Enhanced Test Command
First Published: 12.2(4)TLast Updated: 28, February, 2006The Enhanced Test Command allows you to create named user profile with calling line ID (CLID) or dialed number identification service (DNIS) attribute values. The CLID or DNIS attribute values can be associated with the record that is going out with the user profile thereby providing the RADIUS server with access to CLID or DNIS attribute information for all incoming calls.
History for the Enhanced Test Command Feature
12.2(4)T
This feature was introduced.
12.2(28)SB
This feature was integrated into Cisco IOS Release 12.2(28)SB.
Finding Support Information for Platforms and Cisco IOS Software Images
Use Cisco Feature Navigator to find information about platform support and Cisco IOS software image support. Access Cisco Feature Navigator at http://www.cisco.com/go/fn. You must have an account on Cisco.com. If you do not have an account or have forgotten your username or password, click Cancel at the login dialog box and follow the instructions that appear.
Contents
Feature Overview
The Enhanced Test Command feature introduces two new commands—aaa user profile and aaa attribute—that allow you to create a named user profile with calling line ID (CLID) or dialed number identification service (DNIS) attribute values, which can be associated with a test aaa group command.
Use the aaa attribute command to add CLID or DNIS attribute values to a user profile, which is created by using the aaa user profile command. The CLID or DNIS attribute values can be associated with the record that is going out with the user profile (via the test aaa group command), thereby providing the RADIUS server with access to CLID or DNIS attribute information for all incoming calls.
Benefits
The Enhanced Test Command feature allows you to add a named user profile with CLID or DNIS attribute values and associate the user profile with the test aaa group command. Thus, the attribute values that are added to the user profile go to the RADIUS server, and the RADIUS server can access CLID or DNIS information when it receives a RADIUS record.
Restrictions
The test aaa group command does not work with TACACS+.
Configuration Tasks
See the following sections for configuration tasks for the Enhanced Test Command feature. Each task in the list is identified as either required or optional.
•
Configuring a User Profile (required)
•
•
Configuring a User Profile
To create a named user profile and add CLID or DNIS attribute values, use the following commands beginning in global configuration mode:
Associating a User Profile with a test aaa group Command
To associate a user profile with a test aaa group command, use the following command in privileged EXEC mode:
Verifying Enhanced Test Command
To verify the enhanced test command configurations, use the following privileged EXEC mode:
Configuration Examples
This section provides the following configuration example:
•
User Profile Associated With a test aaa group command Example
The following example shows how to configure the dnis = dnisvalue user profile "prfl1" and associate it with a test aaa group command. In this example, the debug radius command has been enabled and the output follows the configuration.
aaa user profile prfl1aaa attribute dnisaaa attribute dnis dnisvalueno aaa attribute clid! Attribute not found.aaa attribute clid clidvalueno aaa attribute clidexit!! Associate the dnis user profile with the test aaa group command.test aaa group radius user1 pass new-code profile profl1!!!! debug radius output, which shows that the dnis value has been passed to the radius ! server.*Dec 31 16:35:48: RADIUS: Sending packet for Unique id = 0*Dec 31 16:35:48: RADIUS: Initial Transmit unknown id 8 172.22.71.21:1645, Access-Request, len 68*Dec 31 16:35:48: RADIUS: code=Access-Request id=08 len=0068authenticator=1E CA 13 F2 E2 81 57 4C - 02 EA AF 9D 30 D9 97 90T=User-Password[2] L=12 V=*T=User-Name[1] L=07 V="kalki"T=Called-Station-Id[30] L=0B V="dnisvalue"T=Service-Type[6] L=06 V=Login [1]T=NAS-IP-Address[4] L=06 V=10.0.1.81*Dec 31 16:35:48: RADIUS: Received from id 8 172.22.71.21:1645, Access-Accept, len 38*Dec 31 16:35:48: RADIUS: code=Access-Accept id=08 len=0038Additional References
The following sections provide references related to Enhanced Test Command.
Related Documents
Security Configuration Tasks
Cisco IOS Security Configuration Guide, Release 12.4
Security Commands
Cisco IOS Security Command Reference, Release 12.4
Standards
MIBs
None
To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL:
RFCs
Technical Assistance
Command Reference
This section documents new commands only.
aaa attribute
To add calling line identification (CLID) and dialed number identification service (DNIS) attribute values to a user profile, use the aaa attribute command in AAA-user configuration mode. To remove this command from your configuration, use the no form of this command.
aaa attribute {clid | dnis} attribute-value
no aaa attribute {clid | dnis} attribute-value
Syntax Description
clid
Adds CLID attribute values to the user profile.
dnis
Adds DNIS attribute values to the user profile.
attribute-value
Specifies a name for CLID or DNIS attribute values.
Command Default
If this command is not enabled, you will have an empty user profile.
Command Modes
AAA-user configuration
Command History
12.2(4)T
This command was introduced.
12.2(28)SB
This command was integrated into Cisco IOS Release 12.2(28)SB.
Usage Guidelines
Use the aaa attribute command to add CLID or DNIS attribute values to a named user profile, which is created by using the aaa user profile command. The CLID or DNIS attribute values can be associated with the record that is going out with the user profile (via the test aaa group command), thereby providing the RADIUS server with access to CLID or DNIS information when the server receives a RADIUS record.
Examples
The following example shows how to add CLID and DNIS attribute values to the user profile "cat":
aaa user profile cataaa attribute clid clidvalaaa attribute dnis dnisvalRelated Commands
aaa user profile
Creates a AAA user profile.
test aaa group
Associates a DNIS or CLID user profile with the record that is sent to the RADIUS server.
aaa user profile
To create an authentication, authorization, and accounting (AAA) named user profile, use the aaa user profile command in global configuration mode. To remove a user profile from the configuration, use the no form of this command.
aaa user profile profile-name
no aaa user profile profile-name
Syntax Description
Defaults
No default behavior or values.
Command Modes
Global configuration
Command History
12.2(4)T
This command was introduced.
12.2(28)SB
This command was integrated into Cisco IOS Release 12.2(28)SB.
Usage Guidelines
Use the aaa user profile command to create a AAA user profile. Used in conjunction with the aaa attribute command, which adds calling line identification (CLID) and dialed number identification service (DNIS) attribute values, the user profile can be associated with the record that is sent to the RADIUS server (via the test aaa group command), which provides the RADIUS server with access to CLID or DNIS attribute information when the server receives a RADIUS record.
Examples
The following example shows how to configure a dnis = dnisvalue user profile named "prfl1":
aaa user profile prfl1aaa attribute dnisaaa attribute dnis dnisvalueno aaa attribute clid! Attribute not found.aaa attribute clid clidvalueno aaa attribute clidRelated Commands
aaa attribute
Adds DNIS or CLID attribute values to a user profile.
test aaa group
Associates a DNIS or CLID user profile with the record that is sent to the RADIUS server.
test aaa group
To associate a dialed number identification service (DNIS) or calling line identification (CLID) user profile with the record that is sent to the RADIUS server, use the test aaa group command in privileged EXEC mode.
test aaa group {group-name | radius} username password new-code [profile profile-name]
Syntax Description
Command Default
If this command is not enabled, DNIS or CLID attribute values will not be sent to the RADIUS server.
Command Modes
Privileged EXEC
Command History
12.2(4)T
This command was introduced.
12.2(28)SB
This command was integrated into Cisco IOS Release 12.2(28)SB.
Usage Guidelines
Use the test aaa group command to associate a DNIS or CLID named user profile with the record that is sent to the RADIUS server, which can then access DNIS or CLID information when the server receives a RADIUS record.
Note
Examples
The following example shows how to configure a dnis = dnisvalue user profile named "prfl1" and associate it with a test aaa group command:
aaa user profile prfl1aaa attribute dnisaaa attribute dnis dnisvalueno aaa attribute clid! Attribute not found.aaa attribute clid clidvalueno aaa attribute clidexit!! Associate the dnis user profile with the test aaa group command.test aaa group radius user1 pass new-code profile prfl1Related Commands
aaa attribute
Adds DNIS or CLID attribute values to a user profile.
aaa user profile
Creates an AAA user profile.
Glossary
attribute—RADIUS Internet Engineering Task Force (IETF) attributes are the original set of 255 standard attributes that are used to communicate AAA information between a client and a server. Because IETF attributes are standard, the attribute data is predefined and well known; thus all clients and servers who exchange AAA information via IETF attributes must agree on attribute data such as the exact meaning of the attributes and the general bounds of the values for each attribute.
CLID—calling line ID. CLID provides the number from which a call originates.
DNIS—dialed number identification service. DNIS provides the number that is dialed.
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
