121-6.E
|
aaa1383
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-ds-mz.121-7
|
aaa1384
|
16MB
|
64MB
|
c7200-ds-mz.120-16
|
aaa1385
|
16MB
|
64MB
|
c7200-boot-mz.120-16
|
aaa1365
|
16MB
|
64MB
|
CD72-A-12.1.5T=
|
Cisco 7200 Series Enterprise Feature Pack Release 12.1(5) T
|
c7200-js-mz.121-5.T8
|
aaa1386
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-js-mz.121-6.E
|
aaa1387
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-js-mz.121-7
|
aaa1388
|
16MB
|
64MB
|
c7200-js-mz.120-16
|
aaa1389
|
16MB
|
64MB
|
c7200-boot-mz.120-16
|
aaa1365
|
16MB
|
64MB
|
CD72-AL-12.1.5T=
|
Cisco 7200 Series Enterprise IPSEC 56 Feature Pack Release 12.1(5) T
|
c7200-js56i-mz.121-5.T8
|
aaa1390
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-js56i-mz.121-6.E
|
aaa1391
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-js56i-mz.121-7
|
aaa1392
|
16MB
|
64MB
|
c7200-js56i-mz.120-10
|
aaa1393
|
16MB
|
64MB
|
c7200-boot-mz.120-16
|
aaa1365
|
16MB
|
64MB
|
CD72-AK2-12.1.5T=
|
Cisco 7200 Series Enterprise IPSEC 3DES Feature Pack Release 12.1(5) T
|
c7200-jk2s-mz.121-5.T8
|
aaa1394
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-jk2s-mz.121-6.E2
|
aaa1395
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-jk2s-mz.121-7
|
aaa1396
|
16MB
|
64MB
|
CD72-AH-12.1.5T=
|
Cisco 7200 Series Enterprise/FW/IDS Feature Pack Release 12.1(5) T
|
c7200-jo3s-mz.121-5.T8
|
aaa1397
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-jo3s-mz.121-6.E
|
aaa1398
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-jo3s-mz.121-7
|
aaa1399
|
16MB
|
64MB
|
CD72-AHL-12.1.5T=
|
Cisco 7200 Series Enterprise/FW IPSEC 56 Feature Pack Release 12.1(5) T
|
c7200-jo3s56i-mz.121-5.T8
|
aaa1400
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-jo3s56i-mz.121-6.E2
|
aaa1401
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-jo3s56i-mz.121-7
|
aaa1402
|
16MB
|
64MB
|
CD72-AHK2-12.1.5T=
|
Cisco 7200 Series Enterprise/FW IPSEC 3DES Feature Pack Release 12.1(5) T
|
c7200-jk2o3s-mz.121-5.T8
|
aaa1403
|
16MB
|
128MB
|
c7200-kboot-mz.121-5.T8
|
aaa1359
|
16MB
|
128MB
|
c7200-jk2o3s-mz.121-6.E2
|
aaa1404
|
16MB
|
64MB
|
c7200-kboot-mz.121-6.E
|
aaa1361
|
16MB
|
64MB
|
c7200-jk2o3s-mz.121-7
|
aaa1405
|
16MB
|
64MB
|
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Release 12.1 T supports the same feature sets as Release 12.1, but Release 12.1 T can include new features supported by the Cisco 7200 family.
Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit Triple Data Encryption Standard [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay because of United States government regulations. When applicable, the purchaser and user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
Table 3 through Table 8 list the features and feature sets supported by the Cisco 7200 family in Cisco IOS Release 12.1 T and use the following conventions:
•Yes—The feature is supported in the software image.
•No—The feature is not supported in the software image.
•In—The number in the "In" column indicates the Cisco IOS release in which the feature was introduced. For example, (5) means a feature was introduced in 12.1(5) T.
Note This table might not be cumulative or list all the features in each image. You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents may contain updates and modifications made after the hard-copy documents were printed. If you have a Cisco.com login account, you can find image and release information regarding features prior to Cisco IOS Release 12.1(5) T by using the Feature Navigator tool at http://www.cisco.com/go/fn.
Table 3 Feature List by Feature Set for the Cisco 7200 Series
Features
|
In
|
Software Images by Feature Sets
|
IP
|
IP IPSec 56
|
IP IPSec 3DES
|
IP FW/IDS
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
No
|
No
|
No
|
No
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Expression MIB Support of Delta, Wildcarding, and Aggregation
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Individual SNMP Trap Support
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interfaces
|
FastEther Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
No
|
No
|
No
|
Yes
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
No
|
No
|
No
|
Yes
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
No
|
No
|
No
|
No
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
No
|
No
|
No
|
No
|
Virtual Switch Interface Master MIB
|
(3)
|
No
|
No
|
No
|
No
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
No
|
No
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Network-Based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
No
|
No
|
No
|
No
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
Yes
|
Yes
|
No
|
No
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
Yes
|
No
|
No
|
Yes
|
IKE Extended Authentication
|
(1)
|
No
|
Yes
|
Yes
|
No
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
No
|
Yes
|
Yes
|
No
|
SSH, Version 1 Support for T Train
|
(1)
|
Yes
|
Yes
|
Yes
|
No
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
No
|
Yes
|
Yes
|
No
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Class of Service Enhancements
|
(5)
|
No
|
No
|
No
|
No
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
No
|
No
|
No
|
No
|
Traceroute Enhancement for MPLS
|
(5)
|
No
|
No
|
No
|
No
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
Yes
|
No
|
No
|
No
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 4 Feature List by Feature Set for the Cisco 7200 Series, Part 2
Features
|
In
|
Software Images by Feature Sets
|
IP/FW/IDS IPSec 56
|
IP/FW/IDS IPSec 3DES
|
Enterprise
|
Enterprise IpSec 56
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
No
|
No
|
Yes
|
Yes
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
No
|
No
|
Yes
|
No
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Expression MIB Support of Delta, Wildcarding, and Aggregation
|
(3)
|
No
|
No
|
Yes
|
No
|
Individual SNMP Trap Support
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
No
|
No
|
Yes
|
No
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interfaces
|
Fast Ether Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
No
|
No
|
Yes
|
Yes
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
No
|
No
|
Yes
|
Yes
|
Virtual Switch Interface Master MIB
|
(3)
|
No
|
No
|
Yes
|
Yes
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
No
|
No
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
No
|
No
|
Yes
|
No
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Network-Based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
No
|
No
|
Yes
|
Yes
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
No
|
No
|
Yes
|
Yes
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
No
|
No
|
Yes
|
No
|
IKE Extended Authentication
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
Yes
|
Yes
|
No
|
Yes
|
SSH, Version 1 Support for T Train
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Class of Service Enhancements
|
(5)
|
No
|
No
|
Yes
|
Yes
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
No
|
No
|
Yes
|
Yes
|
Traceroute Enhancement for MPLS
|
(5)
|
No
|
No
|
Yes
|
Yes
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
No
|
No
|
Yes
|
No
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 5 Feature List by Feature Set for the Cisco 7200 Series, Part 3
Features
|
In
|
Software Images by Feature Sets
|
Enterprise IPSec 3DES
|
Enterprise MCM
|
Enterprise Wireless
|
Enterprise Wireless IPSec 56
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
No
|
Yes
|
Yes
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
No
|
Yes
|
No
|
No
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Expression MIB Support of Delta, Wildcarding, and Aggregation
|
(3)
|
No
|
Yes
|
No
|
No
|
Individual SNMP Trap Support
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
No
|
Yes
|
Yes
|
No
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interfaces
|
FastEther Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
Yes
|
No
|
Yes
|
Yes
|
Virtual Switch Interface Master MIB
|
(3)
|
Yes
|
No
|
Yes
|
Yes
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
Yes
|
Yes
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
No
|
Yes
|
Yes
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
No
|
Yes
|
Yes
|
No
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Network-based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
No
|
Yes
|
No
|
Yes
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
No
|
Yes
|
Yes
|
No
|
IKE Extended Authentication
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
Yes
|
No
|
No
|
Yes
|
SSH, Version 1 Support for T Train
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
Yes
|
No
|
No
|
Yes
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
No
|
Yes
|
Yes
|
MPLS Class of Service Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Traceroute Enhancement for MPLS
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
No
|
Yes
|
No
|
No
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
Yes
|
Yes
|
No
|
No
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
Yes
|
Yes
|
No
|
No
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
No
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 6 Feature List by Feature Set for the Cisco 7200 Series, Part 4
Features
|
In
|
Software Images by Feature Sets
|
Enterprise/ FW/IDS
|
Enterprise/ FW/IDS IPSec 56
|
Enterprise/ FW/IDS IPSec 3DES
|
Enterprise/ SNASW
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Expression MIB Support of Delta, Wildcarding and Aggregation
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Individual SNMP Trap Support
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
Yes
|
No
|
No
|
Yes
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interfaces
|
FastEther Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Virtual Switch Interface Master MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
No
|
No
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
| |
|
|
|
|
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
Yes
|
No
|
No
|
No
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Network-based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
No
|
No
|
No
|
Yes
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
Yes
|
No
|
No
|
Yes
|
IKE Extended Authentication
|
(1)
|
No
|
Yes
|
Yes
|
No
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
No
|
Yes
|
Yes
|
No
|
SSH, Version 1 Support for T Train
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
No
|
Yes
|
Yes
|
No
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Class of Service Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Traceroute Enhancement for MPLS
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
No
|
No
|
No
|
No
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 7 Feature List by Feature Set for the Cisco 7200 Series, Part 5
Features
|
In
|
Software Images by Feature Sets
|
Enterprise/ SNASW IPSec 56
|
Enterprise/ SNASW IPSec 3DES
|
Desktop/IBM
|
Desktop/ IBM/ IPSec 56
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
No
|
No
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
No
|
No
|
Yes
|
No
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
No
|
Expression MIB Support of Delta, Wildcarding and Aggregation
|
(3)
|
No
|
No
|
Yes
|
No
|
Individual SNMP Trap Support
|
(3)
|
No
|
No
|
Yes
|
No
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
No
|
No
|
Yes
|
No
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Interfaces
|
FastEther Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
Yes
|
Yes
|
No
|
No
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
Yes
|
Yes
|
No
|
No
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
Yes
|
Yes
|
No
|
No
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
Yes
|
Yes
|
No
|
No
|
Virtual Switch Interface Master MIB
|
(3)
|
Yes
|
Yes
|
No
|
No
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
No
|
No
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
No
|
No
|
Yes
|
No
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Network-based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
Yes
|
Yes
|
No
|
No
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
Yes
|
No
|
No
|
No
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
No
|
No
|
Yes
|
No
|
IKE Extended Authentication
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
Yes
|
Yes
|
No
|
Yes
|
SSH, Version 1 Support for T Train
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
Yes
|
Yes
|
No
|
Yes
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
MPLS Class of Service Enhancements
|
(5)
|
Yes
|
Yes
|
No
|
No
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
Yes
|
Yes
|
No
|
No
|
Traceroute Enhancement for MPLS
|
(5)
|
Yes
|
Yes
|
No
|
No
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
No
|
No
|
No
|
No
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
Yes
|
Yes
|
Yes
|
No
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Yes
|
Table 8 Feature List by Feature Set for the Cisco 7200 Series, Part 6
Features
|
In
|
Software Images by Feature Sets
|
Desktop/ IBM/FW/IDS
|
Desktop/ IBM/FW/IDS IPSec 56
|
Desktop/ IBM/FW/IDS IPSec 3DES
|
Bridging and IBM Networking
|
Bridging Between IEEE 802.1Q vLANs
|
(3)
|
No
|
No
|
No
|
SDLC SNRM Timer and Window Size Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
SNMP Support for IOS vLAN Subinterfaces
|
(3)
|
Yes
|
Yes
|
No
|
TN3270 Server Connectivity Enhancements
|
(5)
|
Yes
|
Yes
|
Yes
|
Configuration Fundamentals
|
AutoInstall Using DHCP for LAN Interfaces
|
(5)
|
Yes
|
Yes
|
Yes
|
Configuration though SNMP
|
(3)
|
Yes
|
No
|
No
|
Event MIB
|
(3)
|
Yes
|
Yes
|
Yes
|
Expression MIB Support of Delta, Wildcarding and Aggregation
|
(3)
|
Yes
|
No
|
No
|
Individual SNMP Trap Support
|
(3)
|
Yes
|
Yes
|
Yes
|
Interface Index Persistence
|
(5)
|
Yes
|
Yes
|
Yes
|
Interface Range Specification
|
(5)
|
Yes
|
Yes
|
Yes
|
NTP MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Parser Cache
|
(5)
|
Yes
|
Yes
|
Yes
|
WCCP Redirection on Inbound Interfaces
|
(3)
|
Yes
|
No
|
No
|
Connectivity/Scalability
|
PPPoE on ATM
|
(1)
|
Yes
|
Yes
|
No
|
PPP Over Fast Ethernet 802.1Q
|
(5)
|
Yes
|
Yes
|
Yes
|
Interfaces
|
FastEther Channel Enhancements on Cisco 7200 Series Routers
|
(5)
|
Yes
|
Yes
|
Yes
|
IP Addressing and Services
|
HSRP support for MPLS VPNs
|
(3)
|
Yes
|
Yes
|
Yes
|
NAT—Enhanced H.225/H.245 Forwarding Engine
|
(5)
|
Yes
|
Yes
|
Yes
|
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
|
(5)
|
Yes
|
Yes
|
Yes
|
NAT—Support of H.323 v2 Call Signalling (FastConnect)
|
(5)
|
Yes
|
Yes
|
Yes
|
NAT—Support of IP Phone to Cisco Call Manager
|
(5)
|
Yes
|
Yes
|
Yes
|
Turbo Access Control Lists
|
(5)
|
Yes
|
Yes
|
Yes
|
IP Multicast
|
Bidirectional PIM
|
(2)
|
Yes
|
Yes
|
Yes
|
IGMP, Version 3
|
(5)
|
Yes
|
Yes
|
Yes
|
PIM Dense Mode State Refresh
|
(5)
|
Yes
|
Yes
|
Yes
|
Router-Port Group Management Protocol
|
(5)
|
Yes
|
Yes
|
Yes
|
Source Specific Multicast
|
(3)
|
Yes
|
Yes
|
Yes
|
IP Routing
|
HSRP Support for ICMP Redirects
|
(3)
|
Yes
|
Yes
|
Yes
|
Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
|
(2)
|
Yes
|
Yes
|
Yes
|
OSPF Flooding Reduction
|
(2)
|
Yes
|
Yes
|
Yes
|
Management
|
Service Assurance Agent Enhancement
|
(1)
|
Yes
|
Yes
|
Yes
|
Miscellaneous
|
Inter-Autonomous Systems MPLS VPN Support
|
(5)
|
No
|
No
|
No
|
MPLS Traffic Engineering and Enhancements
|
(3)
|
No
|
No
|
No
|
Virtual Switch Interface Master MIB
|
(3)
|
No
|
No
|
No
|
Mobile Wireless
|
General Packet Radio Service Release 1.4
|
(3)
|
No
|
No
|
No
|
Multiservice Applications—DSL
|
CEF Switching for Routed Bridge Encapsulation
|
(5)
|
Yes
|
Yes
|
Yes
|
PPPoE Radius Port Identification
|
(5)
|
Yes
|
Yes
|
Yes
|
Multiservice Applications—Voice
|
Interworking Signaling Enhancements for H.323 and SIP VoIP
|
(5)
|
Yes
|
Yes
|
Yes
|
Quality of Service
|
Class-Based Marking
|
(3)
|
Yes
|
Yes
|
Yes
|
Class-Based Ethernet CoS Matching and Marking
|
(5)
|
Yes
|
Yes
|
Yes
|
Class-Based Policer for the DiffServ AF PHB
|
(5)
|
Yes
|
Yes
|
Yes
|
Class-Based QoS MIB
|
(5)
|
Yes
|
Yes
|
Yes
|
Class-Based Shaping
|
(3)
|
Yes
|
No
|
No
|
Configurable Per ATM-VC Hold Queue Size
|
(5)
|
Yes
|
Yes
|
Yes
|
COPS for RSVP
|
(1)
|
Yes
|
Yes
|
Yes
|
DiffServ Compliant WRED
|
(5)
|
Yes
|
Yes
|
Yes
|
IP DSCP marking for Frame-Relay PVC
|
(5)
|
Yes
|
Yes
|
Yes
|
Network-based Application Recognition
|
(5)
|
Yes
|
Yes
|
Yes
|
Quality of Service Device Manager Command-Line Interface Commands
|
(5)
|
Yes
|
Yes
|
Yes
|
Quality of Service for Virtual Private Networks
|
(5)
|
Yes
|
Yes
|
Yes
|
RSVP Support for Frame Relay
|
(5)
|
Yes
|
Yes
|
Yes
|
RSVP Support for Low Latency Queuing
|
(3)
|
Yes
|
Yes
|
Yes
|
Set ATM CLP Bit
|
(5)
|
Yes
|
Yes
|
Yes
|
Reliability
|
PGM Host
|
(1)
|
No
|
No
|
No
|
Security
|
AAA Broadcast Accounting
|
(1)
|
Yes
|
Yes
|
Yes
|
AAA Server Group Deadtimer
|
(2)
|
Yes
|
Yes
|
Yes
|
Cisco H.323, Version 2, Phase 2
|
(1)
|
Yes
|
Yes
|
No
|
Ecosystem Gatekeeper Interoperability Enhancements
|
(1)
|
No
|
No
|
No
|
Gateway-to-Gatekeeper Billing Redundancy
|
(1)
|
No
|
No
|
No
|
IKE Extended Authentication
|
(1)
|
No
|
Yes
|
Yes
|
Secure Shell, Version 1 Integrated Client
|
(3)
|
No
|
Yes
|
Yes
|
SSH, Version 1 Support for T Train
|
(1)
|
No
|
Yes
|
Yes
|
Wildcard Pre-Shared Key Enhancement
|
(1)
|
No
|
Yes
|
Yes
|
Switching
|
CEF Support for IP Routing between IEEE 802.1Q vLANs
|
(3)
|
Yes
|
Yes
|
No
|
MPLS Class of Service Enhancements
|
(5)
|
No
|
No
|
No
|
MPLS Scalability Enhancements for LSC and ATM LSR
|
(5)
|
No
|
No
|
No
|
Traceroute Enhancement for MPLS
|
(5)
|
No
|
No
|
No
|
Virtual Profile CEF Switched
|
(2)
|
Yes
|
Yes
|
Yes
|
Voice, Data, and Phone Connectivity
|
Answer Supervision Reporting
|
(1)
|
No
|
No
|
No
|
Cisco H.323, Version 2 Phase 2
|
(1)
|
Yes
|
Yes
|
Yes
|
Configurable Timers in H.225
|
(2)
|
No
|
No
|
No
|
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
|
(2)
|
Yes
|
Yes
|
Yes
|
Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
|
(2)
|
No
|
No
|
No
|
H.323 Support for Virtual Interfaces
|
(2)
|
Yes
|
Yes
|
No
|
ISDN Network Side for PRI for ETSI Net5 PRI
|
(1)
|
Yes
|
Yes
|
Yes
|
PRI and BRI QSIG Protocol Support on the Cisco 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200
|
(2)
|
Yes
|
Yes
|
No
|
Transparent Common Channel Signaling
|
(3)
|
Yes
|
Yes
|
Yes
|
Voice Over Frame Relay Configuration Enhancements
|
(2)
|
Yes
|
Yes
|
No
|
WAN
|
CUG Selection Facility Suppress Option
|
(5)
|
Yes
|
Yes
|
Yes
|
Frame Relay ELMI Address Registration
|
(3)
|
Yes
|
Yes
|
Yes
|
Frame Relay Fragmentation with Hardware Compression
|
(5)
|
Yes
|
Yes
|
Yes
|
Frame Relay PVC Interface Priority Queueing
|
(2)
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Diagnostics and Troubleshooting
|
(5)
|
Yes
|
Yes
|
Yes
|
Frame Relay Switching Enhancements
|
(2)
|
Yes
|
Yes
|
Yes
|
Low Latency Queueing for Frame Relay
|
(2)
|
Yes
|
Yes
|
Yes
|
PPP over ATM SVC
|
(3)
|
Yes
|
Yes
|
Yes
|
Related Documentation
The following sections describe the documentation available for Cisco 7200 family routers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and on the Documentation CD-ROM.
Use these release notes with the following documents:
•Release-Specific Documents
•Platform-Specific Documents
•Feature Modules
•Feature Navigator
•Cisco IOS Software Documentation Set
Release-Specific Documents
The following documents are specific to Release 12.1 and are located on Cisco.com and on the Documentation CD-ROM:
•Cross-Platform Release Notes for Cisco IOS Release 12.1
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•Product bulletins, field notices, and other release-specific documents on Cisco.com at:
Technical Documents
•Caveats for Cisco IOS Release 12.1 T
See Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1 T, which contain caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.1 and Cisco IOS Release 12.1 T.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, log in to Cisco.com and click Software Center: Cisco IOS Software: Bug Toolkit: Bug Navigator II. Another option is to go to http://www.cisco.com/support/bugtools/.
Platform-Specific Documents
These documents are available for Cisco 7200 family routers on Cisco.com and on the Documentation CD-ROM:
•Cisco 7206 VXR Installation and Configuration Guide
•Cisco 7204 VXR Installation and Configuration Guide
•Cisco 7206 Installation and Configuration Guide
•Cisco 7204 Installation and Configuration Guide
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco Product Documentation: Core/High-End Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: Core/High-End Routers
Feature Modules
Feature modules describe new features supported by Release 12.1 T and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1 T: New Feature Documentation
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.
Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For Java Script support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM, unless you specifically order the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On Cisco.com and on the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Release 12.1 Documentation Set Contents
Table 9 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form if ordered.
Note You can find the most current Cisco IOS documentation on Cisco.com and on the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
Table 9 Cisco IOS Release 12.1 Documentation Set
Books
|
Major Topics
|
•Cisco IOS Configuration Fundamentals Configuration Guide
•Cisco IOS Configuration Fundamentals Command Reference
|
Configuration Fundamentals Overview
Cisco IOS User Interfaces
Cisco IOS File Management
Cisco IOS System Management
Cisco IOS User Interfaces Commands
Cisco IOS File Management Commands
Cisco IOS System Management Commands
|
•Cisco IOS Bridging and IBM Networking Configuration Guide
•Cisco IOS Bridging and IBM Networking Command Reference, Volume I
•Cisco IOS Bridging and IBM Networking Command Reference, Volume II
|
Using Cisco IOS Software
Overview of SNA Internetworking
Bridging
IBM Networking
|
•Cisco IOS Dial Services Configuration Guide: Terminal Services
•Cisco IOS Dial Services Configuration Guide: Network Services
•Cisco IOS Dial Services Command Reference
|
Preparing for Dial Access
Modem Configuration and Management
ISDN and Signalling Configuration
PPP Configuration
Dial-on-Demand Routing Configuration
Dial-Backup Configuration
Terminal Service Configuration
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Networks
X.25 on ISDN Solutions
Telco Solutions
Dial-Related Addressing Services
Interworking Dial Access Scenarios
|
•Cisco IOS Interface Configuration Guide
•Cisco IOS Interface Command Reference
|
Interface Configuration Overview
Configuring LAN Interfaces
Configuring Serial Interfaces
Configuring Logical Interfaces
|
•Cisco IOS IP and IP Routing Configuration Guide
•Cisco IOS IP and IP Routing Command Reference
|
IP Addressing and Services
IP Routing Protocols
IP Multicast
|
•Cisco IOS AppleTalk and Novell IPX Configuration Guide
•Cisco IOS AppleTalk and Novell IPX Command Reference
|
AppleTalk and Novell IPX Overview
Configuring AppleTalk
Configuring Novell IPX
|
•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide
•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference
|
Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Overview
Configuring Apollo Domain
Configuring Banyan VINES
Configuring DECnet
Configuring ISO CLNS
Configuring XNS
|
•Cisco IOS Multiservice Applications Configuration Guide
•Cisco IOS Multiservice Applications Command Reference
|
Multiservice Applications Overview
Voice
Video
Broadband
|
•Cisco IOS Quality of Service Solutions Configuration Guide
•Cisco IOS Quality of Service Solutions Command Reference
|
Quality of Service Overview
Classification
Congestion Management
Congestion Avoidance
Policing and Shaping
Signalling
Link Efficiency Mechanisms
Quality of Service Solutions
|
•Cisco IOS Security Configuration Guide
•Cisco IOS Security Command Reference
|
Security Overview
Authentication, Authorization, and Accounting (AAA)
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Other Security Features
|
•Cisco IOS Switching Services Configuration Guide
•Cisco IOS Switching Services Command Reference
|
Cisco IOS Switching Services Overview
Cisco IOS Switching Paths
Cisco Express Forwarding
NetFlow Switching
Multiprotocol Label Switching
Multilayer Switching
Multicast Distributed Switching
Virtual LANs
LAN Emulation
|
•Cisco IOS Wide-Area Networking Configuration Guide
•Cisco IOS Wide-Area Networking Command Reference
|
Wide-Area Networking Overview
Configuring ATM
Configuring Frame Relay
Configuring Frame Relay-ATM Interworking
Configuring SMDS
Configuring X.25 and LAPB
|
•Cisco IOS Configuration Guide Master Index
•Cisco IOS Command Reference Master Index
•Cisco IOS Debug Command Reference
•Cisco IOS Dial Services Quick Configuration Guide
•Cisco IOS Software System Error Messages
•New Features in 12.1-Based Limited Lifetime Releases
•New Features in Release 12.1 T
•Release Notes (Release note and caveat documentation for 12.1-based releases and various platforms)
|
|
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
The most current Cisco documentation is available on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•Registered Cisco Direct Customers can order Cisco product documentation from the Networking Products MarketPlace:
http://www.cisco.com/cgi-bin/order/order_root.pl
•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:
http://www.cisco.com/go/subscription
•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).
Documentation Feedback
If you are reading Cisco products documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
For your convenience, many documents contain a response card behind the front cover for submitting your comments by mail. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883
We appreciate your comments.
Obtaining Technical Assistance
The following sections provide sources for obtaining technical assistance from Cisco Systems.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.
•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
Cisco.com registered users who cannot resolve a technical issue by using the TAC online resource can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.
•P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
